York YMC2 Guide

YMC2MODEL B
WITH OPTIVIEW™ CONTROL CENTER
CENTRIFUGAL LIQUID CHILLERS
INSTALLATION AND REASSEMBLY Supersedes: 160.84-N1 (416) Form 160.84-N1 (1116)
Issue Date:
November 22, 2016
LD17194

JOHNSON CONTROLS
2
FORM 160.84-N1
ISSUE DATE: 11/22/2016
This equipment is a relatively complicated apparatus.
During rigging, installation, operation, maintenance,
or service, individuals may be exposed to certain com-
ponents or conditions including, but not limited to:
heavy objects, refrigerants, materials under pressure,
rotating components, and both high and low voltage.
Each of these items has the potential, if misused or
handled improperly, to cause bodily injury or death. It
is the obligation and responsibility of rigging, instal-
lation, and operating/service personnel to identify and
recognize these inherent hazards, protect themselves,
and proceed safely in completing their tasks. Failure
to comply with any of these requirements could result
in serious damage to the equipment and the property in
IMPORTANT!
READ BEFORE PROCEEDING!
GENERAL SAFETY GUIDELINES
which it is situated, as well as severe personal injury or
death to themselves and people at the site.
This document is intended for use by owner-authorized
rigging, installation, and operating/service personnel. It
is expected that these individuals possess independent
training that will enable them to perform their assigned
tasks properly and safely. It is essential that, prior to
performing any task on this equipment, this individual
shall have read and understood the on-product labels,
this document and any referenced materials. This in-
dividual shall also be familiar with and comply with
all applicable industry and governmental standards and
regulations pertaining to the task in question.
SAFETY SYMBOLS
The following symbols are used in this document to alert the reader to specific situations:
Indicates a possible hazardous situation
which will result in death or serious injury
if proper care is not taken.
Indicates a potentially hazardous situa-
tion which will result in possible injuries
or damage to equipment if proper care is
not taken.
Identies a hazard which could lead to
damage to the machine, damage to other
equipment and/or environmental pollu-
tion if proper care is not taken or instruc-
tions and are not followed.
Highlights additional information useful
to the technician in completing the work
being performed properly.
External wiring, unless specied as an optional connection in the manufacturer’s product line, is
not to be connected inside the OptiViewTM cabinet. Devices such as relays, switches, transducers and
controls and any external wiring must not be installed inside the cabinet. All wiring must be in ac-
cordance with Johnson Controls’ published specications and must be performed only by a qualied
electrician. Johnson Controls will NOT be responsible for damage/problems resulting from improper
connections to the controls or application of improper control signals. Failure to follow this warning
will void the manufacturer’s warranty and could cause serious damage to property or personal injury.

JOHNSON CONTROLS 3
FORM 160.84-N1
ISSUE DATE: 11/22/2016
CHANGEABILITY OF THIS DOCUMENT
In complying with Johnson Controls’ policy for con-
tinuous product improvement, the information con-
tained in this document is subject to change without
notice. Johnson Controls makes no commitment to
update or provide current information automatically
to the manual or product owner. Updated manuals, if
applicable, can be obtained by contacting the nearest
Johnson Controls Service office or accessing the John-
son Controls QuickLIT website at http://cgproducts.
johnsoncontrols.com.
It is the responsibility of rigging, lifting, and operating/
service personnel to verify the applicability of these
documents to the equipment. If there is any question
regarding the applicability of these documents, rig-
ging, lifting, and operating/service personnel should
verify whether the equipment has been modified and
if current literature is available from the owner of the
equipment prior to performing any work on the chiller.
CHANGE BARS
Revisions made to this document are indicated with a
line along the left or right hand column in the area the
revision was made. These revisions are to technical in-
formation and any other changes in spelling, grammar
or formatting are not included.
ASSOCIATED LITERATURE
MANUAL DESCRIPTION FORM NUMBER
Chiller Operations & Maintenance 160.84-OM1
Unit Installation Checklist and Request for Startup 160.84-CL1
Unit Startup Checklist 160.84-CL2
Field Connections Diagram 160.84-PW1
Field Control, Wiring and MBC Diagrams 160.84-PW2
Replacement Parts 160.84-RP1
Replacement Parts Variable Speed Drive 160.84-RP3
Liquid Chiller Log Sheet 160.84-MR1
Centrifugal Chiller Long Term Storage 50.20-NM5
All Products - Replacement Parts Electrical Connectors 50.20-RP1
All Products - Replacement Parts Fittings 50.20-RP2

