Wood Stone FIRE DECK Series User manual

Toll Free 800.988.8103
Tel [phone]
Fax [phone]
www.woodstone-corp.com
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
FIRE DECK SERIES
Stone Hearth Oven
Gas-Fired, Gas/Wood Combination Models
FIRE DECK 6045 WS-FD-6045
DOC NO M0038.13 REVISED DECEMBER 2019
Installation and
Operation Manual

Fire Deck 6045
Installation and Operation Manual
PG 2 OF 32
M0038.13 DECEMBER 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
TABLE OF CONTENTS
TABLE OF CONTENTS
Fire Deck 6045� � � � � � � � � � � � � � � � � 3
Cautions & Warnings � � � � � � � � � � � � � 4
FD-6045 Specifications� � � � � � � � � � � � 6
Unloading & Moving the Oven � � � � � � � � 7
Optional Temp Caster Install � � � � � � � � � 8
Placing & Installation � � � � � � � � � � � � � 9
Installation Clearances � � � � � � � � � � � �10
Facade Guidelines � � � � � � � � � � � � � � �11
Facade Requirements � � � � � � � � � � � � �12
Venting � � � � � � � � � � � � � � � � � � � � � �13
Hood Specifications � � � � � � � � � � � � � �14
Gas Specifications � � � � � � � � � � � � � � �15
Electrical Specifications� � � � � � � � � � � �17
Controller � � � � � � � � � � � � � � � � � � � �18
Initial Start-Up� � � � � � � � � � � � � � � � � �19
Daily Oven Operation � � � � � � � � � � � � �20
Flame Height Control � � � � � � � � � � � � �21
Wood Burning� � � � � � � � � � � � � � � � � �22
Daily Maintenance & Thermal Cleaning � �23
Troubleshooting Guide� � � � � � � � � � � � �24
Fuelwood Facts� � � � � � � � � � � � � � � � �25
Decorative Flame Burner � � � � � � � � � � �26
Electrical Diagrams � � � � � � � � � � � � � �27
Interlock Diagram � � � � � � � � � � � � � � �30
Limited Warranty � � � � � � � � � � � � � � � �31

INSTALLATION AND OPERATION MANUAL FOR THE
WOOD STONE FIRE DECK
STONE HEARTH COOKING EQUIPMENT
WS-FD-6045-(RFG)-(L, R, LR)-(IR)-(W)-(NG, LP, HLP) MODELS
GAS AND GAS/WOOD MODELS
ADDITIONAL COPIES AVAILABLE UPON REQUEST
Shown: Right-hand configuration
Fire Deck 6045
Installation and Operation Manual
PG 3 OF 32
M0038.13 DECEMBER 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
FIRE DECK 6045
Shown: FD-6045-RFG-R-IR

WOOD STONE WS-FD-6045 FIRE DECK INSTALLATION AND OPERATING INSTRUCTIONS
IMPORTANT: Consult your local gas supplier for a statement outlining a procedure to be followed in the
event you smell gas. Post the statement in a prominent location.
CAUTION: Disconnect power to the oven before servicing or cleaning.
No attempt should be made to operate this appliance during a power failure.
READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE
Please read this entire manual before you install the oven. Failure to follow instructions may result in property
damage, bodily injury or even death. Contact your local building or fire officials about restrictions and installation
inspection in your area.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Additional copies of this manual at woodstone-corp�com�
For prompt responses to service/maintenance questions, call us at @ 1-800-988-8103�
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids in the vicinity of
this or any other appliance.
ESURE DE SÉCURITÉ: Ne pas entreposer ni utiliser de’essence ni autres vapeurs ou liquides
inflammables à proximté de cet appareil ou de tout autre appareil.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operation and maintenance instructions thoroughly before
installing or servicing this equipment.
AVERTISSEMENT: L’installation, le réglage, la modification, la réparation ou l’entretien incorrect de
cet appareil peut causer des dommages matériels, des blessures ou la mort. Lire attentivement les
instructions d’installation, de fonctionnement et d’entretien avant de procéder à son installation ou
entretien.
Always keep the area under and around this appliance free and clear of any and all combustible materials.
Fire Deck 6045
Installation and Operation Manual
PG 4 OF 32
M0038.13 DECEMBER 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
CAUTIONS & WARNINGS

