Xbrand HT9737ME User manual

ELECTRIC FIRE DISPLAY
Item # HT9737ME
OWNER’S MANUAL
WARNING
Read and understand this entire owner’s manual, including all safety
information, before plugging in or using this product. Failure to do so could
result in fire, electric shock, or serious personal injury.
CAUTION Keep this owner’s manual for future reference. If you sell or give this product
away, make sure this manual accompanies this product.
NO VENTING REQUIRED
120V AC; 60 Hz; Adjustable 600 Watts or 1500 Watts

2
IMPORTANT SAFETY INSTRUCTIONS!
WARNING
Read all instructions before using this heater!
This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If
provided, use handles when moving this heater. Keep combustible materials, such as
furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of
the heater, and keep them away from the sides and rear.
Extreme caution is necessary when any heater is used by or near children or invalidsand
whenever the heater is left operating and unattended.
DO NOT operate any heater with a damaged cord or plug or after the heater malfunctions,
has been dropped or damaged in any manner. Discard heater, or return to authorized service
facility for examination and/or repair.
DO NOT run power cord under carpeting. DO NOT cover power cord with throw rugs, runners,
or similar coverings. DO NOT route power cord under furniture or appliances. Arrange power
cord away from traffic area, and where it will not be tripped over.
Connect to properly grounded outlets ONLY.
DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening, as
this may cause electric shock or fire, or damage the heater.
To prevent a possible fire, DO NOT block air intakes or exhaust in any manner. Doing so could
cause a fire. DO NOT use on soft surfaces, like a bed, where openings may become blocked.
A heater has hot and arcing or sparking parts inside. DO NOT
use it in areas where
gasoline, paint, or flammable liquids are used or stored.
Use this heater only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or injury to persons.

ALWAYS plug heaters directly into a wall outlet/receptacle. NEVER use with an
extension cord or relocatable power tap (outlet/power strip).
DO NOT place the heater near a bed because objects such as pillows or blankets can fall off
the bed and be ignited by the heater.
NEVER use this heater in bathrooms, laundry rooms, or any other location where the heater
could fall into a bathtub or pool, become damp, or come in contact with water.
AVOID FIRE! Regularly inspect all air vents to make sure they are free from dust, lint, or other
blockage. Unplug the unit and clean with a vacuum ONLY. DO NOT rinse or get wet.
ALWAYS attach all four legs before plugging in or turning on this heater! Failure to do so
could result in fire.
NEVER plug in or turn on this heater with the air vents touching the ground! Doing so could
result in fire.

3
WARNING
For residential use only! NOT for commercial use! Any commercial or public use of this
heater voids all warranties, and could cause injury.
This product is not intended to be a primary heat source. It is for supplemental heat only.
INDOOR use only! NEVER use this heater outdoors! Doing so may result in electric shock!
Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside!
NEVER modify this heater. Doing so could result in personal injury or property damage.
Modification of this fireplace completely voids all warranties.
ALWAYS turn this heater off before unplugging it from the outlet.
ALWAYS disconnect this unit from the power supply before performing any assembly or
cleaning, or before relocating the electric fireplace.
NEVER leave this heater unattended. ALWAYS unplug this heater when not in use.
ALWAYS store this heater in a dry location. NEVER use the fireplace if it has become wet.
Place the heater near a wall outlet so an extension cord is not needed. If an extension cord is
needed, the gauge of the cord must be at least 14AWG, and the rating must be at least
1875 Watts. NEVER use a smaller gauge cord with a lower rating. Doing so may result in
fire or electric shock.
ONLY use this heater on a minimum 120V AC 15-Amp grounded circuit. NEVER overload
the circuit. If this heater trips the circuit breaker, or blows the fuse, unplug it and all other
appliances on the same circuit before the next use.
NEVER plug this heater into an outlet that is old, cracked, or has any loose wires or
connections. Plugging this heater into a faulty outlet could result in electric arcing within the
outlet that could cause the outlet to overheat or catch fire.
ALWAYS check your heater cord and plug connections with each use!
i) MAKE SURE the plug fits tight in the outlet! Faulty wall outlet connections or loose plugs
can cause the outlet to overheat.
ii) Heaters draw more current than small appliances. Overheating may occur even if it has
not occurred with the use of other appliances.
iii) During use check frequently to see if the plug outlet or faceplate is HOT!
iv) If the outlet or faceplate is HOT, discontinue use immediately and have a qualified
electrician inspect and/or replace the faulty outlets.
The power cord supplied with the heater has three
prongs: two flat blades (live and neutral) and one
round pin (ground). If a 3-
slot receptacle is not
available, an adapter MUST
be used. The adapter
MUST be properly grounded to the outlet box (see
figure at right). [NOTE: Adapter NOT INCLUDED.]
SAVE THESE INSTRUCTIONS!

