York LX series Quick start guide

TECHNICAL GUIDE
LX SERIES
SPLIT SYSTEM
AIR CONDITIONERS
13 SEER – R-410A – 1 PHASE
1.5 TO 5 NOMINAL TONS
MODELS: RAC13L18 TO 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.simplygettingthejobdone.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Standard 5-year limited parts warranty.
Standard 5-year limited compressor warranty.
Extended 10-year limited parts and compressor warranty
when product is registered online within 90 days of purchase
for replacement or closing for new home construction.
*Does not apply to R-22 models, 3-Phase models, or Internet sales.
See Limited Warranty certificate in the User's Information Manual for details.
FOR INSTALLATION ONLY IN
US NORTHERN REGION AND CANADA
Installation Allowed
®
TECHNICAL
GUIDE
TECHNICAL
GUIDE
5752574-UTG-C-1020
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The RAC13L models are optimized for the 13 SEER Regional
Minimum Efficiency in the North US and Canada, and are spe-
cifically designed to be matched with Johnson Controls Ducted
Systems indoor coils, furnaces, and air handlers to provide a
complete system solution.
FEATURES
•Easier Installation - Independent panels provide quick
access for unit setup. Installation time is reduced by easy
power and control wiring access. Options are provided for
indoor piston or TXV. The factory installed filter-drier and fac-
tory charge for a 15-ft lineset means less time spent brazing
and charging the system. The small base dimension and
reduced unit clearances make for easier retrofits.
•Durable Finish - The coated steel wire fan guard, coated
external fasteners, and pre-treated G90-equivalent galva-
nized steel chassis components resist corrosion and rust
creep. Powdercoat paint further protects external panels.
•Louvered Coil Protection - Two stamped steel louvered
panels protect the coil from mechanical damage.
•Quality Coils - The high efficiency microchannel aluminum
coil is manufactured using an improved material system pro-
viding reliable performance and small unit size.
•Protected Compressor - Compressors are protected inter-
nally by a high-pressure relief valve and a temperature sen-
sor, and externally by the system high-pressure switch. The
liquid line filter-drier is factory installed to protect the com-
pressor against moisture and debris.
•Environmentally Friendly - CFC-free R-410A refrigerant
delivers environmentally friendly performance with zero
ozone depletion.
•Top Discharge - Warm air is blown up, away from the struc-
ture and any landscaping, allowing compact location on
multi-unit applications.
•Agency Listed - Safety certified by CSA to UL 1995/CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.

5752574-UTG-C-1020
2 Johnson Controls Ducted Systems
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . 3
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . . 4
COOLING CAPACITY - With Air Handler Coils . . . . . . . . . . . . . . . 5
COOLING CAPACITY - Upflow, Downflow, and
Horizontal Furnaces and Coils (Coil Only Ratings) . . . . . . . . . . . 9
COOLING CAPACITY - With High Efficiency Motor Furnaces . . 11
APPLICATIONS AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . 31
SOUND POWER RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 32
TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
ALTERNATIVE INSTALLATION CLEARANCES . . . . . . . . . . . . . . 34
PERFORMANCE DATA - 1.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 35
PERFORMANCE DATA - 2 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 38
PERFORMANCE DATA - 2.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 41
PERFORMANCE DATA - 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 44
PERFORMANCE DATA - 3.5 TON . . . . . . . . . . . . . . . . . . . . . . . . . 47
PERFORMANCE DATA - 4 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 50
PERFORMANCE DATA - 5 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 53
NOMENCLATURE
BRAND RR = OTC Factory Branded
G = Guardian
PRODUCT TYPE AC AC = Air Conditioner
NOMINAL
SERIES EFFICIENCY
AND STAGING
13 13 = 13 SEER/1-Stage
(US Northern Region)
CABINET AND
CONNECTION TYPE LL = New Chassis
Louvered/Sweat Connect
NOMINAL
UNIT CAPACITY
(MBH)
36
18 = 1.5 ton 42 = 3.5 ton
24 = 2 ton 48 = 4 ton
30 = 2.5 ton 60 = 5 ton
36 = 3 ton
REFRIGERANT BB = R-410A
VOLTAGE
(Voltage-Phase-Hertz) 22 = 208/230-1-60
GENERATION
(MAJOR REVISION) 1
1 = 1st Gen
2 = 2nd Gen
etc.
FACTORY OPTION SS = Standard (No Options)
STYLE LETTER
(MINOR REVISION)
NOT USED FOR
ORDERING
A
A = Style A
B = Style B
etc.

5752574-UTG-C-1020
Johnson Controls Ducted Systems 3
‡ Adapter fitting must be field installed for the required 1 1/8 in. line set.
All dimensions are in inches and are subject to change without notice.
Overall height is from the bottom of the base pan to the top of the fan guard.
Overall length and width include screw heads.
PHYSICAL AND ELECTRICAL DATA
MODEL RAC13L18
B23S
RAC13L24
B24S
RAC13L30
B23S
RAC13L36
B24S
RAC13L42
B24S
RAC13L48
B23S
RAC13L60
B23S
Unit Supply Voltage 208-230 V, 1 60 Hz
Normal Voltage Range1
1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.
187 to 252
Minimum Circuit Ampacity 12.9 11.4 18.4 19.8 21.1 28.5 29.1
Maximum Overcurrent Device (A)2
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
20 15 30 30 35 50 50
Minimum Overcurrent Device (A)3
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
15 15 20 20 25 30 30
Compressor
Type4
4. Rotary compressor models are limited to an equivalent length of lineset of 100 ft with no exceptions.
Scroll Rotary Scroll Scroll Scroll Scroll Scroll
Rated Load 9.7 8.4 14.1 14.7 15.9 21.8 22.2
Locked Rotor 46.0 53.0 73.0 75 112.3 117.0 127.9
Crankcase Heater No No No No No No No
Factory External Discharge Muffler No No No No No No No
HS Kit Required with TXV No n/a No No No No No
HS Kit Part Number (S1-2SA067*****)5
5. Use S1-2SA067***** series kit. Refer to the Hard Start Kit Accessory Installation Manual.
21806 n/a 10106 10106 10206 10106 10206
Fan Diameter (in.) 18 18 18 18 22 22 22
Fan Motor
Rated HP 1/8 1/8 1/8 1/4 1/4 1/4 1/4
Rated Load (A) 0.80 0.80 0.80 1.50 1.30 1.30 1.30
Nominal RPM 1075 1075 1075 1100 850 850 850
Nominal CFM 1950 1950 2150 2575 2925 3225 3350
Coil
Face Area (ft2)9.78 9.78 11.07 12.37 13.83 13.83 17.37
Rows Deep 1111111
Fins/Inch 23 23 23 23 23 23 23
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed)6
6. For applications with non-standard vapor line sizes, see the APPLICATIONS AND ACCESSORIES section.
3/4 3/4 3/4 3/4 7/8 7/8 1-1/8‡
Unit Charge (lb - oz)7
7. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 ft of refrigerant tubing. For tubing lengths other than 15 ft, add or subtract the
amount of refrigerant, using the difference in actual lineset length (not the equivalent length) multiplied by the per foot value.
2 - 13 3 - 7 3 - 10 3 - 12 4 - 6 4 - 8 5 - 1
Charge (oz/ft) 0.62 0.62 0.62 0.62 0.67 0.67 0.75
Operating Weight (lb) 125 130 140 165 175 165 190
&
%
$
$
DIMENSIONS
Unit
Model
Dimensions
(in.)
Refrigerant Connection
Service Valve Size
A B C Liquid Vapor
RAC13L18B23S 26 3/4 24 24
3/8
3/4
RAC13L24B24S 26 3/4 24 24
RAC13L30B23S 30 24 24
RAC13L36B24S 33 1/4 24 24
RAC13L42B24S 30 29 1/4 29 1/4 7/8
RAC13L48B23S 30 29 1/4 29 1/4
RAC13L60B23S 36 1/4 29 1/4 29 1/4 7/8‡

5752574-UTG-C-1020
4 Johnson Controls Ducted Systems
CHARGING PROCEDURES:
1. Check the Factory Unit Charge listed on the unit nameplate to verify the refrigerant charge for the outdoor unit, the smallest matched indoor unit, and the 15 ft of
interconnecting lineset.
2. Verify the indoor metering device and additional charge required for the specific matched indoor unit in the system using the SYSTEM CHARGE FOR VARIOUS
MATCHED SYSTEMS table.
3. Add additional charge for the amount of interconnecting lineset tubing greater than 15 ft at the rate specified in the PHYSICAL AND ELECTRICAL DATA table.
4. For installations requiring additional charge, weigh in refrigerant for the specific matching indoor unit and actual lineset length.
5. After weighing in the charge adders for the matched indoor unit and lineset, verify the system operation against the temperatures and pressures in the Charging
Chart for the outdoor unit. Locate the Charging Charts on the outdoor unit and also in the Service Data Application Guide on www.simplygettingthejobdone.com. Fol-
low the Subcool or Superheat charging procedure in the Installation Manual according to the type of indoor metering device in the system, and allow 10 min after
each charge adjustment for the system operation to stabilize. Record the charge adjustment made to match the Charging Chart.
6. Permanently stamp the unit nameplate with the TOTAL SYSTEM CHARGE defined as follows: TOTAL SYSTEM CHARGE = Base Charge (as shipped) + charge
adder for matched indoor unit + charge adder for actual lineset length + charge adjustments to match the Charging Chart.
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS
System Charge for Various Matched Systems
Outdoor Unit RAC13L18
B23S
RAC13L24
B24S
RAC13L30
B23S
RAC13L36
B24S
RAC13L42
B24S
RAC13L48
B23S
RAC13L60
B23S
Required Orifice or TXV 1,2
1. For applications requiring a TXV, use S1-1TVM*** series kit.
2. Approved orifice(s) shipped with outdoor unit.
0.049 / BH1 0.057 / BH1 0.061 / BA1 0.070 / BA1 0.075 / BC1 0.077 / BC1 0.084 / BD1
Indoor Unit 3,4,5
3. Systems matched with furnaces or air handlers not equipped with blower-off delays may require 60-s time delay.
4. CF coils cannot be used in horizontal applications.
5. Charge adders shown above do not indicate that coils are rated for every application. See the performance data tables for actual performance for specified
system matches. Obtain certified system ratings from www.ahridirectory.org.
Additional Charge (oz)
RFCX18BP 0––– – – –
RFCX24BP 30–– – – –
RFCX30BP –72– – – –
RFCX36BP –––0 – – –
RFCX36CP ––22 – – –
RFCX37CP –––5 – – –
RFCX42CP –––– 0 – –
RFCX48CP –––5 2 0 –
RFCX48DP –––– 2 0 –
RFCX60(CP,DP) –––– – 2 0
RFCX18BE 0––– – – –
RFCX24BE 30–– – – –
RFCX30BE 850– – – –
RFCX36(BE,CE) –720 – – –
RFCX42CE –––5 2 – –
RFCX48(CE,DE) –––5 2 0 –
RFCX60CE –––– 9 2 0
RFCX60DE ––––29 oz TXV ONLY 22 oz TXV ONLY 20 oz TXV ONLY
CF/CM/CU18(A,B) 0––– – – –
CF/CM/CU24(A,B) 30–– – – –
CF/CM/CU30(A,B,C) 850– – – –
CF/CM/CU36(A,B,C,D) 10 7 2 0 – – –
CF/CM/CU42(B,C,D) – 11 2 2 0 – –
CF/CM/CU48(C,D) –––5 2 0 –
CF/CM/CU60(C,D) –––– 9 2 0
CF/CM64D ––––29 oz TXV ONLY 22 oz TXV ONLY 20 oz TXV ONLY
Some of the combinations shown in this table require Advanced Main Air Circulating Fan indoor product. For approved coil only matches, see the
COOLING CAPACITY - Upflow, Downflow, and Horizontal Furnaces and Coils (Coil Only Ratings) table.
FOOTNOTES:

5752574-UTG-C-1020
Johnson Controls Ducted Systems 5
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.