JOHNSON CONTROLS
4
FORM 160.84-N1
ISSUE DATE: 11/22/2016
VESSEL NOMENCLATURE
Inlet from Front View
R = Right
L = Left
Waterbox Type
C = Compact
M = Marine
Water Side Pressure Code
1 = 150 psi
3 = 300 psi
Water Connection Type
F = Flanges
G = Grooved Standard
A = Victaulic AGS
Number of Passes
Vessel
E = Evaporator
C = Condenser
Vessel Refrigerant Pressure Code
R = Code 180
S = Code 235
T = Code 300
U = Code 350
V = Code 400
Tube Code
B = 3/4" Code 1
C = 3/4" Code 2
D = 3/4" Code 3
E = 3/4" Code 4
2 = 1" Code 1
3 = 1" Code 2
4 = 1" Code 3
5 = 1" Code 4
Heat Exchanger Mod Level
Nominal Inside Diameter (Inches)
Nominal Length (Feet)
Marketing Tube Number
E A 25 14 271 B R 1 1 F C R
COMPRESSOR NOMENCLATURE
Gas Path Revision Level
Down Discharge
Impeller Design Revision Level
Motor
Motor Design Level
Impeller Tip Diameter (mm)
Rotation
F = Forward
R = Reverse
M2 B - 197 F A C D
SYSTEM NOMENCLATURE
YORK
Centrifugal Chiller
Magnetic Bearing
Mod Level
S = Single Stage
T = Two Stage
Capacity in KW
A = Refrigerant R-134a
B = Refrigerant R-513a
Y M C 2 - S 0756 A B
Liquid DWP
15 = 150 psi
30 = 300 psi
40 = 380V 60Hz
50 = 400V 50Hz
46 = 460V 60Hz
68 = 415V 50Hz
D = Disconnect Switch
B = Circuit Breaker
X = Factory Mount
R = Retrot Model
VARIABLE SPEED DRIVE NOMENCLATURE
Hyp
H = YMC2Chiller
C = Condenser Cooled
E = Evaporator Cooled
Amps
0490, 0612, 0774, 1278
HYP 0774 X H C 15 D - 40 A
Mod Level

JOHNSON CONTROLS 5
FORM 160.84-N1
ISSUE DATE: 11/22/2016
TABLE OF CONTENTS
SECTION 1 - OVERVIEW.........................................................................................................................................9
General.............................................................................................................................................................9
Component Combinations................................................................................................................................9
Inspection – Damage – Shortage...................................................................................................................10
Chiller Data Plate ...........................................................................................................................................10
YMC2Shipment Forms...................................................................................................................................10
Form 1 ................................................................................................................................................... 11
Form 2 ................................................................................................................................................... 11
Form 3 ................................................................................................................................................... 11
Form 7 ...................................................................................................................................................12
Form 9 ...................................................................................................................................................12
Form 10 ................................................................................................................................................13
Form 11 .................................................................................................................................................14
SECTION 2 - RIGGING AND LIFTING ...................................................................................................................15
Form 1 Total Weight .......................................................................................................................................15
Form 1 Shipment............................................................................................................................................15
Unit Rigging...........................................................................................................................................15
Form 2 Total Weight .......................................................................................................................................17
Form 2 Shipment............................................................................................................................................17
Unit Rigging...........................................................................................................................................17
Form 3 Shipment............................................................................................................................................18
Shells.....................................................................................................................................................18
Compressor Motor Assembly ................................................................................................................18
Variable Speed Drive (VSD)..................................................................................................................19
Power Panel ..........................................................................................................................................20
OptiView™ Control Center ....................................................................................................................20
Form 7 Shipment............................................................................................................................................21
Condenser.............................................................................................................................................21
Evaporator ............................................................................................................................................22
Compressor Motor Assembly ................................................................................................................22
Variable Speed Drive (VSD)..................................................................................................................22
Power Panel ..........................................................................................................................................23
OptiView™ Control Center ....................................................................................................................23
Form 9 Shipment............................................................................................................................................24
Unit Rigging...........................................................................................................................................25
Variable Speed Drive (VSD)..................................................................................................................25
Form 10 Shipment..........................................................................................................................................26
Unit Rigging...........................................................................................................................................26
Variable Speed Drive (VSD)..................................................................................................................26
Form 11 Shipment ..........................................................................................................................................27
Condenser Assembly ............................................................................................................................27
Evaporator Assembly ............................................................................................................................29
OptiView™ Control Center ....................................................................................................................29

JOHNSON CONTROLS
6
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 3 - INSTALLATION ................................................................................................................................31
Overview ........................................................................................................................................................31
Determine Location ........................................................................................................................................31
Foundation Requirements .....................................................................................................................31
Clearance Requirements.......................................................................................................................31
Rig Unit To Final Location...............................................................................................................................31
Install Isolators ...............................................................................................................................................31
Neoprene Isolator Pads.........................................................................................................................31
Install Optional Spring Isolators.............................................................................................................34
Make Connections.......................................................................................................................................... 35
Piping Connections ...............................................................................................................................35
Refrigerant Relief Piping .......................................................................................................................38
Unit Piping .............................................................................................................................................39
Control Wiring........................................................................................................................................39
Power Wiring .........................................................................................................................................39
Supplied Variable Speed Drive.............................................................................................................. 39
Apply Insulation ..............................................................................................................................................39
Installation Check – Request For Startup Service..........................................................................................39
SECTION 4 - REASSEMBLY..................................................................................................................................41
Form 3 and Form 7 Reassembly...........................................................................................................41
Form 9 and Form 10 Reassembly.........................................................................................................48
Form 11 Reassembly ............................................................................................................................50
Refrigerant Tubing Reassembly .....................................................................................................................52
Assembly of Straight Thread O-ring Port Fittings.................................................................................. 52
Assembly of O-ring Face Seal Fittings ..................................................................................................53
SECTION 5 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS.........................................................55
Compressor Unit Dimensions......................................................................................................................... 55
Evaporator 150 & 300 PSI Compact Water Boxes.........................................................................................59
Condenser 150 & 300 PSI Compact Water Boxes.........................................................................................63
Evaporator 150 & 300 PSI Marine Water Boxes ............................................................................................64
Condenser 150 PSI Marine Water Boxes.......................................................................................................67
Condenser 150 & 300 PSI Marine Water Boxes Dimensions ........................................................................ 69
Weights...........................................................................................................................................................70
M6 Motor ........................................................................................................................................................71
M6 Weights.....................................................................................................................................................72
TABLE OF CONTENTS (CONT'D)

