Wulfsberg Electronics VSC 40C User manual

PRINTING INSTRUCTIONS
VCS-40C VHF Communication System
Installation Manual
150-042001, Rev H
Pages 3 through 44 are A size (8-1/2 X 11). They can be
printed single-sided or double-sided.
Pages 45 through 49 are B size (11 X 17). They can be
printed on A size or B size paper.

This page intentionally left blank.

APPLICATION REVISIONS
REV
H
NEXT ASSEMBLY FINAL ASSEMBLY REV DESCRIPTION DATE APPROVED APPROVED
A Initial Release per DCN W1700 10-16-01 V Wallace R DeLong
SH
1
B Revised Per DCN W2055 06-12-02 V Wallace R DeLong
C Revised Per DCN W2245 08-30-02 V Wallace SW/CE
D Revised Per DCN W2831 10-03-03 V Wallace S Wagner
E Revised Per DCN W3296 08-06-04 R Talken R DeLong
F Revised Per DCN W4107 01-10-05 V Wallace R DeLong
G Revised Per DCN W4362 03-30-05 R Talken C Estes
H Revised Per DCN W5897 02-27-07 L Evans J Jensen
DWG. NO.
150-042001
THIS COVER SHEET IS FOR WULFSBERG ELECTRONICS INTERNAL USE. IT IS NOT
TO BE PUBLISHED WITH THE DOCUMENT IT DESCRIBES
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF WULFSBERG ELECTRONICS, A CHELTON GROUP
COMPANY, NEITHER RECEIPT NOR POSSESSION THEREOF CONFERS ANY RIGHT TO REPRODUCE OR USE, OR
DISCLOSE, IN WHOLE OR IN PART, ANY SUCH INFORMATION WITHOUT WRITTEN AUTHORIZATION FROM
WULFSBERG ELECTRONICS
APPROVALS DATE
DRAWN
C Gregory 1-15-02
CHECKED
CEstes 1-14-02
INSTALLATION MANUAL
VCS 40C
ENGINEER
R DeLong 1-16-02
ISSUED
V Wallace 10-16-01
SIZE
A
CAGE CODE
1B7G3 DWG NO.
150-042001 REV H
Typed signatures indicate approval. Handwritten signature
approval of this document is on file at Wulfsberg Electronics,
Prescott, Arizona.
SCALE: NONE DO NOT SCALE DRAWING

This page intentionally left blank.

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
Wulfsberg Electronics, A Cobham Avionics & Surveillance Group Company, located in Prescott,
Arizona, designs and manufactures the Wulfsberg Electronics Series III line of products, including
the VCS 40C VHF Communication System. For more than 25 years, Chelton Avionics, Inc. has
distinguished itself by providing top quality avionics products for civil, air transport, and military
applications.
Wulfsberg Electronics makes no warranty, expressed or implied, with regard to this manual,
including but not limited to any implied warranties of merchantability, fitness for a particular
purpose, and non-infringement. In addition, Wulfsberg Electronics makes no warranty with regard
to the documentation or data contained herein. Wulfsberg Electronics is not liable in the event of
incidental, special, consequential, or any other damages in connection with or arising from
furnishing, performance, or use of this manual.
Reproduction of this publication or any portion thereof by any means is prohibited. For further
information contact Sales, Wulfsberg Electronics 6400 Wilkinson Drive, Prescott, Arizona, 86301.
Telephone: [phone].
Information in this manual is subject to change without notice.
©2001 Wulfsberg Electronics. All rights reserved
VCS 40C, VC-401C, and CD-402C are trademarks of Wulfsberg Electronics.
PROPRIETARY NOTICE
This document contains proprietary information and such information may not be disclosed to
others for any purpose, nor used for manufacturing purposes without written permission from
Wulfsberg Electronics.
