YOKOGAWA SMARTDAC+ GM User manual

Technical
Information
SMARTDAC+ GM and UPM100
Power Monitoring Package
Wiring and Setup Guide
TI 77C01H01-01EN
TI 77C01H01-01EN
©Copyright Oct. 2018
1st Edition Oct. 2018
Yokogawa Electric Corporation
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan

i
TI 77C01H01-01EN Oct.17, 2018-00
How to use this manual
This manual provides a technical description, installation precautions, and application examples
for the Power Monitoring Package, consisting of the SMARTDAC+ Data Acquisition System GM
and the UPM100 Power Monitor.
Notice
• The contents of this manual are subject to change without notice as a result of continuing
improvements to the instrument’s performance and functions.
• Everye󰀨orthasbeenmadetoensureaccuracyinthepreparationofthismanual.Should
any errors or omissions come to your attention, however, please inform Yokogawa Electric’s
saleso󰀩ceorsalesrepresentative.
• Under no circumstances may the contents of this manual, in part or in whole, be transcribed
or copied without our permission.
Trademarks
• Our product names or brand names mentioned in this manual are the trademarks or
registered trademarks of Yokogawa Electric Corporation (hereinafter referred to as
YOKOGAWA).
• Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• Adobe, Acrobat, and Postscript are either registered trademarks or trademarks of Adobe
Systems Incorporated.
• We do not use the TM or ® mark to indicate these trademarks or registered trademarks in
this user’s manual.
• All other product names mentioned in this user’s manual are trademarks or registered
trademarks of their respective companies.
Media No. IM 77C01H01-01EN 1st Edition : Oct. 2018 (YK)
All Rights Reserved Copyright © 2018, Yokogawa Electric Corporation

Blank Page

Toc-1
TI 77C01H01-01EN Oct.17,2018-00
SMARTDAC+ GM and UPM100
Power Monitoring Package
Wiring and Setup Guide
CONTENTS
TI 77C01H01-01EN
TOFC
How to use this manual ...........................................................................................i
1. Overview.................................................................................................... 1-1
2. Devicecongurationandrelateddocuments....................................... 1-2
3. Packagespecications............................................................................ 1-3
4. UPM connection settings ........................................................................ 1-4
5. Universal Viewer....................................................................................... 1-7
6. Power monitor wiring precautions......................................................... 1-8
7. Power package application................................................................... 1-12
Revision Information ...............................................................................................i

Blank Page

1-1
TI 77C01H01-01EN Oct. 17, 2018-00
1. Overview
The Power Monitoring Package is a power monitoring system designed for smallscale
applications. It consists of the SMARTDAC+ GM, the UPM100 Power Monitor, and a CTW
xedwiretypecurrenttransformer.Youcanalsoselectinstrumentsandcommunication
functions to meet your needs including RS-485 or Ethernet (with a VJET RS-485 to
Ethernet converter).

1-2
TI 77C01H01-01EN Oct. 17, 2018-00
2. Devicecongurationandrelated
documents
Devices in the system
Device Model(Ex.) Specications Notes
Data logger GM10-□□□/MT/MC/WH Supports MATH & reports/
communication channels/
integral bar graph
(*1)
Data logger power supply GM90PS-1N1W0/WH
Data logger base GM90MB-01N0
Power monitor UPM100-□□□□□-20
Current transformer CTW□□
*1: Please be sure to specify the option codes /MT, /MC and /WH.
Please be sure to specify / C3 for RS45 communication.
 Su󰀩xcode/WHcannotbecombinedwithsu󰀩xcode/AS.
Related documents
Generalspecications
Title Number
Data Acquisition System GM GS 04L55B01-01EN
Model UPM100 Universal Power Monitor GS 77C01H01-01EN
Models CTW15 and CTW35 Clamp-on Current Transformers GS 77C01W03-01E
Models CTW10, CTW20, CTW100, and CTW130 Clamp-on Current Transformers GS 77C01W02-01E
User’s manual
Title Number
Data Acquisition System GM User’s Manual IM 04L55B01-01EN
Data Acquisition System GM First Step Guide IM 04L55B01-02EN
Model GM10 Integration Bar Graph Function (/WH) User’s Manual IM 04L55B01-07EN
SMARTDAC+STANDARDHardwareConguratorUser’sManual IM 04L61B01-02EN
SMARTDAC+STANDARDIPAddressCongurator IM 04L61B01-03EN
SMARTDAC+ STANDARD Universal Viewer User’s Manual IM 04L61B01-01EN
UPM100 Universal Power Monitor User’s Manual IM 77C01H01-00EN
UPM100, UPM101 Universal Power Monitor Communications Functions User’s
Manual
IM 77C01H01-10EN
Models CTW15 and CTW35 Clamp-on Current Transformers IM 77C01W03-01E
Models CTW10, CTW20, CTW100, and CTW130 Clamp-on Current Transformers IM 77C01W02-01E
You can download new versions of electronic documents from the following website.
http://www.yokogawa.com/ns/powercert/im/

