Xylem e-IXP Manual

e-IXP, e-IXPC, e-IXPF
Pumps according to ISO 2858 and ISO 5199
Installation, Operation
and Maintenance Instructions

en – Original instructions
2 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
Table of Contents
1Introduction and Safety ............................................................................................................................................ 5
1.1 Introduction ...................................................................................................................................................... 5
1.2 Hazard levels and safety symbols.................................................................................................................... 5
1.3 User safety ........................................................................................................................................................ 6
1.4 Protection of the environment......................................................................................................................... 6
1.5 Spare parts........................................................................................................................................................ 7
2Handling and Storage............................................................................................................................................... 8
2.1 Unit inspection upon delivery.......................................................................................................................... 8
2.1.1 Package inspection ...................................................................................................................................... 8
2.1.2 Unpacking and inspection of the unit ......................................................................................................... 8
2.2 Guidelines for transport ................................................................................................................................... 8
2.2.1 Handling of the packed unit using a forklift truck....................................................................................... 9
2.2.2 Lifting with a crane ....................................................................................................................................... 9
2.3 Storage ........................................................................................................................................................... 11
2.3.1 Storage of the packed unit ........................................................................................................................11
2.3.2 Long-term storage of the unit....................................................................................................................11
2.3.3 Return..........................................................................................................................................................11
3Description of the Product .....................................................................................................................................12
3.1 Features .......................................................................................................................................................... 12
3.2 Data plate ....................................................................................................................................................... 13
3.3 Identification code .........................................................................................................................................13
3.4 Part names ......................................................................................................................................................14
4Installation ...............................................................................................................................................................15
4.1 General precautions.......................................................................................................................................15
4.2 Mechanical installation................................................................................................................................... 15
4.2.1 Precautions ................................................................................................................................................. 15
4.2.2 Installation area .......................................................................................................................................... 15
4.2.3 Installation on concrete foundation........................................................................................................... 15
4.2.4 Frame installation....................................................................................................................................... 17
4.3 Hydraulic connection ..................................................................................................................................... 17
4.3.1 Precautions ................................................................................................................................................. 17
4.3.2 Guidelines for the hydraulic system ..........................................................................................................17
4.3.3 Forces and torques that can be applied to the ports ...............................................................................18
4.3.4 Auxiliary Connections ................................................................................................................................19
4.4 Alignment of the motor-pump coupling.......................................................................................................20
4.4.1 Disassembling the coupling guards..........................................................................................................20
4.4.2 Checking the coupling alignment .............................................................................................................20
4.4.3 Installing the coupling guards ...................................................................................................................21

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 3
4.5 Bearing lubrication......................................................................................................................................... 22
4.6 Mechanical seals and auxiliary systems ........................................................................................................ 22
4.6.1 Stuffing box gland adjustment .................................................................................................................. 23
4.7 Electrical connection......................................................................................................................................23
4.7.1 Precautions ................................................................................................................................................. 23
4.7.2 Guidelines for electrical connection.......................................................................................................... 24
4.7.3 Motor connection.......................................................................................................................................24
4.7.4 Overload protection................................................................................................................................... 24
4.7.5 Operation with frequency converter .........................................................................................................25
5Use and operation ..................................................................................................................................................26
5.1 Precautions .....................................................................................................................................................26
5.2 Checking the rotation direction..................................................................................................................... 27
5.3 Intended use...................................................................................................................................................28
5.4 Start-up ...........................................................................................................................................................28
5.5 Stopping .........................................................................................................................................................29
6Maintenance............................................................................................................................................................30
6.1 Precautions .....................................................................................................................................................30
6.2 Periodic maintenance .................................................................................................................................... 31
6.2.1 Grease top up.............................................................................................................................................33
6.2.2 Replacing the grease .................................................................................................................................33
6.2.3 Changing the oil ......................................................................................................................................... 33
6.2.4 Inspection work ..........................................................................................................................................34
6.2.5 Replacement of the shaft seal.................................................................................................................... 34
6.3 Long periods of inactivity...............................................................................................................................35
6.4 Spare parts ordering ......................................................................................................................................35
6.5 Tightening torques.........................................................................................................................................36
7Troubleshooting......................................................................................................................................................38
7.1 Precautions .....................................................................................................................................................38
7.2 The unit does not start ...................................................................................................................................38
7.3 The differential protection device (RCD) has tripped .................................................................................. 38
7.4 The unit produces excessive noise and/or vibrations ..................................................................................38
7.5 The thermal overload protection triggers or the fuses trip..........................................................................39
7.6 The thermal overload protection triggers..................................................................................................... 39
7.7 The motor becomes excessively hot .............................................................................................................39
7.8 Little or no hydraulic performance ................................................................................................................39
7.9 When switched off, the unit turns in the opposite direction ........................................................................40
7.10 The unit starts and stops too frequently........................................................................................................ 40
7.11 The unit does not stop ...................................................................................................................................40
7.12 The unit is leaking at the mechanical seal.....................................................................................................40
7.13 The frequency converter is in error mode or turned off...............................................................................40
8Technical Information .............................................................................................................................................41
8.1 Operating environment .................................................................................................................................41

