Laser safety
!Warning: Adjustments, use of controls, or performance of
procedures other than those specified herein may result in
hazardous light exposure.
The Xerox DocuPrint printers are certified to comply with the
performance standards of the U.S. Department of Health, Education,
and Welfare for Class 1 laser products. Class 1 laser products do not
emit hazardous radiation. The DocuPrint printers do not emit
hazardous radiation because the laser beam is completely enclosed
during all modes of customer operation.
The laser danger labels on the system are for Xerox service
representatives and are on or near panels or shields that must be
removed with a tool. DO NOT REMOVE LABELED PANELS OR
PANELS NEAR LABELS. ONLY XEROX SERVICE
REPRESENTATIVES HAVE ACCESS TO THESE PANELS.
Ozone information
This product produces ozone during normal operation. The amount
of ozone produced depends on copy volume. Ozone is heavier than
air. The environmental parameters specified in the Xerox installation
instructions ensure that concentration levels are within safe limits. If
you need additional information concerning ozone, call 1-800-828-
6571 to request the Xerox publication 600P83222, OZONE.
Operation safety
Your Xerox equipment and supplies have been designed and tested
to meet strict safety requirements. They have been approved by
safety agencies, and they comply with environmental standards.
Please observe the following precautions to ensure your continued
safety.
•Always connect equipment to a properly grounded electrical
outlet. If in doubt, have the outlet checked by a qualified
electrician.
!Warning: Improper connection of the equipment grounding
conductor may result in risk of electrical shock.
•Never use a ground adapter plug to connect equipment to an
electrical outlet that lacks a ground connection terminal.
•Always place equipment on a solid support surface with
adequate strength for its weight.



iv XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
•Always use materials and supplies specifically designed for
your Xerox equipment. Use of unsuitable materials may result in
poor performance and may create a hazardous situation.
•Never move either the printer or the Printer Controller without
first contacting Xerox, Xerox Ltd., or Fuji Xerox for approval.
•Never attempt any maintenance that is not specifically
described in this documentation.
•Never remove any covers or guards that are fastened with
screws. There are no operator-serviceable areas within these
covers.
•Never override electrical or mechanical interlocks.
•Never use supplies or cleaning materials for other than their
intended purposes. Keep all materials out of the reach of
children.
•Never operate the equipment if you notice unusual noises or
odors. Disconnect the power cord from the electrical outlet and
call service to correct the problem.
If you need any additional safety information concerning the
equipment or materials Xerox supplies, call Xerox Product Safety at
the following toll-free number in the United States:
1-800-828-6571
For customers outside the United States, contact your local Xerox
representative or operating company.

XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE v
Table of Contents
Laser safety iii
Ozone information iii
Operation safety iii
Introduction ix
About this guide ix
Contents ix
Conventions x
Notice x
1. Product overview 1-1
System overview 1-1
4850/4890 IPS hardware features 1-3
NPS/IPS Dual Mode 1-5
Sixth Sense 1-5
Base system components 1-6
2. Controller components and options 2-1
Controller hardware 2-1
Sun Ultra 2 workstation 2-1
Sun Ultra 60 workstation 2-4
IPS user interface screen 2-9
Host Channel Unit (HCU)—channel-attached systems only 2-10
3. Printer components and options 3-1
Printer components 3-1
Printer control console 3-3
Printer options 3-4
High-capacity feeder 3-4
Dual stacker 3-5
Stitcher/stacker 3-6
Customer-changeable unit (CCU) 3-7
Bypass transport option (4890 only) 3-8
Interface with third-party devices 3-9
Electrical interface 3-9

TABLE OF CONTENTS
vi XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
4. Preparing for installation 4-1
Responsibilities 4-1
Xerox responsibilities 4-1
Customer responsibilities 4-2
Installation planning checklist 4-4
Connectivity requirements 4-7
Ethernet specifications 4-7
Token Ring specifications 4-7
5. Controller specifications and requirements 5-1
Power requirements 5-1
Outlet configurations 5-2
Environmental specifications 5-3
Space requirements 5-4
Printer controller placement 5-4
Controller hardware specifications and requirements summary 5-9
6. Printer specifications and requirements 6-1
Power requirements 6-1
Outlet configurations 6-2
Printer outlet voltages—60 Hz 6-2
Printer outlet voltages—50 Hz 6-3
Environmental specifications 6-4
Space requirements 6-5
Printer placement 6-5
CCU changeout cart 6-10
Space planning guidelines 6-11
Clearance space requirements 6-11
Shared space 6-11
Floor leveling 6-15
Delivery access requirements 6-15
Printer hardware specifications and requirements summary 6-18
Space planning templates 6-20
7. System connections 7-1
Cable lengths 7-1
Cable locations 7-2
Channel attachments 7-2
8. Installation 8-1
Installation process 8-1
Your responsibilities 8-2
Defining the IPS printer to the host 8-3