1-3
TI 77C01H01-01EN Oct. 17, 2018-00
3. Packagespecications
 Systemarchitectureexample
Ethernet
Report file
Monitor on a tablet
RS-485
PC
PC
Web Application
(Data display/UPM connection settings)
Hardware Configurator
(UPM connection settings)
Universal Viewer
(Data display)
Wi-Fi router
Max. connected power monitors (UPM100) GM10-1: 20
GM10-2: 30
Communicationspecications Select from the following:
RS-485 or Ethernet (RS-485/Ethernet converter; when using
VJET)
Functions You can acquire watt-hours from the power monitor (UPM100)
and display digital values, intetration bar graphs, and integral
trends on the web application. You can also create hourly
reports. Also, to assign power monitor channels and enter
formulas, you can automatically assign each required channel
simply by registering your devices on the UPM100 connected
hardwareconguratororthewebapplication’swizard.
Displays Integration bar graph, integration trend, digital, list
Display language English, Korean, Japanese
Web application display example

1-4
TI 77C01H01-01EN Oct. 17, 2018-00
4. UPM connection settings
UPMConnectionSettingsisasettingswizardthatimplementsalloftheGMsettingsneeded
to connect the GM and UPM and display integration bar graphs. By using UPM Connection
Settings, you can easily enter all of the settings needed for communication and display of integral
graphs.Youcanuseitwiththehardwarecongurator(version4.05.01orlater)andtheweb
application (version 4.05.01 or later).
Hardware Configurator/Web Application
UPM Connection settings
UPM connection settings
Display settings
Integral power calculation
UPMconnectionsettingsle
WithUPMConnectionSetup,youcansaveyoursettingstoale(.wzu).Later,whenexpanding
orchangingyourconguration,youcanloadthecurrentUPMconguration(savedsettings)on
UPM Connection Setup and easily edit the settings.

1-5
TI 77C01H01-01EN Oct. 17, 2018-00
UPMConnectionSettingsworkow
Select a communication mode for connecting the GM and UPM.
For Ethernet, select a gateway device.
Configure the settings (device tags, models, parameters,
connection destination numbers, etc.) of the connected UPM.
Configure UPM group names and groupings for displaying
integral graphs.
Start UPM Connection Settings
Precautions are displayed before UPM Connection Settings starts.
From this screen you can load UPM connection settings files.*
Apply settings on the GM.
Settings are complete.
Completed settings can be saved to a UPM Connection Settings file.*
Setup complete
Start UPM Connection Settings.
1
2
3
4
5
6
Welcome screen
Configure communication settings: Modbus master (RS-485),
Modbus client (Ethernet)
7
[How to connect the GM10
and UPM]
[Configuring the connected
UPM]
[Modbus communications
settings]
[Make UPM groups]
[Applying settings]
* A file containing the contents of the settings saved by UPM
Connection Settings. To expand or change configuration,
you can simply load and edit them on UPM Connection
Settings.

