OPERATING MANUAL
ba75981e02 12/2017
MPP 910 IDS
MPP 930 IDS
MODULARE MULTIPARAMETERSONDE MIT TIEFENMESSUNG
MPP 910 IDS MPP 930 IDS

2ba75981e02 12/2017
MPP 9x0 IDS
Copyright ©2017 Xylem Analytics Germany GmbH
Printed in Germany.

MPP 9x0 IDS - Contents
ba75981e02 12/2017 3
MPP 9x0 IDS Contents
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Opening and closing the plug connections . . . . . . . . . . . . . . . . . 7
2.2 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Mounting the holding shackle . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1 Dimensions, weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.1 MPP 910 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1.2 MPP 930 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2 Application characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.3 General data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4 Measurement characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Wear parts and accessories . . . . . . . . . . . . . . . . . . . . . . . . . 15

Overview MPP 9x0 IDS
4ba75981e02 12/2017
1Overview
The MPP 9x0 IDS multi-parameter probe is a modular system, consisting of
a basic module and various expansion options.
System
components
(figure see page
on the right)
Depth
measurement
On the shaft of the basic module there is a pressure sensor with integrated
temperature measurement. Based on the pressure and temperature value
the meter calculates the depth of immersion in the measuring medium. The
temperature measurement is used for the temperature compensation of the
pressure sensor and for density compensation.
1Basic module MPP 910 IDS with one sensor plug-in position
2Basic module MPP 930 IDS with three sensor plug-in positions
3AS/IDS-xx connection cable between basic module and meter or sen-
sor and meter (xx = different lengths available)
4Blind plug BPO/IDS 900 for cable plug-in position
Expansion options:
5Digital sensors of the XXX-P series, e.g. FDO 925-P
6BPI/IDS 900 blind plug for BPI/IDS 900 sensor plug-in position
7Long protective tube, to protect the sensors connected
8Short protective tube, for usage of the basic module without any sen-
sors. Reduces the distance between the depth/temperature sensor
and the bed of the water body
9Sinker
10 Holding shackle (accessory) to be screwed on instead of the protec-
tive ring (pos. 11)
11 Protective ring
Depth/temperature sensor

MPP 9x0 IDS Overview
5
ba75981e02 12/2017
MPP 930 IDSMPP 910 IDS
21
34
5
6
7
8
7
8
9
9
10
11
11
10

Overview MPP 9x0 IDS
6ba75981e02 12/2017
IDS plug
connection
All plug connections of the basic module, sensors, connection cable and blind
plug are of the same type. A lock protects the connections against being inad-
vertently disconnected.
With the connection cable, the individual sensors can also be directly
connected to the meter if necessary (for calibration or firmware update).
Recommended
fields of
application
On-site measurements in rivers, lakes, sea water and brackish water,
wells, leachate that is not or only slightly polluted
Measurements in boreholes
Depth profile measurements
Measurements in ground and spring water

MPP 9x0 IDS Operation
7
ba75981e02 12/2017
2 Operation
2.1 Opening and closing the plug connections
The following instructions apply to all actions where any components are con-
nected or disconnected (e.g. exchange of blind plug ⇌sensor):
Opening the plug
connection
If necessary, clean the plug connection
Open the locking device (step 1)
Use your thumb and index finger to press the clips of the connector
together, and pull the connector out of the plug (step 2).
Closing the plug
connection
Make sure that the plug connection is completely dry and clean.
Align the guidance of the connector with the groove in the plug and insert
the connector in the unlocked plug until it catches (step 3).
Close the locking device (step 4).
2
4
3
1
Plug connection
closed and locked
Guidance
Groove

