FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
FT DX 9000 S ERIES
CAT O PERATION
R EFERENCE B OOK

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
OVERVIEW
The CAT (Computer Aided Transceiver) System in the
FT DX 9000 series provides control of frequency, VFO,
memory, and other settings such as dual-channel memo-
ries and diversity reception using an external personal
computer. This allows multiple control operations to be
fully automated as single mouse clicks or keystroke op-
erations on the computer keyboard.
The FT DX 9000 series has a built-in level converter, al-
lowing direct connection from the rear-panel CAT jack to
the serial port of your computer without the need of any
external boxes. You will need a serial cable for connec-
tion to the RS-232C (serial or COM port) connector on
your computer. Purchase a standard serial cable (not the
so-called “null modem” type), ensuring it has the correct
gender and number of pins (some serial COM port con-
nectors use a 9-pin rather than 25-pin configuration). If
your computer uses a custom connector, you may have to
construct the cable. In this case, refer to the technical docu-
mentation supplied with your computer for correct data
connection.
Vertex Standard does not produce CAT System operating
software due to the wide variety of personal computers
and operating systems in use today. However, the infor-
mation provided in this chapter explains the serial data
structure and opcodes used by the CAT system. This in-
formation, along with the short programming examples,
is intended to help you start writing programs on your
own. As you become more familiar with CAT operation,
you can customize programs later on for your operating
needs and discover the true operating potential of this sys-
tem.
Page 1
CAT JACK
PIN NO.
c
d
e
f
g
h
i
j
k
PIN NAME
N/A
SERIAL OUT
SERIAL IN
N/A
GND
N/A
RTS
CTS
N/A
FUNCTION
---
Outputs the Serial Data from the
transceiver to the computer.
Inputs the Serial Data from the
computer to the transceiver.
---
Signal Ground
---
When the computer is not ready
to receive data, this port goes to
“L” for inhibit the transmit data
from the transceiver.
When the transceiver is not ready
to receive data, this port goes to
“L” for inhibit the transmit data
from the computer.
---
I/O
---
Output
Input
---
---
---
Input
Output
---
COM 1
CAT
RS-232C “Straght” Cable

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
CONTROL COMMAND
A computer control command is composed of an alpha-
betical command, various parameters, and the terminator
that signals the end of the control command.
Example: Set the main band (VFO-A) frequency to
14.250000 MHz.
FA 14250000 ;
KKK
Command Parameter Terminator
There is three for the FT DX 9000 Command as shown
below:
Set command: Set a particular condition
(to the FT DX 9000)
Read command: Reads an answer
(from the FT DX 9000)
Answer command: Transmits a condition
(from the FT DX 9000)
For example, note the following in the case of the FA com-
mand (Set the main band (VFO-A) frequency):
To set the main band (VFO-A) frequency to 14.250000
MHz, the following command is sent from the com-
puter to the transceiver:
“FA14250000;” (Set command)
To read the main band (VFO-A) frequency, the fol-
lowing command is sent from the computer to the trans-
ceiver:
“FA;” (Read command)
When the Read command above has been sent, the
following command is returned to the computer:
“FA14250000;” (Answer command)
Alphabetical Commands
A command consists of 2 alphabetical characters.
You may use either lower or upper case characters. The
commands available for this transceiver are listed in the
“PC Control Command Tables” on the following pages.
Page 2
Parameters
Parameters are used to specify information necessary to
implement the desired command.
The parameters to be used for each command are prede-
termined. The number of digits assigned to each param-
eter is also predetermined. Refer to the “Control Com-
mand List” and the “Control Command Tables” to con-
figure the appropriate parameters.
When configuring parameters, be careful not to make the
following mistakes.
For example, when correct parameter is “IS0+1000” (IF
SHIFT):
IS01000;
Not enough parameters specified (No direction (+)
given for the IF shift)
IS0+100;
Not enough digits (Only three frequency digits
given)
IS0_+_1000;
Unnecessary characters between parameters
IS0+10000;
Too many digits (Five frequency digits given)
Note: If a particular parameter is not applicable to the FT
DX 9000, the parameter digits should be filled using any
character except the ASCII control codes (00 to 1Fh) and
the terminator (;).
Terminator
To signal the end of a command, it is necessary to use a
semicolon (;). The digit where this special character must
appear differs depending on the command used.

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
VFO-A TO VFO-B
ANTENNA TUNER CONTROL
AF GAIN
AUTO INFORMATION
AF LIMITER
VFO-A TO MEMORY CHANNEL
ANTENNA NUMBER
VFO-B TO VFO-A
AUTO NOTCH
BAND DOWN
BREAK-IN
MANUAL NOTCH
BAND SELECT
BAND UP
BUSY
CLASS-A
CHANNEL UP/DOWN
ACM
CTCSS NUMBER
CONTOUR
CW SPOT
CTCSS
DIMMER
DOWN
DISPLAY
DIMMER SWITCH
ENCORDER DOWN
ENT KEY
ENCORDER UP
MENU
FREQUENCY VFO-A
FREQUENCY VFO-B
FUNCTION KEY
FUNCTION RX
FAST STEP
FUNCTION TX
AGC FUNCTION
IDENTIFICATION
INFORMATION
IF-SHIFT
KEY COMMAND
KEYER MEMORY
KEY PITCH
KEYER
KEY SPEED
CW KEYING
LOCK
LOAD MESSEGE
MEMORY CHANNEL TO VFO-A
MEMORY CHANNEL
MODE
MIC GAIN
AB
AC
AG
AI
AL
AM
AN
BA
BC
BD
BI
BP
BS
BU
BY
CA
CH
CM
CN
CO
CS
CT
DA
DN
DP
DS
ED
EK
EU
EX
FA
FB
FK
FR
FS
FT
GT
ID
IF
IS
KC
KM
KP
KR
KS
KY
LK
LM
MA
MC
MD
MG
C OMMAND FUNCTION SET READ AI
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
X
O
O
O
O
O
O
O
O
O
O
O
O
O
C OMMAND FUNCTION SET READ AI
X
O
O
O
O
X
O
X
O
X
O
O
X
X
O
O
X
O
O
O
O
O
O
X
O
O
X
X
X
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
X
O
O
X
O
O
O
X
O
O
O
O
X
O
X
O
X
O
O
X
X
O
O
X
O
O
O
O
O
O
X
O
O
X
X
X
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
X
O
O
X
O
O
O
X
O
X
O
X
O
O
O
O
O
X
O
O
X
O
O
O
X
X
X
X
O
X
X
O
O
O
O
O
X
O
O
X
O
O
O
O
O
O
X
O
O
O
X
O
O
O
X
O
O
O
X
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
X
X
X
O
X
X
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
X
O
O
O
X
O
O
O
X
O
O
O
O
O
X
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
O
X
O
X
O
O
O
O
O
O
X
O
O
O
O
X
O
O
O
O
O
O
O
O
MODE KEY
MONITOR LEVEL
MEMORY READ
METER SW
MEMORY WRITE
MOX SET
NARROW
NOISE BLANKER
NOISE BLANKER LEVEL
NOISE REDUCTION
OPPOSITE BAND INFORMATION
OFFSET (REPEATER SHIFT)
PRE-AMP (IPO)
PLAY BACK
POWER CONTROL
SPEECH PROCESSOR LEVEL
SPEECH PROCESSOR
POWER SWITH
QMB STORE
QMB RECALL
QUICK SPLIT
RF ATTENUATOR
CLAR CLEAR
CLAR DOWN
ROOFING FILTER
RF GAIN
RADIO INFORMATION
NOISE REDUCTION LEVEL
READ METER
ROTATOR
RADIO STATUS
CLAR
CLAR UP
SCAN
SEMI BREAK-IN DELAY TIME
SUB-DIAL FUNCTION
WIDTH
S METER
SQUELCH LEVEL
SWAP VFO
TXW
TX SET
UNLOCK
UP
VOX DELAY TIME
VRF FILTER
VOX GAIN
[V/M]KEY FUNCTION
VFO SELECT
VOX
TX CLAR
MK
ML
MR
MS
MW
MX
NA
NB
NL
NR
OI
OS
PA
PB
PC
PL
PR
PS
QI
QR
QS
RA
RC
RD
RF
RG
RI
RL
RM
RO
RS
RT
RU
SC
SD
SF
SH
SM
SQ
SV
TS
TX
UL
UP
VD
VF
VG
VM
VS
VX
XT
CONTROL COMMAND LIST
Page 3
ANS.
X
O
O
X
O
X
O
X
O
X
O
O
X
X
O
O
X
O
O
O
O
O
X
X
O
O
X
X
X
O
O
O
X
O
O
O
O
X
O
O
O
X
O
O
O
X
O
X
X
X
O
O
ANS.
X
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
X
X
X
O
X
X
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
X
O
O
O
X
O
O
O
X
O
O
O

