YA S K AWA
MANUAL NO. SIEZ-C887-2.6B
YASKAWA
USER'S MANUAL
Machine Controller MP920
Communications Module

Copyright ©1999 YASKAWA ELECTRIC CORPORATION
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system,
or transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording,
or otherwise, without the prior written permission of Yaskawa. No patent liability is assumed
with respect to the use of the information contained herein. Moreover, because Yaskawa is con-
stantly striving to improve its high-quality products, the information contained in this manual is
subject to change without notice. Every precaution has been taken in the preparation of this
manual. Nevertheless, Yaskawa assumes no responsibility for errors or omissions. Neither is
any liability assumed for damages resulting from the use of the information contained in this
publication.

iii
Using this Manual
Please read this manual to ensure correct usage of the MP900-Series system. Keep this man-
ual in a safe place for future reference.
Overview
This manual describes the Communications Modules designed for MP900-Series Machine
Controllers.
The following Communications Modules can be used with MP900-Series Machine Control-
lers.
• 215IF (for realtime core networks)
• 217IF (for serial, RS-422/485 networks)
• 218IF (for Ethernet networks)
This manual describes the following items required to use these Communications Modules.
• Communications Module setup
• Communications protocols
• Communications messages
• Communications programming examples
Read this manual carefully when building a communications system or network around
MP900-Series Machine Controllers. Also, keep this manual in a safe place so that it can be
referred to whenever necessary.
Intended Audience
This manual is intended for the following users.
• Those responsible for estimating the MP920 system
• Those responsible for deciding whether to apply the MP920 system
• Those responsible for designing the MP920 system so that it can be mounted in the con-
trol and operating panels
• Those responsible for making, inspecting, testing, adjusting, and maintaining the control
and operating panels in which the MP920 is mounted
Basic Terms
Unless otherwise specified, the following definitions are used:
• MP920 = MP920 Machine Controller, which consists of a Power Supply Module, CPU
Module, I/O Modules, and other Modules
• PC: Programmable Logic Controller
• PP: Programming Panel
• MPE720: The Programming Device Software or a Programming Device (i.e., a personal
computer) running the Programming Device Software
• PLC = Programmable Logic Controller
• “” in “MOV [axis1]...” represents numeric data for axis 1.

iv
Visual Aids
The following aids are used to indicate types of information for easier reference.
Indication of Reverse Signals
In this manual, the names of reverse signals (ones that are valid when low) are written with a
forward slash (/) before the signal name, as shown in the following example:
Indicates important information that should be memorized.
Indicates supplemental information.
Indicates application examples.
Describes technical terms that are difficult to understand, or in the text
without an explanation being given.
• S-ON = /S-ON
• P-CON = /P-CON
IMPORTANT
INFO
EXAMPLE
TERMS

v
Related Manuals
Refer to the following related manuals as required.
Thoroughly check the specifications, restrictions, and other conditions of the product before
attempting to use it.
Manual Name Manual Number Contents
Machine Controller MP900/MP2000
Series Ladder Logic Programming
User’s Manual
SIEZ-C887-1.2 Describes the instructions used in MP900/
MP2000 Series ladder logic programming.
Machine Controller MP900/MP2000
Series Motion Programming
User’s Manual
SIEZ-C887-1.3 Describes the motion programming language
used for MP900/MP2000 Series Machine
Controllers.
Machine Controller MP900/MP2000
Series User’s Manual
MPE720 Software for Programming
Device
SIEPC88070005 Describes how to install and operate the
MP900/MP2000 Series programming sys-
tem MPE720.
Machine Controller MP920 Motion
Module User’s Manual
SIEZ-C887-2.5 Describes the functions, specifications, and
usage of the MP920 Motion Modules (SVB-
01 and PO-01).
Machine Controller MP920 User’s
Manual: Design and Maintenance
SIEZ-C887-2.1 Describes the design and maintenance for
the MP920 Machine Controller.
FDS System Installation Manual SIE-C873-16.4 Describes transmission line wiring methods.