1-6
TI 77C01H01-01EN Oct. 17, 2018-00
Examplesofconnectionsforcommunication
RS-485 connection
PC
RS-485
Ethernet
GM
UPM 1
Slave
(Address: 2)
UPM 2
Slave
(Address: 3)
UPM 3
Slave
(Address: 4)
IP: 192.168.1.99
Master
(Address: 1)
IP: 192.168.1.1
Ethernet connection
PC
RS-485
Ethernet
GM
UPM 1
Unit 2
(Address: 2)
UPM 2
Unit 3
(Address: 3)
UPM 3
Unit 4
(Address: 4)
IP: 192.168.1.99
IP: 192.168.1.100
VJET
Server (gateway)
Client
IP: 192.168.1.1
Unit: 1
(Address: 1)
RS-485 and Ethernet connection
PC
RS-485
Ethernet
GM
UPM 1
Slave
(Address: 2)
UPM 2
Slave
(Address: 3)
UPM 3
Slave
(Address: 4)
IP: 192.168.1.99
RS-485
UPM 1
Unit 2
(Address: 2)
UPM 2
Unit 3
(Address: 3)
UPM 3
Unit 4
(Address: 4)
IP: 192.168.1.100
VJET
Server
Master
Client
Address 1
IP: 192.168.1.1
Unit 1
(Address: 1)

1-7
TI 77C01H01-01EN Oct. 17, 2018-00
5. Universal Viewer
Screens
Integral graph display
Legend, cursor value
display pane (fixed)
Date picker
Toolbar
Item Description
Date setting Specify the date of the integral graph to display.
Legend and cursor value
display area
The legend and cursor value are docked on the right edge of
the screen
Two graph comparison
You can compare two integral graphs of any dates.
Date picker
Toolbar
Item Description
Date setting (upper) Specify the date of the upper integral graph.
Date setting (lower) Specify the date of the lower integral graph.

1-8
TI 77C01H01-01EN Oct. 17, 2018-00
6. Power monitor wiring precautions
UPM100PowerMonitorwiringexample
 WiringwithoutaVT(3phase3wireexample)
Note: If not using a VT, do not ground P2.
With a VT Without a VT
Power supply Power supply
Load
Fuse Fuse
Load
This is an example with the UPM100, but the voltage input wiring is also the same on the PR300
and UPM101.
Selecting a fuse
If not using a VT, insert a fuse of 0.5–1.0 A into lines P1 and P3.
Setting the VT and CT ratios
What are the VT and CT ratios?
Generally, when measuring high voltage and high current transformer signals, you use a VT
(voltage transformer) and CT (current transformer). The ratio between the primary and secondary
voltage and current ratings are the VT and CT ratios. With these ratios, a power monitor can
convert the primary voltage and current of the VT and CT and display the electrical quantities.
VT ratio: VT primary/secondary voltage rating
Ex.: VT ratio = 6600 VAC/110 VAC = 60
CT ratio: CT primary/secondary current rating
Ex.: CT ratio = 500 AAC/5 AAC = 100
If not using a VT or CT, each ratio is 1.

1-9
TI 77C01H01-01EN Oct. 17, 2018-00
6600 VAC
500 AAC
6600VAC
Settings: VT ratio 60, CT ratio 100
Power monitor
110VAC
500AAC 5AAC
VT
CT
CT load rating and wiring length
●CT load rating
For the rated load, use a value within the sum of the wiring loss between the CT and the device
connected to the secondary side, and the input loss to the device connected to the secondary
side. The load rating notation could be, for example, “0.5 VA, 2.5 VA.”
CT
CT rated load ≧wiring loss + input loss of device connected to the secondary side
To calculate wiring loss, see “Checking the wiring distance and material” and
“Detailed example (approximation using the CTW10).”
Wiring distance Connected device
Device input lossWiring loss
●Checking the wiring distance and material
The wiring loss increases in proportion with the wiring distance. The total wiring length is the
round trip distance.
Approximate wiring material resistance (ex.)
 Nominalcrosssection1.25mm=approx.18Ω/km
 Nominalcrosssection2.0mm=approx.10Ω/km
● Detailedexample(approximationusingtheCTW10)
CT: Primary/secondary rated current: 100 A/1A
CT load rating: 0.5 VA
Wiring distance: 15 m, input loss of device connected to secondary side: 0.2 VA
• When using wiring material of nominal cross section 1.25 mm2
 WiringresistanceR=18Ω/km×0.015km×2(roundtrip)=0.54Ω
 Wiringloss≈I2R = (second. rated current)2×wiringresistance=1×1×0.54=0.54VA
 Condition:CTratedload≥wiringloss+inputlossofdevicecnctd.tosecondaryside
   0.5≥0.54+0.2=0.74VA
This does not meet the condition.