Wood Stone ovens
have been tested and approved by Intertek Testing Services and
conform to ANSI Z83.11, UL 2162, UL 737 and CGA 2.17;
are certified to CSA 1.8, ULC/ORD 2162 and ULC S627;
and to NSF/ANSI 4.
SAVE THE INSTRUCTIONS
This product must be installed by a licensed plumber or gas fitter when installed within the Commonwealth
of Massachusetts.
It is recommended that this oven be installed, maintained and
serviced by authorized professionals.
A MAJOR CAUSE OF OVEN RELATED FIRES IS A
FAILURE TO MAINTAIN REQUIRED CLEARANCES
TO COMBUSTIBLE MATERIAL. IT IS OF UTMOST
IMPORTANCE THAT THIS OVEN BE INSTALLED ONLY
IN ACCORDANCE WITH THESE INSTRUCTIONS.
ANSI Z83.11
CSA 1.8
ANSI/NSF 4
Fire Deck 6045
Installation and Operation Manual
PG 5 OF 32
M0038.13 DECEMBER 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
CAUTIONS & WARNINGS

Air intake: Do not
facade or cover over
Must be left
removable for service
Unit Shipping Weight:
3,200 lbs.
UTILITIES SPECIFICATIONS
Gas
3/4 inch FNPT gas inlet
160,000 BTU/hr Natural Gas (NG)
OR
160,000 BTU/hr Propane (LP)
Optional Decorative Flame adds
15,000 BTU/hr to total rated input
Maximum gas inlet pressure:
1/2 psi (14 inches W�C�)
Venting
The Fire Deck 6045 must be vented using a Listed Type
1 exhaust hood, or a hood constructed and installed
in accordance with NFPA 96 and all relevant local and
national codes� The oven must be vented in accordance
with all relevant local and national codes, and in a
manner acceptable to the authority having jurisdiction�
Important: Models with -W in the model number must
be vented as a solid fuel appliance�
Electrical
120 VAC, 1�1 A, 50/60 Hz
240 VAC� 1 A, 60 Hz (optional)
Electrical connection always on the
left side of the oven� Gas connection
on same side as Radiant Burner (left
or right option)�
Refer to data plate when installing�
NOTES
This oven is available in a left or
right side burner configuration� Gas
connections will be on the same side of
the oven as the radiant flame� Electrical
connections are always on the left�
Shown: Right side burner configuration�
NOTE: Using the temporary optional
casters will add 3" to the height of
the oven, resulting in a 77-1/2" total�
However, the 3-3/4" vent shield on
top can be removed temporarily if
necessary�
Fire Deck 6045
Installation and Operation Manual
PG 6 OF 32
M0038.13 DECEMBER 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
FD-6045 SPECIFICATIONS
Side view
REV:
LEGEND:
PART #:
FD-6045-RFG-R-IR
6045 Fire Deck
General Arrangement
5/10/2018 lucasm 3
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-6045_General_Arrangement-3.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 1.1A, 50/60Hz
GAS INLET: 3/4" NPT
160,000 BTU, NG (RFG-IR)
160,000 BTU, LP (RFG-IR)
1 of 1
AIR INTAKE
G
G
1"
30mm
6"
150mm
17 3/4"
450mm
13 1/4"
340mm
29 3/4"
760mm
48 1/4"
1230mm
3"
80mm
10"
250mm 16 3/4" 430mm
34"
860mm
2 1/4"
60mm
40 1/2"
1030mm
3 3/4"
100mm
R11 1/2"
290mm
Cleaning Position
Swing Radius
43"
1090mm
45 1/4"
1150mm
7 1/2"
190mm
37 1/2"
950mm
59 3/4"
1520mm
52 3/4"
1340mm
5 3/4"
150mm
9 3/4"
250mm
33 3/4"
860mm
9 3/4"
250mm 14"
360mm
78 1/4"
1990mm
48"
1220mm
25 1/2"
650mm
4"
100mm
10 1/4"
260mm
23 3/4"
600mm 24 3/4" 630mm
Plan view
Front view
REV:
LEGEND:
PART #:
FD-6045-RFG-R-IR
6045 Fire Deck
General Arrangement
5/10/2018 lucasm 3
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-6045_General_Arrangement-3.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 1.1A, 50/60Hz
GAS INLET: 3/4" NPT
160,000 BTU, NG (RFG-IR)
160,000 BTU, LP (RFG-IR)
1 of 1
AIR INTAKE
G
G
1"
30mm
6"
150mm
17 3/4"
450mm
13 1/4"
340mm
29 3/4"
760mm
48 1/4"
1230mm
3"
80mm
10"
250mm 16 3/4" 430mm
34"
860mm
2 1/4"
60mm
40 1/2"
1030mm
3 3/4"
100mm
R11 1/2"
290mm
Cleaning Position
Swing Radius
43"
1090mm
45 1/4"
1150mm
7 1/2"
190mm
37 1/2"
950mm
59 3/4"
1520mm
52 3/4"
1340mm
5 3/4"
150mm
9 3/4"
250mm
33 3/4"
860mm
9 3/4"
250mm 14"
360mm
78 1/4"
1990mm
48"
1220mm
25 1/2"
650mm
4"
100mm
10 1/4"
260mm
23 3/4"
600mm 24 3/4" 630mm
REV:
LEGEND:
PART #:
FD-6045-RFG-R-IR
6045 Fire Deck
General Arrangement
5/10/2018 lucasm 3
DWN BY:
SHEET:
Bellingham, WA 360/650-1111 www.woodstone-corp.com
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2°
UNLESS NOTED OTHERWISE
\\woodstone\dfs\CAD\0 Pn\WS Top Level\FD-Fire_Deck\FD-6045_General_Arrangement-3.dft
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS
PROHIBITED
AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT
MAY REQUIRE US TO CHANGE SPECIFICATIONS
WITHOUT NOTICE.
DATE:
G
120VAC, 1.1A, 50/60Hz
GAS INLET: 3/4" NPT
160,000 BTU, NG (RFG-IR)
160,000 BTU, LP (RFG-IR)
1 of 1
AIR INTAKE
G
G
1"
30mm
6"
150mm
17 3/4"
450mm
13 1/4"
340mm
29 3/4"
760mm
48 1/4"
1230mm
3"
80mm
10"
250mm 16 3/4" 430mm
34"
860mm
2 1/4"
60mm
40 1/2"
1030mm
3 3/4"
100mm
R11 1/2"
290mm
Cleaning Position
Swing Radius
43"
1090mm
45 1/4"
1150mm
7 1/2"
190mm
37 1/2"
950mm
59 3/4"
1520mm
52 3/4"
1340mm
5 3/4"
150mm
9 3/4"
250mm
33 3/4"
860mm
9 3/4"
250mm 14"
360mm
78 1/4"
1990mm
48"
1220mm
25 1/2"
650mm
4"
100mm
10 1/4"
260mm
23 3/4"
600mm 24 3/4" 630mm

