XTM Racing X-Cellerator Nitro Assembly instructions

1
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
Thank you for purchasing the XTM Racing X-Cellerator Nitro Stadium Racer. This Basic Operating Guide is provided to help you enjoy your
new X-Cellerator Nitro Stadium Racer without any of the hassles you might expect. Please read through all of the literature that is provided in the box.
Doing so will help you become familiar with how your X-Cellerator Nitro Stadium Racer, XTM Racing .18 size engine and Lynx radio system operate.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Before operating your new X-Cellerator Nitro Stadium Racer, please read and understand the warnings listed on the next page.
Failure to do so could lead to bodily harm and/or injury. The XTM Racing X-Cellerator Nitro Stadium Racer is not intended for persons under 12 years
of age, unless closely supervised by an adult.
BASICBASIC
BASICBASIC
BASIC
OPERAOPERA
OPERAOPERA
OPERATIONS GUIDETIONS GUIDE
TIONS GUIDETIONS GUIDE
TIONS GUIDE
Features of Your New XTM Racing X-Cellerator Nitro Stadium Racer:
●Factory-Installed XTM Racing .18 Engine
●Factory-Installed Hitec Lynx Radio System
●Racing Legal Dimensions
●Thick, Aluminum Countersunk Chassis
●Aluminum Chassis/Gear Box Brace
●Multiple Shock & Suspension Adjustments
●Threaded Shock Bodies
●Ball Differential
●CVA-Type Rear Drive Axles
●Low CG Gear Box and Chassis Layout
●Sealed Receiver Compartment
●Turn-Buckle Suspension Links
●Adjustable Slipper Clutch
●Aluminum Tuned Pipe
●Fiberglass Brake Disc
●Race Disc Wheels
●Shock Dust Boots
●Full Ball-Bearings
●Center-Mounted Fuel Tank
The XTM Racing X-Cellerator Nitro Stadium Racer is distributed exclusively by Global Hobby Distributors
18480 Bandilier Circle, Fountain Valley, CA 92708
All contents copyright © 2003, Global Hobby Distributors Version V1.0 June 2003
Kit Product # 145610

2Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
ENGINE WARNINGS
●Never use any fuel in your engine other than glow fuels
specifically designed for use in model car engines. Use of any
other types of fuel can cause severe damage to the engine and/or
personal injury. NEVER USE GASOLINE!
●Never operate your model on any public streets. This could
cause traffic accidents, personal injury or property damage.
●Glow fuel engines emit exhaust vapors that are poisonous and
can be dangerous to your health. It is important that you operate
your engine in a very well-ventilated area, preferably outdoors.
●Before starting the engine, make sure that the throttle trim is
set to the idle position. Starting the engine at any setting above
idle can cause the model to lurch out of your hands.
●When the engine is running, there are certain parts that rotate
at high speeds. Be careful not to touch the drive shafts, gears,
clutch assembly or any other moving parts. Otherwise, serious
injury could result.
●It is normal for the engine, exhaust header and tuned pipe to
get very hot during operation. Never touch these parts while
they are hot or you might be burned.
●Model car engines produce vibration when they are running. It
is important to periodically check the engine mounting screws
and other assemblies to ensure they are tight. Running the
engine with the engine mounting screws loose can lead to
severe engine and/or chassis damage.
FUEL WARNINGS
●Glow fuels like those used in your X-Cellerator Nitro Stadium
Racer are poisonous. Follow all the precautions that are printed
on the fuel manufacturer's container.
●Keep fuel out of the reach of children.
●Glow fuel is extremely flammable. Keep away from high heat,
sparks and flame.
GENERAL WARNINGS
●Under no circumstances should you operate your model in
crowds of people. Serious injury could result.
●Never operate your model on busy streets or if there are cars
around.
●Do not use your model to chase pets or other animals.
●The radio system included in your model is not waterproof;
therefore, do not drive through water, wet grass, mud or snow.
●Because your model is operated by radio control, it is important
to make sure you always are using fresh and/or fully charged
batteries. Never allow the batteries to run low or you could lose
control of the model.
●If your model becomes stuck, allow the engine to idle, then
retrieve your model by hand.
●To prevent excessive r.p.m.'s from damaging the engine and/or
drive-train components, we suggest reducing throttle while in the
air during jumps.
If you should have any trouble with any of the steps listed in this Basic Operations Guide, we have provided an extensive troubleshooting
guide beginning on page # 16. The troubleshooting guide is provided to help you find a quick and immediate resolution to a number of
problems that might occur. If you cannot solve a problem using the troubleshooting guide, or if you have any other questions or
concerns, please contact us at the address below:
FOR YOUR INFORMATION
FOR YOUR SAFETY - PLEASE READ THESE WARNINGS FIRST!
To allow us to serve your needs better, please include your email address with any correspondence you send to us. Your email
address will be added to our Customer Service Database so you will automatically receive free updates and tech notices for your
particular product. You will also receive repair status updates (if applicable) and other important information about your product as
it becomes available.
IMPORTANT INFORMATION ABOUT YOUR EMAIL ADDRESS
Global Hobby Distributors will not disclose the information it collects to outside parties. Global Hobby Distributors does not sell,
trade, or rent your personal information to others . Your privacy is important to us.
Visit Our Website
http://globalservices.globalhobby.com
Global Services
18480 Bandilier Circle
Fountain Valley CA 92708
Phone: [phone] Fax: [phone] Email: [e-mail]