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
ABAB
ABAB
AB VFO-A TO VFO-B
Set 12345678910
AB ;
Read 12345678910
Answer 12345678910
CONTROL COMMAND TABLES
AA
AA
AGG
GG
GAF GAIN
Set 12345678910
AGP1 P2 P2 P2 ;
Read 12345678910
AGP1 ;
Answer 12345678910
AGP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 000 - 255
AA
AA
ACC
CC
CANTENNA TUNER CONTROL
Set 12345678910
ACP1 P2 P3 ;
Read 12345678910
AC ;
Answer 12345678910
ACP1 P2 P3 ;
P1 0: Fixed P3 0: Tuner “OFF”
P2 0: Fixed 1: Tuner “ON”
2: Tuning Start
AIAI
AIAI
AI AUTO INFORMATION
Set 12345678910
AIP1 ;
Read 12345678910
AI ;
Answer 12345678910
AIP1 ;
P1 0: Auto Information “OFF”
1: Auto Information “ON”
This parameter is set to “0” (OFF) automatically when the transceiver is turned “OFF.”
AMAM
AMAM
AM VFO-A TO MEMORY CHANNEL
Set 12345678910
AM ;
Read 12345678910
Answer 12345678910
ALAL
ALAL
AL AF LIMITER
Set 12345678910
ALP1 P2 ;
Read 12345678910
ALP1 ;
Answer 12345678910
ALP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: AF Limiter “OFF”
1: AF Limiter “ON”
BB
BB
BAA
AA
AVFO-B TO VFO-A
Set 12345678910
BA ;
Read 12345678910
Answer 12345678910
Page 4
BCBC
BCBC
BC AUTO NOTCH
Set 12345678910
BCP1 P2 ;
Read 12345678910
BCP1 ;
Answer 12345678910
BCP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: Auto Notch “OFF”
1: Auto Notch “ON”
ANAN
ANAN
AN ANTENNA NUMBER
Set 12345678910
ANP1 P2 ;
Read 12345678910
ANP1 ;
Answer 12345678910
ANP1 P3 P4 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
1: ANT “1”
2: ANT “2”
3: ANT “3”
4: ANT “4”
5: ANT “RX”
P3P2 0: ANT “RX” “OFF”
1: ANT “RX” “ON”
1: ANT “1”
2: ANT “2”
3: ANT “3”
4: ANT “4”
P4

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
CONTROL COMMAND TABLES
BSBS
BSBS
BS BAND SELECT
Set 12345678910
BSP1 P1 ;
Read 12345678910
Answer 12345678910
P1 00: 1.8 MHz 06: 18 MHz
01: 3.5 MHz 07: 21 MHz
02: 5 MHz 08: 24.5 MHz
03: 7 MHz 09: 28 MHz
04: 10 MHz 10: 50 MHz
05: 14 MHz 11: GEN
BB
BB
BUU
UU
UBAND UP
Set 12345678910
BUP1 ;
Read 12345678910
Answer 12345678910
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
BYBY
BYBY
BY BUSY
Set 12345678910
Read 12345678910
BY ;
Answer 12345678910
BYP1 P2 ;
P1 0: Main (VFO-A) Band BUSY “OFF”
1: Main (VFO-A) Band BUSY “ON”
P2 0: Sub (VFO-B) Band BUSY “OFF”
1: Sub (VFO-B) Band BUSY “ON”
CHCH
CHCH
CH CHANNEL UP/DOWN
Set 12345678910
CHP1 ;
Read 12345678910
Answer 12345678910
P1 0: Memory Channel “UP”
1: Memory Channel “DOWN”
Page 5
BDBD
BDBD
BD BAND DOWN
Set 12345678910
BDP1 ;
Read 12345678910
Answer 12345678910
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
BIBI
BIBI
BI BREAK-IN
Set 12345678910
BIP1 ;
Read 12345678910
BI ;
Answer 12345678910
BIP1 ;
P1 0: Break-in “OFF”
1: Break-in “ON”
BPBP
BPBP
BP MANUAL NOTCH
Set 12345678910
BPP1 P2 P3 P3 P3 ;
Read 12345678910
BPP1 P2 ;
Answer 12345678910
BPP1 P2 P3 P3 P3 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: Manual NOTCH “ON/OFF”
1: Manual NOTCH LEVEL
P3 When P2=0
000: OFF
001: ON
When P2=1
001 - 400 (NOTCH Frequency: x 10 Hz )
CACA
CACA
CA CLASS-A
Set 12345678910
CAP1 P2 P2 P2 ;
Read 12345678910
CAP1 ;
Answer 12345678910
CAP1 P2 P2 P2 ;
P1 0: CLASS-A Operation “ON” and “OFF”
1: BIAS LEVEL
P2 When P1=0
000: CLASS-A Operation “OFF”
001: CLASS-A Operation “ON”
When P1=1
001 - 255
CMCM
CMCM
CM ACM
Set 12345678910
CMP1 ;
Read 12345678910
CM ;
Answer 12345678910
CMP1 ;
P1 0: ACM “OFF”
1: ACM “ON”

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
CONTROL COMMAND TABLES
CNCN
CNCN
CN CTCSS TONE FREQUENCY
Set 12345678910
CNP1 P2 P2 ;
Read 12345678910
CNP1 ;
Answer 12345678910
CNP1 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0 - 49: Tone Frequency Number (See “CTCSS Tone Chart” Below)
DD
DD
DAA
AA
ADIMMER
Set 12345678910
DAP1 P1 P2 P2 ;
Read 12345678910
DA ;
Answer 12345678910
DAP1 P1 P2 P2 ;
P1 00 - 15: VFD Backlight Brightness Level
P2 00 - 15: Meter (except VFD) Brightness Level
DNDN
DNDN
DN MIC DWN
Set 12345678910
DN ;
Read 12345678910
Answer 12345678910
CTCT
CTCT
CT CTCSS
Set 12345678910
CTP1 P2 ;
Read 12345678910
CTP1 ;
Answer 12345678910
CTP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: CTCSS “OFF”
1: CTCSS ENC/DEC “ON”
2: CTCSS ENC “ON”
DPDP
DPDP
DP DISPLAY
Set 12345678910
DPP1 ;
Read 12345678910
DP ;
Answer 12345678910
DPP1 ;
P1 0: World Clock Display
1: Band Scope Display
2: AF Oscilloscope/Spectrum Analyzer Display
3: Log Book Display
4: Temperature/SWR Display
5: Rotator Display
6: Memory Channel List Display
DSDS
DSDS
DS DIMMER SWITCH
Set 12345678910
DSP1 ;
Read 12345678910
DS ;
Answer 12345678910
DSP1 ;
P1 0: DIMMER “OFF”
1: DIMMER “ON”
Page 6
Ú: This command does not acti-
vates when the optional Data
Managemnt Unit is not attached.
CSCS
CSCS
CS CW SPOT
Set 12345678910
CSP1 ;
Read 12345678910
CS ;
Answer 12345678910
CSP1 ;
P1 0: OFF
1: ON
00
01
02
03
04
05
06
07
08
67.0 Hz
69.3 Hz
71.9 Hz
74.4 Hz
77.0 Hz
79.7 Hz
82.5 Hz
85.4 Hz
88.5 Hz
09
10
11
12
13
14
15
16
17
91.5 Hz
94.8 Hz
97.4 Hz
100.0 Hz
103.5 Hz
107.2 Hz
110.9 Hz
114.8 Hz
118.8 Hz
123.0 Hz
127.3 Hz
131.8 Hz
136.5 Hz
141.3 Hz
146.2 Hz
151.4 Hz
156.7 Hz
159.8 Hz
27
28
29
30
31
32
33
34
35
162.2 Hz
165.5 Hz
167.9 Hz
171.3 Hz
173.8 Hz
177.3 Hz
179.9 Hz
183.5 Hz
186.2 Hz
36
37
38
39
40
41
42
43
44
189.9 Hz
192.8 Hz
196.6 Hz
199.5 Hz
203.5 Hz
206.5 Hz
210.7 Hz
218.1 Hz
225.7 Hz
45
46
47
48
49
---
---
---
---
229.1 Hz
233.6 Hz
241.8 Hz
250.3 Hz
254.1 Hz
---
---
---
---
CTCSS TONE CHART
18
19
20
21
22
23
24
25
26
COCO
COCO
CO CONTOUR/APF
Set 12345678910
COP1 P2 P3 P3 ;
Read 12345678910
COP1 P2 ;
Answer 12345678910
COP1 P2 P3 P3 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: CONTOUR/APF “ON/OFF”
1: CONTOUR FREQUENCY
P3 When P2=0,
00: CONTOUR/APF “OFF”
01: CONTOUR “ON”
02: APF “ON”
When P2=1,
01 - 40 (CONTOUR Frequency)

