YOKOGAWA SMARTDAC+ GX10 User manual

User’s
Manual
IM 04L51B01-17EN
9th Edition
Model GX10/GX20/GP10/GP20/GM10
Communication Command
User’s Manual

i
IM 04L51B01-17EN
Introduction Thank you for purchasing the SMARTDAC+ GX10/GX20/GP10/GP20/GM10 Series
(hereafter referred to as the recorder, GX, GP, or GM).
This manual explains the dedicated commands for the recorder. To ensure correct use,
please read this manual thoroughly before beginning operation.
Notes • The contents of this manual are subject to change without prior notice as a result of
continuing improvements to the instrument’s performance and functions.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its
contents. However, should you have any questions or find any errors, please contact your
nearest YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the
permission of YOKOGAWAis strictly prohibited.
• The TCP/IP software of this product and the documents concerning it have been
developed/created by YOKOGAWAbased on the BSD Networking Software, Release 1
that has been licensed from the Regents of the University of California.
Trademarks • SMARTDAC+ and SMARTDACPLUS are registered trademarks of Yokogawa Electric
Corporation.
• Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation
in the United States and/or other countries.
• Adobe and Acrobat are registered trademarks or trademarks of Adobe Systems
Incorporated.
• Kerberos is a trademark of Massachusetts Institute of Technology (MIT).
• Bluetooth is a trademark or registered trademark of Bluetooth SIG Inc.
• Company and product names that appear in this manual are registered trademarks or
trademarks of their respective holders.
• The company and product names used in this manual are not accompanied by the
registered trademark or trademark symbols (® and ™).
Revisions December 2012 1st Edition
February 2013 2nd Edition
May 2013 3rd Edition
May 2014 4th Edition
December 2014 5th Edition
August 2015 6th Edition
December 2015 7th Edition
March 2016 8th Edition
June 2017 9th Edition
9th Edition: June. 2017 (YK)
All Rights Reserved, Copyright © 2012, Yokogawa Electric Corporation

ii IM 04L51B01-17EN
Recorder Version and Functions Described in This Manual
Edition Product Explanation
1 GX/GP: Version 1.01 and later —
2 GX/GP: Version 1.02 and later Feature additions.
3 GX/GP: Version 1.03 and later Electromagnetic relay type analog input modules have been
added.
Feature additions.
4 GX/GP: Version 2.01 and later Support for GX20/GP20 large memory type and expandable
I/O has been added.
Support for new modules (current (mA) input, low withstand
voltage relay, and DI/DO) has been added.
Feature additions.
Advanced security function (/AS option)
Custom display function (/CG option)
EtherNet/IP communication (/E1 option)
WT communication (/E2 option)
Log scale function (/LG option)
Etc.
5 GX/GP: Version 2.02 and later
GM: Version 2.02 and later Describes the GM.
Feature additions.
Bluetooth communication (/C8 option) [GM]
USB communication [GM]
Pulse input (DI module)
6 GX/GP: Version 2.02 and later
GM: Version 2.03 and later Advanced security function (/AS option) is added to the GM.
7 GX/GP: Version 3.01 and later
GM: Version 3.01 and later Support for new modules (pulse input). Feature additions.
Aerospace Heat Treatment (/AH option)
Multi batch function (/BT option)
OPC-UA server function (/E3 option)
SLMP communication (/E4 option)
Others
Etc.
8 GX/GP: Version 3.02 and later
GM: Version 3.02 and later Port limitation setting of DARWIN compatible communication has been added.
9 GX/GP: Version 4.01 and later
GM: Version 4.01 and later Support for new modules (analog output, high-speed AI, 4-wire RTD, PID control)
Feature additions.
Program control (/PG option)
Logic math function (/MT option)
Support for new measurement modes (high-speed AI,
dual interval)