vi
Safety Information
The following conventions are used to indicate precautions in this manual. Failure to heed
provided in this manual can result in serious or possibly even fatal injury or damage to he
products or to related equipment and systems.
The warning symbols for ISO and JIS standards are different, as shown below.
The ISO symbol is used in this manual.
Both of these symbols appear on warning labels on Yaskawa products. Please abide by these
warning labels regardless of which symbol is used.
Indicates precautions that, if not heeded, could possibly result in loss of
life, serious injury.
Indicates precautions that, if not heeded, could result in relatively serious
or minor injury, damage to the product, or faulty operation.
ISO JIS
WARNING
CAUTIONCAUTIONCAUTION

vii
Safety Precautions
This section describes precautions that apply to ladder programming. Before programming,
always read this manual and all other documents provided to ensure correct programming.
Before using the equipment, familiarize yourself with equipment details, safety information,
and all other precautions.
Handling
Installation
• Do not subject the product to halogen gases, such as fluorine, chlovine, bromine, and
iodine, at any time even during transportation or installation.
Failure to observe this caution may cause damage or failure of the product.
• Firmly tighten the Module mounting screws and terminal block mounting screws to pre-
vent them from loosening during operation.
Loose screws may result in a malfunction of the MP920.
• Always turn OFF the power supply to the Module before installing it.
• Insert the connectors of the cables that are to be connected to the MP920 Modules and
secure them well.
Incorrect insertion of the connectors may result in a malfunction of the MP920.
CAUTION
CAUTION
Module mounting screw
(Use an M4 Phillips screw driver.)

viii
Wiring
• Always connect a power supply that meets the given specifications.
Connecting an inappropriate power supply may cause fires.
• Wiring must be performed by qualified personnel.
Incorrect wiring may cause fires, product failure, or electrical shocks.
• Do not accidentally leave foreign matter such as wire chips on the Mounting Base or in
the Module when wiring.
This may cause fires, failures, and malfunctions.
CAUTION
• Always ground the FG terminal to a ground resistance 100Ωor less.
Failure to ground the MP920 may result in electrical shocks or malfunctioning.
Select, separate, and lay external cables correctly.
• Consider the following items when selecting the I/O signal lines (external cables) to
connect the MP920 Module to external devices.
• Mechanical strength
• Noise interference
• Wiring distance
• Signal voltage, etc.
• Separate the I/O signal lines from the power lines both inside and outside the control
panel to reduce the influence of noise from the power lines.
If the I/O signal lines and power lines are not separated properly, malfunctioning may result.
MANDATORY
Steel separator
Example of Separated External Cables
Power
circuit
cables
General
control cir-
cuit cables
Digital I/O
signal
cables

ix
Application
Maintenance
• Do not touch any Module terminals when the system power is ON.
There is a risk of electrical shock.
WARNING
• Do not attempt to modify the MP920 programs, force outputs, switch between RUN and
STOP, or perform other similar operations while the MP920 is operating without know-
ing the direct and indirect consequences of the operation.
Incorrect programming or operation may damage the equipment or cause an accident.
CAUTION
• Make sure that the polarity of the Module’s built-in battery is correct. The battery must
be installed correctly and must not be charged, disassembled, heated, thrown into fire,
or short-circuited.
Improper handling may cause the battery to explode or ignite.
WARNING
• Do not attempt to disassemble or modify the MP920 Modules in any way.
Doing so can cause fires, product failure, or malfunctions.
• The customer must not replace any built-in fuses.
If the customer replaces a built-in fuse, the MP920 Module may malfunction or break down.
The built-in fuse must always be replaced by Yaskawa service staff.
PROHIBITED