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
EXEX
EXEX
EX MENU
Set 12345678nn
**
EXP1 P1 P1 P2 P2 ~ P2 ;
Read 12345678910
EXP1 P1 P1 ;
Answer 12345678nn
**
EXP1 P1 P1 P2 P2 ~ P2 ;
P1 : 001-176 (MENU Number)
P2 : Parameter
See Table 1, Table 2, and Table 3.
EDED
EDED
ED ENCORDER DOWN
Set 12345678910
EDP1 P2 P2 ;
Read 12345678910
Answer 12345678910
P1 0: MAIN ENCORDER
1: SUB ENCORDER
P2 01-99: Steps
EKEK
EKEK
EK ENT KEY
Set 12345678910
EK ;
Read 12345678910
Answer 12345678910
EUEU
EUEU
EU ENCORDER UP
Set 12345678910
EUP1 P2 P2 ;
Read 12345678910
Answer 12345678910
P1 0: MAIN ENCORDER
1: SUB ENCORDER
P2 01-99: Steps
CONTROL COMMAND TABLES
Page 7
P1 FUNCTION P2 BYTE
001 MAIN BAND AGC FAST DELAY 0020 ~ 4000 msec (20 msec/step) 4
002 MAIN BAND AGC FAST HOLD 0000 ~ 2000 msec (20 msec/step) 4
003 MAIN BAND AGC MID DELAY 0020 ~ 4000 msec (20 msec/step)4
004 MAIN BAND AGC MID HOLD 0000 ~ 2000 msec (20 msec/step)4
005 MAIN BAND AGC SLOW DELAY 0020 ~ 4000 msec (20 msec/step)4
006 MAIN BAND AGC SLOW HOLD 0000 ~ 2000 msec (20 msec/step)4
007 SUB BAND AGC FAST DELAY 0020 ~ 4000 msec (20 msec/step) 4
008 SUB BAND AGC FAST HOLD 0000 ~ 2000 msec (20 msec/step) 4
009 SUB BAND AGC MID DELAY 0020 ~ 4000 msec (20 msec/step)4
010 SUB BAND AGC MID HOLD 0000 ~ 2000 msec (20 msec/step)4
011 SUB BAND AGC SLOW DELAY 0020 ~ 4000 msec (20 msec/step)4
012 SUB BAND AGC SLOW HOLD 0000 ~ 2000 msec (20 msec/step)4
013 TFT COLOR 0: COOL BLUE 1: CONTRAST BLUE 2: FLASH BLUE 3: CONTRAST UMBER 4: UMBER 1
014 DIMMER-METER 00 ~ 15 2
015 DIMMER-VDF 00 ~ 15 2
016 BAR DISPLAY SELECT 0: CLARIFIER OFFSET 1: CW TUNING 2: VRF/μTUNE PEAK POSITION 3: NOTCH 1
017 ROTATOR START UP 0: 0° 1: 90° 2: 180° 3: 270° 1
018 ROTATOR OFFSET ADJ 00 ~ 30 (00 ~ –30°, 2° step) 2
019 RIGHT TX METER 0: ALC 1: VDD 1
020 QMB MAKER 0: OFF 1: ON 1
021 MY SCREEN 0: OFF 1: ON (See Below) 7
022 LEVEL INDICATOR 0: OFF 1: ON (See Below) 7
023 BEACON TIME 000 (OFF) ~ 255 sec 3
024 NUMBER STYLE 0: 1290 1: AunO 2: Aunt 3: A2nO 4: A2nt 5: 12nO 6: 12nt 1
025 CONTEST NUMBER 0000 ~ 9999 4
026 CW MEMORY “1” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY 1
027 CW MEMORY “2” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY 1
028 CW MEMORY “3” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY 1
029 CW MEMORY “4” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY 1
030 CW MEMORY “5” MEMORY TYPE 0: TEXT MEMORY 1: MESSAGE MEMORY 1
031 ANTENNA SELECTION MODE 0: BAND 1: STACK 1
032 BEEP LEVEL 000 ~ 255 3
033 CAT BAUD RATE 0: 4800 bps 1: 9600 bps 2: 19200 bps 3: 38400 bps 1
034 CAT TIME-OUT TIMER 0: 10 msec 1: 100 msec 2: 1000 msec 3: 3000 msec 1
035 CAT RTS PORT 0: OFF 1: ON 1
036 CAT DATA INDICATOR 0: OFF 1: ON 1
037 MEMORY GROUP 0: OFF 1: ON 1
038 QUICK SPLIT TUNING OFFSET –20 ~ +00 (or –00)~ +20 kHz 3
039 VFO TRACK 0: OFF 1: BAND 2: FREQUENCY 1
TABLE 1
X X X X X X X
MCH LIST
ROTATOR
SWR
LOGBOOK
AF SCOPE
RF SCOPE
MAP
Menu Item 021 MY SCREEN
Command P2 7-Byte Details
1 Byte - - - - - 7-Byte
ÈÈ
X X X X X X X
VOX DELAY
CW DELAY
DNR FREQUENCY
NOTCH FREQUENCY
CONTOUR FREQUENCY
CW SPEED
CW PITCH
Menu Item 022 LEVEL INDICATOR
Command P2 7-Byte Details
1 Byte - - - - - 7-Byte
ÈÈ

