Wood Stone WS-GVR Series User manual

Toll Free 800.988.8103
Tel [phone]
Fax [phone]
www.woodstone-corp.com
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
WHATCOM
GAS VERTICAL ROTISSERIE
Rotisserie
Gas-Fired, Stand, Double Door and
Countertop Models
WHATCOM WS-GVR-(6,10)-(CT)-(DD)
WS-GVR-10-(CT)-(DD)-CE
DOC NO M0009.11 REVISED JANUARY 2020
Service Manual

TABLE OF CONTENTS
Cautions & Warnings � � � � � � � � � � � � 3
Operational Overview � � � � � � � � � � � � 4
Venting � � � � � � � � � � � � � � � � � � � � � � 5
Control Panel� � � � � � � � � � � � � � � � � � 6
Electric & Gas Components � � � � � � � 7
10-Spit Drive Assembly � � � � � � � � � � 8
6-Spit Drive Assembly � � � � � � � � � � � 9
Gimbal Assembly � � � � � � � � � � � � � � 10
Drain Plug / Idler Arm Assembly � � � 11
Rear Door Closure Assembly� � � � � � 12
Burners � � � � � � � � � � � � � � � � � � � � � 13
Optional Rear Door� � � � � � � � � � � � � 14
Troubleshooting Guide � � � � � � � � � � 15
120 VAC Wire Diagram� � � � � � � � � � 17
220-240 VAC Wire Diagram � � � � � � 19
220 CE Model Wire Diagram� � � � � � 21
Limited Warranty � � � � � � � � � � � � � � 23
Gas Vertical Rotisserie (GVR)
Service Manual
PG 2 OF 24
M0009.11 JANUARY 2020
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
TABLE OF CONTENTS

Always keep the area under and around this appliance free and clear of any and all combustible materials.
ANSI Z83.11
CSA 1.8
ANSI/NSF 4
The Wood Stone Gas Vertical Rotisserie has been tested
and approved by Intertek Testing Services and
conforms to ANSI Z83.11:2016 Ed. 4;
is certified to CSA 1.8:2016 Ed. 4;
and to NSF/ANSI 4:2016.
SERVICE MANUAL FOR WOOD STONE
WHATCOM GVR GAS-FIRED VERTICAL ROTISSERIE
WS-GVR-10 MODELS
This manual is intended for use ONLY by qualified service personnel. There are no user serviceable parts in
this appliance. Any service or repair of this appliance must be performed by qualified and properly trained
personnel. Please adhere to the warnings and cautions below, as well as all warnings and cautions found in
the appliance Installation and Operation Manual. Please do not hesitate to contact the Wood Stone Service
Department if you have any questions.
IF THIS APPLIANCE IS NOT PROPERLY INSTALLED A FIRE COULD RESULT. TO REDUCE THE RISK OF FIRE,
FOLLOW THE INSTALLATION INSTRUCTIONS INCLUDED IN THE INSTALLATION AND OPERATION MANUAL.
A MAJOR CAUSE OF APPLIANCE RELATED FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES
(AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS APPLIANCE
BE INSTALLED ONLY IN ACCORDANCE WITH THE INSTRUCTIONS FOUND IN THE INSTALLATION AND
OPERATION MANUAL.
WARNING: Improper installation, adjustment, alteration, service or maintenance can result in property
damage, injury or death. Read the installation, operation and maintenance instructions thoroughly before
installing or servicing this equipment.
AVERTISSEMENT: L’installation, le réglage, la modification, la réparation ou l’entretien incorrect de cet
appareil peut causer des dommages matériels, de blessures ou la mort. Lire attentivement les instructions
d’installation, de fonctionement et d’entretien avant de procéder à son installation ou entretien.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids in the vicinity of
this or any other appliance.
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser d’essence ou d’autres vapeurs de liquides
inflammables ou des liquides dans les environs de ce ou de tout autre appareil.
Gas Vertical Rotisserie (GVR)
Service Manual
PG 3 OF 24
M0009.11 JANUARY 2020
An ongoing program of product improvement may
require us to change specifications without notice.
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
TOLL FREE 800.988.8103
TEL [phone]
FAX [phone]
E-MAIL [e-mail]
woodstone-corp.com
CAUTIONS & WARNINGS

