WOLFF 355 B Manual

Slewing tower crane
English
English
WOLFF 355 B
Technical information
TI_2017-3
WOLFF 355 B

Published by
WOLFFKRAN GmbH
Austraße 72
74076 Heilbronn
Germany
Phone [phone]
Fax [phone]
www.wolffkran.com
[email protected]
Copyright
This documentation including all of its subsections is protected by copyright laws.
Any type of use or modification outside of the stringent limits of the copyright laws without permission
of WOLFFKRAN GmbH is prohibited and subject to penalties.
This applies particularly for copying, translation, microfilming and storage and processing in electronic
systems.
At the time of printing, the information, data, illustrations and notes comprised in this manual were up-
to-date.
Subject to change of design, error and typos.
Stand: 03/2017
2 TI_2017-3WOLFF 355 B

Table of contents
Schedule drawing1 7
Schedule drawing WOLFF 355 B1.1 7
Load carrying capacities2 8
Table of load carrying capacity WOLFF 355 B (1 fall operation)2.1 9
Table of load carrying capacities (kg) in meter intervals, WOLFF 355 B (1 fall operation)2.2 10
Table of load carrying capacity WOLFF 355 B (2 fall operation)2.3 11
Table of load carrying capacities (kg) in meter intervals, WOLFF 355 B (2 fall operation)2.4 12
Table of load carrying capacity WOLFF 355 B (1 fall operation, BOOST)2.5 13
Table of load carrying capacities (kg) in meter intervals, WOLFF 355 B (1 fall operation,2.6
BOOST)
14
Table of load carrying capacity WOLFF 355 B (2 fall operation, BOOST)2.7 15
Table of load carrying capacities (kg) in meter intervals, WOLFF 355 B (2 fall operation,2.8
BOOST)
16
Tower combinations3 17
Tower combinations on foundation (slewing section with TV 20 - connection)3.1 18
Tower combinations on foundation (slewing section with HT 23 - connection)3.2 33
Tower combinations on cross frame (slewing section with TV 20 - connection)3.3 42
Tower combinations on cross frame element (slewing section with TV 20 - connection)3.4 53
Tower combinations on mobile cross frame (slewing section with TV 20 - connection)3.5 56
Tower combinations on undercarriage (slewing section with TV 20 - connection)3.6 66
Foundation loads / central ballast weights / corner loads in compliance with EN 14439 /4
EN 13001
69
Foundation loads slewing section with TV 20 connection (jib 30 m - 40 m)4.1 71
Foundation loads slewing section with TV 20 connection (jib 45 m - 50 m)4.2 72
Foundation loads slewing section with TV 20 connection (jib 55 m - 60 m)4.3 73
Foundation loads slewing section with HT 23 connection (jib 30 m - 40 m)4.4 74
Foundation loads slewing section with HT 23 connection (jib 45 m - 50 m)4.5 75
Foundation loads slewing section with HT 23 connection (jib 55 m - 60 m)4.6 76
Operating speeds5 77
Out of service positions6 81
Table of contents
3TI_2017-3 WOLFF 355 B

Package list7 83
Package list 355 B7.1 83
Assembly weights8 85
Counterweight blocks8.1 85
Counterweight block, 6.2 t8.1.1 86
Counterweight block, 8.0 t8.1.2 87
Counterweight block, 8.0 t8.1.3 88
Counterweight block, 6.2 t with edge protection8.1.4 89
Counterweight block, 8.0 t with edge protection8.1.5 91
Counterweight block, 8.0 t with edge protection8.1.6 92
Total weight jib assembly8.2 93
Assembly weight slewing section8.3 94
Assembly weight cross frame8.4 95
Assembly weights traveling cross frame8.5 96
Assembly weight cross frame elements8.6 97
Assembly weight undercarriage8.7 98
Required hook height for mobile cranes8.8 99
Assembly diagrams9 100
Jib attachment diagram9.1 100
Jib attachment diagram 60 m to 45 m9.1.1 101
Jib attachment diagram 40 m to 30 m9.1.2 102
Counterjib lifting diagram9.2 103
Jib brace diagram9.3 105
Arrangement of standard railings9.4 108
Standard railings (NG) and accessories9.4.1 108
Arrangement of standard railings9.4.2 109
Support blocks for brace9.5 111
Suitable climbing devices10 113
Outer climbing devices10.1 114
Outer climbing device KWH 20.6 / KWH 20.6.1 / KWH 20.6.210.1.1 115
Outer climbing device KWH 23 / KWH 23.110.1.2 116
Inner climbing devices10.2 117
Inner climbing device KSH 20 SH10.2.1 118
Table of contents
4 TI_2017-3WOLFF 355 B

