Fitting Instructions
for YewdaleKestrel® Roller blinds
(KR20 & KR20S Top & Face fix)
yewdale.co.uk
Fitting Instructions
for YewdaleKestrel®Roller blinds
(KR20 & KR20S Top & Face fix)
Part no: 927

YewdaleKestrel® fitting instructions Part no: 9272
Fitting Instructions
YewdaleKestrel®Roller blinds (KR20 & KR20S Top & Face fix)
KR20T/F, KR20ST/F Roller Blind:
KR20T/F Roller Blind:
NB. The KR20T/F is not suitable for installations where there are unsupervised
children under the age of 42 months.
1. Unpack the blind and remove the blind from back bar and brackets.
2. Check the position and height of the blind, ensuring it hangs correctly and
that nothing will prevent the blind from collapsing if it needed to.
3. Fit back the bar and brackets to the substrate in accordance with drawings
shown in above, ensuring the correct type and quantity of brackets are used
with suitable fixing screws/plugs as per figures on page 3. It is important
that the bracket is securely fixed to the substrate using TWO fixing screws
and care must be taken to ensure that no ligature points are left once
installation has been completed. If a degree of float is required in the
magnet, the packing disc may be discarded.
1350mm 50mm
Glass

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 3
4. Lift the blind into position by suppressing the pin end of the blind located in
the idle end bracket and clicking the control end into place.
5. Lift the blind into position by suppressing the pin end of the blind located in
the idle end bracket and clicking the control end into place.
6. Once the blind is fitted and the bracket positioning has been confirmed by
testing, the push-in screw cover MUST be fitted ensuring that it is flush with
the bracket body. The push-in screw cover is intended to be a tight fit to
prevent unauthorized access to fixings.
K558PC: K555PC:

YewdaleKestrel® fitting instructions Part no: 9274
Fitting Instructions
YewdaleKestrel®Roller blinds (KR20 & KR20S Top & Face fix)
KR20ST/F Roller Blind:
1. Unpack the blind and remove the blind from the back bar and brackets.Check
the position and height of the blind ensuring it will hang correctly and that
nothing will prevent the blind from collapsing.
2. Fit the back bar and brackets to the substrate in accordance with the
drawings shown in figures on page 2, ensuring that the correct type and
quantity of brackets are used with suitable fixing screws/plugs as shown
in figures on page 3. It important that the bracket is securely fixed to the
substrate using TWO fixing screws and care must be taken to ensure that no
ligature points are left once installation has been completed. If a degree of
float is required in the magnet, the packing disc may be discarded.
3. The spring must be on the right-hand side unless the fabric is reverse rolled.
4. The spring would have been tensioned during the manufacturing process
but the tension can be increased or decreased if required.
5. If the fabric does not wind up completely when the blind is operated, greater
spring tension can be applied as follows:
a) Bring the blind down 250mm from its uppermost position.
b) Remove the blind from the brackets and roll the fabric by hand back onto
the roller.
c) Replace the blind in the brackets.
d) If tension is still not enough, repeat steps a to c.
e) If tension is too much follow the above but in reverse i.e. remove the blind
from the brackets and unroll the fabric by hand of the roller. Ensure the
blind is not over tensioned as it will result in the bottom bar crashing into
the blind and potentially jamming.

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 5
6. If the blind is installed outside the recess then adjusting the tension can be
done without taking the blind out of its brackets if preferred. Use a flat head
screwdriver through the hole in the bracket to either increase or decrease
the tension as desired.
7. Once the blind is fitted and the bracket positioning has been confirmed by
testing, the push-in screw cover MUST be fitted ensuring that it is flush with
the bracket body. The push-in screw cover is intended to be a tight fit to
prevent unauthorized access to fixings.

YewdaleKestrel® fitting instructions Part no: 9276
Fitting Instructions
YewdaleKestrel®Roller blinds (KR20 & KR20S Top & Face fix)
All Brackets
Discs should be horizontal and the centre of the gravity of the load should be
directly beneath the centre-line of the discs. Test the completed installation.
The downward force needed to part the brackets should never be more than
400N (40kg static load) at any point.
Warning
The magnetic element of the YewdaleKestrel®bracket is POWERFUL. Handle
with care. If attached to a flat steel surface it may be dicult to remove the
magnet. DO NOT PLACE NEAR SENSITIVE ELECTRONIC EQUIPMENT.
YewdaleKestrel®products are designed as standalone products only.
Care should be taken when assessing or arranging a room to ensure that
YewdaleKestrel®products cannot be misused in conjunction with any other
item, furniture or fixings in the room. It is the responsibility of the end user or
client to ensure the product is suitable for the environment it is being installed
in. YewdaleKestrel®products must be fitted by a qualified professional with
an up to date training certificate and in accordance with the manufacturer’s
instructions. Failure to do so could jeopardise the product’s eectiveness as
an anti-ligature system. All installations must be tested when complete to
ensure the downward force does not exceed the maximum nor is it breaking
under below normal force. It is highly recommended that sign o with proof of
testing is issued to the client after installation.

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 7

Yewdale, Enterprise Way,
Wickford, Essex SS11 8DH
Call [phone]
Fax [phone]
Email [email protected]
Visit yewdale.co.uk
For more information on all
Yewdale products, please call
the sales department.