Page ii Publication No. 150-042001
Table of Contents Rev. H
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
Record of Revisions
Rev
No. Rev Date Date Inserted By Rev No. Rev Date Date Inserted By
A 10/2001
B 4/2002
C 8/2002
D 10/2003
E 8/2004
F 12/2004
G 3/2005
H 3/2007
Publication No. 150-042001 Page iii
Rev. H Table of Contents
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
Record of Revisions
Rev
No. Rev Date Date Inserted By Rev No. Rev Date Date Inserted By
Page iv Publication No. 150-042001
Table of Contents Rev. H
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
TABLE OF CONTENTS
Section Page
SECTION 1 – GENERAL INFORMATION
1. Introduction .......................................................................................................................... 1-1
2. Applicability........................................................................................................................... 1-1
3. Equipment Description ........................................................................................................ 1-1
A. VC-401C VHF Communications Transceiver............................................................... 1-1
B. CD-402C Control Display Unit .................................................................................... 1-1
4. Available Configuration Variations ...................................................................................... 1-2
5. Technical Specifications ...................................................................................................... 1-3
6. Installation Kits and Accessories ......................................................................................... 1-6
A. VC-401C Connector Kits.............................................................................................. 1-6
B. CD-402C Connector Kits ............................................................................................. 1-7
C. Dual Mounting.............................................................................................................. 1-7
7. Accessories Required But Not Supplied ........................................................................... 1-10
8. Tools Required But Not Supplied ...................................................................................... 1-10
9. License Requirements ....................................................................................................... 1-10
SECTION 2 – INSTALLATION
1. General ................................................................................................................................ 2-1
2. Unpacking and Inspecting Equipment ................................................................................. 2-1
3. Equipment Installation.......................................................................................................... 2-1
A. Cooling Considerations ............................................................................................... 2-1
B. VC-401C Mechanical Installation................................................................................. 2-1
C. Dual Installation Considerations................................................................................... 2-2
D. VC-401C Harness and Connector Assembly............................................................. 2-11
E. CD-402C Mechanical Installation .............................................................................. 2-19
F. Antenna Installation ................................................................................................... 2-23
G. Optional Strapping ..................................................................................................... 2-23
4. Post Installation Check....................................................................................................... 2-24
A. System Test .............................................................................................................. 2-24
B. Flight Check .............................................................................................................. 2-24
SECTION 3 – OPERATION
1. General................................................................................................................................. 3-1
Publication No. 150-042001 Page v
Rev. H Table of Contents
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
LIST OF FIGURES
Figure/Title Page
2-1 Three Radio System Transmit Interlock Wiring....................................................... 2-3
2-2 VC-401C Outline Drawing ...................................................................................... 2-5
2-3 VC-401C Mounting Tray Envelope Drawing (2 Sheets).......................................... 2-7
2-4 RF Cable Fabrication ........................................................................................... 2-11
2-5 VC-401C Rack Mount Connector ......................................................................... 2-12
2-6 VC-401C Polarizing Post Assembly ..................................................................... 2-15
2-7 VCS 40C Interconnect Diagram ........................................................................... 2-17
2-8 CD-402C Cable Connector Assembly .................................................................. 2-19
2-9 CD-402C Outline Drawing..................................................................................... 2-21
LIST OF TABLES
Table Title Page
1-1 VC-401C Configuration Variations ......................................................................... 1-2
1-2 CD-402C Configuration Variations.......................................................................... 1-2
1-3 VC-401C Specifications ......................................................................................... 1-3
1-4 CD-402C Specifications ......................................................................................... 1-5
1-5 VC-401C Connector Kit........................................................................................... 1-6
1-6 VC-401C Mounting Tray Safety Wire Compatible .................................................. 1-6
1-7 VC-401C Mounting Tray Non-Safety Wire Compatible........................................... 1-6
1-8 CD-402C Connector Kit .......................................................................................... 1-7
1-9 VC-401C Mounting Tray Dual, Safety Wire Compatible......................................... 1-7
1-10 VC-401C Mounting Tray Dual, Non-Safety Wire Compatible ................................. 1-8
1-11 VC-401C Mounting Tray Adapter Kit....................................................................... 1-9
1-12 CD-402C Mounting Adapter Kit, Black ................................................................... 1-9
1-13 CD-402C Mounting Adapter Kit, Gray .................................................................... 1-9
2-1 VC-401C Pin-outs ................................................................................................. 2-13
2-2 CD-402C Pin-outs ................................................................................................ 2-20
2-3 Strapping Options ................................................................................................. 2-23
Page vi Publication No. 150-042001
Table of Contents Rev. H
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
SECTION 1 – GENERAL INFORMATION
1. Introduction
This section contains information relative to the physical, mechanical, and electrical
characteristics of the Wulfsberg VCS 40C VHF Communications System. This manual is
applicable only to VC-401C Transceiver and CD-402C Control Display.
