YOKOGAWA EJA564E User manual

IM-P-20200626-01
©Copyright 2020
1st Edition, October 2020
Yokogawa Corporation of America
2 Dart Road, Newnan, Georgia 30265 U.S.A.
Tel: [phone] Fax: [phone]
User’s
Manual Hygienic & Sanitary Pressure
Transmitter EJA564E
IM-P-20200626-01

2
IM-P-20200626-01
Hygienic & Sanitary Pressure Transmitter
EJA564E
CONTENTS
IM-P-20200626-01 1st Edition
1. Introduction...................................................................................................4
1.1 Description ........................................................................................................... 4
1.2 Barometric Reference ......................................................................................... 4
2. Dimensional Drawings.................................................................................5
3. Installing the Transmitter.............................................................................6
3.1 Installing Weld-On Nipple ................................................................................... 6
3.2 Installing Transmitter (Code W33) ..................................................................... 6
3.3 Mounting Position................................................................................................ 6
3.4 Mounting Position Effect..................................................................................... 6
3.5 Calibration ............................................................................................................ 6
3.6 Connection Terminal ........................................................................................... 7
3.7 Wiring .................................................................................................................... 7
4. Remaining .....................................................................................................8
4.1 External Load ....................................................................................................... 8
5. Display and Push Buttons...........................................................................9
5.1 Display Readout................................................................................................... 9
5.2 Summary Programming Points.......................................................................... 9
6. Explanation Programming Points ........................................................... 10
6.1 Zero Adjustment (ZERO)................................................................................... 10
6.2 Span Adjustment (SPAN) .................................................................................. 10
6.3 Cancel Mounting Position Effect...................................................................... 10
6.4 Display Setting of Units..................................................................................... 11
6.5 Output Selection 4-20 mA or 20-4 mA.............................................................. 11
6.6 Damping Adjustment......................................................................................... 11
6.7 Temperature Units ............................................................................................. 12
6.8 Device Setup....................................................................................................... 12
6.9 Readout............................................................................................................... 12
6.10 Burst Mode (HART) ............................................................................................ 12
6.11 Information ......................................................................................................... 13

3
IM-P-20200626-01
7. Programming ............................................................................................. 14
7.1 Programming with Hand Held Terminal .......................................................... 14
8. Specifications ............................................................................................ 16
9. Precautions and Warnings....................................................................... 17
Revision Information ........................................................................................... 18
7.2HART Commands and Parameters ................................................................. 15

4
IM-P-20200626-01
<1. Introduction>
1. Introduction
The EJA564E solid-state pressure and level
transmitters are based on a piezoresistive silicon
sensor, with a very high burst pressure. The
sensor element is mounted in a stainless steel
"foot".Atemperature sensor is mounted inside the
foot to and is used for active temperature
compensation. A strong stainless steel “flush”
diaphragm protects the sensor from the process
medium. A minimal amount of special oil fills the
chamber surrounding the sensor and transfers
pressure from the flush mounted diaphragm to the
sensor hydraulically.
Pressure on the sensor element creates a small
deection of the silicon substrate and bridge network.
The resulting strain in the silicon resistors causes a
change in the bridge resistance that is proportional to
the pressure being applied. The transmitter
electronics detect this change in the bridge
resistance and converts it into the measured value.
The amplifier system is based on a single Integrated
Circuit, which ensures perfect linearity in the output,
all within an accuracy of 0.2 %.
1.1 Description
The EJA564E transmitter is specially designed with
a flush mounted diaphragm so it fully meet the
needs of the food, pharmaceutical, chemical and
other industries. Standard wetted parts are made of
316L SST, other materials are also available, like
Hastelloy C. Various process connections can be
adapted and available for manufacture;
(1.5”, 2” and 3” tri-clamp), SMS (1.5” and 2”), dairy
milk couplings (DN 25, 40 and 50), flanges (DIN and
ANSI) and sanitary weld-on nipples (ø 48, 62 and
85 mm.), among others.
Certain variants of the EJA564E are designed to be
non-clogging and are capable of being cleaned
inside. Various process connection types are
manufactured according to 3-A (74-06)
requirements such as Tri-Clamp and others.
1.2 Barometric Reference
The EJA564E is a “relative transmitter” which means
that barometric changes will not affect the zero.
The venting is placed in the cover of the electronics
housing next to the cable entry and is the lter for the
barometric reference to atmospheric pressure.
The vent mechanism must be kept clean.

