The XRAY M18 Micro is a unique 1/18th micro-sized model racing car
that is the epitome of high-performance and fine distinctive design.
Your M18 offers highest performance, responsive handling, and
traditionally exceptional XRAY quality, engineering, and design.
The XRAY M18 enters a new frontier in micro-car design by offering
fully-adjustable suspension, responsive shaft-drive drivetrain, and
ultra-smooth gear differentials. The superb craftsmanship and
attention to detail are clearly evident everywhere on the XRAY M18.
The XRAY M18 was created by blending highest-quality materials and
excellent design. The result? A very affordable, durable, high-
performance micro race car that is extremely easy to assemble, drive,
and race. On high-speed asphalt tracks or short twisty indoor tracks,
whether driving for fun or racing to win, the M18 delivers outstanding
performance, speed, and precision handling. M18 can be used for
competition micro racing, but is also well suited for novice drivers who
choose the XRAY M18 as their entrance into the R/C hobby.
We have made every effort to make these instructions as easy to
understand as possible. However, if you have any difficulties, problems,
or questions, please do not hesitate to contact the XRAY support team
at [e-mail]. Also, please visit our web site at
www.teamxray.com to find the latest updates, setup information,
option parts, and many other goodies. We pride ourselves on taking
excellent care of our customers.
CONGRATULATIONS
R/C TIPS
QUALITY CERTIFICATE
• Read and fully understand the instruction manual before building.
• Always keep this instruction manual ready at hand for quick
reference, even after completing the assembly.
• Make sure all screws are tight. Check them periodically.
Make sure that the chassis screws do not protrude from the chassis.
• For the best performance, it is very important that great
care is taken to ensure the free movement of all parts.
• Clean all ball-bearings so they move very easily and freely.
• Tap or pre-thread the plastic parts when threading screws.
• Self-tapping screws cut threads into the parts when being tightened.
• Do not use excessive force when tightening the self-tapping screws,
or you may strip out the thread in the plastic. We recommended you
stop tightening a screw when you feel some resistance.
• Ask your local hobby shop for any advice.
• Please support your local hobby shop. We at XRAY Model Racing
Cars support all local hobby dealers. Therefore we ask you, if at all
possible, to purchase XRAY products at your hobby dealer and give
them your support like we do. If you have difficulty finding XRAY
products, please check out www.teamxray.com to get advice, or
contact us via email at [e-mail], or contact the XRAY
distributor in your country.
XRAY MODEL RACING CARS uses only the highest quality materials,
the best compounds for molded parts and the most sophisticated
manufacturing processes. We guarantee that all parts of a newly-
purchased kit are manufactured with the highest regard to quality.
However, due to the many factors inherent in model racecar competition,
we cannot guarantee any parts once you start racing the car.
We wish you enjoyment of this high-quality and high-performance
micro car and wish you best success on the track!
In line with our policy of continuous product development, the exact specifications of the kit may vary. In the unlikely event of any problems
with your new kit, you should contact the model shop were you purchased it, quoting the part number.
We do reserve all rights to change any specification without prior notice. All rights reserved.
391018.1 MANUAL Xray M18 strana 2 CYAN MAGENTA YELLOW BLACK

2
SYMBOLS USED
TOOLS REQUIRED
TOOLS INCLUDED
EQUIPMENT REQUIRED
Hobby Knife Side Cutters Needlenose Pliers Curved Scissors Hole Reamer
1:1
L=R
1
CA
2x
C
Self-tapping screws cut threads into the parts when being tightened. Excessive force may permanently damage
parts when tightening screws. It is recommended to stop tightening when the part is attached or when some
resistance is felt after the threaded portion enters the plastic.
Overtightened
CORRECT WRONG
The threads are stripped.
Micro Servo Receiver
Transmitter Micro Motor 5-Cell Micro
Battery Pack
Battery Charger Transmitter
Batteries
Micro Speed
Controller
CA GlueLexan Paint
(Typically AA type)(Ni-MH recommended)
Differential Assembly Tool Phillips Screwdriver 1.5mm Allen Wrench
Assemble as
many times
as specified
(here twice)
Cut off
remaining
material
Cut off
remaining
material from all
plastic parts.
Cut off
shadded
portion
Ensure smooth
non-binding
movement
Apply instant
glue
Pivot ball
type used
Pay attention
here
Assemble in
the specified
order
Assemble left
and right
sides the
same way
Part bags
used
True-to-scale
diagram
Car
orientation
Tighten screw
gently
391018.1 MANUAL Xray M18 strana 2 CYAN MAGENTA YELLOW BLACK