JOHNSON CONTROLS 7
FORM 160.84-N1
ISSUE DATE: 11/22/2016
LIST OF FIGURES
FIGURE 1 - YMC2Chiller Components .....................................................................................................................9
FIGURE 2 - Form 1 and 2 Rigging with Side Spreader Bar .................................................................................... 16
FIGURE 3 - Form 1 and 2 Rigging without Side Spreader Bar ............................................................................... 16
FIGURE 4 - Driveline Rigging..................................................................................................................................18
FIGURE 5 - Form 3 Rigging without Side Spreader Bars .......................................................................................19
FIGURE 6 - Variable Speed Drive Rigging..............................................................................................................19
FIGURE 7 - Power Panel ........................................................................................................................................20
FIGURE 8 - OptiView Control Center......................................................................................................................20
FIGURE 9 - Form 7 Rigging with Side Spreader Bars ............................................................................................21
FIGURE 10 - Driveline Rigging................................................................................................................................22
FIGURE 11 - Variable Speed Drive Rigging ............................................................................................................23
FIGURE 12 - Power Panel ......................................................................................................................................23
FIGURE 13 - OptiView Control Center....................................................................................................................24
FIGURE 14 - Form 9 and 10 Rigging with Side Spreader Bars ..............................................................................24
FIGURE 15 - Form 9 and 10 Rigging without Side Spreader Bars .........................................................................25
FIGURE 16 - Variable Speed Drive Rigging............................................................................................................26
FIGURE 17 - Variable Speed Drive Rigging............................................................................................................27
FIGURE 18 - Form 11 Condenser Assembly Rigging with Side Spreader Bars......................................................28
FIGURE 19 - Form 11 Evaporator Assembly Rigging with Side Spreader Bars......................................................28
FIGURE 20 - OptiView Control Center....................................................................................................................29
FIGURE 21 - Neoprene Isolators ............................................................................................................................32
FIGURE 22 - Skid Options ......................................................................................................................................33
FIGURE 23 - Spring Isolators .................................................................................................................................34
FIGURE 24 - Pressure Relief Piping .......................................................................................................................35
FIGURE 25 - Schematic of a Typical Piping Arrangement ......................................................................................36
FIGURE 26 - Typical Refrigerant Vent Piping..........................................................................................................38
FIGURE 27 - Unit Insulation....................................................................................................................................40
FIGURE 28 - Shell Reassembly..............................................................................................................................41
FIGURE 29 - YMC2 Piping Reassembly Hardware Identication ............................................................................ 43
FIGURE 30 - YMC2 Form 3 Reassembly Hardware Identication...........................................................................44
FIGURE 31 - YMC2 Form 7 Reassembly Hardware Identication...........................................................................45
FIGURE 32 - VSD Mounting Hardware Identication..............................................................................................46
FIGURE 33 - Power and Control Panel Mounting Hardware Identication ............................................................. 47
FIGURE 34 - YMC2 Form 9 and Form 10 Reassembly Hardware Identication ..................................................... 49
FIGURE 35 - Shell Reassembly..............................................................................................................................50
FIGURE 36 - Refrigerant Piping..............................................................................................................................50
FIGURE 37 - YMC2 Form 11 Reassembly Hardware Identication......................................................................... 51
FIGURE 38 - Adjustable End Fitting........................................................................................................................52
FIGURE 39 - Back off Locknut ................................................................................................................................52
FIGURE 40 - Screw Fitting into Port........................................................................................................................52
FIGURE 41 - Torque Fitting .....................................................................................................................................53
FIGURE 42 - SAE or ISO 6149 Straight Thread O-ring Port...................................................................................53
FIGURE 43 - Dimensions - 197 & 246 Compressor Units Ft-In (Mm).....................................................................56
FIGURE 44 - Evaporator - Compact Water Boxes (1-Pass Nozzle Arrangements) ...............................................59
FIGURE 45 - Evaporator - Compact Water Boxes (2-Pass Nozzle Arrangements) ...............................................59
FIGURE 46 - Evaporator - Compact Water Boxes (3-Pass Nozzle Arrangements) ...............................................59
FIGURE 47 - Evaporator And Condenser - 150 & 300 Psi Compact Water Boxes.................................................61
FIGURE 48 - Condenser - Compact Water Boxes (1-Pass Nozzle Arrangements) ...............................................63
FIGURE 49 - Condenser - Compact Water Boxes (3-Pass Nozzle Arrangements) ...............................................63
FIGURE 50 - Condenser - Compact Water Boxes (2-Pass Nozzle Arrangements) ...............................................63
FIGURE 51 - Evaporator - Marine Water Boxes (1-Pass Nozzle Arrangements) ..................................................64

