WRC GT2-5E User manual

GT2 is a new generation high quality 1/8 scale nitro car.
GT2 is supplied in a box,you can download the Instruction manual from www.wrc-racing.com
Its use is intended for more than 16 years old persons with experience on rc model car field.
Children and all the persons without this requirement MUST have direct supervision of a
knowledgeable adult responsible.
Please don't hesitate to contact WRC support at [email protected] for any problem or
question.
Also kindly visit our website www.wrc-racing.com to find last updates, set-up information, option
parts and other information.
W.R.C. world racing car s.r.l.
Via A. Volta 2 Bis
36040 Brendola (VI)
ITALY
Phone: [phone]
E-mail: [email protected]
Website: www.wrc-racing.com
CUSTOMER SUPPORT
WRC guarantees this model kit to be free from defects in both material and workmanship within 30
days of purchase.
The total monetary value under warranty will in no case exceed the cost of the original kit
purchased.
This warranty doesn't cover any compnents damaged by use or modification or as result of wear.
Part or parts missing from this kit must be reported within 30 days of purchase.
No part or parts will be sent under warranty without proof of purchase.
If you find a defective or missing part, contact the local distributor.
Customer service and support will be provided through local hobby store.
No warranties are expressed or implied that cover damage caused by what is considered normal
use or cover or imply how long any model cars' components or electric components will last before
requiring replacement.
Due to the high performance level of this model car you will need to periodically maintain and
replace consumable components; any and all warranty coverage will not cover replacement of any
part or component damaged by neglect, abuse or improper or unreasonable use.
This includes but is not limited to damage from crashing, excessive moistur, improper use or no
maintenance or user modifications which compromise the integrity of components.
Warranty will not cover compnents that are considered consumable on RC model car.
WRC doesn't pay nor refund on any component sent from WRC or its distributor for warranty.
WRC reserves the right to make final determination of the warranty status of any component or part
Use only original WRC spare part:
WARRANTY
Assemble the kit only away from the reach of children.
Follow the building and operating instructions using the utmost care.
Don't put any part of your body inside rotating and moving elements as this may cause damage or
serious injury.
Check and clean the model before putting it away.
Don't use your model car in public places or in roads and areas where it could generate conflict with
person or vehicular traffic.
The model car is controlled by radio: you MUST put great care to avoid loss of radio control always
keeping a safety margin all around your model in order to prevent any collision.
Operating frequency: check and be sure it is clear and not shared with anybody at same time; it could
cause loss of control of the RC model.
Always turn on your transmitter before you turn on the receiver in the car and always turn off the
receiver before you turn off your transmitter.
Keep the wheels of the model off the ground when checking the operation of the radio equipment.
Disconnect the battery pack before storing your model.
GENERAL INFORMATION
Instruction Manual MUST be read and fully understood before to start building and operating
functions.
Always keep Instruction Manual in safety place, ready to be consulted for any reference you need.
Use only original WRC spare parts.
SAFETY PRECAUTIONS
INTRODUCTION

RING PLIERS ALLEN:
1.5 MM.
2.0 MM.
2.5 MM.
3.0 MM.
SIDE CUTTER
SCISSORS
TECHNICAL INFORMATION
- BODY: PROTOTIPE MODEL (NOT INCLUDED)
- ADJUSTABLE FRONT TOE, CAMBER AND CASTER
- ADJUSTABLE REAR TOE AND CAMBER
- BUMPER /FRONT BACKSTOP
- ALUMINIUM CHASSIS
- FULL BALL BEARING
- CARBON RADIO PLATE
- TRANSMISSION: BELT
- REAR DIFFERENTIAL: DIFFERENTIAL GEAR
TECHNICAL DATA
- LENGHT .............................................435 MM.
- WIDTH .............................................264 MM.
- WHEEL BASE ....................................300 MM.
- WEIGHT CHASSIS.............................2080 GR.
REQUIRED BUT NOT INCLUDED IN THE KIT
ADDITIONAL ITEMS NEEDED FOR COMPLETION
ELECTRIC MOTOR
TOOLS REQUIRED
THESE TOOLS ARE NOT INCLUDED IN THE KIT BUT ARE REQUIRED FOR PROPER ASSEMBLY
LOW PROFILE STEERING SERVO
TRANSMITTER
THE FOLLOWING ITEMS ARE NEEDED FOR COMPLETION OF THE GT2; THEY ARE NOT INCLUDED IN THIS KIT (UNLESS NOTED) AND
SHOULD BE OBTEINED FROM YOUR LOCAL HOBBY SHOP.
BE SURE TO READ THE INSTRUCTION COMPLETELY PRIOR TO ASSEMBLY
NOTICE:
RECEIVER
WHEEL - TYRES - INSERTS
LEXAN BODY
2
ELECTRIC MOTOR
BATTERIES
WRC BATTERIES MOUNTING SYSTEM
BATTERIES