WHATCOM VERTICAL ROTISSERIE OPERATION SEQUENCE
The Whatcom GVR is a gas-fired vertical rotisserie� It utilizes a unique drive system that allows food to be hung on vertical spits
and hooks so that different types of food may be cooked at the same time without cross contamination�
Operation is quite straightforward� See diagram below�
FUNCTIONS
• STOP Button - Pressing STOP turns OFF drive and all flames�
• JOG Button� When the rotisserie is stopped (OFF), the JOG button may be used to rotate the rotisserie drive to make loading
the rotisserie easier� Press and hold the JOG button as necessary to rotate the rotisserie drum to the desired position�
• Rear Door Option: If rear door is opened while the unit is running, rotisserie drive and all flames will shut down immediately�
Once the rear door has been closed, press the START button to resume operation�
• IR Knob. The GVR utilizes a “percent” timer module to control the cycle times of the IR burners�
•The percent timer runs in 10 minute cycles whenever the rotisserie is running�
•The IR Knob controls the percentage of the 10 minute cycle that the IR burners will fire, i�e� 10% = 1 minute�
For example, if the IR knob is turned to 60:
•The IR burners will be on 60% of the time�
•That is, the IR burners will fire for 6 minutes, turn OFF for 4 minutes�
•This cycle will run until the unit is turned OFF, or the IR Knob setting is changed�
Note the Flame Post Burner is alway lit when the unit is ON; it is not influenced by the timer�
• Water Bath and Drain. This rotisserie utilizes a water bath in the cooking chamber and must be connected, utilizing a
flexible water line, to a potable water supply� This unit also has a drain connection, and must be connected to a suitable drain
line served by a grease trap� The water bath has drain plug with a built in overflow feature� Use the water knob on the front
of the rotisserie to turn on the water to fill the water bath� The water bath must be used anytime the rotisserie is in operation
to prevent damage to the unit, and to minimize the chance of a grease fire in the rotisserie� Fill the water bath until it begins
to overflow slightly through the drain plug� Adjust the water so that there is just a slight continuous amount of water flowing
through the drain plug� If the water is left on at too high of a flow rate, the cold water will have a cooling effect on the cook
chamber which will cause poor performance and longer cook times� All plumbing connections must be made in accordance
with all pertinent local and national codes�
Gas Vertical Rotisserie (GVR)
Service Manual
Drive turns- Flame Post and IR
burners light�
Flame Post runs continuously until
STOP button is pressed�
IR burner cycle times are
controlled by the IR Knob on the
front panel of the Rotisserie� This
is how cooking is controlled�
Press START Button
PG 4 OF 24
M0009.11 JANUARY 2020
OPERATIONAL OVERVIEW

VENTILATION:
This appliance must be vented with a Type 1 hood in accordance with NFPA 96, and any additional applicable local requirements�
Makeup air must not be aimed at the rotisserie as excessive air blowing at or into the unit will cause lighting issues which will not
be covered by the WARRANTY�
Gas Vertical Rotisserie (GVR)
Service Manual
PG 5 OF 24
M0009.11 JANUARY 2020
VENTING

CONTROL PANEL - FRONT VIEW
Start Switch
(Operator and NO
Contactor Block)
7000-1821
REV:
DATE:
PART #:
WS-GVR-10
Whatcom Rotisserie
General Arrangement 9/30/2011
amandaz 5
DWN BY:
SHEET:
2 of 4
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE W ITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
Bellingham, WA 360/650-1111 www.woodstone-corp.com
REV:
DATE:
PART #:
WS-GVR-10
Whatcom Rotisserie
General Arrangement 9/30/2011
amandaz 5
DWN BY:
SHEET:
2 of 4
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE W ITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
Bellingham, WA 360/650-1111 www.woodstone-corp.com
CONTROL PANEL - INTERNAL VIEW
Stop Switch
(Operator and NC
Contactor Block)
7000-1821
Jog Switch
(Operator and NO
Contactor Block)
7000-1821
Percentage Timer Control
70ROW-0024
IR Potentiometer
002-60ROW-1
Gas Vertical Rotisserie (GVR)
Service Manual
PG 6 OF 24
M0009.11 JANUARY 2020
CONTROL PANEL