5
IM-P-20200626-01
<2. Dimensional Drawings>
2. Dimensional Drawings
nEJA564E- "T20" PROCESS CONNECTION
1/2" NPT Electrical Connection
M12 Electrical Connection
Note. Standard Drawings for all other connection types are available on request.

6
IM-P-20200626-01
<3. Installing the Transmitter>
3. Installing the Transmitter
The diaphragm of the transmitter is protected with
a special protection cap. Protect the diaphragm
until installation takes place. Take special care
with the fragile diaphragm.
3.1 Installing Weld-On Nipple
A certied welder should perform the installation of
the weld-on nipple. Weld with Argon, MIG or TIG,
with the smallest welding pin possible.
1. Cut a hole in the process vessel or pipe for
a precise t of the weld-on nipple. The hole
should be a tight t when coupled with the
weld-on nipple.
2. Prepare the hole by bevelling the edge to
accept ller material.
3. Remove the weld-on nipple from the
transmitter.
Remove the gasket and O-Ring out of the
weld-on nipple!
WARNING
Improper installation may result in distortion
of the weld-on nipple. Excessive heat will
distort the weld-on nipple. Weld in sections
as shown in the figure below and allow
adequate cooling between passes. To
reduce the chances of distortion to the weld-
on nipple, use a mandrel.
4. Position the weld-on nipple in the vessel hole
and tack six places. The weld sequence is
shown in the gure above.
5. Weld the weld-on nipple in place using 0.03
to 0.045 in. (0.762 to 1.143 mm) stainless rod
as ller material in the bevelled area. Adjust
amperage for penetration.
6. Remove the mandrel after the welding
operation.
3.2 Installing Transmitter
(Code W33)
1. After welding, clean up edges, and take care
of the inside nipple wall.
2. Make sure the O-ring (10) is properly located.
3. Improper installation of the O-ring can cause a
process leak.
4. Apply silicone grease to the O-ring (10),
diaphragm ring and the hole inside wall of
the weld-on nipple, this prevents galvanic cell
corrosion between transmitter and the nipple
inside.
5. Install the transmitter and x it with the SS M8
bolt.
3.3 Mounting Position
When the transmitter is mounted horizontally,
the cable gland must be pointed downwards.
Furthermore, 3-A certified units with leakage
detection holes in weld-on nipples should be on
the lowest point and pointing down 90 degrees
from the horizontal.
3.4 Mounting Position Effect
All transmitters are calibrated in a vertical position
(diaphragm points downwards). If the transmitter is
mounted in another position, there can be a slight
zero shift. (example 4.02 mA instead of 4.00 mA).
After installation of the transmitter,the zero must
be set to 4.00 mA with P103 (cancelsmounting
position effect). This will not affect the span.
3.5 Calibration
All transmitters are calibrated at the factory to the
customer specified range. If the calibration is not
specified, the transmitter will be calibrated to the
maximum span.
Determine (before welding) the position of
the electronics housing so that the cable
entry and the venting are in the right position.
These positions are fixed after welding.

7
IM-P-20200626-01
<3. Installing the Transmitter>
3.6 Connection Terminal
The figure below shows the wiring connection of the transmitter. The 2-wires must be connected to the
terminal board. The wiring terminals can be connected without a screwdriver. The opening levers of the
terminal can be lifted and pressed down by hand. Lift the opening levers of the terminals and insert the
corresponding wires. Press down the levers by hand. The terminal spring will close and the wire is clamped.
3.7 Wiring
The transmitter must always be connected to ground. The transmitter must be connected with standard
two-wire shielded cable. Do not run signal wiring in open trays with power wiring or near heavy electrical
equipment (Frequency controller or heavy pumps). Shielding must always be connected at the side of the power
supply. In case the process connection is already connected to ground (e.g. via the tank or pipe line) do not
connect the instrument to ground. Please ensure that the instrument is not connected to ground twice to prevent
an ‘earth loop’. In applications with synthetic process connections, the enclosure (internal or external) must be
connected to ground.
Reversing the polarity will not damage the transmitter, but the transmitter will not function until the + and – are
properly connected.
CAUTION
•Please ensure that the transmitter is not connected to ground twice to prevent an earth loop.
1
2
3
1Voltage Supply / Output Signal (4-20 mA)
2Internal Ground
3Terminal Connector
Insert the wires into the connector and
push the lever down by hand.