RAC13L18B23S RFCX18BE06MP22 17.5 – 650 17.90 14.90 15.00 12.75
RAC13L18B23S RFCX24BE08MP22 17.5 – 625 18.00 14.70 15.00 12.75
RAC13L18B23S RFCX30BE10MP22 17.5 – 600 18.00 14.40 15.00 12.75
RAC13L18B23S RFCX18BP06MP22 17.5 – 650 17.60 14.60 13.50 11.50
RAC13L18B23S RFCX24BP08MP22 17.5 – 675 17.60 15.00 13.50 11.50
RAC13L18B23S RFCX18BE06MP22 17.5 – 650 17.90 14.90 15.00 12.75
RAC13L18B23S RFCX18BE06MP22 17.5 – 600 17.90 14.20 15.00 12.75
RAC13L18B23S RFCX18BE06MP22 17.5 – 625 18.00 14.50 15.00 12.75
RAC13L18B23S ME08BN21 17.5 CF/CM18B 575 17.70 13.90 15.00 12.75
RAC13L18B23S ME08BN21 17.5 CF/CM24B 575 17.80 14.00 15.00 12.75
RAC13L18B23S ME08BN21 17.5 CF/CM30B 600 18.00 14.40 15.00 12.75
RAC13L18B23S ME08BN21 17.5 CF/CM36B 575 18.00 14.10 15.00 12.75
RAC13L18B23S ME12BN21 17.5 CF/CM18B 675 18.00 15.20 15.00 12.75
RAC13L18B23S ME12BN21 17.5 CF/CM24B 675 18.00 15.40 15.00 12.75
RAC13L18B23S ME12BN21 17.5 CF/CM30B 675 18.00 15.00 15.00 12.75
RAC13L18B23S ME12BN21 17.5 CF/CM36B 675 18.00 15.00 15.00 12.75
RAC13L18B23S ME12CN21 21.0 CF/CM24C 600 17.90 14.20 15.00 12.75
RAC13L18B23S ME12CN21 21.0 CF/CM30C 600 18.00 14.40 15.00 12.75
RAC13L18B23S ME12CN21 21.0 CF/CM36C 600 18.00 14.30 15.00 12.75
RAC13L18B23S RGF29040AE10MP11 17.5 CF/CM18B 650 17.90 14.90 15.00 12.75
RAC13L18B23S RGF29040AE10MP11 17.5 CF/CM24B 650 18.00 14.90 15.00 12.75
RAC13L18B23S RGF29040AE10MP11 17.5 CF/CM30B 650 18.00 15.00 15.00 12.75
RAC13L18B23S RGF29040AE10MP11 17.5 CF/CM36B 650 18.00 14.90 15.00 12.75
RAC13L24B24S RFCX24BE08MP22 17.5 – 825 24.00 19.60 14.50 12.50
RAC13L24B24S RFCX30BE10MP22 17.5 – 900 24.00 20.80 14.75 12.50
RAC13L24B24S RFCX36BE12MP22 17.5 – 850 24.00 20.40 14.75 12.50
RAC13L24B24S RFCX36CE12MP22 21.0 – 800 24.00 19.80 15.00 12.50
RAC13L24B24S RFCX24BP08MP22 17.5 – 675 23.60 17.40 13.00 11.50
RAC13L24B24S RFCX30BP10MP22 17.5 – 850 24.00 20.00 13.50 11.50
RAC13L24B24S RFCX18BE06MP22 17.5 – 750 24.00 18.80 14.50 12.50
RAC13L24B24S RFCX18BE06MP22 17.5 – 750 24.00 19.00 14.75 12.50
RAC13L24B24S RFCX18BE06MP22 17.5 – 850 24.00 20.40 14.75 12.50
RAC13L24B24S RFCX18BE06MP22 21.0 – 900 24.00 21.30 15.00 12.50
RAC13L24B24S ME08BN21 17.5 CF/CM24B 800 24.00 19.30 14.50 12.50
RAC13L24B24S ME08BN21 17.5 CF/CM30B 800 24.00 20.00 14.75 12.50
RAC13L24B24S ME08BN21 17.5 CF/CM36B 800 24.00 19.90 14.75 12.50
RAC13L24B24S ME08BN21 17.5 CF42B 775 24.00 19.50 14.75 12.50
RAC13L24B24S ME12BN21 17.5 CF/CM24B 875 24.00 20.30 14.75 12.50
RAC13L24B24S ME12BN21 17.5 CF/CM30B 875 24.00 20.50 15.00 12.50
RAC13L24B24S ME12BN21 17.5 CF/CM36B 875 24.00 20.90 15.00 12.50
RAC13L24B24S ME12BN21 17.5 CF42B 850 24.00 20.50 15.00 12.50
RAC13L24B24S ME12CN21 21.0 CF/CM24C 850 24.00 20.00 14.75 12.50
RAC13L24B24S ME12CN21 21.0 CF/CM30C 850 24.00 20.50 15.00 12.50
RAC13L24B24S ME12CN21 21.0 CF/CM36C 850 24.00 20.50 15.00 12.50
RAC13L24B24S ME12CN21 21.0 CF/CM42C 850 24.00 20.50 15.00 12.50
RAC13L24B24S ME14DN21 24.5 CF/CM36D 875 24.00 20.90 15.00 12.50
RAC13L24B24S ME14DN21 24.5 CF/CM42D 875 24.00 20.90 15.00 12.50
RAC13L24B24S ME16CN21 21.0 CF/CM24C 925 24.00 19.40 14.50 12.50
RAC13L24B24S ME16CN21 21.0 CF/CM30C 925 24.00 21.30 15.00 12.50
RAC13L24B24S ME16CN21 21.0 CF/CM36C 925 24.00 21.50 15.00 12.50
RAC13L24B24S ME16CN21 21.0 CF/CM42C 925 24.00 21.60 15.00 12.50
RAC13L24B24S RGF29040AE10MP11 17.5 CF/CM24B 725 24.00 18.40 14.50 12.50
RAC13L24B24S RGF29040AE10MP11 17.5 CF/CM30B 800 24.00 20.00 14.75 12.50

5752574-UTG-C-1020
6 Johnson Controls Ducted Systems
RAC13L24B24S RGF29040AE10MP11 17.5 CF/CM36B 725 24.00 18.80 14.75 12.50
RAC13L24B24S RGF29040AE10MP11 17.5 CF42B 725 24.00 18.90 15.00 12.50
RAC13L24B24S RGF29040AE10MP11 17.5 CF/CM24B 775 24.00 19.20 14.50 12.50
RAC13L24B24S RGF29040AE10MP11 17.5 CF/CM30B 775 24.00 19.30 14.75 12.50
RAC13L24B24S RGF29040AE10MP11 17.5 CF/CM36B 875 24.00 20.70 14.75 12.50
RAC13L24B24S RGF29040AE10MP11 17.5 CF42B 775 24.00 19.70 15.00 12.50
RAC13L24B24S RGF29040AE10MP11 24.5 CF/CM36D 875 24.00 20.90 15.00 12.50
RAC13L24B24S RGF29040AE10MP11 24.5 CF/CM42D 875 24.00 20.90 15.00 12.50
RAC13L24B24S RGF29040AE10MP11 21.0 CF/CM24C 925 24.00 19.40 14.75 12.50
RAC13L24B24S RGF29040AE10MP11 21.0 CF/CM30C 925 24.00 21.30 15.00 12.50
RAC13L24B24S RGF29040AE10MP11 21.0 CF/CM36C 925 24.00 21.50 15.00 12.50
RAC13L24B24S RGF29040AE10MP11 21.0 CF/CM42C 925 24.00 21.50 15.00 12.50
RAC13L30B23S RFCX30BE10MP22 17.5 – 875 28.80 21.80 14.00 12.25
RAC13L30B23S RFCX36BE12MP22 17.5 – 825 28.80 21.20 14.25 12.25
RAC13L30B23S RFCX36CE12MP22 21.0 – 975 29.60 23.20 14.50 12.50
RAC13L30B23S RFCX30BP10MP22 17.5 – 825 28.80 23.60 13.00 11.50
RAC13L30B23S RFCX36CP12MP22 21.0 – 1125 29.60 24.60 13.00 11.50
RAC13L30B23S RFCX18BE06MP22 17.5 – 825 28.60 21.00 14.25 12.25
RAC13L30B23S RFCX18BE06MP22 17.5 – 850 29.00 21.40 14.25 12.25
RAC13L30B23S RFCX18BE06MP22 21.0 – 900 29.40 22.20 14.50 12.50
RAC13L30B23S ME08BN21 17.5 CF/CM30B 875 28.80 21.80 14.00 12.25
RAC13L30B23S ME08BN21 17.5 CF/CM36B 900 29.20 22.20 14.25 12.25
RAC13L30B23S ME08BN21 17.5 CF42B 875 29.20 22.00 14.25 12.25
RAC13L30B23S ME12BN21 17.5 CF/CM30B 850 28.80 21.60 14.25 12.25
RAC13L30B23S ME12BN21 17.5 CF/CM36B 850 29.00 21.40 14.50 12.50
RAC13L30B23S ME12BN21 17.5 CF42B 850 29.00 21.60 14.50 12.50
RAC13L30B23S ME12CN21 21.0 CF/CM30C 1000 29.40 23.20 14.50 12.50
RAC13L30B23S ME12CN21 21.0 CF/CM36C 1000 29.60 23.40 14.50 12.50
RAC13L30B23S ME12CN21 21.0 CF/CM42C 825 29.00 21.20 14.50 12.50
RAC13L30B23S ME14DN21 24.5 CF/CM36D 1025 29.80 24.00 14.75 12.50
RAC13L30B23S ME14DN21 24.5 CF/CM42D 1025 29.80 24.00 14.75 12.50
RAC13L30B23S ME16CN21 21.0 CF/CM30C 900 29.00 22.20 14.25 12.25
RAC13L30B23S ME16CN21 21.0 CF/CM36C 900 29.40 22.20 14.50 12.50
RAC13L30B23S ME16CN21 21.0 CF/CM42C 900 29.40 22.40 14.50 12.50
RAC13L30B23S RGF29040AE10MP11 17.5 CF/CM30B 825 28.60 21.00 14.25 12.25
RAC13L30B23S RGF29040AE10MP11 17.5 CF/CM36B 825 28.80 21.20 14.25 12.25
RAC13L30B23S RGF29040AE10MP11 17.5 CF42B 850 29.00 21.60 14.25 12.25
RAC13L30B23S RGF29040AE10MP11 17.5 CF/CM30B 875 28.80 21.60 14.25 12.25
RAC13L30B23S RGF29040AE10MP11 17.5 CF/CM36B 875 29.20 22.00 14.25 12.25
RAC13L30B23S RGF29040AE10MP11 17.5 CF42B 875 29.20 22.00 14.50 12.50
RAC13L30B23S RGF29040AE10MP11 24.5 CF/CM36D 1000 29.80 23.60 14.75 12.50
RAC13L30B23S RGF29040AE10MP11 24.5 CF/CM42D 1000 29.80 23.40 14.75 12.50
RAC13L30B23S RGF29040AE10MP11 21.0 CF/CM30C 925 29.00 22.60 14.50 12.50
RAC13L30B23S RGF29040AE10MP11 21.0 CF/CM36C 1025 29.80 24.00 14.50 12.50
RAC13L30B23S RGF29040AE10MP11 21.0 CF/CM42C 925 29.40 22.60 14.75 12.50
RAC13L36B24S RFCX36BE12MP22 17.5 – 1100 35.60 27.00 13.75 12.00
RAC13L36B24S RFCX36CE12MP22 21.0 – 1175 36.00 27.80 14.25 12.25
RAC13L36B24S RFCX42CE14MP22 21.0 – 1150 36.00 27.90 14.25 12.25
RAC13L36B24S RFCX48CE16MP22 21.0 – 1050 36.00 26.70 14.50 12.25
RAC13L36B24S RFCX48DE16MP22 24.5 – 1050 36.00 26.70 14.50 12.25
RAC13L36B24S RFCX36BP12MP22 17.5 – 1150 35.40 27.40 13.00 11.25
RAC13L36B24S RFCX36CP12MP22 21.0 – 1125 35.40 27.00 13.00 11.25
RAC13L36B24S RFCX48CP16MP22 21.0 – 1300 36.00 29.00 13.00 11.25
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
Johnson Controls Ducted Systems 7
RAC13L36B24S RFCX18BE06MP22 17.5 – 1200 36.00 28.30 13.75 12.00
RAC13L36B24S RFCX18BE06MP22 21.0 – 1175 36.00 28.00 14.25 12.25
RAC13L36B24S RFCX18BE06MP22 21.0 – 1050 36.00 26.80 14.50 12.25
RAC13L36B24S RFCX18BE06MP22 21.0 – 1025 36.00 26.40 14.50 12.25
RAC13L36B24S RFCX18BE06MP22 24.5 – 1150 36.00 27.90 14.50 12.25
RAC13L36B24S ME12BN21 17.5 CF/CM36B 1050 35.60 26.60 14.00 12.00
RAC13L36B24S ME12BN21 17.5 CF42B 1050 36.00 26.40 14.00 12.00
RAC13L36B24S ME12CN21 21.0 CF/CM36C 1000 35.40 25.90 14.25 12.25
RAC13L36B24S ME12CN21 21.0 CF/CM42C 1000 35.80 25.90 14.25 12.25
RAC13L36B24S ME12CN21 21.0 CF/CM48C 1000 35.80 26.10 14.50 12.25
RAC13L36B24S ME14DN21 24.5 CF/CM36D 1200 36.00 28.60 14.50 12.25
RAC13L36B24S ME14DN21 24.5 CF/CM42D 1025 35.80 26.60 14.50 12.25
RAC13L36B24S ME14DN21 24.5 CF/CM48D 1025 36.00 26.40 14.75 12.25
RAC13L36B24S ME16CN21 21.0 CF/CM36C 1100 35.80 27.20 14.25 12.25
RAC13L36B24S ME16CN21 21.0 CF/CM42C 1100 36.00 27.50 14.25 12.25
RAC13L36B24S ME16CN21 21.0 CF/CM48C 1100 36.00 27.70 14.50 12.25
RAC13L36B24S ME20DN21 24.5 CF/CM36D 1275 36.00 29.30 14.50 12.25
RAC13L36B24S ME20DN21 24.5 CF/CM42D 1275 36.00 29.20 14.50 12.25
RAC13L36B24S ME20DN21 24.5 CF/CM48D 1275 36.00 29.40 14.75 12.25
RAC13L36B24S RGF29040AE10MP11 17.5 CF/CM36B 1000 35.20 25.80 14.00 12.00
RAC13L36B24S RGF29040AE10MP11 17.5 CF42B 1000 35.60 25.70 14.00 12.00
RAC13L36B24S RGF29040AE10MP11 17.5 CF/CM36B 1075 35.60 26.70 14.00 12.00
RAC13L36B24S RGF29040AE10MP11 17.5 CF42B 975 35.60 25.50 14.25 12.00
RAC13L36B24S RGF29040AE10MP11 24.5 CF/CM36D 1175 36.00 28.00 14.50 12.25
RAC13L36B24S RGF29040AE10MP11 24.5 CF/CM42D 1175 36.00 28.10 14.75 12.25
RAC13L36B24S RGF29040AE10MP11 24.5 CF/CM48D 1175 36.00 28.30 14.75 12.25