USING A FORKLIFT.
The Wood Stone Fire Deck 6045 weighs approximately 3,200 lbs� and is top-heavy�
Use a forklift with adequate fork lengths and lifting capacity� When using a forklift, always use the forklift pockets� Lifting the oven
any other way with a forklift may result in damage� Use extreme caution and make sure that the forks extend all the way through the
pockets provided� Fork length must be at least 5' long� If it is necessary to approach the oven from the front, be sure the mast does
not contact the mantle (shelf)�
There are fork pockets at the front and sides of the oven�
Once the oven is on a smooth, flat floor it can be rolled on its optional heavy-duty, temporary shipping Casters (details next page)�
USING A PALLET JACK.
The oven may also be moved with a Pallet Jack using the front or rear fork pockets only� Once the oven is on a smooth, flat floor it
can be rolled to its final position� DO NOT ATTEMPT TO MANUALLY ROLL THE OVEN UP OR DOWN A RAMP OR INCLINE. Do not
position yourself between the moving oven and an immovable object or surface such as a wall or door frame�
DO NOT TURN THE OVEN ON ITS SIDE!.
Moving a Wood Stone oven can present interesting challenges to even the most
experienced riggers� Make sure to secure the proper equipment and make safety
your first priority� Please don’t hesitate to call the factory for technical support�
Shown:
Left-hand configuration
CAUTION HOT PRUDENCE CHAUD
USING A CRANE.
If you are planning to use a crane to unload the oven,
specify a flatbed truck delivery.
Use the pickeyes provided on the sides of the oven to lift the oven
with a crane� The spreader bar should be of a sufficient length to keep
the sling from contacting the oven, and oriented as shown in fig� 1�
DELIVERY NOTE.
The customer will receive an Oven Shipping Notification when
the oven leaves the Wood Stone factory� This will include a
PRO# and a trucking company contact number� Wood Stone
recommends that you confirm the delivery date/time with the
trucking company before committing to heavy equipment and/
or labor� Our goal is a smooth and safe delivery�
Pickeye
Capacity per
Beam
4,000 lbs
Front Forklift / Pallet Jack Pockets Side Forklift Pockets
Minimum Required
Forklift Capacities
5' FORKS MINIMUM
Model
Lifting from
Front, Rear or Sides
FD-6045 6,000 lbs
WARNING
Use caution
near mantle
Fire Deck 6045
Installation and Operation Manual
PG 7 OF 32
M0038.13 DECEMBER 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
UNLOADING & MOVING THE OVEN
LOAD
Orient Spreader Bar
as shown in fig. 1
50°MIN Angle
Pickeye
Beam
fig. 1