en – Original instructions
4 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
8.2 Temperature of pumped liquid .....................................................................................................................41
8.3 Maximum operating pressure .......................................................................................................................42
8.4 Electrical specifications..................................................................................................................................42
8.5 Maximum number of starts per hour............................................................................................................. 43
8.6 Sound pressure .............................................................................................................................................. 43
8.7 Construction and maintenance data ............................................................................................................. 44
8.8 Section drawings and list of parts.................................................................................................................. 45
8.8.1 Drawings..................................................................................................................................................... 45
8.8.2 List of parts ................................................................................................................................................. 51
9Disposal................................................................................................................................................................... 53
9.1 Precautions .....................................................................................................................................................53
9.2 WEEE (EU/EEA) .............................................................................................................................................. 53
9.3 WEEE (UK) ...................................................................................................................................................... 53
10 Declarations........................................................................................................................................................54
10.1 EC Declaration of Conformity (Original) .......................................................................................................54
10.2 EU Declaration of Conformity (n. 59) ............................................................................................................54
10.3 UKCA Declaration of Conformity (Original).................................................................................................. 55
10.4 UKCA Declaration of Conformity (n. 59).......................................................................................................56
11 Warranty .............................................................................................................................................................57
11.1 Information .....................................................................................................................................................57

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 5
1Introduction and Safety
1.1 Introduction
Purpose of this manual
This manual provides information on how to do the following in the correct manner:
•Installation
•Operation
•Maintenance.
CAUTION:
This manual is an integral part of the unit. Be sure to read and understand the manual before
installing the unit and putting it to use. The manual must always be made availabl
e to the user,
stored in the proximity of the unit, and well kept.
Supplementary instructions
The instructions and warnings of this manual apply to the standard unit as described in the sale
documentation. Special version pumps may be supplied with supplementary instruction
manuals. For situations not considered in the manual or in the commercial documentation,
contact Xylem or its Authorised Distributor.
1.2 Hazard levels and safety symbols
Before using the unit, the user must read, understand and comply with the indications of the
danger warnings in order to avoid the following risks:
•Injuries and health hazards
•Damage to the product
•Unit malfunction.
Hazard levels
Hazard level
Indication
DANGER:
It identifies a dangerous situation which, if not avoided, causes
serious injury, or even death.
WARNING:
It identifies a dangerous situation which, if not avoided, may cause
serious injury, or even death.
CAUTION:
It identifies a dangerous situation which, if not avoided, may cause
small or medium level injuries.
NOTE:
It identifies a situation which, if not avoided, may cause damage to
property but not to people.

en – Original instructions
6 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
Complementary symbols
Symbol
Description
Electrical hazard
Hot surface hazard
Danger, pressurized system
Specific marking for explosion protection
Do not use flammable liquids
Do not use corrosive liquids
Read the instruction manual
Ionizing radiation hazard
1.3 User safety
Strictly comply with current health and safety regulations.
Qualified personnel
This unit must be used only by qualified users. Qualified users are people able to recognise
the risks and avoid hazards during installation, use and maintenance of the unit.
1.4 Protection of the environment
Disposal of packaging and product
Comply with the current regulations on sorted waste disposal.
Leaking of fluid
If the unit contains lubricating fluid, take appropriate measures to prevent the dispersion of
leaks into the environment.
Sites exposed to ionizing radiations
WARNING: Ionizing radiation hazard
If the unit has been exposed to ionizing radiations,
implement the necessary safety measures
for the protection of people. If the unit needs to be dispatched, inform the carrier and the
recipient accordingly, so that appropriate safety measures can be put in place.