8
IM-P-20200626-01
4. Remaining
4.1 External Load
External loads must be placed in the negative side of the 2-wire loop. The minimum power supply is based on
the total circuit resistance. The maximum external load (RI max.) for 24 Vdc will be 600 Ω (Ohm).
CAUTION
•With a loop resistance of 250 Ω a power supply of at least 17 Vdc must be used.
<4. Remaining>
+
−
−
+
R
I
max. = Voltage - 12 V (min.)
20 mA
R

9
IM-P-20200626-01
5. Display and Push Buttons
The EJA564E has a high contrast display for optimal readout. The menu is controlled by 3 push buttons.
Navigate with the up and down through menus and measuring values.
Enter a menu and conrm selections with the menu button.
Display EJA564E
5.1 Display Readout
When the transmitter is powered, a startup screen with the software version and the pressure range appears for
a few seconds. After the startup screen the transmitter will automatically continue to the main screen with the
actual measurement reading.
5.2 Summary Programming Points
PROGRAM POINT NAME FUNCTION
P100 Menu-Exit menu Start and exit
P101 ZERO value Zero adjustment (ZERO 4 mA) with or without test pressure
P102 SPAN value Span adjustment (SPAN 20 mA) with or without test pressure
P103 MOUNT correction Cancel mounting position effect
P104 UNITS Selection of engineering units
P105 REVERSE mA Output selection: 4-20 mA or 20-4 mA
P106 DAMPING Adjustable damping: 0.00 to 25.00 seconds
P107 TEMP UNITS Temperature unit selection: Celsius or Fahrenheit
P108 DEVICE SETUP Conguration: Protection, HART, Display mode, Display update
P109 READOUT Readout options on display: Current, Unit, percentage and temperature
P110 BURST MODE Continuously broadcast a standard HART reply message
Push the up button to browse through various menus
and adjusting values.
Push the down button to browse through various
menus and adjusting values.
Push the menu button to enter menus or conrm a
selection.
<5. Display and Push Buttons>

10
IM-P-20200626-01
6.2 Span Adjustment
(SPAN)
This setting can be used to adjust
the range (SPAN) according to an
entered value or adjusted with or without an applied
pressure. The maximum pressure value that can be
measured: The measurement at ZERO (P101) +
the entered value SPAN (P102). If the ZERO (P101)
is increased, the maximum measured value will
automatically be set higher by the same amount as
the zero. This will be explained step by step by an
example.
6. Explanation of Programming Points
6.1 Zero Adjustment
(ZERO)
The transmitter is set to 0 mbar at
atmospheric pressure.
The ZERO can be adjusted at a lower or higher
point. This will be explained step by step by an
example.
Example: Increase ZERO to 100 mBar.
1. The measuring unit of the transmitter is set to
mBar. If not, this can be selected by choosing
the right measuring unit in program point
P104.
2. Navigate to program point P101, and push the
menu button to enter the menu.
3. The actual measured value appears on the
display.
4. Increase this value with the arrow button to
100 mBar, and push the button until
save appearson the display.
5. The transmitter will return to the home screen.
The measurement value at atmospheric
pressure is now -100 mBar. At an applied
pressure of 100 mbar the transmitter will
display 0 mbar.
The transmitter can be adjusted to zero in a real
process situation. The transmitter will measure the
pressure in an actual process. This measurement
will be used as the zero value (4 mA).
1. Go to the home screen, the transmitter will
display the actual measured value.
2. Push the button until the actual measured
zero andthe message ZERO PUSHED
appearson the display.
3. The transmitter will return to home screen.
Example: Measurement range 0 – 2000 mbar.
1. The span must be set to 2000 mbar
2. Navigate to program point P102, and push the
menu button to enter the menu.
3. Adjust the SPAN with the push buttons to
2000 mbar and push the button until save
appearson the display.
4. The transmitter will return to the home screen.
The span can also be adjusted to a real process
situation. The transmitter will measure the pressure
in an actual process. This measurement will be used
as the span value (20 mA).
1. Go to the home screen, the transmitter will
display the actual measured value.
2. Push the button until the actual measured
span and the message SPAN
PUSHED appearson the display.
3. The transmitter will return to home screen.
TIP
P102 is the adjustment of the total span.
When a compound range must be adjusted
(for example -1 till +3 bar), a span of 4 bar
must be programmed.
The Zero (P101) must be set at -1 bar. The
transmitter is adjusted at - 1 bar = Zero and +3
bar = Span.
6.3 Cancel Mounting
Position Effect
All transmitters are calibrated
vertically. If the transmitter is
installed horizontally, the transmitter has a small
“mounting position” effect on the zero. For example,
the pressure value displayed may be 0.002 mbar
instead of 0.000 mbar.
1. Navigate to program point P103, and push the
menu button to enter the menu.
2. Two choices appear on the screen: Set and Reset.
<6. Explanation Programming Points>