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
Page 8
CONTROL COMMAND TABLES
TABLE 2
P1 FUNCTION P2 BYTE
040 TX TIME OUT TIMER 0: OFF 1: 5 min 2: 10 min 3: 15 min 4: 20 min 5: 25 min 6: 30 min 1
041 TRANSVERTER FREQUENCY DISPLAY 30 ~ 49 MHz 2
042 μ-TUNE DIAL STEP 0: STEP-2 1: STEP-1 2: OFF 1
043 MIC SCAN 0: OFF 1: ON 1
044 SCAN RESUME 0: PAUSE 1: TIME 1
045 AF/RF DIAL SWAP 0: NORMAL 1: SWAP 1
046 AM MIC GAIN 1000: MIC KNOB 0000 ~ 0255 (FIX) 4
047 AM MIC SELECT 0: FRONT JACK 1: DATA JACK 2: PC JACK 3: REAR 1
048 FRONT PANEL KEY JACK TYPE 0: OFF 1: BUG 2: IAMBIC KEYER W/O ACS 3: IAMBIC KEYER W/ACS 1
049 FRONT PANEL KEY JACK WIRING 0: NORNAL 1: REVERSE 1
050 REAR PANEL KEY JACK TYPE 0: OFF 1: BUG 2: IAMBIC KEYER W/O ACS 3: IAMBIC KEYER W/ACS 1
051 REAR PANEL KEY JACK WIRING 0: NORNAL 1: REVERSE 1
052 CW AUTO MODE 0: OFF 1: 50 MHz ONLY 2: ON 1
053 CW BFO INJECTION SIDE 0: USB 1: LSB 2: AUTO 1
054 CW BREAK-IN MODE 0: SEMI BREAK-IN 1: FULL BREAK-IN 1
055 CW CARRIER WAVE FORM SHAPE 0: 1 msec 1: 2 msec 2: 4 msec 3: 6 msec 1
056 CW WEIGHT 25 (1:2.5)~ 45 (1:4.5)2
057 CW FREQUENCY DISPLAY 0: DIRECT FREQUENCY 1: PITCH OFFSET 1
058 CW PC KEYING 0: OFF 1: ON 1
059 CW QSK TIME 0: 15 msec 1: 20 msec 2: 25 mesc 3: 30 msec 1
060 DATA INPUT PORT 0: DATA JACK 1: PC JACK 1
061 DATA INPUT LEVEL 000 ~ 255 3
062 DATA OUTPUT BAND 0: MAIN (VFO-A)BAND 1: SUB (VFO-B)BAND 1
063 DATA VOX DELAY TIME 0030 ~ 3000 msec 4
064 DATA VOX GAIN 000 ~ 255 3
065 FM MIC GAIN 1000: MIC KNOB 0000 ~ 0255 (FIX) 4
066 FM MIC SELECT 0: FRONT JACK 1: DATA JACK 2: PC JACK 3: REAR 1
067 28 MHz REPEATER SHIFT 0000 ~ 1000 kHz (10 Hz/step) 4
068 50 MHz REPEATER SHIFT 0000 ~ 4000 kHz (10 Hz/step) 4
069 SSB PACKET MODE DISPLAY FREQUENCY –3000 ~ +0000 (or –0000)~ +3000 kHz (10 Hz/step)5
070 SSB PACKET GAIN 000 ~ 255 3
071 SSB PACKET MODE SHIFT FREQUENCY –3000 ~ +0000 (or –0000)~ +3000 kHz (10 Hz/step)5
072 RTTY MODE RX POLARITY (MARK/SPACE)0: NORNAL 1: REVERSE 1
073 RTTY MODE TX POLARITY (MARK/SPACE)00.: NORNAL 1: REVERSE 1
074 RTTY MODE SHIFT FREQUENCY 1: 170 Hz 1: 200 Hz 2: 425 Hz 3: 850 Hz 1
075 RTTY MODE MARK FREQUENCY 1: 1275 Hz 2: 2125 Hz 1
076 SSB MIC SELECT 0: FRONT JACK 1: DATA JACK 2: PC JACK 3: REAR 1
077 SSB MODE TX BPF BANDWIDTH 0: 50 - 3000 Hz 1: 100 - 2900 Hz 2: 200 - 2800 Hz 1
3: 300 - 2700 Hz 4: 400 - 2600 Hz 5: 3000WB
078 LSB RX CARRIER POINT –200 ~ +000 (or –000)~ +200 Hz (10 Hz/step) 4
079 LSB TX CARRIER POINT –200 ~ +000 (or –000)~ +200 Hz (10 Hz/step) 4
080 USB RX CARRIER POINT –200 ~ +000 (or –000)~ +200 Hz (10 Hz/step) 4
081 USB TX CARRIER POINT –200 ~ +000 (or –000)~ +200 Hz (10 Hz/step) 4
082 AGC GAIN CURVE 0: NORMAL 1: SLOPED 1
083 HEADPHONE MIX 0: SEPARATE 1: COMBINE-1 2: COMBINE-2 1
084 SPEAKER MIX 0: SEPARATE 1: COMBINE 1
085 MAIN BAND CONTOUR LEVEL –40 ~ +00 (or –00)~ +20 dB 3
086 MAIN BAND CONTOUR WIDTH 01 ~ 11 2
087 SUB BAND CONTOUR LEVEL –40 ~ +00 (or –00)~ +20 dB 3
088 SUB BAND CONTOUR WIDTH 01 ~ 11 2
089 IF NOTCH WIDTH 0: NARROW 1: WIDE 1
090 MAIN BAND CW FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP 1
091 MAIN BAND CW FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE 1
092 MAIN BAND CW FILTER BANDWIDTH 00: 25 Hz 01: 50 Hz 02: 100 Hz 03: 200 Hz 04: 300 Hz 05: 400 Hz 2
093 MAIN BAND PACKT FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP 1
094 MAIN BAND PACKT FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE 1
095 MAIN BAND PACKT FILTER BANDWIDTH 00: 25 Hz 01: 50 Hz 02: 100 Hz 03: 200 Hz 04: 300 Hz 05: 400 Hz 2
096 MAIN BAND RTTY FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP 1
097 MAIN BAND RTTY FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE 1
098 MAIN BAND RTTY FILTER BANDWIDTH 0: 25 Hz 1: 50 Hz 2: 100 Hz 3: 200 Hz 4: 300 Hz 5: 400 Hz 2
099 MAIN BAND SSB FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP 1
100 MAIN BAND SSB FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE 1
101 MAIN BAND SSB NARROW FILTER BANDWIDTH 00: 200 Hz 01: 400 Hz 02: 600 Hz 03: 850 Hz 04: 1100 Hz 05: 1350 Hz 2
06: 1500 Hz 07: 1650 Hz 08: 1800 Hz 09: 1950 Hz 10: 2100 Hz 11: 2250 Hz
102 SUB BAND CW FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP 1
103 SUB BAND CW FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE 1
104 SUB BAND CW FILTER BANDWIDTH 00: 25 Hz 01: 50 Hz 02: 100 Hz 03: 200 Hz 04: 300 Hz 05: 400 Hz 2
105 SUB BAND PACKT FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP 1
106 SUB BAND PACKT FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE 1
107 SUB BAND PACKT FILTER BANDWIDTH 00: 25 Hz 01: 50 Hz 02: 100 Hz 03: 200 Hz 04: 300 Hz 05: 400 Hz 2
108 SUB BAND RTTY FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP 1
109 SUB BAND RTTY FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE 1
110 SUB BAND RTTY FILTER BANDWIDTH 00: 25 Hz 01: 50 Hz 02: 100 Hz 03: 200 Hz 04: 300 Hz 05: 400 Hz 2
111 SUB BAND SSB FILTER PASSBAND CHARACTER 0: SOFT 1: SHARP 1
112 SUB BAND SSB FILTER SHAPE FACTOR 0: STEEP 1: MEDIUM 2: GENTLE 1
113 SUB BAND SSB NARROW FILTER BANDWIDTH 00: 200 Hz 01: 400 Hz 02: 600 Hz 03: 850 Hz 04: 1100 Hz 05: 1350 Hz 2
06: 1500 Hz 07: 1650 Hz 08: 1800 Hz 09: 1950 Hz 10: 2100 Hz 11: 2250 Hz
114 MAIN BAND SPECTRUM SCOPE SCAN START FREQ (1.8 MHz) 01800 ~ 01999 (1.800 MHz ~ 1.999 MHz) 5
115 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (3.5 MHz) 03500 ~ 03999 (3.500 MHz ~ 3.999 MHz) 5
116 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (5.0 MHz) 05250 ~ 05499 (5.250 MHz ~ 5.499 MHz) 5
117 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (7.0 MHz) 07000 ~ 07299 (7.000 MHz ~ 7.299 MHz) 5
118 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (10 MHz) 10100 ~ 10149 (10.100 MHz ~ 10.149 MHz) 5
119 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (14 MHz) 14000 ~ 14349 (14.000 MHz ~ 14.349 MHz) 5
120 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (18 MHz) 18000 ~ 18199 (18.000 MHz ~ 18.199 MHz) 5
121 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (21 MHz) 21000 ~ 21449 (21.000 MHz ~ 21.449 MHz) 5
122 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (24.5 MHz) 24800 ~ 24989 (24.800 MHz ~ 24.989 MHz) 5
123 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (28 MHz) 28000 ~ 29699 (28.000 MHz ~ 29.699 MHz) 5
124 MAIN BAND SPECTRUM SCOPE SCAN START FREQ. (50 MHz) 50000 ~ 53999 (50.000 MHz ~ 53.999 MHz) 5
125 SUB BAND SPECTRUM SCOPE SCAN START FREQ (1.8 MHz) 01800 ~ 01999 (1.800 MHz ~ 1.999 MHz) 5