RAC13L36B24S RGF29040AE10MP11 21.0 CF/CM36C 1125 36.00 27.70 14.50 12.25
RAC13L36B24S RGF29040AE10MP11 21.0 CF/CM42C 1150 36.00 27.70 14.50 12.25
RAC13L36B24S RGF29040AE10MP11 21.0 CF/CM48C 1125 36.00 27.70 14.75 12.25
RAC13L36B24S RGF29040AE10MP11 24.5 CF/CM36D 1175 36.00 28.00 14.75 12.25
RAC13L36B24S RGF29040AE10MP11 24.5 CF/CM42D 1175 36.00 28.10 14.75 12.25
RAC13L36B24S RGF29040AE10MP11 24.5 CF/CM48D 1275 36.00 29.40 14.75 12.25
RAC13L42B24S RFCX42CE14MP22 21.0 – 1350 41.50 32.10 14.00 12.00
RAC13L42B24S RFCX43CE14MP22 21.0 – 1200 41.00 30.30 14.00 12.25
RAC13L42B24S RFCX48CE16MP22 21.0 – 1425 42.00 33.60 14.25 12.25
RAC13L42B24S RFCX48DE16MP22 24.5 – 1475 42.00 34.30 14.50 12.50
RAC13L42B24S AE60CX21 21.0 – 1425 42.00 33.40 14.00 12.25
RAC13L42B24S RFCX60CE20MP23 21.0 – 1425 41.50 32.60 14.00 12.00
RAC13L42B24S RFCX60DE20MP22 24.5 – 1350 42.00 32.90 14.25 12.50
RAC13L42B24S RFCX48CP16MP22 21.0 – 1300 41.00 31.30 13.00 11.50
RAC13L42B24S RFCX48DP16MP22 24.5 – 1475 41.50 33.40 13.00 11.50
RAC13L42B24S AP60DX22 24.5 – 1550 41.50 34.50 13.00 11.25
RAC13L42B24S RFCX60DP20MP24 24.5 – 1550 41.00 33.60 13.00 11.00
RAC13L42B24S RFCX18BE06MP22 21.0 – 1325 41.50 32.00 14.00 12.00
RAC13L42B24S RFCX18BE06MP22 21.0 – 1275 41.50 31.50 14.25 12.25
RAC13L42B24S RFCX18BE06MP22 24.5 – 1375 42.00 32.50 14.50 12.50
RAC13L42B24S AVC60CX22 21.0 – 1200 40.50 29.90 14.00 12.00
RAC13L42B24S RFCX18BE06MP22 24.5 – 1175 42.00 30.80 14.25 12.50
RAC13L42B24S ME12CN21 21.0 CF/CM42C 1225 41.00 30.60 14.25 12.25
RAC13L42B24S ME12CN21 21.0 CF/CM48C 1225 41.50 31.00 14.25 12.25
RAC13L42B24S ME12CN21 21.0 CF/CM60C 1225 41.00 30.40 14.25 12.25
RAC13L42B24S ME14DN21 24.5 CF/CM42D 1200 41.00 30.50 14.50 12.25
RAC13L42B24S ME14DN21 24.5 CF/CM48D 1375 42.00 32.50 14.25 12.25
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
8 Johnson Controls Ducted Systems
RAC13L42B24S ME14DN21 24.5 CF/CM60D 1200 41.00 30.30 14.50 12.25
RAC13L42B24S ME14DN21 24.5 CF/CM64D 1200 42.00 30.80 14.25 12.75
RAC13L42B24S ME16CN21 21.0 CF/CM42C 1325 41.50 31.90 14.00 12.25
RAC13L42B24S ME16CN21 21.0 CF/CM48C 1325 41.50 32.00 14.00 12.00
RAC13L42B24S ME16CN21 21.0 CF/CM60C 1325 41.00 31.10 14.00 12.00
RAC13L42B24S ME20DN21 24.5 CF/CM42D 1275 41.50 31.30 14.50 12.50
RAC13L42B24S ME20DN21 24.5 CF/CM48D 1275 41.50 31.50 14.75 12.50
RAC13L42B24S ME20DN21 24.5 CF/CM60D 1525 42.00 34.20 14.50 12.25
RAC13L42B24S ME20DN21 24.5 CF/CM64D 1250 42.00 31.70 14.50 12.75
RAC13L42B24S RGF29040AE10MP11 24.5 CF/CM42D 1250 41.50 31.40 14.50 12.50
RAC13L42B24S RGF29040AE10MP11 24.5 CF/CM48D 1250 41.50 31.30 14.50 12.50
RAC13L42B24S RGF29040AE10MP11 24.5 CF/CM60D 1175 41.00 29.80 14.50 12.50
RAC13L42B24S RGF29040AE10MP11 24.5 CF/CM64D 1250 42.00 31.70 14.50 12.75
RAC13L42B24S RGF29040AE10MP11 21.0 CF/CM42C 1275 41.50 31.30 14.50 12.50
RAC13L42B24S RGF29040AE10MP11 21.0 CF/CM48C 1275 41.50 31.50 14.50 12.50
RAC13L42B24S RGF29040AE10MP11 21.0 CF/CM60C 1275 41.00 30.80 14.50 12.25
RAC13L42B24S RGF29040AE10MP11 24.5 CF/CM42D 1300 42.00 32.00 14.75 12.75
RAC13L42B24S RGF29040AE10MP11 24.5 CF/CM48D 1275 41.50 31.50 14.75 12.75
RAC13L42B24S RGF29040AE10MP11 24.5 CF/CM60D 1175 41.00 29.80 14.75 12.50
RAC13L42B24S RGF29040AE10MP11 24.5 CF/CM64D 1275 42.00 32.00 14.50 12.75
RAC13L48B23S RFCX48CE16MP22 21.0 – 1425 47.50 35.00 14.25 12.25
RAC13L48B23S RFCX48DE16MP22 24.5 – 1425 48.00 35.50 14.50 12.25
RAC13L48B23S AE60CX21 21.0 – 1425 48.00 35.50 14.50 12.25
RAC13L48B23S RFCX60DE20MP22 24.5 – 1400 48.00 35.00 14.75 12.25
RAC13L48B23S RFCX48CP16MP22 21.0 – 1300 46.00 32.50 13.25 11.50
RAC13L48B23S RFCX48DP16MP22 24.5 – 1475 47.50 35.00 13.00 11.00
RAC13L48B23S AP60CX21 21.0 – 1500 48.00 35.50 13.00 11.25
RAC13L48B23S AP60DX22 24.5 – 1475 47.50 34.80 13.25 11.25
RAC13L48B23S RFCX60DP20MP24 24.5 – 1475 47.50 34.80 13.25 11.25
RAC13L48B23S RFCX18BE06MP22 21.0 – 1350 47.50 34.50 14.25 12.00
RAC13L48B23S RFCX18BE06MP22 24.5 – 1400 48.00 35.00 14.50 12.25
RAC13L48B23S RFCX18BE06MP22 21.0 – 1350 48.00 34.50 14.25 12.25
RAC13L48B23S RFCX18BE06MP22 24.5 – 1475 48.00 35.50 14.50 12.25
RAC13L48B23S ME14DN21 24.5 CF/CM60D 1425 48.00 35.00 14.50 12.25
RAC13L48B23S ME14DN21 24.5 CF/CM64D 1375 48.00 34.50 14.75 12.25
RAC13L48B23S ME16CN21 21.0 CF/CM48C 1475 48.00 35.50 14.50 12.25
RAC13L48B23S ME16CN21 21.0 CF/CM60C 1450 48.00 35.50 14.50 12.25
RAC13L48B23S ME20DN21 24.5 CF/CM48D 1475 48.00 35.50 14.50 12.25
RAC13L48B23S ME20DN21 24.5 CF/CM60D 1425 48.00 35.00 14.50 12.25
RAC13L48B23S ME20DN21 24.5 CF/CM64D 1425 48.00 35.50 14.75 12.25
RAC13L48B23S RGF29040AE10MP11 24.5 CF/CM48D 1325 47.50 33.50 14.50 12.25
RAC13L48B23S RGF29040AE10MP11 24.5 CF/CM60D 1350 47.50 34.00 14.25 12.25
RAC13L48B23S RGF29040AE10MP11 24.5 CF/CM64D 1325 48.00 34.00 14.75 12.25
RAC13L48B23S RGF29040AE10MP11 21.0 CF/CM48C 1425 48.00 35.00 14.25 12.25
RAC13L48B23S RGF29040AE10MP11 21.0 CF/CM60C 1650 48.00 37.00 15.00 12.50
RAC13L48B23S RGF29040AE10MP11 24.5 CF/CM48D 1450 48.00 35.50 14.25 12.00
RAC13L48B23S RGF29040AE10MP11 24.5 CF/CM60D 1475 48.00 35.50 14.50 12.25
RAC13L48B23S RGF29040AE10MP11 24.5 CF/CM64D 1375 48.00 34.50 14.75 12.25
RAC13L60B23S RFCX60CE20MP23 21.0 – 1600 56.00 41.00 13.25 11.25
RAC13L60B23S RFCX60DE20MP22 24.5 – 1550 57.00 41.00 13.25 11.25
RAC13L60B23S RFCX18BE06MP22 24.5 – 1600 56.50 41.00 13.50 11.25
RAC13L60B23S ME16CN21 21.0 CF/CM60C 1575 55.50 40.50 13.50 11.25
RAC13L60B23S ME20DN21 24.5 CF/CM60D 1700 56.00 41.50 13.50 11.25
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
Johnson Controls Ducted Systems 9
– = Not applicable.
MP Modular Air Handlers use Coil Only Ratings.
RAC13L60B23S ME20DN21 24.5 CF/CM64D 1675 56.50 42.00 13.50 11.50
RAC13L60B23S RGF29040AE10MP11 21.0 CF/CM60C 1650 56.00 41.00 13.50 11.50
RAC13L60B23S RGF29040AE10MP11 24.5 CF/CM60D 1550 56.00 40.00 13.50 11.25
RAC13L60B23S RGF29040AE10MP11 24.5 CF/CM64D 1575 56.50 41.00 13.50 11.25
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated airflow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in
watt-hours during the same period.
1. CM coils available with a factory installed horizontal drain pan. Refer to the Price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.
COOLING CAPACITY - Upflow, Downflow, and Horizontal Furnaces and Coils (Coil Only Ratings)
UNIT MODEL
COIL CFM RANGE
(MINIMUM–
MAXIMUM)
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER1EER
TOTAL SENS.
RAC13L18B23S CF/CM/CU18A 14.5 450–750 600 17.2 13.0 13.00 11.50
RAC13L18B23S CF/CM/CU18B 17.5 450–750 600 17.2 13.8 13.00 11.50
RAC13L18B23S CF/CM/CU24A 14.5 450–750 600 17.4 13.9 13.00 11.50
RAC13L18B23S CF/CM/CU24B 17.5 450–750 600 17.4 13.9 13.00 11.50
RAC13L18B23S CF/CM/CU30A 14.5 450–750 600 17.6 14.1 13.00 11.50
RAC13L18B23S CF/CM/CU30B 17.5 450–750 600 17.6 14.1 13.00 11.50
RAC13L18B23S CF/CM/CU36B 17.5 450–750 600 17.6 14.0 13.25 11.75
RAC13L18B23S CF/CM/CU36C 21.0 450–750 600 17.6 14.0 13.25 11.75
RAC13L18B23S CF/CM24C 21.0 450–750 600 17.4 13.9 13.00 11.50
RAC13L18B23S CF/CM30C 21.0 450–750 600 17.6 14.1 13.00 11.50
RAC13L18B23S CF/CM36A 14.5 450–750 600 17.6 14.0 13.25 11.75
RAC13L18B23S CF/CM36D 24.5 450–750 600 17.6 14.0 13.25 11.75
RAC13L24B24S CF/CM/CU24A 14.5 600–1000 800 23.6 16.8 13.00 11.50
RAC13L24B24S CF/CM/CU24B 17.5 600–1000 800 23.6 18.9 13.00 11.50
RAC13L24B24S CF/CM/CU30A 14.5 600–1000 800 23.6 19.3 13.00 11.50
RAC13L24B24S CF/CM/CU30B 17.5 600–1000 800 23.6 19.3 13.00 11.50
RAC13L24B24S CF/CM/CU36B 17.5 600–1000 800 23.8 19.2 13.00 11.50
RAC13L24B24S CF/CM/CU36C 21.0 600–1000 800 23.8 19.2 13.00 11.50
RAC13L24B24S CF/CM/CU42C 21.0 600 - 1000 800 24.0 19.3 13.00 11.50
RAC13L24B24S CF/CM24C 21.0 600–1000 800 23.6 18.9 13.00 11.50
RAC13L24B24S CF/CM30C 21.0 600–1000 800 23.6 19.3 13.00 11.50
RAC13L24B24S CF/CM36A 14.5 600–1000 800 23.8 19.2 13.00 11.50
RAC13L24B24S CF/CM36D 24.5 600–1000 800 23.8 19.2 13.00 11.50
RAC13L24B24S CF/CM42D 24.5 600–1000 800 24.0 19.3 13.00 11.50
RAC13L24B24S CF42B 17.5 600–1000 800 24.0 19.3 13.00 11.50
RAC13L30B23S CF/CM/CU30B 17.5 800–1200 1000 28.6 21.4 13.00 11.00
RAC13L30B23S CF/CM/CU36B 17.5 800–1200 1000 29.0 23.0 13.00 11.25
RAC13L30B23S CF/CM/CU36C 21.0 800–1200 1000 29.0 23.0 13.00 11.25
RAC13L30B23S CF/CM/CU42C 21.0 800–1200 1000 29.0 22.8 13.00 11.25
RAC13L30B23S CF/CM30C 21.0 800–1200 1000 28.8 22.8 13.00 11.00
RAC13L30B23S CF/CM36A 14.5 800–1200 900 28.6 21.8 13.00 11.00
RAC13L30B23S CF/CM36D 24.5 800–1200 1000 29.0 23.0 13.00 11.25
RAC13L30B23S CF/CM42D 24.5 800–1200 1000 29.0 22.8 13.00 11.25
RAC13L36B24S CF/CM/CU36B 17.5 1000–1400 1200 35.4 23.6 13.00 11.00
RAC13L36B24S CF/CM/CU36B 17.5 1000–1400 1200 35.4 23.6 13.00 11.00

5752574-UTG-C-1020
10 Johnson Controls Ducted Systems
– = Not Applicable.
MP Modular Air Handlers use Coil Only Ratings.
Furnaces that are listed individually in the above table, such as the RGF1L*P, RGF19*P, and RGF1L*E, use Coil Only Ratings.