x
General
Always note the following to ensure safe use.
• MP920 was not designed or manufactured for use in devices or systems directly related
to human life. Users who intend to use the product described in this manual for special
purposes such as devices or systems relating to transportation, medical, space avia-
tion, atomic power control, or underwater use must contact Yaskawa Electric Corpora-
tion beforehand.
• MP920 has been manufactured under strict quality control guidelines. However, if this
product is to be installed in any location in which a failure of MP920 involves a life and
death situation or in a facility where failure may cause a serious accident, safety
devices MUST be installed to minimize the likelihood of any accident.
• Drawings in this manual show typical product examples that may differ somewhat from
the product delivered.
• This manual may change without prior notice due to product improvements and specifi-
cation changes or for easier use. We will update the manual number of the manual and
issue revisions when changes are made. The revision number of the revised manual
appears on the back of the manual.
• Contact your nearest Yaskawa sales representative or the dealer from whom you pur-
chased the product and quote the manual number on the front page of the manual if
you need to replace a manual that was lost or destroyed.
• Contact your nearest Yaskawa sales representative or the dealer from whom you pur-
chased the product to order new nameplates whenever a nameplate becomes worn or
damaged.
• Products modified by the customer are not covered by the Yaskawa warranty, nor does
Yaskawa assume any liability for injury or damage that may result from such modifica-
tions.

xi
CONTENTS
Using this Manual- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - iii
Safety Information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - vi
Safety Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - vii
1 Communications Modules
1.1 Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
1.1.1 Communications Modules - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1-2
1.1.2 Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1-4
1.1.3 General Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1-5
1.2 Communications Software- - - - - - - - - - - - - - - - - - - - - - - - - 1-6
1.2.1 Communications Processing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1-6
1.2.2 Communications Processing Software - - - - - - - - - - - - - - - - - - - - - - -1-7
1.2.3 Communications Process - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1-7
1.2.4 Application Software - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1-8
2 Communications Modes
2.1 Communications Modes - - - - - - - - - - - - - - - - - - - - - - - - - - 2-2
2.1.1 Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2-2
2.2 Link Communications - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-3
2.2.1 Link Allocation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2-3
2.2.2 Conceptual Diagram of Link Communications - - - - - - - - - - - - - - - - - -2-3
2.2.3 Communications Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2-4
2.3 Message Communications - - - - - - - - - - - - - - - - - - - - - - - - 2-5
2.3.1 MEMOBUS Message Transmissions - - - - - - - - - - - - - - - - - - - - - - - -2-5
2.3.2 General-purpose Message Transmissions - - - - - - - - - - - - - - - - - - - -2-6
2.4 Engineering Communications - - - - - - - - - - - - - - - - - - - - - - 2-7
2.4.1 Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -2-7
3 Communications Protocols
3.1 Overview of Communications Protocols - - - - - - - - - - - - - - - 3-2
3.1.1 List of Communications Protocols - - - - - - - - - - - - - - - - - - - - - - - - - -3-2
3.1.2 Communications Protocols and Message Communications - - - - - - - -3-3
3.2 Protocol Functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-4
3.2.1 Extended MEMOBUS Protocol - - - - - - - - - - - - - - - - - - - - - - - - - - - -3-4
3.2.2 MEMOBUS Protocol - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3-6
3.2.3 MELSEC-A Protocol - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3-7
3.2.4 OMRON Protocol - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-10
3.2.5 No Protocol Mode (Through Mode) - - - - - - - - - - - - - - - - - - - - - - - -3-12
3.3 Sample Programming Example - - - - - - - - - - - - - - - - - - - - 3-13
3.3.1 Master Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3-13
3.3.2 Slave Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -3-15

xii
4 Communications Process
4.1 Communications Process - - - - - - - - - - - - - - - - - - - - - - - - - 4-2
4.1.1 Overview- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-2
4.1.2 Opening the Communications Process - - - - - - - - - - - - - - - - - - - - - - 4-2
4.2 Communications Port Settings- - - - - - - - - - - - - - - - - - - - - - 4-4
4.2.1 Serial Communications Ports - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-4
4.2.2 CP-215 Communications Port Settings - - - - - - - - - - - - - - - - - - - - - - 4-7
4.2.3 CP-218 Communications Port Settings - - - - - - - - - - - - - - - - - - - - - 4-11
4.3 Setting the Logical Port Numbers- - - - - - - - - - - - - - - - - - - 4-13
4.3.1 Setting the MPE720 Logical Port Numbers- - - - - - - - - - - - - - - - - - - 4-13
5 215IF Module
5.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-3
5.1.1 Standard System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-3
5.1.2 System Configuration Using the Relay Function - - - - - - - - - - - - - - - - 5-4
5.2 Part Names - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-5
5.2.1 215IF Module External Appearance- - - - - - - - - - - - - - - - - - - - - - - - - 5-5
5.2.2 Setting Switches - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-6
5.3 Module Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-10
5.3.1 Hardware Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-10
5.3.2 Communications Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-10
5.4 Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-12
5.4.1 215IF Connection Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-12
5.4.2 Precautions on Wiring Communications- - - - - - - - - - - - - - - - - - - - - 5-13
5.4.3 Token Passing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-14
5.4.4 Tokens - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-15
5.5 CP-215 Transmission Definitions - - - - - - - - - - - - - - - - - - - 5-17
5.5.1 Overview of CP-215 Transmissions - - - - - - - - - - - - - - - - - - - - - - - - 5-17
5.5.2 Opening the CP-215 Transmission Definitions Window - - - - - - - - - - 5-18
5.5.3 The CP-215 Transmission Definitions Window Menus - - - - - - - - - - - 5-19
5.5.4 Setting CP-215 Transmission Definitions - - - - - - - - - - - - - - - - - - - - 5-20
5.5.5 Saving CP-215 Transmission Definitions Data - - - - - - - - - - - - - - - - 5-28
5.5.6 Deleting CP-215 Transmission Definitions Data - - - - - - - - - - - - - - - 5-28
5.6 Relay Function- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-29
5.6.1 Relays Between Networks - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-29
5.6.2 Relay Processing Flow - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-30
5.6.3 Example of a Network Configuration Using the Relay Function - - - - 5-30

xiii
5.7 CP-215 Repeaters - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-36
5.7.1 CP-215 Repeaters - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5-36
5.7.2 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-38
5.7.3 Specifications Common to All CP-215 Repeaters- - - - - - - - - - - - - - -5-44
5.7.4 CP-215 Repeater-TT - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5-49
5.7.5 CP-215 Repeater-TC - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5-50
5.7.6 CP-215 Repeater-TP - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5-52
5.7.7 CP-215 Repeater-TS2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5-53
5.7.8 CP-215 Repeater-TS5 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5-54
6 217IF Module
6.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-2
6.1.1 Standard System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - -6-2
6.1.2 System Configuration with Controllers Manufactured
by Other Companies- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -6-3
6.2 Part Names - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-4
6.2.1 217IF Module - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -6-4
6.3 Module Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-7
6.3.1 Hardware Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -6-7
6.3.2 Communications Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - -6-7
6.3.3 Time Required for Communications - - - - - - - - - - - - - - - - - - - - - - - - -6-8
6.4 Cables- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-10
6.4.1 RS-232C Interface Cables- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-10
6.4.2 RS-422/485 Interface Cables- - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6-11
6.5 CP-217 Transmission Definitions - - - - - - - - - - - - - - - - - - - 6-15
6.5.1 Overview of CP-217 Transmissions - - - - - - - - - - - - - - - - - - - - - - - -6-15
6.5.2 Opening the CP-217 Transmission Definitions Window - - - - - - - - - -6-16
6.5.3 The CP-217 Transmission Definitions Window Menus - - - - - - - - - - -6-16
6.5.4 Setting CP-217 Transmission Definitions Data- - - - - - - - - - - - - - - - - 6-17
6.5.5 Saving CP-217 Transmission Definitions Data- - - - - - - - - - - - - - - - -6-20
6.5.6 Deleting CP-217 Transmission Definitions Data- - - - - - - - - - - - - - - -6-20
6.6 217IF Communications Protocols - - - - - - - - - - - - - - - - - - 6-21
6.6.1 MEMOBUS Communications- - - - - - - - - - - - - - - - - - - - - - - - - - - - -6-21
6.6.2 MELSEC Communications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -6-22
6.6.3 OMRON Communications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -6-27
7 218IF Module
7.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-3
7.1.1 Standard System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - -7-3
7.1.2 10Base-T Connection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -7-4
7.2 Part Names - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-5
7.2.1 218IF Module - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -7-5
7.2.2 Setting Switches- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -7-6

