Yale Z-Wave Plus YRMZW2-US User manual

® ®
Yale Z-Wave Plus Smart Module
Installation Guide
®
Adding a Yale Z-Wave Plus Smart Module to your Assure Lock & Z-Wave System
1. On your lock keypad, enter your master entry code followed by the icon
2. Press the 7 key followed by the icon
3. Press the 3 key followed by the icon
4. Open the Z-Wave system's smart home or alarm app and follow the instructions for
removing a device
5. Remove the Yale Smart Module from the slot above the battery compartment
IMPORTANT: The batteries must be removed before removing the Yale Smart Module:
• Remove battery cover
• Remove batteries
• Insert or remove Yale Smart Module
• Reinstall batteries
• Reinstall battery cover
6. If you're adding a new Yale Smart Module, follow the instructions included with it
P/N AYR202-ZW-INSTAL-FUL Rev E
®
®
Removing a Yale Z-Wave Plus Smart Module from your Assure Lock & Z-Wave System
1. Install the Yale Smart Module into the slot above the battery compartment
IMPORTANT: The batteries must be removed before removing the Yale Smart Module:
• Remove battery cover
• Remove batteries
• Insert or remove Yale Smart Module
• Reinstall batteries
• Reinstall battery cover
2. Open the Z-Wave system's smart home or alarm app on your smartphone or tablet
3. Follow the in-app instructions for adding a new device
4. On your lock keypad, enter your master entry code followed by the icon
5. Press the 7 key followed by the icon
6. Press the 1 key followed by the icon
Please use this procedure only when network primary controller is missing
or otherwise inoperable.

!Warning: Changes or modifications to this device, not expressly approved by ASSA ABLOY
Residential Group could void the user's authority to operate the equipment.
FCC:
This radio transmitter 6982A-YRHCPZW0FM has been
approved by Industry Canada to operate with the antenna
types listed below with the maximum permissible gain
indicated. Antenna types not included in this list, having a
gain greater than the maximum gain indicated for that type,
are strictly prohibited for use with this device.
Model: YRMZW2-US
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,
AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
Model: YRMZW2-US
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
Interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
Ÿ Reorient or relocate the receiving antenna.
Contain FCC ID: U4A-YRHCPZW0FM
Ÿ Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Contain IC: 6982A-YRHCPZW0FM
Section 7.1.2 of RSS-GEN Under Industry Canada
regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for
the transmitter by Industry Canada. To reduce potential radio
interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary for
successful communication.
Ÿ Increase the separation between the equipment and
receiver.
Section 7.1.3 of RSS-GEN This Device complies with
Industry Canada License-exempt RSS standard(s). Operation
is subject to the following two conditions: 1) this device may
not cause interference, and 2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
Industry Canada:
Ÿ Consult the dealer or an experienced radio/TV technician
for help.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS.
En vertu des règlements d'Industrie Canada, cet émetteur
radio ne peut fonctionner avec une antenne d'un type et un
maximum (ou moins) approuvés pour gagner de l'émetteur
par Industrie Canada. Pour réduire le risque d'interférence
aux autres utilisateurs, le type d'antenne et son gain doivent
être choisies de façon que la puissance isotrope rayonnée
équivalente (PIRE) ne dépasse pas ce qui est nécessaire pour
une communication réussie.
Cet appareil est conforme avec Industrie Canada RSS
standard exemptes de licence(s). Son fonctionnement est
soumis aux deux conditions suivantes: 1) ce dispositif ne
peut causer des interférences, et 2) cet appareil doit
accepter toute interférence, y compris les interférences qui
peuvent causer un mauvais fonctionnement du dispositif.
Le présent émetteur radio 6982A-YRHCPZW0FM a été
approuvé par Industrie Canada pour fonctionner avec les
types d'antenne énumérés ci-dessous et ayant un gain
admissible maximal. Les types d'antenne non inclus dans
cette liste, et dont le gain est supérieur au gain maximal
indiqué, sont strictement interdits pour l'exploitation de
l'émetteur.
CAN ICES-3B/NMB-3B
24/7 Tech Support : 1-855-492-0505 • www.yalehome.com
Yale® is a registered trademark of ASSA ABLOY Residential Group. Other products' brand names may
be trademarks or registered trademarks of their respective owners and are mentioned for reference
purposes only. © Copyright 2019. All rights reserved. Reproduction in whole or in part without the
express written permission of ASSA ABLOY Residential Group is prohibited.
This device is a security enabled Z-Wave Plus product that is able to use encrypted Z-Wave Plus messages to
communicate to other security enabled Z-Wave Plus products. This device must be used in conjunction with a Security
Enabled Z-Wave Controller in order to fully utilize all implemented functions. This product can be operated in any Z-
Wave network with other Z-Wave certified devices from other manufacturers. All non-battery operated nodes within the
network will act as repeaters regardless of vendor to increase reliability of the network.

