York YCWJ45EE0 Owner's manual

INSTALL., OPER., MAINT.
RecipPak LIQUID CHILLERS
WATER COOLED - RECIPROCATING HERMETIC
Supersedes: 150.24-NM27 (1295) Form 150.24-NM27 (298)
MODELS
200, 230, 460-3-60
60 HZ
YCWJ45EE0, YCRJ45E00,
YCWJ55HE0, YCRJ55H00,
YCWJ56HF0, YCRJ56H00,
YCWJ66KH0, YCRJ66K00,
YCWJ67KH0, YCRJ67K00,
YCWJ77KH0, YCRJ77K00,
YCWJ88MH0, YCRJ88M00
YCWJ99MJ0, YCRJ99M00
STYLE A*
50 HZ
YCWJ56EE0, YCRJ56E00,
YCWJ66HE0, YCRJ66H00,
YCWJ67HF0, YCRJ67H00,
YCWJ77KH0, YCRJ77K00,
YCWJ78KH0, YCRJ78K00,
YCWJ88KH0, YCRJ88K00,
YCWJ99MH0, YCRJ99M00
STYLE A*
26214A
*With EPROM (Standard, Brine & Metric Models, Combined)
031-01652-001
or
031-01096-001

2YORK INTERNATIONAL
TABLE OF CONTENTS
GENERAL DESCRIPTION
YORK YCWJ45EE0  YCWJ99MJ0 and YCRJ45E00 
YCRJ99M00 Series Packaged Liquid Chillers are of the
semi-hermetic type. Each unit includes dual refrigerant
circuits, accessible hermetic motor-compressors, a di-
rect expansion type liquid cooler, a shell and tube con-
denser, refrigerant piping and feed controls, a micropro-
cessor control center, and power panel.
Each unit is fully assembled on a steel base, piped,
insulated, wired and are fully charged with refrigerant.
YCR models for remote condenser application are fur-
nished less condenser, and with a refrigerant holding
charge.
CODE STATUS
The units are designed in accordance with U.L. (200,
230, 460-3-60), N.E.C., ASHRAE/ANSI STANDARD 15,
and ASME Codes.
GENERAL INFORMATION
GENERAL INFORMATION .............................................................................. 2
NOMENCLATURE ........................................................................................... 3
OPERATIONAL LIMITATIONS .......................................................................... 6
PHYSICAL DATA ............................................................................................ 8
DIMENSIONS ................................................................................................. 9
MOUNTING DETAIL FOR SPRING ISOLATORS ......................................... 9
CONTROL PANEL ...................................................................................... 9
WATER COOLED ....................................................................................... 10
REMOTE CONDENSER ............................................................................. 11
ELECTRICAL DATA ......................................................................................... 12
INSTALLATION ................................................................................................ 18
WIRING DIAGRAM ......................................................................................... 27
UNIT CONTROLS AND OPERATION ............................................................... 38
COMPRESSOR CAPACITY CONTROL ........................................................... 86
START-UP CHECKLIST / REPORT ................................................................. 87
PREVENTATIVE MAINTENANCE ................................................................... 92
OPTIONS ........................................................................................................ 93
TROUBLESHOOTING CHART......................................................................... 100
TEMPERATURE CONVERSION TABLE.......................................................... 106
WARNING
HIGH VOLTAGE
is used in the operation of this equipment.
DEATH OR SERIOUS INJURY
may result if personnel fail to observe safety precautions.
Work on electronic equipment should not be undertaken unless the individual(s) have been trained in
the proper maintenance of equipment and is (are) familiar with its potential hazards.
Shut off power to equipment before beginning work and follow lockout procedures. When working
inside equipment with power off, take care to discharge every capacitor likely to hold dangerous
potential.
Be careful not to contact high voltage connections when installing or operating this equipment.
LOW VOLTAGE
DO NOT be misled by the term low voltage.
Voltages as low as 50 volts may cause death.

