WT sensor PCMPT01 Series User manual

April 2023 1 www.wtsensor.com
PCMPT01&PCMPT02&PCMPT03 Series
Economical Melt Pressure Transmitter
Features
■Signal output:4～20mA,0～10V,0～5V
■Accuracy grade:±1.0%F.S
■Special diaphragm coating
■IP65 ingress protection
■80% internal calibration
Applications
■Injection molding industry
■Chemical fiber industry
Notes:
1 Do not touch the diaphragm with hard
objects, which may cause damage to the
diaphragm.
2 Please read the Instruction Manual of the
product carefully before installation and
check the relevant information of the product.
3 Strictly follow the wiring method for wiring,
otherwise it may cause product damage or
other potential faults.
4 Misuse of the product may cause danger or
personal injury.
Product overview
PCMPT01&PCMPT02&PCMPT03 series economical melt
pressure transmitter series is specially designed for pressure
measurement at high temperature in the injection molding
industry, special diaphragm and highly anti-abrasive coating of
which enable it to work normally at high temperature up to
320℃.This series is installed in the manner of standard
threaded connection and has many advantages like high
stability and long service life.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for reference only.
Do not use this document as a product installation guide.
3 Complete installation, operation, and maintenance information is
provided in the instructions of the product.
4 Misuse of the product may cause danger or personal injury.
Performance parameters
Input Voltage
24VDC(12～36VDC)
Output
4～20mA,0～10V,0～5V
Accuracy Grade
±1.0%F.S
Pressure Range
Refer to below pressure range form
Pressure Unit
MPa (default), psi, bar
Overload Capacity
1.5 times rated pressure
Zero Temp Drift
0.005MPa/℃

April 2023 2 www.wtsensor.com
Electrical Environmental Temp
-20～85℃
Bridge Resistance
350Ω
Diaphragm Materia
15-5PH
Diaphragm Temp
320℃
E-Connection
5-pin standard aviation connector
Mounting Torque
40N.m Max
Process Connection
M14×1.5
Protection Level
IP65
Temperature Measurement type
E, J, K type or Pt100
Pressure range selection
Pressure range code
Pressure Range
1.5M
10MPa、1500psi、100bar
3M
20MPa、3000psi、200bar
5M
35MPa、5000psi、350bar
7.5M
50MPa、7500psi、500bar
10M
70MPa、10000psi、700bar
15M
100MPa、15000psi、1000bar
Dimension

April 2023 3 www.wtsensor.com
E- Connection
5-Pin Connector
Voltage Output Signal(0-5V, 0-10V)
1
2
3
4
5
S+
E+
S-
E-
CAL
Blue
Red
White
Yellow
Black
5-Pin Connector
Current Output Signal(4-20mA)
1
2
3
4
5
E-
E+
CAL
CAL
Blue
Red
Yellow
Black
How to order
PCMPT03 -5M -B- M14- 6 -80- MA -J
Pressure range
Refer to ”Pressure
range selection” on
page 2
Rigid Stem Length
6: 152mm（6 inches）
0: 229mm（9 inches）
12: 318mm（12.5 inches）
15: 381mm（15 inches）
18: 460mm（18 inches）
Process Connection
1/2: 1/2-20UNF
M14: M14×1.5
M18: M18×1.5
M22: M22×1.
（movable screw
thread）
Signal Output
MA: 4-20mA
10V: 0-10V
5V: 0-5V
Product model
01: rigid stem type
02: flexible type
03: flexible type
Pressure unit
Default: MPa
P: psi
B: bar
Flexible Length
Default: 0mm（0 inches）
（only for PT111B series）
80: 460mm（18inches）
30: 760mm（30inches）
Temperature Measurement
type
J: J type
K: K type
E; K type
RTD1: PT100

April 2023 4 www.wtsensor.com
Example: PCMPT03-5M-B-M14-6-80-MA-J
The product model is PCMPT03.5M is the pressure range code(detailed pressure range please refer to
the pressure range selection on page 2, B is pressure unit bar, M14 is pressure connection M14×1.5, 6
is rigid stem length 152mm (6 inches), 80 is flexible length 460mm(18 inches), MA is signal output
4-20mA, J is Temperature Measurement J type
Ordering tips:
Ensure compatibility between measured media and contacting part of product when placing an order.
Wotian reserves the right to make any change in this publication without notice. The information
provided is believed to be accurate and reliable as of this product sheet.