2. Applicability
This manual applies to VC-401C Transceivers and CD-402C Control Displays.
3. Equipment Description
The Wulfsberg VCS 40C VHF Communications System is a fully synthesized ATC VHF
transceiver with TSO certification to TSO-37d and TSO 38d that provides a voice/data
communications link between the aircraft and ground facilities. The VCS 40C system consists of
a lightweight, remote-mounted VC-401C transceiver and a panel-mounted CD-402C Control
Display.
A. VC-401C VHF Communications Transceiver
The VC-401C VHF Communications Transceiver is available with fixed 8.33 kHz channel
spacing and switchable 25 kHz - 8.33 kHz channel spacing. Operation within the frequency
range of 118.00 – 136.975 MHz is standard. Extended operation within the frequency range
of 118.00 – 151.975 MHz is available as an option. These units are ICAO compliant.
The VC-401C is designed for rack mounting. The case is fitted with a handle on the front
panel for ease of handling during installation and removal.
The VC-401C consists of functional subassemblies interconnected via ribbon cables. The
subassemblies or circuit modules are hinged and attached to rigid, durable main frames
permitting easy access removal for service. Adjustments and test points are exposed and
available to the service technician without having to remove circuit module subassemblies or
use extender cables or cards.
Circuit modules are plug-in, enabling fault isolation through module substitution. A single
connector accepts all harness wiring on the rear of the VC-401C, while a BNC type RF
connector provides the VHF antenna connection through conventional coaxial cable.
B. CD-402C Control Display Unit
The CD-402C Control Display Unit is designed to be mounted in the instrument panel
individually, or combined in pairs in an adapter plate that will fit a standard DZUS mounting.
Front panel controls establish and display the operating status of all VC-401C functions.
Nonvolatile memory is used to retain the last frequency used, thus eliminating frequency
changes as a result of momentary or extended power disruptions.
Publication No. 150-042001 Page 1-1
Rev. H Section 1 – General Information
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
The system uses full-time self-test to monitor key internal circuits and to display the word
"FAIL" followed by a preassigned number to indicate which specific module has failed. Refer
to the Pilot’s Guide for FAIL message details.
The system is designed for compatibility with ARINC Characteristic 429 Digital Information
Transfer System to allow external frequency control of the VHF communications system. It is
also ACARS and Selcal compatible.
4. Available Configuration Variations
The following tables list the currently available configuration variations of the VC-401C and the
CD-402C.
Table 1-1. VC-401C Configuration Variations
400-042000-XX11
XX= 50 51 52 53 54 55 60 61 62 63 64 65
Freq Range 136.975 MHz X X X X X X
Freq Range 151.975 MHz X X X X X X
Audio & Sidetone 10 mW X X X X
Audio & Sidetone 20 mW X X X X
Audio & Sidetone 40 mW X X X X
8.33 kHz Fixed X X X X X X
8.33 kHz Switchable X X X X X X
Table 1-2. CD-402C Configuration Variations
400-043000-XX10 XX= 50 51 52 53 54 55 56 57 58
Panel, Black X X X X
Panel, Gray X X X X X
28 V Panel, Backlight X X X X
5 V Panel, Backlight X X X X X
8.33 kHz Switch. X X X X X X X X X
VolumeControl X X X X
AC Ground Isolation X
Page 1-2 Publication No. 150-042001
Section 1 – General Information Rev. H
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
5. Technical Specifications
Table 1-3. VC-401C Specifications
CERTIFICATION:
Transmitter TSO-C37d, DO-186A Class 3 & 5, and EUROCAE ED-23B.
Receiver TSO-C38d, DO-186A Class C & E, ICAO Annex 10, and
EUROCAE ED-23B.