FORM 150.24-NM27
YORK INTERNATIONAL 3
Compressor Series
Compressor Style
No. of Active Cylinders
(4, 6, & 8)
Stroke (3, 4)
Steps of Unloading (1, 2, 3)
Motor Size (M, N, Q, P, S, T)
Voltage Code:
17 = 200-3-60
28 = 230-3-60
40 = 380-3-60
46 = 460-3-60
50 = 380/415-3-50
64 = 346-3-50
Motor Manufacturer
(S = A.O. Smith, L = Leroy Somer)
J G 4 3 1 M -17 S
COMPRESSOR NOMENCLATURE
J MODELS
UNIT NOMENCLATURE
The model number denotes the following characteristics of the unit:
YCWJ67HF0-46PA*
YORK S = Special
* = Blank if not used
Chiller
Design Level
W = Water Cooled
R = Remote Condenser Type Start
P = Part Wind
Compressor Type (J or Z)
Voltage Code:
System #1Compressor Code 17 = 200-3-60
4 thru 9 (See PHYSICAL DATA) 28 = 230-3-60
40 = 380-3-60
System #2 Compressor Code 46 = 460-3-60
4 thru 9 (See PHYSICAL DATA) 50 = 380/415-3-50
58 = 575-3-60
Cooler Code: 64 = 346-3-50
E, H, K, M
Blank
Condenser Code:
E, F, H, J

4YORK INTERNATIONAL
FIG. 1  UNIT COMPONENTS
SYS. 1 COMPRESSOR SYS. 2 COMPRESSOR
COOLER
INLET
LIQUID STOP
VALVE
LIQUID
SOLENOID
VALVES
FILTER DRIERS
LIQUID
STOP
VALVE
CONDENSER
1/2" RELIEF
VALVE
COOLER
OUTLET
COOLER
26125A
REAR VIEW
OPTIONAL SINGLE
POINT POWER
CONNECTION
POWER PANEL
CONTROL PANEL WITH
KEYBOARD
CONDENSER
INLET
CONDENSER
OUTLET
26124A
FRONT VIEW

FORM 150.24-NM27
YORK INTERNATIONAL 5
FIG. 1A  COMPRESOR COMPONENTS
COMPRESSOR
TERMINAL BOX
8 CYLINDER
MODEL J G COMPRESSOR
DISCHARGE
STOP VALVE
SUCTION PRESSURE
CONNECTION
CAPACITY CONTROL
SOLENOIDS
RAINTIGHT
TERMINAL BOX
SUCTION
STOP VALVE
SIGHT GLASSES (2)
OIL CHARGING
VALVE
CRANKCASE
HEATER
OIL PRESSURE
ACCESS CONNECTION
MOTOR
TERMINALS
SUPPRESSORS
MOTOR PROTECTOR (MP)
27299A
27599A

6YORK INTERNATIONAL
VOLTAGE LIMITATIONS
The following voltage limitations are absolute and opera-
tion beyond these limitations may cause serious dam-
age to the compressor.
NOMINAL VOLTAGE VOLTAGE
MIN. MAX.
200-3-60 180 220
230-3-60 207 253
380-3-60 355 415
460-3-60 414 506
380/415-3-50 342 440
346-3-50 311 381
575-3-60 517 633
OPERATIONAL LIMITATIONS
NOTES:
1. Measured externally on pump suction boss as shown below.
2. May be lower due to motor selection.
See Rating in Form 150.24-EG2.
3. 15°F on Brine application.
4. Standard units can not be operated below 40°F leaving chilled
liquid.
* These may be higher for heat recovery or other special units.