TABLE OF CONTENTS
XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE vii
Software licensing 8-3
Ongoing maintenance 8-4
Routine maintenance 8-4
Meter reading and reporting 8-4
A. Supplies A-1
Paper and other throughput stocks A-1
Selecting paper A-1
Paper care A-3
Other supplies A-6
Dry ink A-6
Fuser lubricant A-6
Developer A-6
Stitcher wire A-7
Diskettes A-7
Cartridge tapes A-7
Fonts A-7
Consumable supplies tables A-8
Paper and special stocks tables A-8
Complete supplies list—4850/4890 printers A-11
Ordering supplies A-13
B. Xerox support services B-1
Xerox Customer Service Support Center B-1
Xerox Printing Systems Customer Support Center B-2
Xerox Customer Documentation Catalog B-3
Xerox Documentation and Software Services (XDSS) B-3
Operator training B-3
Xerox Customer Education B-4
Xerox Font Center B-4
C. Related publications C-1
D. Defining the channel-attached printer to the host D-1
MVS parameters D-1
OS/2 procedures D-4
AIX procedures D-5
VM sample definitions D-6
VSE sample definitions D-6
E. Defining the printer to the host: TCP/IP attachment E-1
MVS or OS/390 parameters E-1
Software prerequisites –MVS E-1

TABLE OF CONTENTS
viii XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
Network configurations –MVS E-1
Configuration steps –MVS E-2
1. Configure the IPS printer for TCP/IP at the GUI E-2
2. Configure the MVS CCU for the MVS host to MVS E-2
3. Configure the PSF printer in JES2 or JES3 E-2
4. Configure the printer in PSF/MVS E-7
5. Configure TCP/IP for MVS for the printer E-11
6. Test the printer to ensure it prints from the MVS host E-14
Correcting for printer performance issues –MVS E-16
References E-17
AS/400 parameters E-18
Software prerequisites –AS/400 E-18
Network configurations –AS/400 E-18
Configuration steps –AS/400 E-19
1. Configure the IPS printer for TCP/IP at the GUI E-19
2. Create the PSF/400 configuration E-19
3. Create the printer device description –AS/400 E-20
4. Test the printer connection –AS/400 E-22
Correcting for printer performance issues –AS/400 E-24
References –AS/400 E-24
AIX parameters E-25
Software prerequisites –AIX E-25
Network configurations –AIX E-26
Configuration steps—AIX E-26
References E-27
OS/2 parameters E-28
Software prerequisites –OS/2 E-28
Network configurations –OS/2 E-28
Configuration steps –OS/2 E-29
1. Configure the printer for TCP/IP in OS/2 E-29
2. Provide TCP/IP routing information if necessary E-29
3. Define the printer to PSF/2 E-30
4. Define a PSF/2 print queue for the printer (optional) E-31
5. Test the printer connection in OS/2 E-32
Correcting for printer performance issues –OS/2 E-34
References –OS/2 E-35
Glossary GLOSSARY-1
Index INDEX-1

XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE ix
Introduction
This Xerox Printing Systems Installation Planning Guide helps you
prepare for delivery and installation of your new Xerox DocuPrint
printing system.
About this guide
This guide is intended for the person responsible for coordinating the
installation of the DocuPrint printer at your site. It lists the tasks you
must complete before installation can begin, as well as your
responsibilities during the installation.
Before using this guide, become familiar with its contents and
conventions.
Contents
This guide contains the following:
•Chapter 1, "Product overview," provides an overview of the
DocuPrint 4850 and 4890 printing systems.
•Chapter 2, "Controller components and options," describes
system controller hardware, software, and options.
•Chapter 3, "Printer components and options," describes printer
components, configurations, and options.
•Chapter 4, "Preparing for installation," provides a checklist of
tasks that must be accomplished before the installation. It also
explains connectivity requirements for transporting documents
from the host or client to the DocuPrint printing system.
•Chapter 5, "Controller specifications and requirements,"
describes power, environmental, and space requirements for
the system controller.
•Chapter 6, "Printer specifications and requirements," describes
power, environmental, and space requirements for the printer.
Space planning guidelines and diagrams are provided to help
you set up the work area.
•Chapter 7, "System connections," provides cable requirements
for your DocuPrint 4850 and 4890 printing systems.
•Chapter 8, "Installation," describes the activities that occur
during installation. It also describes ongoing maintenance
activities.
•Appendix A, "Supplies," describes how to select, store, and use
supplies for the DocuPrint printing system. It also provides a list
of consumable supplies you can order.