REV:
DATE:
PART #:
WS-GVR-10
Whatcom Rotisserie
General Arrangement 9/30/2011
amandaz 5
DWN BY:
SHEET:
3 of 4
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE W RITTEN PERMISSION OF WOOD STONE IS PROHIBITED
Bellingham, WA 360/650-1111 www.woodstone-corp.com
REV:
DATE:
PART #:
WS-GVR-10
Whatcom Rotisserie
General Arrangement 9/30/2011
amandaz 5
DWN BY:
SHEET:
3 of 4
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE W ITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
Bellingham, WA 360/650-1111 www.woodstone-corp.com
Ignition Module - Right IR
R2 - Relay
R1 - Relay
Motor
Capacitor
TS2-
Terminal Strip
TS1-
Terminal
Strip
Transformer
70CE-0081 Circuit Breakers
Right IR
Gas Valve
(SV-3)
Left IR Gas Valve
(SV-2)
Flame Post Gas
Valve (SV-1)
Ignition Module -
Flame Post
Ignition Module-
Left - IR
Drive Motor
ELECTRIC AND GAS COMPONENTS - REAR VIEW
Description Part no.
Motor Capacitor - 120 VAC 70ROW-0004-1
Motor Capacitor 230-240 VAC Contact Factory
Ignition Module 70ROC-0005
Ignition Module-CE Model 70ROW-0049
R1 or R2 Relay 70ROC-0300
Drive Motor 120 VAC 70ROW-0004
Drive Motor 230-240 VAC 70ROW-0042
Transformer 230 VAC 70CE-0081
Description Part no.
Circuit Breaker 5 A 7000-0068
Circuit Breaker 3 A 7000-0060
Circuit Breaker 1 A
(CE models only) 7000-0097
50" Igniter Wire 70ROC-0007
80" Igniter Wire
(Older models) 70ROW-0015
SV-1, SV-2, SV-3 Gas Valves
(Specify NG or LP) 70ROC-0004
SV-1, SV-2, SV-3 CE Gas Valves
(Specify NG or LP) 70CE-0010
Gas Vertical Rotisserie (GVR)
Service Manual
PG 7 OF 24
M0009.11 JANUARY 2020
ELECTRIC & GAS COMPONENTS

10-SPIT DRIVE ASSEMBLY
TOP VIEW
SIDE VIEW
IR Exhaust
V-Belt
70ROW-0052
Swivel Roller
Mount
Drive Frame
Assembly
IR Exhaust
Planetary Wheel
Assembly
Planetary (Horizontal) Rollers
50ROW-0135
Vertical Bearing-2 per Roller
50ROW-0106
Planetary V-Belt
Tensioner Spring
70ROW-0051
Planetary Belt Tensioner
1410659
Main Exhaust Opening
Idler Arm Assembly
RP-50ROW-0110
Drive Pulley
Idler Arm
Tensioner
Spring
70ROW-0051
Flat Drive Belt
70ROW-0053
Drive Motor
Hook Roller
Assembly
50ROW-0031
Hook Roller
Assembly
50ROW-0031
Hook Roller Planetary Wheel Bushing
50ROW-0081
Planetary (Vertical) Rollers
50ROW-0133
Planetary Belt Roller
50ROW-0117-1
Planetary Support
Roller (hidden)
Gas Vertical Rotisserie (GVR)
Service Manual
PG 8 OF 24
M0009.11 JANUARY 2020
10-SPIT DRIVE ASSEMBLY

REV:
DATE:
PART #:
WS-GVR-10
Whatcom Rotisserie
General Arrangement 10/11/2011
amandaz 5
DWN BY: SHEET:
1 of 4
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
Bellingham, WA 360/650-1111 www.woodstone-corp.com
6-SPIT DRIVE ASSEMBLY
TOP VIEW
SIDE VIEW
IR Exhaust
V-Belt
70ROW-0052
Swivel Roller
Mount
Drive Frame
Assembly
IR Exhaust
Planetary Wheel
Assembly
Planetary (Horizontal) Rollers
50ROW-0135
Vertical Bearing-2 per Roller
50ROW-0106
Planetary V-Belt
Tensioner Spring
70ROW-0051
Planetary Belt Tensioner
1410659
Main Exhaust Opening
Idler Arm Assembly
RP-50ROW-0110
Drive Pulley
Idler Arm
Tensioner
Spring
70ROW-0051
Flat Drive Belt
70ROW-0053
Drive Motor
Hook Roller
Assembly
50ROW-0031
Hook Roller
Assembly
50ROW-0031
Hook Roller Planetary Wheel Bushing
50ROW-0081
Planetary (Vertical) Rollers
50ROW-0133
Planetary Belt Roller
50ROW-0117-1
Planetary Support
Roller (hidden)
Gas Vertical Rotisserie (GVR)
Service Manual
6-SPIT DRIVE ASSEMBLY
PG 9 OF 24
M0009.11 JANUARY 2020

