Freedom 10
Inverter/Charger
Owner’s Manual


Freedom 10 Inverter/Charger
Owner’s Manual

About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from
50 watt mobile units to one MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup
power applications in both grid-connected and stand-alone systems. Xantrex products include inverters, battery
chargers, programmable power supplies, and variable speed drives that convert, supply, control, clean, and distribute
electrical power.
Trademarks
Freedom 10 Inverter/Charger is a trademark of Xantrex International. Xantrex is a registered trademark of Xantrex
International.
Other trademarks, registered trademarks, and product names are the property of their respective owners and are used
herein for identification purposes only.
Notice of Copyright
Freedom 10 Inverter/Charger Owner’s Manual © August 2005 Xantrex International. All rights reserved.
Disclaimer
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”)
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSS OR DAMAGE, WHETHER DIRECT,
INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH
INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK.
Date and Revision
August 2005 Revision A
Part Number
975-0251-01-01
Contact Information
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Web: www.xantrex.com

975-0251-01-01 iii
About This Manual
Purpose
The purpose of this Owner’s Manual is to provide explanations and procedures for
installing, operating, maintaining, and troubleshooting the Freedom 10 Inverter/
Charger.
Scope
The Manual provides safety guidelines, detailed planning and setup information,
procedures for installing the inverter, as well as information about operating and
troubleshooting the unit. It does not provide details about particular brands of
batteries. You need to consult individual battery manufacturers for this
information.
Audience
The Manual is intended for anyone who needs to install and operate the Freedom
10 Inverter/Charger. Installers should be certified technicians or electricians.
Conventions Used
The following conventions are used in this guide.
Related Information
You can find more information about Xantrex Technology Inc. as well as its
products and services at www.xantrex.com
WARNING
Warnings identify conditions or practices that could result in personal injury or loss of life
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or other
equipment.
Important: These notes describe things that are important for you to know, but not as
serious as a caution or warning.

iv

975-0251-01-01 v
Important Safety Instructions
1. Before installing and using the Freedom 10 Inverter/Charger, read all
instructions and cautionary markings on the Freedom 10 Inverter/Charger, the
batteries, and all appropriate sections of this guide.
2. For continued protection against the possibility of fire, replace the fuse only
with a fuse of the specified voltage, current, and type ratings.
3. To avoid damage, operate the equipment only within the specified AC (mains)
and DC (battery) voltages.
4. Do not expose the Freedom 10 Inverter/Charger to rain, snow, spray, or bilge
water. To reduce risk of fire hazard, do not cover or obstruct the ventilation
openings. Do not install the Freedom 10 Inverter/Charger in a zero-clearance
compartment. Overheating may result.
5. Use only attachments recommended or sold by the manufacturer. Doing
otherwise may result in a risk of fire, electric shock, or injury to persons.
6. To avoid a risk of fire and electric shock, make sure that existing wiring is in
good condition and that wire is not undersized. Do not operate the Freedom
10 Inverter/Charger with damaged or substandard wiring.
7. Do not operate the Freedom 10 Inverter/Charger if it has received a sharp
blow, been dropped, or otherwise damaged in any way. If the Freedom 10
Inverter/Charger is damaged, see the Warranty section.
8. Do not disassemble the Freedom 10 Inverter/Charger. It contains no user-
serviceable parts. See Warranty for instructions on obtaining service.
Attempting to service the Freedom 10 Inverter/Charger yourself may result in
a risk of electrical shock or fire. Internal capacitors remain charged after all
power is disconnected.
9. To reduce the risk of electrical shock, disconnect both AC and DC power
from the Freedom 10 Inverter/Charger before attempting any maintenance or
cleaning or working on any circuits connected to the Freedom 10 Inverter/
Charger. Turning off controls will not reduce this risk.
10. The Freedom 10 Inverter/Charger must be provided with an equipment-
grounding conductor connected to the AC input ground.
WARNING
This chapter contains important safety and operating instructions. Read and keep this
Owner’s Manual for future reference.
Important: General safety information for installation and operation is contained
throughout this manual where they apply and are not included In this summary.

Safety
vi 975-0251-01-01
Explosive gas precautions
1. Working in the vicinity of lead-acid batteries is dangerous. Batteries generate
explosive gases during normal operation. Therefore, you must read this guide
and follow the instructions exactly before installing or using your Freedom 10
Inverter/Charger.
2. This equipment contains components that tend to produce arcs or sparks. To
prevent fire or explosion, do not install the Freedom 10 Inverter/Charger in
compartments containing batteries or flammable materials, or in locations that
require ignition-protected equipment. This includes any space containing
gasoline-powered machinery, fuel tanks, as well as joints, fittings, or other
connections between components of the fuel system.
3. To reduce the risk of battery explosion, follow these instructions and those
published by the battery manufacturer and the manufacturer of the equipment
in which the battery is installed.
Precautions When Working With Batteries
1. Follow all instructions published by the battery manufacturer and the
manufacturer of the equipment in which the battery is installed.
2. Make sure the area around the battery is well ventilated.
3. Never smoke or allow a spark or flame near the engine or batteries.
4. Use caution to reduce the risk or dropping a metal tool on the battery. It could
spark or short circuit the battery or other electrical parts and could cause an
explosion.
5. Remove all metal items, like rings, bracelets, and watches when working with
lead-acid batteries. Lead-acid batteries produce a short circuit current high
enough to weld metal to skin, causing a severe burn.
6. Have someone within range of your voice or close enough to come to your aid
when you work near a lead-acid battery.
7. Have plenty of fresh water and soap nearby in case battery acid contacts skin,
clothing, or eyes.
WARNING: Explosion hazard
WARNING: Explosion or fire hazard

Safety
975-0251-01-01 vii
8. Wear complete eye protection and clothing protection. Avoid touching your
eyes while working near batteries.
9. If battery acid contacts skin or clothing, wash immediately with soap and
water. If acid enters your eye, immediately flood it with running cold water
for at least twenty minutes and get medical attention immediately.
10. If you need to remove a battery, always remove the ground terminal from the
battery first. Make sure all accessories are off so you don’t cause a spark.
Precautions for Using Rechargeable Appliances
Most rechargeable battery-operated equipment uses a separate charger or
transformer that is plugged into an AC receptacle and produces a low voltage
charging output.
Some chargers for small rechargeable batteries can be damaged if connected to the
Freedom 10 Inverter/Charger. Do not use the following with the Freedom 10
Inverter/Charger:
• Small battery-operated appliances like flashlights, razors, and night lights that
can be plugged directly into an AC receptacle to recharge.
• Some chargers for battery packs used in power hand tools. These affected
chargers display a warning label stating that dangerous voltages are present at
the battery terminals.
CAUTION: Equipment damage
Important: if you are unsure about using your rechargeable appliance with the
Freedom 10 Inverter/Charger, contact the equipment manufacturer to find out if there are
high voltages at the battery terminals or if the appliance incorporates the use of
transformers.