Inner climbing device KSH 23/ KSH E 2310.2.2 121
Arrangement of counterweight blocks11 125
5TI_2017-3 WOLFF 355 B

1 Schedule drawing
1.1 Schedule drawing WOLFF 355 B
x
[X] max. hook height above ground
Data WOLFF 355B
Item Data
Crane type BGL GROUP C.0.11.0355
Design Overhead travelling crane with top slewing luffing
jib, with climbing feature
Type of setup Stationary or traveling
Basis of calculation EN
Load moment max. 5100 kNm
Hoist winch Hw 28110FU / Hw 28132FU
7
1 Schedule drawing
TI_2017-3 WOLFF 355 B

2 Load carrying capacities
!
NOTICE
WOLFF-Boost
With the WOLFF-Boost function, the load is allowed to exceed the load torque
range specified for the lifting capacities by up to 10%. This is, however, sub-
ject to the restriction that hoisting gear and trolley drive (trolley crane)
respectively hoisting gear and derricking gear (luffing crane) must only be
moved alternatingly.
8
2 Load carrying capacities
TI_2017-3WOLFF 355 B

2.1 Table of load carrying capacity WOLFF 355 B (1 fall operation)
14.0 t
Operating radius
[m]
20.0 25.0 30.0 35.0 40.0 45.0 50.0 55.0 60.0
JL
[m]
60 5.4 - 27.0 14.0 14.0 12.2 9.8 8.1 6.7 5.6 4.7 4.0 LCC
[t]
55 5.0 - 28.0 14.0 14.0 12.8 10.5 8.7 7.3 6.2 5.3
50 4.5 - 29.5 14.0 14.0 13.7 11.3 9.5 8.1 7.0
45 4.1 - 31.0 14.0 14.0 14.0 12.2 10.4 9.0
40 3.6 - 33.5 14.0 14.0 14.0 13.4 11.6
35 3.2 - 34.5 14.0 14.0 14.0 13.8
30 2.7 - 30.0 14.0 14.0 14.0
JL Jib length
LCC Load carrying capacity
The load carrying capacity is related to a tower height of 40.5 m. Tower heights greater than that reduce
the maximum load carrying capacity by the weight of the additional hoisting ropes (one fall operation =
3.25 kg per meter of the hook range).
9
2 Load carrying capacities
TI_2017-3 WOLFF 355 B

2.2 Table of load carrying capacities (kg) in meter intervals, WOLFF 355 B
(1 fall operation)
Operating radius Jib length [m]
[m] 30 35 40 45 50 55 60
26 14000 14000 14000 14000 14000 14000 14000
27 14000 14000 14000 14000 14000 14000 14000
28 14000 14000 14000 14000 14000 14000 13350
29 14000 14000 14000 14000 14000 13390 12750
30 14000 14000 14000 14000 13700 12800 12200
31 14000 14000 14000 13170 12280 11650
32 14000 14000 13500 12670 11780 11160
33 14000 14000 13030 12190 11310 10690
34 14000 13780 12580 11740 10870 10260
35 13800 13400 12200 11300 10500 9800
36 12970 11770 10920 10060 9450
37 12600 11390 10540 9690 9090
38 12250 11040 10180 9340 8740
39 11920 10700 9840 9000 8410
40 11600 10400 9500 8700 8100
41 10080 9210 8380 7790
42 9790 8920 8090 7510
43 9510 8640 7820 7230
44 9250 8370 7560 6980
45 9000 8100 7300 6700
46 7880 7070 6490
47 7640 6840 6260
48 7420 6620 6050
49 7210 6400 5840
50 7000 6200 5600
51 6010 5440
52 5820 5260
53 5640 5080
54 5470 4910
55 5300 4700
56 4580
57 4430
58 4280
59 4140
60 4000
10
2 Load carrying capacities
TI_2017-3WOLFF 355 B