Rotate
P/N YRD136-MNL-0008 Rev A
2-3/8" position
2-3/4" position
O
optional
x4
Installing Latch & Strike Plate
1
Bolt must be in retracted
(unlocked) position. UP
arrow must be facing
upwards.
!
Installing Keypad Escutcheon
2
Outside of Door
Ensure cable is
routed under the
deadbolt.
!
Installing Interior Mounting Plate
3
Attaching the Cable Assembly
4Testing Operation
Preparing Door and
Keypad Escutcheon
Initial Programming
Bolt must be in
retracted
(unlocked)
position before
installing AA
batteries.
!
6
Yale ProSL
®
Key Free Keypad Deadbolt with Z-Wave Plus
Installation and Programming Instructions
Installing Cover
®
Congratulations, you've installed the Yale ProSL Key Free
Keypad Deadbolt with Z-Wave Plus! Turn sheet over for
Programming Instructions to customize your product.
default
Installing Interior Escutcheon
5
After entering the Master PIN
code, press any key to complete
handing.
Press .
Enter new Master PIN
code (4-8 digits).
Press to complete.
®
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN DAMAGE TO
THE PRODUCT AND VOID THE FACTORY WARRANTY
Before you begin
for step-by-step installation
instructions & to register
your product
DOWNLOAD
THE BILT APP
3
2- /8
3
2- /8
3
2- /4
Thumbturn
should be in
vertical
position.
!Deadbolt should
extend and retract
smoothly. If not, go
back to step 2.
!
Lock will not operate
until gear is pressed
and Master PIN code
is set.
!
x4
x3
#8-32 x 5/16"
Machine screws
#7 wood & #8-32
machine x 20mm
Combination screws
x2 Silver
M6x55mm
PPHMS
(2-1/4")
OR
x2 Black
M6x44mm
PPHMS
(Standard 1-3/4" - 2")
OR
x2 Gold
M6x36mm
PPHMS
(1-3/8")
x2
Choose
through bolt
appropriate for
your door
thickness.
!
If bore hole is less
than 2-1/8", remove
cup by gently
compressing two
tabs while pulling.
!
!
Cup must be removed from
escutcheon if bore hole is
less than 2-1/8".
2-1/8" Application <2-1/8" Application

