Xiaomi Xiaowa E2 Series User manual

User Manual of Xiaowa Robotic Vacuum Cleaner
Please read this user manual carefully before use and keep it well for future reference

IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING (THISAPPLIANCE), Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
WARNING
To reduce the risk of fire, electric shock, or injury:
Do not use outdoors or on wet surfaces
Do not allow to be used as a toy. Close attention is necessary when used by or near children, pets or plants.
Use only as described in this manual. Use only manufacturer’s recommended attachments
Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service center.
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners.
Do not run appliance over cord. Keep cord away from heated surfaces.
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
Do not handle charger, including charger plug, and charger terminals with wet hands
Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything
that may reduce air flow.
Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present.
Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
Do not use without dust bag.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to battery pack, picking
up or carrying the appliance. Carrying the appliance with your finger on the switch or energizing appliance that
have the switch on invites accidents.
Safety Information
1

For use only with xiaowa CDZ03RR or CDZ04RR charger.Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
Use appliances only with specifically designated battery packs. Use of any other battery packs may create a risk of
injury and fire.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush
with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation
or burns.
Do not use a battery pack or appliance that is damaged or modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk of injury.
Do not expose a battery pack or appliance to fire or excessive temperature. Exposure to fire or temperature above
130°C may cause explosion.
Follow all charging instructions and do not charge the battery pack or appliance outside of the temperature range
specified in the instructions. Charging improperly or at temperatures
outside of the specified range may damage the battery and increase the risk of fire.
Have servicing performed by a qualified repair person using only identical replacement parts.This will ensure that
the safety of the product is maintained.
Do not modify or attempt to repair the appliance or the battery pack except as indicated in the instructions for use
and care.
Place the cords from other appliances out of the area to be cleaned.
Do not operate the vacuum in a room where an infant or child is sleeping.
Do not operate the vacuum in an area where there are lit candles or fragile objects on thefloor to be cleaned.
Do not operate the vacuum in a room that has lit candles on furniture that the vacuum may
accidentally hit or bump into.
Do not allow children to sit on the vacuum.
Safety Information
2

Do not use the vacuum cleaner on a wet surface.
Risk Of Injury. Brush May Start Unexpectedly.Disconnect the main Brush Before Cleaning or Servicing.
Do not use the product when the temperature is higher than 40℃ or lower than 4℃, or there is any liquid or sticky
substance on the floor
SAVE THESE INSTRUCTIONS
Household use only
Safety Information
3
IMPORTANTES MESURES DE S CURIT
L’utilisation d’un appareil électrique demande certaines précautions:
LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CETAPPAREIL), Le non-respect des mises
en garde et des instructions peut causer des chocs électriques, des incendies et/ou des blessures graves.
AVERTISSEMENT
Pour réduire les risques d’incendie, de choc électrique ou de blessure:
Ne pas exposer à la pluie, Ranger à l’intérieur.
Ne pas permere aux enfants de jouer avec l’appareil. Une aention particulière est nécessaire lorsque
l’appareil est utilize par des enfants ou à proximité de ces derniers.
N’utiliser que conformément à cee notice avec les accessories recommandés par le fabricant.
Ne pas utiliser si le cordon ou la fiche est endommagé. Retourner l’appareil à un atelier de reparation s’il
ne fonctionne pas bien, s’il est tombé ou s’il a été endommagé, oublié à l’extérieur ou immergé.
Ne pas tirer soulever ni trainer l’appareil par le cordon. Ne pas utiliser le cordon comme une poignée, le
coincer dans l’embrasure d’une porte ou l’appuyer contre des arêtes vives ou des coins. Ne pas faire
rouler l’appareil sur le cordon. Garder le cordonà l’écart des surfaces chaudes.
Ne pas débrancher en tyrant sur le cordon. Tirer plu la fiche.