4
PREPARATION
This product has a GLASS panel! ALWAYS use extreme caution when handling glass.
Failure to do so could result in personal injury or property damage.
Remove all parts and hardware from the carton and place them on a clean, soft, and dry
surface.
Make sure all parts are dry, and the power cord and plug are not damaged. See
IMPORTANT SAFETY INFORMATION on pages 2 and 3.
Compare the contents with the parts list to make sure nothing is missing.
Dispose of all packaging materials properly.
Please recycle whenever possible.
TOOLS NEEDED FOR ASSEMBLY
Phillips (“+”) screwdriver (not included)
PARTS AND HARDWARE
Item
Description
Qty
A
Stove 1
B
Legs 4
C
Screws
12*
*Two extra screws included.
B
C

5
ASSEMBLY
ALWAYS make sure the unit is unplugged before beginning assembly! NEVER move or
clean the heater, or change the bulb(s), while it is plugged in.
1) Carefully turn the STOVE (A) upside down and lay it on a clean soft surface.
2) Align the holes in the leg (B) with the holes in the corner of the stove frame as shown.
3) Thread three SCREWS (C) through the holes in the leg and into the stove frame. Partially
tighten the screws with a Phillips screwdriver.
4) Repeat Steps 2 and 3 for the other three legs.
5) Check the alignment and tighten all 12 screws securely with the screwdriver.
DO NOT over-tighten the screws.
ALWAYS attach the feet before using! NEVER plug in or operate this unit if the feet are
not securely attached!

6
OPERATION
NOTICE
When the heat function is used for the first time, a slight odor may be present. This
is normal and should not occur again unless the heater is not used for an extended
period of time.
BUTTON
ACTION / FUNCTION
INDICATION / RESULT
Power
1. Press to turn on flame effect and
enable heater.
Heater switches will not work unless
this switch is turned on.
2. Press again to shut off the power to
all functions.
1. Flame effect turns on. Power light on switch
illuminates.
The heater is now enabled.
2. Flame effect, heater, and power lights all turn
off.
I
1. With power turned on, press to turn
on low heat.
Low heat must be on to use high heat.
2. Press again to turn off low heat.
1. Heater and fan turn on low.
2. Low heat and fan turn off. Flame stays on.
II
1. With power and low heat turned on,
press to turn on high heat.
2. Press again to turn off high heat.
1. Heater and fan turn on high.
2. High heat and fan turn off. Low heat and
flame stay on.
TEMPERATURE LIMITING CONTROL
This heater is equipped with a Temperature Limiting Control. Should the heater reach an unsafe
temperature, the heater will automatically turn OFF. To reset:
1. Unplug the power cord from the outlet.
2. Turn the ON/OFF switch on the CONTROL PANEL to OFF.
3. Wait 5 minutes.
4. Inspect the fireplace to make sure no vents are blocked, or clogged with dust or lint. If they are,
use a vacuum to clean the vent areas.
5. With the POWER switch OFF, plug the power cord back into the outlet.
6. If the problem continues, have your outlet and wiring inspected by a professional.
CARE AND MAINTENANCE
Replacing the light bulb
ALWAYS turn the heater OFF and unplug the power cord from the outlet before
changing the bulb. Failure to do so could result in electric shock, or personal injury.

7
1. Allow the fireplace to cool down before moving it. 2. Lay the fireplace down on a soft surface.
3. Unscrew the two bulb plate screws and remove the bulb plate. 4. Carefully unscrew the light bulb
and replace it with another 40W candelabra style light bulb of the same design. 5. Replace the bulb
plate and secure it in place with the two screws. Note: Do not over-tighten the screws.
WARNING! Other than replacing the light bulb, NO SERVICING of the internal or
electrical parts should be performed by the consumer. Do not service the unit yourself.
CLEANING
Metal:
•Buff using a soft cloth, slightly dampened with a citrus oil-based product.
•DO NOT use brass polish or household cleaners as these will damage the metal.
Glass:
•Use glass cleaner and dry thoroughly with a paper towel or lint-free cloth.
•NEVER use abrasive cleansers or any cleaner that could scratch the surface.
Plastic:
•Wipe with a slightly damp cloth and a mild solution of dish soap and warm water.
Vents:
•Use a vacuum or duster to remove dust and dirt from the heater and vent areas.
NEVER immerse in water or spray with water. Doing so could result in electric shock,
fire, or personal injury.
MAINTENANCE
Risk of electric shock! DO NOT OPEN the main panels! No user-serviceable parts
inside!
Storage:
•Store heater in a clean dry place when not in use.
Electrical and Moving Parts:
•The fan and motors are lubricated at the factory and will not require lubrication for the life of
the stove.
•Except for the light bulb(s), all electrical parts and components are integrated into the heater
and are not serviceable by the consumer.

WARRANTY RELATED ISSUES
1. Distributed by XBrand.
2. For details, please see our website www.XBrand-inc.com
PLEASE LET US HELP YOU BEFORE RETURNING TO STORE.
For any questions please email us at [email protected], or visit us at www.XBrand-Inc.com.
WE APPRECIATE YOUR FEEDBACK ONLINE. PLEASE HELP US REVIEW THIS PRODUCT AT
YOUR PLACE OF PURCHASE.
