XPower B-8S User manual

OWNER’S MANUAL
MODEL: B-8S (115V/60Hz)
XPOWER MANUFACTURE, INC.
220 Clary Avenue
San Gabriel, CA 91776, USA
Tel: [phone] Fax: [phone]
www.xpower.com
PLEASE READ AND SAVE THESE INSTRUCTIONS
PET DRYER + HEATER
Nozzles included

TABLE OF CONTENTS
Introducon ..........................................................................................................................................
Operaon ..............................................................................................................................................
Specificaons ........................................................................................................................................
Important Safety Instrucons ...............................................................................................................
Grounding Instrucons .........................................................................................................................
Parts List ...............................................................................................................................................
Maintenance .........................................................................................................................................
Warranty / Service ................................................................................................................................
Warranty Registraon Form .................................................................................................................
1
2
2
3
4
5
6
7
9

INTRODUCTION
Thank you for purchasing an XPOWER B-8S professional force dryer. Featuring advanced BRUSHLESS
technology, the B-8S will outlast standard brush motor dryers with its 7,000+ hour motor. Enjoy full
control when drying or styling with variable heat and speed controls. Add a stand and staonary
styling arm (sold separately) for convenient hands-free drying.
- 1 -
Special Features:
• 4 HP BRUSHLESS DC Motor
• Powerful and Energy-Efficient
• Super Lightweight and Compact
• Remarkably QUIET Motor
• 8' Flexible Heat Protected PU Hose
• Thermally Protected
• Variable Heat and Speed Control Switches
• Digital temp and speed LCD display
• Durable & Rugged ABS Housing
• 1 Year Limited Warranty
• 3 Nozzle Aachments (included)

1. Place the dryer on a flat surface. Plug the electrical cord into a 3-prong outlet.
2. Connect the hose to the front hose connector and aach the desired nozzle.
3. Turn variable speed switch to desired speed.
4. To use heang element, choose desired heat seng or leave on off seng.
5. To reduce the risk of injury, close supervision is necessary when the unit is used near children.
Do not allow children to play with or around the unit.
- 2 -
OPERATION
SPECIFICATIONS
Model B-8S Unit Weight 12.3lbs
Volts/Cycle 115V/60Hz Unit Dimensions 17.2"x6.3"x9.8"
Power 4 HP Cord Length 10'
Motor
BRUSHLESS DC Filter System 
Max AMP 15A Styling Nozzles 3
Rated Airflow 150CFM Housing ABS
Speeds Variable Thermal Protecon 
Heang Element
Variable

SAFETY INSTRUCTIONS
WARNING: IMPORTANT SAFETY PRECAUTIONS!
When using electrical appliances, especially when children or animals are present, basic safety
precauons should always be followed to reduce the risk of fire, electric shock, and personal injury,
including, but not limited to the following:
• Do not leave the dryer and animal unaended while the product is in use.
• Unplug dryer when not in use.
• Do not use extension cords with the product.
• Do not unplug unit by pulling on cord.
• Do not expose dryer to rain or water.
• Unplug unit before aempng any maintenance or service.
• Do not let air-intake get clogged.
• Do not direct dryer air towards eyes or ears of people or pets.
• Never use dryer with a damaged cord/plug or when unit has been dropped, damaged, or
exposed to rain/water. Please call our Technical Department for service or repair.
• Do not use any other nozzles not intended for use with the dryer.
• Do not operate without filter in place. Keep filter clean, as a dirty filter limits air intake and may
damage the motor or cause overheang.
• Plug only into a properly grounded receptacle. Always confirm that the amperage rang of the
electrical outlet complies with the Dryer rang.
• Do not use product for anything other than its intended purpose.
• Do not aempt to perform any service or maintenance not outlined in the instrucon manual.
- 3 -

SAVE THESE INSTRUCTIONS
HOUSEHOLD and COMMERCIAL USE
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfuncon or breakdown, grounding provides a
path of least resistance for electric current to reduce the risk of electric shock. This appliance is
equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug
must be plugged into an appropriate outlet that is properly installed and grounded in accordance
with all local codes and ordinances.
- 4 -
This appliance is for use on a
nominal 115V circuit, and has a
grounding plug that looks like the
plug illustrated in sketch A. Make
sure that the appliance is
connected to an outlet having the
same configuraon as the plug. No
adaptor should be used with this
appliance.
GROUNDING
PIN
Grounding methods
METAL SCREW
OUTLET BOX
COVER OF GROUNDED
(A)