OPERATING LIMITATIONS
Maximum Compressor Ratio ............................... 9.5:1
Maximum Operating Differential (PSI) ................... 325
Maximum Suction Pressure (PSIG) ........................ 84
Maximum Discharge Temp. (°F) ............................ 275
Minimum Superheat At Compressor ..................... 5°F
Minimum Oil Pressure
(above suction pressure) ............................... 20 psi
Oll Temperature (Max.)1.................................. 160°F *
Maximum Sat. Discharge Temp.2....................... 150°F
Maximum Ambient ............................................. 115°F
Minimum Ambient ................................................40°F
Minimum Leaving Liquid Temp.3...........................40°F
Maximum Leaving Liquid Temp. ........................ 50°F *
YCWJ & YCRJ Models
YCWJ (60 HZ) 45EE0 55HE0 56HF0 66KH0 67KH0 77KH0 88MH0 99MJ0
YCWJ (50 HZ) 56HE0 66HE0 67HF0 77KH0 78KH0 88KH0 99MH0 
DESCRIPTION
YCRJ (60 HZ) 45E00 55H00 56H00 66K00 67K00 77K00 88M00 99M00
YCRJ (50 HZ) 56E00 66H00 67H00 77K00 78K00 88K00 99M00 
Min. Cooler Water Flow (GPM) 195 140 140 245 245 245 315 315
Max. Cooler Water Flow (GPM) 535 535 535 696 696 696 803 803
Min. Condenser Water Flow (GPM) 211 211 285 300 300 300 300 470
Max. Condenser Water Flow (GPM) 704 704 800 1200 1200 1200 1200 1400
Min. Leaving Liquid Temp. (°F) * 40 40 40 40 40 40 40 40
Max. Leaving Liquid Temp. (°F) 50 50 50 50 50 50 50 50
Min. Entering Condenser Water Temp. (°F) 70 70 70 70 70 70 70 70
Max. Entering Condenser Water Temp. (°F) 110 110 110 110 110 110 110 110
Max. Saturated Discharge Temp. (°F) (YCRJ) 142 142 142 142 142 142 142 142
Min. Equipment Room Temp. (°F) 40 40 40 40 40 40 40 40
Max. Equipment Room Temp. (°F) 115 115 115 115 115 115 115 115
LD02344

FORM 150.24-NM27
YORK INTERNATIONAL 7
COOLER PRESSURE DROP CONDENSER PRESSURE DROP
CAUTION: Excessive flow will cause damage to the cooler. Do
not exceed max. cooler GPM Special care should be
taken when multiple chillers are fed by a single pump.
FIG. 2  COOLER WATER PRESSURE DROP
PRESSURE DROP KEY
MODEL YCWJ56EE0
LETTER FOR COOLER
LETTER FOR CONDENSER
LD02345 LD02346

8YORK INTERNATIONAL
PHYSICAL DATA
(YCWJ & YCRJ Models)
NOTES:
1. 3.0 Gal. Oil/Compressor
2. YCWJ Models only
