Yetter 2967-035A User manual

2967-035A
RESIDUE MANAGER
FOR NO-TILL COULTERS
2565-487_REV_E 06/2021
YETTER MANUFACTURING CO.
FOUNDED 1930
Colchester, IL 62326-0358
Toll free: 800/447-5777
309/776-3222 (Fax)
Website: www.yetterco.com
E-mail: [e-mail]

2
FOREWORD
You’ve just joined an exclusive but rapidly
growing club.
For our part, we want to welcome you to the
group and thank you for buying aYetterProduct.
We hope your new Yetter implement will help
you achieve both increased productivity and
increased efficiency so that you may generate
more profit. This operator’s manual has been
designed into six major sections.
Foreword, Safety Precautions, assembly
instructions, Operation, parts identification and
troubleshooting.
It is important the owner/operator knows the
implement model number. Write the model
number in the space provided and use it in all
correspondence when referring to the
implement.
Throughout the manual references may be
made to left side and right side. These terms
are used as viewed from the operator’s seat
facing the front of the tractor.
This SAFETY ALERT SYMBOL
indicates important safetymessages in
the manual. When you see this symbol, be alert
to the possibility of PERSONAL INJURY and
carefully read the message that follows.
The word NOTE is used to convey information
that is out of context with the manual text. It
contains special information such as
specifications,techniques,referenceinformation
and other information of a supplementary
nature. The word IMPORTANT is used in the
text when immediate damage will occur to the
machine due to improper techniqueor operation.
Important will apply to the same information as
specified by note only of an immediate and
urgent nature.
It is the responsibility of the user to read the
operator’s manual and comply with the safe and
correct operating procedure and to lubricate and
maintain the product according to the
maintenance schedule in the operator’s manual.
The user is responsible for inspecting his
machine and for having parts repaired or
replaced when continued use of the product
would cause damage or excessive wear to the
other parts.
It is the user’s responsibility to deliver his
machine to the Yetter dealer who sold him the
product for service or replacement of defective
parts that are covered by the warranty policy.
If you are unable to understand or follow
the instructions provided in the
publication, consult you local Yetter
dealer or contact:
YETTER MANUFACTURING CO.
309/776-4111
800/447-5777
309/776-3222 (FAX)
Website: www.yetterco.com
E-mail: [e-mail]
WARRANTY POLICY
Yetter Manufacturing warrants all products manufactured and sold by it against defects in material.
This warranty being expressly limited to replacement at the factory of such parts or products as will
appear to be defective after inspection. This warranty does not obligate the Company to bear cost of
labor in replacement of parts. It is the policy of the company to make improvements without incurring
obligations to add them to any unit already sold. No warranty is made or authorized to be made, other
than herein set forth. This warranty is in effect for one year after purchase.
Model Number:_________________________
Dealer :___________________
Yetter Manufacturing warrants its own products only and cannot be responsible for damage to
equipment on which it is mounted.

SAFETY
A brief description of signal words that may be used in this manual:
CAUTION: Used as a general reminder of good safety practices or to direct attention to unsafe
practices.
WARNING: Denotes a specific potential hazard.
DANGER: Denotes the most serious specific potential hazard.
SAFETY PRECAUTIONS
You can make your farm a safer place to live and work if you observe the safety precautions given.
Study these precautions carefully and insist that those working with you and for you follow them.
Finally, remember this: an accident is usually caused by someone’s carelessness, neglect or
oversight.
WARNING
Never clean, lubricate or adjust a machine that is in motion. Always lower or block the implement
before performing service.
If the machine must be serviced in the raised position, jack or block it up to prevent it from accidentally
falling and injuring someone.
Do not allow riders on the tractor or implement.
Use speeds and caution dictated by the terrain being traversed. Do not operate on any slope steep
enough to cause tipping or loss of control.
Be sure all personnel are clear of the immediate area before operating.
Read and understand the operator’s manual and require all other persons who will operate the
equipment to do the same.
Be familiar with all tractor and implement controls and be prepared to stop engine and implements
quickly in an emergency.
CAUTION
Consult your implement and tractor operator’s manual for correct and safe operating practices.
Beware of towed implement width and allow safe clearance.
FAILURE TO HEED MAY RESULT IN PERSONAL INJURY OR DEATH.

4
TABLE OF CONTENTS
Introduction…………………………………………………………..pg. 2
Warranty……………………………….……………………………..pg. 2
Safety Information…………………………………………………...pg. 3
Table of Contents……………………………………………………pg. 4
Optional Equipment…………………………………………………pg. 4
Application/Use Guide………………………………………………pg. 5
Assembly Instruction…………………….………………………….pg.6-9
Operation……………………………...……………………………..pg. 10
Maintenance……………..…………………………………………..pg. 11
Parts Identification………………………………..………….…...pg.12-14

TITAN F.P.M. RESIDUE MANAGER
OPERATION / USE GUIDE
IMPORTANT: The 2967-035 Residue Manager Will Limit the full “up-travel” of the planter row
unit. Please check the amount of travel that the planter row unit has before going to the field to plant.
NOTE: The recommended height of a level planter toolbar frame is 18”-22”. Always visually check
seed spacing and depth-calibrate your equipment if necessary.
Solution to “UP” travel issue. Trim upper corners of face plate bracket.
If there is insufficient clearance between the residue manager wheels and the fertilizer coulter opener,
then a fertilizer extension bar is required to move the fertilizer coulter forward to have sufficient
clearance.