3
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
SECTION 1: OUR RECOMMENDATIONS
This section lists the recommended items necessary to run and maintain your new X-Cellerator Nitro Stadium Racer. We have tested
these items extensively with the X-Cellerator Nitro Stadium Racer and found that they offer the best in reliability and value.
What Fuel Do I Use in My X-Cellerator Nitro Stadium Racer?
Fuel can make a big difference in the way your engine performs. For the break-in period you should use a fuel specifically designed for
R/C car engines that contains no more than 20% nitromethane. Once the engine has been adequately broken in (about 45 minutes of
run-time) you can switch to an R/C car fuel containing up to, but no more than, 30% nitromethane.
✦✦
✦✦
✦WARNGING✦✦
✦✦
✦We do not recommend using fuels designed for R/C airplane engine use. These fuels do not contain the proper
amount of lubricants; therefore, they will cause the engine to overheat and severe damage to the engine will result.
Use the following fuels for the best performance:
Trinity 16% Nitro Car Fuel - Part # 837826 (use this for break-in)
Trinity 20% Nitro Car Fuel - Part # 837828 (use this after break-in)
Trinity 30% Nitro Car Fuel - Part # 837832 (use this after break-in for more power)
How Do I Remove the Glow Plug?
A long reach glow plug wrench is necessary to easily and quickly
remove and replace glow plugs. The Magnum Long 4-Way Wrench
works great.
Do I Need to Purchase Extra Glow Plugs?
Yes. Even though your X-Cellerator Nitro Stadium Racer comes with a glow plug already installed in the engine, glow plugs wear out,
especially during the break-in period; therefore, it's a good idea to have a couple of spares handy. The glow plug can make a big
difference in how your engine performs. We recommend using a "hot" type glow plug intended specifically for performance engines, like
the Thunderbolt # 3 (P/N 115559) or the McCoy MC-59 (P/N 690215), for the break-in period. After the break-in period you may want
to use a medium heat-range plug like the McCoy MC-8 (P/N 690205). Do not use glow plugs intended for four cycle airplane engines.
Using the wrong type of glow plug will cause the engine to run erratically and make it difficult to tune properly.
What Do I Use to Ignite the Glow Plug?
A glow starter is a battery-operated device that, when attached to
the glow plug, heats the glow plug so that the engine can start. The
glow starter is then removed after the engine is running. The
Magnum Glow Starter with Meter is a perfect choice. It comes
complete with a battery, charger and a built-in meter to let you know
if your glow plug is good.
Do I need to Use a Fuel Bottle?
Yes. Because fuel is packaged in quarts or gallons, you will need to
use a smaller bottle with an extension tube or wand to fill the fuel
tank. Fueling using this method is much easier and a lot less messy.
The Promax 500cc Fuel Bottle is a good choice.
Promax 500cc Fuel Bottle
Part # 360895
Magnum Long 4-Way Wrench
Part # 237425
Magnum Glow Starter
with Meter Part # 237438

4Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
●Trinity "8 Pack" AA Alkaline batteries for the transmitter -- Part # 837801
●Trinity "4 Pack" AA Alkaline batteries for the receiver -- Part # 837800
●Trinity "Final Solution" after-run oil to "wet" the air filter and to lubricate the engine -- Part # 843744
●Emerald Nitro Car Cleaner to clean the chassis and engine -- Part # 340196
●Small, flat blade screwdriver to make engine adjustments -- Part # 146101
●1/16", 5/64" (2mm), 3/32" & 3mm Hex Wrenches to remove the battery box cover and to perform basic maintenance
●Adjustable wrench to make turn-buckle and slipper clutch adjustments
Each radio system comes with stickers on the back of the transmitter and on the receiver showing which frequency the radio system
operates on (either in the 27Mhz or 75Mhz band). No two radio systems can operate nearby each other if they are on the same
frequency. You can purchase transmitter and receiver crystals separately and change them if you plan on running your X-Cellerator
Nitro Stadium Racer with other people. We have provided a list of the frequencies that are available for your radio system.
Battery Cover: This cover houses the 8 AA Alkaline batteries that power the transmitter.
Crystal: This is the frequency crystal of the transmitter. You can change crystals in both the transmitter and the receiver (in the chassis) so that you
and your friends can drive at the same time. No two radio systems nearby can be on the same frequency.
On/Off Switch: Turns the transmitter on and off. Two L.E.D.s show the power of the batteries.
Servo Reversing Switches: Allow you to quickly and easily switch the direction the servos rotate by just flipping the switches on the top of the
transmitter.
Steering Wheel: Controls the X-Cellerator Nitro Stadium Racer's steering. Turn the wheel to the right and the vehicle turns right. Turn the wheel to
the left and the vehicle turns left.
Throttle/Brake Trigger: Controls the speed and braking ability of your X-Cellerator Nitro Stadium Racer. Pull the trigger to accelerate, release the
trigger to decelerate, and push the trigger to brake.
Trim Levers: These levers, one for steering and one for throttle/brake control, allow you to fine tune the servo's center by sliding the levers on the
transmitter.
Channel # Frequency Part # (tx/rx)
67427xx/66427xx
01 16.995
02 27.045
03 27.095
04 27.145
05 27.195
06 27.255
61 75.410
90 75.990
Through 67475xx/66475xx
Note that "xx" is the actual channel number
you want to purchase.
27Mhz
75Mhz
SECTION 2: OTHER RECOMMENDED ITEMS
SECTION 3: BECOMING FAMILIAR WITH YOUR X-CELLERATOR NITRO STADIUM RACER

5
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
Air Filter: The air filter is made of foam and prevents dirt and debris from entering the engine through the carburetor.
Battery Box: This is where the receiver battery is mounted. The battery box protects the battery from dust, dirt and oil.
Body Mount: Made of high-impact plastic for strength, the body mount secures the Lexan body into place. There is one body mount assembly on the
front of the chassis and one on the back of the chassis.
Engine: The X-Cellerator Nitro Stadium Racer includes the powerful XTM Racing .18 engine with pull-starter for ease of use and great performance.
Fuel Tank: The fuel tank holds the fuel that your engine uses. This fuel tank includes a fuel pressure nipple that connects to the tuned pipe to
pressurize the fuel system and also features a quick-flip type lid for fast refueling.
On/Off Switch: Turns the receiver on and off. The on/off switch is protected from dust, dirt and oil by a silicone cover.
Pull-Starter: Used to start the engine in place of an electric starter.
Receiver Box: This is where the receiver is mounted. The receiver box protects the receiver from dust, dirt and oil.
Shock Assembly: The shocks are oil-filled and use a spring that is well suited for most off-road conditions. The shocks feature threaded shock
bodies that allow the shocks to be easily tuned for different driving conditions.
Steering Servo: This servo controls the vehicle's steering. A "servo saver" is used to help prevent the servo gears from being stripped out.
Steering Tie-Rod: The tie-rod connects the steering linkage and the castor block. The tie-rods are adjustable so you can make toe-angle
adjustments to the front wheels.
Throttle/Brake Servo: This servo controls both the engine's throttle and the vehicle's brake.
Tuned Pipe: The tuned pipe is an expansion muffler that greatly increases the power output of the engine.
Wheel/Tire Assembly: The X-Cellerator Nitro Stadium Racer includes molded rubber tires with a tread pattern that is good for most off-road
applications. The wheels are molded in one piece from high-impact plastic for strength

6Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
Now that you are familiar with the major component parts of your X-Cellerator Nitro Stadium Racer, and with the functions of the Hitec
Lynx Sport transmitter, it's time to prepare your X-Cellerator Nitro Stadium Racer for its first run.
Step 1: Final Assembly
❑Push the antenna down into the molded hole in the top of the transmitter.
❑Thread the antenna (clockwise) into place and tighten it gently until it stops.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Do not force the antenna into place or tighten it too strongly. Doing so
could cause damage to the antenna and/or transmitter.
❑Remove the plastic battery cover from the bottom of the transmitter.
❑Install 8 AA Alkaline batteries into the battery tray, double-checking to make sure that
the polarity is correct.
❑Reinstall the battery cover and set the transmitter aside for now.
❑Using a 1/16" hex wrench, remove the four screws holding the battery cover in place,
then remove the battery cover from the battery box.
❑Remove the battery holder from the battery box.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦The battery holder plug has already been plugged into the switch. Do
not unplug it when removing the batter holder.
❑Install 4 AA Alkaline batteries into the battery holder, double-checking to make sure
that the polarity is correct.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Make sure that the batteries are pushed firmly into place. They should
not be loose. If for any reason the plug from the battery holder is not plugged into the
switch plug, plug them together now.
SECTION 4: PREPARING TO RUN YOUR X-CELLERATOR NITRO STADIUM RACER
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦The plug from the switch harness that is secured to the rear shock tower is a charging plug. This plug is optional and
is used if you have an optional transmitter/receiver wall charger and use rechargeable AA batteries. Never attempt to recharge
non-rechargeable batteries. The batteries could explode and cause serious injury.

7
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
❑Push the battery holder into the battery box, along with the wire and plugs.
❑Reinstall the battery box cover, making sure that you don't pinch the wire.
❑Slide the receiver antenna into one end of the plastic antenna tube and out the
other end.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦To make it easier to slide the antenna through the tube, first make
sure there are no kinks or bends in the antenna wire, then wet the antenna wire with
glass cleaner. The glass cleaner will make the antenna slide easily through the tube.
❑Push the end of the antenna tube firmly into the molded hole in the top of the receiver
box cover.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Leave the excess antenna hanging from the top of the tube. Under
no circumstances should you cut or shorten the antenna.
❑Slide the transmitter's on/off switch to turn on the transmitter. The green LED should
glow brightly.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦If the green LED does not glow or if the red LED is glowing, check the
batteries and replace them if necessary.
❑Slide the receiver's on/off switch to turn the receiver on. You should hear the servos
move to their proper positions.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Always turn on the transmitter first, followed by the receiver. After
you're done, turn off the receiver first, then turn off the transmitter. This will prevent the
possibility of a runaway vehicle or damage to the servos.

8Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
Step 2: Range Checking the Radio System
❑With the transmitter and the receiver turned on, rotate the
transmitter's wheel forward (to the right). The front wheels on the
X-Cellerator Nitro Stadium Racer should turn right.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦If the wheels don't turn right, flip the steering servo
reversing switch on the top of the transmitter to change the direction.
Refer to the transmitter photo on page # 4 if you don't remember
how to use the servo reversing switches.
❑Rotate the transmitter's wheel backward (to the left). The front
wheels on the X-Cellerator Nitro Stadium Racer should turn left. Let
go of the wheel. The X-Cellerator Nitro Stadium Racer's wheels should
return to center.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦If the wheels do not point straight ahead (center)
after you return the steering wheel to center, move the steering trim
lever on the transmitter to adjust the wheels so that they point straight
ahead. Refer to the transmitter photo on page # 4 if you don't
remember how to use the servo trim levers.
Step 3: Double-Check the Steering and Throttle/Brake Controls
To prevent any chance of a runaway vehicle, the radio system should be range checked before the first run of the day and/or after a
crash. To range check the radio system, do the following:
❑With the transmitter and receiver turned on, extend the transmitter antenna completely.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Remember to always turn on the transmitter first, then turn on the receiver.
❑With the X-Cellerator Nitro Stadium Racer on the ground (without the engine running) walk away from it about 150 feet. Move the
steering wheel while looking at the vehicle's wheels. The wheels should pivot back and forth as you rotate the steering wheel back
and forth.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦If the radio system does not operate properly, please refer to the troubleshooting guide starting on page # 16 before
going further.
✦✦
✦✦
✦WARNING✦✦
✦✦
✦Never attempt to operate your X-Cellerator Nitro Stadium Racer if the radio control system is not functioning properly.
Doing so could be harmful to others around you and/or to you or your vehicle.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦We suggest doing the steering tests with the truck resting on a smooth surface, like a table or on concrete or asphalt.
If the truck is setting on a rough surface or in grass, the tests may not work properly. In such a case, we suggest lifting the front of the
truck off the ground while testing the steering.

