Wolf L Series SO30F Guide

WOLF DESIGN GUIDE

Contents
Ovens and Warming Drawers . . . . . . . . . . . . . . . . . . . 3
Cooktops .................................. 29
RangesandRangetops ....................... 53
OutdoorGrills............................... 79
CooktopVentilation .......................... 87
ProVentilation ............................. 101
ShippingWeights........................... 111
WolfWarranties ............................ 112
Features and specifications are subject to change at any time
without notice. Visit wolfappliance.com/specs for the most
up-to-date information.
I PORTANT NOTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specified.
MODEL SO30U

Wolf Built- n Ovens 3
wolfappliance.com/specs
L Series Ovens. Since their introduction a few short years ago, Wolf L series electric ovens have taken the culinary
world by storm—and not just for their stylish cobalt blue interior and 10 cooking modes. Thanks to a Wolf innovation called
dual convection, the L series delivers faster, more consistent results for baking, roasting, broiling—even drying fruits. Wolf
L series ovens are crafted of stainless steel in framed and unframed door styles with tubular handles.
SO30F
30" (762) S NGLE
FRAMED
SO30U
30" (762) S NGLE
UNFRAMED
SO36U
36" (914) S NGLE
UNFRAMED
DO30F
30" (762) DOUBLE
FRAMED
DO30U
30" (762) DOUBLE
UNFRAMED
KEY FEATURES L SERIES OVENS
•Dual convection: two fans for even heat distribution.
•Ten cooking modes, including the bake stone and
dehydration kits for precise, easy-to-use control.
•Rotating control panel.
•Full-extension bottom rack for easier access to foods.
•Spring and damper door hinge for quiet, effortless
opening and closing of the door.

Wolf Built- n Ovens 4
24" (610)
BEHIND FRAME
271/2"
(699)
283/16"
(716)
28"
(711)
297/8"
(759)
24"
(610)
CONDUIT
CHANNEL
OPEN OVEN DOOR
TOP VIEW
3"
(76)
203/4"
(527)
11/4"
(32)
17/8"
(48)
17/8"
(48)
RIGHT SIDE VIEW
261/16"
(662)
INSIDE
SIDE TRIM
24" (610)
BEHIND FRAME
243/8"
(619)
355/8"
(905)
24"
(610)
23" (584)
INSIDE
SIDE TRIM
CONDUIT
CHANNEL
OPEN OVEN DOOR
TOP VIEW
341/8"
(867)
3311/16"
(870)
3"
(76)
173/4"
(451)
11/4"
(32)
17/8"
(48)
17/8"
(48)
RIGHT SIDE VIEW
L Series Ovens
30" (762) SINGLE OVENS
36" (914) SINGLE OVEN

Wolf Built- n Ovens 5
wolfappliance.com/specs
50"
(1270)
297/8"
(759)
24" (610)
BEHIND FRAME
24"
(610)
OPEN OVEN DOOR
CONDUIT
CHANNEL
TOP VIEW
283/16"
(716)
28"
(711)
3"
(76)
203/4"
(527)
11/4"
(32)
17/8"
(48)
17/8"
(48)
RIGHT SIDE VIEW
481/2"
(1232)
INSIDE
SIDE TRIM
L Series Ovens
30" (762) DOUBLE OVENS
Interior Specifications
INTERIOR CAPACITY CU FT (L)
30" (762) Oven 4.5 (127)
36" (914) Oven 4.4 (125)
INTERIOR DI ENSIONS WHD
30" (762) Oven 25" (635) 161/2"(419) 19" (483)
36" (914) Oven 30" (762) 131/4"(337) 19" (483)