Ne pas manipuler le chargeur, y compris la prise du chargeur, et les bornes du chargeur avec les mains mouillées
N’insérer aucun objet dans les ouvertures. Ne pas utiliser l’appareil lorsqu’une ouverture est bloquée. S’
assurer que de la poussière, de la peluche, des cheveux ou d’autres matières ne réduisent pas le debit d’air.
Maintenir les cheveux, les vêtements amples, les doigts et toutes les parties du corps à l’écart des ouvertures
et des pieces mobiles.
User de prudence lors du neoyage des escaliers.
Ne pas aspirer des liquids inflammables ou combustibles, comme de l’essence, et ne pas faire fonctionner
dans des endroits où peuvent se trouver de tells liquides.
Ne pas aspirer de matières en combustion ou qui dégagent de la fumée, comme des cigarees, des allumeesou
des cendres chaudes.
Ne pas utiliser l’appareil si le sac à poussière ou le filter n’est pas en place.
Safety Information
4
Emêcher une mise en marche accidentelle. S’assurer que l’interrupteur est à la position arrêt avant de
raccorder la baerie, de lever ou de déplacer l’appareil.
Transporter l’appareil en gardant un doigt sur l’interrupteur, ou mere sous tension un appareil dont
l’interrupteur est à la position marche peut causer un accident.
Pour emploi seulement avec xiaowa CDZ03RR ou CDZ04RR chargeur.Recharger uniquement avec le
chargeur prescrit par le fabricant. Un chargeur convenant à un type de baerie peut présenter un risque d’
incendie lorsqu’il est utilisé avec une autre baerie.
Utiliser uniquement les baeries recommandées pour l’appareil. L’utilisation d’autres types de baeries
peut présenter un risque de blessure ou d’incendie.
Lorsque l’appareil n’est pas utilisé, tenir la baerie loin d’objets métalliques comme des trombones, des
pièces de monnaie, des clés, des clous, des vis ou autres petits objets qui pourraient établir une liaison entre
les bornes. Un courtcircuit des bornes des baeries peut causer des brûlures ou un incendie.
Encondition d’usage abusif, du liquide peut s’échapper de la baerie ; éviter tout contact avec ce liquide.
En cas de contact accidentel, rincer abondamment avec de l’eau. En cas de contact avec les yeux, consulter
également un médecin. Le liquide projeté peut causer des irritations ou des brûlures.

Ne pas utiliser une baerie ou un appareil endommagé ou qui a été modifié. Des baeries endommagées
ou modifies peuvent avoir un comportement imprévisible pouvant causer un incendie, une explosion ou
un risque de blessure.
Ne pas exposer une baerie ou un appareil à la flamme ou à des températures excessives. L’exposition à
une flamme ou à des températures supérieures à 130 °C peut causer une explosion.
Respecter toutes les instructions de chargement et ne pas charger la baerie ou l’appareil à des températures
qui ne sont pas incluses dans la gamme de températures indiquées dans la notice d’instructions.
Un chargement mal effctué.
Confier les réparations à une personne qualifiée qui utilisera uniquement des pièces de remplacement
identiques. Cee façon de faire garantira la sécurité du produit.
Ne pas modifier ni tenter de réparer l’appareil ou la baerie sauf comme il est indiqué dans les instructions
d’utilisation et d’entretien.
Éloigner les cordons d’autres appareils de la zone à neoyer.
Ne pas utiliser l’aspirateur dans une pièce où un nourrisson ou un enfant dort.
Ne pas utiliser l’aspirateur dans un endroit où il ya des bougies allumées ou des objets fragiles sur le plancher
à neoyer.
Ne pas utiliser l’aspirateur dans une pièce où il ya des bougies allumées sur les meubles que l’aspirateur
peut heurter ou se cogner accidentellement.
Ne pas laisser les enfants s’assoir sur l’aspirateur.
Ne pas utiliser l’aspirateur sur une surface mouillée.
Risque de blessures. La brosse motorisée peut se mere en marche d’une manière imprévue.
Déconnecter la brosse principale avant le neoyage ou le service.
Safety Information
5
CONSERVER CES INSTRUCTIONS
Usage Domestique seulement
Laser Safety
Class I Laser Product, complies with FDA 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser
Notice. No.50, dated June 24, 2007.