INTRODUCTION
x XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
•Appendix B, "Xerox support services," explains how to utilize
available Xerox support services.
•Appendix C, "Related publications," lists other Xerox
documents that are part of this publication set.
•Appendix D, "Defining the channel-attached printer to the host,"
provides explanations and sample printer parameters for
defining your channel-attached printer to your host.
•Appendix E, "Defining the printer to the host: TCP/IP
attachment," provides instructions, prerequisites, and sample
printer parameters for defining your TCP/IP-attached printer to
your host.
A glossary and index are provided at the back of the guide.
Conventions
This document uses the following conventions:
Italics—Document and library names are shown in italics (for
example, the Xerox DocuPrint IPS Series Messages Guide).
Note: Notes are hints that help you perform a task or understand
the text.
Caution: Cautions alert you to an action that could damage
hardware or software.
!Warning: Warnings alert you to conditions that may affect the
safety of people.
Notice
This publication may contain descriptions of concepts and features
not currently available for your Xerox printing system. Consult your
Xerox sales representative or your operating system software
program description for additional information.


XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE 1-1
1. 1Product overview
This chapter provides an overview of the features and functions of
the Xerox DocuPrint 4850 IPS and the 4890 IPS.
System overview
The Xerox DocuPrint 4850 IPS and 4890 IPS are cut-sheet, duplex
highlight color printers that are fully compatible with the IBM AFP
architecture. They accept an IPDS data stream from any PSF eligible
platform, including MVS, VM, VSE, OS/2, OS/400 (with TCP/IP only),
and AIX. They are plug-compatible in the AFP/IPDS environment,
and emulate an IBM IPDS Group 3 page printer with the AFIG
(Advanced Function Image and Graphics) option.
The IPS printer series is a combination of proven Xerox print engines
matched with a high-performance RISC-based controller. Each
system consists of a Sun workstation controller and the printer,
sometimes referred to as the Image Output Terminal (IOT).
Host environments The IPS emulates an IBM AFP Group 3 page printer with the
Advanced Function Image and Graphics (AFIG) option and can print
in all the following PSF environments:
•MVS
•VM (channel-attached only)
•VSE (channel-attached only)
•OS/2
•OS/400 (with TCP/IP only)
•AIX
Note: Although PSF/VSE does not support TCP/IP directly, a
printing system with PSF/2, PSF/6000, or InfoPrint Manager can
attach to a PSF/VSE system and the PSF/2, PSF/6000, or InfoPrint
Manager can furnish the TCP/IP support for the IPS printer.
Note: There is no minimum host operating system software level
required to support IPS. The minimum PSF levels needed to support
the IPS are:
•PSF/MVS: V2.1
•PSF/VM: V2.1
•PSF/VSE: V2.2
•PSF/400: V3.2
•PSF/6000: V2.1
•PSF/2: V2.0

PRODUCT OVERVIEW
1-2 XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
The DocuPrint IPS can be set up to receive data from the IBM host
in one of two ways:
•Through a bus and tag channel connection.
Note: If your system will be channel-attached, the printer
controller requires an additional component called a Host
Channel Unit (HCU), which interfaces between the IBM host and
the IPS controller.
•Through a Token Ring or Ethernet interface using TCP/IP (the
HCU is not used).
Note: A transmission rate of at least 16 megabits per second
should be used with a Token Ring interface on the IPS. (Overall
performance depends on network traffic and job density.)
•The software supports Token Ring over TCP/IP, and
Ethernet over TCP/IP, with the exception of VM and VSE
platforms.
•Of the other platforms that support TCP/IP, only the
RS/6000 supports 100 Mb Ethernet connectivity.
Note: Customers can have multiple connectivities (Token
Ring, Ethernet, or Bus and Tag), but only one type of
connectivity can be active at any given time.
Data is printed at production speeds:
•4850 IPS: Up to 50 impressions per minute
•4890 IPS: Up to 92 impressions per minute.
A full-color graphical user interface on the Sun workstation enables
interaction with the IPS.
Figure 1-1. Xerox 4850/4890 IPS: channel-attached
configuration
1 Host system (PC or mainframe)
2 4850 or 4890 IPS printer
3 Printer interface cable (DCIM2)
4 Sun workstation controller
5 SCSI interface
6 Host Channel Unit (HCU)
7 Bus and tag cables
1
7
65
4
3
2
IBM
Host