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
P1 FUNCTION P2 BYTE
126 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (3.5 MHz) 03500 ~ 03999 (3.500 MHz ~ 3.999 MHz) 5
127 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (5.0 MHz) 05250 ~ 05499 (5.250 MHz ~ 5.499 MHz) 5
128 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (7.0 MHz) 07000 ~ 07299 (7.000 MHz ~ 7.299 MHz) 5
129 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (10 MHz) 10100 ~ 10149 (10.100 MHz ~ 10.149 MHz) 5
130 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (14 MHz) 14000 ~ 14349 (14.000 MHz ~ 14.349 MHz) 5
131 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (18 MHz) 18000 ~ 18199 (18.000 MHz ~ 18.199 MHz) 5
132 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (21 MHz) 21000 ~ 21449 (21.000 MHz ~ 21.449 MHz) 5
133 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (24.5 MHz) 24800 ~ 24989 (24.800 MHz ~ 24.989 MHz) 5
134 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (28 MHz) 28000 ~ 29699 (28.000 MHz ~ 29.699 MHz) 5
135 SUB BAND SPECTRUM SCOPE SCAN START FREQ. (50 MHz) 50000 ~ 53999 (50.000 MHz ~ 53.999 MHz) 5
136 DIAL STEP 0: 1 Hz 1: 5 Hz 2: 10 Hz 1
137 CW FINE TUNING 0: OFF 1: ON 1
138 SUB VFO-B KNOB MHz STEP 0: 1 MHz 1: 100 kHz 1
139 AM CH STEP 0: 2.5 kHz 1: 5 kHz 2: 9 kHz 3: 10 kHz 4:12.5 kHz 1
140 FM CH STEP 0: 5 kHz 1: 6.25 kHz 2: 10 kHz 3: 12.5 kHz 4: 25 kHz 1
141 FM DIALSTEP 0: 10 Hz 1: 100 Hz 1
142 MY BAND SELECT 0: OFF 1: ON (See Below) 13
143 FRONT MIC EQUAQLIZER CENTER FREQUENCY (LOW RANGE) 00: OFF 01: 100 Hz 02: 200 Hz 03: 300 Hz 04: 400 Hz 2
05: 500 Hz 06: 600 Hz 07: 700 Hz
144 FRONT MIC EQUAQLIZER GAIN (LOW RANGE)
–10 ~ +00 (or –00)~ +10 3
145 FRONT MIC EQUAQLIZER BANDWIDTH (LOW RANGE) 01 ~ 10 2
146 FRONT MIC EQUAQLIZER CENTER FREQUENCY (MID RANGE) 00: OFF 01: 700 Hz 02: 800 Hz 03: 900 Hz 04: 1000 Hz 2
05: 1100 Hz 06: 1200 Hz 07: 1300 Hz 08: 1400 Hz 09: 1500 Hz
147 FRONT MIC EQUAQLIZER GAIN (MID RANGE)
–10 ~ +00 (or –00)~ +10 3
148 FRONT MIC EQUAQLIZER BANDWIDTH (MID RANGE) 01 ~ 10 2
149 FRONT MIC EQUAQLIZER CENTER FREQUENCY (HIGH RANGE) 00: OFF 01: 1500 Hz 02: 1600 Hz 03: 1700 Hz 04: 18000 Hz 05: 1900 Hz 2
06: 2000 Hz 07: 2100 Hz 08: 2200 Hz 09: 2300 Hz 10: 2400 Hz 11: 2500 Hz
12: 2600 Hz 13: 2700 Hz 14: 2800 Hz 15: 2900 Hz 16: 3000 Hz 17: 3100 Hz
18: 3200 Hz
150 FRONT MIC EQUAQLIZER GAIN (HIGH RANGE)
–10 ~ +00 (or –00)~ +10 3
151 FRONT MIC EQUAQLIZER BANDWIDTH (HIGH RANGE) 01 ~ 10 2
152 REAR MIC EQUAQLIZER CENTER FREQUENCY (LOW RANGE) 00: OFF 01: 100 Hz 02: 200 Hz 03: 300 Hz 04: 400 Hz 2
05: 500 Hz 06: 600 Hz 07: 700 Hz
153 REAR MIC EQUAQLIZER GAIN (LOW RANGE)
–10 ~ +00 (or –00)~ +10 3
154 REAR MIC EQUAQLIZER BANDWIDTH (LOW RANGE) 01 ~ 10 2
155 REAR MIC EQUAQLIZER CENTER FREQUENCY (MID RANGE) 00: OFF 01: 700 Hz 02: 800 Hz 03: 900 Hz 04: 1000 Hz 2
05: 1100 Hz 06: 1200 Hz 07: 1300 Hz 08: 1400 Hz 09: 1500 Hz
156 REAR MIC EQUAQLIZER GAIN (MID RANGE)
–10 ~ +00 (or –00)~ +10 3
157 REAR MIC EQUAQLIZER BANDWIDTH (MID RANGE) 01 ~ 10 2
158 REAR MIC EQUAQLIZER CENTER FREQUENCY (HIGH RANGE) 00: OFF 01: 1500 Hz 02: 1600 Hz 03: 1700 Hz 04: 18000 Hz 05: 1900 Hz 2
06: 2000 Hz 07: 2100 Hz 08: 2200 Hz 09: 2300 Hz 10: 2400 Hz 11: 2500 Hz
12: 2600 Hz 13: 2700 Hz 14: 2800 Hz 15: 2900 Hz 16: 3000 Hz 17: 3100 Hz
18: 3200 Hz
159 REAR MIC EQUAQLIZER GAIN (HIGH RANGE)
–10 ~ +00 (or –00)~ +10 3
160 REAR MIC EQUAQLIZER BANDWIDTH (HIGH RANGE) 01 ~ 10 2
161 SPEECH PROCESSOR EQUAQLIZER CENTER FREQUENCY 00: OFF 01: 100 Hz 02: 200 Hz 03: 300 Hz 04: 400 Hz 2
(LOW RANGE)05: 500 Hz 06: 600 Hz 07: 700 Hz
162 SPEECH PROCESSOR EQUAQLIZER GAIN (LOW RANGE)– 10 ~ +00 (or –00)~ +10 3
163 SPEECH PROCESSOR EQUAQLIZER BANDWIDTH 01 ~ 10 2
(LOW RANGE)
164 SPEECH PROCESSOR EQUAQLIZER CENTER FREQUENCY 00: OFF 01: 700 Hz 02: 800 Hz 03: 900 Hz 04: 1000 Hz 2
(MID RANGE)05: 1100 Hz 06: 1200 Hz 07: 1300 Hz 08: 1400 Hz 09: 1500 Hz
165 SPEECH PROCESSOR EQUAQLIZER GAIN (MID RANGE)– 10 ~ +00 (or –00)~ +10 3
166 SPEECH PROCESSOR EQUAQLIZER BANDWIDTH 01 ~ 10 2
(MID RANGE)
167 SPEECH PROCESSOR EQUAQLIZER CENTER FREQUENCY 00: OFF 01: 1500 Hz 02: 1600 Hz 03: 1700 Hz 04: 18000 Hz 05: 1900 Hz 2
(HIGH RANGE)06: 2000 Hz 07: 2100 Hz 08: 2200 Hz 09: 2300 Hz 10: 2400 Hz 11: 2500 Hz
12: 2600 Hz 13: 2700 Hz 14: 2800 Hz 15: 2900 Hz 16: 3000 Hz 17: 3100 Hz
18: 3200 Hz
168 SPEECH PROCESSOR EQUAQLIZER GAIN (HIGH RANGE)– 10 ~ +00 (or –00)~ +10 3
169 SPEECH PROCESSOR EQUAQLIZER BANDWIDTH 01 ~ 10 2
(HIGH RANGE)
170 MAXIMUM OUTPUT POWER LIMIT FT DX 9000D/Contest 0: 10 W 1: 50 W 2: 100 W 3: 200 W 1
FT DX 9000MP 0: 50 W 1: 100 W 2: 200 W 3: 400 W
171 RF PWR KNOB FUNCTION 0: ALL MODE 1: CARRIER 1
172 TX-GND JACK 0: DISABLE 1: ENABLE 1
173 TUNER DRIVEING POWER FT DX 9000D/Contest 0: 10 W 1: 50 W 2: 100 W 3: 200 W 1
FT DX 9000MP 0: 50 W 1: 100 W 2: 200 W 3: 400 W
174 FULL DUPLEX OPERATION 0: SIMPLEX 1: DUPLEX 1
175 VOX OPERATION 0: MIC INPUT 1: DATA INPUT 1
176 EMERGENCY CHANNEL 0: DISABLE 1: ENABLE 1
CONTROL COMMAND TABLES
TABLE 3
Page 9
X X X X X X X X X X X X X
TRANSVERTER
GENERAL
50 MHz
28 MHz
24.5 MHz
21 MHz
18 MHz
14 MHz
10 MHz
7 MHz
5 MHz
3.5 MHz
1.8 MHz
Menu Item 142 MY BAND SELECT
Command P2 13-Byte Details
1 Byte - - - - - - - - - - - - - 13-Byte
ÈÈ

