WURM CRC-BL-EEV User manual

Cold location controller for top-hat rail installation with enhanced operating modes
for 4 cold locations or 2 control circuits with EEV
CRC-BL-EEV_V2.0.0_PI_2018-12_EN 1
Subject to technical modifications
CRC-BL-EEV
1 CRC-BL-EEV
Cold location controller for top-hat rail installation with enhanced operating modes
for 4 cold locations or 2 control circuits with EEV
1.1 Front view
Fig. 1: Front view
1.2 Features
• Suitable for max. 4 cold locations
• Up to 2 electronic expansion valves possible via expansion module
• Basic functional sequences and parameters preprogrammed through selection of cold location
type
• Plain text designation for each parameter on the display
• Unique parameter identification with Quicklinks
• One-finger operation
• Intelligent fan control, compressor oscillation protection, fan delay
• Thermal fan control and draining time after defrosting
• Suitable for electric defrost, forced air defrost, hot gas defrost and cool gas defrost
• Defrost control by real-time clock with power reserve
• Simple defrost synchronisation of multiple controllers (master-slave)
• 6 defrost times via integrated weekly timer
• Digital inputs for setpoint switchover, manual defrost initiation and door contact
• Option to select 3-point control
• Weighting of the control sensor for day operation and night operation can be set separately
• Connection of up to 2 external displays
• Plug-in screw terminals
• Large data memory for temperature list
• Connection to the Wurm system through a Wurm CAN communication bus (C-BUS) and
FRIGODATA XP

Cold location controller for top-hat rail installation with enhanced operating modes for 4 cold locations
or 2 control circuits with EEV
2 CRC-BL-EEV_V2.0.0_PI_2018-12_EN
Subject to technical modifications
CRC-BL-EEV
1.3 Safety instructions
Writing conventions
WARNING
• Avoid the described hazard: otherwise, electric voltage poses a hazard that could lead to death
or serious bodily injury.
CAUTION
• Avoid the described hazard: otherwise, minor or medium physical injury or damage to property
will result.
For your safety
For safe operation and to avoid personal injury and equipment damage through operator error, always
read these instructions, become familiar with the device, and follow all safety instructions on the prod-
uct and in this document, as well as the safety guidelines of Wurm GmbH & Co. KG Elektronische
Systeme. Keep these instructions ready to hand for quick reference and pass them on with the device
if the product is sold.
Wurm GmbH & Co. KG Elektronische Systeme accepts no liability in the event of improper use or use
for other than the intended purpose.
WARNING
DANGER TO LIFE FROM ELECTRIC SHOCK AND/OR FIRE!
• Switch off the power to the entire plant when installing, wiring or removing. Otherwise, mains
voltage and/or external voltage may still be present, even if the control voltage is switched off.
Always remove both power plugs (L and N).
• The device should only be wired by a qualified electrician.
• Always use the correct tools for all work.
• Check all wiring after connection.
• Take note of the maximum loads on all connections.
• Never expose the device to moisture, for example, condensation or cleaning agents.
• Take the device out of operation if it is faulty or damaged and is therefore compromising safe
operation.
• Do not open the device.
• Do not repair the device yourself. If required, send it in for repair with an exact description of the
fault.
CAUTION
ELECTROMAGNETIC INTERFERENCE CAN CAUSE FAULTS!
• Always use shielded data cables and place them far away from power lines.
Target group This manual is intended for "service technicians".
Intended use The CRC-BL-EEV is a cold location controller for max. 4 cold locations
or max. 2 control circuits with EEV via X-tra module.