iii
IM 04L51B01-17EN
How to Use This Manual
This manual explains the dedicated communication commands for the recorder and how
to use them. For details on the features of the recorder and how to use it, see the following
manuals.
• Model GX10/GX20/GP10/GP20 Paperless Recorder First Step Guide (IM 04L51B01-
02EN)
• Model GX10/GX20/GP10/GP20 Paperless Recorder User’s Manual (IM 04L51B01-01EN)
• Data Acquisition System GM First Step Guide (IM 04L55B01-02EN)
• Data Acquisition System GM User’s Manual (IM 04L55B01-01EN)
Conventions Used in This Manual
Unit KDenotes 1024. Example: 768K (file size)
kDenotes 1000.
Markings Improper handling or use can lead to injury to the user or damage to
the instrument. This symbol appears on the instrument to indicate that
the user must refer to the user’s manual for special instructions. The
same symbol appears in the corresponding place in the user’s manual
to identify those instructions. In the manual, the symbol is used in
conjunction with the word “WARNING” or “CAUTION.”
WARNING Calls attention to actions or conditions that could cause serious or fatal
injury to the user, and precautions that can be taken to prevent such
occurrences.
CAUTION Calls attention to actions or conditions that could cause light injury
to the user or cause damage to the instrument or user’s data, and
precautions that can be taken to prevent such occurrences.
Note Calls attention to information that is important for the proper operation
of the instrument.

Blank

v
IM 04L51B01-17EN
1
2
App
Contents
Introduction................................................................................................................................................i
Recorder Version and Functions Described in This Manual..................................................................... ii
How to Use This Manual ..........................................................................................................................iii
Conventions Used in This Manual............................................................................................................iii
Chapter 1 Using Dedicated Commands (General)
1.1 Operations over an Ethernet Network.................................................................................1-1
1.1.1 Preparing the Instrument........................................................................................................1-1
1.1.2 Sending Commands and Receiving Responses....................................................................1-1
1.2 Operations over the Serial Interface (RS-232, RS-422/485, USB, Bluetooth)....................1-2
1.2.1 Preparing the Instrument........................................................................................................1-2
1.2.2 Sending Commands and Receiving Responses....................................................................1-2
1.2.3 RS-232 Connection Procedure (GX/GP) ...............................................................................1-3
1.2.4 RS-422/485 Connection Procedure.......................................................................................1-6
1.2.5 USB Connection Procedure (GM)..........................................................................................1-9
1.2.6 Bluetooth Connection Procedure (GM, /C8 option)..............................................................1-10
Chapter 2 Commands and Responses
2.1 Command Transmission and Recorder Responses............................................................2-1
2.1.1 General Communication ........................................................................................................2-1
2.1.2 Command Types and Functions ............................................................................................2-1
2.1.3 Command Syntax...................................................................................................................2-1
2.1.4 Recorder Responses .............................................................................................................2-4
2.2 List of Commands...............................................................................................................2-5
2.2.1 Setting Commands.................................................................................................................2-5
2.2.2 Output Commands.................................................................................................................2-8
2.2.3 Operation Commands............................................................................................................2-9
2.2.4 Communication Control Commands......................................................................................2-9
2.2.5 Instrument Information Commands......................................................................................2-10
2.2.6 Conditions for Executing Commands...................................................................................2-10
2.2.7 How to Use Commands.......................................................................................................2-11
2.2.8 Device Nomenclature in Command Descriptions.................................................................2-11
2.3 Parameters........................................................................................................................2-12
2.3.1 Measuring Range Parameters.............................................................................................2-12
2.3.2 Parameter Notation and Range ...........................................................................................2-12
2.3.3 Specifying a Range..............................................................................................................2-13
2.4 Setting Commands............................................................................................................2-14
2.5 Output Commands............................................................................................................2-94
2.6 Operation Commands.....................................................................................................2-101
2.7 Communication Control Commands...............................................................................2-113
2.8 Instrument Information Output Commands.....................................................................2-115
2.9 Responses to Commands...............................................................................................2-117
2.9.1 Affirmative Response (For commands other than output request commands)..................2-117
2.9.2 Negative Response............................................................................................................2-117
2.9.3 Data Output Response.......................................................................................................2-118
2.9.4 Output in Response to RS-422/485 Commands................................................................2-120
2.10 ASCII Output Format.......................................................................................................2-121
2.10.1 Most Recent Channel Data (FData)...................................................................................2-121
2.10.2 Most Recent (DO Channel) Status (FRelay)......................................................................2-122
2.10.3 Internal Switch Status (FRelay)..........................................................................................2-124
2.10.4 Latest re-transmission output (AO channel) state (FTransStatAO)....................................2-124
2.10.5 Users Who Are Currently Logged In (FUser).....................................................................2-126
2.10.6 All Users Who Are Currently Logged In (FUser)................................................................2-128
2.10.7 Instrument Address (FAddr) ...............................................................................................2-130
2.10.8 Recorder status (FStat)......................................................................................................2-131
2.10.9 Alarm Summary (FLog)......................................................................................................2-134
2.10.10 Message Summary (FLog).................................................................................................2-135
2.10.11 Event log (FLog).................................................................................................................2-136
2.10.12 Error Log (FLog).................................................................................................................2-136
2.10.13 Address Setting Log (FLog)...............................................................................................2-137
2.10.14 General Communication Log (FLog)..................................................................................2-138