- 5 -
1
Le housing
2
Right housing
3
Switch panel
4
5
6
7
Heater
8
Motor rubber sleeve
9
Motor
10
11
12
13
Motor filter
14
Rear cover
15
16
Crossed cover
17
18
Inlet filter
19
Hose
20
Round groomer rake
21
Flat nozzle
22
Cone nozzle 23
Baffle board cover
Baffle board 1
PCB board 1
PCB board 2
Baffle board 2
Heater cover
PCB board 3
PCB board 4
Speed switch knob
Power cord
Heat switch knob
Switch
1
2
3
4
5
6
7
8
9
15
10
11
14
12
13
17
18
19
20
21
22
23
24
25
26
16
24
25
26
PART LIST

MAINTENANCE
IMPORTANT!
Always turn off the unit and disconnect from electrical outlet before maintenabce or cleaning.
Product Maintenance:
1. To keep the Pet Dryer, use a damp cloth to wipe the surface of the housing. Removable part(s)
and filters may be cleaned with water and dried thoroughly before reassembling.
2. When not in use, unplug and store the Pet Dryer in a dry place indoors and keep out of reach of
children.
Cleaning Filters and Rear Cover:
The B-8S Pet Dryer has two washable filters - Inlet Filter and Motor Filter. The Inter filter is located
on one side of dryer (rather than the side with hose). Open the rear cover to find motor filter. Both
filters should be kept clean regularly. If the filters are coated with too much hair or dirt, the air
output of the Dryer will be reduced, and this may cause damage to the motors or cause the motors
to overheat. You should never operate the dryer without filters in place.
- 6 -

- 7 -
XPOWER’s Limited Warranty covers the unit (excludes POWER CORD) from defects in material
and crasmanship. The Warranty covers normal use for a term of one year from the original
date of purchase including parts, labor, and one way shipping. Non-conguous states must
pay for roundtrip freight. A purchase receipt must be provided.
Important!
This warranty does not cover or apply to defects due directly or indirectly to misuse, abuse,
disassembly, alteraon, corrosive chemicals, improper voltage, fire, flood, negligence,
accident, improperly or incorrectly performed maintenance or repair, or failure to perform
necessary maintenance or repair, or if the use of this product is not in compliance with the
instrucons and specificaons for its use
For Warranty service and parts replacement (US customer only), you must:
A. Call 1-855-855-8868 for a RMA (Return-Merchandise-Authorizaon) number.
B. Have original proof of purchase.
C. Use the original undamaged packaging or an industrial cerfied packaging method.
End user will be responsible for shipping the unit (with RMA Number showing on the
shipping label) to the XPOWER Service Department. XPOWER will inspect, assess and advise
the repairs needed and the applicable cost, if any.
For users outside the US, please contact an XPOWER Distributor in your country or region for
Warranty service and parts replacement.
SERVICE
XPOWER LIMITED WARRANTY (USA)

XPOWER PET PRODUCTS FOR PROFESSIONAL GROOMING INDUSTRY
Force Dryers
B-3 (2 HP / 8 Amps / 130 CFM) - with vacuuming feature
Stand Dryers
B-16 (1/4 HP / 12 Amps / 300 CFM)
B-16S (1/4 HP / 15 Amps / 300 CFM)
Cage Dryers
X-430TF w/ 430MDK (1/3 HP / 3.8 Amps / 2000 CFM)
X-800TF w/ 800MDK (3/4 HP / 7.5 Amps / 3200 CFM)
B-4 (3 HP / 10 Amps / 150 CFM) -with vacuuming feature
B-8 (4 HP / 12 Amps / 150 CFM) - brushless DC motor with heater
B-25 (4 HP / 12 Amps / 160 CFM) - double motor
B-24 (3 HP / 12 Amps / 150 CFM) - with heater
B-27 (6 HP / 19 Amps / 180 CFM) - double motor
Air Purificaon:
APDS-1 - Air Purificaon & Drying System
X-3300 / X-3500 - Air Scrubbers

For your product warranty, please complete and mail / fax this form to XPOWER MANUFACTURE, INC.
Address: 220 Clary Ave., San Gabriel, CA 91776. Tel: [phone] Fax: [phone]
Warranty Registration
Company Name / Contact Person / Title
State / Province Zip Country
(for US customer only)
(For your convenience, register your product online at xpower.com)

TO:
XPOWER MANUFACTURE, INC.
220 Clary Avenue
San Gabriel, CA 91776, USA
Tel: [phone], Fax: [phone]
From:
