Yard Works YRD1245-14 User manual

11/13
Owners Manual
Model YRD1245-14
For product inquiries:
Tricam
7677 Equitable Drive
Eden Prairie, MN 55344
1-800-867-6763
www.tricam.com
•Important Safety Instructions
•Assembly Instructions
•Parts and Hardware Identification
CAUTION: Read, understand and follow ALL instructions before using this product.
Questions, problems, or missing parts? Before returning to your retailer, visit us
online at www.tricam.com and complete the replacement parts submission form or
call our customer service department at 1-800-867-6763, 9 a.m. - 4 p.m., CST,
Monday-Friday.
WARNING: Not for recreational use. Persons should never ride in the cart.
Pull-Behind
Steel Utility Cart

Exploded Drawing for Assembly
Parts List
A. Bed (1)
B. Side Panels (2)
C. Front Panel (1)
D. Back Panel (1)
E. 10in (25.4cm) Wheels (4)
F. Front Axle Sub-Assembly (1)
G. Yoke (1)
H. Front Strut (1)
I. Front Axle Connection Bar (1)
J. Rear Axle Sub-Assembly (1)
K. Rear Struts (2)
L. Handle (1)
M. Liner (1)
K.
J.
A.
B.
C. D. E.
F. G. H.
I.
M.
L.
A. Fence Assembly Pins (8)
B. M8x180 Carriage Bolt (1)
C. M8 Washers (6)
D. M8 Lock Nuts (6)
E. M10 Washer (1)
F. Cotter Pin (1)
G. M8x17 Shoulder Bolts (2)
H. M6 Washers (2)
I. M6 Lock Nuts (2)
J. M8x20 Carriage Bolts (4)
K. Wheel Nylon Spacers (4)
L. M12 Washers (4)
M. M12 Lock Nuts (4)
N. M8x60 Hex Bolt (1)
Hardware List Images are
not to scale A.
G. H. I.
K. L. M.
J.
B.
D.
C. E. F.
N.
Parts List
Replacement Parts List
For replacement parts, please visit us online at www.tricam.com to complete the
replacement parts submission form or call our customer service department at
1-800-867-6763, 9 a.m. - 4 p.m., CST, Monday - Friday.
B. Side Panels (2)
C. Front Panel (1)
D. Back Panel (1)
E. 10in (25.4cm) Wheels (4)
F. Front Axle Sub-Assembly (1)
G. Yoke (1)
H. Front Strut (1)
I. Front Axle Connection Bar (1)
J. Rear Axle Sub- Assembly (1)
K. Rear Struts (2)
L. Handle (1)
M. Liner
N. Hardware Kit
K.
J.
B.
C.
D.
E. F.
G. H.
I.
L.
M.
N.

Step 1
Important Safety Instructions
Assembly Instructions
Tools required for assembly: pliers, adjustable wrenches and/or metric socket set
NOTE: During each step of assembly, assemble all hardware and hand tighten.
Once all the hardware is installed for that particular step, tighten all hardware.
1. READ ALL INSTRUCTIONS CAREFULLY BEFORE USE. If you do notunderstand
these instructions, need clarification or further explanation, please call our toll
free answer line for assistance at 1-800-867-6763. Monday through Friday 9:00
a.m. until 4 :00 p.m. CST.
2. Do not exceed the overall maximum load capacity of 900 lbs (408 kg).The weight
rating is based on an evenly distributed load.
3. Do not load items on the top edges of the panels. Remove panels before loading
oversized items.
4. Do not allow children to use this cart without supervision. This cart is not a toy.
5. Do not use this cart to transport passengers.
6. This cart is not intended for highway use.
7. Do not exceed 5 mph.
8. If any parts become damaged, broken or misplaced, do not use the cart until
replacement parts have been obtained.
9. Do not use the cart on surfaces or for transporting objects that can cause
damage to the pneumatic tires or tubes. Do not inflate the tires to more
than 30 PSI (2.07 BAR).
10. It is recommended that the cart be inspected for damage before each use.
11. KEEP THESE INSTRUCTIONS FOR FURTHER REFERENCE.
Your cart requires assembly. Account for all parts and hardware before beginning
assembly. If any parts are missing, damaged or if you have questions or need
additional instructions DO NOT RETURN THIS PRODUCT TO THE RETAILER, visit us
online at www.tricam.com to complete the replacement parts submission form or call
our customer service department at 1-800-867-6763.
Turn the cart bed upside down. Use the
cardboard from the carton to keep from
scratching or damaging the finish.
Step 2
Attach the front strut and yoke to the front axle
sub-assembly using M8x180 carriage bolt (1), M8 washer
(1) and M8 lock nut (1).Tighten securely.
Step 8
Attach the handle to the
yoke using M8x180 hex
bolt (1), M8 washer (1)
and M8 lock nut (1).
Tighten securely.
Step 9
The lock handles are
pre-assembled onto the
panels. NOTE: Do not
tighten the lock nuts on the
lock handles until the end
of this step. Attach the
front, back, and side panels
(2) onto the bed using the
fence assembly pins. Latch
the front and back panels
to the side panels using the
lock handles. Once all
panels are locked together
in the upright position,
tighten all M8 lock nuts on
the lock handles for smooth
operation without being
overly tight.
CAUTION
DO NOT EXCEED MAXIMUM OVERALL
LOAD CAPACITY 900 LBS (408 KG).
PERSONS SHOULD NEVER RIDE IN THE
UTILITY CART. WEIGHT RATING IS BASED
ON AN EVENLY DISTRIBUTED LOAD.

Step 3
Attach the connection bar onto the front axle subassembly using M8x17 shoulder
bolts (2), M6 washers (2), M6 lock nuts (2) M10 washer (1) and cotter pin (1).
Step 4
Attach the front axle assembly and front strut
to the bed using M8x20 carriage bolts (2), M8
washers (2) and M8 lock nuts (2). NOTE: the
hardware to attach the front strut to the bed
is pre-assembled to the strut.
A. Place the front axle assembly and front
strut onto the bed. Attach the front strut to
the bed first. Place the M8x25 carriage bolt
(pre-assembled to the strut) into
the pre-punched hole on the
bed and slide it into place. Lift
up slightly on the strut and
tighten bolt securely.
B. Next secure the front axle
assembly to the bed using
M8x20 carriage bolts (2), M8
washers (2) and M8 lock nuts
(2). Tighten bolts securely.
Step 5
4A
4B
5A
Attach the rear axle assembly
and rear struts onto the bed
using M8x20 carriage bolts (2),
M8 washers (2) and M8 lock nuts
(2). NOTE: the hardware to attach
the rear struts to the bed is
pre-assembled to each strut.
A. Slide the rear struts onto each
end of the rear axle assembly.
Continued
Step 6
Attach the wheels by first placing
the nylon wheel spacers (4) onto
the front and rear axles.
Step 7
Place the wheels onto each axle (valve stems facing out) using M12 wheel washers
(4) and M12 lock nuts (4). Tighten all nuts securely. Turn the cart upright on all
4 wheels.
5B
5C
Step 5 Continued
B. Place the rear axle assembly and
rear struts onto the bed. Attach the
rear struts to the bed first. Place the
M8x25 carriage bolts
(pre-assembled to the strut) into the
pre-punched holes on the bed and
slide them into place. Lift up slightly
on each strut and tighten
bolts securely.
C. Next secure the rear axle
assembly to the bed using M8x20
carriage bolts (2), M8 washers (2)
and M8 lock nuts (2). Tighten
bolts securely.