1-10
TI 77C01H01-01EN Oct. 17, 2018-00
• When using wiring material of nominal cross section 2.00 mm2
 WiringresistanceR=10Ω/km×0.015km×2=0.3Ω
 Wiringloss≈I2R = (secondary rated current)2×wiringresistance=1×1×0.3=0.3VA
 Condition:CTratedload≥wiringloss+inputlossofdevicecnctd.tosecondaryside
   0.5≥0.3+0.2=0.5VA
This does meet the condition.
CT handling precautions
●CT inspection and maintenance precautions
Do not perform work while measuring lines are live. If the secondary side is open while CT
currentisowing,highvoltageoccursonthesecondaryside.Thiscancauseinsulationto
degrade, and if left as-is, can cause burning and accidents and is extremely dangerous.
When maintenance is complete, before turning on the power, you must check the CT’s
secondary side connection (short).
TheCTWseriesofxedwiretypecurrenttransformershavebuilt-inhazardousvoltage
suppressors that function when the secondary side is open. In the unlikely case that the
secondary side is released, it will prevent burns and accidents.
When there is abnormal UPM100 power monitor measured data
Q. Voltage and current measurements on the power monitor are correct, but power integration
either doesn’t occur, or there are small values. What should I check?
A. Check the active power.
If the active power turns negative or extremely small, check the points below. The active
power is negative when the power is regenerating.
Points to check (3 phase 3 wire)
(1) Is the CT installed in the correct orientation?
(2) Is the CT installed to the R and T phases?
(3) Is the R phase side of the CT connected to 1S and 1L, and the T phase side connected to
3S and SL? Also check the CT secondary side polarity (k, l).
(4) Are R, S, and T wired to P1, P2, and P3?

1-11
TI 77C01H01-01EN Oct. 17, 2018-00
P1
P2
P3
1S
1L
3S
3L
(1)(2)(3)
(1)(2)(3)
(4)
3 phase 3 wire
R S T
FUSE
FUSE
Power supply
Load
k
K
K
l
L
L
k
l
(1) CT orientation
×
○
Power monitor terminal
Current input
Voltage input
Check the installation for other phase and wiring schemes as well.
Wiring RS-485 communication
Wiring for communication between the Data Acquisition System GM and the UPM100 Power
Monitor (RS-485 4 wire <=> 2 wire)
(FG)
Approximately 1.2 km maximum length (up to 31 units)
Ethernet
RS-485
SMARTDAC+ GM
(RDA-) (RDB+) (SDA-) (SDB+) (SG) (A-) (B+) (SG) (A-) (B+) (SG) (A-) (B+) (SG)
RS-485RS-485
UPM100
GM10 UPM100 UPM100
Terminator
120Ω
Terminator
120Ω
PC

1-12
TI 77C01H01-01EN Oct. 17, 2018-00
7. Power package application
 Exampleofsimultaneousmeasurementofquantitiesofvapor,gas,
and other substances
Youcanaddapulsemodule(foracquiringowmeterpulses)andmeasureowquantitiesof
power, vapor, and gas.
●System architecture
SMARTDAC+ GM
UPM100
Flow meter
Flow meter
RS-485
For the pulse input module, use the GX90XP from the SMARTDAC+ SMARTDAC+ series.

i
TI 77C01H01-01EN Oct. 17, 2018-00
Revision Information
Title : SMARTDAC+ GM and UPM100 Power Monitoring Package
Wiring and Setup Guide
Manual number : TI 77C01H01-01EN
Oct. 2018/1st Edition
Newly published
Written by Yokogawa Electric Corporation
Published by Yokogawa Electric Corporation
2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, JAPAN

Blank Page