xiv
7.3 Module Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-7
7.3.1 Hardware Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-7
7.3.2 Communications Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-7
7.3.3 Module Startup - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-8
7.4 Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-11
7.4.1 218IF Connection Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-11
7.5 CP-218 Transmission Definitions - - - - - - - - - - - - - - - - - - - 7-12
7.5.1 Overview of CP-218 Transmissions - - - - - - - - - - - - - - - - - - - - - - - - 7-12
7.5.2 Opening the CP-218 Transmission Definitions Window - - - - - - - - - - 7-12
7.5.3 The CP-218 Transmission Definitions Window Menu - - - - - - - - - - - 7-13
7.5.4 Setting CP-218 Transmission Definitions - - - - - - - - - - - - - - - - - - - - 7-14
7.5.5 Transmission Parameter Settings - - - - - - - - - - - - - - - - - - - - - - - - - 7-14
7.5.6 Saving CP-218 Transmission Definitions Data - - - - - - - - - - - - - - - - 7-26
7.5.7 Deleting CP-218 Transmission Definitions Data - - - - - - - - - - - - - - - 7-27
7.6 Connecting 218IF Modules - - - - - - - - - - - - - - - - - - - - - - - 7-28
7.6.1 218IF Communications Protocols - - - - - - - - - - - - - - - - - - - - - - - - - 7-28
7.6.2 Communications Ladder Logic Programming - - - - - - - - - - - - - - - - - 7-29
7.7 Connection with Devices Manufactured
by Other Companies - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-33
7.7.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-33
7.7.2 Socket Communications Flow - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-34
7.7.3 Data Format - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-35
7.7.4 Precautions on Creating Data Using a Personal Computer - - - - - - - 7-35
7.7.5 Programming Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-36
7.8 Connections with MELSEC - - - - - - - - - - - - - - - - - - - - - - - 7-38
7.8.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-38
7.8.2 Message Flow - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-38
7.8.3 Programming- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-39
7.8.4 MELSEC Commands - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-39
7.8.5 MELSEC Devices - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-41
7.8.6 MP900-Series Machine Controller and MELSEC Register Maps - - - 7-43
7.9 Troubleshooting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-44
8 Example Communications Module Applications
8.1 Connection to a Display Device - - - - - - - - - - - - - - - - - - - - - 8-3
8.1.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-3
8.1.2 Cable Specifications- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-4
8.1.3 217IF Transmission Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-7
8.1.4 GP-450 Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-8
8.1.5 MSG-RCV Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-9
8.2 Connection to a SYSMAC PLC - - - - - - - - - - - - - - - - - - - - 8-10
8.2.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-10
8.2.2 Cable Specifications- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-10
8.2.3 217IF Transmission Settings- - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-13
8.2.4 SYSMAC PLC Settings (C28H) - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-13
8.2.5 MSG-SND Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-16