Wolf Built- n Ovens 6
SO30-2F/S-TH
30" (762) S NGLE
FRAMED
SO30-2U/S-TH
30" (762) S NGLE
UNFRAMED
DO30-2F/S-TH
30" (762) DOUBLE
FRAMED
DO30-2U/S-TH
30" (762) DOUBLE
UNFRAMED
KEY FEATURES
•Dual convection: two fans for even heat distribution.
•Ten cooking modes, including the bake stone and
dehydration kits for precise, easy-to-use control.
•Full-extension bottom rack for easier access to foods.
•Balanced door hinge system for smooth opening and
closing of the door.
E Series Ovens. The newest addition to the Wolf built-in oven family is a true partner, helping to create great meals
with ease, as well as adding a striking design feature to the kitchen. Smart technology gives the E series 10 cooking
modes, with Wolf’s innovative dual convection in single ovens and in the upper unit of double ovens. E series ovens can be
installed flush with cabinets for a contemporary, integrated look. Wolf E series ovens are crafted of stainless steel in framed
and unframed door styles with tubular handles.
E SERIES OVENS
MODEL SO30-2U/S-TH

Wolf Built- n Ovens 7
wolfappliance.com/specs
E Series Ovens
233/4"(603)
BEHIND FRAME
277/8"
(708)
281/4"
(718)
297/8"
(759)
233/4"
(603)
CONDUIT
CHANNEL
OPEN OVEN DOOR
TOP VIEW
22"
(559)
11/4"
(32)
1"(25)
17/8"
(48)
17/8"
(48)
RIGHT SIDE VIEW
271/16"
(687)
297/8"
(759)
25/8"
(67)
30" (762) SINGLE OVENS
233/4"(603)
BEHIND FRAME
503/8"
(1280)
491/2"
(1257)
281/4"
(718)
297/8"
(759)
233/4"
(603)
OPEN OVEN DOOR
TOP VIEW
25/8"
(67)
22"
(559)
11/4"
(32)
1" (25)
17/8"
(48)
17/8"
(48)
RIGHT SIDE VIEW
297/8"
(759)
CONDUIT
CHANNEL
30" (762) DOUBLE OVENS
Interior Specifications
INTERIOR CAPACITY CU FT (L)
30" (762) Oven 4.5 (127)
INTERIOR DI ENSIONS WHD
30" (762) Oven 25" (635) 161/2"(419) 19" (483)

Wolf Built- n Ovens 8
DIMENSION WILL VARY*
43/4"(121) TYPICAL*
36" (914)
FLOOR TO
COUNTERTOP
*Dimension must accommodate height of oven trim.
NOTE: Location of electrical supply within opening may require additional cabinet depth. Dashed line represents profile of unit.
E
281/2"(724)
OPENING WIDTH
273/16"
(691)
OPENING
HEIGHT
24" (610) min
OPENING DEPTH
E
5"
(127)
4"
(102)
FRONT VIEWSIDE VIEW
FLUSH INSET INSTALLATION (E SERIES ONLY)
For E series ovens, a flush inset installation requires the
oven to be recessed into the cabinet. A minimum 25" (635)
deep cabinet is needed if you want the front of the oven to
be flush with surrounding cabinetry.
ELECTRICAL REQUIRE ENTS
The single oven requires a separate, grounded 4-wire
240/208 V AC, 60 Hz, 30 amp service with its own circuit
breaker. The double oven requires a separate, grounded
4-wire 240/208 V AC, 60 Hz, 50 amp service with its own
circuit breaker. 30" (762) single ovens have a 4' (1.2 m)
conduit, the 36" (910) single oven has a 3' (.9 m) conduit
and double ovens have a 5' (1.5 m) conduit. Total amps for
single ovens is 21 and for double ovens, 37.
Planning nformation
STANDARD INSTALLATION
For ease of installation, Wolf recommends using 33" (838)
wide cabinets with 30" (762) ovens and 39" (991) wide
cabinets with the 36" (914) L series oven. You will need a
minimum 24" (610) of usable cabinet depth. The cabinet
must be able to support 250 lbs (113 kg) for a single oven
and 400 lbs (181 kg) for a double oven.
The oven has a face trim on all four sides and will overlap
stiles and rails. Refer to the chart for overlap dimensions.
30" (762) L Series and E Series Single Oven
STANDARD INSTALLATION
Oven Trim Overlap
OVEN TRI L SERIES E SERIES
Top Overlap 3/16"(5) 5/8"(16)
Bottom Overlap 1/8"(3) 1/8"(3)
Side Overlap 3/4"(19) 3/4"(19)

