Woodland MEMPHIS User manual

W1
W19
Z31
W20
2. Wooden parts, if necessary, can be treated with natural wax or oil before the assembly of the bed.
Advice: We advise you not to treat the bed to sustain better environment for children (regulating humidity in the air). In addition it saves wax and oil costs and
offers advantage that it is easier to clean with tissues and cloth. Two further benefits: Untreated wood is easier for children to take a grip on handles and the
natural colour of the wood stays longer.
3. For the assembly of the bed you need the following tools: a ratchet with a size ten socket, a cross-end screwdriver (better yet a
cordless screwdriver with a changeable head and size ten ratchet attachment) and a hammer. Assistance is only necessary
when assembling the corner beams of the bed.
1. Please take a moment to see how everything fits together by using the diagram above. All the important building parts have
labers to help you see how they fit into the overview. Please note that there is a separate beam list as an additional assembly aid.
All beams are shown horizontally or vertically as they should be positioned and assembled together. The labels on the packages
Lets begin:
Assembly Instructions MEMPHIS Post. 506
B1-B16
Z30 Z30Z32
Z32
Z31 Z31
W13 W2
W14 W1
F2
F3
F1
W19
W20
W9
W8
Not all specifications are guaranteed. © Copyrights by WOODLAND 1998
1.1.
Z30 Z30
Z31
Z31
W14
W1
W19
W8
2.2.
W1
Z31
Z31
Z32
Z32
Z30 Z30
W8
W19
W2
W14
W20
W9
W13
110mm flathead bolt
Start the assembly of the bed with the horizontal beams W1, W8, W14 and W19 (W = horizontal, S =
vertical).
CAUTION! All horizontal beams (W1, W2, W8, W9) are built in a way that the side with most
round indentations (= ), face inside and the surface with two round indentations face
underneath!
The labels as shown ´in , can be found on the end of each beam. Position the beams
on the floor so that you can still walk around the bed while it is in the building phase .
The surface of beam W13 with round indentations should face the inner side.
During the beam assembly install the flathead bolts from outside to inside. From the inside screw a
size 6 flange nut using a screwdriver with size 10 attachment. But do not over tighten bolts.
diagram1.1diagram1.1
1.1.
16mm 35mm
screws
110 mm
flathead bolt
flange nut M6
R
flange
nut M6

Wooden peg 8 x 36 mm
Screw 35 mm
Diagram 1.4Diagram 1.4
Spax-Schraube 35 mm
Diagram 1.5Diagram 1.5
W9
W9
W2
W2
Spaxschraube 35mm
Schubladenboden in Nut einfügen
Diagram 1.2Diagram 1.2
Seite 2
Before installing slats for mattress support assemble the
drawers together. Place drawer board in the notch
between the font and back board and attach the side
boards to front and back boards with screws ( ) .
Fix small wheels on a wooden block attached to the side
boards
( ). Both drawers should be placed from the top
through the space between the beams W1 and W2 from
inside to outside . Corner boards F1, F2 and F3 should be
attached to the beams Z30/Z31, S1/Z32 and S7/S8 with 40
x 40-mm-Brackets. So that the drawers slide along the
corner boards. The corner boards with wider ends should
be positioned in the back ( ).
Diagram1.2Diagram1.2
Diagram 1.3Diagram 1.3
Diagram 1.3Diagram 1.3
Diagram 1.3Diagram 1.3
F2F3
Fix wheels to the wooden
blocks from below using
the screw 16 mm.
Z31
Z32
W1
Install the drawer on the right side between the corner
board F1 and beams S2 and S7.
W8
Assemble corner beams Z30 and Z31as well as middle beam Z32. Be aware that the surface of the beams Z30, Z31 with round
indentations face the direction of the middle beam. Continue the assembly using the diagrams + .
For mattress support beams W2 and W9 has a notch to support the mattress slats, which is positioned to face upward. The
beams on the end of the bed ( W13, W14, W19 and W20) are fixed together at the corner with additional flathead bolt (vertically
attached) and fixed with washer and nut.
1.1. 2.2.
The slatted frame: as shown in 15 wooden peg
should be placed between each slats. The peg is attached to
one side of every slat except for the 16th slat. Slats are placed
on the notch of beams W2 and W9, W3 and W10 and fixed
with wooden screws. The slatted frame should only be
used with a mattress on top for safety since there are
space between the slats.
Other option: If you would like a bunk bed without a
mattress, an extra slat can be added (“Spielboden-Set”,
Best. Nr. 650). The wooden pegs should be taken out and
collected for later use. ( ).
Diagram 1.4Diagram 1.4
Diagram1.5Diagram1.5
After approximately three weeks tighten falthead bolts
again. But be careful not to tighten too much that the head
of the bolt buries inside the wood.
If you have any technical questions to build the bed please
contact us on 0049 2133 2482 - 19. The WOODLAND team
hope that you and your family will enjoy the WOODLAND
adventure beds!
Keep the cover for round
indentations away from small
children!
CAUTION!
First attach the bracket on the board
F2 so that the drawers slide in
smoothly.
WOODLAND reserves the right for printing errors © Copyrights by WOODLAND 1998