PRODUCT OVERVIEW
XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE 1-3
Figure 1-2. 4850/4890 IPS: TCP/IP configuration
1 Host system (PC or mainframe)
2 Token Ring or Ethernet network connection
3 Sun workstation controller
4 Printer interface cable (DCIM2)
5 4850 or 4890 IPS printer
For information on the various IPS printer configuration options, refer
to the “Printer components and options”chapter of this guide.
4850/4890 IPS hardware features
The 4850/4890 IPS systems provide numerous features that can be
accessed with standard AFP compatible software products. The
following features are available and can be enabled or configured
using the graphical user interface on the printer controller:
•Highlight color —The 4850 and 4890 IPS have the capability
of printing in one highlight color plus black. A number of inks are
available for adding color to documents: red, green, blue, cyan,
magenta, brown, cardinal, royal, ruby, and violet.
When a colored ink is installed in the IPS, you can combine
black and the additional color under software control to:
—Create darker shades by mixing black and a color
—Create lighter tints by letting the white of the paper show
through between the black or colored dots.
•Up to four input trays —Two addressable input trays are
standard with the printing system. Two additional feeder trays
are available as options. These trays can be used to configure
print jobs in the most effective manner. For example, the trays
can be used to provide nonstop printing of a complex job that
requires multiple paper stocks, or only a few paper stocks, but
using the continuous loading capability of the input trays. A
different tray can also be selected for each copy of a specific
page in a print job; for example, to provide different paper colors
for specific pages.
Feeder tray capacities, based on 20-pound or 80 gsm (grams
per square meter) bond, are:
—Tray 1: 1000 sheets
—Tray 2: 500 sheets
—High-capacity feeder trays (3 and 4): 1000 sheets each.
•Advanced paper handling —The IPS can handle paper
stocks ranging in size from 8 by 10 inches / 203 by 254 mm to
8.5 by 14 inches / 216 by 356 mm, including A4, and in weight
from 20-pound or 80 gsm bond to 110-pound / 200 gsm index.

PRODUCT OVERVIEW
1-4 XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
Jobs can also be printed on special stocks such as labels and
transparencies.
The printer engine monitors the print job so that, should a paper
jam occur, the job resumes on the correct page, providing
complete document integrity.
•300 dpi resolution —The 4850 and 4890 IPS provide high
print quality at 300 dpi resolution. They can receive data at 240
or 300 dpi; 240 data is converted to 300 by the controller.
The IPS must be configured to the same font resolution as the
host input data stream (refer to your 4850/4890 IPS Guide to
Configuring and Managing the System for instructions on
configuring for the correct input resolution). Conflicts between
the input font resolution and the IPS configuration could result
in inability to print the job, or in variable data missing from the
output.
Note: You will normally achieve better print quality by
converting all 240 dpi fonts and other resources to 300 dpi
before printing, rather than leaving the conversion for the
controller to do. However, you should always run test prints to
validate your particular applications.
•Bypass transport option (4890 IPS only) —The bypass
transport enables sheets to pass through the printer output
module to a third-party finishing device. With such a device, you
add to your 4890 IPS such finishing capabilities as saddle-
stitching, binding, trimming, etc. The bypass transport fits into
tray 1 of the dual stacker, and can be easily removed and
installed by the operator. (For further information on this option,
refer to the “Bypass transport specifications”appendix of this
guide.)
•Sixth Sense Remote Service —The Xerox Sixth Sense
Remote Service feature allows Xerox support personnel to
access IPS/NPS controller via modem from a remote location.
More information about Remote Service can be found in the
Xerox DocuPrint 4850/4890 IPS Troubleshooting Guide.
•Choice of dual or stitcher stacker —Your 4850/4890 IPS is
available with one of two stacker types: a dual stacker, with two
output trays, or a stitcher/stacker which can place a wire stitch
in sets of up to 50 sheets.
Output tray capacities, based on 20-pound or 80 gsm stock,
are:
—Dual stacker trays 1 and 2: 750 sheets each
—Stitcher/stacker: 2000 sheets.