3
389343
309080
309080
389373
389373
385060 309040
385005
385060 385005
385005
DIFF ASSEMBLY TOOL
385550
309040 BALL-BEARING MR106ZZ 6x10x3 (2)
309080 BALL-BEARING MR128ZZ 8x12x3.5 (2)
385005 COMPOSITE FRONT GEAR DIFF. + DRIVESHAFT PINION GEAR
385060 GEARBOX CASE
385550 O-RING 4x1 (10)
389343 SCREW PHILLIPS 2.2 x 6 (10)
389373 WASHER S 3x6x0.3 (10)
1. FRONT DIFFERENTIAL
BAG
1
391018.1 MANUAL Xray M18 strana 3 CYAN MAGENTA YELLOW BLACK

4
NOTE
ORIENTATION
TIGHTEN DIFF SCREW (CW) = TIGHTENS DIFF
LOOSEN DIFF SCREW (CCW) = LOOSENS DIFF
SET DIFF MEDIUM TIGHT SO IT ROTATES
SMOOTHLY WITHOUT BINDING
ADJUST THE DIFF SO
IT SPINS SMOOTHLY
TIGHTEN
GENTLY
NOTE
ORIENTATION
CUT OFF
CUT OFF
LARGER HOLE
SMALLER HOLE
1. 2. 3.
CCW.
CW.
ASSEMBLED VIEW
1:1
1:1
3.1mm
2.6mm
BLACK
SHIM
BLACK
SHIM
309080
BB 8x12x3.5
389373
SHIM 3x6x0.3
389343
2.2x6
4x
2x
391018.1 MANUAL Xray M18 strana 4 CYAN MAGENTA YELLOW BLACK

5
4. 5. 6.
ASSEMBLED VIEW
ASSEMBLED VIEW
LONG
SHORT
309040
BB 6x10x3
385550
O 4x1
NOTE
ORIENTATION
ORIENTATION
NOTE
ORIENTATION
391018.1 MANUAL Xray M18 strana 5 CYAN MAGENTA YELLOW BLACK

6
309080
309460
389373
385000
309080
389373
385000
385060
385060
385000
309040
385736
385550
309040 BALL-BEARING MR106ZZ 6x10x3 (2)
309080 BALL-BEARING MR128ZZ 8x12x3.5 (2)
309460 PIN 3x16 (10)
385000 COMPOSITE REAR GEAR DIFF. + DRIVESHAFT PINION GEAR
385060 GEARBOX CASE
385550 O-RING 4x1 (10)
385736 SPUR GEAR 36T/48
389373 WASHER S 3x6x0.3 (10)
2. REAR DIFFERENTIAL
BAG
2
391018.1 MANUAL Xray M18 strana 6 CYAN MAGENTA YELLOW BLACK

7
1. 2. 3.
ASSEMBLED VIEW
NOTE
ORIENTATION
NOTE
ORIENTATION
SAME
LENGTH
LR
L=R
4x
CUT OFF CUT OFF
309080
BB 8x12x3.5
2x
389373
SHIM 3x6x0.3
309460
P 3x16
391018.1 MANUAL Xray M18 strana 7 CYAN MAGENTA YELLOW BLACK

8
LONG
SHORT
NOTE
ORIENTATION
NOTE
ORIENTATION
385550
O 4x1
4. 5. 6.
ASSEMBLED VIEW ASSEMBLED VIEW
309040
BB 6x10x3
SHORTER LONGER
391018.1 MANUAL Xray M18 strana 8 CYAN MAGENTA YELLOW BLACK

9
389336
387400
382100
381100
387400
387400
389344
389343
387400
382100
389343
389356
383200
389343
389995
309040
382200
309040
385200
309450
309040 BALL-BEARING MR106ZZ 6x10x3 (2)
309450 PIN 2x8 (10)
381100 COMPOSITE MICRO CHASSIS
382100 SET OF SUSPENSION ARMS, LOWER + UPPER (2+1+1)
382200 COMPOSITE SUSPENSION BLOCK, L+R (2)
383200 SET OF LINKAGES + BALL JOINTS
385200 COMPOSITE DRIVE SHAFT - SET (2)
387400 SET OF COMPOSITE PIVOT BALLS
389336 SCREW PHILLIPS FH 2.5x12 (10)
389343 SCREW PHILLIPS 2.2x6 (10)
389344 SCREW PHILLIPS 2.2x8 (10)
389356 SCREW PHILLIPS 2.5x12 (10)
389995 INNER WHEEL ADAPTORS, F+R
3. REAR SUSPENSION
BAG
3
391018.1 MANUAL Xray M18 strana 9 CYAN MAGENTA YELLOW BLACK

10
NOTE ORIENTATION
OF ALL PIVOT BALLS
309450
P 2x8
1. 2. 3.
SAME
LENGTH
LEFT LOWER ARM
RIGHT LOWER ARM
L
L=R
L=R
R
2x
2x
CHECK
A
A
A
A
B
B
AB
391018.1 MANUAL Xray M18 strana 10 CYAN MAGENTA YELLOW BLACK