Intermodulation Paragraph 2.2.10 (EUROCAE ED-23B, Section 3.1.10)
Desensitization Paragraph 2.2.11 (EUROCAE ED-23B, Section 3.1.11)
FCC IDENTIFICATION: FRWVC-401B
TEMPERATURE RANGE:
Operational -55°C to +70°C (-67°F to +158°F)
Storage -55°C to +85°C (-67°F to +185°F)
COOLING: Free air circulation
ALTITUDE: 55,000 feet (16,764 meters)
WEIGHT: 6.0 lbs. maximum (2.72 kg)
Single mounting tray 0.97 lbs. maximum (0.44 kg)
Dual mounting tray 2.88 lbs. Maximum (1.31 kg)
OVERALL DIMENSIONS:
Height: 4.00 inches maximum (101.60 mm)
Width: 4.10 inches maximum (104.14 mm)
Length: 13.30 inches maximum (337.82 mm)
INPUT POWER
REQUIREMENTS:
Receive (NORM) 24.8 to 30.3 Vdc, 0.66 Ampere @ 24.8 V
(EMER) 20.0 Vdc, 0.80 Amperes
Transmit (NORM) 24.8 to 30.3 Vdc, 5.7 Amperes @ 24.8 V
(EMER) 20.0 Vdc, 6.1 Amperes
FREQUENCY RANGE: 118.000 MHz to 136.975 MHz
118.000 MHz to 151.975 MHz optional
FREQUENCY STABILITY: ± 2.5 PPM
CHANNEL SPACING: 8.33 kHz Fixed, 8.33/25 kHz Switchable
Continues…
Publication No. 150-042001 Page 1-3
Rev. H Section 1 – General Information
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
Table 1-3. VC-401C Specifications (Cont'd)
FREQUENCY CONTROL: Gray Code/ARINC 429
Label Description TX(Out) RX(In) Eq. ID
notes BCD BNR
030 25 kHz X X not 04D X
047 8.33 kHz X X not 033,
10A, 10B X
The VC-401C has two ARINC 429 buses. Data received on either of the ARINC input channels will
tune the radio. ARINC data with a label of 030 will tune the radio to a 25 kHz channel. ARINC data
with a label of 047 will tune the radio to an 8.33 kHz channel. The VC-401C re-transmits the
frequency it is currently tuned to over the output ARINC 429 buses. Frequencies on 25 kHz channels
have an ARINC label of 030. Frequencies on 8.33 kHz channels have an ARINC label of 047. No
radio BIT status is transmitted.
RF POWER OUTPUT: 20 Watts nominal, 16 Watts minimum over temperature
DUTY CYCLE: 1 min on 4 min off, continuous at reduced power without damage
to unit.
HARMONIC CONTENT: 60 dB down from carrier minimum
SPURIOUS CONTENT OF
OUTPUT: 80 dB down from carrier minimum
MODULATION CAPABILITY: 85% minimum with 95% limiting @ 1 kHz
MODULATION FIDELITY: 4 dB maximum variation in modulation percentage,
350 Hz to 2500 Hz
RECEIVER SENSITIVITY: 2.0 μV maximum for 6 dB (S+N)/N (hard)
NOISE LEVEL: 30 dB minimum (S+N)/N ratio for 100 μV
SELECTIVITY:
25 kHz MODE: 6 dB maximum at ±10 kHz, 60 dB minimum ±25 kHz
8.33 kHz MODE: -6 dB maximum at ±3.55 kHz, -60 dB minimum ±5.05 kHz
AGC RANGE: 3 dB maximum variation, 5 to 500,000 μV
AUDIO OUTPUT: 10 mW into 600 ohm load for -50, -51, -60, -61
20 mW into 600 ohm load for -50, -51, -60, -61
40 mW into 600 ohm load for -52, -53, -62, -63
AUDIO RESPONSE: 3 dB maximum variation, 350 Hz to 2500 Hz
40 dB minimum attenuation at 4000 Hz
AUDIO DISTORTION:
Receive 25% maximum at rated output (85% modulation at
100 - 100,000 μV)
Transmit 10% maximum (85% modulation), 350 Hz to 2500 Hz
AUDIO INPUT: Dynamic or carbon microphone, 250 mV minimum
Continues…
Page 1-4 Publication No. 150-042001
Section 1 – General Information Rev. H
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
Table 1-3. VC-401C Specifications (Cont'd)
SIDETONE OUTPUT: 10 mW into 600 ohms (90% modulation) for -50, -51, -60, -61
20 mW into 600 ohms (90% modulation) for -54, -55, -64, -65
40 mW into 600 ohms (90% modulation) for -52, -53, -62, -63
SIDETONE FIDELITY: 6 dB maximum variation, 350 Hz to 2500 Hz
DATA KEY: Grounded with PTT for XMIT
VOICE KEY Open for REC
DATA IN: 0 dBm (.77 Vrms) at 1000 Hz, 85% modulation
DATA OUT: 0 dBm (.77 Vrms)
VOICE/DATA: Open for voice, grounded for data
Table 1-4. CD-402C Specifications
TSO COMPLIANCE: TSO-C37d, TSO-C38d, DO-186A, and EUROCAE ED-23B.