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 7
1.5 Spare parts
WARNING:
Replace all worn or
faulty parts with original spare parts, to prevent unit malfunction and
personal injury, as well as the warranty from becoming null and void.
Identify the spare parts with the product codes directly on the site www.lowara.com/spark.
Contact Xylem or its Authorised Distributor for technical information.

en – Original instructions
8 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
2Handling and Storage
2.1 Unit inspection upon delivery
2.1.1 Package inspection
1. Check that quantity, descriptions and product codes match the order.
2. Check the packaging for any damage or missing components.
3. In case of immediately detectable damage or missing parts:
•Accept the goods with reserve, indicating any findings on the transport document, or
•Reject the goods, indicating the reason on the transport document.
In both cases, promptly contact Xylem or its Authorised Distributor from whom the product
was purchased.
2.1.2 Unpacking and inspection of the unit
CAUTION: Cut and abrasion hazard
Always wear personal protective equipment.
1. Remove the packaging.
2. Ensure sorting of all packaging materials in accordance with the applicable regulations.
3. Release the unit by removing the screws and/or cutting the straps, if fitted.
4. Check the unit for integrity and to make sure that there are no missing components.
5. In case of damage or missing components, promptly contact Xylem or its Authorised
Distributor.
2.2 Guidelines for transport
Precautions
WARNING: Crushing hazard
The unit and components are heavy: risk of crushing.
WARNING:
Always wear personal protective equipment.
WARNING:
Check the gross weight marked on the packaging.
WARNING:
Handle the unit in compliance with the current regulations on "manual load handling", to avoid
undesirable ergonomic conditions causing risks of back
-spine injury.

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 9
2.2.1 Handling of the packed unit using a forklift truck
The Figure shows the types of packaging and the lifting points.
1. Cardboard box with wooden base
2. Wooden crate
2.2.2 Lifting with a crane
WARNING:
Use ropes, chains and/or slings (hereinafter referred to as "ropes"),
hooks and/or clasps
(hereinafter referred to as "hooks"), shackles or eyebolts that comply with the applicable
directives and are suitable for use.
WARNING:
It is forbidden to use the shaft end and/or the motor eyebolts to move the unit.
NOTE:
Make sure that the harnessing does not hit and/or damage the unit.
WARNING:
Lift and handle the unit slowly to avoid stability issues.
WARNING:
During handling, make sure to avoid injury to people and animals, and/or damage to property.
Preparing the unit for lifting
1. Depending on the model:
•Attach the shackles to the eyelets, if any, and attach the ropes to the shackles, or
•Use the ropes to make a tie harness.
The figure shows how to harness and lift the different models.
1 2

en – Original instructions
10 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
2. Fix the ropes to the crane.
3. Lift the crane and tension the ropes without lifting the unit.
Lifting and positioning
1. Lift and move the unit slowly
2. Set the unit down slowly.
3. Depending on the model:
•Release the ropes from the shackles, or
•Release the harness.

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 11
2.3 Storage
Precautions
WARNING:
Pay attention to liquids that are excessively hot or cold.
WARNING:
Make sure that the drained liquid cannot cause damage or injuries.
WARNING:
It is prohibited to dispose of lubricant liquids and other
hazardous substances in the
environment.
2.3.1 Storage of the packed unit
The unit must be stored:
•In a covered and dry place
•Away from heat sources
•Protected from dirt
•Protected from vibrations
•At an ambient temperature between -5°C and +40°C (23°F and 140°F), and relative
humidity between 5% and 95%.
NOTE:
Do not place heavy loads on top of the unit.
NOTE:
Protect the unit from collisions.
2.3.2 Long-term storage of the unit
1. Correctly empty the unit.
2. Close the suction and discharge ports with caps or flanges.
3. Follow the same instructions for the storage of the packed unit.
NOTE:
This operation is essential in environments with cold temperatures. Otherwise, any residual
liquid in the unit could have an adverse effect on its condition and performance.
For more information on long-term storage contact the Xylem sales company or Authorised
Distributor.
2.3.3 Return
1. Correctly empty the unit.
2. Wash and clean the unit, especially if used to process harmful, explosive, hot or potentially
hazardous liquids.
3. Neutralize the unit further and blow with inert gas without water to dry it, in case of liquids
the residues of which can cause corrosion damage due to moisture, or can ignite on contact
with oxygen.
4. Please attach a completed release statement to the unit. Indicate the safety and
decontamination measures implemented.