3. YCRJ Models shipped with holding charge. This is lbs. per circuit.
60 HZ YCWJ 45E00 55HE0 56HF0 66KH0 67KH0 77KH0 88MH0 99MJ0
YCRJ 45E00 55H00 56H00 66K00 67K00 77K00 88M00 99M00
MODEL
50 HZ YCWJ 56EE0 66HE0 67HF0 77KH0 78KH0 88KH0 99MH0 
YCRJ 56E00 66H00 67H00 77K00 78K00 88K00 99M00 
COMPRESSOR
60 HZ SYS 1
G43-M(60HP) G44-M(60HP) G44-M(60HP) G63-N(70HP) G63-N(70HP) G64-Q(90HP) G83-Q(90HP) G84-T(135HP)
SYS 2 G44-M(60HP) G44-M(60HP) G63-N(70HP) G63-N(70HP) G64-Q(70HP) G64-Q(90HP) G83-Q(90HP) G84-T(135HP)
YCWJ
50 HZ SYS 1
G44-N(58HP) G63-P(67HP) G63-P(67HP) G64-Q(75HP) G64-Q(75HP) G83-S(96HP) G84-T(113HP) 
SYS 2 G63-P(67HP) G63-P(67HP) G64-Q(75HP) G64-Q(75HP) G83-S(96HP) G83-S(96HP) G84-T(113HP) 
60 HZ SYS 1
G43-M(60HP) G44-N(70HP) G44-N(70HP) G63-P(80HP) G63-P(80HP) G64-S(115HP) G83-S(115HP) G84-V(160HP)
SYS 2 G44-N(70HP) G44-N(70HP) G63-P(80HP) G63-P(80HP) G64-S(115HP) G64-S(115HP) G83-S(115HP) G84-V(160HP)
YCRJ
50 HZ SYS 1
G44-P(67HP) G63-Q(75HP) G63-Q(75HP) G64-S(96HP) G64-S(96HP) G83-T(113HP) G83-T(113HP) 
SYS 2 G63-Q(75HP) G63-Q(75HP) G64-S(96HP) G64-S(96HP) G83-T(113HP) G83-T(113HP) G83-T(113HP) 
UNIT 60 HZ 5 Steps 5 Steps 6 Steps 7 Steps 7 Steps 7 Steps 10 Steps 10 Steps
CAPACITY
CONTROL 50HZ 6 Steps 7 Steps 7 Steps 7 Steps 7 Steps 10 Steps 10 Steps 
COOLER  DUAL CIRCUIT
DWP REF. SIDE (PSIG) 235 235 235 235 235 235 235 235
DWP WATER SIDE (PSIG) 150 150 150 150 150 150 150 150
DlA.x LENGTH 14"x8" 16"x8" 16"x8" 18"x8" 18"x8" 18"x8" 20"x8" 20"x8"
WATER VOLUME (GALS.) 38 48 48 60 60 60 70 70
CONDENSER2
DWP REF. SIDE (PSIG) 350 350 350 365 365 365 365 365
DWP WATER SIDE (PSIG) 150 150 150 150 150 150 150 150
DlA.x LENGTH 16"x8" 16"x8" 16"x8" 18"x8" 18"x8" 18"x8" 18"x8" 18"x8"
WATER VOLUME (GALS.) 26 26 30 32 32 32 32 37
WEIGHTS (LBS.)
YCWJ SHIPPING 7,650 7,750 7,800 7,850 8,050 7,850 10,300 10,500
OPERATING 8,200 8,450 8,550 8,700 8,900 8,700 11,200 11,450
YCRJ SHIPPING 6,000 6,100 6,100 6,150 6,350 6,150 8,250 8,500
OPERATING 6,400 6,600 6,600 6,750 7,000 6,750 9,050 9,250
REFRIG. YCWJ SYS 1 70 85 85 85 99 143 143 148
CHARGE SYS 2 85 105 105 105 122 143 143 148
(LBS. R-22) YCRJ314 14 14 14 16 21 21 21

FORM 150.24-NM27
YORK INTERNATIONAL 9
MODEL WATER COOLED
NO. HZ LOAD POINTS WEIGHT
A B C D SHIPPING OPERATING