DO-160C Env. Cat. F1-BA(MNY)XXXXXXABABATAXXX
EUROCAE ED-14A.
ALTITUDE: 55,000 feet (16,764 meters)
TEMPERATURE RANGE:
Operational -20°C to +55°C (-4°F to +131°F)
Storage -55°C to +85°C (-67°F to +185°F)
COOLING: Convection and Radiation
WEIGHT: 0.80 lbs. maximum (0.363 kg)
OVERALL DIMENSIONS:
Height 3.15 inches maximum (80.01 mm)
Width 2.50 inches maximum (63.50 mm)
Length 4.39 inches maximum (111.51 mm)
INPUT POWER: Supplied from VC-401C
DISPLAY BACKLIGHTING
CURRENT:
28 Vdc 100 mA ±10% at maximum brightness
5 Vdc 500 mA ±10% at maximum brightness
PANEL LAMP CURRENT:
28 Vdc 96 mA ±10% at maximum brightness
5 Vac or dc 460 mA ±10% at maximum brightness
HEATER CURRENT: 40 mA ±10% at 28 Vdc
On at 0°±5°C (32°±9°F)
Off at approx. 10°C (50°F)
TUNING CONTROL: Gray Code
Publication No. 150-042001 Page 1-5
Rev. H Section 1 – General Information
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
6. Installation Kits and Accessories
A. VC-401C Connector Kits
Installation of the VC-401C requires a connector kit, P/N 050-02398-0000 (see Table 1-5)
and a mounting tray P/N 071-04047-0000 (see Table 1-6).
Table 1-5. VC-401C Connector Kit (050-02398-0000, Rev. E)
PART NUMBER DESCRIPTION U/M QTY
030-02704-0000 CONNECTOR DPXBMA-A106-33P-03FO each 1
030-01311-0000 CONTACT, PIN, CRIMP each 106
089-06008-0005 SCREW, FHP 4-40 X 5/16 each 4
156-041929-01 LABEL, MOUNTING TRAY CONNECTOR KIT,
VC-401B, VC-401C, VN-411B, DM-441B, CDM-451 each 1
Table 1-6.
VC-401C Mounting Tray, 4 Inch, Safety Wire Compatible (071-04047-0000, Rev. L)
PART NUMBER DESCRIPTION U/M QTY
154-04047 ENVELOPE DRAWING, MOUNTING TRAY, 4
INCH RF RF
400-04047 ASSEMBLY, MOUNTING TRAY, 4 INCH RF RF
200-07788-0000 PARTS LIST, ASSEMBLY, MOUNTING
TRAY, 4 INCH SAFETY WIRE COMPATIBLE EA 1
156-041904-01 TSO LABEL, MOUNTING TRAY, 4 INCH EA 1
Table 1-7.
VC-401C Mounting Tray, 4 Inch, Non-Safety Wire Compatible (071-04047-0002, Rev A)
PART NUMBER DESCRIPTION U/M QTY
154-04047 ENVELOPE DRAWING, MOUNTING TRAY, 4
INCH RF RF
400-04047 ASSEMBLY, MOUNTING TRAY, 4 INCH RF RF
200-07788-0002 PARTS LIST, MOUNTING TRAY WELDED, 4
INCH, NONO-SAFETY WIRE COMPATIBLE EA 1
156-041904-01 TSO LABEL, MOUNTING TRAY, 4 INCH EA 1
Page 1-6 Publication No. 150-042001
Section 1 – General Information Rev. H
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
B. CD-402C Connector Kits
Installation of the CD-402C requires a connector kit P/N 050-02372-0000 (see Table 1-7).