en – Original instructions
12 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
3Description of the Product
3.1 Features
The product is a single-stage end suction pump in back pull-out configuration with bearing
support, compliant with EN 22858 and ISO 2858. The product can be supplied as a pump unit
(pump with electric motor), or as a pump only.
Intended use
•Water supply
•Water transfer and circulation
•Process cooling and heating
•Cooling and heating in industrial buildings
•Industrial liquid transfer
•Boiler supply
•Remote heating and cogeneration
•Filtration and ultra-filtration systems
•Filtration in treatment systems
•Washers
•Galvanic processes and painting systems
•Cleaning of tanks and cisterns
•Mixing of liquids
•Water movement in water parks.
Observe the operating limits in Technical Information on page 41.
DANGER: Potentially explosive atmosphere hazard
It is prohibited to start the unit in environments with potentially explosive
atmospheres or with combustible dusts if it has no
EX-approval.
Pumped liquids
•Water
•Sea water
•Salt water
•Demineralized water
•Hot water
•Acids
•Brine
•Petrochemical products
•Chlorides
•Heat transfer fluids
•Oils
•Solvents
•Detergents
•Condensation.
DANGER:
Only EX approved units are allowed to pump
flammable liquids.

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 13
3.2 Data plate
1. Pump or pump unit type
2. Maximum operating pressure
3. Maximum liquid operating temperature
4. Full impeller diameter (non-trimmed impellers only)
5. Manufacturing date + serial number
6. Product code
7. Weight
8. Flow rate range
9. Minimum liquid operating temperature
10. Head range
11. Rotation speed
12. Reduced impeller diameter (trimmed impellers only)
13. Pump unit absorbed power
14. Minimum efficiency index
15. Hydraulic efficiency at the best efficiency point
3.3 Identification code
1. Series name
2. Size from 40-25-160 to 600-600-600
3. Impeller with full [A], reduced [B, C or D], standard [ ] or special [X] diameter
4. Motor power in kWx10 (370) or, for bare shaft pump only, impeller diameter in mm (324)
5. Lowara motor [P, L], WEG [W], ABB [A], or other manufacturer's [X]
6. 2-pole [2], 4-pole [4] or 6-pole [6] motor
7. Frequency 50 Hz [5] or 60 Hz [6]
8. Standard operating pressure, discharge side, PN 16 bar [B], PN 25 bar [C], class 150 [R] or class 300 [S]
9. Pump body made of cast ductile iron [D], stainless steel [N], duplex [R], super duplex [T], super-austenitic stainless
steel [U] or other material [X]
10. Impeller made of stainless steel [N], duplex [R], super duplex [T], super-austenitic stainless steel [U] or other
material [X]
11. Mechanical seal made of SiC/Carbon/EPDM [4], SiC/Carbon/EPDM for hot water [6], SiC/Carbon/FKM [2],
SiC/SiC/EPDM [Z], SiC/SiC/FKM [W] or other material [X]
12. Shaft sealing version
13. Bearing support lubricated with grease [G] or oil [O]
XIP_M0003_A_sc
123456
8 9 10 11 12 13 14 157
XIP_M0004_A_sc
I X P 2 0 0 - 1 5 0 - 3 1 5 A 3 7 0 W 2 5 B D N 2 S 1 G
12
4 5
6 8
91 2 3 7
10
11 13

en – Original instructions
14 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
3.4 Part names
1. Volute casing
2. Bolt
3. Lifting lug
4. Shaft seal ring
5. Bearing support
6. Shaft seal ring
7. Shaft
8. Coupling key
9. Bearing cover
10. Support foot
11. Plug
12. Impeller
13. Wear ring
14. Impeller key
15. Impeller nut
16. Plug
17. O-ring
18. Plug
19. O-ring
20. Gasket; optional to 19
21. Casing cover
22. Mechanical seal
23. Shaft sleeve
24. Bearing cover
6
8
7
23
4
5
1
11
12
14
15
16
18
17
13
19 20 21
22 23
24
9
10
XIP_M0005_A_sc