9
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
❑Carefully pull the air filter assembly off of the carburetor.
❑Pull back on the throttle trigger. The carburetor barrel should
open completely and the brake should be disengaged.
❑Let go of the trigger and the carburetor barrel should return to its
idle position - open about 1/16". The brake should still be disengaged.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦If the carburetor barrel does not open when you
pull back on the trigger, flip the throttle servo reversing switch on
the top of the transmitter to change the direction.
If the carburetor barrel does not open completely, move the throttle
trim lever on the transmitter until the barrel is opened completely
when you pull back completely on the trigger.
❑Push the throttle trigger forward. The carburetor barrel should
stay in the idle position and the brake lever should move and engage
the brake.
❑Let go of the trigger and the brake lever should disengage.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦If necessary, you can adjust the brake linkage by
sliding the wheel collar (on the brake linkage wire) forward or back.
See page # 15 "Adjusting the Brake Linkage" for more details.
❑Turn off the transmitter and receiver for now and push the air
filter back onto the carburetor. Never run your X-Cellerator Nitro
Stadium Racer without the air filter in place.
Your X-Cellerator Nitro Stadium Racer comes equipped with the user-friendly and powerful XTM Racing .18 nitro engine.
Before starting the engine for the first time, please read these next two sections very carefully.
Idle Stop Screw:
The idle stop screw is preset from the factory and should not require
adjustment. The idle stop screw adjusts the closure of the throttle
barrel. We recommend that the idle stop screw be adjusted so that
the carburetor barrel stays open about 1/16". Turning the screw
clockwise will cause the barrel to stay open more. Turning the screw
counterclockwise will allow the barrel to close more.
High Speed Needle Valve:
The high speed needle valve is preset from the factory for the initial starting procedure. Do not make adjustments to it at this time. The
high speed needle valve is used to meter the air/fuel mixture at full throttle. Turn the needle clockwise to lean the mixture or turn the
needle counter-clockwise to richen the mixture. When you start the engine for the very first time, the needle valve should be turned in
completely, then backed out 3 turns. When you start the engine after that, leave the needle valve in the same position it was in when you
shut down the engine.
SECTION 5: BECOMING FAMILIAR WITH THE XTM RACING .18 NITRO ENGINE
Please refer to the photo below to familiarize yourself with your engine's carburetor. You should have a small flat blade screwdriver
handy to make adjustments to the carburetor.

10 Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
Low Speed Needle Valve:
The low speed needle valve is preset from the factory for the initial starting procedure. Do not make adjustments to it at this time. The
low speed needle valve meters the air/fuel mixture at idle and during transition from idle to full throttle. Turn the low speed needle
clockwise to lean the mixture. Turn it counterclockwise to richen the mixture. The low speed needle valve is preset from the factory, but
minor adjustments may need to be made to suit your application: fuel used, glow plug and environment all contribute to the setting. To
reset the low speed needle valve to the factory setting, follow these simple procedures:
❑Open the carburetor barrel completely.
❑While holding the barrel open with your finger, use a flat blade screwdriver to turn the idle mixture needle clockwise until it stops.
From this point, turn the needle counter-clockwise 5 turns. This is the factory setting.
If at any time the pull-starter becomes very tight or difficult to pull - STOP! The engine has become flooded and the excess fuel
must be removed from the engine or damage to the pull-starter and/or engine could occur. To remove the excess fuel from the
engine follow the procedures listed below:
●Completely close the high speed needle valve (turn it clockwise gently) until it bottoms out.
●Remove the glow plug from the cylinder head.
●With a rag over the top of the engine, pull the pull-starter cord several times to clear the excess fuel from the engine.
●Check to make sure that the glow plug has not been fouled, then reinstall it.
●Reset the high speed needle valve 3 turns out from bottom. (Turn it counter-clockwise.)
WARNING!! PLEASE READ THIS BEFORE STARTING YOUR ENGINE FOR THE FIRST TIME!!
SECTION 6: FUELING AND STARTING THE XTM RACING .18 NITRO ENGINE
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦The following photos show the air filter removed for clarity. Under no circumstances should you operate the
engine without the air filter installed. The air filter prevents dust and debris from entering the engine and damaging it. If you
operate your engine at any time without the air filter installed, the engine will not be covered under warranty should it
need repair.
✦✦
✦✦
✦WARNING✦✦
✦✦
✦If you will be using a long-reach glow plug in your XTM Racing .18 engine, you MUST use two glow plug washers under
the glow plug or the engine won't run properly.
❑Lift the fuel tank lid and carefully fill the fuel tank until the fuel level is just below the top
of the tank.
✦✦
✦✦
✦WARNING✦✦
✦✦
✦Use fuel that is appropriate for nitro car and buggy engines. DO NOT
USE GASOLINE!
❑Prime the engine by first opening the throttle completely and covering the opening in the
tuned pipe with your thumb, then pull the pull-starter cord several times until you see
fuel just start to enter the carburetor through the fuel line.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Do not pull the cord all the way out or damage to the pull-starter
will occur.
❑Using your glow plug wrench, verify that the glow plug is installed in the cylinder head and tight.

11
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
❑Remove your finger from the opening in the tuned pipe and close the throttle down to
the idle position.
❑While holding the vehicle with one hand, carefully pull on the pull-starter cord 3 times
using short, quick pulls.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦If you can't turn the engine over using the pull-starter, don't force it.
The engine is probably flooded. See the warning and resolution on the previous page.
❑Connect a fully charged glow starter to the top of the glow plug, making sure that the
glow starter is locked firmly onto the top of the glow plug. You don't want it to fall off while
you're trying to start the engine.
❑While holding the vehicle with one hand, carefully pull on the pull-starter cord using
short, quick pulls, until the engine starts.
❑After the engine starts, release the pull-starter cord, allow the engine to run for about
10 seconds, then remove the glow starter from the engine.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦If the engine does not start after a dozen pulls, refer to the trouble-
shooting guide starting on page # 16 before going further.
❑To stop the engine, carefully pinch the fuel line with your fingers until the engine stops.
Make sure to pinch the fuel pick-up line and not the fuel pressure line. The fuel pick-up
line is connected to the carburetor.
✦✦
✦✦
✦WARNING✦✦
✦✦
✦Be careful not to touch any parts of the engine or tuned pipe because
they will be hot.
Fuel Recommendation:
Fuel can make a big difference in the way your engine performs. For the break-in period you should use a fuel specifically designed for
R/C car engines that contains no more than 20% nitromethane. Once the engine has been adequately broken in (about 45 minutes of
run-time) you can switch to an R/C car fuel containing up to, but no more than, 30% nitromethane.
✦✦
✦✦
✦WARNING✦✦
✦✦
✦We do not recommend using fuels designed for R/C airplane engine use. These fuels do not contain the proper
amount of lubricants; therefore, they will cause the engine to overheat and severe damage to the engine will result.
SECTION 7: BREAKING IN THE XTM RACING .18 NITRO ENGINE