JOHNSON CONTROLS
8
FORM 160.84-N1
ISSUE DATE: 11/22/2016
LIST OF TABLES
TABLE 1 - Compressor Motor Weights...................................................................................................................18
TABLE 2 - Variable Speed Drive Weights...............................................................................................................19
TABLE 3 - Power Panel ..........................................................................................................................................20
TABLE 4 - Control Panel Weights ..........................................................................................................................20
TABLE 5 - Compressor Motor Weights...................................................................................................................22
TABLE 6 - Variable Speed Drive Weights...............................................................................................................22
TABLE 7 - Power Panel ..........................................................................................................................................23
TABLE 8 - Control Panel Weights...........................................................................................................................23
TABLE 9 - Variable Speed Drive Weights...............................................................................................................25
TABLE 10 - Variable Speed Drive Weights.............................................................................................................26
TABLE 11 - Control Panel Weights ........................................................................................................................29
TABLE 12 - Assembly Torque Metric for Metric Tube Fittings.................................................................................42
TABLE 13 - Assembly Torque English for SAE Tube Fittings .................................................................................42
TABLE 14 - Re-Assembly Torque Values................................................................................................................43
TABLE 15 - Evaporator Weights, Dry* ....................................................................................................................58
TABLE 16 - Condenser Weights, Dry* ....................................................................................................................58
TABLE 17 - Approximate Evaporator Weights 150 PSI Compact Water Boxes .....................................................70
TABLE 18 - Approximate Condenser Weights 150 PSI Compact Water Boxes .....................................................70
TABLE 19 - Evaporator Weights, Dry* ....................................................................................................................71
TABLE 20 - Condenser Weights, Dry* ....................................................................................................................71
TABLE 21 - VSD Weights .......................................................................................................................................72
TABLE 22 - Compressor Weights .........................................................................................................................72
TABLE 23 - Unit Assembly – Panels, Piping, Wiring, Etc .......................................................................................72
TABLE 24 - Refrigerant & Water Weight.................................................................................................................72
TABLE 25 - Approximate Variable Speed Drive (VSD) Weights .............................................................................73
TABLE 26 - Approximate Driveline Weights............................................................................................................73
TABLE 27 - Approximate Refrigerant & Water Weight............................................................................................73
FIGURE 52 - Evaporator - Marine Water Boxes (2-Pass Nozzle Arrangements) .................................................. 64
FIGURE 53 - Evaporator - Marine Water Boxes (3-Pass Nozzle Arrangements) .................................................. 64
FIGURE 54 - Evaporator - 150 and 300 PSI Marine Water Boxes.......................................................................... 66
FIGURE 55 - Condenser - Marine Water Boxes (1-Pass Nozzle Arrangements) .................................................. 67
FIGURE 56 - Condenser - Marine Water Boxes (2-Pass Nozzle Arrangements) .................................................. 67
FIGURE 57 - Condenser - Marine Water Boxes (3-Pass Nozzle Arrangements) .................................................. 67
FIGURE 58 - Condenser - 150 and 300 PSI Marine Water Boxes.......................................................................... 68
LIST OF FIGURES (CONT'D)

JOHNSON CONTROLS 9
FORM 160.84-N1
ISSUE DATE: 11/22/2016
1
SECTION 1 - OVERVIEW
GENERAL
This manual provides instructions for rigging and in-
stalling a YMC2Liquid Chilling Unit.
Chillers can be shipped as a single factory assembled,
piped, wired package, requiring a minimum of field la-
bor to make chilled water connections, condenser wa-
ter connections, refrigerant atmospheric relief connec-
tions, and electrical power connections. (Refrigerant
charges shipped separately unless optional condenser
isolation valves are ordered.)
They can also be shipped dismantled when required by
rigging conditions, but it is generally more economical
to enlarge access openings to accommodate the factory
assembled unit. Chillers that are shipped dismantled
MUST be field-assembled under the supervision of a
Johnson Controls representative, but otherwise instal-
lation will be as described in this manual.
COMPONENT COMBINATIONS
Figure 1 identifies the major components of the YMC2
Chiller. The chiller is customized based on the selected
combination of Motor, Compressor, Evaporator, and
Condenser. Section 5 - Dimensions, Nozzle Arrange-
ments And Weights lists all of the allowable YMC2
Chiller combinations.
FIGURE 1 - YMC2CHILLER COMPONENTS
LD14022b
COMPRESSORTRANSFORMERS
OPTIVIEW
CONTROL
PANEL
CONDENSER
EVAPORATOR
VSD
COOLING
PIPING
COMPACT
WATERBOXES
VARIABLE
SPEED
DRIVE
DIRECT-DRIVE
MOTOR
MAGNETIC
BEARING
CONTROLLER
LIFTING
OPENINGS
POWER
PANEL