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 15
4Installation
4.1 General precautions
Before starting, make sure that the safety instructions shown in Introduction and Safety on
page 5 have been fully read and understood.
WARNING:
All the hydraulic and electrical connections must be completed by a technician possessing the
technical
-professional requirements outlined in the current regulations.
WARNING:
Always wear personal protective equipment.
WARNING:
Always use suitable working tools.
4.2 Mechanical installation
4.2.1 Precautions
WARNING: Risk of injury due to improper floor installation
Install the unit on a
concrete or metal foundation base sufficiently strong to ensure permanent
and rigid support, suitable for the size and weight of the unit and as flat and even as possible.
4.2.2 Installation area
1. Follow the provisions in Operating environment on page 41.
2. Place the unit in a raised position in relation to the floor.
3. Check that the air clearance between the wall and the motor fan grid is:
•≥ 100 mm (4 in), to ensure suitable ventilation
•≥ 300 mm (12 in), to allow inspection and removal of the motor.
4. Make sure that any leaks will not cause flooding to the installation area or submerge the
unit.
5. Make sure that the unit is protected from sudden temperature changes.
Permitted positions
NOTE:
Only install the unit in the horizontal position, to allow self
-venting.
4.2.3 Installation on concrete foundation
Foundation requirements
•The concrete must have a compression resistance of C12/15 and meet the requirements of
exposure class XC1 according to EN 206-1
•Sizes must be appropriate for the sizes of the unit support plate
•The foundation weight must be ≥ 1.5 times the unit weight (≥ 5 times the weight of the unit
if a quieter operation is required)
•The surface should be as flat and level as possible.

en – Original instructions
16 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
Installation
The figure shows the position of the levelling shims depending on the distance of the tie rods.
1. Unit
2. Levelling thickness
3. Tie rod
1. Drill the tie rod holes in accordance with the quantity, diameter and centre distances shown
in the technical catalogue.
2. Insert the tie rods into the holes and secure them with chemical anchors.
3. Remove the caps of the suction and discharge ports.
4. Place the unit on the foundation by inserting the tie rods into the holes in the plate.
5. Level the unit with a spirit level on the shaft and discharge port: the maximum permitted
tolerance is 0.2 mm/m (0.0024 in/ft).
6. Align the suction and discharge ports to their piping.
7. If necessary, insert levelling shims between the plate and the foundation: If the distance
between the tie rods is ≥ 800 mm (31 in), insert additional shims in the middle of the plate.
8. Tighten the nuts on the tie rods evenly and fully.
Hexagon nut
Torque, Nm (lbf·in)
M12
60 (44)
M16
120 (89)
M20
200 (148)
M24
350 (258)
M27
530 (391)
DANGER: Explosion due to static charge
Make sure that the base plate is appropriately earthed.
Reducing vibrations
The motor and the flow of liquid in the piping can generate vibrations, which may be amplified
from the possible incorrect installation of the unit and the piping. See Hydraulic connection on
page 17.

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 17
4.2.4 Frame installation
•The frame must be rigid and must not vibrate during operation
•The contact surface of the pump and motor feet support bases must be as level as possible
•Position the pump and the motor at a distance that allows the coupling to be fitted
•Ensure a gap of 4-6 mm (0.16-0.24 in) between the frame and the motor to allow for vertical
adjustment in case of replacement.
•Make sure that pump and motor are securely attached to the frame.
4.3 Hydraulic connection
4.3.1 Precautions
WARNING:
The piping system must be sized to ensure safety at the maximum operating pressure and
temperature.
WARNING: Danger of hot and/or toxic liquid escaping from non-sealed piping system
connections
Support the piping system independently to prevent them from weighing on the unit. Secure
the piping system to the unit ports making sure to comply with the permitted forces and
torques. Install appropriate gaskets between the unit and the piping system.
WARNING: Hot surface hazard
If the temperature exceeds 60°C (140°F), isolate the unit before touching it.
NOTE:
When carrying out welding activities never use the unit for
grounding: risk of pitting damage
to the bearings.
NOTE:
Residues from welding work or other impurities in the pipes lead to pump damage. The type
and the duration of the cleaning activity during the flush and pickling operations must be in
accordance with the used casing and sealing materials. Use a filter with 0.5 mm (0.02 in) mesh
and 0.25 mm (0.01in) wire diameter made of corrosion
-resistant material. Insert a filter with a
section three times that of the pipeline.
4.3.2 Guidelines for the hydraulic system
1. Support the piping system independently to prevent them from weighing on the unit.
2. Remove any welding residues, deposits and impurities from the piping system in order to
avoid damage to the unit: the method and duration of the cleaning operation must be
adapted to the materials of the unit and the gaskets.
3. To reduce the transmission of vibrations between the unit and the system and vice versa,
install:
•anti-vibration joints on the suction and discharge sides of the unit
•dampers between the unit and the surface on which it is installed.
4. In order to reduce flow resistance, the pipe on the suction side must be:
•As short and as straight as possible
•For the section connected to the unit, straight and without bottlenecks, covering a
length equal to at least six times the diameter of the suction port
•Wider than the suction port; if necessary, install an eccentric reducer that is horizontal on
top
•Without bends; if this cannot be avoided, bends of a radius as wide as possible
•Without traps and goosenecks