vi IM 04L51B01-17EN
Contents
2.10.15 Modbus Communication Log (FLog)..................................................................................2-139
2.10.16 FTP Client Log (FLog)........................................................................................................2-140
2.10.17 SNTP (Time Adjustment) Client Log (FLog).......................................................................2-141
2.10.18 E-Mail Client Log (FLog)....................................................................................................2-142
2.10.19 Web Log (FLog).................................................................................................................2-143
2.10.20 SLMP Log (FLog)...............................................................................................................2-144
2.10.21 Control Alarm Summary (FLog) .........................................................................................2-145
2.10.22 Control Summary (FLog)....................................................................................................2-146
2.10.23 Detail Event Log Output (FEventLog) (/AS).......................................................................2-148
2.10.24 External Storage Medium and Internal Memory File List (FMedia)....................................2-157
2.10.25 External Storage Medium Free Space (FMedia)................................................................2-157
2.10.26 Setting Data (FCnf)............................................................................................................2-158
2.10.27 Decimal Place and Unit Information (FChInfo)...................................................................2-158
2.10.28 System Configuration (FSysConf)......................................................................................2-159
2.10.29 Bluetooth Device Information (FBTDevInfo) ......................................................................2-161
2.10.30 Reminder Information Output (FReminder)........................................................................2-162
2.10.31 Outputs the Most Recent Control Data (FCtrlData) ...........................................................2-163
2.10.32 SP Number and PID Number Output (FCtrlNo.)................................................................2-164
2.10.33 Control Mode Output (FCtrlMode)......................................................................................2-165
2.10.34 Program Operation Mode Output (FPrgMode)...................................................................2-166
2.10.35 Program Pattern Information Output (FPrgPtnInfo) ...........................................................2-167
2.10.36 PV event and time event information output (FPrgEvent)..................................................2-168
2.10.37 Program control end signal status output (FPrgEnd).........................................................2-169
2.10.38 Currently Running Program Pattern Number and Status Output (FPrgPtnCur).................2-169
2.10.39 Instrument Manufacturer (_MFG).......................................................................................2-170
2.10.40 Instrument’s Product Name (_INF) ....................................................................................2-170
2.10.41 Instrument’s Basic Specifications (_COD).........................................................................2-171
2.10.42 Instrument’s Firmware Version Information (_VER)...........................................................2-171
2.10.43 Instrument’s Option Installation Information (_OPT)..........................................................2-172
2.10.44 Instrument’s Temperature Unit and Daylight Saving Time Installation Information (_TYP)2-173
2.10.45 Instrument’s Error Number Information (_ERR).................................................................2-173
2.10.46 Instrument’s Unit Configuration Information (_UNS or _UNR)...........................................2-174
2.10.47 Instrument’s Module Configuration Information (_MDS or MDR).......................................2-175
2.11 Format of the Data Block of Binary Output .....................................................................2-177
2.11.1 Most Recent Channel Data (FData)...................................................................................2-177
2.11.2 Channel FIFO Data (FFifoCur)...........................................................................................2-180
2.11.3 FIFO Data Read Range (FFifoCur)....................................................................................2-180
2.11.4 The Most Recent Control Data (FCtrlData)........................................................................2-181
Appendix
Appendix 1 ASCII Character Codes...................................................................................................App-1
Appendix 2 Login Procedure..............................................................................................................App-2
When Using the Login Function ....................................................................................................... App-2
When Not Using the Login Function................................................................................................. App-3
Appendix 3 Output Flow Chart of External Storage Medium Files and File Lists...............................App-4
Example for Outputting File aaaa.dtd............................................................................................... App-4
Example for Outputting a File List .................................................................................................... App-5
Appendix 4 FIFO Data Output Flow Chart.........................................................................................App-6
Overview of the FIFO Buffer............................................................................................................. App-6
Example of FIFO Buffer Operation................................................................................................... App-6
Appendix 5 Check Sum Calculation Method......................................................................................App-7
Appendix 6 Data Group Name and Data Name for WT Communication...........................................App-8
Parameters p5 (Data Group Name) and p6 (Data Name) for SWattData Command....................... App-8
Appendix 7 Bluetooth Communication Connection Flow Chart .......................................................App-14