RAC13L36B24S CF/CM/CU36C 21.0 1000–1400 1200 35.4 28.0 13.00 11.00
RAC13L36B24S CF/CM/CU42C 21.0 1000–1400 1200 35.8 27.6 13.00 11.00
RAC13L36B24S CF/CM/CU48C 21.0 1000–1400 1200 35.8 27.8 13.00 11.25
RAC13L36B24S CF/CM/CU48D 24.5 1000–1400 1200 35.8 27.8 13.00 11.25
RAC13L36B24S CF/CM36D 24.5 1000–1400 1200 35.4 28.0 13.00 11.00
RAC13L36B24S CF/CM42D 24.5 1000–1400 1200 35.8 27.6 13.00 11.00
RAC13L36B24S CF42B 17.5 1000–1400 1200 35.8 27.6 13.00 11.00
RAC13L42B24S CF/CM/CU42C 21.0 1200–1600 1400 40.5 29.0 13.00 11.00
RAC13L42B24S CF/CM/CU42C 21.0 1200–1600 1400 40.5 29.0 13.00 11.00
RAC13L42B24S CF/CM/CU48C 21.0 1200–1600 1400 41.0 32.1 13.00 11.25
RAC13L42B24S CF/CM/CU48D 24.5 1200–1600 1400 41.0 32.1 13.00 11.25
RAC13L42B24S CF/CM/CU60C 21.0 1200–1600 1400 40.5 31.6 13.00 11.25
RAC13L42B24S CF/CM42D 24.5 1200–1600 1400 41.0 32.4 13.00 11.25
RAC13L42B24S CF/CM64D 24.5 1200–1600 1400 42.0 33.1 13.00 11.50
RAC13L48B23S CF/CM/CU48C 21.0 1400–1800 1600 46.0 33.5 13.00 11.00
RAC13L48B23S CF/CM/CU48D 24.5 1400–1800 1600 46.0 33.5 13.00 11.00
RAC13L48B23S CF/CM/CU60C 21.0 1400–1800 1600 48.0 36.0 13.00 11.25
RAC13L48B23S CF/CM/CU60D 24.5 1400–1800 1600 48.0 36.0 13.00 11.25
RAC13L48B23S CF/CM64D 24.5 1400–1800 1600 48.0 36.0 13.00 11.25
RAC13L60B23S CF/CM/CU60C 21.0 1520–1920 1725 55.0 41.0 13.00 11.00
RAC13L60B23S CF/CM/CU60D 24.5 1520–1920 1725 55.5 38.0 13.00 11.00
RAC13L60B23S CF/CM/CU60D 24.5 1520–1920 1725 55.5 38.0 13.00 11.00
RAC13L60B23S CF/CM64D 24.5 1520–1920 1725 56.5 42.5 13.00 11.00
For rated condition information, see the COOLING CAPACITY - With Air Handler Coils table footnotes.
1. Requires a S1-2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
COOLING CAPACITY - Upflow, Downflow, and Horizontal Furnaces and Coils (Coil Only Ratings) (Continued)
UNIT MODEL
COIL CFM RANGE
(MINIMUM–
MAXIMUM)
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER1EER
TOTAL SENS.

5752574-UTG-C-1020
Johnson Controls Ducted Systems 11
COOLING CAPACITY - With High Efficiency Motor Furnaces1
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.
RAC13L18B23S RGF2L060AE12MP11 14.5 CF/CM/CU18A 625 17.8 14.5 14.75 12.75
RAC13L18B23S RGF2L060AE12MP11 14.5 CF/CM/CU18B 650 17.9 14.9 14.75 12.75
RAC13L18B23S RGF2L060AE12MP11 14.5 CF/CM/CU24A 625 17.9 14.6 15.00 12.75
RAC13L18B23S RGF2L060AE12MP11 14.5 CF/CM/CU24B 650 18.0 14.9 15.00 12.75
RAC13L18B23S RGF2L060AE12MP11 14.5 CF/CM/CU30A 625 18.0 14.5 14.75 12.75
RAC13L18B23S RGF2L060AE12MP11 14.5 CF/CM/CU30B 650 18.0 14.9 15.00 12.75
RAC13L18B23S RGF2L060AE12MP11 14.5 CF/CM/CU36B 650 18.0 15.0 15.00 12.75
RAC13L18B23S RGF2L060AE12MP11 14.5 CF/CM36A 625 18.0 14.6 15.00 12.75
RAC13L18B23S RGF2L080BE12MP11 17.5 CF/CM/CU18B 675 18.0 15.2 15.00 12.75
RAC13L18B23S RGF2L080BE12MP11 17.5 CF/CM/CU24B 675 18.0 15.4 15.00 12.75
RAC13L18B23S RGF2L080BE12MP11 17.5 CF/CM/CU30B 675 18.0 15.0 15.00 12.75
RAC13L18B23S RGF2L080BE12MP11 17.5 CF/CM/CU36B 675 18.0 15.0 15.00 12.75
RAC13L18B23S RGF2L080BE12MP11 17.5 CF/CM24C 675 18.0 15.4 15.00 12.75
RAC13L18B23S RGF2L080BE12MP11 17.5 CF/CM30C 675 18.0 15.0 15.00 12.75
RAC13L18B23S RGF29040AE10MP11 14.5 CF/CM/CU18A 675 17.7 15.0 13.75 12.25
RAC13L18B23S RGF29040AE10MP11 14.5 CF/CM/CU18B 525 17.3 13.0 14.50 12.75
RAC13L18B23S RGF29040AE10MP11 14.5 CF/CM/CU24A 675 17.7 15.1 14.00 12.25
RAC13L18B23S RGF29040AE10MP11 14.5 CF/CM/CU24B 525 17.4 13.2 14.75 12.75
RAC13L18B23S RGF29040AE10MP11 14.5 CF/CM/CU30A 675 18.0 15.0 13.75 12.50
RAC13L18B23S RGF29040AE10MP11 14.5 CF/CM/CU30B 525 17.6 13.4 14.25 12.75
RAC13L18B23S RGF29040AE10MP11 14.5 CF/CM/CU36B 525 17.7 13.3 14.50 12.75
RAC13L18B23S RGF29040AE10MP11 14.5 CF/CM36A 675 18.0 15.0 14.00 12.50
RAC13L18B23S RGF19060BE12MP12 17.5 CF/CM/CU18B 675 17.9 15.1 15.00 12.75
RAC13L18B23S RGF19060BE12MP12 17.5 CF/CM/CU24B 675 17.9 15.3 15.00 12.75
RAC13L18B23S RGF19060BE12MP12 17.5 CF/CM/CU30B 675 18.0 15.0 14.50 12.75
RAC13L18B23S RGF19060BE12MP12 17.5 CF/CM/CU36B 675 18.0 15.0 15.00 12.75
RAC13L18B23S RGF19060BE12MP12 17.5 CF/CM24C 675 17.9 15.3 15.00 12.75
RAC13L18B23S RGF19060BE12MP12 17.5 CF/CM30C 675 18.0 15.0 14.75 12.75
RAC13L18B23S RGF19080CE16MP12 21.0 CF/CM/CU36C 600 18.0 14.3 15.00 12.75
RAC13L18B23S RGF19080CE16MP12 21.0 CF/CM24C 600 17.9 14.2 15.00 12.75
RAC13L18B23S RGF19080CE16MP12 21.0 CF/CM30C 600 18.0 14.4 15.00 12.75
RAC13L18B23S RGF19080CE16MP12 21.0 CF/CM36D 600 18.0 14.3 15.00 12.75
RAC13L18B23S RGF19100CE16MP12 21.0 CF/CM/CU36C 650 18.0 14.9 15.00 12.75
RAC13L18B23S RGF19100CE16MP12 21.0 CF/CM24C 625 18.0 14.7 15.00 12.75
RAC13L18B23S RGF19100CE16MP12 21.0 CF/CM30C 625 18.0 14.5 15.00 12.75
RAC13L18B23S RGF19100CE16MP12 21.0 CF/CM36D 650 18.0 14.9 15.00 12.75
RAC13L18B23S RGF29040AE12MP11 14.5 CF/CM/CU18A 675 17.7 15.0 13.75 12.25
RAC13L18B23S RGF29040AE12MP11 14.5 CF/CM/CU18B 525 17.3 13.0 14.50 12.75
RAC13L18B23S RGF29040AE12MP11 14.5 CF/CM/CU24A 675 17.7 15.1 14.00 12.25
RAC13L18B23S RGF29040AE12MP11 14.5 CF/CM/CU24B 525 17.4 13.2 14.75 12.75
RAC13L18B23S RGF29040AE12MP11 14.5 CF/CM/CU30A 675 18.0 15.0 13.75 12.50
RAC13L18B23S RGF29040AE12MP11 14.5 CF/CM/CU30B 525 17.6 13.4 14.25 12.75
RAC13L18B23S RGF29040AE12MP11 14.5 CF/CM/CU36B 525 17.7 13.3 14.50 12.75
RAC13L18B23S RGF29040AE12MP11 14.5 CF/CM36A 675 18.0 15.0 14.00 12.50
RAC13L18B23S RGF29060BE12MP11 17.5 CF/CM/CU18B 675 17.9 15.1 15.00 12.75
RAC13L18B23S RGF29060BE12MP11 17.5 CF/CM/CU24B 675 17.9 15.3 15.00 12.75
RAC13L18B23S RGF29060BE12MP11 17.5 CF/CM/CU30B 675 18.0 15.0 14.50 12.75
RAC13L18B23S RGF29060BE12MP11 17.5 CF/CM/CU36B 675 18.0 15.0 15.00 12.75
RAC13L18B23S RGF29060BE12MP11 17.5 CF/CM24C 675 17.9 15.3 15.00 12.75
RAC13L18B23S RGF29060BE12MP11 17.5 CF/CM30C 675 18.0 15.0 14.75 12.75
RAC13L18B23S RGF29080CE16MP11 21.0 CF/CM/CU36C 600 18.0 14.3 15.00 12.75
RAC13L18B23S RGF29080CE16MP11 21.0 CF/CM24C 600 17.9 14.2 15.00 12.75
RAC13L18B23S RGF29080CE16MP11 21.0 CF/CM30C 600 18.0 14.4 15.00 12.75

5752574-UTG-C-1020
12 Johnson Controls Ducted Systems
RAC13L18B23S RGF29080CE16MP11 21.0 CF/CM36D 600 18.0 14.3 15.00 12.75
RAC13L18B23S RGF29100CE16MP11 21.0 CF/CM/CU36C 650 18.0 14.9 15.00 12.75
RAC13L18B23S RGF29100CE16MP11 21.0 CF/CM24C 625 18.0 14.7 15.00 12.75
RAC13L18B23S RGF29100CE16MP11 21.0 CF/CM30C 625 18.0 14.5 15.00 12.75
RAC13L18B23S RGF29100CE16MP11 21.0 CF/CM36D 650 18.0 14.9 15.00 12.75
RAC13L18B23S RGF1L060AE12MP11 14.5 CF/CM/CU18A 625 17.8 14.5 14.75 12.75
RAC13L18B23S RGF1L060AE12MP11 14.5 CF/CM/CU18B 650 17.9 14.9 14.75 12.75
RAC13L18B23S RGF1L060AE12MP11 14.5 CF/CM/CU24A 625 17.9 14.6 15.00 12.75
RAC13L18B23S RGF1L060AE12MP11 14.5 CF/CM/CU24B 650 18.0 14.9 15.00 12.75
RAC13L18B23S RGF1L060AE12MP11 14.5 CF/CM/CU30A 625 18.0 14.5 14.75 12.75
RAC13L18B23S RGF1L060AE12MP11 14.5 CF/CM/CU30B 650 18.0 14.9 15.00 12.75
RAC13L18B23S RGF1L060AE12MP11 14.5 CF/CM/CU36B 650 18.0 15.0 15.00 12.75
RAC13L18B23S RGF1L060AE12MP11 14.5 CF/CM36A 625 18.0 14.6 15.00 12.75
RAC13L18B23S RGF1L080BE12MP11 17.5 CF/CM/CU18B 675 18.0 15.2 15.00 12.75
RAC13L18B23S RGF1L080BE12MP11 17.5 CF/CM/CU24B 675 18.0 15.4 15.00 12.75
RAC13L18B23S RGF1L080BE12MP11 17.5 CF/CM/CU30B 675 18.0 15.0 15.00 12.75
RAC13L18B23S RGF1L080BE12MP11 17.5 CF/CM/CU36B 675 18.0 15.0 15.00 12.75
RAC13L18B23S RGF1L080BE12MP11 17.5 CF/CM24C 675 18.0 15.4 15.00 12.75
RAC13L18B23S RGF1L080BE12MP11 17.5 CF/CM30C 675 18.0 15.0 15.00 12.75
RAC13L24B24S RLF1L060AE12MP11 14.5 CF/CM/CU24A 650 24.0 17.4 14.00 12.25
RAC13L24B24S RLF1L060AE12MP11 14.5 CF/CM/CU24B 700 24.0 18.1 14.25 12.25
RAC13L24B24S RLF1L060AE12MP11 14.5 CF/CM/CU30A 650 24.0 17.5 14.25 12.25
RAC13L24B24S RLF1L060AE12MP11 14.5 CF/CM/CU30B 700 24.0 18.4 14.50 12.50
RAC13L24B24S RLF1L060AE12MP11 14.5 CF/CM/CU36B 700 24.0 18.4 14.50 12.50
RAC13L24B24S RLF1L060AE12MP11 14.5 CF/CM36A 625 24.0 17.1 14.25 12.25
RAC13L24B24S RLF1L060AE12MP11 14.5 CF42B 675 24.0 18.2 14.25 12.50
RAC13L24B24S RLF1L080CE16MP11 21.0 CF/CM24C 950 24.0 19.6 14.00 12.25
RAC13L24B24S RLF1L080CE16MP11 21.0 CF/CM30C 950 24.0 21.5 14.50 12.50
RAC13L24B24S RLF19060BE12MP12 17.5 CF/CM/CU24B 650 24.0 17.4 14.00 12.25
RAC13L24B24S RLF19060BE12MP12 17.5 CF/CM/CU30B 675 24.0 17.8 14.25 12.25
RAC13L24B24S RLF19060BE12MP12 17.5 CF/CM/CU36B 650 24.0 17.5 14.25 12.25
RAC13L24B24S RLF19060BE12MP12 17.5 CF/CM/CU36C 700 24.0 18.4 14.25 12.25