Press Press Press
Press each keypad key for response when pressed.
Apply 9V battery to terminals below the keypad for
Programming Instructions
Press
Enter Master PIN code
Press
Enter 4-8 digit PIN code
"Unlock"
Audio Mode
All Code Lockout Mode
Enable
Enable
Disable
Disable For quiet areas, select Disable (3)
in Audio Mode.
Programming Troubleshooting
Symptom Suggested Action
Press
Press
Press
Press
Press
Definitions
Changing Master PIN Code
1
Enter 4-8
digit Master
PIN Code.
Creating User PIN Codes
2Master PIN code must be created first.
*Max User Codes = 250 in network
Unlocking Door with PIN Code
3
Enter PIN
Press
Resetting Lock to Factory Default
Factory Settings
Settings Factory Setting
Master PIN Code Registration required*
Automatic Re-lock Disabled
One Touch Locking Enabled
Audio Enabled
Automatic Re-lock Time 30 Seconds
Wrong Code Entry Limit 5 Times
Shutdown Time 60 Seconds
*The Master PIN code must be registered prior to any other programming of the lock.
When lock is reset to factory defaults all
user codes (including the Master PIN
code*) are deleted and all programming
features are reset to original default
settings (see "Factory Default Settings").
2. Remove the batteries.
1. Remove the battery cover.
Upon reset, Master Code creation is the
only option available and must be
performed prior to any other
programming of the lock.
4. Replace battery cover.
NOTE: After setting the Master Code,
press any key to complete handing of
the lock.
3. While pressing the reset button
(minimum of 3 seconds) reinstall
batteries. Release reset button.
Default settings
in bold.
Enrolling Lock In Z-Wave Plus Network
Your network controller first needs to be in
enrollment or exclusion mode for the lock
to be enrolled or removed from network.
1. Remove the battery cover.
2. Press button and hold until unit beeps
two (2) times.
Once you put the controller in the
enrollment or exclusion mode, the lock
can be enrolled or removed in the Z-Wave
Plus Plus network by pressing the
button.
3. Release button and network removal
automatically begins.
To enroll lock using the button option:
3. Release button and network joining
automatically begins.
4. Replace battery cover.
1. Remove the battery cover.
4. Replace battery cover.
To remove lock using the button option:
2. Press button and hold until unit beeps
five (5) times.
Product Support Tel [phone] • www.yalehome.com
ASSA ABLOY Residential Group. Other products' brand names may be trademarks or registered
permission of ASSA ABLOY Residential Group is prohibited.
Yale® and Yale Real Living® are registered trademarks of
© Copyright 2019. All rights reserved. Reproduction in whole or in part without the express written
trademarks of their respective owners and are mentioned for reference purposes only.
Master PIN Code must be created before any further programming.
Max User Codes = 250 in network
Warning: Changes or modifications to this device, not expressly approved by
ASSA ABLOY Residential Group could void the user's authority to operate the
equipment.
PIN Code Management - Up to 250 Users (in network)
Duplicate if necessary
User Name PIN Code
Code Chart
Low Battery Warning
Flashes RED
All Code Lockout Mode: This feature is enabled by the Master code. When enabled, it
restricts all user (except Master) PIN code access. When attempting to enter a code while
the unit is in Lockout, the lock rapidly beeps 5 times.
Audio Mode: Choosing Disable (3) in Audio mode shuts off the code confirmation tone
play-back for use in quiet areas. Audio mode is enabled or disabled through feature
programming by the Master code.
Automatic Re-lock Time: After a successful code entry or manual unlock with the key, the
lock will automatically re-lock after each unlock in an effort to keep your home secure. This
feature is optional, and can be turned off. In the ON mode, the lock will automatically re-lock
after thirty (30) seconds.
Low Battery: When battery power is low, the Low Battery Warning Indicator flashes RED. If
battery power is completely lost, use the 9Volt battery override. To use the 9V battery
override apply 9V battery, in either direction, to terminals below the keypad for backup
power option. Wake up the lock and enter your pin code to unlock the door.
Master PIN Code: The Master PIN code is used for programming and for feature settings. It
must be created prior to programming the lock. The Master code will also operate
(unlock/lock) the lock.
Network Setting: This setting is available through the wireless button on the interior
escutcheon and allows the lock to connect with a network controller.
User PIN Code: The User code operates the lock. Maximum number of user codes is 250 in
network.
Wrong Code Entry Limit: After five (5) unsuccessful attempts at entering a valid PIN code,
the unit will shut down and not allow operation for sixty (60) seconds.
Tamper Alert: Audible alarm sounds if attempting to forcibly remove outside lock from door.
One Touch Locking: When the latch is retracted, activating the keypad will extend the latch
(during Automatic Re-lock duration or when Automatic Re-lock is disabled).
Shutdown Time: The unit will shutdown (flashing keypad) for sixty (60) seconds and not
allow operation after the wrong code entry limit has been met.
All Code Lockout Mode
Rapidly beeps 5 times
Failsafe 9 Volt
Battery Connection
(Use Alkaline battery)
®
While Yale has included several features to prevent lockout (9-
Volt battery jumper, low battery warnings), it is still possible for
a lockout situation to occur. Because this product does not
®
have a mechanical override (a key), Yale recommends to use
this product in an environment where there are additional
entry points into the dwelling.
NOTE TO INSTALLER AND CONSUMER
Keypad Wake-Up
M
U
Master PIN Code Setting
User PIN Code Registration
Register
Delete
Complete
Handing the Lock Preforms automatic
handing of the lock
Advanced Lock Settings Automatic Re-lock Disable
30 sec
One Touch Locking Enable
Disable
Continue
60 sec
3 min
2 min
U
2. Enter the 4-8 digit Master PIN code followed by the key.
3. Enter digit corresponding to the function to be performed followed by the key.
1. Wake the lock by pressing the .
!Warning: Changes or modifications to this device, not expressly approved by ASSA
ABLOY Residential Group could void the user's authority to operate the equipment.
Industry Canada:
Section 7.1.3 of RSS-GEN This Device complies with
Industry Canada License-exempt RSS standard(s).
Operation is subject to the following two conditions: 1)
this device may not cause interference, and 2) this
device must accept any interference, including
interference that may cause undesired operation of the
device.
Contain 11626A- YRIZW2USTS1
Le présent émetteur radio 6982A-YRHCPZW0FM a été
approuvé par Industrie Canada pour fonctionner avec
les types d'antenne énumérés ci-dessous et ayant un
gain admissible maximal. Les types d'antenne non
inclus dans cette liste, et dont le gain est supérieur au
gain maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.
CAN ICES-3B/NMB-3B
Section 7.1.2 of RSS-GEN Under Industry Canada
regulations, this radio transmitter may only operate
using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada.
To reduce potential radio interference to other users,
the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful
communication.
En vertu des règlements d'Industrie Canada, cet
émetteur radio ne peut fonctionner avec une antenne
d'un type et un maximum (ou moins) approuvés pour
gagner de l'émetteur par Industrie Canada. Pour
réduire le risque d'interférence aux autres utilisateurs,
le type d'antenne et son gain doivent être choisies de
façon que la puissance isotrope rayonnée équivalente
(PIRE) ne dépasse pas ce qui est nécessaire pour une
communication réussie.
Model: YRD156-ZW-619,605,0BP
This radio transmitter 6982A-YRHCPZW0FM has been
approved by Industry Canada to operate with the
antenna types listed below with the maximum
permissible gain indicated. Antenna types not included
in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for
use with this device.
Cet appareil est conforme avec Industrie Canada RSS
standard exemptes de licence(s). Son fonctionnement
est soumis aux deux conditions suivantes: 1) ce
dispositif ne peut causer des interférences, et 2) cet
appareil doit accepter toute interférence, y compris les
interférences qui peuvent causer un mauvais
fonctionnement du dispositif.
Ÿ Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful Interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
FCC:
Contain FCC ID: 2ABFG- YRIZW2USTS1
Ÿ Reorient or relocate the receiving antenna.
Model: YRD156-ZW-619,605,0BP
Ÿ Increase the separation between the equipment
and receiver.
Ÿ Consult the dealer or an experienced radio/TV
technician for help.
(1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
Enter Master PIN code
Press
Press
Press
Feature Programming Through Menu Mode
Using Master PIN code*
Use this procedure only
when network primary
controller is missing or
otherwise inoperable.