JOHNSON CONTROLS
10
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 1 - OVERVIEW
3. When units are shipped dismantled, notify the
nearest Johnson Controls ofce in ample time for
a Johnson Controls representative to supervise
rigging the unit to its operating position and the
assembly of components.
4. Do not make nal power supply connections to
the compressor motor drive or control center.
5. Do not charge the unit with refrigerant.
6. Do not attempt to start the system.
7. Do not run hot water (>110°F / 43°C max) or
steam through the evaporator or condenser at any
time.
CHILLER DATA PLATE
A unit data plate is mounted on the control center as-
sembly of each unit, giving unit model number; design
working pressure; water passes; refrigerant charge; se-
rial numbers; and motor power characteristics and con-
nection diagrams.
Additional information may be found on the compres-
sor and motor data plates. This information should be
included when contacting the factory on any problem.
YMC2SHIPMENT FORMS
The chiller may be ordered and shipped in any of the
following forms:
• Form 1 (shipped complete with refrigerant charge)
• Form 2 (shipped complete with refrigerant charge
shipped separately)
• Form 3 (shipped in three assemblies)
• Form 7 (shipped in four assemblies)
• Form 9 (shipped in two assemblies with refriger-
ant charge shipped separately)
• Form 10 (shipped in two assemblies with refriger-
ant charge)
• Form 11 (shipped as split shells with refrigerant
charge)
Units that are shipped dismantled MUST
be reassembled by, or under the supervi-
sion of a Johnson Controls representative.
Refer to Section 4 - Reassembly for de-
tailed reassembly instructions.
INSPECTION – DAMAGE – SHORTAGE
The unit shipment should be checked on arrival to see
that all major pieces, boxes and crates are received.
Each unit should be checked on the trailer or rail car
when received, before unloading, for any visible signs
of damage. Any damage or signs of possible damage
must be reported to the transportation company imme-
diately for their inspection.
JOHNSON CONTROLS WILL NOT BE RESPON-
SIBLE FOR ANY DAMAGE IN SHIPMENT OR AT
JOB SITE OR LOSS OF PARTS. (Refer to Shipping
Damage Claims Form (Form 50.15-NM).
When received at the job site all containers should be
opened and contents checked against the packing list.
Any material shortage should be reported to Johnson
Controls immediately. (Refer to Shipping Damage
Claims Form (Form 50.15-NM).
YMC2Chillers are not intended to be stored outdoors,
exposed to rain and moisture. The shipping wrap is for
shipping, not for extended outdoor storage. The chiller
should be tarped during any delays to get indoors and
moisture desiccant, available for purchase for inside
electrical panels should be used for damp areas.
If the chiller was not shipped complete (as shown in
Form 1 or 2) use the Section 4 - Reassembly in con-
junction with this installation manual.
The services of a Johnson Controls representative will
be furnished to check the installation, supervise the
initial start-up and operation of all chillers installed
within the Continental United States.
The Johnson Controls Warranty may be
voided if the following restrictions are not
adhered to.
1. No valves or connections should be opened under
any circumstances because such action will result
in loss of the factory refrigerant (Form 1) or nitro-
gen charge (Form 2).
2. Do not dismantle or open the chiller for any rea-
son except under the supervision of a Johnson
Controls representative.

JOHNSON CONTROLS 11
SECTION 1 - OVERVIEW
FORM 160.84-N1
ISSUE DATE: 11/22/2016
1
When more than one chiller is involved,
the major parts of each unit will be
marked to prevent mixing of assemblies.
Piping and wiring drawings to be fur-
nished by Johnson Controls.
Form 1
The chiller is shipped complete with miscellaneous
loose items shipped together and refrigerant charges
are included.
Chiller Unit
The unit is completely assembled at the factory.
• The driveline (compressor/motor assembly) is
mounted and all the necessary interconnecting
piping is assembled.
• The complete unit is factory leak-tested, evacu-
ated, and shipped charged with refrigerant.
• The OptiView™ Control Center is mounted on
the unit.
• The Variable Speed Drive (VSD) and Power Pan-
el are mounted, wired, and shipped with glycol.
Miscellaneous Items
The following items are shipped together:
• Four (4) vibration isolation pads (or optional
spring isolators and brackets).
• VSD operating coolant (inhibited water)
• Other shipped loose items, including piping, wa-
ter temperature controls, wiring, etc.
Form 2
The chiller is shipped complete with refrigerant charg-
es shipped separately and miscellaneous loose items
shipped together.
Arrangements with the local service office must be
made to ensure refrigerant is on-site when the unit is
ready to be charged.
Chiller Unit
The unit is completely assembled at the factory.
• The driveline (compressor/motor assembly) is
mounted and all the necessary interconnecting
piping is assembled.
• The complete unit is factory leak-tested, evacu-
ated, and shipped charged with a 3 to 7 PSIG (20
to 50 kPa) holding charge of dry nitrogen.
• The OptiView™ Control Center is mounted on
the unit.
• The Variable Speed Drive (VSD) and Power Pan-
el are mounted, wired, and shipped with Glycol.
Miscellaneous Items
The following items are shipped together:
• Four (4) vibration isolation pads (or optional
spring isolators and brackets).
• Other shipped loose items, including piping, wa-
ter temperature controls, wiring, etc.
• VSD operating coolant (inhibited water)
Form 3
Prior to shipping, the unit is completely assembled at
the factory. Interconnecting piping is assembled and
the complete unit is wired and leak-tested.
The unit is dismantled and shipped as follows:
1. The driveline (compressor/motor assembly).
2. The evaporator/condenser shell assembly.
3. The Variable Speed Drive (VSD).
4. Miscellaneous shipped loose items.
5. Refrigerant charges shipped separately.
Arrangements with the local service office must be
made to ensure refrigerant is on-site when the unit is
ready to be charged.
Driveline
The driveline (compressor/motor assembly) is re-
moved from the shells and skidded.
• All integral wiring is left on the compressor.
• All openings on the compressor are closed and
shipped charged with a 3 to 7 PSIG (20 to 50 kPa)
holding charge of dry nitrogen.