Operation MPP 9x0 IDS
8ba75981e02 12/2017
NOTE
All plug-in positions have to be equipped with sensors or closed with
blind plugs before the multi-parameter probe is immersed in the
measuring medium.
2.2 Commissioning
Prepare the sensors for the measuring operation (see sensor operating
manual). For calibration, connect the sensors to the meter with the 1.5 m
connection cable.
Equip the basic module with the required sensors:
– Unscrew the short protective pipe
– Per plug-in position:
Replace the blind plug with a sensor (depending on the required
design, how to do this is described on page 7).
– Screw on the long protective pipe
Screw the sinker on the open end of the protective pipe so the probe will
go down faster.
Connect the basic module to the meter.
NOTE
The connection cable without any problems withstands the tractive
forces that occur when it is pulled by hand in a water body where there
are no strong current and no obstacles. If the current is strong or if
there are obstacles the tractive forces can temporarily be much higher
and cause the cable to snap. If you are in doubt we recommend to
attach the multi-parameter probe with the holding shackle (accesso-
ries) to a sufficiently strong rope or a chain so the probe will not be lost.
NOTE
All plug-in positions have to be equipped with sensors or closed with
blind plugs before the multi-parameter probe is immersed in the
measuring medium.
Calibrating the sensors while they are installed is not possible.
The depth and temperature measurement of the basic module is
calibration free (factory calibration).

MPP 9x0 IDS Operation
9
ba75981e02 12/2017
2.3 Mounting the holding shackle
The holding shackle is screwed onto the sensor instead of the protective ring.
To do so, proceed as follows (sample figure of MPP 930 IDS):
Disconnect the connection cable from the basic module (see page 7)
Unscrew the protective ring (pos. 1).
Thread the connection cable through the connecting piece of the holding
shackle (pos. 2) and reconnect it to the basic module
Screw the holding shackle to the basic module
1
2

Cleaning MPP 9x0 IDS
10 ba75981e02 12/2017
3 Cleaning
Exterior cleaning Remove water-soluble contamination by rinsing with deionized water. Other
types of contamination have to be removed as follows while the contact time
with the detergents should be kept as short as possible:
Thoroughly rinse the multi-parameter probe with water after this.
Cleaning the
pressure sensor
To clean the pressure sensor, remove the screen lid with your fingernails.
Then rinse the recess with a mild water jet (e.g. wash bottle or slightly-
running faucet).
NOTE
The membrane of the depth sensor is very sensitive to mechanical
impacts. Therefore, avoid any touching of the membrane. Do not point
a sharp water jet at the membrane while cleaning it.
Please observe the instructions on cleaning the sensors given in
the respective sensor operating manuals. If necessary, remove
the sensor for cleaning and close its plug-in position with a blind
plug.
Contamination Cleaning procedure
Fat and oil Rinse with water containing household wash-
ing-up liquid
Lime and hydroxide deposits Rinse with citric acid (10 % by weight)

MPP 9x0 IDS Technical data
11
ba75981e02 12/2017
4 Technical data
4.1 Dimensions, weights
4.1.1 MPP 910
Dimensions
(in mm)
Weights Basic module without cable,
sinker and sensors (all plug
connections closed with
blind plugs)
With short protective pipe
approx. 274 g
With long protective pipe
approx. 355 g
Sinker Approx. 497 g
Holder EH/40-SW 64 g
297
443
347
503
40
40
Protective pipe long
Protective pipe
short

Technical data MPP 9x0 IDS
12 ba75981e02 12/2017
4.1.2 MPP 930
4.1.3 Accessories
Dimensions
(in mm)
Weights Basic module without cable,
sinker and sensors (all plug
connections closed with
blind plugs)
With short protective pipe
approx. 929 g
With long protective pipe
approx. 1131 g
Sinker Approx. 1870 g
Holder EH/70-SW 105 g
400
297
69,5
69,5
500
347
Protective pipe long
Protective pipe
short
Weights BPI/IDS 900 17 g
BPO/IDS 900 12 g