6
ASSEMBLY INSTRUCTIONS
2967-035 RESIDUE MANAGER ONLY
NOTE: Do not fully tighten the mounting
hardware at this time. Alignment
adjustments will be made once the R.M.
wheels are attached.
When using the 2967-035 Residue
Manager unit with out a coulter, attach the
2967-281 –Mount W.A. using 4) ½” x 1 ½”
bolts, large flat washers and lock nuts.
JD MAX EMERGE II COULTER
Use 3) ½” x 2” carriage bolts when mounting a JD
MEII coulter or a White single arm coulter
(700728036).
Use 4) ½” x 2” carriage bolts when mounting a JD
7000 coulter, Kinze double arm, White double arm,or
the Yetter 2960-130 Double Arm Coulter.
2960 SERIES II UNIT MOUNTED CONSERVATION COULTER
Use 2) ½” x 2” carriage bolts (upper holes), 1) ½” x 2”
hex bolt and a large flat washer (lower left hole) are
used when mounting the Yetter Series II coulter.

ASSEMBLY INSTRUCTIONS
STEP 1 Install the 2967-283 Adjustment Slide onto the right hand side of the 2967-282
Combo Arm. The adjustment slide should move freely on the combo arm.
STEP 2 Attach the combo arm assembly to the 2967-281 Mount Bracket using 2) 5/8” x 2”
bolts, flat washers, bushings, and lock nuts. Securely tighten the pivot hardware at this time.

8
ASSEMBLY INSTRUCTIONS
STEP 3. Install the 2984-326 Adjustment Pin through the adjustment holes of theslide (float)or through
the adjustment arm of the mount bracket (rigid) and secure with the 2570-448 Hairpin clip.

ASSEMBLY INSTRUCTIONS
STEP 4 Choose the mounting hole in which to attach the R.M. wheels. Both wheels mounted in
the front holes –wheels are interlocked. One wheel mounted in the front hole and one mounted in the
rear hole –wheels are offset. Both wheels mounted in the rear holes –wheels are spaced apart.
Attach the R.M. wheel/hub assemblies to the 2967-282 Combo Arm using 5/8” lock washers and hex
nuts. Adjust the bearing shield to top dead center, rotate slightly forward. Torque to 150 ft./lbs.
STEP 5 Align the residue manager wheels, conservation coulter (if used) to the planter opener
blades. The 2967-281 Mount Bracket has slotted holes in the faceplate to move the residue manager
wheels side to side; to be able to center the wheels on the seed furrow. Fully tighten mounting bolts.
Torque to 85 ft/lbs.

10
OPERATION
CAUTION: Where rocks are present the residue manager should be set in the “float”
position, not locked down.
STEP 1. Adjust the residue manager to move crop residue aside and not move any soil.
Adjustments to the residue manager may have to be made when changing field conditions
and type and amount of residue. Use the handle for leverage when changing depth settings.
“FLOAT SETTINGS”
To raise the wheels, lift the 2967-282 and move the slide toward the rear.
To lower the wheels move the slide toward the front.
“RIGID SETTING”
To raise the wheels, lift the 2967-282 Combo Arm to the desired position and insert the pin.
To lower the wheels, lower the combo arm to the desired position and insert the pin.
ROW CLEANER DO’S AND DON’TS
1. DO NOT move soil; Residue Managers are designed to move crop
residue only.
2. DO NOT operate planter at slow speeds, ground speed affects how
aggressive the spoke wheels are; operate at sufficient speed (4-6 mph)
to maintain good residue flow.
3. DO NOT expect 100% of crop residue to be cleared, it is not necessary
and would necessitate engaging the soil. The width of path cleared
depends on ground conditions, depth setting and ground speed.
4. DO expect to see wheels occasionally quit turning, indicates ideal
(shallow) setting which is not moving soil.
5. DO adjust toolbar frame height 20”-22” and drawbar correctly. Very
important to ensure planter openerwill follow ground contours
properly.
IMPORTANT: For proper operation, the planter frame must operate level (for, aft and side to side)
and at the correct height, typically 20”-22”.

MAINTENANCE
Regularly inspect the residue manager for loose or worn bolts. Repair and replace as
needed.
Storing the Equipment
Store the machine in an area away from human activity
Store machine in RAISED position.
Install service locks on all wheel cylinders.
At the end of the season, the machine should be thoroughly inspected and prepared
for storage. Repair or replace any worn or damaged components to prevent down
time at the start of the next season. Store machine under cover with all parts in
operating condition.
Clean machine thoroughly to remove all dirt, debris and crop residue, which
would hold moisture and cause rusting.
Inspect machine for worn or broken parts. See your Yetter Farm Equipment
dealer during the off-season so that parts or service can be acquired when
machine is not needed in the field.
Lubricate bearings as outlined in the Lubrication section
Paint all parts which are chipped or worn and require repainting.
Store machine in a clean, dry place with the planting unit out of the sun.
If the machine cannot be stored inside, cover with a waterproof tarpaulin and
tie securely in place.
Do not allow children to play on or around the machine

12
PARTS IDENTIFICATION
2967-035A-ST-FW

PARTS IDENTIFICATION
2966-140-ST-FW
2966-140-BW-FW

14
PARTS IDENTIFICATION
2966-141-FW

NOTES

16
2565-487_REV_E 06/2021