INSTRUCTIONS FOR INSTALLING AND REMOVING OPTIONAL OVEN CASTERS
The Fire Deck 6045 weighs approximately 3,200 lbs.
Do not attempt to move the oven over any type of grade or sloped surface when using the Casters or Pallet Jack.
WARNING: Failure to follow these instructions may result in severe injury or death.
If you have any questions call Wood Stone at 800.988.8103.
NOTE: The casters will add 3" to the total height of the oven, for a total of 81-1/4".
The 3-3/4" Vent Shield on top can be removed temporarily if necessary.
Shipping Casters are for moving the oven only. THEY MUST BE REMOVED ONCE THE OVEN IS IN PLACE.
3Once at final destination, use two scissor jacks (or
pallet jack) to lift the one side of the oven by placing
one jack under each caster assembly�
Raise the oven just high enough so the wheels clear
the floor�
Unbolt each Caster and remove it�
Note: Casters are for moving oven only� They must
be removed once the oven is in place�
4Lower the oven back to the ground�
Remove the Self-Drilling Screw and slide the rest of
the Caster Assembly out of the fork pocket�
Install Fork Pocket Covers
Repeat steps 3and 4for the other side of the oven�
This oven is designed to be sealed to the floor upon
installation using a silicone sealant acceptable to the
local health official� See the Placing & Installation
section of this manual for additional instructions�
Caster Bolts
2Insert a Caster Assembly into each of the side
fork pockets and secure it to the oven with a
Self-Drilling Screw and washer�
Install the screw through the Mounting Tab�
Once the Caster Assemblies are installed, lower
the oven�
It may then be rolled over a smooth flat
surface to its final destination�
Self-Drilling Screw
& Washer through
Mounting Tab
1 Use a forklift (or pallet jack) to raise the oven
using the front or rear forklift pockets�
Fire Deck 6045
Installation and Operation Manual
PG 8 OF 32
M0038.13 DECEMBER 2019
OPTIONAL TEMP CASTER INSTALL