FINISH:
REV:
DATE:
PART #:
50ROW-0140
Whatcom Rotisserie
Gimbal Assembly 1/22/2015
bena 5
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/16, ANGULAR ±1°
UNLESS NOTED OTHERWISE
DWN BY:
SHEET:
MATL:
1 of 1
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
See Body of Drawing
Bellingham, WA 360/650-1111 www.woodstone-corp.com
3
4
5
7
11
1
2
6
8
9
10
Item Part Number Rev Description Material Qty
11570653 3Planetary Bearing Mount Stainless Steel, 304 1
21570654 3Planetary Gimbal Base Stainless Steel, 304 1
350ROW-0106 2Planetary Bearing PTFE, Mechanical Grade 6
450ROW-0133 1Planetary Vertical Roller Steel, 8620 2
550ROW-0135 2Planetary Support Roller Steel, 8620 1
69000-0552 0Shoulder Screw 3/8" Shoulder Dia, 1-1/2" L Shoulder, 5/16"-18
Thrd
Steel 1
79000-0552 0Shoulder Screw 3/8" Shoulder Dia, 1-1/2" L Shoulder, 5/16"-18
Thrd
Steel 2
89000-0553 0Shoulder Screw 5/16" Shoulder Dia, 1/4" L Shoulder, 1/4-20
Thrd
Steel 2
99000-0554 01/4-20 Kep Nut Steel 2
10 9000-0628 0NUT Kep 5/16-18 Steel 1
11 9000-0628 0NUT Kep 5/16-18 Steel 2
FINISH:
REV:
DATE:
PART #:
50ROW-0140
Whatcom Rotisserie
Gimbal Assembly 1/22/2015
bena 5
DIMENSIONS ARE IN INCHES
TOLERANCES: LINEAR ±1/16, ANGULAR ±1°
UNLESS NOTED OTHERWISE
DWN BY:
SHEET:
MATL:
1 of 1
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
See Body of Drawing
Bellingham, WA 360/650-1111 www.woodstone-corp.com
3
4
5
7
11
1
2
6
8
9
10
Item Part Number Rev Description Material Qty
11570653 3Planetary Bearing Mount Stainless Steel, 304 1
21570654 3Planetary Gimbal Base Stainless Steel, 304 1
350ROW-0106 2Planetary Bearing PTFE, Mechanical Grade 6
450ROW-0133 1Planetary Vertical Roller Steel, 8620 2
550ROW-0135 2Planetary Support Roller Steel, 8620 1
69000-0552 0Shoulder Screw 3/8" Shoulder Dia, 1-1/2" L Shoulder, 5/16"-18
Thrd
Steel 1
79000-0552 0Shoulder Screw 3/8" Shoulder Dia, 1-1/2" L Shoulder, 5/16"-18
Thrd
Steel 2
89000-0553 0Shoulder Screw 5/16" Shoulder Dia, 1/4" L Shoulder, 1/4-20
Thrd
Steel 2
99000-0554 01/4-20 Kep Nut Steel 2
10 9000-0628 0NUT Kep 5/16-18 Steel 1
11 9000-0628 0NUT Kep 5/16-18 Steel 2
Item Part Number Rev Description Material Qty
1 1570653 3 Planetary Bearing Mount Stainless Steel, 304 1
2 1570654 3 Planetary Gimbal Base Stainless Steel, 304 1
3 50ROW-0106 2 Planetary Bearing PTFE, Mechanical
Grade 6
4 50ROW-0133 1 Planetary Vertical Roller Steel, 8620 2
5 50ROW-0135 2 Planetary Support Roller Steel, 8620 1
6 9000-0552 0
Shoulder Screw 3/8"
Shoulder Dia, 1-1/2" L
Shoulder, 5/16"-18 Thrd
Steel 1
7 9000-0552 0
Shoulder Screw 3/8"
Shoulder Dia, 1-1/2" L
Shoulder, 5/16"-18 Thrd
Steel 2
8 9000-0553 0
Shoulder Screw 5/16"
Shoulder Dia, 1/4" L
Shoulder, 1/4-20 Thrd
Steel 2
9 9000-0554 0 1/4-20 Kep Nut Steel 2
10 9000-0628 0 NUT Kep 5/16-18 Steel 1
11 9000-0628 0 NUT Kep 5/16-18 Steel 2
Gas Vertical Rotisserie (GVR)
Service Manual
GIMBAL ASSEMBLY
PG 10 OF 24
M0009.11 JANUARY 2020