xv
8.3 Connection with MELSEC - - - - - - - - - - - - - - - - - - - - - - - - 8-17
8.3.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-17
8.3.2 Cable Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8-17
8.3.3 217IF Transmission Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-19
8.3.4 MELSEC Settings (AJ71UC24 Example) - - - - - - - - - - - - - - - - - - - -8-19
8.3.5 MSG-SND Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-22
8.4 Connection to a Temperature Controller - - - - - - - - - - - - - - 8-23
8.4.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-23
8.4.2 Cable Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8-24
8.4.3 217IF Transmission Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-26
8.4.4 Temperature Controller Settings- - - - - - - - - - - - - - - - - - - - - - - - - - -8-27
8.4.5 MSG-SND and MSG-RCV Functions - - - - - - - - - - - - - - - - - - - - - - -8-28
8.5 Connection to an Inverter - - - - - - - - - - - - - - - - - - - - - - - - 8-30
8.5.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-30
8.5.2 Cable Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8-30
8.5.3 217IF Transmission Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-32
8.5.4 Inverter Constants Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8-32
8.5.5 MSG-SND Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-33
8.6 Modem-to-Modem Connection - - - - - - - - - - - - - - - - - - - - 8-34
8.6.1 System Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-34
8.6.2 Cable Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8-34
8.6.3 217IF Transmission Master Settings- - - - - - - - - - - - - - - - - - - - - - - -8-36
8.6.4 MP930 Slave Settings- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -8-36
8.6.5 MSG-SND and MSG-RCV Functions (MEMOBUS Master)- - - - - - - - 8-37
Appendix A System Functions
A.1 SEND MESSAGE Function (MSG-SND) - - - - - - - - - - - - - - A-2
A.1.1 Basic Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-2
A.1.2 Parameter List (PARAM) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-3
A.1.3 Parameter Details - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A-4
A.1.4 Inputs - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A-10
A.1.5 Outputs - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A-12
A.2 RECEIVE MESSAGE Function (MSG-RCV)- - - - - - - - - - - A-13
A.2.1 Basic Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A-13
A.2.2 Parameter Lists (PARAM) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A-14
A.2.3 Parameter Details - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A-15
A.2.4 Inputs - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A-19
A.2.5 Outputs - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -A-20

xvi
Appendix B 218IF Messages
B.1 Extended MEMOBUS Messages- - - - - - - - - - - - - - - - - - - - B-2
B.1.1 Message Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-2
B.1.2 MEMOBUS Binary Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-5
B.1.3 MEMOBUS ASCII Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-16
B.1.4 General-purpose Message Binary Mode - - - - - - - - - - - - - - - - - - - - B-16
B.1.5 General-purpose Message ASCII Mode- - - - - - - - - - - - - - - - - - - - - B-17
B.2 MEMOBUS Messages - - - - - - - - - - - - - - - - - - - - - - - - - - B-18
B.2.1 Message Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-18
B.2.2 MEMOBUS RTU Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-19
B.2.3 MEMOBUS ASCII Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-25
B.3 General-purpose Messages - - - - - - - - - - - - - - - - - - - - - - B-26
B.3.1 Message Configuration - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - B-26
B.3.2 General-purpose Binary Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - B-27
B.3.3 General-purpose ASCII Mode- - - - - - - - - - - - - - - - - - - - - - - - - - - - B-27
Appendix C C Language Sample Programs
C.1 Sample Programs for Master Station - - - - - - - - - - - - - - - - - C-2
C.1.1 TCP (When Using Extended MEMOBUS Protocol (SFC = 09)) - - - - - C-2
C.1.2 UDP (When Using Extended MEMOBUS Protocol (SFC = 09)) - - - - -C-7
C.2 Sample Programs for Slave Station - - - - - - - - - - - - - - - - - - C-9
C.2.1 TCP (When Using Extended MEMOBUS Protocol)- - - - - - - - - - - - - - C-9
C.2.2 UDP (When Using Extended MEMOBUS Protocol) - - - - - - - - - - - - C-15
Appendix D Wiring Communications
D.1 In-panel Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-3
D.1.1 Connection Methods - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -D-3
D.1.2 In-panel Cables- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-12
D.1.3 In-panel Wiring Separation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-13
D.1.4 Shield Treatment - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-13
D.1.5 Exposed Conductor Length - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-13
D.2 Indoor Panel-to-Panel Wiring - - - - - - - - - - - - - - - - - - - - - D-14
D.2.1 Panel-to-Panel Cable Connections - - - - - - - - - - - - - - - - - - - - - - - - D-14
D.2.2 Panel-to-Panel Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-16
D.2.3 Wiring Separation - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-16
D.2.4 Shield Treatment - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-16
D.2.5 Exposed Conductor Length - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-16
D.3 Outdoor Panel-to-Panel Wiring - - - - - - - - - - - - - - - - - - - - D-17
D.3.1 Wiring Precautions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-17