Wolf Built- n Ovens 9
wolfappliance.com/specs
67" (1702)
TYPICAL*
495/8"
(1260)
OPENING
HEIGHT
E
E
E
281/2"(724)
OPENING WIDTH
E
5"
(127)
4"
(102)
24" (610) min
OPENING DEPTH
*Dimension must accommodate height of oven trim.
NOTE: Location of electrical supply within opening may require additional cabinet depth. Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
36" (914)
FLOOR TO
COUNTERTOP
E
341/2"(876)
OPENING WIDTH
241/16"
(611)
OPENING
HEIGHT
E
5"
(127)
4"
(102)
73/4"(197)
TYPICAL*
DIMENSION WILL VARY*
24" (610) min
OPENING DEPTH
*Dimension must accommodate height of oven trim.
NOTE: Location of electrical supply within opening may require additional cabinet depth. Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
36" (914) L Series Single Oven
STANDARD INSTALLATION
30" (762) L Series and E Series Double Oven
STANDARD INSTALLATION

Wolf Built- n Ovens 10
273/16"
(691)
OPENING
HEIGHT
281/2"
(724) min
FLUSH INSET
HEIGHT
281/2"(724)
OPENING WIDTH
25" (635) min
CABINET DEPTH 303/8"(772) min
FLUSH INSET WIDTH
7/8"(22) TOP CLEAT
7/16"(11)
PLATFORM*
SIDE CLEATS
243/4"
(629) min
FLUSH INSET
DEPTH
1" (25)
*Platform must support 250 lbs (113 kg).
NOTE: Location of electrical supply within opening may require additional cabinet depth. Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
1" (25)
SIDE CLEATS
5"
(127)
4"
(102)
EE
E
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION

Wolf Built- n Ovens 11
wolfappliance.com/specs
495/8"
(1260)
OPENING
HEIGHT
5015/16"
(1294) min
FLUSH INSET
HEIGHT
281/2"(724)
OPENING WIDTH
25" (635) min
CABINET DEPTH 303/8"(772) min
FLUSH INSET WIDTH
7/8"(22) TOP CLEAT
7/16"(11)
PLATFORM*
SIDE CLEATS
243/4"
(629) min
FLUSH INSET
DEPTH
1" (25)
*Platform must support 400 lbs (181 kg).
NOTE: Location of electrical supply within opening may require additional cabinet depth. Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
1" (25)
SIDE CLEATS
5"
(127)
4"
(102)
EE
E
67" (1702)
TYPICAL
30" (762) E Series Double Oven
FLUSH INSET INSTALLATION

Wolf Built- n Ovens 12
24" (610) min
OPENING DEPTH
*Platform must support 250 lbs (113 kg).
NOTE: Location of electrical supply within oven opening may require additional cabinet depth.
FRONT VIEWSIDE VIEW
285/8"(727)
WARMING DRAWER
OPENING WIDTH
281/2"(724)
OVEN OPENING WIDTH
E
E
MICROWAVE
OPENING
273/16"
(691)
11/2"(38)
min
91/8"(232) 3/4"(19)
min
PLATFORM* E
E
5"
(127)
4"
(102)
30" (762) L Series and E Series Single Oven
STANDARD INSTALLATION WITH ICROWAVE AND WAR ING DRAWER