2
3
1
DRAIN PLUG ASSEMBLY
Item Part Number Rev Description Material Qty
1 50ROW-0021 0 Drain Plug w/ O-Rings (complete) Aluminum 1
2 7000-0786 0 O-Ring, 1/8" DIA x 1-3/8" ID Buna-N 1
3 7000-0827 0 O-Ring, 3/16" DIA x 1-1/2" ID Buna-N 1
IDLER ARM ASSEMBLY
Item Part Number Rev Description Material Qty
1 1550652 0 Idler Arm Stainless Steel, 304 1
2 50ROW-0106 2 Planetary Bearing PTFE, Mechanical
Grade 2
3 70ROW-0031 2 Idler Wheel Mild Steel 1
4 9000-0551 0 Shoulder Screw 3/8" Shoulder Dia,
1-1/4" L Shoulder, 5/16"-18 Thrd Steel 1
2 9000-0628 0
Znc-Pltd Stl Machine Screw Nut W/
Tooth Washer 5/16"-18 Screw Size,
1/2" Width, 17/64" Height
Steel 1
Gas Vertical Rotisserie (GVR)
Service Manual
DRAIN PLUG / IDLER ARM ASSY
PG 11 OF 24
M0009.11 JANUARY 2020

Item Part Number Rev Description Material Qty
1 1630661 0 Rear Door Hinge Cover Stainless Steel, 304 1
2 50ROW-0057 1 Rear Door - Upper Bearing
Mount 6061 Aluminum 1
3 7000-0827 0 Rear Door - Drive Link TYPE 304 SS 1
4 50ROW-0058 1 Rear Door - Upper Bearing brass 1
5 50ROW-0061 4 Cam Follower Support Aluminum, 6061-T6 2
6 50ROW-0066 2 Rear Door - Cam Aluminum, 6061-T6 3
7 50ROW-0067 0 Rear Door - Cam Follower brass 4
8 50ROW-0068 1 Mag Switch Mounting
Bracket - Rear Door 10 Ga TYPE 304 SS 5
9 70ROW-0034 0
Steel Extension Spring,
6-1/2" Length, 5/8" OD,
�080" Wire
Zinc 1
unit
10 70ROW-0047 0 Magnetic Switch Kit 1
11 70ROW-0048 0 Bearing - 1/2" Shaft Dia,
5/8" Od, 1/2" Length
Nylon, general
purpose 1
12 9000-0054 0 #8-32 x 3/8, Screw, Pan
HD, Phil, S Zinc Plated steel 4
13 9000-0275 0 Screw, Truss, 1/4-20 x
1/2", SS Stainless Steel, 304 4
14 9000-0479 0 10-32 x 3/16 Set Screw 1
15 9000-0487 0
Shoulder Screw 5/16"
Dia x 5/8" Long, 1/4-20
Thread
Alloy Steel 1
16 9000-0489 0 Shoulder Screw 5/16" Dia
x 1/2" Long 1/4-20 Thread 1
17 9000-0497 0 l/4"-20 Eye Nut, Female Steel 1
18 9000-0504 0 1/4-20 x 7/8 Eye Machine
Screw
Stainless Steel,
304 1
Gas Vertical Rotisserie (GVR)
Service Manual
REAR DOOR CLOSURE ASSEMBLY
PG 12 OF 24
M0009.11 JANUARY 2020