11
IM-P-20200626-01
Choosing Set will adjust the zero to 0.000 mbar in
the mounting position when applicable.
•Select Set, and push the menu button to
conrm.
•The corrected is value is shown on the display.
•Push the menu button to save.
Choosing Reset will put the transmitter back t
the factory setting. (vertical adjustment)
• Select Reset, and push the menu button to
conrm to reset back to factory setting.
•The transmitter will return to the home screen.
CAUTION
•Do not apply pressure when executing
“Cancel mounting position effect”
6.4 Display Setting
of Units
Various engineering units can be
displayed on the display.
1. Navigate to program point P104, and push the
menu button to enter the menu.
2. Several engineering units can be selected.
Each selected engineering unit is
automatically converted to the correct value of
the corresponding unit.
3. Navigate through this menu and choose the
required unit, push the menu button to confirm.
4. The transmitter will return to the home screen.
The measured reading will be displayed in the
selected unit in the home screen.
CAUTION
•The selected pressure unit is only visible
on the display when UNITS is chosen in
program point P109.
6.5 Output Selection
4-20 mA or
20-4 mA
Factory setting = 4 - 20 mA
1. Navigate to program point P105, and push the
menu button to enter the menu.
2. Two choices appear on the screen: 4-20 and
20-4
3. Make an output choice and push the menu
button to conrm.
4. The transmitter will return to the home screen.
6.6 Damping
Adjustment
The transmitter has an adjustable
damping between 0.00 to 25.00 seconds.
Factory setting = 0.00 seconds
•Navigate to program point P106, and push the
menu button to enter the menu.
•Two choices appear on the screen: Set and
Reset
Choosing Set allows a value to be set between 0.00
and 25.00 seconds.
•Select Set, and push the menu button to
conrm.
• Adjust the damping with the push buttons and
push the menu button to conrm.
•The transmitter will return to the home screen.
Choosing Reset will put the transmitter back to
factory setting (0.00 seconds)
•Select Reset, and push the menu button to
conrm to reset back to factory setting.
•The transmitter will return to the home screen.
<6. Explanation Programming Points>