RAC13L24B24S RLF19060BE12MP12 17.5 CF/CM/CU42C 700 24.0 18.4 14.25 12.25
RAC13L24B24S RLF19060BE12MP12 17.5 CF/CM24C 700 24.0 17.9 14.00 12.25
RAC13L24B24S RLF19060BE12MP12 17.5 CF/CM30C 700 24.0 18.4 14.25 12.25
RAC13L24B24S RLF19060BE12MP12 17.5 CF42B 675 24.0 18.2 14.50 12.50
RAC13L24B24S RLF19080CE16MP12 21.0 CF/CM/CU36C 925 24.0 21.5 14.75 12.50
RAC13L24B24S RLF19080CE16MP12 21.0 CF/CM/CU42C 925 24.0 21.4 14.75 12.50
RAC13L24B24S RLF19080CE16MP12 21.0 CF/CM24C 900 24.0 19.1 14.00 12.25
RAC13L24B24S RLF19080CE16MP12 21.0 CF/CM30C 925 24.0 21.4 14.50 12.50
RAC13L24B24S RLF19080CE16MP12 21.0 CF/CM36D 925 24.0 21.5 14.75 12.50
RAC13L24B24S RLF19080CE16MP12 21.0 CF/CM42D 925 24.0 21.4 14.75 12.50
RAC13L24B24S RGF1L040AE12MP12 14.5 CF/CM/CU24A 650 24.0 17.3 14.25 12.25
RAC13L24B24S RGF1L040AE12MP12 14.5 CF/CM/CU24B 775 24.0 19.0 14.25 12.25
RAC13L24B24S RGF1L040AE12MP12 14.5 CF/CM/CU30A 725 24.0 18.6 14.25 12.25
RAC13L24B24S RGF1L040AE12MP12 14.5 CF/CM/CU30B 775 24.0 19.4 14.50 12.50
RAC13L24B24S RGF1L040AE12MP12 14.5 CF/CM/CU36B 775 24.0 19.5 14.50 12.50
RAC13L24B24S RGF1L040AE12MP12 14.5 CF/CM36A 725 24.0 18.6 14.50 12.50
RAC13L24B24S RGF1L040AE12MP12 14.5 CF42B 775 24.0 19.5 14.50 12.50
RAC13L24B24S RGF1L060AE12MP12 14.5 CF/CM/CU24A 725 24.0 18.4 14.25 12.25
RAC13L24B24S RGF1L060AE12MP12 14.5 CF/CM/CU24B 750 24.0 18.8 14.25 12.25
RAC13L24B24S RGF1L060AE12MP12 14.5 CF/CM/CU30A 775 24.0 19.4 14.25 12.25
RAC13L24B24S RGF1L060AE12MP12 14.5 CF/CM/CU30B 825 24.0 20.0 14.50 12.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
Johnson Controls Ducted Systems 13
RAC13L24B24S RGF1L060AE12MP12 14.5 CF/CM/CU36B 750 24.0 19.0 14.50 12.50
RAC13L24B24S RGF1L060AE12MP12 14.5 CF/CM36A 725 24.0 18.6 14.50 12.50
RAC13L24B24S RGF1L060AE12MP12 14.5 CF42B 750 24.0 19.3 14.50 12.50
RAC13L24B24S RGF1L080BE12MP12 17.5 CF/CM/CU24B 725 24.0 18.4 14.25 12.25
RAC13L24B24S RGF1L080BE12MP12 17.5 CF/CM/CU30B 725 24.0 18.6 14.50 12.50
RAC13L24B24S RGF1L080BE12MP12 17.5 CF/CM/CU36B 725 24.0 18.8 14.50 12.50
RAC13L24B24S RGF1L080BE12MP12 17.5 CF/CM/CU36C 750 24.0 19.0 14.50 12.50
RAC13L24B24S RGF1L080BE12MP12 17.5 CF/CM/CU42C 750 24.0 19.2 14.75 12.50
RAC13L24B24S RGF1L080BE12MP12 17.5 CF/CM24C 750 24.0 18.8 14.25 12.25
RAC13L24B24S RGF1L080BE12MP12 17.5 CF/CM30C 750 24.0 19.0 14.50 12.50
RAC13L24B24S RGF1L080BE12MP12 17.5 CF42B 725 24.0 18.9 14.75 12.50
RAC13L24B24S RGF1L080CE16MP12 21.0 CF/CM/CU36C 825 24.0 20.4 14.75 12.50
RAC13L24B24S RGF1L080CE16MP12 21.0 CF/CM/CU42C 825 24.0 20.0 15.00 12.50
RAC13L24B24S RGF1L080CE16MP12 21.0 CF/CM24C 825 24.0 19.8 14.50 12.50
RAC13L24B24S RGF1L080CE16MP12 21.0 CF/CM30C 825 24.0 20.0 15.00 12.50
RAC13L24B24S RGF1L080CE16MP12 21.0 CF/CM36D 825 24.0 20.4 14.75 12.50
RAC13L24B24S RGF1L080CE16MP12 21.0 CF/CM42D 825 24.0 20.2 14.75 12.50
RAC13L24B24S RGF1L100BE12MP12 17.5 CF/CM/CU24B 725 24.0 18.4 14.25 12.25
RAC13L24B24S RGF1L100BE12MP12 17.5 CF/CM/CU30B 725 24.0 18.6 14.50 12.50
RAC13L24B24S RGF1L100BE12MP12 17.5 CF/CM/CU36B 725 24.0 18.8 14.50 12.50
RAC13L24B24S RGF1L100BE12MP12 17.5 CF/CM/CU36C 725 24.0 18.8 14.50 12.50
RAC13L24B24S RGF1L100BE12MP12 17.5 CF/CM/CU42C 850 24.0 20.5 14.75 12.50
RAC13L24B24S RGF1L100BE12MP12 17.5 CF/CM24C 725 24.0 18.4 14.25 12.25
RAC13L24B24S RGF1L100BE12MP12 17.5 CF/CM30C 725 24.0 18.6 14.50 12.50
RAC13L24B24S RGF1L100BE12MP12 17.5 CF42B 825 24.0 20.0 14.75 12.50
RAC13L24B24S RGF1L100CE16MP12 21.0 CF/CM/CU36C 800 24.0 19.9 14.75 12.50
RAC13L24B24S RGF1L100CE16MP12 21.0 CF/CM/CU42C 800 24.0 19.8 15.00 12.50
RAC13L24B24S RGF1L100CE16MP12 21.0 CF/CM24C 800 24.0 19.3 14.50 12.50
RAC13L24B24S RGF1L100CE16MP12 21.0 CF/CM30C 800 24.0 20.0 14.75 12.50
RAC13L24B24S RGF1L100CE16MP12 21.0 CF/CM36D 800 24.0 19.9 14.75 12.50
RAC13L24B24S RGF1L100CE16MP12 21.0 CF/CM42D 800 24.0 19.8 14.75 12.50
RAC13L24B24S RGF1L120CE16MP12 21.0 CF/CM/CU36C 825 24.0 20.6 15.00 12.50
RAC13L24B24S RGF1L120CE16MP12 21.0 CF/CM/CU42C 825 24.0 20.2 15.00 12.50
RAC13L24B24S RGF1L120CE16MP12 21.0 CF/CM24C 800 24.0 19.3 14.50 12.50
RAC13L24B24S RGF1L120CE16MP12 21.0 CF/CM30C 800 24.0 20.0 14.75 12.50
RAC13L24B24S RGF1L120CE16MP12 21.0 CF/CM36D 825 24.0 20.6 14.75 12.50
RAC13L24B24S RGF1L120CE16MP12 21.0 CF/CM42D 825 24.0 20.2 14.75 12.50
RAC13L24B24S RGF2L060AE12MP11 14.5 CF/CM/CU24A 625 23.6 16.9 14.00 12.25
RAC13L24B24S RGF2L060AE12MP11 14.5 CF/CM/CU24B 725 24.0 18.4 14.25 12.50
RAC13L24B24S RGF2L060AE12MP11 14.5 CF/CM/CU30A 625 24.0 17.2 14.25 12.50
RAC13L24B24S RGF2L060AE12MP11 14.5 CF/CM/CU30B 800 24.0 19.8 14.50 12.50
RAC13L24B24S RGF2L060AE12MP11 14.5 CF/CM/CU36B 725 24.0 18.6 14.25 12.50
RAC13L24B24S RGF2L060AE12MP11 14.5 CF/CM36A 625 24.0 17.2 14.25 12.50
RAC13L24B24S RGF2L060AE12MP11 14.5 CF42B 725 24.0 18.7 14.50 12.50
RAC13L24B24S RGF2L080BE12MP11 17.5 CF/CM/CU24B 775 24.0 19.0 14.25 12.50
RAC13L24B24S RGF2L080BE12MP11 17.5 CF/CM/CU30B 775 24.0 19.4 14.50 12.50
RAC13L24B24S RGF2L080BE12MP11 17.5 CF/CM/CU36B 775 24.0 19.5 14.50 12.50
RAC13L24B24S RGF2L080BE12MP11 17.5 CF/CM/CU36C 850 24.0 20.4 14.50 12.50
RAC13L24B24S RGF2L080BE12MP11 17.5 CF/CM/CU42C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF2L080BE12MP11 17.5 CF/CM24C 775 24.0 19.0 14.25 12.50
RAC13L24B24S RGF2L080BE12MP11 17.5 CF/CM30C 775 24.0 19.4 14.50 12.50
RAC13L24B24S RGF2L080BE12MP11 17.5 CF42B 750 24.0 19.1 14.75 12.50
RAC13L24B24S RGF2L080CE16MP11 21.0 CF/CM/CU36C 700 24.0 18.4 14.75 12.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
14 Johnson Controls Ducted Systems
RAC13L24B24S RGF2L080CE16MP11 21.0 CF/CM/CU42C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF2L080CE16MP11 21.0 CF/CM24C 700 24.0 18.1 14.50 12.50
RAC13L24B24S RGF2L080CE16MP11 21.0 CF/CM30C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF2L080CE16MP11 21.0 CF/CM36D 725 24.0 18.8 14.75 12.50
RAC13L24B24S RGF2L080CE16MP11 21.0 CF/CM42D 725 24.0 18.9 15.00 12.50
RAC13L24B24S RGF2L100CE16MP11 21.0 CF/CM/CU36C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF2L100CE16MP11 21.0 CF/CM/CU42C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF2L100CE16MP11 21.0 CF/CM24C 700 24.0 18.1 14.50 12.50
RAC13L24B24S RGF2L100CE16MP11 21.0 CF/CM30C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF2L100CE16MP11 21.0 CF/CM36D 725 24.0 18.8 14.75 12.50
RAC13L24B24S RGF2L100CE16MP11 21.0 CF/CM42D 725 24.0 18.9 15.00 12.50
RAC13L24B24S RGF29040AE10MP11 14.5 CF/CM/CU24A 675 23.6 17.6 13.50 11.75
RAC13L24B24S RGF29040AE10MP11 14.5 CF/CM/CU24B 700 24.0 17.8 13.50 11.50
RAC13L24B24S RGF29040AE10MP11 14.5 CF/CM/CU30A 675 24.0 17.6 13.50 11.75
RAC13L24B24S RGF29040AE10MP11 14.5 CF/CM/CU30B 700 24.0 18.3 13.75 12.00
RAC13L24B24S RGF29040AE10MP11 14.5 CF/CM/CU36B 700 24.0 18.2 13.75 12.00
RAC13L24B24S RGF29040AE10MP11 14.5 CF/CM36A 675 24.0 17.8 13.50 11.75
RAC13L24B24S RGF29040AE10MP11 14.5 CF42B 675 24.0 18.0 13.75 12.00
RAC13L24B24S RGF19040AE10MP13 14.5 CF/CM/CU24A 600 23.2 16.5 13.50 11.50
RAC13L24B24S RGF19040AE10MP13 14.5 CF/CM/CU24B 625 23.6 16.9 13.75 11.75
RAC13L24B24S RGF19040AE10MP13 14.5 CF/CM/CU30A 600 24.0 16.8 14.00 12.25
RAC13L24B24S RGF19040AE10MP13 14.5 CF/CM/CU30B 625 24.0 17.2 14.00 12.25
RAC13L24B24S RGF19040AE10MP13 14.5 CF/CM/CU36B 625 24.0 17.2 14.00 12.25
RAC13L24B24S RGF19040AE10MP13 14.5 CF/CM36A 675 24.0 17.8 14.00 12.25
RAC13L24B24S RGF19040AE10MP13 14.5 CF42B 625 24.0 17.3 14.00 12.25
RAC13L24B24S RGF19060AE10MP13 14.5 CF/CM/CU24A 675 24.0 17.7 13.75 11.75
RAC13L24B24S RGF19060AE10MP13 14.5 CF/CM/CU24B 700 24.0 18.0 14.00 12.25
RAC13L24B24S RGF19060AE10MP13 14.5 CF/CM/CU30A 675 24.0 17.8 14.25 12.25
RAC13L24B24S RGF19060AE10MP13 14.5 CF/CM/CU30B 700 24.0 18.4 14.25 12.25
RAC13L24B24S RGF19060AE10MP13 14.5 CF/CM/CU36B 700 24.0 18.2 14.25 12.25
RAC13L24B24S RGF19060AE10MP13 14.5 CF/CM36A 675 24.0 18.0 14.25 12.25
RAC13L24B24S RGF19060AE10MP13 14.5 CF42B 700 24.0 18.5 14.25 12.25
RAC13L24B24S RGF19060BE12MP12 17.5 CF/CM/CU24B 675 24.0 17.7 14.00 12.25
RAC13L24B24S RGF19060BE12MP12 17.5 CF/CM/CU30B 675 24.0 18.0 14.25 12.50
RAC13L24B24S RGF19060BE12MP12 17.5 CF/CM/CU36B 675 24.0 18.0 14.25 12.50
RAC13L24B24S RGF19060BE12MP12 17.5 CF/CM/CU36C 700 24.0 18.4 14.25 12.50
RAC13L24B24S RGF19060BE12MP12 17.5 CF/CM/CU42C 700 24.0 18.4 14.50 12.50
RAC13L24B24S RGF19060BE12MP12 17.5 CF/CM24C 675 24.0 17.7 14.00 12.25
RAC13L24B24S RGF19060BE12MP12 17.5 CF/CM30C 675 24.0 18.0 14.25 12.50