12 Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
Glow Plug Recommendation:
The glow plug can make a big difference in how your engine performs. We recommend using a "hot" type glow plug intended specifically
for performance engines like the Thunderbolt # 3 (P/N 115559) or the McCoy MC-59 (P/N 690215) during the break-in process. After the
break-in period you may want to use a medium heat-range plug like the McCoy MC-8 (P/N 690205). Do not use glow plugs intended
for four cycle airplane engines. Using the wrong type of glow plug will cause the engine to run erratically and make it difficult to
tune properly.
Air Filter:
The air filter is a very important part of your engine. Failure to use the air filter will damage the engine in a very short period of time. If
you are driving your vehicle in very dusty conditions, we suggest wetting the foam air filter element with after-run oil to prevent fine dust
particles from passing through the filter element.
Step 1: Breaking In the Engine
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦The XTM Racing .18 nitro engine is an ABC engine.
The cylinder sleeve is tapered at the top, causing severe resistance when
the piston moves through the top of the stroke. This is normal. When
the engine heats up to operating temperature, this resistance will decrease
and the proper clearance will be achieved. The break-in procedure will
guide you through the steps necessary to properly break in your new
engine. Please follow the steps closely.
The break-in process allows the engine parts to perfectly fit to each other
and properly protect each part from premature wear. The engine should
be broken in using a good quality R/C car fuel that contains no more than
20% nitromethane.
❑Follow the previous procedures to fill the fuel tank and start the engine.
❑Once the engine starts, keep the glow starter attached to the glow plug
and let the engine run for about 10 seconds without giving it throttle. This
will allow the engine to warm up. At this point the engine should be running
very "rich" and there should be excessive white smoke coming from the
tuned pipe.
❑After the engine has been running for about 10 seconds, remove the
glow starter from the glow plug. Advance the throttle in short, quick bursts
and drive the vehicle around for about 2-3 minutes. If the engine is running
rich enough, you should notice excessive white smoke coming from the
exhaust and the engine should sound like it’s running very rough. Also,
the vehicle will barely be moving. If there is not excessive white smoke
coming from the exhaust, richen the high speed needle valve. After 2-3
minutes stop the engine by pinching the fuel line to the carburetor.
❑Let the engine cool for approximately 10 minutes, then restart it. Set the
high speed needle valve mixture to a slightly leaner setting, about 1/8 turn
more in. Repeat the procedure above then stop the engine and let it cool
for approximately 10 minutes.
❑Repeat the procedure above, while leaning the needle valve slightly more
each time. In all, you should run the engine a total of about 45 minutes.
After 45 minutes of run-time the engine will be broken in. Run the engine
with the needle valve set slightly rich, but lean enough to power the
vehicle adequately. At this point the engine should hold a good setting on
the high speed needle valve and you can begin to fine tune the needle
valve settings to increase performance.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦It is of the utmost importance that the engine never be
leaned out too much. When running the engine, you should always be
able to see a trail of white smoke coming from the tuned pipe. If you can’t,
stop the engine immediately and richen the mixture. You should also
make sure there is plenty of air flowing over the cylinder head to keep
the engine from overheating.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Be careful to never lean out the engine too much.
Remember that the lubricants for your engine are suspended in the fuel.
If you lean out the fuel mixture too much you will also be lowering the
amount of lubricant entering your engine. Less lubricant means more
chance of your engine overheating and possible engine failure.
Setting the High Speed Needle Valve:
❑Start the engine and remove the glow starter from the glow plug, then
allow the engine to warm up for about 10 seconds.
❑After the engine has warmed up, drive the vehicle as you normally would.
If the engine seems to be running rich, lean the mixture screw about 1/16
of a turn at a time until the desired setting is achieved. Always make sure
you run the engine slightly rich - you want to be able to see a white exhaust
trail at all times.
To get more power from your engine you can use fuels containing up
to 30% nitromethane. We must caution you, though, that once you run
the engine with increased nitro you may not get satisfactory results if
you decide to go back to a lower nitro content. Also, if you use fuels
containing 30% nitro, we highly suggest adding a .10mm head gasket
(# 148453) to lower the compression ratio. If you don’t lower the
compression ratio, overheating and erratic running will likely occur.
Setting the Low Speed Needle Valve:
❑Start the engine and lean out the high speed needle valve as per the
previous procedures. Close the throttle until the engine slows down enough
so that the clutch is disengaged and the wheels don’t turn when the vehicle
is lifted from the ground. Allow the engine to idle for about 10-15 seconds.
❑While holding the vehicle off the ground (making sure to keep your
fingers out of the moving parts) quickly open the throttle in a short burst. If
the engine just stops running as soon as the throttle is advanced, the idle
mixture is too lean. With the engine stopped, richen the idle mixture about
1/16 of a turn.
❑Restart the engine and repeat the procedure above until the engine will
transition smoothly and quickly. Very slight hesitation in the transition is normal.
❑If you quickly advance the throttle and the engine seems to be very rich
during transition (i.e., lots of smoke coming from the exhaust and very
rough sounding), the idle mixture is too rich. With the engine stopped, lean
the idle mixture about 1/16 of a turn.
❑Restart the engine and repeat the procedure above until the engine will
transition smoothly and quickly. Very slight hesitation in the transition is normal.
❑Now drive the vehicle as you normally would for a while to get a feel for
how the engine reacts to throttle. Now that you know the proper way to tune
the engine, you can make slight adjustments to the carburetor until you are
satisfied with the performance.
After your engine has been broken in, you can set the high and low speed
needle valves for optimum engine performance.
Step 2: Fine Tuning the Engine