REV:
DATE:
PART #:
WS-GVR-10
Whatcom Rotisserie
General Arrangement 9/30/2011
amandaz 5
DWN BY:
SHEET:
4 of 4
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
Bellingham, WA 360/650-1111 www.woodstone-corp.com
FLAME POST (RADIANT)
BURNERS
Flame Post Igniter
70ROW-0017
Flame Post Cover
50ROW-0024-1
Flame Post
REV:
DATE:
PART #:
WS-GVR-10
Whatcom Rotisserie
General Arrangement 9/30/2011
amandaz 5
DWN BY:
SHEET:
3 of 4
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
Bellingham, WA 360/650-1111 www.woodstone-corp.com
IR BURNER
IR Igniter
70ROC-0006
IR Igniter cover
50ROW-0029
IR deflector
1640672
IR Burner Jets
(not shown)-
Call factory
Flame Post (Radiant) Jets-
Call factory
Igniter (Pilot) Jet
(not shown)-
Call factory
Gas Vertical Rotisserie (GVR)
Service Manual
BURNERS
PG 13 OF 24
M0009.11 JANUARY 2020

REV:
DATE:
PART #:
WS-GVR-10
Whatcom Rotisserie
General Arrangement 9/30/2011
amandaz 5
DWN BY:
SHEET:
4 of 4
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF WOOD STONE CORPORATION
ANY REPRODUCTION OR USE IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS PROHIBITED
Bellingham, WA 360/650-1111 www.woodstone-corp.com
Rear Door Switch
(under cover)
70ROW-0047
Jog Switch
RP-0015
Start Switch
RP-0015
MODEL WITH OPTIONAL REAR DOOR
Gas Vertical Rotisserie (GVR)
Service Manual
PG 14 OF 24
M0009.11 JANUARY 2020
OPTIONAL REAR DOOR

Rotisserie does not turn on� 1. No power to rotisserie� Check fuse or breaker for circuit supplying the rotisserie�
Verify that incoming power matches that shown on the equipment data plate�
2. Circuit breaker on rotisserie tripped� Remove right side, rear corner panel
to access circuit breakers� If breaker(s) trip repeatedly check wiring and
connections for damage or shorts�
3. Loose wire in control panel� Check wiring connections to the START, STOP and
JOG switches�
4. Check transformer� If there is no power to the transformer, recheck Step 1 and
Step 2 above� If incoming voltage is correct to the transformer, check for 24 VAC
at the output of the transformer�
If 24 VAC is not present, TURN OFF INCOMING POWER TO THE ROTISSERIE�
Then verify that all wiring connections on the transformer are tight, and that the
wires are connected as specified for the voltage supplied on the data plate� Turn
power back on and retry�
If 24 VAC is still not present at the output of the transformer, replace the
transformer�
SYMPTOM PROBABLE CAUSE/SOLUTION
No burners light, rotisserie drum is
turning�
No gas to rotisserie� Verify that gas quick connect is securely engaged� Verify that
any gas shut-offs on the supply line are in the ON position�
Be aware that your incoming gas supply may be interlocked to the ventilation/
exhaust and or fire suppression system� Check that interlock system is functioning
properly� On a new installation there may also be air in the gas line that will need to
be purged�
Flame Post does not light or cuts out� 1. Air is blowing at the rotisserie, disrupting the flame and flame sense�
2. Holes on flame post cover plugged� Make sure flame post cover is clean and all
holes clear�
3. Check ground wire connection and igniter wire connection at the burner� To
access, remove the 2 screws at the base of the burner and carefully lift burner
assembly up� Then disconnect flex line at base of burner to remove�
4. Broken igniter�
5. Bad gas valve or ignition module�
Both IR Burners not lighting,
No spark at either IR igniter�
Drum is turning�
1. IR percent control not calling for heat because it is set at 0%, or it is in the
OFF phase of the timing cycle� The control is based on a 10 minute cycle� For
example: if the control is set at 70%, the burners will fire for 7 minutes, then
shut off for 3 minutes, then the cycle repeats�
2. Visually inspect both IR igniters for damage� If igniters look good proceed to 3�
3. Loose connections at ignition module� Carefully remove control panel� With the
Rotisserie on, check for 24 VAC between the (-) and (+) terminals� Turn the
rotisserie OFF, then set the control knob to 100%� Turn the rotisserie back ON�
Between the NO terminal and ground, there should be 24 VAC� If no voltage
present, check the potentiometer for damage and replace if necessary� If the
potentiometer is good, replace IR percent control� If control is good, proceed to
IR troubleshooting below�
Gas Vertical Rotisserie (GVR)
Service Manual
TROUBLESHOOTING GUIDE
PG 15 OF 24
M0009.11 JANUARY 2020