YCWJ45EE0 60 2,050 2,050 2,050 2,050 7,650 8,200
Isolator AWCB-1625
YCWJ55HE0 60 2,113 2,113 2,113 2,113 7,750 8,450
Isolator AWCB-1628
YCWJ56HF0 60 2,138 2,138 2,138 2,138 7,800 8,550
Isolator AWCB-1628
YCWJ66KH0 60 2,175 2,175 2,175 2,175 7,850 8,700
Isolator AWCB-1628
YCWJ67KH0 60 2,225 2,225 2,225 2,225 8,050 8,900
Isolator AWCB-1628
YCWJ77KH0 60 2,575 2,575 2,575 2,575 9,450 10,300
Isolator AWCB-1628
YCWJ88MH0 60 2,800 2,800 2,800 2,800 10,300 11,200
Isolator AWCB-1632
YCWJ99MJ0 60 2,863 2,863 2,863 2,863 10,500 11,450
Isolator AWCB-1632
YCWJ56EE0 50 2,050 2,050 2,050 2,050 7,650 8,200
Isolator AWCB-1625
YCWJ66HE0 50 2,113 2,113 2,113 2,113 7,750 8,450
Isolator AWCB-1628
YCWJ67HF0 50 2,138 2,138 2,138 2,138 7,800 8,550
Isolator AWCB-1628
YCWJ77KH0 50 2,175 2,175 2,175 2,175 9,450 10,300
Isolator AWCB-1628
YCWJ78KH0 50 2,225 2,225 2,225 2,225 8,050 8,900
Isolator AWCB-1628
YCWJ88KH0 50 2,575 2,575 2,575 2,575 9,450 10,450
Isolator AWCB-1628
YCWJ99MH0 50 2,800 2,800 2,800 2,800 10,300 11,200
Isolator AWCB-1632
MODEL NO. HZ REMOTE CONDENSER
YCWJ45E00 60 1600 1600 1600 1600 6,000 6,400
Isolator AWCB-1600
YCWJ55H00 60 1625 1625 1625 1625 5,950 6,500
Isolator AWCB-1625
YCWJ56H00 60 1650 1650 1650 1650 6,100 6,600
Isolator AWCB-1625
YCWJ66K00 60 1688 1688 1688 1688 6,150 6,750
Isolator AWCB-1625
YCWJ67K00 60 1750 1750 1750 1750 6,350 7,000
Isolator AWCB-1625
YCWJ77K00 60 1688 1688 1688 1688 6,150 6,750
Isolator AWCB-1625
YCWJ88M00 60 2263 2263 2263 2263 8,250 9,050
Isolator AWCB-1628
YCWJ99M00 60 2313 2313 2313 2313 8,500 9,250
Isolator AWCB-1628
YCWJ56E00 50 1600 1600 1600 1600 6,000 6,400
Isolator AWCB-1600
YCWJ66H00 50 1625 1625 1625 1625 5,950 6,500
Isolator AWCB-1625
YCWJ67H00 50 1650 1650 1650 1650 6,100 6,600
Isolator AWCB-1625
YCWJ77K00 50 1688 1688 1688 1688 6,150 6,750
Isolator AWCB-1625
YCWJ78K00 50 1750 1750 1750 1750 6,350 7,000
Isolator AWCB-1625
YCWJ88K00 50 1688 1688 1688 1688 7,800 8,450
Isolator AWCB-1625
YCWJ99M00 50 2263 2263 2263 2263 8,500 9,250
Isolator AWCB-1628
MOUNTING DETAIL
FOR SPRING ISOLATORS
(OPTIONAL)
WEIGHT DISTRIBUTION AND ISOLATOR LOCATIONS FOR EACH MODEL
WATER COOLED
ALL YCWJ & YCRJ Models except
YCWJ88MH0 & J99MJ0 & YCRJ88M00 - J99M00
REMOTE CONDENSER
YCWJ88MH0 - J99MJ0
& YCRJ88M00 - J99M00
DIMENSIONS (in.)