12
IM-P-20200626-01
6.7 Temperature
Units
In this menu,the preferred
temperature unit can be selected.
1. Navigate to program point P107, and push the
menu button to enter the menu.
2. Two choices appear on the screen: Celsius
and Fahrenheit.
3. Make a choice and push the menu button to
conrm.
4. The transmitter will return to the home screen.
6.8 Device Setup
In this menu, several operational
settings can be made for the
transmitter and the display.
1. Navigate to program point P108, and push the
menu button to enter the menu.
2. Five choices appear on the screen:
LocProtect: The transmitter can be protected
against local adjustments
ComProtect: The transmitter can be
protected against adjustments with HART.
HART: Option for HART 5 and HART 7
communication.
DispMode: Option for turning the display on
or off.
Disp.Upd.: Option to adjust the refresh rate of
the measuring value on the display between
0.0 to 5.0 seconds. For example when this
value is set to 2.0 seconds, the measuring
value on the display will be refreshed every 2
seconds.
•Select Set, and push the menu button to
conrm.
•Adjust the setting with the push buttons
and conrm with the menu button.
•The transmitter will return to the home
screen.
•Choosing Reset will put the transmitter
back to factory setting (0.0 seconds).
6.9 Readout
In this menu, the type of readout on
the display can be adjusted.
Factory Setting = Unit
1. Navigate to program point P109, and push the
menu button to enter the menu.
2. Four choices appear on the screen:
Current: Current value (4 - 20 mA)
Unit: Pressure unit (Selected in P104)
Percentage: 0 - 100 %
Temperature: Actual process temperature
(°C or °F) Indication, accuracy depending on
sensor position.
3. Navigate to the desired choice, conrm by
pushing the menu button.
4. The transmitter will return to the home screen.
6.10 Burst Mode
(HART)
The transmitter can be congured
for Burst mode. This will enable continuously
broadcasting standard HART reply messages.
1. Navigate to program point P110, and push the
menu button to enter the menu.
2. Five choices appear on the screen: Mode
Cntrl, Cmd number, Message, Period and
Trigger
3. Select Mode Cntrl, and push to conrm.
4. Two choices appear on the screen: On and
Off
• Choose On to turn on burst mode.
•Choose Off to turn off burst mode.
5. Select Message to select the burst message
0,1,2 or 3 and push the menu button to
conrm.
6. Select Cmd number, and push the menu
button to conrm.
Five choices appear on the screen:
•Cmd 01 = PRIMARY VARIABLE
•Cmd 02 = CURRENT AND PERCENT
OF RANGE
•Cmd 03 = DYNAMIC VARIABLES AND
CURRENT
<6. Explanation Programming Points>

13
IM-P-20200626-01
•Cmd 09 = DEVICE VARIABLES WITH
STATUS
•Cmd 48 = ADDITIONAL
TRANSMITTER STATUS
Choose the preferable burst mode, and push
menu button to conrm.
7. Select Period, and push the menu button to
conrm.
Two choices appear on the screen: Max Time
and Min Time
•Select Max Time to set the maximum
amount of time when the message will
be sent.This value can be set from 0.5
to 3600 seconds.
•Select Min Time to set the minimum
amount of time when the message will
be send. This value can be set from 0.5
to 3600 seconds.
Enter the preferred value, and push the menu
button to conrm.
8. Select Trigger, and push the menu button to
conrm.
9. Five choices appear on the screen:
Continuous = The Burst message is send
continuously.
Windowed = The Burst message is triggered
when the measured value deviates more than
the specied trigger value.
Rising = The Burst message is triggered when
the measured value rises above the triggered
value.
Falling = The Burst message is triggered
when the measured value falls below the
triggered value.
On-Change = The Burst message is triggered
when any value in the measuring changing.
Choose the desired burst mode, and set the
preferred parameters.
6.11 Information
This menu summarizes information
about the conguration of the
transmitter.
Below the contents of the information screen.
V No: Software Version number
No: Serial number of the transmitter
Z: Zero adjustment
S: Span adjustment
Da: Out delay on display
O: Output (4-20 mA or 20-4 mA)
Lpro: Local protection (on/off)
Tunit: Temperature unit (°C or °F)
Tph: Highest measured process temperature
Tpl: Lowest measured process temperature
Tah: Highest measured ambient temperature
Tal: Lowest measured ambient temperature
Tc no: Tag number
<6. Explanation Programming Points>

