Worx WG154E Installation manual

2-in-1 Grass Trimmer/Edger WG154E
SAFETY AND OPERATING MANUAL

3
2-in-1 Grass Trimmer/Edger WG154E
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING: Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for
future reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in
explosive atmospheres, such as in the
presence of flammable liquids, gases
or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use
the cord for carrying, pulling or
unplugging the power tool. Keep cord
away from heat, oil, sharp edges or
moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected
supply. Use of an RCD reduces the risk of
electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
under the influence of drugs, alcohol
or medication. A moment of inattention
while operating power tools may result in
serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate conditions
will reduce personal injuries.
c)
Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger
on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating
part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your
hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use
of these devices can reduce dust-related
hazards.

4
2-in-1 Grass Trimmer/Edger WG154E
4. POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application.The correct power tool will
do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the
switch does not turn it on and off.
Any power tool that cannot be controlled
with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories,
or storing power tools. Such preventive
safety measures reduce the risk of starting
the power tool accidentally.
d) Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
5. BATTERY TOOL USE AND CARE
a) Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire when
used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects, that can
make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid
may be ejected from the battery;
avoid contact. If contact accidentally
occurs, flush with water. If liquid
contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
6. SERVICE
a) Have your power tool serviced by
a qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool is
maintained.
ADDITIONAL SAFETY
REQUIREMENTS FOR YOUR
LAWN TRIMMER
This grass trimmer is designed for cutting
grass and similar soft vegetation and for
trimming grass edges in private and hobby
garden areas which are not accessible with a
lawnmower.
The device is not allowed to be used in public
gardens, parks, sports centres or at roadsides
as well as in agriculture and forestry.
This lawn trimmer is not allowed to be used
for cutting or chopping:
- Hedges, shrubs and bushes,
- Flowers,
- In terms of composting.
Otherwise, there is a risk of injury.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they

5
2-in-1 Grass Trimmer/Edger WG154E
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Safe operating practices
1. Training
a) Read the instructions carefully. Be familiar
with the controls and the proper use of the
machine.
b) Never allow people unfamiliar with these
instructions or children to use the machine.
Local regulations can restrict the age of the
operator.
c) Keep in mind that the operator or user
is responsible for accidents or hazards
occurring to other people or their property.
2. Preparation
a) Never operate the machine while people,
especially children, or pets are nearby.
b) Wear eye protection and stout shoes at all
times while operating the machine.
3. Operation
a) Use the machine only in daylight or good
artificial light.
b) Never operate the machine with damaged
guards or shields or without guards or
shields in place.
c) Switch on the motor only when the hands
and feet are away from the cutting means.
d) Always remove the battery pack from the
appliance,
– Whenever leaving the machine unattended;
– Before clearing a blockage;
– Before checking, cleaning or working on
the machine;
– After striking a foreign object;
– Whenever the machine starts vibrating
abnormally.
e) Take care against injury to feet and hands
from the cutting means.
f) Always ensure that the ventilation
openings are kept clear of debris.
4. Maintenance and storage
a) Remove the battery pack from the
appliance before carrying out maintenance
or cleaning work.
b) Use only the manufacturer’s recommended
replacement parts and accessories.
c) Inspect and maintain the machine
regularly. Have the machine repaired only
by an authorized repairer.
d) When not in use, store the machine out of
the reach of children.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred cells
or battery pack.
b) Do not short-circuit a battery pack. Do
not store battery packs haphazardly
in a box or drawer where they may
short-circuit each other or be short-
circuited by conductive materials.
When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together
may cause burns or a fire.
c) Do not expose battery pack to heat or
fire. Avoid storage in direct sunlight.
d) Do not subject battery pack to
mechanical shock.
e) In the event of battery leaking, do not
allow the liquid to come into contact
with the skin or eyes. If contact has
been made, wash the affected area
with copious amounts of water and
seek medical advice.
f) Seek medical advice immediately
if a cell or battery pack has been
swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with
a clean dry cloth if they become dirty.
i) Battery pack needs to be charged
before use. Always refer to this
instruction and use the correct
charging procedure.