13
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
SECTION 8: INSTALLING THE BODY & WING
❑Secure the wing to the back of the body using your favorite method. One option is
to use double-sided tape between the wing and the body, or a second option is to use
small machine screws, washers and nuts. The second option is preferred because it's
stronger and will last longer.
❑Place the body onto the chassis, making sure that the four predrilled holes in the body
slide over the four body posts.
❑Secure the body in place using four metal body clips.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦We suggest cutting out the driver's side window to allow adequate
airflow over the engine. This will help prevent the engine from over-heating. It will also
allow you to fill the fuel tank and start the engine without removing the body.
SECTION 9: MAKING CHASSIS ADJUSTMENTS
Chassis alignment and geometry are important if you want your X-Cellerator Nitro Stadium Racer to perform well. A good performing
vehicle means a vehicle that is easier to drive, too. Follow our guidelines in this section to get the most out of your vehicle.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦It's very important when making changes to the settings of your vehicle that you make the settings the same for
each side. For example, if you change the camber angle on the right front tire, you should change the camber angle on the left front
tire the same amount. If you change the spring tension on the left front shock, you should change the spring tension on the right
front shock the same amount, and so on.
Do not make any changes that are more than 3 degrees from the initial settings listed or the handling characteristics of your vehicle will
become very poor.
RECOMMENDED INITIAL SETTINGS:
●1-2 degrees toe-in on the front to add stability.
☞Adding more than 3 degrees of toe-in or toe-out will result in excessive loss of speed
and erratic handling.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦For more precise toe-in adjustments, use the R.P.M. Toe-in Gauge
part # 708049.
The toe angle is the angle of both front tires to each other - when viewed from above. Toe-in (both tires pointing toward each other) will
make your truck track straighter, but the steering will be more sensitive. Toe-out (both tires pointing away from each other) will
desensitize the steering, making the truck a little more driver-friendly.
●Adjust the toe angle of the front wheels by turning the tie-rods with an adjustable wrench.
Step 1: Adjusting the Toe Angle

14 Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
RECOMMENDED INITIAL CAMBER SETTINGS:
●For driving on smooth surfaces set both the front and back wheels at 0 degrees.
●For driving on rough surfaces set the front wheels at -1 degree and the back wheels at -2 degrees.
☞Camber settings should be measured with the vehicle at its normal ride height.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦For more precise camber adjustments, use the R.P.M. Precision Camber Gauge part # 708099.
Negative Camber Positive Camber
Camber changes the amount of the tire's surface that contacts the ground. Tires that are exactly perpendicular to ground have 0
degrees of camber. If the top of the tires lean toward each other, the tires have negative camber. If the top of the tires lean out away from
each other, the tires have positive camber.
●Adjust the camber angle of the front and/or rear wheels by turning the upper turnbuckles using an adjustable wrench.
Step 2: Adjusting the Camber Angle
RECOMMENDED INITIAL SETTINGS:
●We recommend initially leaving the adjustment rings in the factory locations.
☞When adjusting the spring tension, make sure to adjust the right and left sides equally.
By adjusting the spring tension of the shocks, you can increase steering sensitivity and increase the ride-height of your vehicle. How you
drive your vehicle will dictate what settings you should be using. As an example, if you're using your vehicle off-road and going over lots
of jumps, you may want to increase the spring tension of the front shocks to help prevent the front of the vehicle from bottoming out.
●Increase or decrease spring tension by threading the adjustment ring up or down the shock shaft. Threading the ring down increases
spring tension, threading the ring up decreases spring tension.
Step 3: Adjusting Shock Spring Tension
Changing the shock oil (the oil inside the shocks) will change the dampening characteristics of the shocks. Typically, if you are running
on smooth surfaces, use a heavier weight oil. If you are running on rough surfaces, use a lighter weight oil.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦We recommend using only 100% Silicone Shock Oil. Do not use motor oil. The shock oil in the X-Cellerator Nitro
Stadium Racer's shocks is good for most off-road applications.
Moving the upper mounting position of the rear shocks to a hole in the shock tower that results in the shock assembly being more upright
will result in more "bite" in the rear of the vehicle.
Step 4: Adjusting Shock Dampening & Shock Body Mounting Location

15
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
Step 5: Adjusting the Slipper Clutch
The slipper clutch is a traction control device that uses two metal plates and a series of fiber pads to control how much power is
transmitted from the engine to the gear box and drive-train. Adjusting the slipper clutch allows you to fine tune how your vehicle reacts
when giving it throttle. Driving the vehicle with the slipper clutch too tight will usually result in the vehicle doing wheelies or spinning out
of control instead of accelerating. Driving the vehicle with the slipper clutch too loose will result in very poor or no acceleration at all.
●To adjust the slipper clutch you simply turn the hex nut either in to tighten the clutch (less slip) or out to loosen the clutch (more slip).
After making each adjustment, accelerate the vehicle for a short distance while carefully watching the slipper clutch. Ideally the clutch
should slip for about the first foot after acceleration.
RECOMMENDED INITIAL SETTINGS:
●Initially no adjustments should be necessary. The slipper clutch is preset. If you do
adjust the slipper clutch, make adjustments in 1/4-turn increments until you are satisfied
with the result.
✦✦
✦✦
✦IMPORTANT✦✦
✦✦
✦Running the slipper clutch too loose can cause the fiber pads to wear out
very quickly and replacement under this circumstance will not be covered under warranty.
With the transmitter and receiver turned on, and the throttle/brake trim lever centered, the
vehicle should roll smoothly (i.e., the brake should be disengaged). If the brake is
dragging when the throttle trigger is at neutral, the brake disc will wear out very quickly. To
ensure that the brake is disengaged, always make sure that there is a 1/8" gap between
the linkage collar and the brake lever.
●To make adjustments to the brake, simply loosen the set screw in the wheel collar next
to the brake lever and reposition it, then retighten the set screw.
The throttle/brake linkage in the X-Cellerator Nitro Stadium Racer is preset from the factory; however, after running the vehicle you may
find that the brake linkage needs adjusting.
Step 6: Adjusting the Brake Linkage
Step 7: Adjusting the Ball Differential
The ball differential should be adjusted after the first couple of runs. After that, it should require very little adjustment - only to fine-tune
the differential to your driving style or track.
●To adjust the differential you will need to pull the passenger's side axle from the drive
cup. To do this, first remove the wheel from the axle, then remove the shock assembly
from only the shock tower. Second, lower the suspension arm down as far as possible
and the axle should come out of the drive cup.
●After the axle is removed from the drive cup, use a small screwdriver to pop out the
nylon plate that is inside the drive cup.
●While holding the opposite wheel with one hand, use a 5/64" (2mm) hex wrench to tighten or loosen the hex screw in the center of the
drive cup, until you're satisfied with the operation of the differential.
●After adjusting the differential, reinstall the assemblies in the reverse order of removal.