14
IM-P-20200626-01
7. Programming
7.1 Programming with Hand Held Terminal
CAUTION
•When using HART or a Hand Held Terminal (HHT), a minimum resistance of 250Ω must be present in
the loop of the 2-wire system. This is necessary for proper communication (see drawing below). A power
supply of at least 17 Vdc must be used.
The EJA564E can easily be programmed with the Hand Held Terminal (YHC HART Communicator).
Option 1: HART Hand Held terminal connected across the transmitter.
Option 2: HART Hand Held terminal connected across the loop resistor.
−
+
Power
Supply
250 Ω
17 - 36 Vdc
−
+
Power
Supply
250 Ω
17 - 36 Vdc
<7. Explanation - Programming Points>

15
IM-P-20200626-01
7.2HART Commands and Parameters
<7. Explanation - Programming Points>
Note
PVPressure Selected units (psi...mBar)
SV Sensor Temperature Selected units (Deg. F or C)
TVElectronic Temperature Selected units (Deg. F or C)
FV(Pressure) Same as PV
・Dynamic variables (PV,SV,TV,FV) and current can be read using HART Command #3.
・Device variables with Status can be read using HART Command #9.
Dynamic Variables (Command #3)

16
IM-P-20200626-01
8. Specications
<8.Specications>
Please refer to the General Specifications. Document GS-P-20200626-01 for model, suffix, option
codes and all required dimensional and electrical specifications.
The General Specificaitions listed below can be downloaded from the Yokogawa Corporation of
America website: https://www.yokogawa.com/us/solutions/products-platforms/field-instruments/
pressure-transmitters/hygienic-sanitary-transmitters/
nGeneral Specification List
Model Document Title Document No.
EJA564E, EJA565E Hygienic & Sanitary Pressure Transmitter GS-P-20200626-01

17
IM-P-20200626-01
9. Precautions and Warnings
CAUTION
• Check if the specications of the transmitter meet the needs of the process conditions
•When the EJA564E is used as a level transmitter, be aware of the place where the transmitter is
mounted. Here are some suggestions:
•DO NOT mount a level transmitter in- or near lling or discharging pipes.
• In case of automatic cleaning systems or hand cleaning: never point the water jets on the
diaphragm, take necessary steps to avoid this. This will void the warranty.
•When the EJA564E is used as a pressure transmitter, be aware of the following points:
•Rapid closing valves in combination with high ow velocity will cause water hammer(spikes) and
can destroy the transmitter. DO NOT mount a transmitter near such valves, always a few pipe
bends away up or down stream (avoid suction).
•Install a pressure transmitter a few pipe bends away from pumps, as well on the suction or
pressure side of the pump.
nWelding Information
CAUTION
•When using the EJA564E process connectors suffix code “W□□”, the welding information on
page 6 must be followed exactly. This is very important to prevent distortion of the weld-on
nipples. It also prevents the screw thread from the EJA564E from being deformed.
•The diaphragm of the transmitter is protected with a special protection cap. Protect the diaphragm until
installation takes place to prevent damaging of the diaphragm.
• Configuring the transmitter locally and remotely simultaneously will cause transmission errors and must be
prevented.
•As soon as the wiring is brought inside through the cable gland and connected to the terminal board,
make sure the cable gland is tightly fixed so that moisture cannot enter into the electronics housing.
• Avoid high pressure water-jets pointed at the venting.
•If the ambient conditions are very wet, we advise to use a venting through the cable. A special vented
cable can be connected on request. (The normal venting will be removed) In that case the transmitter is
IP68 rated.
•The covers must be fully engaged so that moisture cannot ingress into the electronics housing.
<9. Precautions and Warnings>

18
IM-P-20200626-01
Revision Information
Title : Hygienic & Sanitary Pressure Transmitter
EJA564E
Manual No. : IM-P-20200626-01
Aug 2020/1st Edition/R1.01 or later Newly published
nFor Questions and More Information
If you have any questions, you can send an E-mail to the following address.
E-mail: [e-mail]
n If you want have more information about Yokogawa products, you can visit
Yokogawa’s homepage at the following web site.
Homepage: http://www.yokogawa.com/
nWritten by Marketing Dept.
Transmitters Div.
Yokogawa Corporation of America
n Published by Yokogawa Corporation of America
2 Dart Road, Newnan, Georgia 30265 U.S.A.
nPrinted by Yokogawa Corporation of America
