INSTALLATION INSTRUCTIONS
CB12
CONNECTING BLOCK
The Model CB12 provides a low cost means of connecting Xantech "Quick Connect" IR Receivers and
standard 3-wire IR Receivers to one single or one dual emitter and a power supply in an infrared repeater
system.
FEATURES AND SPECIFICATIONS
• Inputs: 1 - "IRRCVR"3.5mmstereominijack. Accepts
any Xantech IR Receiver equipped with a
3.5mm stereo mini plug, such as the 291
series or 490-30.
1 - Three terminal "VGS" block for wired
connection of Xantech IR Receivers and
SmartPad keypads.
• Output: 1 - Emitter "OUT" port (3.5mm mono mini jack).
• Model 282, 283, 284 & 286 Xantech series Mini Emitters may be used.
• 2.1mm coaxial power jack for Xantech 781RG or 782-00 Power Supplies.
• Dimensions: 2-1/8" x 1-1/4" x 3/4"
CAUTION: Plug only Xantech IR Receivers equipped with a stereo mini plug into the IR RCVR jack.
Do not plug emitters or other devices into this jack; to do so may damage emitters and power
supplies!
INSTALLATION
Fig. 2 illustrates a typical in-
stallation using the CB12 in a
multiroom IR repeater sys-
tem. In this case a Xantech
291 Hidden Link™ IR Re-
ceiver is used to control a
Satellite Receiver and a VCR
in a cabinet behind closed
doors in Room 1. Control of
the same equipment is ac-
complished from two other
roomswith a Xantech 780-10
J-box IR Receiver and a
Smart Pad™ keypad, by us-
ingthe3-terminal"VGS"con-
nector on the CB12
(V=+12Volts, G=Gnd., S=IR
Signal). When connecting a system, follow this diagram carefully:
When you use more than 1 keypad and one IR receiver together in a system, use the high current power
supply, model 782-00, in place of the 781RG.
Fig. 1 Model CB12 Connecting Block
OUT
VGS
IR
RCVR
PWR
+12 VDC
IR OUT
GND
780-10 J-BOX RECEIVER
®
Model 286M
Dual Blink IR
Mouse Emitter
7-Foot 3-
Conductor
Cable with
Quick Connect
Mini Plug
291
IR Receiver
To 120 V AC
(unswitched)
781RG
Power Supply
Hand Held
Remote
VCR
3-Conductor
Room-to-Room
Cable
(unshielded OK)
Equipment
Mounted Behind
Closed Doors
Satellite Receiver
CB12 Connecting Block
780-10
J-Box
IR Receiver Smart Pad™
GND
IR OUT
+12V
OUT
VGS
IR
RCVR
PWR
GND
IR OUT
+12V
ROOM 2 ROOM 3
ROOM 1
Fig. 2 The CB12 in a Typical 3-Room IR Repeater System



2CB12
The OUT port can drive any of the Xantech emitter models in the 282, 283, 284 and 286 series as well as
the 286M shown in Fig. 2.NOTE: Be sure the Power Supplies, in any of these systems, are plugged into
an unswitched AC outlet. This maintains the system in "stand-by" operation so that power-on commands
can be sent to the controlled equipment.INSTALLATION (cont'd)
Fig. 3 illustrates another application of the CB12. In this case it serves as a "break-out" block for the
convenient connection of a 291 IR Receiver to a 3-conductor room-to-room cable in a larger multiroom
system. You may also use it with any other Xantech quick-connect IR Receiver, such as the 490-30, for
the same purpose.
INSTALLATION NOTES:
1. When used as a "break-out" block, you do not need to connect a power supply to the "PWR" jack on
the CB12. Power is supplied on the 3-conductor cable coming from the connecting block in the
equipment room.
Also, do not plug an emitter into the "OUT" jack in this case. To do so will prevent operation of the
emitters in the equipment room.
2. When paralleling IR receivers, a maximum of 12 is recommended. More than this may result in
unreliable operation due to the buildup of IR noise.
3. The Smart Pad™ keypads may be paralleled in larger numbers. They are not subject to the IR noise
limitation.
4. Mounting: The CB12 may be mounted on any flat surface using the double-sided adhesive tape
supplied.
Fig. 3 The CB12 used as a "Break-Out" Block
+12 VDC
IR OUT
GND
780-10 J-BOX RECEIVER
®
Satellite Receiver
AV Receiver
VCR
MAIN ROOM 1, EQUIPMENT CABINET, ETC.
282M
Mouse Emitter
282M
Emitter
283M
Blink IR Emitter
490-30 Series
Micro Link™
IR Receivers
GND
IR OUT
+12V
780-10
J-Box
IR Receiver
3-Wire
Cable
IR OUT
GND
+12V
480-00
Dinky Link™
IR Receiver
Red
Stripe
GND
IR OUT
+12V
286M
Dual Blink IRs
(to other
controlled
devices)
Hand Held
Remote
CB12
Connecting
Block
OUT
VGS
IR
RCVR
PWR
ROOM 2
291 IR Receiver
(See Text)
X X
3-Conductor Room-to-Room Cable
24 to 18 gauge (unshielded OK)
Smart
Pad™
789-44
Connecting Block
To 120 V AC
(unswitched)
782-00
Power
Supply
ROOM 4
ROOM 3
12VDC
+12 VDC
GND
STATUS
IR IN
EMITTERS
IR
RCVR
789-44
CONNECTING BLOCK
®
8-30-00
NOTE: Be sure the power supplies, in any of these systems, are plugged into an un-switched AC outlet.