16 Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
Following a simple maintenance schedule will ensure that your X-Cellerator Nitro Stadium Racer, engine and radio system operate in
top condition every time you use them. It is strongly suggested.
●Check the foam air filter element for dirt blockage. If the foam
is dirty, remove it from the filter housing and wash it in liquid soap
and warm water. Dry the foam element with a paper towel,
reinstall it and "wet" it with after-run oil.
●Check the chassis for any loose screws, especially the engine
and tuned pipe mounting screws. Tighten them if necessary.
●Check the steering linkage and the throttle/brake linkage for
any signs of wear or misalignment. Tighten and/or readjust them
if necessary.
●Once in a while, remove the wheels and clean the wheel bearings
using a bearing cleaner. This will remove any dust and grit that
may, over time, damage the bearings. After cleaning the
bearings, re-oil them using a good quality bearing oil. Never run
the bearings dry or damage to the bearings will result.
●Check the fuel system, including the fuel tank and fuel lines,
for any signs of cracking or looseness. Replace any fuel line you
suspect may be damaged.
●Periodically check the condition of the transmitter and receiver
batteries. If you think they might be low, replace them with a
fresh set.
●You should periodically check and adjust the slipper clutch as
described on page # 15.
●After a period of time the chassis will accumulate a lot of dirt
and debris, especially around the engine area. This build-up
should be cleaned off using a high-powered spray cleaner like
Emerald Nitro Car Cleaner. Some nitro car cleaners will damage
anodized and/or plated parts. Test on an inconspicuous
area first.
●After cleaning the chassis and engine with Nitro Car Cleaner
you should oil the moving parts of the chassis. Do not oil the
clutch bell, spur gear or the brake disc.
●Always use new fuel and keep the cap on the fuel tightly closed.
As fuel ages it absorbs water, which degrades the fuels performance
and will cause erratic engine operation.
●After you have finished using the engine for the day, remove
the glow plug and squirt several drops of a high-quality after-run
oil into the cylinder. Reinstall the glow plug and crank the engine
over a couple of times (without the glow starter attached) to
distribute the oil. This will prevent corrosion inside the engine.
●Never leave unused fuel in the fuel tank for more than a couple
of days. The nitromethane and methanol in the fuel will
evaporate, leaving the oil behind. This will eventually turn into a
thick sludge that will require replacement of the fuel tank to fix.
SECTION 10: MAINTAINING YOUR X-CELLERATOR NITRO STADIUM RACER
This troubleshooting guide has been provided to help you diagnose and solve most problems that you may encounter with your X-Cellerator
Nitro Stadium Racer. Most problems encountered can be solved by carefully following the problem-cause-solution sections. If you
cannot solve the problem using this troubleshooting guide, please feel free to contact us at the address, phone number or email address
shown on the second page of this Basic Operations Guide.
IF YOU'RE HAVING A PROBLEM WITH THE HITEC LYNX SPORT RADIO SYSTEM:
PROBLEM CAUSE SOLUTION
1) Radio system does not operate A) Transmitter and/or receiver batteries are low A) Replace transmitter and/or receiver batteries
B) Batteries are installed incorrectly B) Check that the polarity of the batteries is correct
C) Receiver battery connector is loose C) Check that receiver battery connector is plugged in and tight
2) Operating range is short A) Transmitter antenna is retracted A) Extended transmitter antenna completely
B) Receiver antenna is not extended B) Extend receiver antenna completely
C) Receiver antenna is cut C) Return receiver to Hitec/RCD for repair
D) Transmitter and/or receiver batteries are low D) Replace transmitter and/or receiver batteries
3) Servos do not operate normally A) Transmitter and/or receiver batteries are low A) Replace transmitter and/or receiver batteries
B) Servo gear stripped or otherwise damaged B) Return to Hitec/RCD for repair
4) When engine is running, radio A) Receiver crystal is loose A) Remove and reinstall the receiver crystal
system operates erratically B) Receiver battery connector is loose B) Check that receiver battery connector is tight
C) Damage to receiver after a crash C) Return to Hitec/RCD for repair
SECTION 11: TROUBLESHOOTING GUIDE