6
2-in-1 Grass Trimmer/Edger WG154E
j) Do not maintain battery pack on
charge when not in use.
k) After extended periods of storage,
it may be necessary to charge
and discharge the battery pack
several times to obtain maximum
performance.
l) Battery pack gives its best
performance when it is operated at
normal room temperature (20°C ± 5°C).
m)When disposing of battery packs,
keep battery packs of different
electrochemical systems separate
from each other.
n) Recharge only with the charger
specified by WORX. Do not use any
charger other than that specifically
provided for use with the equipment.
A charger that is suitable for one type of
battery pack may create a risk of fire when
used with another battery pack.
o) Do not use any battery pack which
is not designed for use with the
equipment.
p) Keep battery pack out of the reach of
children.
q) Retain the original product literature
for future reference.
r) Remove the battery from the
equipment when not in use.
s) Dispose of properly.

7
2-in-1 Grass Trimmer/Edger WG154E
Read instruction sheet
Keep bystanders away
Wear eye protection
Do not expose to moisture
RCM approval mark
ABN: Australian Business
Number. By this number, business
information such as entity type,
status, business location etc. can
be found at website http://abr.
business.gov.au.
ABN of Positec Australia Pty
Limited is 14 101 682 357
Do not burn
Batteries may enter water cycle if
disposed improperly, which can
be hazardous for ecosystem. Do
not dispose of waste batteries as
unsorted municipal waste.
SYMBOLS
Li-Ion battery.This product has been
marked with a symbol relating to
‘separate collection’ for all battery
packs and battery pack. It will
then be recycled or dismantled in
order to reduce the impact on the
environment. Battery packs can be
hazardous for the environment and
for human health since they contain
hazardous substances.
Edging
Trimming

8
2-in-1 Grass Trimmer/Edger WG154E
1
6
2 3
4
7
5

9
2-in-1 Grass Trimmer/Edger WG154E
1. AUXILIARY HANDLE
2. LOCK OFF BUTTON
3. ON/OFF SWITCH
4. BATTERY PACK
5. SAFETY GUARD
6. FLOWER GUARD
7. LINE CUTTER
8. TRIMMER HEAD COVER (See Fig. F2)
9. CAP RELEASE LATCH (See Fig. F2)
10. SPOOL (See Fig. F2)
11. TRIMMER HEAD (See Fig. F2)
12. EYELET (See Fig. F2)
13. LINE FEED BUTTON (See Fig. F1)
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Voltage 20V Max* Lithium
No load speed 8000/min
Cutting diameter 30cm
Line diameter 1.65mm
Charging time Approx. 3hr
Machine weight 2kg
* Voltage measured without workload. Initial battery voltage reaches Maximum of 20 volts.
Nominal voltage is 18 volts.
ACCESSORIES
Charger (WA3759) 1
Battery pack (WA3549.1) 1
Spool (WA0004) 1
Safety guard 1
We recommend that you purchase your accessories from the same store that sold you the
tool. Use good quality accessories marked with a well-known brand name. Choose the type
according to the work you intend to undertake. Refer to the accessory packaging for further
details. Store personnel can assist you and offer advice.

10
2-in-1 Grass Trimmer/Edger WG154E
ASSEMBLY
1. ASSEMBLY OF THE MAIN HANDLE (See Fig. A)
Align and insert the shaft into the upper housing until a
click can be heard. Make sure the grooves are correctly
matched (See Fig. A).
NOTE: Make sure that the handle is firmly locked
in place. Do not try to remove these pieces after
connecting.
2. ASSEMBLY OF THE SAFETY GUARD
(See Fig. B1, B2)
Remove a screw from the guard; attach the safety
guard to the trimmer head. Align the guard so it slides
into the slots located on the trimmer head.Turn the
tool over and secure the safety guard onto the trimmer
head with the screw (a) provided.
OPERATION INSTRUCTIONS
WARNING! The charger and battery pack are
specially designed to work together so do not
attempt to use any other devices. Never insert or allow
metallic objects into your charger or battery pack
connections because of an electrical failure and hazard
will occur.
1. BEFORE USING YOUR CORDLESS GRASS
TRIMMER
The battery pack included is shipped UNCHARGED.You
must charge before first use.
The battery charger supplied was designed to only
charge the Li-Ion battery also supplied. Do not use
another battery charger.
2. CHARGING YOUR BATTERY PACK
The Li-Ion battery is protected against deep
discharging. When the battery is empty, the machine
will switch off by means of a protective circuit:The
trimmer head will no longer rotate .
In a warm environment or after heavy use, the battery
pack may become too hot to permit charging. Allow
time for the battery to cool down before recharging.
3. TO REMOVE OR INSTALL BATTERY PACK
(See Fig. C1, C2)
Depress the battery release button to release battery
pack from your trimmer (Fig. C1). After recharging,
insert the battery pack into trimmer’s battery port (Fig.
C2). A simple push and slight pressure will be sufficient
until a click is heard.
a
a
8
9
10
11
12
13
A
B1
B2
C1
C2
D
E
E1
E2
E3
E4
F1
F2
G
H1
H2
H3