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
FTFT
FTFT
FT FUNCTION TX
Set 12345678910
FTP1 ;
Read 12345678910
FT ;
Answer 12345678910
FTP2 ;
P1 0: TX Band = Main (VFO-A) Band QSub (VFO-B) Band (Toggle)
1: TX Band = Sub (VFO-B) Band QMain (VFO-A) Band (Toggle)
2: TX Band = Main (VFO-A) Band
3: TX Band = Sub (VFO-B) Band
P2 0: TX Band = Main (VFO-A) Band
1: TX Band = Sub (VFO-B) Band
GTGT
GTGT
GT AGC FUNCTION
Set 12345678910
GTP1 P2 ;
Read 12345678910
GTP1 ;
Answer 12345678910
GTP1 P3 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
P2 0: AGC “OFF”
1: AGC “FAST”
2: AGC “MID”
3: AGC “SLOW”
4: AGC “AUTO”
P3 0: AGC “OFF”
1: AGC “FAST”
2: AGC “MID”
3: AGC “SLOW”
4: AGC “AUTO-FAST”
5: AGC “AUTO-MID”
6: AGC “AUTO-SLOW”
FSFS
FSFS
FS FAST STEP
Set 12345678910
FSP1 ;
Read 12345678910
FS ;
Answer 12345678910
FSP1 ;
P1 0: FAST Key “OFF”
1: FAST Key “ON”
IDID
IDID
ID IDENTIFICATION
Set 12345678910
Read 12345678910
ID;
Answer 12345678910
IDP1 P1 P1 P1 ;
P1 0101: FTDX9000D
0102: FTDX9000Contest
0103: FTDX9000MP
CONTROL COMMAND TABLES
FF
FF
FAA
AA
AFREQUENCY VFO-A
Set 12345678910
FAP1 P1 P1 P1 P1 P1 P1 P1
11 12 13 14 15 16 17 18 19 20
;
Read 12345678910
FA ;
Answer 12345678910
FAP1 P1 P1 P1 P1 P1 P1 P1
11 12 13 14 15 16 17 18 19 20
;
P1 00300000 - 60000000 (Hz)
FBFB
FBFB
FB FREQUENCY VFO-B
Set 12345678910
FBP1 P1 P1 P1 P1 P1 P1 P1
11 12 13 14 15 16 17 18 19 20
;
Read 12345678910
FB ;
Answer 12345678910
FBP1 P1 P1 P1 P1 P1 P1 P1
11 12 13 14 15 16 17 18 19 20
;
P1 00300000 - 60000000 (Hz)
FKFK
FKFK
FK FUNCTION KEY
Set 12345678910
FKP1 ;
Read 12345678910
Answer 12345678910
P1 1: F1
2: F2
3: F3
4: F4
5: F5
6: F6
7: F7
FRFR
FRFR
FR FUNCTION RX
Set 12345678910
FRP1 ;
Read 12345678910
FR ;
Answer 12345678910
FRP1 ;
P1 0: Main (VFO-A) Band Receiver: RX, Sub (VFO-B) Band Receiver: “OFF”
1: Main (VFO-A) Band Receiver: Mute, Sub (VFO-B) Band Receiver: “OFF”
2: Main (VFO-A) Band Receiver: RX, Sub (VFO-B) Band Receiver: RX
3: Main (VFO-A) Band Receiver: Mute, Sub (VFO-B) Band Receiver: RX
Page 10

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
KSKS
KSKS
KS KEY SPEED
Set 12345678910
KSP1 P1 P1 ;
Read 12345678910
KS ;
Answer 12345678910
KSP1 P1 P1 ;
P1 004 - 060 (WPM)
KYKY
KYKY
KY CW KEYING
Set 12345678910
KYP1 ;
Read 12345678910
Answer 12345678910
P1 1: Keyer Memory “1” Playback 6: Message Keyer “1” Playback
2: Keyer Memory “2” Playback 7: Message Keyer “2” Playback
3: Keyer Memory “3” Playback 8: Message Keyer “3” Playback
4: Keyer Memory “4” Playback 9: Message Keyer “4” Playback
5: Keyer Memory “5” Playback A: Message Keyer “5” Playback
KRKR
KRKR
KR KEYER
Set 12345678910
KRP1 ;
Read 12345678910
KR ;
Answer 12345678910
KRP1 ;
P1 0: KEYER “OFF”
1: KEYER “ON”
Page 11
KMKM
KMKM
KM KEYER MEMORY
Set 1234567~53
**
KMP1 P2 P2 P2 P2 ~ P2 ;
Read 12345678910
KMP1 ;
Answer 1234567~53
**
KMP1 P2 P2 P2 P2 ~ P2 ;
P1 1 - 5 : Keyer Memory Channel Number
P2 Message Characters (up to 50 characters)
IFIF
IFIF
IF INFORMATION
Set 12345678910
Read 12345678910
IF;
Answer 12345678910
IFP1 P1 P1 P2 P2 P2 P2 P2
11 12 13 14 15 16 17 18 19 20
P2 P2 P2 P3 P3 P3 P3 P3 P4 P5
21 22 23 24 25 26 27 28 29 30
P6 P7 P8 P9 P9 P10 ;
P1 000-117 (Memory Channel) P2 VFO-A Frequency (Hz)
P3 Clarifier Direction +: Plus Shift, --: Minus Shift
Clarifier Offset: 0000 - 9999 (Hz)
P4 0: RX CLAR “OFF” 1: RX CLAR “ON”
P5 0: TX CLAR “OFF” 1: TX CLAR “ON”
P6 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
P7 0: VFO 1: Memory 2: Memory Tune 3: Quick Memory Bank (QMB) 4: QMB-MT
P8 0: CTCSS “OFF” 1: CTCSS ENC/DEC 2: CTCSS ENC
P9: Tone Number (See page 6: “CTCSS Tone Chart”)
P10 0: Simplex 1: Plus Shift 2: Minus Shift
CONTROL COMMAND TABLES
ISIS
ISIS
IS IF-SHIFT
Set 12345678910
ISP1 -/+ P2 P2 P2 P2 ;
Read 12345678910
ISP1 ;
Answer 12345678910
ISP1 -/+ P2 P2 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 -- 1000 ~ +1000 Hz
KPKP
KPKP
KP KEY PITCH
Set 12345678910
KPP1 P1 ;
Read 12345678910
KP ;
Answer 12345678910
KPP1 P1 ;
P1 00: 300 Hz
01: 350 Hz
02: 400 Hz
03: 450 Hz
04: 500 Hz
05: 550 Hz
06: 600 Hz
07: 650 Hz
08: 700 Hz
09: 750 Hz
10: 800 Hz
11: 850 Hz
12: 900 Hz
13: 950 Hz
14: 1000 Hz
15: 1050 Hz
KK
KK
KCC
CC
CKEY COMMAND
Set 12345678910
KCP1 P1 P2 ;
Read 12345678910
KCP1 P1 ;
Answer 12345678910
KCP1 P1 P3 ;
P1 00: B-DISP “OFF”
01: VDD (Contest/MP only)
01: BIAS (Contest/MP only)
01: TEMP (Contest/MP only)
01: SWR (Contest/MP only)
P2 0 (Fixed)
P3 0: OFF
1: ON

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
MGMG
MGMG
MG MIC GAIN
Set 12345678910
MGP1 P1 P1 ;
Read 12345678910
MG ;
Answer 12345678910
MGP1 P1 P1 ;
P1 000 - 255
CONTROL COMMAND TABLES
MDMD
MDMD
MD OPERATING MODE
Set 12345678910
MDP1 P2 ;
Read 12345678910
MDP1 ;
Answer 12345678910
MDP1 P2 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
P2 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
MAMA
MAMA
MA MEMORY CHANNEL TO VFO-A
Set 12345678910
MA ;
Read 12345678910
Answer 12345678910
Page 12
LMLM
LMLM
LM LOAD MESSEGE
Set 12345678910
LMP1 P2 ;
Read 12345678910
LMP1 ;
Answer 12345678910
LMP1 P2 ;
P1 0: DVS P2 When P1=0 When P1=1
1: P. B 0: DVS (Recording Stop) 0: P.B (Recording Stop)
1: DVS (CH “1” Recording Start/Stop) 1: P.B (Recording Start)
2: DVS (CH “2” Recording Start/Stop)
3: DVS (CH “3” Recording Start/Stop)
4: DVS (CH “4” Recording Start/Stop)
5: DVS (CH “5” Recording Start/Stop)
MCMC
MCMC
MC MEMORY CHANNEL
Set 12345678910
MCP1 P1 P1 ;
Read 12345678910
MC ;
Answer 12345678910
MCP1 P1 P1 ;
P1 001 - 117: Memory Channel Number
001 - 099: Regular Memory Channel
100: P1L
101: P1U
116: P9L
117: P9U
~
MLML
MLML
ML MONITOR LEVEL
Set 12345678910
MLP1 P2 P2 P2 ;
Read 12345678910
MLP1 ;
Answer 12345678910
MLP1 P2 P2 P2 ;
P1 0: MONI “ON/OFF”
1: MONI Level
P2 When P1=0
000: MONI “OFF”
001: MONI “ON”
When P1=1
001 - 255
MKMK
MKMK
MK MODE KEY
Set 12345678910
MKP1 ;
Read 12345678910
Answer 12345678910
P1 KEY 0: LSB
1: USB
2: CW
3: AM
4: FM
5: RTTY
6: PKT
LKLK
LKLK
LK LOCK
Set 12345678910
LKP1 ;
Read 12345678910
LK ;
Answer 12345678910
LKP1 ;
P1 0: DIAL Lock “OFF”
1: DIAL Lock “ON”