Table 1-8. CD-402C Connector Kit (050-02372-0000, Rev. D)
PART NUMBER DESCRIPTION U/M QTY
030-02703-0000 CONNECTOR RD25F110JVL each 1
030-01058-0000 CONNECTOR PLUG, KEYING each 2
035-01762-0002 BAG POLY CLEAR each 0
156-041921-01 LABEL, INSTALLATION KIT, CD-4XXX each 1
C. Dual Mounting
When installing dual systems, use mounting tray kit 071-04047-0001 (see Table 1-8). This kit
includes two of the mounting trays listed above, plus an adapter kit P/N 050-02376-0000 (see
Table 1-9). Two connector kits (050-02398-0000) are also needed.
Table 1-9. VC-401C Mounting Tray, Dual, 4 Inch, Safety Wire Compatible
(071-04047-0001, Rev M)
PART NUMBER DESCRIPTION U/M QTY
154-04047 ENVELOPE DRAWING, MOUNTING TRAY, 4 INCH RF RF
400-04047 ASSEMBLY, MOUNTING TRAY, DUAL 4 INCH RF RF
071-04047-0000 PARTS LIST, MOUNTING TRAY, 4 INCH, SAFETY
WIRE COMPATIBLE each 2
047-07849-0003 GROUND STRAP each 4
089-08485-0006 WASHER, EXTOOTH #6 each 8
200-07765-0001 PARTS LIST, BRACKET SUPPORT, LEFT each 1
200-07765-0003 PARTS LIST, BRACKET SUPPORT, RIGHT each 1
200-07757-0001 PARTS LIST, BRACKET, MOUNTING each 4
091-00477-0001 ISOLATION GROMMET each 8
089-05931-0005 SCREW, BHP 6-32 X 5/16 each 8
089-06008-0004 SCREW, FHP 4-40 X 1/4 each 8
089-06008-0005 SCREW, FHP 4-40 X 5/16 each 28
076-01763-0000 BUSHING SHIELD 6-32 each 8
076-01764-0000 BUMPER TRAY .255 each 1
155-05659 INSTRUCTION SHEET, DUAL TRAY KIT each 1
047-09832-0002 CABLE BRACKET ASSY each 1
091-00109-0001 CABLE TIE .315 each 1
089-05903-0004 SCREW, PHP 4-40 X 1/4 each 2
156-041909-01 AVERY LABEL, MOUNTING TRAY, DUAL, 4 INCH,
SAFETY WIRE COMPATIBLE each 1
Publication No. 150-042001 Page 1-7
Rev. H Section 1 – General Information
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
Table 1-10. VC-401C Mounting Tray, Dual, 4 Inch, Non-Safety Wire Compatible
(071-04047-0003, Rev A)
PART NUMBER DESCRIPTION U/M QTY
154-04047 ENVELOPE DRAWING, MOUNTING TRAY, 4 INCH RF RF
400-04047 ASSEMBLY, MOUNTING TRAY, DUAL 4 INCH RF RF
071-04047-0002 PARTS LIST, MOUNTING TRAY, 4 INCH, NON-
SAFETY WIRE COMPATIBLE each 2
047-07849-0003 GROUND STRAP each 4
089-08485-0006 WASHER, EXTOOTH #6 each 8
200-07765-0001 PARTS LIST, BRACKET SUPPORT, LEFT each 1
200-07765-0003 PARTS LIST, BRACKET SUPPORT, RIGHT each 1
200-07757-0001 PARTS LIST, BRACKET, MOUNTING each 4
091-00477-0001 ISOLATION GROMMET each 8
089-05931-0005 SCREW, BHP 6-32 X 5/16 each 8
089-06008-0004 SCREW, FHP 4-40 X 1/4 each 8
089-06008-0005 SCREW, FHP 4-40 X 5/16 each 28
076-01763-0000 BUSHING SHIELD 6-32 each 8
076-01764-0000 BUMPER TRAY .255 each 1
155-05659 INSTRUCTION SHEET, DUAL TRAY KIT each 1
047-09832-0002 CABLE BRACKET ASSY each 1
091-00109-0001 CABLE TIE .315 each 1
089-05903-0004 SCREW, PHP 4-40 X 1/4 each 2
156-041909-01 AVERY LABEL, MOUNTING TRAY, DUAL, 4 INCH,