PRODUCT OVERVIEW
XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE 1-5
NPS/IPS Dual Mode
The Xerox DocuPrint Dual Mode option enables both DocuPrint IPS
and NPS systems to coexist on the same printer controller (Sun
workstation). This allows the DocuPrint system to receive data
streams supported by NPS and IPS, including IPDS, PostScript
Levels 1 and 2, HP PCL5c, HP PCL5e, and ASCII.
Either of the following two types of configurations may be used:
•The same Token Ring or Ethernet connection can be used for
both IPDS (IPS) and Postscript/PCL (NPS).
•Both a Token Ring card and an Ethernet card can reside in the
Sun workstation controller, with one being used for IPDS and
the other for PostScript/PCL.
The customer may switch from one mode to the other. When your
system is operating in IPS mode, it can accept PostScript and PCL
data streams in the background; however, you can print these jobs
only when the system is in NPS mode. When in NPS mode, the
system cannot accept IPDS data streams in the background; you can
print them only when the system is in IPS mode.
Refer to the Xerox DocuPrint IPS/NPS Dual Mode Switching
Instructions and other Xerox DocuPrint IPS documentation for more
information.
Sixth Sense
Sixth Sense is a unique suite of diagnostic tools that allows Xerox
customer service engineers, analysts, and consultants to serve
customers more effectively.
Sixth Sense is intended to automate and expedite the range of
service-related support functions. Sixth Sense is a tool that enables
Xerox to provide benchmark service support. Xerox customers
benefit from the ability to bring broader support to focus more quickly.
For example, Sixth Sense can allow the Service Representative to
repeatedly "preview" the condition of the system prior to an actual
site visit. This may provide the ability to determine the correct part or
piece of information to have on hand when the site visit is made.
Sixth Sense is a no charge feature available to customers through
Xerox Service. The customer need only provide an analog phone line
for use by the Sixth Sense modem connection. For those customers
unable to dedicate a phone line to the Sixth Sense connection, three
and five port phone share devices are available for purchase.
To take advantage of Sixth Sense, the customer needs to:
•Request Sixth Sense enablement through Xerox Service
•Provide an analog phone line
•If necessary, purchase an optional phone share device.
More information about the Sixth Sense can be found in the Xerox
DocuPrint 4850/4890 NPSIPS System Administration Guide.

PRODUCT OVERVIEW
1-6 XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
Base system components
The IPS system consists of the following major components:
•Printer controller —The printer controller (also called the
system controller) accepts IPDS data from the host, processes
the data, and sends the data to the printer engine using the IPS
operating system. The controller provides the printer with print
data and commands, and receives status information from the
printer.
•Printer —The printer, also called the Image Output Terminal
(IOT), accepts formatted pages of data from the printer
controller and performs the imaging and printing of documents.
The printer also provides paper stacking, collating, and optional
finishing capabilities you enable using the IPS application
software accessed through the graphical user interface.

XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE 2-1
2. 2Controller components and
options
The printer controller provides the printer with print data and
commands, and receives status information from the printer. This
chapter describes the components and options available for the
controller.
Controller hardware
The printer controller consists of a Sun workstation and, if you are
printing data received over a channel, a Host Channel Unit (HCU).
The controller uses proprietary Xerox hardware, firmware, and
software to run the IPS.
Your controller may be either a Sun Ultra 2 or Ultra 60 workstation.
The following sections contain information about both the Ultra 2 and
the Ultra 60.
Sun Ultra 2 workstation
The Sun workstation provides a user interface to the print engine. It
is used to operate the IPS software which controls the printer. The
workstation contains the following hardware components:
•Sun Ultra 2 workstation processor (system unit)
•Display monitor
•Keyboard and mouse
•Connectivity boards for Ethernet and, optionally, Token Ring
•A Data Control Interface Module (DCIM2) card installed in the
processor to interface with the print engine.