Cold location controller for top-hat rail installation with enhanced operating modes
for 4 cold locations or 2 control circuits with EEV
CRC-BL-EEV_V2.0.0_PI_2018-12_EN 3
Subject to technical modifications
CRC-BL-EEV
Software revision and validity of documentation
Any software versions not listed are special solutions for individual projects and are not described in detail in this
document. This document automatically ceases to be valid if a new technical description is issued.
Manufacturer: Wurm GmbH & Co. KG Elektronische Systeme, Morsbachtalstraße 30, D-42857 Remscheid
You can find more information on our website at www.wurm.de.
1.4 Connection diagram
Fig. 2: Connection diagram
Software version
V2.0.0 – 2018-12 Documentation status
Item Designation Function
1C-BUS interface Data communication (H = CAN high, S = shield, L = CAN
low)
2Display sockets External displays DSP002, DSP100, DSP-LCD, DSP-
Booster
3Output relays K1...K4 Dependent on cold location type, potential-free contact,
230V~, 4(2)A
4Power supply for L 230V~/50Hz
5X-tra interface Expansion module for 2 electronic
expansion valves
6Power supply for N Neutral conductor
7Digital inputs Di1...Di4 Dependent on cold location type
8Defrost bus Defrost synchronisation
9Sensor inputs S1...S4 Temperature sensor
12 13 14 15 16 17 18 11 22 23 24 25 26 27 28 29
21
38 37 36 35 34 33 32 31 39
4321
12 13 14 15 16 17 18 11 22 23 24 25 26 27 28 29
21
38 37 36 35 34 33 32 31 39
CRC-BL-EEV
Frigoentry Blueline
2sec.
74451213
d
c
13
6
8
4
7
9
2
S2 S3 S4 S1
GND
Di2
Sync.
Di3
N
Di1 Di4
L
K1
K2
K3
K4
DSP1
DSP2
H
5
0V
S
L

Cold location controller for top-hat rail installation with enhanced operating modes for 4 cold locations
or 2 control circuits with EEV
4 CRC-BL-EEV_V2.0.0_PI_2018-12_EN
Subject to technical modifications
CRC-BL-EEV
1.5 Installing the device
This device is designed for top-hat rail installation. The housing has standard dimensions according
to DIN 43880 and is also suitable for operation in fuse boxes and distribution cabinets.
The device can be positioned immediately next to another without gaps.
WARNING
DANGER TO LIFE FROM ELECTRIC SHOCK AND/OR FIRE!
• Switch off the power to the entire plant before installing. Otherwise, mains voltage and/or exter-
nal voltage may still be present, even if the control voltage is switched off. Always remove both
power plugs (L and N).
The entire system must be free of voltage.
1. (A) Place the device with the leading edge at an acute angle to the top-hat rail.
2. (B) Push the device downwards onto the top-hat rail.
The device snaps into place with the fastening safety catch (a) on the top-hat rail.
You can now connect the device.
Fig. 3: Top-hat rail installation
1.6 Technical data
NOTICE
• You can find more information about the device in the Wurm Infocenter.
Power supply 230V~, +10% / -15%, max. 7VA
Display 1 x display with text display
2 x green LEDs, C-BUS data traffic (CAN Tx, CAN Rx)
C-BUS communication 3-wire CAN bus interface with integrated power supply, galvani-
cally isolated
Expansion module commu-
nication
Interface for connecting X-tra module
Temperature sensor 4 x TRK277, T3000, T2015, DGF, K243, TF201/TF231
Digital inputs 4 x potential-free
Output relay 4 x relays 230V~, normally open contact, 230V~, 4(2)A
Display connection 2 x sockets for prefabricated cable to display DSP002, DSP100,
DSP-LCD, DSP-Booster
Real-time clock Battery-powered
Monitoring system Monitoring of data memory and connected sensors
Dimensions (W x H x D) 106mm x 90mm x 58mm (DIN 43880)
Fastening Top-hat rail TH 35-15 or TH 35-7.5 (DIN EN 60715)
Ambient temperature Operation: 0...+55°C, storage: -25...+70°C
Weight About 450g
CE conformity - 2014/30/EU (EMC Directive)
- 2014/35/EU (Low Voltage Directive)
RoHS II
Valid from Version 2.0.0
A
B