Wolf Built- n Ovens 13
wolfappliance.com/specs
25" (635) min
CABINET DEPTH
303/8"(772) min
FLUSH INSET WIDTH
SIDE CLEATS
243/4"
(629) min
FLUSH
INSET
DEPTH
1"(25)
*Platform must support 250 lbs (113 kg).
NOTE: Location of electrical supply within oven opening may require additional cabinet depth. Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
105/8"
(270)
FLUSH INSET
HEIGHT
91/8"(232)
OPENING HEIGHT
E
1" (25) PLATFORM
285/8"(727)
WARMING DRAWER
OPENING WIDTH
17" (432)
OPENING
HEIGHT
181/2"(470)
FLUSH INSET
HEIGHT
271/2"(699)
STANDARD MICROWAVE
OPENING WIDTH
E
281/2"(724)
E SERIES OVEN
OPENING WIDTH
11/16"(17) TOP CLEAT
9/16"(14)
PLATFORM*
1" (25)
SIDE CLEATS
E
E
5"
(127)
4"
(102)
273/16"
(691)
OPENING
HEIGHT
281/8"
(714) min
FLUSH INSET
HEIGHT
111/16"(43) PLATFORM
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION WITH STANDARD ICROWAVE AND WAR ING DRAWER

Wolf Design Guide 14
25" (635) min
CABINET DEPTH
303/8"(772) min
FLUSH INSET WIDTH
SIDE CLEATS
243/4"
(629) min
FLUSH
INSET
DEPTH
1"(25)
*Platform must support 250 lbs (113 kg).
NOTE: Location of electrical supply within oven opening may require additional cabinet depth. Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
105/8"
(270)
FLUSH INSET
HEIGHT
91/8"(232)
OPENING HEIGHT
E
1" (25) PLATFORM
285/8"(727)
WARMING DRAWER
OPENING WIDTH
187/8"(479)
OPENING
HEIGHT
201/8"
(511)
FLUSH INSET
HEIGHT
271/2"(699)
CONVECTION MICROWAVE
OPENING WIDTH
E
281/2"(724)
E SERIES OVEN
OPENING WIDTH
1/2"(13) TOP CLEAT
9/16"(14)
PLATFORM*
1" (25)
SIDE CLEATS
E
E
5"
(127)
4"
(102)
273/16"
(691)
OPENING
HEIGHT
281/8"
(714) min
FLUSH INSET
HEIGHT
15/8"(41) PLATFORM
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION WITH CONVECTION ICROWAVE AND WAR ING DRAWER

Wolf Built- n Ovens 15
wolfappliance.com/specs
273/16"
(691)
OPENING
HEIGHT
281/8"
(714) min
FLUSH INSET
HEIGHT
281/2"(724)
E SERIES OVEN
OPENING WIDTH
25" (635) min
CABINET DEPTH
303/8"(772) min
FLUSH INSET WIDTH
281/2"(724)
DRAWER MICROWAVE
OPENING WIDTH
E
7/8"(22) TOP CLEAT
9/16"(14)
PLATFORM*
5/8"(16) PLATFORM
SIDE CLEATS
243/4"
(629) min
FLUSH
INSET
DEPTH
11/4"(32)
FOR MICROWAVE
1" (25) FOR
OVEN
AND WARMING
DRAWER
*Platform must support 250 lbs (113 kg.
NOTE: Location of electrical supply within oven opening may require additional cabinet depth. Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
143/4"(375)
OPENING
HEIGHT
153/8"
(391)
FLUSH INSET
HEIGHT
1" (25)
SIDE CLEATS
105/8"
(270)
FLUSH INSET
HEIGHT
91/8"(232)
OPENING HEIGHT
E
1" (25) PLATFORM
285/8"(727)
WARMING DRAWER
OPENING WIDTH
E
E
5"
(127)
4"
(102)
30" (762) E Series Single Oven
FLUSH INSET INSTALLATION WITH DRAWER ICROWAVE AND WAR ING DRAWER