CONTROLLER COMPONENTS AND OPTIONS
2-2 XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
Figure 2-1. Components of the Sun Ultra 2 workstation
1 Processor
2 Monitor
3 Mouse and mouse pad
4 Keyboard
5 Diskette drive
6 CD-ROM drive
Processor The processor is the central processing unit of the Sun workstation.
It contains a power switch, an internal disk drive, a diskette drive, a
CD-ROM drive, a power receptacle and outlet, connectors and ports.
The processor has the following components:
•Internal disk drive: One high-speed internal disk drive is
provided as a standard feature of the processor. The operating
system, the IPS application, and any queued print jobs are
stored on the internal disk. This disk cannot be used to store
other applications or data except as directed by your service
representative.
•Diskette drive: Diskettes inserted into a diskette drive are used
to load files to, and back up files from, the internal disk drive.
The diskette drive uses industry standard 3.5 inch, 1.44 Mb,
double-sided, high-density diskettes. This diskette drive is not
an input source for print jobs nor any other data or application; it
is reserved exclusively for use by a service representative to
update software and to store files. The diskette drive is located
in the processor, on the right front section for the Ultra 2.
1
3
4
2
6
5

CONTROLLER COMPONENTS AND OPTIONS
XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE 2-3
•CD-ROM drive: The CD-ROM drive is a high density, read-only,
optical laser storage device used for loading the IPS operating
system and other files. The CD-ROM drive is located in the
processor above the floppy drive.
•Cartridge tape drive (not shown): An optional 8 GB, 4 mm
SCSI cartridge tape drive also is available for the IPS. Like the
diskette and CD drives, this tape drive is not an input source for
print jobs or for any other data or application. It provides the
service representative with another means of loading system
maintenance files or saving diagnostic information.
Caution: When installing a cartridge drive on an IPS with a
host channel unit (HCU), the tape drive must be “daisy-chained”
to the HCU. In this situation, do not attempt to run both the tape
drive and the HCU at the same time.
•Back panel: The back panel of the processor has a power
switch, a power receptacle and outlet, connectors, connector
openings, and ports. The following figure shows the back panel
of the Sun workstation that is part of your IPS controller.
Figure 2-2. Back panel of the Sun Ultra 2 processor
1 Power inlet
2 Serial connectors (2): RS-432/RS-232
3 Graphics/video output: UPA slot
4 Sbus slots (Number of slots varies depending on the model)
5 Audio connectors (4)
6 Parallel connector
7 Keyboard/mouse connector
8 TPE connector
9 MII connector
10 UPA slot
11 SCSI connector
12 Power on/Standby switch
Note: The controller back panel contains two serial ports on
one DB-25 connector. Both ports are used exclusively by the
IPS software for diagnostic purposes. The ports and diagnostic
software are accessed only by the service representative.
11 98765
12
1234
10
3
20
1

CONTROLLER COMPONENTS AND OPTIONS
2-4 XEROX DOCUPRINT 4850/4890 IPS INSTALLATION PLANNING GUIDE
Display monitor The display monitor has a 1192 x 700 pixel screen which displays the
IPS graphical user interface windows.
Keyboard The keyboard consists of alphanumeric keys similar to a typewriter,
symbols and special character keys, an extended character set, and
function keys. The keyboard is one of your main methods of
communicating with the printer. You can use the keyboard to make
selections, and to enter commands that control functions such as
requesting sample prints, obtaining billing meter totals, shutting down
the system, and so forth.
Mouse The mouse is another main method of communicating with the
printer. The mouse has three buttons. The left and right buttons are
used to select IPS functions. The center button provides additional
functions that you will not be required to use. If your workstation has
an optical mouse, it must remain on its designated metallic pad to be
active. If the mouse has a roller ball instead of an optical sensor
underneath, it requires a non-metallic pad.
Note: Printer controller hardware configurations are subject to
upgrade.
Sun Ultra 60 workstation
The Sun Ultra 60 workstation provides a user interface to the print
engine. It has a high performance RISC processor chipset, based on
the industry standard Scalable Processor Architecture (SPARC). It is
used to operate the software that controls the printer. The
workstation contains the following hardware components:
•Sun Ultra 60 workstation processor (system unit)
•Display monitor
•Keyboard and mouse
•Diskette, CD-ROM, and cartridge tape drives
•Connectivity board for Ethernet and, optionally, Token Ring
•A Data Control Interface Module (PDCIMu) card installed in the
processor to interface with the print engine.