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
NBNB
NBNB
NB NOISE BLANKER STATUS
Set 12345678910
NBP1 P2 ;
Read 12345678910
NBP1 ;
Answer 12345678910
NBP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: Noise Blanker “OFF”
1: Noise Blanker “ON”
2: Noise Blanker (Wide) “ON”
MWMW
MWMW
MW MEMORY CHANNEL WRITE
Set 12345678910
MWP1 P1 P1 P2 P2 P2 P2 P2
11 12 13 14 15 16 17 18 19 20
P2 P2 P2 P3 P3 P3 P3 P3 P4 P5
21 22 23 24 25 26 27 28 29 30
P6 P7 P8 P9 P9 P10 ;
Read 12345678910
Answer 12345678910
P1 Memory Channel Number P2 Memory Channel Frequency (Hz)
P3 Clarifier Direction +: Plus Shift, --: Minus Shift
Clarifier Offset: 0000 - 9999 (Hz)
P4 0: RX CLAR “OFF” 1: RX CLAR “ON”
P5 0: TX CLAR “OFF” 1: TX CLAR “ON”
P6 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
P7 0: (Fixed)
P8 0: CTCSS “OFF” 1: CTCSS ENC/DEC 2: CTCSS ENC
P9: Tone Number (See page 6: “CTCSS Tone Chart”)
P10 0: Simplex 1: Plus Shift 2: Minus Shift
MSMS
MSMS
MS METER SW
Set 12345678910
MSP1 ;
Read 12345678910
MS ;
Answer 12345678910
MSP1 ;
P1 0: PO
1: MIC
2: IDD
3: SWR
4: COMP
MXMX
MXMX
MX MOX SET
Set 12345678910
MXP1 ;
Read 12345678910
NX ;
Answer 12345678910
NXP1 ;
P1 0: MOX “OFF”
1: MOX “ON”
NN
NN
NAA
AA
ANARROW
Set 12345678910
MAP1 P2 ;
Read 12345678910
NAP1 ;
Answer 12345678910
NAP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: OFF
1: ON
CONTROL COMMAND TABLES
NLNL
NLNL
NL NOISE BLANKER LEVEL
Set 12345678910
NLP1 P2 P2 P2 ;
Read 12345678910
NLP1 ;
Answer 12345678910
NLP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 000 - 255
NRNR
NRNR
NR NOISE REDUCTION
Set 12345678910
NRP1 P2 ;
Read 12345678910
NRP1 ;
Answer 12345678910
NRP1 P2 ;
P1 0: Main Band (VFO-A) Receiver
1: Sub Band (VFO-B) Receiver
P2 0: Noise Reduction “OFF”
1: Noise Reduction “ON”
Page 13
MRMR
MRMR
MR MEMORY CHANNEL READ
Set 12345678910
Read 12345678910
MRP1 P1 P1 ;
Answer 12345678910
MRP1 P1 P1 P2 P2 P2 P2 P2
11 12 13 14 15 16 17 18 19 20
P2 P2 P2 P3 P3 P3 P3 P3 P4 P5
21 22 23 24 25 26 27 28 29 30
P6 P7 P8 P9 P9 P10 ;
P1 Memory Channel Number P2 Memory Channel Frequency (Hz)
P3 Clarifier Direction +: Plus Shift, --: Minus Shift
Clarifier Offset: 0000 - 9999 (Hz)
P4 0: RX CLAR “OFF” 1: RX CLAR “ON”
P5 0: TX CLAR “OFF” 1: TX CLAR “ON”
P6 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
P7 0: VFO 1: Memory
P8 0: CTCSS “OFF” 1: CTCSS ENC/DEC 2: CTCSS ENC
P9: Tone Number (See page 6: “CTCSS Tone Chart”)
P10 0: Simplex 1: Plus Shift 2: Minus Shift

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
CONTROL COMMAND TABLES
Page 14
OSOS
OSOS
OS OFFSET (REPEATER SHIFT)
Set 12345678910
OSP1 P2 ;
Read 12345678910
OSP1 ;
Answer 12345678910
OSP1 P2 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
P2 0: Simplex
1: Plus Shift
2: Minus Shift
ÚÚ
ÚÚ
Ú: FM mode only
PCPC
PCPC
PC POWER CONTROL
Set 12345678910
PCP1 P1 P1 ;
Read 12345678910
PC ;
Answer 12345678910
PCP1 P1 P1 ;
P1 000 - 255
PP
PP
PAA
AA
APRE-AMP (IPO)
Set 12345678910
PAP1 P2 ;
Read 12345678910
PAP1 ;
Answer 12345678910
PAP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: IPO “ON”
1: IPO “OFF”
PBPB
PBPB
PB PLAY BACK
Set 12345678910
PBP1 P2 ;
Read 12345678910
PBP1 ;
Answer 12345678910
PBP1 P2 ;
P1 0: DVS P2 When P1=0 When P1=1
1: P.B 0: DVS (Playback Stop) 0: P.B (Playback Stop)
1: DVS (CH “1” Playback Start) 1: P.B (Playback Start)
2: DVS (CH “2” Playback Start)
3: DVS (CH “3” Playback Start)
4: DVS (CH “4” Playback Start)
5: DVS (CH “5” Playback Start)
PLPL
PLPL
PL SPEECH PROCESSOR LEVEL
Set 12345678910
PLP1 P1 P1 ;
Read 12345678910
PL ;
Answer 12345678910
PLP1 P1 P1 ;
P1 000 - 255
PRPR
PRPR
PR SPEECH PROCESSOR
Set 12345678910
PRP1 ;
Read 12345678910
PR ;
Answer 12345678910
PRP1 ;
P1 0: Speech Processor “OFF”
1: Speech Processor “ON”
PSPS
PSPS
PS POWER SWITCH
Set 12345678910
PSP1 ;
Read 12345678910
PS ;
Answer 12345678910
PSP1 ;
P1 0: POWER “OFF”
1: POWER “ON”
OIOI
OIOI
OI OPPOSITE BAND INFORMATION
Set 12345678910
Read 12345678910
OI ;
Answer 12345678910
OIP1 P1 P1 P2 P2 P2 P2 P2
11 12 13 14 15 16 17 18 19 20
P2 P2 P2 P3 P3 P3 P3 P3 P4 P5
21 22 23 24 25 26 27 28 29 30
P6 P7 P8 P9 P9 P10 ;
P1 Current Memory Channel P2 VFO-B Frequency (Hz)
P3 Clarifier Direction +: Plus Shift, --: Minus Shift
Crarifier Offset: 0000 - 9999 (Hz)
P4 0: RX CLAR “OFF” 1: RX CLAR “ON”
P5 0: TX CLAR “OFF” 1: TX CLAR “ON”
P6 MODE 1: LSB 2: USB 3: CW 4: FM 5: AM 6: FSK (RTTY-LSB)
7: CW-R 8: PKT-L 9: FSK-R (RTTY-USB) A: PKT-FM
B: FM-N C: PKT-U
P7 0: VFO 1: Memory
P8 0: CTCSS “OFF” 1: CTCSS ENC/DEC 2: CTCSS ENC
P9: Tone Number (See page 6: “CTCSS Tone Chart”)
P10 0: Simplex 1: Plus Shift 2: Minus Shift