17
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]
PROBLEM CAUSE SOLUTION
1) Engine does not start A) Failed glow plug A) Replace glow plug with new one
B) Glow Starter not charged and/or faulty B) Fully charge glow starter and/or replace
C) Idle mixture screw set too lean C) Reset idle mixture to factory setting (P10)
D) Old or contaminated fuel D) Replace with new fuel
E) Engine flooded with too much fuel E) Remove glow plug and expel fuel from cylinder (P10)
F) Air leak in fuel system and/or engine F) Replace fuel lines and/or tighten all engine bolts
2) Engine does not draw fuel A) Air leak in fuel system and/or engine A) Replace fuel lines and/or tighten all engine bolts
B) High speed needle valve fully closed B) Reset high speed needle valve to factory setting (P9)
C) Idle mixture screw set too lean C) Reset idle mixture to factory setting (P10)
D) Fuel lines kinked D) Check and straighten fuel lines
E) Defective fuel tank E) Replace fuel tank
3) Engine does not transition A) Failed and/or wrong type glow plug A) Replace with new recommended glow plug (P12)
B) Old and/or wrong type fuel B) Replace with new recommended fuel (P3)
C) High speed needle valve set too rich C) Reset high speed needle valve to leaner setting (P12)
D) Idle mixture set too lean D) Set idle mixture richer (P12)
E) Idle mixture set too rich E) Set idle mixture leaner (P12)
F) Air leak in fuel system and/or engine F) Replace fuel lines and/or tighten all engine bolts
4) Engine overheats A) Engine running too lean A) Richen high speed needle valve (P12)
B) Body too Restrictive B) Open larger vents in body to allow air to enter and exit
C) Wrong type of fuel used C) Use fuel recommended only for R/C cars (P3)
D) Engine not fully broken in D) Allow engine further break-in time (P12)
5) Engine vibrates excessively A) Engine and/or engine mounts loose A) Tighten all engine and engine mounting bolts
6) Engine does not idle down A) Idle stop screw out of adjustment A) Adjust idle stop screw to factory setting (P10)
B) Engine has developed an air leak B) Check and tighten all engine screws
C) One or more carburetor O-rings damaged C) Replace carburetor O-rings
IF YOU'RE HAVING A PROBLEM WITH THE XTM RACING .18 ENGINE AND/OR PULL-STARTER ASSEMBLY:
IF YOU'RE HAVING A PROBLEM WITH THE X-CELLERATOR NITRO STADIUM RACER CHASSIS:
PROBLEM CAUSE SOLUTION
1) Vehicle pulls to one side A) Steering trim out of adjustment A) Readjust trim to center both wheels (P8)
B) Toe-in not equal B) Readjust the toe-in to 1 - 2 degrees (P13)
C) Wheel on one side is hanging or has damaged bearing C) Remove wheel and clean bearing. Replace if necessary
2) Brake seems ineffective A) Brake linkage out of adjustment A) Readjust brake linkage (P15)
B) Brake disc worn B) Replace brake disc
3) Clutch does not engage A) Clutch shoes damaged or worn A) Replace clutch shoes
B) Clutch bell damaged or worn B) Replace clutch bell
4) Clutch does not disengage A) Clutch springs worn or damaged A) Replace clutch springs
5) Vehicle does not "go" A) Stripped spur gear A) Replace spur gear
B) Stripped differential gear(s) B) Replace differential gear(s)
C) Slipper clutch set too loose C) Readjust slipper clutch until vehicle accelerates
smoothly (P15)
6) Vehicle wheelies or A) Slipper clutch set too tight A) Loosen slipper clutch until vehicle accelerates
flips over backwards smoothly (P15)
7) Suspension not smooth or free A) One or more shocks sticking A) Clean and/or rebuild the affected shock
B) Bent shock shaft B) Rebuild affected shock
C) Bent or otherwise damaged hinge pin C) Replace hinge pin
8) Shocks leaking oil A) Shock seals worn A) Replace shock seals
B) Bent shock shaft B) Rebuild affected shock

18 Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com

19
Need help or have any questions? Call us at 1-714-963-0329 or send us an Email at [e-mail]

20 Visit our website at http://xtm.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
IMPORTANT WARRANTY SERVICE INFORMATION
Before returning your X-Cellerator Nitro Stadium Racer for warranty consideration, the status of the unit must be within the guarantee as
stated above. Do not return your X-Cellerator Nitro Stadium Racer to the place of purchase. They are not authorized or equipped to
perform warranty work on XTM Racing products. When requesting warranty service, please observe the following:
●Crash damage will not be covered under warranty. Do not request warranty service for a crash-damaged product.
●If you are requesting warranty on anything other than just the radio control system, always send your vehicle complete with the
transmitter. Please unplug and/or remove the batteries both from the transmitter and the vehicle before returning it. We like to have the
vehicle complete so it can be thoroughly tested before returning it to you.
●If you are requesting warranty service for only the radio system do not send the radio system or the vehicle to us. Remove the radio
system from the vehicle and return it to Hitec/RCD for warranty consideration. See Special Notice above.
●Include a note detailing the problem or service you are requesting. Service cannot be provided without this information. Include your
daytime phone number, shipping address and/or email address in the event we need more details pertaining to the service requested.
●If your vehicle is out of the warranty period you may request an estimate of services at the time you return your vehicle for service. An
omission of this request implies permission for Global Services to service your vehicle at our discretion.
●Include a method of payment for any service charges.
●Send the unit to us by United Parcel Service, Federal Express or by Insured Mail. Postage is non-refundable. Send your package to:
IMPORTANT WARRANTY INFORMATION - PLEASE READ!
Your XTM Racing X-Cellerator Nitro Stadium Racer is warranted against manufacturer defects in materials and workmanship for a
period of 90 days from the date of purchase. Warranty service will be provided within 90 days of the date of purchase only if you are
able to provide the original or a copy of the original dated sales receipt.
SPECIAL NOTICE
The radio control system preinstalled in your XTM Racing X-Cellerator Nitro Stadium Racer is manufactured and warranted by Hitec/RCD
North America. This includes the transmitter, receiver, servos, battery box and on/off switch. Do not return the radio system to Global
Services. It must be removed from the X-Cellerator Nitro Stadium Racer and returned to Hitec/RCD at the address shown:
Hitec/RCD, Inc.
Attn: Customer Service Center
12115 Paine Street
Poway, CA 92064
To locate the dealer nearest you, please call us at [phone] or visit our dealer directory on the Internet at
www.globalhobby.com/where2buy.htm
or Order Directly From Us at the Address, Phone Number or Web Site Shown Above
Visit Our Website
http://globalservices.globalhobby.com
Global Services
18480 Bandilier Circle
Fountain Valley CA 92708
Phone: [phone] Fax: [phone] Email: [e-mail]
PURCHASING REPLACEMENT PARTS
Included with your X-Cellerator Nitro Stadium Racer is a separate listing of available replacement parts. The part numbers for each
part are provided for ordering convenience. Replacement parts are available through your local authorized XTM Racing dealer or
directly from us.