1
Yale Locks
YRD116/126/136/156 Z-Wave Plus System Integrators Guide
Yale Assure Deadbolt Lock
June 3, 2019

2
Contents
Yale Z-Wave Plus Product Info ................................................................................................................. 3
Supported Command Classes .................................................................................................................. 3
Association Table ....................................................................................................................................4
Notifications Table .................................................................................................................................. 4
Configurable Parameters......................................................................................................................... 6

3
Yale Z-Wave Plus Product Info
Manufacturer ID: Assa Abloy (0x0129)
Z-Wave Device Type: Door Lock Keypad
Z-Wave Role Type: Listening Sleeping Slave (LSS)
Product ID: 0x0508
Product Type ID:
0x803A –YRD126-ZW2/YRD156-ZW2 (Touch Screen Deadbolt)
or
0x803B –YRD116-ZW2/YRD136-ZW2 (Pushbutton Deadbolt)
Supported Command Classes
Command Class Z-Wave Plus Info
Command Class Manufacturer Specific
Command Class Security
Command Class Device Reset Locally
Command Class Power Level
Command Class Version
Command Class Battery*
Command Class Door Lock*
Command Class Door Lock Logging*
Command Class Schedule Entry Lock*
Command Class User Code*
Command Class Time Parameters*
Command Class Time*
Command Class Association*
Command Class Association Group Info*
Command Class Notification*
Command Class Configuration*
Command Class Firmware Update Md*
* Command Class Requires Security