en – Original instructions
18 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
•With valves with a low specific flow resistance.
5. Install a check valve on the discharge side to prevent the liquid from flowing back into the
pump unit when this is at standstill.
6. Install a diaphragm tank or flywheel to prevent water hammer.
7. Install a pressure gauge (or a vacuum pressure gauge, in case of suction lift installation) on
the suction side, and a pressure gauge on the discharge side, for checking the actual
operating pressure of the pump unit.
8. To exclude the unit from the system for the purpose of maintenance, install:
•An on-off valve on the suction side
•An on-off valve on the discharge side, downstream the check valve and pressure gauge,
also useful for regulating the flow rate.
9. In case of suction lift installation, the suction pipe must have an increasing slope towards
the unit exceeding 2%; to avoid air pockets.
4.3.3 Forces and torques that can be applied to the ports
The figure and the table show the maximum allowable forces and torques exerted by the
piping system on the ports of the unit, depending on the material, with temperature up to
180°C (356°F).
Material code NN (UU)
Model
Suction port
Discharge port
DN,
mm
Forces, N
Torques, Nm
DN,
mm
Forces, N
Torques, Nm
Fx
Fy
Fz
Σ F
Mx
My
Mz
Σ M
Fx
Fy
Fz
Σ F
Mx
My
Mz
Σ M
40-25-
40
438
385
350
680
455
315
368
664
25
263
245
298
466
315
210
245
451
50-32-
50
578
525
473
912
490
350
403
724
32
315
298
368
568
385
263
298
553
65-50-
65
735
648
595
1146
525
385
420
775
50
525
473
578
912
490
350
403
724
65-40-
65
735
648
595
1146
525
385
420
775
40
385
350
438
680
455
315
368
664
80-65-
80
875
788
718
1379
560
403
455
826
65
648
595
735
1146
525
385
420
775
100-65-
80
875
788
718
1379
560
403
455
826
50
525
473
578
912
490
350
403
724
100-80-
100
1173
1050
945
1836
613
438
508
908
80
788
718
875
1379
560
403
455
826
100-65-
100
1173
1050
945
1836
613
438
508
908
65
648
595
735
1146
525
385
420
775
125-80-
125
1383
1243
1120
2170
735
525
665
1122
80
788
718
875
1379
560
403
455
826
125-100-
125
1383
1243
1120
2170
735
525
665
1122
100
1050
945
1173
1836
613
438
508
908
150-125-
150
1750
1575
1418
2748
875
613
718
1287
125
1243
1120
1383
2170
735
525
665
1122
200-150-
200
2345
2100
1890
3672
1138
805
928
1674
150
1575
1418
1750
2748
875
613
718
1287
250-200-
250
3340
2980
2700
5227
1780
1260
1460
2624
200
2100
1890
2345
3672
1138
805
928
1674
300-250-
300
4000
3580
3220
6260
2420
1720
1980
3569
250
2980
2700
3340
5227
1780
1260
1460
2624
350-300-
350
4660
4180
3760
7302
3100
2200
2540
4572
300
3580
3220
4000
6260
2420
1720
1980
3569
400-400-
400
5320
4780
4300
8345
3880
2760
3180
5726
400
4780
4300
5320
8345
3880
2760
3180
5726
400-350-
400
5320
4780
4300
8345
3880
2760
3180
5726
350
4180
3760
4660
7302
3100
2200
2540
4572
500-500-
500
6640
5980
5380
10430
5780
4100
4720
8515
500
5980
5380
6640
10430
5780
4100
4720
8515
600-600-
600
7960
7184
6460
12518
8080
5760
6640
11940
600
7184
6460
7960
12518
8080
5760
6640
11940
XIP_M0007_A_sc
Fy
Fx
Mx
My
Mz
Fz
FxFy
Fz
Fz
FxFy