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
QSQS
QSQS
QS QUICK SPLIT
Set 12345678910
QS ;
Read 12345678910
Answer 12345678910
RR
RR
RCC
CC
CCLAR CLEAR
Set 12345678910
RC ;
Read 12345678910
Answer 12345678910
RDRD
RDRD
RD CLAR MINUS OFFSET
Set 12345678910
RDP1 P1 P1 P1 ;
Read 12345678910
Answer 12345678910
P1 0000 - 9999 (Hz)
CONTROL COMMAND TABLES
Page 15
RR
RR
RGG
GG
GRF GAIN
Set 12345678910
RGP1 P2 P2 P2 ;
Read 12345678910
RGP1 ;
Answer 12345678910
RGP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 000 - 255
QIQI
QIQI
QI QMB STORE
Set 12345678910
QI ;
Read 12345678910
Answer 12345678910
QRQR
QRQR
QR QMB RECALL
Set 12345678910
QR ;
Read 12345678910
Answer 12345678910
RARA
RARA
RA RF ATTENUATOR
Set 12345678910
RAP1 P2 ;
Read 12345678910
RAP1 ;
Answer 12345678910
RAP1 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: OFF
1: 3 dB
2: 6 dB
3: 12 dB
4: 18 dB
RFRF
RFRF
RF ROOFING FILTER
Set 12345678910
RFP1 P2 ;
Read 12345678910
RFP1 ;
Answer 12345678910
RFP1 P3 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: AUTO
1: 15 kHz
2: 6 kHz
3: 3 kHz
P3 1: 15 kHz
2: 6 kHz
3: 3 kHz
4: AUTO - 15 kHz
5: AUTO - 6 kHz
6: AUTO - 3 kHz
RIRI
RIRI
RI RADIO INFORMATION
Set 12345678910
Read 12345678910
RIP1 ;
Answer 12345678910
RIP1 P2 ;
P1 0: Hi-SWR
1: MIC-EQ
2: CLASS-A
3: REC
4: PLAY
5: DUAL
P2 0: OFF
1: ON

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
RR
RR
RTT
TT
TCLAR
Set 12345678910
RTP1 ;
Read 12345678910
RT ;
Answer 12345678910
RTP1 ;
P1 0: RX Clarifier “OFF”
1: RX Clarifier “ON”
RR
RR
RUU
UU
URX CLARIFIER PLUS OFFSET
Set 12345678910
RUP1 P1 P1 P1 ;
Read 12345678910
Answer 12345678910
P1 0000 - 9999 (Hz)
SCSC
SCSC
SC SCAN
Set 12345678910
SCP1 ;
Read 12345678910
SC ;
Answer 12345678910
SCP1 ;
P1 0: Scan “OFF”
1: Scan “ON” (Upward)
2: Scan “ON” (Downward)
CONTROL COMMAND TABLES
RR
RR
ROO
OO
OROTATOR
Set 12345678910
ROP1 ;
Read 12345678910
RO ;
Answer 12345678910
ROP1 P2 P2 P2 P3 P3 P3 ;
P1 0: OFF
1: Counter Clockwise
2: Clockwise
3: SPEED 1 % DOWN
4: SPEED 1 % UP
P2 DIRECTION (0 - 450 degree)
P3 SPEED (0 - 100 %)
RSRS
RSRS
RS RADIO STATUS
Set 12345678910
Read 12345678910
RS ;
Answer 12345678910
RSP1 ;
P1 0: NORMAL MODE
1: MENU MODE
2: MENU DATA READ (from CF Card)
Page 16
SDSD
SDSD
SD CW BREAK-IN DELAY TIME
Set 12345678910
SDP1 P1 P1 P1 ;
Read 12345678910
SD ;
Answer 12345678910
SDP1 P1 P1 P1 ;
P1 0000: Full Break-in
0001 - 5000 mS
SFSF
SFSF
SF SUB VFO-B KNOB FUNCTION
Set 12345678910
SFP1 P1 ;
Read 12345678910
SF ;
Answer 12345678910
SFP1 P1 ;
P1 00: OFF (Read only) 05: BAND (Sub (VFO-B) Band)
01: BAND (Main (VFO-A) Band) 06: MHz (Sub (VFO-B) Band)
02: MHz (Main (VFO-A) Band) 07: FAST (Sub (VFO-B) Band)
03: GRP 08: A/B
04: MCH 09: CLAR
10: MODE (Sub (VFO-B) Band)
RLRL
RLRL
RL NOISE REDUCTION LEVEL
Set 12345678910
RLP1 P2 P2 ;
Read 12345678910
RLP1 ;
Answer 12345678910
RLP1 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 01 - 15
RMRM
RMRM
RM READ METER
Set 12345678910
Read 12345678910
RMP1 P1 ;
Answer 12345678910
RMP1 P1 P2 P2 P2 ;
P1 00: Current Main Meter
01: Current Sub Meter
02: Current VDD/BIAS Meter
(Contest/MP versions)
03: Current TEMP/SWR Meter
(Contest/MP versions)
04: S Meter (Main)
05: S Meter (Sub)
06: COMP Meter
07: ALC Meter
08: PO Meter
09: SWR Meter
10: ID Meter
P2 000 - 255
11: VDD Meter
12: MIC Meter
13: BIAS Meter
14: TEMP Meter

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
UPUP
UPUP
UP UP
Set 12345678910
UP ;
Read 12345678910
Answer 12345678910
VDVD
VDVD
VD VOX DELAY TIME
Set 12345678910
VDP1 P1 P1 P1 ;
Read 12345678910
VD ;
Answer 12345678910
VDP1 P1 P1 P1 ;
P1 0000 - 5000 mS (20 mS multiples)
SQSQ
SQSQ
SQ SQUELCLH LEVEL
Set 12345678910
SQP1 P2 P2 P2 ;
Read 12345678910
SQP1 ;
Answer 12345678910
SQP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band
1: Sub (VFO-B) Band
P2 000 - 255
ULUL
ULUL
UL PLL UNLOCK STATUS
Set 12345678910
Read 12345678910
UL ;
Answer 12345678910
ULP1 ;
P1 0: PLL “Lock”
1: PLL “Unlock”
CONTROL COMMAND TABLES
SVSV
SVSV
SV SWAP VFO
Set 12345678910
SV ;
Read 12345678910
Answer 12345678910
TSTS
TSTS
TS TXW
Set 12345678910
TSP1 ;
Read 12345678910
TS ;
Answer 12345678910
TSP1 ;
P1 0: TXW “OFF”
1: TXW “ON”
TXTX
TXTX
TX TX SET
Set 12345678910
TXP1 ;
Read 12345678910
TX ;
Answer 12345678910
TXP1 ;
P1 0: RADIO TX “OFF” CAT TX “OFF”
1: RADIO TX “OFF” CAT TX “ON”
2: RADIO TX “ON” CAT TX “OFF” (Answer)
Page 17
SHSH
SHSH
SH WIDTH
Set 12345678910
SHP1 P2 P2 ;
Read 12345678910
SHP1 ;
Answer 12345678910
SHP1 P2 P2 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 00 (Counter Clockwise) - 31 (Clockwise), 16 (Center)
SMSM
SMSM
SM S-METER READING
Set 12345678910
Read 12345678910
SMP1 ;
Answer 12345678910
SMP1 P2 P2 P2 ;
P1 0: Main (VFO-A) Band S-meter
1: Sub (VFO-B) Band S-meter
P2 000 - 255

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
VXVX
VXVX
VX VOX STATUS
Set 12345678910
VXP1 ;
Read 12345678910
VX ;
Answer 12345678910
VXP1 ;
P1 0: VOX “OFF”
1: VOX “ON”
XTXT
XTXT
XT TX CLAR
Set 1213 4 5 6 7 8 910
XTP1 ;
Read 12345678910
XT ;
Answer 12345678910
XTP1 ;
P1 0: TX CLAR “OFF”
1: TX CLAR “ON”
CONTROL COMMAND TABLES
VMVM
VMVM
VM VFO-A TO MEMORY CHANNEL
Set 12345678910
VM ;
Read 12345678910
Answer 12345678910
VSVS
VSVS
VS VFO SELECT
Set 12345678910
VSP1 ;
Read 12345678910
VS ;
Answer 12345678910
VSP1 ;
P1 0: VFO-A
1: VFO-B
Page 18
VV
VV
VGG
GG
GVOX GAIN
Set 12345678910
VGP1 P1 P1 ;
Read 12345678910
VG ;
Answer 12345678910
VGP1 P1 P1 ;
P1 000 - 255
VFVF
VFVF
VF VRF FILTER
Set 12345678910
VFP1 P2 P3 P4 ;
Read 12345678910
VFP1;
Answer 12345678910
VFP1 P2 P5 P5 P5 P6 ;
P1 0: Main (VFO-A) Band Receiver
1: Sub (VFO-B) Band Receiver
P2 0: OFF
1: ON
2: Default set
P3 +: Plus Shift
–: Minus Shift
P4 0 - 9 (Step)
P5 000 - 255
P6 0: VRF
1: μTUNE

FT DX 9000 SERIES CAT OPERATION REFERENCE
CAT (COMPUTER AIDED TRANSCEIVER)OPERATION
EH010H121
Copyright 2008
VERTEX STANDARD CO., LTD.
All rights reserved
No portion of this manual
may be reproduced without
the permission of
VERTEX STANDARD CO., LTD.