11
2-in-1 Grass Trimmer/Edger WG154E
NOTE: When removing the battery pack, hold it
firmly to avoid potential accidents.
4. SAFETY ON/OFF SWITCH (See Fig. D)
The safety switch is locked off to prevent accidental
starting. Depress the lock off button (2) then depress
the on/off switch (3) and release lock off button.Your
trimmer is now on.To switch off, just release the on/off
switch.
WARNING! The cutting head continues to
rotate after the trimmer has been switched
off; wait until it has completely stopped then lay
down the tool.
OPERATION
WARNING: Always wear the eye protection.
Never lean over the trimmer head. Rocks or
debris can ricochet or be thrown into eyes and face and
cause blindness or other serious injury. When operating
unit, check for the following:
Wear eye protection and heavy clothing. Hold front
handle with one hand and auxiliary handle with the
other hand. Keep unit below waist level. Work only from
your right to your left to ensure debris is thrown away
from you. Without bending over, keep line near and
parallel to the ground (perpendicular when edging) and
not crowded into material being cut.
WARNING: Make sure that line is fed out
before operation. Make sure motor is up to
full speed before trimming.
WARNING: Use only 1.65mm diameter
cutting line. Other sizes of line will not feed
properly and will result in improper cutting head
function or can cause serious injury. Do not use other
material such as wire, string, rope, etc. Wire can break
off during cutting and become a dangerous projectile
that can cause serious injury.
FLOWER GUARD (See Fig. E)
Fold the Flower Guard (6) when edging and unfold it
before trimming, as shown in Fig. E Before trimming or
edging make sure the Flower Guard is locked firmly in
position.
TRIMMING (See Fig. E1)
Postion the trimmer head as shown in Fig. E1 for
trimming.
Keep the bottom of the trimmer head just above the
ground and at an angle. Allow only the tip of line to
a
a
8
9
10
11
12
13
A
B1
B2
C1
C2
D
E
E1
E2
E3
E4
F1
F2
G
H1
H2
H3

12
2-in-1 Grass Trimmer/Edger WG154E
make contact. Do not force trimmer line into work area.
EDGING (See Fig. E2, E3, E4)
ALWAYS REMOVE THE BATTERY PACK
BEFORE ADJUSTING THE TRIMMER HEAD
POSITION
For edging, position the trimmer head as Fig. E2.
To rotate the trimmer head to edging—first hold the
trimmer shaft as shown in Fig. E3---then with your
other hand hold the trimmer head - Push down and
rotate 180 degrees and then release- the trimmer will
then lock into the edging position automatically—Fig.
E4
NOTE: The trimmer head will only rotate in one
direction.
Take extra caution while edging as objects can be
thrown from the trimmer line.
AUTOMATIC LINE FEED SYSTEM
When initially switching ON the trimmer, a small length
of line is fed out.
A ‘clattering’ noise will be heard when the lines hit the
line cutter. DO NOT BE ALARMED, this is normal.
After a few seconds the line will be cut to the correct
length and the noise will reduce as the motor receives
full speed.
If the noise of the line being cut can’t be heard, more
line will need to be fed out.
To feed more line, it is first necessary to allow the
trimmer to stop completely, then restart, allowing the
motor to reach full speed.
Repeat above until you hear the lines hitting against the
line cutter.
TO MANUALLY FEED THE LINE
(See Fig. F1)
ALWAYS REMOVE THE BATTERY PACK
BEFORE ADJUSTING THE TRIMMER HEAD
POSITION
If required, line can be feed out manually.
To operate, press and release manual line feed button
(13), while gently pulling out the line until it is long
enough to reach the line cutter.
If the line extends past the line cutter, too much line has
been fed out.
If too much line is fed out, remove the spool cap and
turn spool counter-clockwise until the line is at the
desired length.
a
a
8
9
10
11
12
13
A
B1
B2
C1
C2
D
E
E1
E2
E3
E4
F1
F2
G
H1
H2
H3