Stainless Steel Toe Kick
Fork pocket covers
(Both sides & rear)
Fork pocket covers
(Both sides & rear)
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
REAR FORK POCKETS
Pocket covers
arrive
fastened in
temporary UP
position.
Unfasten, lower
over each fork
pocket, and
refasten.
L1217
ATTENTIONINSTALLER
ForkPocket Cover
MUSTbe installed
overpocket for oven
tooperate properly.
L1217
ATTENTIONINSTALLER
ForkPocket Cover
MUSTbe installed
overpocket for oven
tooperate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTIONINSTALLER
ForkPocket Cover
MUSTbe installed
overpocket for oven
tooperate properly.
L1217
ATTENTIONINSTALLER
ForkPocket Cover
MUSTbe installed
overpocket for oven
tooperate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
GAS INLET SIDE FORK POCKETS
Unfasten,
place one cover
over each fork
pocket, and
refasten.
Two pocket covers
will arrive fastened in
temporary UP
position above front-
most fork pocket.
L1217
ATTENTIONINSTALLER
ForkPocket Cover
MUSTbe installed
overpocket for oven
tooperate properly.
L1217
ATTENTIONINSTALLER
ForkPocket Cover
MUSTbe installed
overpocket for oven
tooperate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
L1217
ATTENTION INSTALLER
Fork Pocket Cover
MUST be installed
over pocket for oven
to operate properly.
NON-GAS INLET SIDE FORK POCKETS
Pocket covers
arrive
fastened in
temporary UP
position.
Unfasten, lower
over each fork
pocket, and
refasten.
Note: Additional
Tek screws
supplied in
hardware kit.
• •• • ••••
ÜÜ
• •• •
ÜÜÜÜ
• •• • ••••
ÜÜ
FORK POCKET
COVER
INSTALLATION
PLACING THE OVEN
The oven must be installed on a flat level surface� The weight of the oven is carried by the full perimeter of the oven stand� If it is
necessary to shim the oven for leveling purposes, it is critical that the shim material be metal, and that the shims are installed in such
a way that the full perimeter of the stand is solidly supported� Any gaps created by shimming between the oven and the floor must be
sealed (using a silicone sealant acceptable to the local health official) to prevent airflow issues beneath the oven� Failure to solidly
support the full perimeter of the oven stand can result in costly damage to the oven and will void the warranty. The floor
design and construction must be adequate to handle the weight of the oven�
See woodstone-corp.com for floor loading information�
TOE KICK AND FORK POCKET COVERS
Once the oven is in place, the Toe Kick must be installed along the front, and the Fork Pockets on the sides and back of the oven
using the screws provided� The area under the oven must be enclosed in order to prevent pests from entering this space and to
prevent air flow issues which can detrimentally effect burner operation�
FACADE READY OVENS: If the lower front of the oven is shipped facade ready, the toe kick will not be included� Instead, fork pocket
covers and pre-cut blocks of cement board to cover the pocket covers will be included�
If the sides and/or rear of the oven is shipped facade ready, the Fork Pocket Covers will not be included� Pre-cut blocks of cement
board or other facade material will be shipped instead of the Fork Pocket Covers� The blocks must be inserted into the fork pockets
before the oven facade is put in place�
Fire Deck 6045
Installation and Operation Manual
PG 9 OF 32
M0038.13 DECEMBER 2019
PLACING & INSTALLATION

1. The Wood Stone Fire Deck oven must have a minimum 1-inch clearance to combustibles from all sides, and 24-inch
clearance to combustibles from the top� If building materials will contact the oven, they must be completely non-combustible�
Please note that standard Drywall (or Sheetrock) is considered a combustible� When non-combustible building materials
contact the body of the oven, the respective clearances are transferred to those non-combustibles�
2. Any facade 6 inches to either side of the oven doorway or above, must be constructed of non-combustible building materials�
3. For gas-only models, this oven is suitable for installation on combustible floors (convient à l’installation sur un plancher
combustible)�
For gas/wood combination models, this oven is suitable for installation on combustible floors (convient à l’installation
sur un plancher combustible)� The minimum hearth extension area to be covered with a non-combustible floor surface must
extend 36 inches in front of and 30 inches to either side of the oven door opening�
1-inch minimum
side clearance
to combustible
construction
Maintain 24-inch
clearance from
top of the oven
TO REDUCE THE RISK OF FIRE, FOLLOW THESE INSTALLATION INSTRUCTIONS. A MAJOR CAUSE OF OVEN RELATED
FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF
UTMOST IMPORTANCE THAT THIS OVEN BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.
!
WARNING: Installation and servicing of this product could expose you to glasswool/ceramic fibers as well
as calcium silicate dust� ALWAYS WEAR RESPIRATORY AND EYE PROTECTION WHEN INSTALLING OR
SERVICING THIS APPLIANCE. Please read this entire manual before you install the oven� Failure to follow
instructions may result in property damage, bodily injury or even death� Contact your local building or fire
officials about restrictions and installation inspection in your area�
!WARNING: Do not pack required air spaces (clearance) with insulation or other material� When
non-combustible building materials contact the body of the oven, the clearances to combustibles are
transferred to those non-combustibles�
CAUTION HOT PRUDENCE CHAUD
Gas-only models:
Suitable for
installation on
combustible
floors
Gas/wood combination models: This oven is suitable for installation on combustible
floors (convient à l’installation sur un plancher combustible)� The minimum hearth
extension area to be covered with a non-combustible floor surface must extend 36
inches in front of and 30 inches to either side of the oven door opening�
Fire Deck 6045
Installation and Operation Manual
PG 10 OF 32
M0038.13 DECEMBER 2019
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
INSTALLATION CLEARANCES