Wolf Microwave Ovens 16
WD24-2U/S
24" (610) UNFRAMED
WD30-2U/S
30" (762) UNFRAMED
KEY FEATURES
•Large-capacity interior.
•Built-in or freestanding option for design versatility
(except drawer models).
•Sensor cooking to monitor and adjust settings.
•Warming feature for gentle heating.
Microwave Ovens. As true cooking instruments, Wolf microwave ovens have features that make fast meals better
meals. Wolf offers both a roomy, powerful standard microwave and a convection model that can microwave, broil and
cook in three convection modes. Stainless steel trim kits are available through your authorized Wolf dealer to match
L series and E series ovens. Drawer microwave models can be conveniently located undercounter, in a corner or below a
Wolf E series oven. They are designed to match the trim style of E series ovens and can be installed in a standard or flush
inset application.
WD30-2F/S
30" (762) FRAMED
WC24
L SER ES TR M
WC24
E SER ES TR M
W24
L SER ES TR M
W24
E SER ES TR M
MODEL MWD30-2U/S
DRAWER ICROWAVES
CONVECTION ICROWAVE
STANDARD ICROWAVE

Wolf Microwave Ovens 17
wolfappliance.com/specs
Drawer Microwaves
233/8"(594)
BEHIND FRAME
151/4"
(387)
237/8"(606)
219/16"(548)
149/16"
(370)
233/8"
(594)
237/8"(606)
POWER
CORD
CHANNEL
11/4"
(32)
411/16"
(119)
13/4"
(44)
161/2"
(419)
24" (610) ICROWAVE
233/8"(594)
BEHIND FRAME
151/4"
(387)
297/8"(759)
281/8"(714)
POWER
CORD
CHANNEL
11/4"
(32)
411/16"
(119)
2"
(51)
149/16"
(370)
233/8"
(594)
161/2"
(419)
297/8"(759)
30" (762) ICROWAVE

Wolf Microwave Ovens 18
Convection Microwave
355/8"(905) FOR 36" TRIM
297/8"(759) FOR 30" TRIM
243/4"(629)
FREESTANDING WIDTH
147/8"
(378)
FREE-
STANDING
HEIGHT
197/8"
(505)
TRIM
HEIGHT
19" (483)
L SERIES TRI
297/8"(759) FOR 30" TRIM
267/8"(683) FOR 27" TRIM
243/4"(629)
FREESTANDING WIDTH
147/8"
(378)
FREE-
STANDING
HEIGHT
197/8"
(505)
TRIM
HEIGHT
19" (483)
E SERIES TRI
297/8"(759)
30" (762) TRIM WIDTH
24" (610)
FREESTANDING WIDTH
133/8"
(340)
FREE-
STANDING
HEIGHT
181/4"
(464)
TRIM
HEIGHT
19" (483)
L SERIES TRI
24" (610)
FREESTANDING WIDTH
133/8"
(340)
FREE-
STANDING
HEIGHT
181/4"
(464)
TRIM
HEIGHT
19" (483)
297/8"(759) FOR 30" TRIM
267/8"(683) FOR 27" TRIM
E SERIES TRI
Standard Microwave