IR Burner not lighting 1. If neither IR burner is lighting, make sure IR control is set to call for heat and not
in an OFF portion of the cycle�
2. Air blowing into the rotisserie. Redirect any air vents in the area away from
the rotisserie doorway�
3. Broken igniter. Inspect igniter for cracked insulator or other damage� Replace if
damaged� Make sure igniter cover is installed�
4. Igniter cable. Make sure cable is firmly attached to igniter and not damaged�
5. Gas pressure. Check for proper burner manifold gas pressure at the appropriate
gas control valve� See Gas Pressure Specifications section of this manual� Also
verify incoming gas pressure to the rotisserie while rotisserie is ON�
For NG models incoming gas pressure, should not exceed 14 inches W�C�, and
should not be below approximately 7 inches W�C�
For LP models, incoming pressure must not exceed 14 inches W�C�, and should
not be below 11 inches W�C�
IF THE INCOMING PRESSURE FOR NG OR LP MODELS EXCEEDS 14 inches W�C�,
AN EXTERNAL REGULATOR MUST BE PROVIDED TO AVOID DAMAGE TO THE
ROTISSERIE�
6. Bad gas valve. Check for 24 VAC at valve when Ignition Module is energized�
If 24 VAC is present at valve, and gas supply to the rotisserie is connected, valve
should output gas at the rated pressure� If after checking the incoming pressure
as directed in step 5, the valve does not open, or outlet pressure is low and
cannot be adjusted higher with the regulator adjustment on the gas valve, the
gas valve may be defective and should be replaced�
7. Bad Ignition Module. Check for 24 VAC at the module (25 V and 25 V Neutral
connections)� If voltage present, but no voltage output to gas valve, OR when unit
is first turned on there is no spark output from the spark terminal - check fuse
on module� If fuse good replace module� (Note: No fuse on Fenwal modules used
on European models)�
SYMPTOM PROBABLE CAUSE/SOLUTION
Drum turns, but hooks are not
rotating�
1. Disconnect gas supply to the rotisserie� Remove the top cover of the rotisserie, to
expose the drive components� Press Start button�
2. From the top of the rotisserie check that motor is turning� If motor is turning
check for loose or broken drive belt� Check idler arm spring� Replace belt or
spring if necessary� If motor is not turning proceed to step 3�
3. Push STOP button and disconnect power to the rotisserie� Check wire
connections at motor� Check motor capacitor and replace if defective� Check
connections at Relay 2� Check that Relay 2 is seated firmly in its socket� Once
connections, capacitor and relay has been checked� Retry� If motor still not
turning motor may need to be replaced�
Rotisserie drum does not turn�
Burners are lighting�
Check planetary belt and planetary belt tensioner�
Gas Vertical Rotisserie (GVR)
Service Manual
PG 16 OF 24
M0009.11 JANUARY 2020
TROUBLESHOOTING GUIDE

DATE:
DIAG #:
WD221 Rev. 0
2/4/2014
Whatcom Vertical Gas Rotisserie - 120 Volt
Electrical Diagram
Bellingham, WA [phone] www.woodstone-corp.com
SHEET:
1of 2
FLAME POST
LEFT INFRARED
RIGHT INFRARED
TS1-15
TS1-10






Igniter
Gas Valve








Igniter
Gas Valve








Igniter
Gas Valve


R
PK
Start
Magnetic
Switch
To TS1-7
To TS1-8
Jog
To TS1-2
To TS1-8
To TS1-12
To TS1-13
BN
BK
BU
OR
Note: Remove Jumper Between TS1-7 And TS1-8
Optional Rear Door
BR
BR
BR
BR
BR
BR
TS1-5
TS1-4
TS1-14
PK
Y
Y
Y
ICR
ICFP
ICL
GVR 120 VAC WIRING DIAGRAM
Gas Vertical Rotisserie (GVR)
Service Manual
120 VAC WIRE DIAGRAM
PG 17 OF 24
M0009.11 JANUARY 2020