00153
00152
93035
M5x16
03127
1.5
2.5
PLEASE
NOTE ORIENTATION
ADJUSTING BELT
TENSION (SET 0 POSITION)
+
0
_
REAR FRONT
(STANDARD POSITION)
00141
00100
90012
12x18x4
00226
00154 90012
12x18x4
00226
00107
TENSION BELT REGULATION
3
FRONT
BAG.1
X2

00138
97021
Ø3x25
95009
Oring 6X1
00168
00189
91001
M3x10
90012
12x18x4
00117
98012
M4x4
95010
Ø 38x1
900016
6x10x3
95009
Oring 6X1
00187
95010
Ø 38x1
00168
00189
90012
12x18x4
98012
M4x4
00117
94001
M 3x4
BAG.2
900016
6x10x3
900016
6x10x3 900016
6x10x3
PLEASE SEE ATTENTION
TO THE GEAR POSITION
SILICON OIL
200000 cst
4

00161
Z46
03277
92001
M3 x6
98012
M4x4
00167
Z20
00163-1
97001
Ø3x11.8
90010
8x14x4
99001
Ø 8
90010
8x14x4
00118
BAG.3
00225
5

92021
M4 x 10
00112-3
00113-4
03104
98001
M3X6
03223
00219-1
92020
M4 x 8
03374
98001
M3X6
92021
M4 x 10
92021
M4 x 10
03377
93007
M3 x18
03155
94001
M3 Autolock
93007
M3 x18
94001
M3
Autolock
6
BAG.4

00204
93004
M3 x12
93001
M3 x6
97027
Ø3x55
00210
00224
00207
98003
M3x4
00205
00224
00207
00208
00211
92020
M4 x 8
00158
00109
93004
M3 x12
93001
M3 x6
00108
93031
M4 x8
99005
Seeger Ø12
99005
Seeger Ø12
7
BAG.5

03110
03110
1mm
00100
00141
03069
03101 93001
M3 x6
03110
90012
12-18-4
0321903152
93004
M3 x12
X2
03069
00105
93001
M3 x6
00145
03069
00145
90001
6_10_3
92002
M3 x8
00103
90001
6_10_3
100412
95015
12x1.5
8
BAG.6
03152-1
Optinal Alu 7075 T6

93001
M3 x6
NOT INCLUDED
93001
M3 x6
93001
M3 x6
03055
40
00132 0013200124 00132 98005
M3x8
03069
00132
1
3
2°
9
BAG.6

00192
92002
M3 x8
00160-1
94005
M4
00150-1
92020
M4 x 8
92020
M4 x 8
BAG.7
00150-2
00209-3
03180
93009
M2 x 5
93010
M2.5 x 5
92001
M3 x6
00209-2
02013
95000
OR 101
03075
93001
M3 x6
92001
M3 x6
02045
92001
M3 x6
93001
M3 x6
00209-4
10

96001
M4 x 10
NOT
INCLUDED
02014
03281
REGULATOR
NOT INCLUDED
93001
M3 x6
PINION 19T
98003
M3x4
98014
M3x10
03280
95011
03332
OPTIONAL
11
WRC BATTERY
MOUNTING SYSTEM

03285
03219
97009
Ø3x22
X2
97008
3x20
03219
03284
98000
M3x3
ADJUST TO BALANCE
WEIGHT BATTERIES
12
FRONT REAR
X2

REAR CAMBER
FRONT CAMBER
NAME
DATE
TRACK
TRACK CONDITION
TRACTION
LOW MEDIUM HIGH
SMOOTH
SURFACE
SIZE
MEDIUM BUMPY
TIGHT MEDIUM FAST
DRIVE RATIO
PINION
SPUR
SETUP SHEET
TOE
SHORE
REAR
TYRES
DIAMETER
start mm .
DIAMETER
start mm .
FRONT
BODY POSITION
BODY POSITION
SPOILER POSITION
TOE
CAMBER
CAMBER
FRONT WIDTH
REAR WIDTH

IN -2°
REAR CAMBER
FRONT CAMBER
NAME
DATE
TRACK
TRACK CONDITION
TRACTION
LOW MEDIUM HIGH
SMOOTH
SURFACE
SIZE
MEDIUM BUMPY
TIGHT MEDIUM FAST
DRIVE RATIO
PINION
SPUR
SETUP SHEET
TOE
18
46
SHORE
REAR
TYRES
DIAMETER
start mm .
DIAMETER
start mm .
FRONT
40/40 35/35
67 75
BODY POSITION
BODY POSITION
10 mm SPOILER POSITION
15 mm
OUT +1.5°
TOE
CAMBER
1°
1°
CAMBER
FRONT WIDTH
259
REAR WIDTH
264
