Wolf RT484CG User manual

48" Gas Rangetops
Wolf gas rangetops offer that
professional look but give you the
flexibility to use ovens in other locations
in the kitchen. Wolf gas rangetops offer
standard features such as dual brass
surface burners and our signature large
red control knobs. Optional infrared
charbroiler, infrared griddle and French
top give you the freedom to customize
your gas rangetop.
Features
Natural or LP gas models
Classic stainless steel exterior finish
Optional infrared charbroiler, infrared
griddle and French Top configurations
Distinctive red control knobs with chrome
bezels—black knobs optional
Dual brass burners with automatic
reignition at all settings
Porcelain-coated cast iron top grates
Stainless steel drip tray
Features
Model RT488 RT486C RT486G RT484CG RT484DG RT484F
Surface Burners – 16,000 Btu/hr
with 500 Btu/hr
delivered at simmer 8 6 6 4 4 4
Infrared Charbroiler – 16,000 Btu/hr
Infrared Griddle – 18,000 Btu/hr
Double Griddle – 18,000 Btu/hr
French Top – 15,000 Btu/hr
Model numbers are for natural gas rangetops, add (-LP) to the model number for LP gas.
Accessories
101/2" classic stainless steel riser
Black control knobs
Classic stainless steel standard or
island trim
Porcelain-coated cast iron wok grate
Porcelain-coated cast iron S-grates
Hardwood cutting board
(griddle models only)
High altitude conversion kit
Accessories are available through your
Wolf dealer. To obtain local dealer information,
visit the Showroom Locator section of our
website, wolfappliance.com.
Model RT484F
Model RT488
Model RT486C
Model RT486G
Model RT484CG
Model RT484DG
French TopInfrared Charbroiler
This appliance is certified by Star-K to
meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.

48" (1219)
OVERALL WIDTH
20" (508)
WITH
101/2"
RISER
24" (610)
271/4" (692)
OVERALL DEPTH
TO KNOBS
2 3/4" (70)
101/2" (267)
OVERALL
HEIGHT
91/2"
(241)
2"
(51)
COOKING
SURFACE
Installation Notes
A riser is required for installations
against a combustible surface.
A Wolf Pro wall, chimney, island ventila-
tion hood or hood liner is recommended.
Natural gas and LP gas installations
above 8,000' require the high altitude kit.
Unit dimensions may vary by ±
1
/ 8 ".
VENTILATION HOOD
14"
(356)
16"
(406)
LOCATION OF GAS AND
ELECTRICAL SUPPLY CUT-OUT
WITHIN SHADED AREA
THROUGH BOTTOM OF
PLATFORM
TOP VIEW
OF PLATFORM
E G
16"
(406)
3"
(76) BACK WALL
1/2"
(13)
481/4" (1226)
FINISHED ROUGH OPENING WIDTH
3/4" (19) PLATFORM
6"min (152)
TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
30"min (762)
TO 36"max (914)
COUNTERTOP
TO BOTTOM OF
VENTILATION HOOD
30"min (762)
COUNTERTOP
TO COMBUSTIBLE
MATERIALS
36"min (914)
FOR CHARBROILER
2 3/4"
(70)
ISLAND INSTALLATIONS: 12" (305) MINIMUM
CLEARANCE FROM BACK OF RANGETOP TO
COMBUSTIBLE REAR WALL ABOVE COUNTERTOP–
0" (0) TO NON-COMBUSTIBLE MATERIALS
3/4" (19) PLATFORM
91/2" (241)
OPENING
HEIGHT
24" (610)
13" max
(330)
36"
(914)
18"min (457)
TO COUNTERTOP
Specifications
Exterior Finish Classic Stainless Steel
Overall Width 48"
Overall Height
(to cooking surface) 101/2"
Overall Depth 271/4"
Opening Width 481/4"
Opening Height
(to countertop) 91/2"
Opening Depth 24"
Electrical Requirements 110/120 V AC
60 Hz, 15 amp circuit
Shipping Weight 220– 280 lbs
Installation Specifications
Overall Dimensions
48" Gas Rangetops
Dimensions in parentheses are in
millimeters unless otherwise specified.