Wolf Microwave Ovens 19
wolfappliance.com/specs
ELECTRICAL REQUIRE ENTS
Wolf microwave ovens require a separate, grounded
120 V AC, 60 Hz power supply. The service should have its
own 15 amp circuit breaker. A grounded 3-prong recepta-
cle should be located within reach of the power cord.
Planning nformation
Wolf drawer microwave ovens can be installed in a
standard or flush inset application. A flush inset installa-
tion requires the microwave to be recessed into the
cabinet. Refer to the illustrations on the following pages
for minimum cabinet dimensions for your specific installa-
tion. The cabinet must be able to support 125 lbs (57 kg).
n standard applications, the drawer microwave trim will
overlap stiles and rails and will match the overlaps of
E series ovens. Refer to the chart for overlap dimensions.
Wolf convection and standard microwave ovens can be
used freestanding or built-in with optional trim kit available
through your authorized Wolf dealer. For local dealer infor-
mation, visit the find a showroom section of our website,
wolfappliance.com.
n a freestanding application, allow 2" (51) of airflow space
on the top, rear and both sides. Built-in opening dimen-
sions accommodate air flow space.
n built-in applications, convection and standard
microwaves with trim kit will overlap stiles and rails and
will match the overlaps of L series and E series ovens.
Refer to the chart for overlap dimensions.
Interior Specifications
INTERIOR CAPACITY CU FT (L)
Drawer Microwave 1.0 (28)
Convection Microwave 1.5 (42)
Standard Microwave 2.0 (57)
INTERIOR DI ENSIONS WHD
Drawer Microwave 173/8"(441) 57/8"(149) 171/8"(435)
Convection Microwave 161/8"(410) 95/8"(244) 161/8"(410)
Standard Microwave 173/8"(441) 101/2"(267) 185/8"(473)
icrowave Trim Overlap
DRAWER ICROWAVE 24" ODEL 30" ODELS
Top Overlap 3/8"(10) 3/8"(10)
Bottom Overlap 1/8"(3) 1/8"(3)
Side Overlap 1" (25) 3/4"(19)
27" (686) E SERIES TRI CONVECTION STANDARD
Top Overlap 13/16"(21) 7/16"(11)
Bottom Overlap 13/16"(21) 13/16"(21)
Side Overlap 5/8"(16) 13/16"(21
30" (762) L AND E SERIES TRI CONVECTION STANDARD
Top Overlap 1/4"(6) 7/16"(11)
Bottom and Side Overlap 13/16"(21) 13/16"(21)
36" (914) L SERIES TRI CONVECTION STANDARD
Top Overlap 5/16"(8) NA
Bottom and Side Overlap 13/16"(21) NA

Wolf Microwave Ovens 20
31/2"(89) x 2"(51)
ANTI-TIP BLOCK
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
24" (610) min
CABINET DEPTH
36" (914)
FLOOR TO
COUNTERTOP
231/2"(597) min
OPENING DEPTH
2" (51)
143/4"(375)
OPENING
HEIGHT
221/8"(562)
OPENING WIDTH
PLATFORM
E
31/2"(89) x 2"(51)
ANTI-TIP BLOCK
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
25" (635) min
CABINET DEPTH
36" (914)
FLOOR TO
COUNTERTOP
SIDE CLEATS
243/4"
(629) min
FLUSH INSET
DEPTH
11/4"(32)
TOP VIEW
143/4"(375)
OPENING
HEIGHT
19/16"(38)
153/4"
(400)
FLUSH INSET
HEIGHT
243/8"(619)
FLUSH INSET WIDTH
221/8"(562)
OPENING WIDTH
E
11/8"(29)
SIDE CLEATS
3/8"(10) PLATFORM
5/8"(16)
TOP CLEAT
24" (610) Drawer Microwave
STANDARD INSTALLATION
FLUSH INSET INSTALLATION
Other manuals for L Series SO30F
4
This manual suits for next models
4
Table of contents
Other Wolf Oven manuals

Wolf
Wolf M Series User manual

Wolf
Wolf e Series User manual

Wolf
Wolf L Series SO30U Instructions for use

Wolf
Wolf E Series DO30-2F/S User manual

Wolf
Wolf e Series User manual

Wolf
Wolf BAKE STONE Owner's manual

Wolf
Wolf e Series User manual

Wolf
Wolf WGCO100S User manual

Wolf
Wolf L Series SO30U Guide

Wolf
Wolf CT15E/S Guide
Popular Oven manuals by other brands

Sharp
Sharp SSC0586DS quick start guide

Electrolux
Electrolux EOB2400 user manual

Garland
Garland moisture+ MP-GD-10-S Service manual

Oster
Oster TSSTTVFDDG user manual

ETNA
ETNA OM316MZ Instructions for use

Electrolux
Electrolux E30EW85GPS - Icon 30" Professional Series Electric Double... Specifications and installation
