WT sensor PCT400 User manual

April 2023 1www.wtsensor.com
PCT400 Industrial Temperature Transmitter
Features
■Anti-vibration
■Applicable for harsh environment
■Integrated structure
■Can ensure long-term stable work
■Fast response
■Easy to install
Applications and industries
■Equipment matching
■Pump and compressor, natural gas
pipe network and other automatic
temperature measurement of
control system
■Temperature measurement for
water or oil in the fields of
petroleum, chemical industry,
electricity, light textile,
environmental protection etc.
Notes:
1 During temperature measurement, the
temperature measurement component
should reach thermal equilibrium with the
object under measurement.
2 The insertion depth should be accurate.
3PleasereadtheInstructionManualof
the product carefully before installation
and check the relevant information of the
product.
4 Strictly follow the wiring method for
wiring, otherwise it may cause product
damage or other potential faults.
Product overview
PCT400 Industrial Temperature Transmitter measures the
temperature of measured medium by using the feature that
the platinum resistance value varies with temperature and
shows a certain functional relationship. The transmitter
adopts the high-precision thermocouple and thermal
resistance as measurement elements, uses high stability
circuit for signal processing, realizes continuous
measurement of temperature, outputs industrial control
standard signal, and can have functions of display, remote
transmission etc.
The temperature measurement part of the product adopts all
stainless steel integration processing technology, and the
connecting box adopts 2088 aluminum housing. The product
has the features of strong shock resistance, quick thermal
response etc. The wire adopts special shielded cable, with
wide usage temperature range. It is easy to install, and
applicable to all kinds of automatic control systems for
temperature measurement.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for reference only. Do
not use this document as a product installation guide.
3 Complete installation, operation, and maintenance information is
provided in the instructions of the product.
4 Misuse of the product may cause danger or personal injury.

April 2023 2www.wtsensor.com
Performance parameters
Temperature range -50℃～250℃
Supply & output 4～20mA(16～36VDC) | 4～20mA＋HART protocol (16～36VDC)
Accuracy ±0.5%FS
Sensitive element Pt100 Grade A
Insulation strength 100MΩ/250VDC
Response time ≤30s
Long-term stability ≤0.2%FS/Year
Insertion diameter Φ8mm
Storage temp. -40℃～85℃
Electrical connection 2088 housing
Protection IP65
Rod material 304
Max mounting torque 25Nm
Appearance & structure
Dimension
Unit: mm
Threaded connection
Thread code C1:M20×1.5-6g C2:G1/2
Dimension
Unit: mm
Recommended torque 15～25Nm 15～25Nm
Thread code C4:M14×1.5-6g C22:M16×1.5-6g
Dimension
Unit: mm
Recommended torque 15～25Nm 15～25Nm

April 2023 3www.wtsensor.com
Note: Torque depends on all kinds of factors, such as gasket material, kitting material, thread
lubrication and pressure.
Temperature range selection
Temperature range code Temperature range Remark
（-50～100）-50℃～100℃
（-50～150）-50℃～150℃
（-50～200）-50℃～200℃
（-50～250）-50℃～250℃
（0～100）0℃～100℃
（0～150）0℃～150℃
（0～200）0℃～200℃
（0～250）0℃～250℃
Accessory
Name Appearance Description Material No.
Cable RVVP 3×0.2 Grey 100050000000
How to order
PCT400- （-50～100）B1 C1 L050 J1X
Threaded connection
C1:M20×1.5-6g
C2:G1/2
C3:M14×1.5-6g
C22: M16×1.5-6g
Output signal
B1:4～20mA
B4: 4～20mA+HART
Insertion depth
L030:30mm
L050:50mm
L070:70mm
L100:100mm
Product model
PCT400
Temperature Range
Please refer to
“temperature range
selection” on page 3
Electrical connection
J1:2088 housing
J1X:2088 housing with
display

April 2023 4www.wtsensor.com
Example: PCT400-(-50～100) B1C1L050J1X
The product model is PCT400, (-50～100): temperature range -50℃～100℃, B1: output signal 4～
20mA, C1: threaded connection M20×1.5-6g, L050: insertion depth 50mm, J1X: electrical connection
2088 housing with display.
Ordering tips
1.Please ensure compatibility between measured medium and the contacting part of product when
placing an order.
2.For special requirements for product appearance or performance parameters, our company can
provide customization.
Wotian reserves the right to make any change in this publication without notice. The information
provided is believed to be accurate and reliable as of this product sheet.