JOHNSON CONTROLS
12
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 1 - OVERVIEW
Shells
The evaporator and condenser are assembled prepared
for shipping but not skidded.
• All conduit is left on the shells.
• All openings the shells are closed and charged
with a 3 to 7 PSIG (20 to 50 kPa) holding charge
of dry nitrogen.
Variable Speed Drive (VSD)
The VSD is skidded and shipped separately from the
assembled chiller.
• The VSD is lled with glycol for shipping. The
VSD operating coolant (inhibited water) is
shipped with the other loose items.
Miscellaneous Material
The following assemblies and items are shipped to-
gether:
• OptiView™ Control Center
• Power Panel
• Four (4) vibration isolation pads (or optional
spring isolators and brackets).
• Other shipped loose items, including piping, wa-
ter temperature controls, wiring, etc.
• VSD operating coolant (inhibited water)
Form 7
Prior to shipping, the unit is completely assembled at
the factory. Interconnecting piping is assembled and
the complete unit is wired and leak-tested.
The unit is dismantled and shipped as follows:
1. The driveline (compressor/motor assembly).
2. The evaporator.
3. The condenser.
4. The Variable Speed Drive (VSD).
5. Refrigerant charges shipped separately.
6. Miscellaneous shipped loose items.
Arrangements with the local service office must be
made to ensure refrigerant is on-site when the unit is
ready to be charged.
Driveline
The driveline (compressor/motor assembly) is removed
from shells and skidded.
• All integral wiring is left on the compressor.
• All wiring harnesses on shells are removed.
• All openings on the compressor are closed and
shipped charged with a 3 to 7 PSIG (20 to 50 kPa)
holding charge of dry nitrogen.
Shells
The evaporator and condenser are separated at the tube
sheets and prepared for shipping separately but not
skidded.
• All conduit is left on the shells.
• Refrigerant lines between shells are anged and
capped, requiring no welding.
• All openings the shells are closed and charged
with a 3 to 7 PSIG (20 to 50 kPa) holding charge
of dry nitrogen.
Variable Speed Drive (VSD)
The VSD is skidded and shipped separately from the
assembled chiller.
• The VSD is lled with glycol for shipping. The
VSD operating coolant (inhibited water) is shipped
with the other loose items.
Miscellaneous Items
The following assemblies and items are shipped to-
gether:
• OptiView™ Control Center
• Power Panel
• Four (4) vibration isolation pads (or optional
spring isolators and brackets).
• Operating coolant (inhibited water)
• Other shipped loose items, including piping, wa-
ter temperature controls, wiring, isolators, etc.
Form 9
Prior to shipping, the unit is completely assembled at
the factory. Interconnecting piping is assembled and
the complete unit is wired and leak-tested.

JOHNSON CONTROLS 13
SECTION 1 - OVERVIEW
FORM 160.84-N1
ISSUE DATE: 11/22/2016
1
The chiller is shipped in two assemblies as follows:
1. The chiller unit (less the VSD).
2. The VSD.
3. Refrigerant charges shipped separately.
4. Miscellaneous shipped loose items.
Arrangements with the local service office must be
made to ensure refrigerant is on-site when the unit is
ready to be charged.
Chiller Unit
The unit is first completely assembled at the factory:
• The driveline (compressor/motor assembly) is
mounted, with all necessary interconnecting pip-
ing assembled.
• Interconnecting piping is assembled and the com-
plete unit is factory leak-tested then evacuated
and shipped charged with a 3 to 7 PSIG (20 to 50
kPa) holding charge of dry nitrogen.
• The Motor Terminal Box adapter remains at-
tached to the chiller unit.
Variable Speed Drive (VSD)
The VSD is skidded and shipped separately from the
assembled chiller.
• The VSD is lled with glycol for shipping. The
VSD operating coolant (inhibited water) shipped
with the other loose items.
Miscellaneous Material
The following assemblies and items are shipped to-
gether:
• Four (4) vibration isolation pads (or optional
spring isolators and brackets).
• Other shipped loose items, including piping, wa-
ter temperature controls, wiring, etc.
• VSD operating coolant (inhibited water)
Form 10
Prior to shipping, the unit is completely assembled at
the factory. Interconnecting piping is assembled and
the complete unit is wired and leak-tested.
The chiller is shipped in two assemblies:
1. The assembled chiller unit.
2. The VSD.
3. Refrigerant charges are included.
4. Miscellaneous shipped loose items.
Chiller Unit
The unit is first completely assembled at the factory:
• The driveline (compressor/motor assembly) is
mounted, with all necessary interconnecting pip-
ing assembled.
• The complete unit is factory leak-tested, evacu-
ated, and shipped charged with refrigerant.
• The Motor Terminal Box adapter remains at-
tached to the chiller unit.
Variable Speed Drive (VSD)
The VSD is skidded and shipped separately from the
assembled chiller.
• The VSD is lled with glycol for shipping. The
VSD operating coolant (inhibited water) shipped
with the other loose items.
Miscellaneous Material
The following assemblies and items are shipped to-
gether:
• Four (4) vibration isolation pads (or optional
spring isolators and brackets).
• Other shipped loose items, including piping, wa-
ter temperature controls, wiring, etc.
• VSD operating coolant (inhibited water)

JOHNSON CONTROLS
14
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 1 - OVERVIEW
Form 11
Prior to shipping, the unit is completely assembled at
the factory. Interconnecting piping is assembled and
the complete unit is wired and leak-tested.
The chiller is split down the middle and shipped in two
assemblies:
1. The condenser-side assembly.
2. The evaporator-side assembly.
3. Refrigerant charges are included.
4. Miscellaneous shipped loose items.
Arrangements with the local service office must be
made to ensure refrigerant is on-site when the unit is
ready to be charged.
Condenser-Side Assembly (Condenser /
OptiView™ Control Center / Variable Speed
Drive)
The Condenser-side assembly consists of the Condens-
er, the OptiView™ Control Center and the Variable
Speed Drive.
• All conduit is left on the condenser shell.
• Interconnecting piping between shells are anged
and capped, requiring no welding.
• All openings on the condenser shell are closed
and shipped charged with a 3 to 7 PSIG (20 to 50
kPa) holding charge of dry nitrogen.
Evaporator-Side Assembly (Evaporator /
Driveline / Power Panel)
The evaporator-side assembly consists of the evapo-
rator, the driveline (compressor/motor assembly), and
the Power Panel.
• All conduit is left on the evaporator shell.
• Interconnecting piping between shells are anged
and capped, requiring no welding.
• All integral wiring is left on the compressor.
• All openings on the evaporator shell and driveline
are closed and shipped charged with a 3 to 5 PSIG
(20 to 50 kPa) holding charge of dry nitrogen.
Miscellaneous Material
The following items are shipped together:
• Four (4) vibration isolation pads (or optional
spring isolators and brackets)
• Other shipped loose items, including piping, wa-
ter temperature controls, wiring, etc.
• VSD operating coolant (inhibited water)

