Xylem Rule A53S User manual

INSTALLATION AND OPERATION MANUAL
A53S, A53S-24, A53D
Submersible Utility Pump
The A53S and A53S-24 Automatic Sump and Utility
Pumps activate approximately every 2-1/2 minutes to
check for water. During this “check”, the pump runs for
about one second and checks for resistance or drag
against the impeller. If resistance (water) is found, it will
run for as long as water is present. When all the water is
pumped out, the pump shuts off and returns to its 2-1/2
minute test cycle.
When testing the pump, unplugging/plugging the
pump in will not reset the 2-1/2 minute cycle. The Non-
Automatic A53D Sump pump does not have this feature
and can be activated by plugging the pump into a GFCI
electrical 110VAC outlet.
Cautions and Warnings
WARNING: TO AVOID SERIOUS OR FATAL,
PERSONAL INJURY OR MAJOR PROPERTY
DAMAGE, READ AND FOLLOW ALL SAFETY
INSTRUCTIONS IN MANUAL AND ON PUMP. THIS
MANUAL MUST BE KEPT WITH THE PUMP. MAINTAIN
ALL SAFETY LABELS.
Disconnect electrical power before installing or servicing
the pump. The motor’s sensor or automatic thermal
overload protection may allow the pump to operate
expectantly.
This pump should not be used to drain a pool cover
or prevent water from accumulating on top of a pool
cover. Using this pump as a pool cover pump will void
the warranty.
CAUTION: Pump must always be properly attached
to the strainer before powering the unit to prevent
damage to the pump, the surrounding environment or
property and injury to persons.
CAUTION: This pump has been evaluated for
use with water only. Pump is not designed for use
in or on top of swimming pools, open bodies of water,
hazardous liquids, or where ammable gases exist.
This pump is designed for use with fresh and salt water
only. Use with any other medium, including particularly
hazardous, caustic or corrosive substances, could result in
damage to the pump, the surrounding environment and
injury to persons or property, including possible exposure
to hazardous substance.
WARNING: Do not plug the pump into an outlet
while standing in water or on a damp surface.
WARNING: To reduce the risk of injury, do not
permit children to use this product.
WARNING: To reduce the risk of electric shock,
do not use extension cord to connect unit to an
electric supply; provide a properly located outlet.
WARNING: This pump is provided with a 3-prong
grounding plug for use with a 110 volt AC 3-prong
outlet. To reduce the risk of electric shock, be certain
that it is connected only to a grounding type receptacle
protected by a ground-fault circuit interrupter (GFCI).
Contact a qualied electrician if you cannot verify that the
receptacle is protected by a GFCI.
WARNING: All electrical work must be performed
by a qualied technician. Follow all local and
electrical and safety codes NES and OSHA. Do not bury
cord. Visibly locate cord to minimize possible damage by
lawn mowers, hedge trimmers and other equipment.
WARNING: To reduce the risk of electric shock do
not use if cord or the product is damaged.
General Information
Sump pumps are designed to operate intermittently and
usually seasonally. It is recommended that you test the
pump before your rainy season begins to insure that the
pump is operating properly.
Restricting the ow by using a smaller pipe or hose size
(such as a garden hose) does not damage the pump, but
will result in a reduction in ow. For maximum ow, use
the shortest length of the largest diameter hose available.
If being used in a basement sump or basin, we suggest
installing a high water alarm system and a battery
back-up pump system for nished basements or areas
where ooding will cause property damage. Pump
manufacturer’s warranties cover only the pump. Labor
and incidental damage such as ooding is not covered.
For sump/utility use, attach the strainer to a wood base.
If mounting the pump onto concrete, rst fasten a piece
of wood to the concrete and then attach the strainer to
the wood. Use 1-1/8 “ I.D. hose, 1” pipe with the included
elbow pipe adapter, or use a standard garden hose with
included garden hose adapter. After connecting the
discharge hose to the pump it can be lowered into the
sump. Always lower the pump by holding the housing,
never by the power cord or hose.
All air/water pockets must be eliminated by having the
discharge hose, run level or continuously downwardly.
There must be no loops or “sags” in the hose that would
trap water.
IMPORTANT SAFETY INSTRUCTIONS

Discharge Height Above
Pumping Level 0 FEET 5 FEET 10 FEET
Gallons Per Hour 1800 1250 700
It is imperative that you keep the strainers clean and free
of debris. We recommend that you remove any debris
that may accumulate in and around the plastic strainer,
and around the internal stainless strainer (available in
some models) located under the plastic base strainer.
Should the impeller jam due to ice, no action is necessary.
The pump will resume its normal operation when the ice
thaws. The pump will continue to check for water every
few minutes while frozen and automatically shut itself
off after each check. To prevent unnecessary wear, it is
recommended, but not necessary, to disconnect the
pump if it is frozen in ice for an extended period of time.