13
2-in-1 Grass Trimmer/Edger WG154E
TO REMOVE THE CAP ( See Fig. F2)
• Press and hold the two latches (9).
• Pull cap away from the spool holder.
• When refitting the spool cap, keep all areas of
the cap and spool holder clean.
• Replace the cap, pressing firmly down towards
the spool holder to ensure cap is fully located into
position.
• Check that the cap is correctly fitted by trying to
remove it without depressing the two latches.
REPLACE THE TRIMMER LINE AND SPOOL
( See Fig. G)
ALWAYS REMOVE THE BATTERY PACK
BEFORE ADJUSTING THE TRIMMER HEAD
POSITION
• Remove Spool Cap Cover.
• For your convenience it is recommended you
buy replacement spools with the trimmer line
preinstalled.
• Remove the old Spool from Spool Holder. Clear any
broken line or cutting debris from the spool area.
• Pull the line from the new replacement Spool
through the eyelet of the Spool Holder.
• Place new Spool into the holder with the cut out
areas of the Spool facing inward or down.
When installed into the Spool Holder, the
smooth side of the Spool should be visible.
• Release line from cleat on the Spool.
• Refit the Spool Cap Cover.
TO MANUALLY WIND LINE
( See Fig. H1- H3)
Take approximately 3m of line. Insert 1.65mm of line
into the Spool holes and wind line in the direction of
the arrows on the top of the Spool.
Leave approximately 100mm of line unwound and
place into the cleat.
Ensure that the line is neatly coiled on the Spool.
Failure to do so will impair the efficiency of the
automatic line feed.
Then fit the Spool as described above in “Replace the
trimmer line and Spool”.
STORING YOUR GRASS TRIMMER
Always remove the battery pack from your
trimmer after use.
Store in a dry place where the trimmer and battery can
be protected from damage.
a
a
8
9
10
11
12
13
A
B1
B2
C1
C2
D
E
E1
E2
E3
E4
F1
F2
G
H1
H2
H3

14
2-in-1 Grass Trimmer/Edger WG154E
MAINTENANCE
Always remove the battery pack from your
trimmer after use.
Always check the product prior to being used for any
damage.
Never operate your product if it is damaged.
Your power tool requires no additional lubrication or
maintenance.There are no user serviceable parts in
your power tool. Never use water or chemical cleaners
to clean your power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place. Keep the
motor ventilation slots clean. Keep all working controls
free of dust.
a
a
8
9
10
11
12
13
A
B1
B2
C1
C2
D
E
E1
E2
E3
E4
F1
F2
G
H1
H2
H3

15
2-in-1 Grass Trimmer/Edger WG154E
TROUBLESHOOTING
The following table gives checks and actions that you can perform if your machine does not
operate correctly. If these do not identify and correct the problem, contact your service agent.
WARNING: Switch the machine off and remove the battery prior to any
troubleshooting.
Problems Possible Causes Corrective Action
Trimmer fails to
operate.
Battery discharged.
Battery too hot/cold.
Motor is broken.
Internal wiring of machine damaged.
Recharge battery; also see the
content in charger manual
Allow to cool/warm.
Contact Service Agent.
Contact Service Agent.
Trimmer runs
intermittently.
Motor is broken.
Battery not fully charged.
On/Off switch defective.
Contact Service Agent.
Recharge battery.
Contact Service Agent.
Excessive vibrations/
noise.
Machine defective.
Line spool is not wound well.
Contact Service Agent.
Rewind the line. See ’’To fit
spool and line assembly.’’
Cutting time per
battery charge too
low.
Battery has not been used for long
period or only charged for short term.
Grass too high.
Battery defective.
Fully charge battery; also see
the content in charger manual
Cut in stages.
Replace the battery.
Machine does not cut. Line broken.
Battery not fully charged.
Motor is broken (speed is too low).
Grass entangled around cutting head.
Replace the line.
Recharge battery; also see the
content in charger manual
Contact Service Agent.
Remove grass.
Continuous lighting
of the battery charge
indicator
No charging
procedure possible.
Battery not (properly) inserted.
Battery contacts contaminated.
Battery defective.
Properly insert battery into
battery charger.
Clean the battery contacts (e.g.
by inserting and removing
the battery several times) or
replace the battery.
Replace the battery.
Battery charge
indicator does not
light up.
Plug of battery charger not plugged
in (properly).
Socket outlet, mains cable or battery
charger defective.
Insert mains plug (fully) into
the socket outlet.
Check the mains voltage; have
the battery charger checked
by an authorized after-sales
service agent.
Auto feed does not
work
Cutting line is not wound well.
The line is tangled.
Line is used up.
Manually feed the line, if still
can not feed out, remove the
spool out and rewind the line.
Replace with a new line spool.

Copyright © 2014, Positec. All Rights Reserved.