JOHNSON CONTROLS 15
FORM 160.84-N1
ISSUE DATE: 11/22/2016
2
Improper use of rigging equipment can
result in serious injury. Do not operate
without proper training and authorization.
It is the responsibility of the installer to
have a qualied and certied crane opera-
tor and rigger for lifting components and
relocating to the new site.
To perform a safe and effective rigging practice the
installer is responsible for inspection and operation
of the lifting equipment, special site considerations,
proper rigging and lifting practices, and any safety
considerations.
Particular items the installer must be aware of are:
• Rope with no visible wear, twisted, kinked, or
damaged chains.
• Deformed, cracked, or stretched hooks or safety
latch on the hook is not damaged.
• Correct drum spooling as the hook is raised.
• Do not operate a damaged or malfunctioning
hoist.
• Do not wrap the hoisting rope or chain around the
load.
• Do not lift loads over people.
FORM 1 TOTAL WEIGHT
The heaviest possible YMC² combination of total
weight for Form 1 shipment is 33,863 lbs (15,360 kg)
or 17 ton. See Weights on page 73 for YMC² weight
breakdown.
The actual unit total shipping and operat-
ing weight is on the submittal drawings.
SECTION 2 - RIGGING AND LIFTING
FORM 1 SHIPMENT
The chiller is shipped complete with miscellaneous
items shipped together with refrigerant charges are in-
cluded.
• The unit is completely assembled at the factory.
• The driveline (compressor/motor assembly) is
mounted and all the necessary interconnecting
piping is assembled.
• The complete unit is factory leak-tested, evacu-
ated and shipped charged with refrigerant.
• The OptiView™ Control Center is mounted on
the unit.
• The Power Panel is mounted on the unit.
• The Variable Speed Drive (VSD) is mounted,
wired, and ship with glycol.
Unit Rigging
One lifting chain is required for each lift-
ing point and each chain having a work-
ing load limit 30% of unit total weight.
The lifting chains traversing the evapora-
tor/condenser shells should remain 90°
+/- 10° from horizontal. A spreader bar
may be required to achieve the +/- 10°.
1. Attach rigging chains to an adequate lifting device.
2. Attach chains to the lifting holes at the corner of
each end sheet as shown on Figure 2 on page 16.
3. If necessary to avoid contact with chiller compo-
nents install side spreader bars between the Evap-
orator and Condenser end sheet lifting chains.
4. The angle of the lifting chains traversing the en
sheet should not be less than 65° as shown on Fig-
ure 2 on page 16.
5. With an adequate lifting device lift the unit slight-
ly off the ground to determine adjustments neces-
sary to keep the unit level. Make adjustments as
necessary to level the unit.

JOHNSON CONTROLS
16
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 2 - RIGGING AND LIFTING
LD16719b
Lifting
Holes
Lifting
Holes
Lifting
Holes
Side
Spreader
Bar
90°+/-10°
FIGURE 2 - FORM 1 AND 2 RIGGING WITH SIDE SPREADER BAR
LD16719c
Lifting
Holes
Lifting
Holes
Lifting
Holes
65°
Min.
FIGURE 3 - FORM 1 AND 2 RIGGING WITHOUT SIDE SPREADER BAR

JOHNSON CONTROLS 17
SECTION 2 - RIGGING AND LIFTING
FORM 160.84-N1
ISSUE DATE: 11/22/2016
2
FORM 2 TOTAL WEIGHT
The heaviest possible YMC² combination of total
weight for Form 2 shipment is 21,900 lbs (10,000 kg)
or 11 ton. See Weights on page 73 for YMC² weight
breakdown.
The actual unit total shipping and operat-
ing weight is on the submittal drawings.
FORM 2 SHIPMENT
Arrangements with the local service of-
ce must be made to ensure refrigerant is
on-site when unit is ready to be charged.
The chiller is shipped complete with miscellaneous
items shipped together.
• The driveline (compressor/motor assembly) is
mounted and all the necessary interconnecting
piping is assembled.
• The complete unit is factory leak-tested, evacu-
ated and shipped charged with a 3 to 7 PSIG (20
to 50 kPa) holding charge of dry nitrogen.
• The OptiView™ Control Center is mounted.
• The Power Panel is mounted on the unit.
• The Variable Speed Drive (VSD) is mounted,
wired and shipped with Glycol.
• Refrigerant charges are shipped separately.
Unit Rigging
One lifting chain is required for each lift-
ing point and each chain having a work-
ing load limit 30% of unit total weight.
The lifting chains traversing the evapora-
tor/condenser shells should remain 90°
+/- 10° from horizontal. A spreader bar
may be required to achieve the +/- 10°.
1. Attach rigging chains to an adequate lifting device.
2. Attach chains to the lifting holes at the corner of
each end sheet as shown on Figure 2 on page 16.
3. If necessary to avoid contact with chiller compo-
nents install side spreader bars between the Evap-
orator and Condenser end sheet lifting chains.
4. The angle of the lifting chains traversing the en
sheet should not be less than 65° as shown on Fig-
ure 2 on page 16.
5. With an adequate lifting device lift the unit slight-
ly off the ground to determine adjustments neces-
sary to keep the unit level. Make adjustments as
necessary to level the unit.