RAC13L24B24S RGF19060BE12MP12 17.5 CF42B 675 24.0 18.2 14.50 12.50
RAC13L24B24S RGF19060BE12MP13 17.5 CF/CM/CU24B 750 24.0 18.6 14.00 12.25
RAC13L24B24S RGF19060BE12MP13 17.5 CF/CM/CU30B 750 24.0 18.9 14.50 12.50
RAC13L24B24S RGF19060BE12MP13 17.5 CF/CM/CU36B 750 24.0 19.0 14.25 12.25
RAC13L24B24S RGF19060BE12MP13 17.5 CF/CM/CU36C 750 24.0 19.0 14.25 12.25
RAC13L24B24S RGF19060BE12MP13 17.5 CF/CM/CU42C 750 24.0 19.1 14.25 12.25
RAC13L24B24S RGF19060BE12MP13 17.5 CF/CM24C 750 24.0 18.6 14.00 12.25
RAC13L24B24S RGF19060BE12MP13 17.5 CF/CM30C 750 24.0 18.9 14.25 12.25
RAC13L24B24S RGF19060BE12MP13 17.5 CF42B 725 24.0 18.7 14.50 12.50
RAC13L24B24S RGF19080BE12MP12 17.5 CF/CM/CU24B 700 24.0 17.9 14.25 12.50
RAC13L24B24S RGF19080BE12MP12 17.5 CF/CM/CU30B 700 24.0 18.4 14.50 12.50
RAC13L24B24S RGF19080BE12MP12 17.5 CF/CM/CU36B 700 24.0 18.4 14.50 12.50
RAC13L24B24S RGF19080BE12MP12 17.5 CF/CM/CU36C 925 24.0 21.3 14.50 12.50
RAC13L24B24S RGF19080BE12MP12 17.5 CF/CM/CU42C 700 24.0 18.4 14.50 12.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
Johnson Controls Ducted Systems 15
RAC13L24B24S RGF19080BE12MP12 17.5 CF/CM24C 700 24.0 18.1 14.25 12.50
RAC13L24B24S RGF19080BE12MP12 17.5 CF/CM30C 700 24.0 18.4 14.50 12.50
RAC13L24B24S RGF19080BE12MP12 17.5 CF42B 675 24.0 18.2 14.50 12.50
RAC13L24B24S RGF19080BE12MP13 17.5 CF/CM/CU24B 800 24.0 19.4 14.25 12.25
RAC13L24B24S RGF19080BE12MP13 17.5 CF/CM/CU30B 800 24.0 19.8 14.50 12.50
RAC13L24B24S RGF19080BE12MP13 17.5 CF/CM/CU36B 800 24.0 19.7 14.50 12.50
RAC13L24B24S RGF19080BE12MP13 17.5 CF/CM/CU36C 825 24.0 20.4 14.50 12.50
RAC13L24B24S RGF19080BE12MP13 17.5 CF/CM/CU42C 825 24.0 20.0 14.50 12.50
RAC13L24B24S RGF19080BE12MP13 17.5 CF/CM24C 800 24.0 19.4 14.25 12.25
RAC13L24B24S RGF19080BE12MP13 17.5 CF/CM30C 825 24.0 20.0 14.50 12.50
RAC13L24B24S RGF19080BE12MP13 17.5 CF42B 775 24.0 19.5 14.50 12.50
RAC13L24B24S RGF19080CE16MP12 21.0 CF/CM/CU36C 600 24.0 16.9 14.25 12.50
RAC13L24B24S RGF19080CE16MP12 21.0 CF/CM/CU42C 600 24.0 17.0 14.75 12.50
RAC13L24B24S RGF19080CE16MP12 21.0 CF/CM24C 600 23.4 16.6 14.25 12.50
RAC13L24B24S RGF19080CE16MP12 21.0 CF/CM30C 600 24.0 17.0 14.50 12.50
RAC13L24B24S RGF19080CE16MP12 21.0 CF/CM36D 600 24.0 16.9 14.25 12.50
RAC13L24B24S RGF19080CE16MP12 21.0 CF/CM42D 600 24.0 17.0 14.75 12.50
RAC13L24B24S RGF19080CE16MP13 21.0 CF/CM/CU36C 750 24.0 19.0 14.25 12.50
RAC13L24B24S RGF19080CE16MP13 21.0 CF/CM/CU42C 750 24.0 19.2 14.75 12.50
RAC13L24B24S RGF19080CE16MP13 21.0 CF/CM24C 750 24.0 18.8 14.50 12.50
RAC13L24B24S RGF19080CE16MP13 21.0 CF/CM30C 750 24.0 19.0 14.50 12.50
RAC13L24B24S RGF19080CE16MP13 21.0 CF/CM36D 925 24.0 21.3 14.25 12.50
RAC13L24B24S RGF19080CE16MP13 21.0 CF/CM42D 750 24.0 19.2 14.75 12.50
RAC13L24B24S RGF19100CE16MP12 21.0 CF/CM/CU36C 650 24.0 17.7 14.50 12.50
RAC13L24B24S RGF19100CE16MP12 21.0 CF/CM/CU42C 650 24.0 17.9 14.75 12.50
RAC13L24B24S RGF19100CE16MP12 21.0 CF/CM24C 625 24.0 17.0 14.25 12.50
RAC13L24B24S RGF19100CE16MP12 21.0 CF/CM30C 625 24.0 17.3 14.50 12.50
RAC13L24B24S RGF19100CE16MP12 21.0 CF/CM36D 650 24.0 17.7 14.50 12.50
RAC13L24B24S RGF19100CE16MP12 21.0 CF/CM42D 650 24.0 17.9 14.75 12.50
RAC13L24B24S RGF19100CE16MP13 21.0 CF/CM/CU36C 800 24.0 19.9 14.50 12.50
RAC13L24B24S RGF19100CE16MP13 21.0 CF/CM/CU42C 800 24.0 19.8 14.75 12.50
RAC13L24B24S RGF19100CE16MP13 21.0 CF/CM24C 775 24.0 19.0 14.25 12.50
RAC13L24B24S RGF19100CE16MP13 21.0 CF/CM30C 800 24.0 20.0 14.50 12.50
RAC13L24B24S RGF19100CE16MP13 21.0 CF/CM36D 800 24.0 19.9 14.50 12.50
RAC13L24B24S RGF19100CE16MP13 21.0 CF/CM42D 800 24.0 19.8 14.75 12.50
RAC13L24B24S RGF29040AE12MP11 14.5 CF/CM/CU24A 675 23.6 17.6 13.50 11.75
RAC13L24B24S RGF29040AE12MP11 14.5 CF/CM/CU24B 700 24.0 17.8 13.50 11.50
RAC13L24B24S RGF29040AE12MP11 14.5 CF/CM/CU30A 675 24.0 17.6 13.50 11.75
RAC13L24B24S RGF29040AE12MP11 14.5 CF/CM/CU30B 700 24.0 18.3 13.75 12.00
RAC13L24B24S RGF29040AE12MP11 14.5 CF/CM/CU36B 700 24.0 18.2 13.75 12.00
RAC13L24B24S RGF29040AE12MP11 14.5 CF/CM36A 675 24.0 17.8 13.50 11.75
RAC13L24B24S RGF29040AE12MP11 14.5 CF42B 675 24.0 18.0 13.75 12.00
RAC13L24B24S RGF29060BE12MP11 17.5 CF/CM/CU24B 675 24.0 17.7 14.00 12.25
RAC13L24B24S RGF29060BE12MP11 17.5 CF/CM/CU30B 675 24.0 18.0 14.25 12.50
RAC13L24B24S RGF29060BE12MP11 17.5 CF/CM/CU36B 675 24.0 18.0 14.25 12.50
RAC13L24B24S RGF29060BE12MP11 17.5 CF/CM/CU36C 700 24.0 18.4 14.25 12.50
RAC13L24B24S RGF29060BE12MP11 17.5 CF/CM/CU42C 700 24.0 18.4 14.50 12.50
RAC13L24B24S RGF29060BE12MP11 17.5 CF/CM24C 675 24.0 17.7 14.00 12.25
RAC13L24B24S RGF29060BE12MP11 17.5 CF/CM30C 675 24.0 18.0 14.25 12.50
RAC13L24B24S RGF29060BE12MP11 17.5 CF42B 675 24.0 18.2 14.50 12.50
RAC13L24B24S RGF29080BE12MP11 17.5 CF/CM/CU24B 700 24.0 17.9 14.25 12.50
RAC13L24B24S RGF29080BE12MP11 17.5 CF/CM/CU30B 700 24.0 18.4 14.50 12.50
RAC13L24B24S RGF29080BE12MP11 17.5 CF/CM/CU36B 700 24.0 18.4 14.50 12.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
16 Johnson Controls Ducted Systems
RAC13L24B24S RGF29080BE12MP11 17.5 CF/CM/CU36C 925 24.0 21.3 14.50 12.50
RAC13L24B24S RGF29080BE12MP11 17.5 CF/CM/CU42C 700 24.0 18.4 14.50 12.50
RAC13L24B24S RGF29080BE12MP11 17.5 CF/CM24C 700 24.0 18.1 14.25 12.50
RAC13L24B24S RGF29080BE12MP11 17.5 CF/CM30C 700 24.0 18.4 14.50 12.50
RAC13L24B24S RGF29080BE12MP11 17.5 CF42B 675 24.0 18.2 14.50 12.50
RAC13L24B24S RGF29080CE16MP11 21.0 CF/CM/CU36C 600 24.0 16.9 14.25 12.50
RAC13L24B24S RGF29080CE16MP11 21.0 CF/CM/CU42C 600 24.0 17.0 14.75 12.50
RAC13L24B24S RGF29080CE16MP11 21.0 CF/CM24C 600 23.4 16.6 14.25 12.50
RAC13L24B24S RGF29080CE16MP11 21.0 CF/CM30C 600 24.0 17.0 14.50 12.50
RAC13L24B24S RGF29080CE16MP11 21.0 CF/CM36D 600 24.0 16.9 14.25 12.50
RAC13L24B24S RGF29080CE16MP11 21.0 CF/CM42D 600 24.0 17.0 14.75 12.50
RAC13L24B24S RGF29100CE16MP11 21.0 CF/CM/CU36C 650 24.0 17.7 14.50 12.50
RAC13L24B24S RGF29100CE16MP11 21.0 CF/CM/CU42C 650 24.0 17.9 14.75 12.50
RAC13L24B24S RGF29100CE16MP11 21.0 CF/CM24C 625 24.0 17.0 14.25 12.50
RAC13L24B24S RGF29100CE16MP11 21.0 CF/CM30C 625 24.0 17.3 14.50 12.50
RAC13L24B24S RGF29100CE16MP11 21.0 CF/CM36D 650 24.0 17.7 14.50 12.50
RAC13L24B24S RGF29100CE16MP11 21.0 CF/CM42D 650 24.0 17.9 14.75 12.50
RAC13L24B24S RGF1L060AE12MP11 14.5 CF/CM/CU24A 625 23.6 16.9 14.00 12.25
RAC13L24B24S RGF1L060AE12MP11 14.5 CF/CM/CU24B 725 24.0 18.4 14.25 12.50
RAC13L24B24S RGF1L060AE12MP11 14.5 CF/CM/CU30A 625 24.0 17.2 14.25 12.50
RAC13L24B24S RGF1L060AE12MP11 14.5 CF/CM/CU30B 800 24.0 19.8 14.50 12.50
RAC13L24B24S RGF1L060AE12MP11 14.5 CF/CM/CU36B 725 24.0 18.6 14.25 12.50
RAC13L24B24S RGF1L060AE12MP11 14.5 CF/CM36A 625 24.0 17.2 14.25 12.50
RAC13L24B24S RGF1L060AE12MP11 14.5 CF42B 725 24.0 18.7 14.50 12.50
RAC13L24B24S RGF1L080BE12MP11 17.5 CF/CM/CU24B 775 24.0 19.0 14.25 12.50
RAC13L24B24S RGF1L080BE12MP11 17.5 CF/CM/CU30B 775 24.0 19.4 14.50 12.50
RAC13L24B24S RGF1L080BE12MP11 17.5 CF/CM/CU36B 775 24.0 19.5 14.50 12.50
RAC13L24B24S RGF1L080BE12MP11 17.5 CF/CM/CU36C 850 24.0 20.4 14.50 12.50
RAC13L24B24S RGF1L080BE12MP11 17.5 CF/CM/CU42C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF1L080BE12MP11 17.5 CF/CM24C 775 24.0 19.0 14.25 12.50
RAC13L24B24S RGF1L080BE12MP11 17.5 CF/CM30C 775 24.0 19.4 14.50 12.50
RAC13L24B24S RGF1L080BE12MP11 17.5 CF42B 750 24.0 19.1 14.75 12.50
RAC13L24B24S RGF1L080CE16MP11 21.0 CF/CM/CU36C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF1L080CE16MP11 21.0 CF/CM/CU42C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF1L080CE16MP11 21.0 CF/CM24C 700 24.0 18.1 14.50 12.50
RAC13L24B24S RGF1L080CE16MP11 21.0 CF/CM30C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF1L080CE16MP11 21.0 CF/CM36D 725 24.0 18.8 14.75 12.50
RAC13L24B24S RGF1L080CE16MP11 21.0 CF/CM42D 725 24.0 18.9 15.00 12.50
RAC13L24B24S RGF1L100CE16MP11 21.0 CF/CM/CU36C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF1L100CE16MP11 21.0 CF/CM/CU42C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF1L100CE16MP11 21.0 CF/CM24C 700 24.0 18.1 14.50 12.50
RAC13L24B24S RGF1L100CE16MP11 21.0 CF/CM30C 700 24.0 18.4 14.75 12.50
RAC13L24B24S RGF1L100CE16MP11 21.0 CF/CM36D 725 24.0 18.8 14.75 12.50
RAC13L24B24S RGF1L100CE16MP11 21.0 CF/CM42D 725 24.0 18.9 15.00 12.50
RAC13L30B23S RLF1L060AE12MP11 14.5 CF/CM36A 825 28.8 21.2 13.75 12.00