FCC Statement
6
Warning:
Any changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
Compliance Information
Correspondence of the responsible party in USA
Product Name Robotic Vacuum Cleaner with Dock Charger
Company Roborock Technology Co.
Email [email protected]
Address 108 West 13th Street, Wilmington, Delaware 19801.
Compliance Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation
Produce Model
E2 ,E3 （ can
***** ***** *
Robotic Vacuum Cleaner Model:
be 0 to 9, A to Z, a to z, "-", "_", "\", "/" or blank,
for marketing purpose.)
Dock Charger Model: CDZ03RR , CDZ04RR

Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Statement
MPE Requirements
To satisfy FCC / IC RF exposure requirements, a separation distance of 20 cm or more should be maintained
between the antenna of this device and persons during device operation.
To ensure compliance, operations at closer than this distance is not recommended.
L’antenne installée doit être située de facon à ce que la population ne puissey être exposée à une
distance de moin de 20 cm. Installer l’antenne de facon à ce que le personnel ne puisse approcher
à 20 cm ou moins de la position centrale de l’antenne.La FCC des éltats-unis stipule que cet appareil
doit être en tout temps éloigné d’au moins 20 cm des personnes pendant son functionnement.
CAN ICES-3 (B)/NMB-3(B)
7

Battery and Charging
Please keep the dock charger away from heat (such as heating plates)
The battery must be removed from the appliance before it is scrapped
Do not wipe or clean the chargers shrapnel with a piece of wet cloth or wet hands
Please make sure the cleaner is powered off in shipment and original packaging is advised
If left unused for a long period, please store the cleaner in a cool and dry place after having it fully charged and
switched off, charge it at least every three months to avoid the battery being over discharged
Please do not use the product when the temperature is higher than 40℃ or lower than 4℃, or there is any
liquid or sticky substance on the floor
The battery is to be disposed of safely.Please do not discard waste batteries. Leave them to a professional recycling
organization
The appliance must be disconnected from the supply mains when removing the battery
8
Battery pack charging temperature
Battery pack using temperature
4℃~40℃ @Max Charging Current:0.5C
4℃~40℃ @Max Discharge Current:0.5C
Battery pack storage
temperature
Storage(1month) -20℃~60℃
@Less than 70% RH
If the battery pack store at 25℃over the 3
months period, it should be recharged.
Long Storage(3months) -20℃~45℃
@Less than 70% RH
Long Storage(1year) -20℃~20℃
@Less than 70% RH

Machine
Introduction
Cover lift
POWER light
White: battery capacity ≥ 20%
Red: battery capacity ＜ 20%
Slow flashing: Charging or starting up
Flashing in red: Faulty state
Clean/ON&OFF
Press to start cleaning
Press and hold to power on or off
Spot cleaning
Press to start spot cleaning
Note: press any key to pause cleaning,
recharging or spot cleaning midway
Recharge
Press to start recharging
9
Reset WIFI
Press and hold and for 3 seconds

Part list
Introduction
10
Power cable
Mopping cloth
Dock charger
Water tank
Moistureproof mat
Main brush cleaning tool

Dust bin
Introduction
Machine
11
WIFI indicator
Slow flashing:
Waiting for connection
Fast flashing: Connecting
Glowing: WIFI is
connected
Strainer
Dust bin buckle
Speaker
Air outlet
Dust bin cover

Machine and sensor
Introduction
12
Side brush
Omni-directional wheel
Bumper
Charging contact pieces
Motion tracking sensor
Main brush
Main wheel
Main brush cover buckle
Cliff Sensor
IR decelerate sensor
Omni-directional
recharge sensor
Dock charger
Dock charger
indicator
Charge tab
Power connector
Charge tab
Signal transmitting area

Installation
13
Power on and charge3
Press and hold the key to power on, wait until the power
light is normally on, and then dock the machine body to the
dock charger for charging
The machine is equipped with a built-in high performance
lithium-ion rechargeable battery pack. To maintain battery
performance, please keep the machine charged for normal use.
Clip the dock charger into the groove of the
waterproof mat and install it in place
1
Notes:
Ensure that 0.5 m or above in two sides and 1.5 m in the front are
retained for the dock charger
The power cable, when being vertical to the floor, may be dragged by
the machine body, thereby resulting in displacement or disconnection
of the dock charger
The dock charger indicator is normally on when the dock charger is
electrified, and off when the dock charger works
Place the dock charger against a wall on a
level floor and connect it to the power supply
2
Connect your mobile phone client (this can be skipped)4
Note: The machine may not be powered on when the battery is low.
Please directly dock the machine body to the dock charger
More than 0.5 m
More than 0.5 m
More than 1.5 m
The color of the POWER light
indicates the battery level
White: battery capacity ≥ 20%
Red: battery capacity < 20%