xvii
D.4 Wiring Optical Fiber Cables - - - - - - - - - - - - - - - - - - - - - - D-19
D.4.1 In-panel Wiring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-19
D.4.2 Indoor and Outdoor Panel-to-Panel Optical Wiring - - - - - - - - - - - - D-19
D.5 Transmission Line Components - - - - - - - - - - - - - - - - - - - D-25
D.5.1 215IF Transmission Line Components - - - - - - - - - - - - - - - - - - - - - D-25
D.5.2 217IF Transmission Line Components - - - - - - - - - - - - - - - - - - - - - D-26
D.5.3 CP-215 Repeater Transmission Line Components - - - - - - - - - - - - D-28
D.6 Optical Cable Specifications - - - - - - - - - - - - - - - - - - - - - - D-34
D.6.1 H-PCF Cable Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - D-34
D.6.2 Crystal Fiber Cords for Short Wavelength- - - - - - - - - - - - - - - - - - - D-35
D.6.3 Crystal Fiber Cords for Long Wavelength - - - - - - - - - - - - - - - - - - - D-36
D.6.4 Specifying Detailed Order Patterns - - - - - - - - - - - - - - - - - - - - - - - D-37
Appendix E Module Appearance
E.1 215IF Module - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-2
E.2 217IF Module - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-3
E.3 218IFA Module - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - E-4
INDEX
Revision History

1-1
1
1
Communications Modules
This chapter gives an overview of the Communications Modules and the com-
munications software that can be used for the MP900-Series Machine Control-
lers.
1.1 Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1-2
1.1.1 Communications Modules - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-2
1.1.2 Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-4
1.1.3 General Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-5
1.2 Communications Software - - - - - - - - - - - - - - - - - - - - - - - -1-6
1.2.1 Communications Processing - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-6
1.2.2 Communications Processing Software - - - - - - - - - - - - - - - - - - - - - - 1-7
1.2.3 Communications Process - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-7
1.2.4 Application Software - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-8

1 Communications Modules
1.1.1 Communications Modules
1-2
1.1 Overview
This section describes the Communications Module that are provided as options in the MP920
and outlines their specifications.
1.1.1 Communications Modules
The following three Communications Modules are provided for the MP900-Series building-
block Machine Controllers:
• The 215IF Realtime Core Network Interface Module with link transmission functions.
This is a special Yaskawa network.
• The 217IF Serial Interface Module with RS-232C and RS-422/485 ports
• The 218IF Ethernet Interface Module with 10Base-T port
The following illustration lists the name, a brief description, and the appearance of each
Communications Module.
Table 1.1 Communications Modules
Module Name Overview Appearance
215IF A Yaskawa Realtime Core Network Interface Mod-
ule equipped with one communications line and
having a transmission speed of 4 Mbps.
A relay function can be used to access Machine
Controllers that are not directly connected to the
same network.
217IF A Serial Interface Module equipped with two RS-
232C lines and one RS-422/485 line.
218IF An Interface Module for the international Ethernet
standard equipped with one communications line.
Communications are easily achieved with control-
lers manufactured by other companies, personal
computers, workstations, and other devices.

1.1 Overview
1-3
1
RS-232C ports are standard features on MP920 and MP930 CPU Modules and can be used for commu-
nications even without an optional Communications Module. While some functions of the communi-
cations protocols for these Modules differ, the RS-232C ports are almost the same as those for the
217IF.
Module Name Overview Appearance
CPU Module
(standard serial
port)
An RS-232C interface with two com-
munications lines are standard features
on the CPU Module.
INFO
MP920 CPU
MP930 CPU
