WT sensor PCM3051S User manual

Version No.: V1.0 1www.wtsensor.com
PCM3051S Monocrystalline Silicon Pressure Transmitter
Features
■Advanced MEMS monocrystalline silicon
pressure sensor chip adopted
■Wide pressure range covering
■Double-wire mode, 4～20mA HART®
protocol digital communication option
■Intelligent LCD gauge outfit with backlight
■With both the remote transmission and the
local zero and pressure range adjustment
■Complete varieties, high accuracy, good
stability,
■Isolation ex-proof housing structure, strong
resistance to the frequency conversion
interference
■No mechanical transmission parts, strong
anti-vibration
Applications and industries
■Process control fields for the industries such
as petroleum, chemical industry, metallurgy,
electricity, food, papermaking, medicine,
machine manufacturing, scientific
experiment and military aviation etc.
Notes:
1 Do not touch the diaphragm with hard
objects, which may cause damage to the
diaphragm.
2 Please read the Instruction Manual of the
product carefully before installation and
check the relevant information of the
product.
3 Strictly follow the wiring method for wiring,
Otherwise it may cause product damage
or other potential faults.
4 Misuse of the product may cause danger
or personal injury.
Product overview
PCM3051S chip adopts advanced MEMS
monocrystalline silicon pressure sensor chip. The
sensor signal is converted into a standard signal
output by a dedicated signal processing module.
After long-term aging and stability screening, the
product performance is stable and reliable. It is
applied to the outdoor scene where the environment
is harsh. At the same time, it can display on-site
pressure, zero point and full range migration.
The installation port form of PCM3051S
monocrystalline silicon pressure transmitter can be
processed according to the requirements of users,
and can also be compatible with other brands of
transmitters. This series of products are widely used
in industrial process control, petroleum, chemical,
metallurgical and other industries.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for
reference only. Do not use this document as a product
installation guide.
3 Complete installation, operation, and maintenance
information is provided in the instructions of the product.
4 Misuse of the product may cause danger or personal
injury.

Version No.: V1.0 2www.wtsensor.com
Performance parameters
Pressure range
0～6kPa…40MPa
Pressure reference
Gauge pressure, Sealed gauge pressure
Supply & output
4～20mA+HART® protocol (18V～36V, usually 24V)
Zero temp. coefficient
±0.3%FS/55℃
Full span temperature
coefficient
±0.5%FS/55℃
Ambient temperature
-30℃～80℃; with LCD gauge outfit -30℃～70℃
Medium temp.
-40℃～104℃
Storage temp.
-40℃～85℃
Insulation resistance
≥100MΩ/500VDC (200MΩ/250VDC)
Mechanical vibration
20g (20～5000Hz)
Shock
100g (11ms)
Accuracy
0.075%FS
Overpressure
Please see pressure range selection
Long-term stability
±0.2%FS/year
Protection grade
IP65
Ex-proof grade
Exd II BT6 Gb
Material
Housing low copper aluminum alloy, isolation diaphragm 316L, Hastelloy
C, tantalum
Medium compatibility
All kinds of media compatible with SS316L
Response time
≤1ms (up to 90%FS)
Component diagram

Version No.: V1.0 3www.wtsensor.com
HART communication connection diagram
Outline dimension
Product model
Dimension drawing In mm
Standard type
Pressure connection
Thread code
C1：M20×1.5-6g
C2：G1/2
Dimension
In mm

Version No.: V1.0 4www.wtsensor.com
Recommended
torque
15～25Nm
15～25Nm
Thread code
C7：NPT1/2
C7F：NPT1/2（Female）
Dimension
In mm
Recommended
torque
15～25Nm
15～25Nm
Installation diagram (for reference only)
Installation tips:
(1) The product is installed vertically on pressure port on site.
(2) When installing outdoor, the transmitter should be placed in a
ventilated and dry place as far as possible to avoid direct sunlight
and rain, otherwise the performance will be deteriorated or
malfunction.
(3) When the product is installed in frequent lightning areas, it
should be marked with “Lightning Protection” when ordering. It is
also recommended that users install lightning protection device
on site and ensure reliable grounding of product and power
supply, which can reduce the probability of lightning damage to
the transmitter.
(4) If the transmitter is found to have no output or the output is
abnormal after installation, please check:
a Whether the electrical connection is accurate and firm
b Is the supply voltage too low or the load resistance is too large
Pressure range selection
Pressure range code
Pressure range
Overpressure
6kG
0～6kPa
300kPa
35kG
0～35kPa
1MPa
100kG
0～100kPa
2MPa
250kG
0～250kPa
4MPa
1MG
0～1MPa
6MPa
3MG
0～3MPa
12MPa

Version No.: V1.0 5www.wtsensor.com
10MS
0～10MPa
20MPa
20MS
0～20MPa
40MPa
40MS
0～40MPa
60MPa
Note: G: Gauge pressure, S: Sealed gauge pressure
How to order
PC3051S 40kG B1H C7 J22X
Example: PCM3051S-40kGB1HC7J12X
Refer to product model:PCM3051S,pressure range :40kPa gauge，Output:4～20mA@HART
protocol, pressure connection:NPT1/2, electrical connection: 3051 isolation ex-proof housing (M20×1.5
female)
Wotian reserves the right to make any change in this publication without notice. The information
provided is believed to be accurate and reliable as of this product sheet.
Product model
Pressure range
6kG=6kPa Gauge
40kG=40kPa Gauge
100kG=100kPa Gauge
250kG=250kPa Gauge
1MG=1MPa Gauge
3MG=3MPa Gauge
10MS=10MS Sealed Gauge
20MS=20MS Sealed Gauge
40MS=40MS Sealed Gauge
Pressure connection:
C1=M20×1.5
C2=G1/2
C7=NPT1/2
C7F=NPT1/2 female
Electrical connection:
J8 = 3051 housing (M20×1.5 female)
J8X= 3051 housing with display (M20×1.5
female)
J12 = 3051 isolation ex-proof housing
(M20×1.5 female)
J12X = 3051 isolation ex-proof housing
with display (M20×1.5 female)
J22 = 3051 isolation ex-proof housing
(NPT1/2 female)
J22X = 3051 isolation ex-proof housing
with display (NPT1/2 female)
Output:
B1H=4～20mA+HART®protocol