Should the impeller jam due to debris, the debris should
be removed as soon as possible to allow the pump to
return to its normal automatic pumping mode.
Removing the Debris and Cleaning the Pump
1. Disconnect the power (unplug the power cord) before
cleaning the pump.
2. Remove the plastic strainer by pressing the two red
tabs on either side of the base and remove the red
base.
3. Remove any debris that has built up and clean with a
mild detergent.
4. Place the metal strainer (if equipped) over the inlet of
the pump and press the pump onto the strainer so that
both lock tabs “snap” into place.
Symptom
Possible
Cause Posssible Remedy
Pump only
runs for a
few seconds
Insufcient
water
The automatic control system tests
for water approximately every few
minutes. If the water level detected
is only about 3/4”, the pump will
shut off after a few seconds. Every
few minutes thereafter, it will
automatically check the water level
and will only continue pumping if
sufcient water is present.
Clogged
strainer or
jammed
impeller
Disconnect pump from power source
and remove strainer (some models
contain stainless steel inner strainers).
Remove debris from strainer(s) and
surrounding area. Remove any debris
from the impeller.
Blocked
discharge
line
Disconnect pump from power source
and remove blockage from pipes/
hoses and discharge port.
Pump does
not run
Poor
electrical
connections
Check electric receptacle for power.
Check fuse and/or circuit breaker.
Is the receptacle a three prong
grounded outlet in good condition?
Is the plug making good contact in
the receptacle?
Pump runs,
but does not
pump water
Air lock Check discharge hose. Is it running
level or continuously downwardly
once the hose starts downwardly? Are
there any loops in the hose?
M-785 / INSTRUCTION, A53S & A53D ENGLISH
M-729 / INSTRUCTION, A53S & A53D SPANISH
M-844 / INSTRUCTION, A53S & A53D FRENCH
www.rule-industries.com
USA
Xylem Inc.
100 Cummings Center
Suite 535-N,
Beverly, MA 01915
Tel: [phone]
Fax: [phone]
UK
Xylem Inc.
Bingley Road,
Hoddesdon
Hertfordshire EN11 0BU
Tel: [phone]
Fax: [phone]
GERMANY
Xylem Inc.
Oststrasse 28
22844
Norderstedt
Tel: [phone]
Fax: [phone]
PHILIPPINES
Xylem Inc.
12 Ring Road, LISP II
Brgy. Lamesa,
Calamba City 4027
Tel: [phone]
Fax: [phone]
CHINA
Xylem Inc.
18 Longyang Road
Luhe
(Nanjing) Jiangsu
211500
Tel: [phone]
ITALY
Xylem
Via Tommaseo, 6
20059
Vimercate, Milano
Tel: [phone]
Fax: [phone]
THE PRODUCT DESCRIBED HEREIN THE ORIGINAL INSTRUCTIONS IS SUBJECT TO THE XYLEM LIMITED WARRANTY
XYLEM LIMITED WARRANTY WARRANTS THIS PRODUCT TO BE FREE OF DEFECTS AND WORKMANSHIP FOR A PERIOD OF THREE (3) YEARS. THE
WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER EXPRESS OR IMPLIED WARRANTIES, GUARANTEES, CONDITIONS OR TERMS
OF WHATEVER NATURE RELATING TO THE GOODS PROVIDED HEREUNDER, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WHICH ARE HEREBY EXPRESSLY DISCLAIMED AND EXCLUDED. EXCEPT AS
OTHERWISE PROVIDED BY LAW, BUYER’S EXCLUSIVE REMEDY AND SELLER’S AGGREGATE LIABILITY FOR BREACH OF ANY OF THE FOREGOING
WARRANTIES ARE LIMITED TO REPAIRING OR REPLACING THE PRODUCT AND SHALL IN ALL CASES BE LIMITED TO THE AMOUNT PAID BY
THE BUYER HEREUNDER. IN NO EVENT IS SELLER LIABLE FOR ANY OTHER FORM OF DAMAGES, WHETHER DIRECT, INDIRECT, LIQUIDATED,
INCIDENTAL, CONSEQUENTIAL, PUNITIVE, EXEMPLARY OR SPECIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF PROFIT, LOSS OF
ANTICIPATED SAVINGS OR REVENUE, LOSS OF INCOME, LOSS OF BUSINESS, LOSS OF PRODUCTION, LOSS OF OPPORTUNITY OR LOSS OF
REPUTATION. THIS WARRANTY IS ONLY A REPRESENTATION OF THE COMPLETE LIMITED WARRANTY. FOR A DETAILED EXPLANATION, PLEASE
VISIT US AT www.xylemowcontrol.com/support/, CALL OUR OFFICE NUMBER LISTED, OR WRITE A LETTER TO YOUR REGIONAL OFFICE.
READ AND FOLLOW ALL
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
© 2016 Xylem Inc. All rights reserved.
Rule is a trademark of Xylem Inc. or one of its subsidiaries.
M-785 Rev. A 7/2016