NON-SAFETY WIRE COMPATIBLE each 1
Page 1-8 Publication No. 150-042001
Section 1 – General Information Rev. H
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
Table 1-11. VC-401C Mounting Tray Adapter Kit (050-02376-0000, Rev EB)
PART NUMBER DESCRIPTION U/M QTY
155-05659 INSTRUCTION SHEET, DUAL TRAY KIT each 1
047-07849-0003 GROUND STRAP each 4
089-08485-0006 WASHER, EXTOOTH #6 each 8
200-07765-0001 PARTS LIST, BRACKET SUPPORT, LEFT each 1
200-07765-0003 PARTS LIST, BRACKET SUPPORT, RIGHT each 1
200-07757-0001 PARTS LIST, BRACKET, MOUNTING each 4
091-00477-0001 ISOLATION GROMMET each 8
089-05931-0005 SCREW, BHP 6-32 X 5/16 each 8
089-06008-0004 SCREW, FHP 4-40 X 1/4 each 8
089-06008-0005 SCREW, FHP 4-40 X 5/16 each 28
076-01763-0000 BUSHING SHIELD 6-32 each 8
076-01764-0000 BUMPER TRAY .255 each 1
047-09832-0002 CABLE BRACKET ASSY each 1
091-00109-0001 CABLE TIE .315 each 1
089-05903-0004 SCREW, PHP 4-40 X 1/4 each 2
156-041926-01 LABEL, MOUNTING TRAY ADAPTER KIT, DUAL each 1
When mounting two Control Units, use mounting adapter kit 071-01356-0000
(see Table 1-10) or 071-01356-0001 (see Table 1-11).
Table 1-12. CD-402C Mounting Adapter Kit, Black (071-01356-0000, Rev. F)
PART NUMBER DESCRIPTION U/M QTY
047-07783 ADAPTER, DZUS MOUNTING RF RF
047-07783-0002 BEZEL PAINTED BLK each 1
092-00040-0000 PANEL FASTENER (DZUS) each 4
156-041940-01 LABEL, DZUS MOUNTING ADAPTER KIT, BLACK,
CD each 1
Table 1-13. CD-402C Mounting Adapter Kit, Gray (071-01356-0001, Rev. F)
PART NUMBER DESCRIPTION U/M QTY
047-07783 ADAPTER, DZUS MOUNTING RF RF
047-07783-0003 BEZEL PAINTED GRY each 1
092-00040-0000 PANEL FASTENER (DZUS) each 4
156-041945-01 LABEL, DZUS MOUNTING ADAPTER KIT, GREY,
CD each 1
Publication No. 150-042001 Page 1-9
Rev. H Section 1 – General Information
Mar 2007

VCS 40C VHF COMMUNICATION SYSTEM
INSTALLATION MANUAL
7. Accessories Required But Not Supplied
Microphone with a minimum output level of 250 mV.
•Headphone or speaker that accepts output rated at 2.4 Vrms into a 600 ohm impedance.
•VHF Broadband Antenna with 50 Ωcoaxial cable. VSWR 3:1 maximum.
•Coaxial connectors and interwiring harness.
8. Tools Required But Not Supplied
A special crimping tool, positioner and an insertion/extraction tool are needed when the VCS 40C
VHF Communications System is installed. These tools and their part numbers (P/N) are listed
below.
CRIMPING TOOL POSITIONER INSERTION/EXTRACTION TOOL
MIL M22520/2-01 MIL M22520/2-23 AMP P/N 91066-1
9. License Requirements
Check in the country of operation with the governing body for any licensing requirements.
The end user is responsible for obtaining any required licenses.
This equipment has been type accepted by the FCC under type acceptance number
FRWVC-401B.
Page 1-10 Publication No. 150-042001
Section 1 – General Information Rev. H
Mar 2007