4
Association Table
Group ID
Maximum Nodes
Description
Commands
1
1
Lifeline
Command_Class_Battery, Battery_Report ;
Command_Class_Notification, Notification_Report;
Command_Class_Configuration, Configuration_Report;
Command_Class_Device_reset_locally,
Device_Reset_locally_notification
Notifications Table
Alarm Reports
Alarm
type
Alarm Level
Description
Master Code
changed.
0x70
0x00
Master code was changed at keypad
0xFB
Master code was changed over RF
User added
0x(01-max
users)
User added. Alarm level = user slot number
User deleted
0x21
0x(01-max
users)
User was deleted. Alarm level = user slot number
Tamper Alarm
0xA1
0x01
keypad attempts exceed code entry limit
0x02
front escutcheon removed from main
RF Operate Unlock
0x19
0x01
by RF module
Manual Unlock
0x16
0x01
By key cylinder or
inside thumb turn
Keypad Unlock
0x13
0x(01-max
users)
Where Alarm level represents user slot number (0xFB =
Master Code)
Manual Lock
0x15
0x01
by key cylinder or inside thumb-turn
0x02
by touch function (lock and leave)
0x03
By inside button
RF Operate Lock
0x18
0x01
by RF module
Keypad Lock
0x12
0x (01 –max
users)
Where Alarm level represents user slot number
Non Access
0x26
0x(01-max
users)
A Non Access Code was entered at the lock.
Where alarm level represents user slot number
Deadbolt Jammed
0x09
0x01
Deadbolt jammed
while locking
0x02
Deadbolt jammed
while unlocking

5
Low Battery
Alarms**
0xA9
0x (Current %)
Too Low to operate (Starting at 3.8V)
0xA8
0x (Current %)
Critical Battery Level (Starting at 3.9V)
0xA7
0x (Current %)
Low Battery
(Starting at 4.2V)
Auto Lock Operate
Locked
0x1B
0x01
Auto re-lock cycle complete, locked.
Duplicate Pin-code
error
0x71
0x (01-max
users)
Where Alarm level represents user slot number
Alarm generated in response to add user RF cmd.
This alarm is not generated when attempting to add
duplicate pin at the keypad. The lock simply denies it
and plays the “Denied”. Trying to duplicate the
master code will result in a 0x71 0x00 alarm report.
RF Module Power
Cycled
0x82
0x00
Power to RFM was restored, sent by RF module. The
lock doesn’t send any alarm to the RF module when
power is cycled.
Disabled user
entered at keypad
0x83
0x(01-max
users)
A disabled user pin code was entered at the keypad
Valid user but
outside of schedule
0x84
0x(01-max
users)
A valid user can be both a normal user and a Non-
Access user. If a non-access user is out of schedule this
alarm will be sent instead of the non-access alarm.
Daily Repeating
Schedule
Set/Erased
0x60
0x(01-max
users)
Schedule(s) has been set/erased for specified user ID
Daily Repeating
Schedule
Enabled/Disabled
0x61
0x(01-max
users)
Schedule(s) has been enabled/disabled for specified
user ID
Year Day Schedule
Set/Erased
0x62
0x(01-max
users)
Schedule(s) has been set/erased for specified user ID
Year Day Schedule
Enabled/Disabled
0x63
0x(01-max
users)
Schedule(s) has been enabled/disabled for specified
user ID
All Schedule Types
Erased
0x64
0x(01-max
users)
Schedule(s) has been set/erased for specified user ID
All Schedule Types
Enabled/Disabled
0x65
0x(01-max
users)
Schedule(s) has been enable/disabled for specified user
ID
** - The Yale Assure Deadbolt locks also supports a 3rd low battery alarm, too low to operate. This alarm
is sent out as a Battery Report (with value = 0xFF) through the Battery Command Class. This is the last
low battery alarm level before the product stops functioning.

6
Configurable Parameters
Configuration
Parameters
Parameter
Number
Size
Description
Silent mode on/off
1
1 byte
Level control, 1 = High Volume, 3 = Silent. Default is 1
or High Volume
Auto Relock on/off
2
1 byte
0x00 = OFF, 0xFF = ON default is 0x00 or OFF
Auto Relock time
3
1 byte
10 to 180 seconds default is 30 seconds
Wrong Code Entry Limit
4
1 byte
3 to 10 default is 5 times
Shut down time (after
wrong code entries)
7
1 byte
10 to 180 seconds default is 60 seconds
Operating mode
8
1 byte
00 = normal mode (this is the default mode)
01 = vacation mode, keypad lockout
One Touch Locking
11
1 byte
0x00 = OFF, 0xFF = ON default is 0xFF or ON.
Lock Status LED
13
1 byte
0x00 = OFF, 0xFF = ON default is 0x00 or OFF.
Reset To Factory
Defaults
15
1 byte
01 = Lock will execute Reset To Factory.
No default value