DATE:
DIAG #:
WD221 Rev. 0
2/4/2014
Whatcom Vertical Gas Rotisserie - 120 Volt
Electrical Diagram
Bellingham, WA [phone] www.woodstone-corp.com
SHEET:
2of 2
 


12
5
1
13
9
8
4
14
12
5 1
13
9
8 4
14
1 2 3 4 5 6 7 8 9
10
11 12 13 14 15
1 2 3 4 5
M
3A Breaker
5A Breaker
Transformer - 120 VAC/
24 VAC - 150VA
TS2
TS1
Relay 2
Relay 1
4 uF
1/10 HP 160:1
11 RPM
Gear Motor
Start
Stop
Jog
IEC
Connector
 
Rear
Front
BN
Y
Y
OR
R
R
R
OR
BU
BU
BK
PK
OR
BN
Y
GN-BK
GY
V
WW
W
BK
BK
R
R
BU
BK
GN
Y
BN
BK
BK
BN
Remove Jumper On Rear Door Units
BK
Percent
Timer
PK
ICL-25V
ICFP-25V
ICFP-25V Neu
ICR-25V Neu
ICR-25V
R-BK
GN
PK
Y
Y
R
GVR 120 VAC WIRING DIAGRAM
100-120 Volt
Gas Vertical Rotisserie (GVR)
Service Manual
120 VAC WIRE DIAGRAM
PG 18 OF 24
M0009.11 JANUARY 2020

Whatcom Vertical Gas Rotisserie - 240 Volt
Electrical Diagram
Bellingham, WA [phone] www.woodstone-corp.com DATE:
DIAG #:
WD222 Rev. 0
2/4/2014
SHEET:
1of 2
Start
Magnetic
Switch To TS1-7
To TS1-8
Jog
To TS1-2
To TS1-8
To TS1-12
To TS1-13
BN
BK
BU
OR
Note: Remove Jumper Between TS1-7 And TS1-8
Optional Rear Door
FLAME POST
LEFT INFRARED
RIGHT INFRARED
TS1-15
TS1-10






Igniter
Gas Valve








Igniter
Gas Valve








Igniter
Gas Valve


R
PK
BR
BR
BR
BR
BR
BR
TS1-5
TS1-4
TS1-14
PK
Y
Y
Y
ICR
ICFP
ICL
GVR 220-240 VAC WIRING DIAGRAM
220-240 Volt
Gas Vertical Rotisserie (GVR)
Service Manual
240 VAC WIRE DIAGRAM
PG 19 OF 24
M0009.11 JANUARY 2020

Whatcom Vertical Gas Rotisserie - 240 Volt
Electrical Diagram
Bellingham, WA [phone] www.woodstone-corp.com DATE:
DIAG #:
WD222 Rev. 0
2/4/2014
SHEET:
2of 2
 


12
5
1
13
9
8
4
14
12
5 1
13
9
8 4
14
1 2 3 4 5 6 7 8 9
10
11 12 13 14 15
1 2 3 4 5
M
1A Breaker
5A Breaker
Transformer - 240 VAC/
24 VAC - 150VA
TS2
TS1
Relay 2
Relay 1
1 uF
1/10 HP 160:1
11 RPM
Gear Motor
Start
Stop
Jog
IEC
Connector
 
Rear
Front
BN
Y
Y
OR
R
R
R
OR
BU
BU
BK
PK
OR
BN
Y
GN-BK
GY
V
WW
W
BK
BK
R
R
BU
BK
GN
Y
BN
BK
BK
BN
Remove Jumper On Rear Door Units
BK
Percent
Timer
PK
ICL-25V
ICFP-25V
ICFP-25V Neu
ICR-25V Neu
ICR-25V
R-BK
GN
PK
Y
Y
R
GVR 220-240 VAC WIRING DIAGRAM
220-240 Volt
Gas Vertical Rotisserie (GVR)
Service Manual
240 VAC WIRE DIAGRAM
PG 20 OF 24
M0009.11 JANUARY 2020