RAC13L30B23S RGF1L040AE12MP12 14.5 CF/CM36A 825 28.8 21.2 13.75 12.00
RAC13L30B23S RGF1L060AE12MP12 14.5 CF/CM36A 825 28.8 21.2 13.75 12.00
RAC13L30B23S RGF2L060AE12MP11 14.5 CF/CM/CU30A 875 28.6 21.6 13.50 11.75
RAC13L30B23S RGF2L060AE12MP11 14.5 CF/CM/CU30B 925 28.8 22.4 13.75 12.00
RAC13L30B23S RGF2L060AE12MP11 14.5 CF/CM/CU36B 925 29.0 22.4 13.75 12.00
RAC13L30B23S RGF2L060AE12MP11 14.5 CF/CM36A 875 28.8 21.6 13.50 11.75
RAC13L30B23S RGF2L060AE12MP11 14.5 CF42B 925 29.2 22.4 14.00 12.00
RAC13L30B23S RGF2L080BE12MP11 17.5 CF/CM/CU30B 825 28.6 21.0 14.00 12.25
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
Johnson Controls Ducted Systems 17
RAC13L30B23S RGF2L080BE12MP11 17.5 CF/CM/CU36B 825 28.8 21.0 14.00 12.25
RAC13L30B23S RGF2L080BE12MP11 17.5 CF/CM/CU36C 825 28.8 21.0 14.00 12.25
RAC13L30B23S RGF2L080BE12MP11 17.5 CF/CM/CU42C 825 28.8 21.2 14.25 12.25
RAC13L30B23S RGF2L080BE12MP11 17.5 CF/CM30C 825 28.6 21.0 14.00 12.25
RAC13L30B23S RGF2L080BE12MP11 17.5 CF42B 950 29.4 22.8 14.00 12.25
RAC13L30B23S RGF2L080CE16MP11 21.0 CF/CM/CU36C 950 29.2 22.8 14.25 12.25
RAC13L30B23S RGF2L080CE16MP11 21.0 CF/CM/CU42C 950 29.6 23.0 14.25 12.25
RAC13L30B23S RGF2L080CE16MP11 21.0 CF/CM30C 950 29.2 22.8 14.25 12.25
RAC13L30B23S RGF2L080CE16MP11 21.0 CF/CM36D 975 29.6 23.2 14.25 12.25
RAC13L30B23S RGF2L080CE16MP11 21.0 CF/CM42D 975 29.8 23.2 14.50 12.50
RAC13L30B23S RGF2L100CE16MP11 21.0 CF/CM/CU36C 950 29.2 22.8 14.25 12.25
RAC13L30B23S RGF2L100CE16MP11 21.0 CF/CM/CU42C 950 29.6 23.0 14.25 12.25
RAC13L30B23S RGF2L100CE16MP11 21.0 CF/CM30C 950 29.2 22.8 14.25 12.25
RAC13L30B23S RGF2L100CE16MP11 21.0 CF/CM36D 975 29.6 23.2 14.25 12.25
RAC13L30B23S RGF2L100CE16MP11 21.0 CF/CM42D 975 29.8 23.2 14.50 12.50
RAC13L30B23S RGF2L100CE20MP11 21.0 CF/CM/CU36C 1000 29.6 23.4 14.50 12.50
RAC13L30B23S RGF2L100CE20MP11 21.0 CF/CM/CU42C 1000 29.8 23.6 14.50 12.50
RAC13L30B23S RGF2L100CE20MP11 21.0 CF/CM30C 1000 29.4 23.2 14.25 12.25
RAC13L30B23S RGF2L100CE20MP11 21.0 CF/CM36D 1000 29.6 23.4 14.50 12.50
RAC13L30B23S RGF2L100CE20MP11 21.0 CF/CM42D 1000 29.8 23.6 14.50 12.50
RAC13L30B23S RGF2L120CE20MP11 21.0 CF/CM/CU36C 1000 29.6 23.4 14.50 12.50
RAC13L30B23S RGF2L120CE20MP11 21.0 CF/CM/CU42C 1000 29.8 23.6 14.50 12.50
RAC13L30B23S RGF2L120CE20MP11 21.0 CF/CM30C 1000 29.4 23.2 14.25 12.25
RAC13L30B23S RGF2L120CE20MP11 21.0 CF/CM36D 1000 29.6 23.4 14.50 12.50
RAC13L30B23S RGF2L120CE20MP11 21.0 CF/CM42D 1000 29.8 23.6 14.50 12.50
RAC13L30B23S RGF19040AE10MP13 14.5 CF/CM36A 825 28.6 20.9 13.00 11.25
RAC13L30B23S RGF19060AE10MP13 14.5 CF/CM36A 825 28.6 21.1 13.25 11.50
RAC13L30B23S RGF19060BE12MP12 17.5 CF/CM/CU30B 850 28.6 21.6 13.75 12.00
RAC13L30B23S RGF19060BE12MP12 17.5 CF/CM/CU36B 850 28.8 21.4 13.75 12.00
RAC13L30B23S RGF19060BE12MP12 17.5 CF/CM/CU36C 875 29.0 21.8 14.00 12.00
RAC13L30B23S RGF19060BE12MP12 17.5 CF/CM/CU42C 875 29.0 21.8 14.00 12.25
RAC13L30B23S RGF19060BE12MP12 17.5 CF/CM30C 875 28.6 21.6 13.75 12.00
RAC13L30B23S RGF19060BE12MP12 17.5 CF42B 850 28.8 21.4 13.75 12.00
RAC13L30B23S RGF19080BE12MP12 17.5 CF/CM/CU30B 875 28.6 21.6 14.00 12.00
RAC13L30B23S RGF19080BE12MP12 17.5 CF/CM/CU36B 875 29.0 21.8 14.00 12.25
RAC13L30B23S RGF19080BE12MP12 17.5 CF/CM/CU36C 900 29.2 22.2 14.00 12.25
RAC13L30B23S RGF19080BE12MP12 17.5 CF/CM/CU42C 900 29.2 22.2 14.00 12.25
RAC13L30B23S RGF19080BE12MP12 17.5 CF/CM30C 900 28.8 22.2 14.00 12.25
RAC13L30B23S RGF19080BE12MP12 17.5 CF42B 875 29.0 21.8 14.00 12.25
RAC13L30B23S RGF19080CE16MP12 21.0 CF/CM/CU36C 975 29.4 23.0 14.00 12.25
RAC13L30B23S RGF19080CE16MP12 21.0 CF/CM/CU42C 975 29.6 23.0 14.25 12.25
RAC13L30B23S RGF19080CE16MP12 21.0 CF/CM30C 975 29.2 23.0 14.00 12.25
RAC13L30B23S RGF19080CE16MP12 21.0 CF/CM36D 975 29.4 23.0 14.00 12.25
RAC13L30B23S RGF19080CE16MP12 21.0 CF/CM42D 975 29.6 23.0 14.25 12.25
RAC13L30B23S RGF19100CE16MP12 21.0 CF/CM/CU36C 975 29.4 23.0 14.00 12.25
RAC13L30B23S RGF19100CE16MP12 21.0 CF/CM/CU42C 975 29.6 23.0 14.25 12.25
RAC13L30B23S RGF19100CE16MP12 21.0 CF/CM30C 975 29.2 23.0 14.00 12.25
RAC13L30B23S RGF19100CE16MP12 21.0 CF/CM36D 1000 29.6 23.6 14.25 12.25
RAC13L30B23S RGF19100CE16MP12 21.0 CF/CM42D 1000 29.6 23.4 14.25 12.25
RAC13L30B23S RGF19120DE20MP12 24.5 CF/CM36D 950 29.4 23.0 14.50 12.50
RAC13L30B23S RGF19120DE20MP12 24.5 CF/CM42D 950 29.6 23.0 14.50 12.50
RAC13L30B23S RGF29060BE12MP11 17.5 CF/CM/CU30B 850 28.6 21.6 13.75 12.00
RAC13L30B23S RGF29060BE12MP11 17.5 CF/CM/CU36B 850 28.8 21.4 13.75 12.00
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
18 Johnson Controls Ducted Systems
RAC13L30B23S RGF29060BE12MP11 17.5 CF/CM/CU36C 875 29.0 21.8 14.00 12.00
RAC13L30B23S RGF29060BE12MP11 17.5 CF/CM/CU42C 875 29.0 21.8 14.00 12.25
RAC13L30B23S RGF29060BE12MP11 17.5 CF/CM30C 875 28.6 21.6 13.75 12.00
RAC13L30B23S RGF29060BE12MP11 17.5 CF42B 850 28.8 21.4 13.75 12.00
RAC13L30B23S RGF29080BE12MP11 17.5 CF/CM/CU30B 875 28.6 21.6 14.00 12.00
RAC13L30B23S RGF29080BE12MP11 17.5 CF/CM/CU36B 875 29.0 21.8 14.00 12.25
RAC13L30B23S RGF29080BE12MP11 17.5 CF/CM/CU36C 900 29.2 22.2 14.00 12.25
RAC13L30B23S RGF29080BE12MP11 17.5 CF/CM/CU42C 900 29.2 22.2 14.00 12.25
RAC13L30B23S RGF29080BE12MP11 17.5 CF/CM30C 900 28.8 22.2 14.00 12.25
RAC13L30B23S RGF29080BE12MP11 17.5 CF42B 875 29.0 21.8 14.00 12.25
RAC13L30B23S RGF29080CE16MP11 21.0 CF/CM/CU36C 975 29.4 23.0 14.00 12.25
RAC13L30B23S RGF29080CE16MP11 21.0 CF/CM/CU42C 975 29.6 23.0 14.25 12.25
RAC13L30B23S RGF29080CE16MP11 21.0 CF/CM30C 975 29.2 23.0 14.00 12.25
RAC13L30B23S RGF29080CE16MP11 21.0 CF/CM36D 975 29.4 23.0 14.00 12.25
RAC13L30B23S RGF29080CE16MP11 21.0 CF/CM42D 975 29.6 23.0 14.25 12.25
RAC13L30B23S RGF29100CE16MP11 21.0 CF/CM/CU36C 975 29.4 23.0 14.00 12.25
RAC13L30B23S RGF29100CE16MP11 21.0 CF/CM/CU42C 975 29.6 23.0 14.25 12.25
RAC13L30B23S RGF29100CE16MP11 21.0 CF/CM30C 975 29.2 23.0 14.00 12.25
RAC13L30B23S RGF29100CE16MP11 21.0 CF/CM36D 1000 29.6 23.6 14.25 12.25
RAC13L30B23S RGF29100CE16MP11 21.0 CF/CM42D 1000 29.6 23.4 14.25 12.25
RAC13L30B23S RGF29120DE20MP11 24.5 CF/CM36D 950 29.4 23.0 14.50 12.50
RAC13L30B23S RGF29120DE20MP11 24.5 CF/CM42D 950 29.6 23.0 14.50 12.50
RAC13L30B23S RGF1L060AE12MP11 14.5 CF/CM/CU30A 875 28.6 21.6 13.50 11.75
RAC13L30B23S RGF1L060AE12MP11 14.5 CF/CM/CU30B 925 28.8 22.4 13.75 12.00
RAC13L30B23S RGF1L060AE12MP11 14.5 CF/CM/CU36B 925 29.0 22.4 13.75 12.00
RAC13L30B23S RGF1L060AE12MP11 14.5 CF/CM36A 875 28.8 21.6 13.50 11.75
RAC13L30B23S RGF1L060AE12MP11 14.5 CF42B 925 29.2 22.4 14.00 12.00
RAC13L30B23S RGF1L080BE12MP11 17.5 CF/CM/CU30B 825 28.6 21.0 14.00 12.25
RAC13L30B23S RGF1L080BE12MP11 17.5 CF/CM/CU36B 825 28.8 21.0 14.00 12.25
RAC13L30B23S RGF1L080BE12MP11 17.5 CF/CM/CU36C 825 28.8 21.0 14.00 12.25
RAC13L30B23S RGF1L080BE12MP11 17.5 CF/CM/CU42C 825 28.8 21.2 14.25 12.25
RAC13L30B23S RGF1L080BE12MP11 17.5 CF/CM30C 825 28.6 21.0 14.00 12.25
RAC13L30B23S RGF1L080BE12MP11 17.5 CF42B 950 29.4 22.8 14.00 12.25
RAC13L30B23S RGF1L080CE16MP11 21.0 CF/CM/CU36C 950 29.2 22.8 14.25 12.25
RAC13L30B23S RGF1L080CE16MP11 21.0 CF/CM/CU42C 950 29.6 23.0 14.25 12.25
RAC13L30B23S RGF1L080CE16MP11 21.0 CF/CM30C 950 29.2 22.8 14.25 12.25
RAC13L30B23S RGF1L080CE16MP11 21.0 CF/CM36D 975 29.6 23.2 14.25 12.25
RAC13L30B23S RGF1L080CE16MP11 21.0 CF/CM42D 975 29.8 23.2 14.50 12.50
RAC13L30B23S RGF1L100CE16MP11 21.0 CF/CM/CU36C 950 29.2 22.8 14.25 12.25
RAC13L30B23S RGF1L100CE16MP11 21.0 CF/CM/CU42C 950 29.6 23.0 14.25 12.25
RAC13L30B23S RGF1L100CE16MP11 21.0 CF/CM30C 950 29.2 22.8 14.25 12.25
RAC13L30B23S RGF1L100CE16MP11 21.0 CF/CM36D 975 29.6 23.2 14.25 12.25
RAC13L30B23S RGF1L100CE16MP11 21.0 CF/CM42D 975 29.8 23.2 14.50 12.50
RAC13L30B23S RGF1L100CE20MP11 21.0 CF/CM/CU36C 1000 29.6 23.4 14.50 12.50
RAC13L30B23S RGF1L100CE20MP11 21.0 CF/CM/CU42C 1000 29.8 23.6 14.50 12.50
RAC13L30B23S RGF1L100CE20MP11 21.0 CF/CM30C 1000 29.4 23.2 14.25 12.25
RAC13L30B23S RGF1L100CE20MP11 21.0 CF/CM36D 1000 29.6 23.4 14.50 12.50
RAC13L30B23S RGF1L100CE20MP11 21.0 CF/CM42D 1000 29.8 23.6 14.50 12.50
RAC13L30B23S RGF1L120CE20MP11 21.0 CF/CM/CU36C 1000 29.6 23.4 14.50 12.50
RAC13L30B23S RGF1L120CE20MP11 21.0 CF/CM/CU42C 1000 29.8 23.6 14.50 12.50
RAC13L30B23S RGF1L120CE20MP11 21.0 CF/CM30C 1000 29.4 23.2 14.25 12.25
RAC13L30B23S RGF1L120CE20MP11 21.0 CF/CM36D 1000 29.6 23.4 14.50 12.50
RAC13L30B23S RGF1L120CE20MP11 21.0 CF/CM42D 1000 29.8 23.6 14.50 12.50