MPP 9x0 IDS Technical data
13
ba75981e02 12/2017
4.2 Application characteristics
4.3 General data
The application range of a multi-parameter probe can be limited
due to the sensors installed (see sensor operating manuals). The
following specifications refer to the probe without any sensors
installed.
Measuring
medium
Allowed
temperature range
-5 ... 50 °C (23 ... 122 °F)
Allowed pH range 4 ... 12
Pressure
resistance
IP 68 (1 x 106Pa or 10 bar)
The MPP 9x0 IDS multi-parameter probe meets the requirements accord-
ing to article 3(3) of the directive, 97/23/EC ("pressure equipment direc-
tive").
Storage
conditions
Storage temperature -25 ... 50 °C (-13 ... 122 °F)
Materials Enclosure of the basic mod-
ule, protective pipe, blind
plug
POM
Sinker Stainless steel 1.4571
Depth temperature sensor
including pressure mem-
brane
Hastelloy®C-276
Holding shackle (option) Titan Grade 3
IDS plug
connection
Connection type 4-pole, watertight plug connection with lock,
reverse polarity protected
Materials of plug and con-
nector
Synthetic materials: Glass fiber reinforced
Noryl, TPU, TPC-ET, POM, PEEK, PBT
O-ring: FPM
Contacts gold-plated

Technical data MPP 9x0 IDS
14 ba75981e02 12/2017
4.4 Measurement characteristics
Connection cable Diameter 4.3 mm
Smallest allowed bend
radius
Permanent bend: 63 mm
Single time or short time bend:21 mm
Material of cable sheath TPE-U, aramid fiber reinforced
Depth
measurement
Measuring principle Piezo-resistive pressure sensor, calibration-
free
Measuring ranges at 20 °C
(68 °F)
0.50 ... 100.00 m (328 ft)
Resolution 0.05 m (0.16 ft)
Accuracy at 20 °C (68 °F) 0.25 m (0.82 ft) ± 1 digit
Automatic density compen-
sation
Indirectly through the integrated temperature
measurement. Calculated by the measuring
instrument on the basis of the temperature/
density function of water.
Additional compensation of the salinity after
the salinity value was entered on the meter.
Temperature
measurement
Temperature sensor Semiconductor sensor integrated in the
pressure sensor
Measuring range -5 ... 50 °C (23 ... 122 °F)
Resolution 0.1 K

MPP 9x0 IDS Wear parts and accessories
15
ba75981e02 12/2017
5 Wear parts and accessories
Note
For further accessories, refer to the WTW catalog or the Internet.
Connection
cableMPP 9x0 IDS
- meter
Description Model Order no.
IDS connection cable, 1.5 m AS/IDS-1.5 903 850
IDS connection cable, 3 m AS/IDS-3 903 851
IDS connection cable, 6 m AS/IDS-6 903 852
IDS connection cable, 10 m AS/IDS-10 903 853
IDS connection cable, 15 m AS/IDS-15 903 854
IDS connection cable, 20 m AS/IDS-20 903 855
IDS connection cable, 25 m AS/IDS-25 903 856
IDS connection cable, 40 m AS/IDS-40 903 857
IDS connection cable, 60 m AS/IDS-60 903 858
IDS connection cable, 100 m AS/IDS-100 903 859
Blind plug Description Model Order no.
Blind plug for IDS sensor plug-in position BPI/IDS 900 908 370
Blind plug for IDS cable plug-in position BPO/IDS 900 908 371
General
accessories
Description Model Order no.
Holding shackle for MPP 910 IDS EH/40 SW 109 315
Holding shackle for MPP 930 IDS EH/70 SW 109 316

Wear parts and accessories MPP 9x0 IDS
16 ba75981e02 12/2017

What can Xylem do for you?
We're a global team unified in a common purpose: creating innovative solutions to
meet our world's water needs. Developing new technologies that will improve the way
water is used, conserved, and re-used in the future is central to our work. We move,
treat, analyze, and return water to the environment, and we help people use water
efficiently, in their homes, buildings, factories and farms. In more than 150 countries, we
have strong, long-standing relationships with customers who know us for our powerful
combination of leading product brands and applications expertise, backed by a legacy
of innovation.
Xylem Analytics Germany GmbH
Dr.-Karl-Slevogt-Str. 1
82362 Weilheim
Germany
Xylem Analytics Germany
Sales GmbH & Co. KG
WTW
Dr.-Karl-Slevogt-Str. 1
82362 Weilheim
Germany
Tel.:
Fax:
E-Mail
Internet:
[phone]
[phone]
wtw[email protected]
www.WTW.com
Service and Returns:
®
For more information on how Xylem can help you, go to xyleminc.com.