Installation
14
The product is compatible with Mi Home intelligent platform and could be controlled by Mi Home app.
It supports the MIUI system and can be interconnected with other Mi Home intelligent products
Quick Setup
Download App
Search "Mi Home" in App store/Google play or scan the QR code below to download and install the Mi Home app.
If anything is wrong with WIFI connection, you could try to reset WIFI to default.
Open upper cover to check the WIFI indicator status next to reset button. Press and hold the key and key until you hear the voice
"Reset WIFI ". The resetting is completed when the WIFI indicator starts to flash slowly and the cleaner will enter a pending connection
state.
1
2
Go to "My Device" page of Mi Home app and tap "+" on the top right corner of the page to add a device. You could find newly added
device on "My Device" list
Add Device
3Reset WIFI

Installation
15
Note: When your mobile phone fails to connect to the machine,
please refer to "User Manual" - "Reset WIFI"
Slow flashing: Waiting for connection
Fast flashing: Connecting
Glowing: WIFI is connected
WIFI indicator
Install the mopping module5
1Install the module: push the module in parallel along the
alignment signs on the rear of the machine and on the
mopping module. It is installed in place when you hear
a "click" sound.
Note: Do not use the mopping module when there is nobody at home
Note: To get better mopping effect, it is recommended to install
the mopping module after cleaning for 3 times
Refill the water tank: open the water tank and reinstall the water
tank cover after refilling with tap water
Note: Please be aware that some floor cleaners or disinfectants may
cause blockage of the water tank filter
Install the mopping cloth: dampen the mopping cloth and
squeeze it dry. Insert it to the end along the slot of the
water tank and stick it firmly
2
3

Installation
When the power light changes from white breathing flash to
normally on, charging completes. Press the key or use your
mobile phone client to start cleaning
Start cleaning6
16
Note:
Do not use the mopping module when there is nobody at home
It is recommended to clean the mopping cloth every 30 minutes to ensure
water flow rate and cleaning effect
After the machine completes cleaning and returns to the dock
charger, use your hands to push two buckles in two sides, drag
the mopping module backwards and remove it
Remove the mopping module7
Note:
Remove the mopping module when the machine is charging or left unused.
Empty water residue in the water tank and clean the mopping cloth to
prevent mildew or undesirable odor
When the dock charger is placed on a wooden floor, always place a
moisture-proof mat thereunder to avoid moisture on the floor
Routine Maintenance
Note: It is recommended to replace the main brush every 6-12
months to ensure the cleaning effect
Main brush Clean weekly
1. Flip the machine over and push the buckle to remove
the main brush cover
2. Lift the main brush up and clean its bearing
3. Use the supplied main brush cleaning tool to cut off
hair entangled onto the main brush
4. Reinstall the main brush and clamp tightly the buckle
on the main brush cover
Use of main brush cleaning tool
Buckle
Main brush cover
Main brush
Main brush bearing
*

Routine Maintenance
17
Dust bin and strainer Clean weekly
1. Remove the top cover of the machine and press the
dust bin buckle to lift up and remove the dust bin
2. Open the dust bin cover as indicated by arrow, and empty trash out
*Clean the washable strainer Clean every two weeks
1. Open the dust bin cover as indicated by arrow
2. Fill the dust bin with clean water and close the cover. Shake the
dust bin and then pour out the dirty water
Note: Please rinse with clean water without adding any detergents
*

18
Routine Maintenance
3. Remove the filter and rinse with water
4. Rinse repeatedly and lightly pat the filter to remove any dirt.
Continue until it is clean
5. Dry the filter thoroughly and reinstall it before use
Note: Do not touch the surface of the filter with hands, brushes or sharp
objects so as to avoid damaging the filter
Note:
Always dry the filter thoroughly before use (dry for at least 24 hours)
It is recommended to alternate between two strainers
Note: flush it with tap water and reinstall after drying
1. Flip the machine over and lift the omni-directional wheel up
2. Remove hair and dirt on the wheel body and axle
3. Reinstall the wheel body and press tightly
Omni-directional wheel Clean monthly
Wheel body
Axle
Rack
Side brush Clean monthly
1. Flip the machine over to remove the fixing screw on the side brush
2. Remove and clean the side brush
3. Reinstall the side brush and tighten the screw
Note: It is recommended to replace the side brush every 3-6 months
to ensure the cleaning effect
*
*