11
L=R
A
A
A
A
NOTE ORIENTATION
OF ALL PIVOT BALLS
DOWNSTOP SCREWS
ARE IN LAST BAG
LR
B
B
TECH TIP ADJUSTABLE DOWNSTOPS 4. 5.
REMOVE DOWNSTOP PIN
THREAD SET SCREW
RIGHT LEFT
RIGHT LEFT
309351
SB M3x4 AB
391018.1 MANUAL Xray M18 strana 11 CYAN MAGENTA YELLOW BLACK

12
ALIGN TAB AND SLOT
BEFORE TIGHTENING SCREW
TIGHTEN SCREW,
THEN LOOSEN A LITTLE BIT
CUTAWAY ASSEMBLED VIEW
L=R
2x
ORIENTATION
6. 7. 8.
389343
2.2x6
309040
BB 6x10x3
389343
2.2x6
TIGHTEN
GENTLY
391018.1 MANUAL Xray M18 strana 12 CYAN MAGENTA YELLOW BLACK

13
2x
C
C
L=R
389356
2.5x12
389356
2.5x12
389344
2.2x8
389344
2.2x8
9. 10. 11.
ASSEMBLED VIEW
C
TIGHTEN
GENTLY
MAKE SURE ARMS
MOVE FREELY
391018.1 MANUAL Xray M18 strana 13 CYAN MAGENTA YELLOW BLACK

14
389336
2.5x12
12. ASSEMBLED VIEW
391018.1 MANUAL Xray M18 strana 14 CYAN MAGENTA YELLOW BLACK

15
387400
389345
387400
383200
383200
387400
389344
385512
382610
389356
389343
387400
382100
389343
389995
309040 382200
309040
385200
309450
382100
387400 389336
389343
309040 BALL-BEARING MR106ZZ 6x10x3 (2)
309450 PIN 2x8 (10)
382100 SET OF SUSPENSION ARMS, LOWER + UPPER (2+1+1)
382200 COMPOSITE SUSPENSION BLOCK, L+R (2)
382610 ADJ. TURNBUCKLE 34MM
383200 SET OF LINKAGES + BALL JOINTS
385200 COMPOSITE DRIVE SHAFT - SET (2)
385512 ALU MAIN DRIVESHAFT- SILVER
387400 SET OF COMPOSITE PIVOT BALLS
389336 SCREW PHILLIPS FH 2.5x12 (10)
389343 SCREW PHILLIPS 2.2x6 (10)
389344 SCREW PHILLIPS 2.2x8 (10)
389345 SCREW PHILLIPS 2.2x10 (10)
389356 SCREW PHILLIPS 2.5x12 (10)
389995 INNER WHEEL ADAPTORS, F+R
BAG
4
4. FRONT SUSPENSION
391018.1 MANUAL Xray M18 strana 15 CYAN MAGENTA YELLOW BLACK

16
1. 2. 3.1.
309450
P 2x8 AB
SAME
LENGTH
L
L=R
L=R
R
2x
2x
CHECK
NOTE ORIENTATION
OF ALL PIVOT BALLS
DO NOT USE DOWNSTOP
PIN ON LOWER ARMS
LEFT LOWER ARM
RIGHT LOWER ARM
A
A
B
A
A
B
391018.1 MANUAL Xray M18 strana 16 CYAN MAGENTA YELLOW BLACK

17
TECH TIP4. 5.
LR
L=R
A
A
A
B
B
A
ADJUSTABLE DOWNSTOPS
RIGHT LEFT
RIGHT LEFT
REMOVE DOWNSTOP PIN
THREAD SET
SCREW
DOWNSTOP SCREWS
ARE IN LAST BAG
309351
SB M3x4
ORIENTATION
NOTE ORIENTATION
OF ALL PIVOT BALLS
AB
391018.1 MANUAL Xray M18 strana 17 CYAN MAGENTA YELLOW BLACK

18
6. 7. 8.
389343
2.2x6
309040
BB 6x10x3
389343
2.2x6
L=R
2x
CUTAWAY ASSEMBLED VIEW
ALIGN TAB AND SLOT
BEFORE TIGHTENING SCREW
TIGHTEN
GENTLY
TIGHTEN SCREW,
THEN LOOSEN A LITTLE BIT
ORIENTATION
391018.1 MANUAL Xray M18 strana 18 CYAN MAGENTA YELLOW BLACK

19
10. 11.9.
ASSEMBLED VIEW
C
C
C
C
389356
2.5x12
389356
2.5x12
389344
2.2x8
389344
2.2x8
CC
56mm
ORIENTATION
4x TIGHTEN
GENTLY
391018.1 MANUAL Xray M18 strana 19 CYAN MAGENTA YELLOW BLACK