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
Johnson Controls Ducted Systems 19
RAC13L36B24S RLF1L060AE12MP11 14.5 CF/CM/CU36B 1025 35.2 26.2 13.50 11.50
RAC13L36B24S RLF1L060AE12MP11 14.5 CF42B 1025 35.4 26.3 13.50 11.50
RAC13L36B24S RLF1L080CE16MP11 21.0 CF/CM/CU36C 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RLF1L080CE16MP11 21.0 CF/CM/CU42C 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RLF1L080CE16MP11 21.0 CF/CM/CU48C 1125 36.0 27.6 14.25 12.25
RAC13L36B24S RLF1L080CE16MP11 21.0 CF/CM/CU48D 1125 36.0 27.6 14.25 12.00
RAC13L36B24S RLF1L080CE16MP11 21.0 CF/CM36D 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RLF1L080CE16MP11 21.0 CF/CM42D 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RLF1L100CE20MP11 21.0 CF/CM/CU36C 1050 35.6 26.6 14.25 12.25
RAC13L36B24S RLF1L100CE20MP11 21.0 CF/CM/CU42C 1050 36.0 26.6 14.25 12.25
RAC13L36B24S RLF1L100CE20MP11 21.0 CF/CM/CU48C 1050 36.0 26.8 14.50 12.25
RAC13L36B24S RLF1L100CE20MP11 21.0 CF/CM/CU48D 1050 36.0 26.8 14.50 12.25
RAC13L36B24S RLF1L100CE20MP11 21.0 CF/CM36D 1050 35.6 26.6 14.25 12.00
RAC13L36B24S RLF1L100CE20MP11 21.0 CF/CM42D 1050 36.0 26.6 14.25 12.00
RAC13L36B24S RLF19060BE12MP12 17.5 CF/CM/CU36B 1025 35.0 26.0 13.25 11.50
RAC13L36B24S RLF19060BE12MP12 17.5 CF/CM/CU36C 1050 35.2 26.3 13.25 11.50
RAC13L36B24S RLF19060BE12MP12 17.5 CF/CM/CU42C 1050 35.8 26.3 13.25 11.50
RAC13L36B24S RLF19060BE12MP12 17.5 CF/CM/CU48C 1050 35.6 26.3 13.50 11.50
RAC13L36B24S RLF19060BE12MP12 17.5 CF42B 1025 35.2 26.2 13.25 11.50
RAC13L36B24S RLF19080CE16MP12 21.0 CF/CM/CU36C 1075 35.6 26.8 13.75 12.00
RAC13L36B24S RLF19080CE16MP12 21.0 CF/CM/CU42C 1075 36.0 26.6 13.75 12.00
RAC13L36B24S RLF19080CE16MP12 21.0 CF/CM/CU48C 1075 36.0 26.7 14.00 12.00
RAC13L36B24S RLF19080CE16MP12 21.0 CF/CM/CU48D 1100 36.0 27.6 14.00 11.75
RAC13L36B24S RLF19080CE16MP12 21.0 CF/CM36D 1100 35.8 27.2 13.75 11.75
RAC13L36B24S RLF19080CE16MP12 21.0 CF/CM42D 1100 36.0 27.3 14.00 12.00
RAC13L36B24S RLF19100CE20MP12 21.0 CF/CM/CU36C 1125 36.0 27.5 14.25 12.25
RAC13L36B24S RLF19100CE20MP12 21.0 CF/CM/CU42C 1125 36.0 27.4 14.25 12.25
RAC13L36B24S RLF19100CE20MP12 21.0 CF/CM/CU48C 1125 36.0 27.6 14.50 12.25
RAC13L36B24S RLF19100CE20MP12 21.0 CF/CM/CU48D 1150 36.0 27.9 14.25 12.00
RAC13L36B24S RLF19100CE20MP12 21.0 CF/CM36D 1150 36.0 27.9 14.25 12.00
RAC13L36B24S RLF19100CE20MP12 21.0 CF/CM42D 1150 36.0 27.5 14.25 12.00
RAC13L36B24S RGF1L040AE12MP12 14.5 CF/CM/CU36B 1025 35.2 26.1 13.75 11.75
RAC13L36B24S RGF1L040AE12MP12 14.5 CF42B 1000 35.6 25.7 13.75 11.75
RAC13L36B24S RGF1L060AE12MP12 14.5 CF/CM/CU36B 1025 35.2 26.1 13.75 11.75
RAC13L36B24S RGF1L060AE12MP12 14.5 CF42B 1000 35.6 25.7 13.75 11.75
RAC13L36B24S RGF1L080BE12MP12 17.5 CF/CM/CU36B 1025 35.2 26.1 13.75 11.75
RAC13L36B24S RGF1L080BE12MP12 17.5 CF/CM/CU36C 1050 35.4 26.5 13.75 11.75
RAC13L36B24S RGF1L080BE12MP12 17.5 CF/CM/CU42C 1050 36.0 26.4 13.75 11.75
RAC13L36B24S RGF1L080BE12MP12 17.5 CF/CM/CU48C 1050 35.8 26.4 13.75 11.75
RAC13L36B24S RGF1L080BE12MP12 17.5 CF42B 1025 35.4 26.3 13.75 11.75
RAC13L36B24S RGF1L080CE16MP12 21.0 CF/CM/CU36C 1100 35.8 27.2 14.00 12.00
RAC13L36B24S RGF1L080CE16MP12 21.0 CF/CM/CU42C 1100 36.0 27.3 14.00 12.25
RAC13L36B24S RGF1L080CE16MP12 21.0 CF/CM/CU48C 1100 36.0 27.5 14.25 12.25
RAC13L36B24S RGF1L080CE16MP12 21.0 CF/CM/CU48D 1100 36.0 27.5 14.25 12.00
RAC13L36B24S RGF1L080CE16MP12 21.0 CF/CM36D 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RGF1L080CE16MP12 21.0 CF/CM42D 1125 36.0 27.4 14.25 12.00
RAC13L36B24S RGF1L080CE20MP12 21.0 CF/CM/CU36C 1250 36.0 28.8 14.00 12.00
RAC13L36B24S RGF1L080CE20MP12 21.0 CF/CM/CU42C 1250 36.0 28.6 14.00 12.25
RAC13L36B24S RGF1L080CE20MP12 21.0 CF/CM/CU48C 1250 36.0 28.9 14.25 12.25
RAC13L36B24S RGF1L080CE20MP12 21.0 CF/CM/CU48D 1275 36.0 29.3 14.25 12.00
RAC13L36B24S RGF1L080CE20MP12 21.0 CF/CM36D 1275 36.0 29.1 14.00 12.00
RAC13L36B24S RGF1L080CE20MP12 21.0 CF/CM42D 1275 36.0 29.1 14.00 12.00
RAC13L36B24S RGF1L100BE12MP12 17.5 CF/CM/CU36B 1075 35.4 26.6 13.50 11.75
RAC13L36B24S RGF1L100BE12MP12 17.5 CF/CM/CU36C 1100 35.6 27.0 13.75 11.75
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.

5752574-UTG-C-1020
20 Johnson Controls Ducted Systems
RAC13L36B24S RGF1L100BE12MP12 17.5 CF/CM/CU42C 1100 35.8 27.1 13.75 11.75
RAC13L36B24S RGF1L100BE12MP12 17.5 CF/CM/CU48C 1100 36.0 27.4 13.75 11.75
RAC13L36B24S RGF1L100BE12MP12 17.5 CF42B 1050 35.8 26.3 13.50 11.75
RAC13L36B24S RGF1L100CE16MP12 21.0 CF/CM/CU36C 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RGF1L100CE16MP12 21.0 CF/CM/CU42C 1125 36.0 27.4 14.00 12.00
RAC13L36B24S RGF1L100CE16MP12 21.0 CF/CM/CU48C 1125 36.0 27.6 14.25 12.25
RAC13L36B24S RGF1L100CE16MP12 21.0 CF/CM/CU48D 1125 36.0 27.6 14.25 12.00
RAC13L36B24S RGF1L100CE16MP12 21.0 CF/CM36D 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RGF1L100CE16MP12 21.0 CF/CM42D 1125 36.0 27.4 14.00 12.00
RAC13L36B24S RGF1L100CE20MP12 21.0 CF/CM/CU36C 1250 36.0 28.8 14.00 12.00
RAC13L36B24S RGF1L100CE20MP12 21.0 CF/CM/CU42C 1250 36.0 28.6 14.00 12.00
RAC13L36B24S RGF1L100CE20MP12 21.0 CF/CM/CU48C 1250 36.0 28.9 14.25 12.25
RAC13L36B24S RGF1L100CE20MP12 21.0 CF/CM/CU48D 1275 36.0 29.3 14.25 12.00
RAC13L36B24S RGF1L100CE20MP12 21.0 CF/CM36D 1275 36.0 29.1 14.00 12.00
RAC13L36B24S RGF1L100CE20MP12 21.0 CF/CM42D 1275 36.0 29.1 14.00 12.00
RAC13L36B24S RGF1L120CE16MP12 21.0 CF/CM/CU36C 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RGF1L120CE16MP12 21.0 CF/CM/CU42C 1125 36.0 27.4 14.00 12.00
RAC13L36B24S RGF1L120CE16MP12 21.0 CF/CM/CU48C 1125 36.0 27.6 14.25 12.25
RAC13L36B24S RGF1L120CE16MP12 21.0 CF/CM/CU48D 1125 36.0 27.6 14.25 12.00
RAC13L36B24S RGF1L120CE16MP12 21.0 CF/CM36D 1125 36.0 27.5 14.00 12.00
RAC13L36B24S RGF1L120CE16MP12 21.0 CF/CM42D 1125 36.0 27.4 14.00 12.00
RAC13L36B24S RGF1L120CE20MP12 21.0 CF/CM/CU36C 1275 36.0 29.1 14.00 12.00
RAC13L36B24S RGF1L120CE20MP12 21.0 CF/CM/CU42C 1275 36.0 29.1 14.00 12.00
RAC13L36B24S RGF1L120CE20MP12 21.0 CF/CM/CU48C 1300 36.0 29.4 14.25 12.00
RAC13L36B24S RGF1L120CE20MP12 21.0 CF/CM/CU48D 1300 36.0 29.4 14.25 12.00
RAC13L36B24S RGF1L120CE20MP12 21.0 CF/CM36D 1300 35.4 27.2 13.50 11.50
RAC13L36B24S RGF1L120CE20MP12 21.0 CF/CM42D 1300 36.0 29.6 14.00 12.00
RAC13L36B24S RGF1L130DE20MP12 24.5 CF/CM/CU48D 1300 36.0 29.6 14.25 12.25
RAC13L36B24S RGF1L130DE20MP12 24.5 CF/CM36D 1300 35.4 27.2 13.50 11.75
RAC13L36B24S RGF1L130DE20MP12 24.5 CF/CM42D 1300 36.0 29.6 14.25 12.25
RAC13L36B24S RGF2L060AE12MP11 14.5 CF/CM/CU36B 1125 35.2 27.2 13.25 11.50
RAC13L36B24S RGF2L060AE12MP11 14.5 CF42B 1125 36.0 27.1 13.25 11.50
RAC13L36B24S RGF2L080BE12MP11 17.5 CF/CM/CU36B 975 35.0 25.6 13.75 11.75
RAC13L36B24S RGF2L080BE12MP11 17.5 CF/CM/CU36C 1000 35.2 25.8 13.75 12.00
RAC13L36B24S RGF2L080BE12MP11 17.5 CF/CM/CU42C 1000 35.6 25.7 13.75 12.00
RAC13L36B24S RGF2L080BE12MP11 17.5 CF/CM/CU48C 1000 35.6 25.9 14.00 12.00
RAC13L36B24S RGF2L080BE12MP11 17.5 CF42B 1150 36.0 27.3 13.25 11.50
RAC13L36B24S RGF2L080CE16MP11 21.0 CF/CM/CU36C 1150 36.0 27.9 14.00 12.00
RAC13L36B24S RGF2L080CE16MP11 21.0 CF/CM/CU42C 1150 36.0 27.6 14.00 12.00
RAC13L36B24S RGF2L080CE16MP11 21.0 CF/CM/CU48C 1150 36.0 27.7 14.25 12.00
RAC13L36B24S RGF2L080CE16MP11 21.0 CF/CM/CU48D 975 35.6 25.7 14.25 12.25
RAC13L36B24S RGF2L080CE16MP11 21.0 CF/CM36D 975 35.2 25.7 14.00 12.00
RAC13L36B24S RGF2L080CE16MP11 21.0 CF/CM42D 975 35.6 25.5 14.25 12.25
RAC13L36B24S RGF2L100CE16MP11 21.0 CF/CM/CU36C 1150 36.0 27.9 14.00 12.00
RAC13L36B24S RGF2L100CE16MP11 21.0 CF/CM/CU42C 1150 36.0 27.6 14.00 12.00
RAC13L36B24S RGF2L100CE16MP11 21.0 CF/CM/CU48C 1150 36.0 27.7 14.25 12.00
RAC13L36B24S RGF2L100CE16MP11 21.0 CF/CM/CU48D 975 35.6 25.7 14.25 12.25
RAC13L36B24S RGF2L100CE16MP11 21.0 CF/CM36D 975 35.2 25.7 14.00 12.00
RAC13L36B24S RGF2L100CE16MP11 21.0 CF/CM42D 975 35.6 25.5 14.25 12.25
RAC13L36B24S RGF2L100CE20MP11 21.0 CF/CM/CU36C 1000 35.2 25.7 14.25 12.25
RAC13L36B24S RGF2L100CE20MP11 21.0 CF/CM/CU42C 1000 35.8 25.9 14.25 12.25
RAC13L36B24S RGF2L100CE20MP11 21.0 CF/CM/CU48C 1000 35.8 26.1 14.50 12.25
RAC13L36B24S RGF2L100CE20MP11 21.0 CF/CM/CU48D 1000 35.8 26.1 14.50 12.25
COOLING CAPACITY - With High Efficiency Motor Furnaces1 (Continued)
UNIT
MODEL
FURNACE COIL
MODEL2
COOLING
MODEL WIDTH RATED
CFM
NET MBH SEER EER
TOTAL SENS.