1-1
IM 04L51B01-17EN
Using Dedicated Commands (General)
1
2
App
1.1 Operations over an Ethernet Network
You can control the recorder by sending commands from a PC over an Ethernet network.
There are various types of commands: setting commands, output commands, operation
commands, communication control commands, and instrument information output
commands.
1.1.1 Preparing the Instrument
Recorder Configuration
Configure the recorder to connect to the Ethernet network that you want to use. For
instructions on how to configure the recorder, see section 1.17, “Configuring the Ethernet
Communication Function“ in the Model GX10/GX20/GP10/GP20 Paperless Recorder User’s
Manual (IM 04L51B01-01EN) or section 2.18, “Configuring the Ethernet Communication
Function,” in the Data Acquisition System GM User’s Manual (IM 04L55B01-01EN).
PC
The PC that you will use must meet the following requirements.
• The PC is connected to the Ethernet network that you want to use.
• The PC can run programs that you have created (see section 1.1.2, “Sending Commands
and Receiving Responses,” below).
1.1.2 Sending Commands and Receiving Responses
Programs
When you send a command to the recorder, it will return a response. You can control the
recorder by writing a program that sends commands and processes responses and then
executing the program. You need to create the programs.
Example: If you send the command “FData,0,0001,0020” from your PC to the recorder, the
recorder will return the most recent data of channels 0001 to 0020 in ASCII code.
For details on commands and responses, see chapter 2, “Commands and Responses.”
Notes on Creating Programs
• When Not Using the Login Function
You can start using commands immediately after communication is established with the
recorder.
• When Using the Login Function
Log in to the recorder using a system administrator account or a normal user account that
is registered in the recorder. Log in by connecting to the recorder and then sending the
“CLogin” command.
• Port Number
The defaul port number is “34434.” You can change the port number using the SServer
command.
Chapter 1 Using Dedicated Commands (General)

1-2 IM 04L51B01-17EN
1.2 Operations over the Serial Interface (RS-232,
RS-422/485, USB, Bluetooth)
You can control the recorder by sending commands from a PC through the serial interface.
There are various types of commands: setting commands, output commands, operation
commands, communication control commands, and instrument information output
commands. Except for a few special commands, the commands are the same as those used
over an Ethernet network.
1.2.1 Preparing the Instrument
Connection
See section 1.2.3, “RS-232 Connection Procedure,” section 1.2.4, “RS-422/485 Connection
Procedure,” section 1.2.5, “USB Connection Procedure,” or section 1.2.6, “Bluetooth
Connection Procedure.”
Recorder Configuration
Configure the recorder to use serial communication. For instructions on how to configure
the recorder, see section 1.18, “Configuring the Serial Communication Function (/C2 and /
C3 options)“ in the Model GX10/GX20/GP10/GP20 Paperless Recorder User’s Manual
(IM 04L51B01-01EN) or section 2.19, “Configuring the Serial Communication Function (/
C3 option),” section 2.20, “Configuring the USB Communication Function,” or section 2.21,
“Configuring the Bluetooth Communication Functions,” in the Data Acquisition System GM
User’s Manual (IM 04L55B01-01EN).
PC
The PC that you will use must meet the following requirements.
• The PC is connected to the recorder through the serial interface.
• The PC can run programs that you have created (see section 1.2.2, “Sending Commands
and Receiving Responses,” below).
1.2.2 Sending Commands and Receiving Responses
Programs
When you send a command to the recorder, it will return a response. You can control the
recorder by writing a program that sends commands and processes responses and then
executing the program. You need to create the programs.
Example: If you send the command “FData,0,0001,0020” from your PC to the recorder, the
recorder will return the most recent data of channels 0001 to 0020 in ASCII code.
For details on commands and responses, see chapter 2, “Commands and Responses.”
Notes on Creating Programs
• For RS-232 (GX/GP), USB communication (GM), Bluetooth (GM, /C8 option)
When you connect a PC to the recorder through the serial interface, the recorder will be
ready to receive commands.
• For RS-422/485
The device that receives an open command (ESC O) from a PC will be ready to receive
commands. The connection will close in the following situations.
• When the recorder receives a connection-close command (ESC C).