en – Original instructions
e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions 19
Material code DN, RN, RR (TT)
Model
Suction port
Discharge port
DN,
mm
Forces, N
Torques, Nm
DN,
mm
Forces, N
Torques, Nm
Fx
Fy
Fz
Σ F
Mx
My
Mz
Σ M
Fx
Fy
Fz
Σ F
Mx
My
Mz
Σ M
40-25-
40
875
770
700
1360
910
630
735
1329
25
525
490
595
933
630
420
490
902
50-32-
50
1155
1050
945
1825
980
700
805
1449
32
630
595
735
1136
770
525
595
1106
65-50-
65
1470
1295
1190
2292
1050
770
840
1550
50
1050
945
1155
1825
980
700
805
1449
65-40-
65
1470
1295
1190
2292
1050
770
840
1550
40
770
700
875
1360
910
630
735
1329
80-65-
80
1750
1575
1435
2757
1120
805
910
1652
65
1295
1190
1470
2292
1050
770
840
1550
100-65-
80
1750
1575
1435
2757
1120
805
910
1652
50
1050
945
1155
1825
980
700
805
1449
100-80-
100
2345
2100
1890
3672
1225
875
1015
1816
80
1575
1435
1750
2757
1120
805
910
1652
100-65-
100
2345
2100
1890
3672
1225
875
1015
1816
65
1295
1190
1470
2292
1050
770
840
1550
125-80-
125
2765
2485
2240
4340
1470
1050
1330
2243
80
1575
1435
1750
2757
1120
805
910
1652
125-100-
125
2765
2485
2240
4340
1470
1050
1330
2243
100
2100
1890
2345
3672
1225
875
1015
1816
150-125-
150
3500
3150
2835
5496
1750
1225
1435
2573
125
2485
2240
2765
4340
1470
1050
1330
2243
200-150-
200
4690
4200
3780
7343
2275
1610
1855
3348
150
3150
2835
3500
5496
1750
1225
1435
2573
250-200-
250
5845
5215
4725
9148
3115
2205
2555
4593
200
4200
3780
4690
7343
2275
1610
1855
3348
300-250-
300
7000
6265
5635
10955
4235
3010
3465
6245
250
5215
4725
5845
9148
3115
2205
2555
4593
350-300-
350
8155
7315
6580
12779
5425
3850
4445
8001
300
6265
5635
7000
10955
4235
3010
3465
6245
400-400-
400
9310
8365
7525
14604
6790
4830
5565
10020
400
8365
7525
9310
14604
6790
4830
5565
10020
400-350-
400
9310
8365
7525
14604
6790
4830
5565
10020
350
7315
6580
8155
12779
5425
3850
4445
8001
500-500-
500
11620
10465
9415
18253
10115
7175
8260
14900
500
10465
9415
11620
18253
10115
7175
8260
14900
600-600-
600
13930
12572
11305
21907
14140
10080
11620
20894
600
12572
11305
13930
21907
14140
10080
11620
20894
4.3.4 Auxiliary Connections
NOTE:
Unused or incorrectly used connections may cause malfunction and damage to the unit.
1. Suction port
2. Discharge port
3. Greasing unit M8 nipple
4. Greasing unit M8 nipple
5. G 1/2” drain
6. G 1/4" recirculation outlet (optional)
7. G 1/4” suction pressure port
8. G 1/4" discharge pressure port
9. G 1/2” drain
XIP_M0008_A_sc
8
6
1
4
3
5
2
9
7

en – Original instructions
20 e-IXP, e-IXPC, e-IXPF – Installation, Operation and Maintenance Instructions
4.4 Alignment of the motor-pump coupling
Check the alignment of the motor-pump coupling after the mechanical installation and
hydraulic connection of the unit.
DANGER: Burning
If the coupling is misaligned, it may overheat or overheat the bearings, resulting
in burns.
4.4.1 Disassembling the coupling guards
1. Top fastener
2. Top coupling protection
3. Bottom fastener
4. Side fasteners
5. Bottom coupling protection
6. Adjustment ring
1. Unscrew the side fasteners.
2. Unscrew the top fastener.
3. Remove the top protection.
4. Unscrew the bottom fastener.
5. Remove the bottom protection.
6. Open and lift the adjustment ring.
4.4.2 Checking the coupling alignment
Figure 1: Standard coupling
Figure 2: Coupling with spacer
1. Ruler
2. Thickness gauge
XIP_M0010_A_sc
5
26
1
43
XIP_M0013_A_sc
1
2
XIP_M0017_A_sc
12