AWC L W T R S V
6-1/4" 4" 1/4" 5" 9/16" 5/8"
TYPE DEFLECTION MAX. SPRING
&LOAD COLOR
SIZE in. lbs. OUTER INNER
AWC-1600 1.0 1600 GRAY 
AWC-1625 1.0 2050 GRAY RED
AWC-1628 1.0 2500 GRAY GREEN
LD02347

10 YORK INTERNATIONAL
DIMENSIONS
WATER COOLED  YCWJ MODELS
MODEL
(50HZ) ABCD EFGH J KLMNP
YCWJ56E00 10'0-3/8" 6'1-7/16" 2'11" 2'9-1/8" 4'7-3/16" 8-1/4" 8-1/4" 3'6-1/2" 7-5/8" 1'7-3/4" 1'3-1/2" 5" 6" 4'11-11/16"
YCWJ66H00 10'0-3/8" 6'3-7/16" 2'11" 2'10-1/8" 4'7-3/16" 8-1/4" 8-1/4" 3'5-1/2" 9-5/8" 1'7-3/4" 1'3-1/8" 5" 8" 4'11-11/16"
YCWJ67H00 10'0-3/8" 6'7-3/16" 2'11" 2'10-1/8" 4'7-3/16" 8-1/4" 8-1/4" 3'5-1/2" 9-5/8" 1'7-3/4" 1'3-1/8" 5" 8" 4'11-11/16"
YCWJ77K00 10'0-3/8" 6'10-7/8" 3'1" 3'2-1/4" 4'8-1/2" 9" 9-7/8" 3'5-1/2" 1'1-7/8" 1'8" 1'3-1/2" 6" 8" 4'11-11/16"
YCWJ78K00 10'0-3/8" 6'9-7/8" 3'1" 3'2-1/4" 4'8-1/2" 9" 9-7/8" 3'5-1/2" 1'1-7/8" 1'8" 1'3-1/2" 6" 8" 4'11-11/16"
YCWJ88M00 10'0" 6'10-7/8" 3'1" 3'2-1/4" 4'8-1/2" 9" 9-7/8" 3'5-1/2" 1'1-7/8" 1'8" 1'3-1/2' 6" 8" 4'11-11/16"
YCWJ99M00 10'0" 9'1-1/8" 3'2-3/4" 3'2-3/4" 4'6-1/4" 9" 9-7/8" 3'5-1/2" 1'3-11/16" 1'9" 1'4-1/2" 6" 8" 5'1-9/16"
MODEL
(60HZ) ABCD EFGH J KLMNP
YCWJ45EE0 10'0-3/8" 6'1-7/16" 2'11" 2'9-1/8" 4'7-3/16" 8-1/4" 8-1/4" 3'6-1/2" 7-5/8" 1'7-3/4" 1'3-1/2" 5" 6" 4'11-11/16"
YCWJ55HE0 10'0-3/8" 6'3-7/16" 2'11" 2'10-1/8" 4'7-3/16" 8-1/4" 8-1/4" 3'5-1/2" 9-5/8" 1'7-3/4" 1'3-1/8" 5" 8" 4'11-11/16"
YCWJ56HF0 10'0-3/8" 6'7-3/16" 2'11" 2'10-1/8" 4'7-3/16" 8-1/4" 8-1/4" 3'5-1/2" 9-5/8" 1'7-3/4" 1'3-1/8" 5" 8" 4'11-11/16"
YCWJ66KH0 10'0-3/8" 6'10-7/8" 3'1" 3'2-1/4" 4'8-1/2" 9" 9-7/8" 3'5-1/2" 1'1-7/8" 1'8" 1'3-1/2" 6" 8' 4'11-11/16"
YCWJ67KH0 10'0-3/8" 6'9-7/8" 3'1" 3'2-1/4" 4'8-1/2" 9" 9-7/8" 3'5-1/2" 1'1-7/8" 1'8" 1'3-1/2" 6" 8" 4'11-11/16"
YCWJ77KH0 10'0" 6'10-7/8" 3'1" 3'2-1/4" 4'8-1/2" 9" 9-7/8" 3'5-1/2" 1'1-7/8" 1'8" 1'3-1/2" 6" 8" 4'11-11/16"
YCWJ88MH0 10'0" 9'1-1/8" 3'2-3/4" 3'2-3/4" 4'6-1/4" 9" 9-7/8" 3'5-1/2" 1'3-11/16" 1'9" 1'4-1/2" 6" 8" 5'1-9/16"
YCWJ99MJ0 10'0" 9'1-1/8" 3'2-3/4" 3'2-3/4" 4'6-1/4" 9" 9-7/8" 3'5-1/2" 1'3-11/16" 1'9" 1'4-1/2" 6" 8" 5'1-9/16"
CLEARANCES (All Models)  Minimum YORK required
clearances are as follows:
Rear to wall 2'-0"
Front to wall 2'-8"
Tube cleaning & removal 8'-0"(Either End)
Top 2'-0"
LD02348