JOHNSON CONTROLS
18
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 2 - RIGGING AND LIFTING
FORM 3 SHIPMENT
The chiller is shipped in five major assemblies:
• The evaporator/condenser shell assembly.
• The driveline (compressor/motor assembly).
• The Variable Speed Drive (VSD).
• The OptiView™ Control Center assembly.
• The Power Panel assembly.
• Miscellaneous shipped loose items.
One lifting chain is required for each
lifting point and each chain having a
working load limit 40% of condenser and
evaporator weight or heat exchanger be-
ing lifted.
The lifting chains traversing the evapora-
tor/condenser shells should remain 90°
+/- 10° from horizontal. A spreader bar
may be required to achieve the +/- 10°.
Refrigerant charges are shipped separately.
Arrangements with the local service ofce
must be made to ensure refrigerant is on-
site when the unit is ready to be charged.
When optional skids are used it may be
necessary to remove the skids so riggers
skates can be used under the unit end
sheets to reduce overall height.
Shells
1. Attach rigging chains to an adequate lifting device.
2. Attach chains to the lifting holes at the corner of
each end sheet as shown on Figure 5 on page 19.
3. If necessary to avoid contact with chiller compo-
nents install side spreader bars between the Evap-
orator and Condenser end sheet lifting chains.
4. The angle of the lifting chains traversing the en
sheet should not be less than 65° as shown on Fig-
ure 5 on page 19.
5. With an adequate lifting device lift the unit slight-
ly off the ground to determine adjustments neces-
sary to keep the unit level. Make adjustments as
necessary to level the unit.
Compressor Motor Assembly
TABLE 1 - COMPRESSOR MOTOR WEIGHTS
Compr Code Pounds Kilograms
M2C-197FAC 2,861 1298
M2C-197FACD 2,861 1292
M2C-205FAC 2,867 1300
M2C-205FACD 2,867 1295
M2C-218FAC 2,987 1355
M2C-233FAC 2,999 1,360
M2C-246FAC 2,989 1,356
M6C-295FAC 4,298 1,950
M6C-331FAC 4,500 2,041
1. Attach rigging chains to each end of the com-
pressor/motor assembly as shown in Figure 4 on
page 18.
2. Lift the compressor/motor assembly off the
ground to check for center of gravity. Make ad-
justments as necessary.
The M2C and M6C Compressor/Motor
has metric lifting lugs
Use lifting chains with working load limit
each 70% of total driveline weight.
FIGURE 4 - DRIVELINE RIGGING
LD17276b
45°
Min.
45°
Min.

JOHNSON CONTROLS 19
SECTION 2 - RIGGING AND LIFTING
FORM 160.84-N1
ISSUE DATE: 11/22/2016
2
FIGURE 5 - FORM 3 RIGGING WITHOUT SIDE SPREADER BARS
LD16732a
Lifting
Holes
Lifting
Holes
Lifting
Holes
Lifting
Holes
90°+/-10°
65°
Min.
6. Make all necessary connections for the VSD cool-
ing loop to be complete.
Use lifting chains with working load limit
each 35% of total VSD weight.
FIGURE 6 - VARIABLE SPEED DRIVE RIGGING
LD16730a
Lifting
Holes
Lifting
Holes
65°
Min.
65°
Min.
Variable Speed Drive (VSD)
TABLE 2 - VARIABLE SPEED DRIVE WEIGHTS
Model Pounds Kilograms
HYP0490XH 1,226 556
HYP0612XH 1,954 886
HYP0774XH 2,060 934
HYP1278XH 3,806 1727
The VSD is shipped with glycol in the
cooling system. The VSD coolant must
be changed to the inhibitor provided with
the shipped loose items prior to starting
the unit or a VSD over temperature fault
may occur.
1. Attach rigging chains from an adequate lifting
device to the four lifting holes at the top of the
VSD as shown in Figure 6 on page 19, for VSD
weight refer to Table 2 on page 19.
2. Lift the VSD slightly off the ground to check for
center of gravity. Make adjustments as necessary
to level the VSD.
3. Lift the VSD and remove all packing material.
4. Carefully lower the VSD on to the supports on the
condenser.
5. Fasten the VSD to the condenser and to the motor
terminal box duct. Remove the rigging chains.

JOHNSON CONTROLS
20
FORM 160.84-N1
ISSUE DATE: 11/22/2016
SECTION 2 - RIGGING AND LIFTING
Power Panel
Description Pounds Kilograms
Power Panel 300 135
TABLE 3 - POWER PANEL
1. Attach rigging chains to an adequate lifting device.
2. Attach the chains to the lifting holes at the top of the
Power Panel as shown in Figure 7 on page 20.
3. Lift the Power Panel slightly off the ground to
check for center of gravity. Make adjustments as
necessary to level the Power Panel.
4. Lift the Power Panel and remove all packing ma-
terial.
5. Carefully lower the Power Panel on to the sup-
ports on the evaporator.
6. Attach the Power Panel to the evaporator with the
proper hardware. Remove the rigging chains.
7. Re-connect all unit wiring and harnesses (refer to
YMC2 Unit Wiring and Field Control Modica-
tions (Form 160.78-PW2).
Use lifting chains with working load limit
each 70 of the Power Panel weight.
FIGURE 7 - POWER PANEL
LD17275a
Lifting
Holes
Lifting
Holes
45°
Min.
OptiView™ Control Center
The OptiView™Control Center weighs
over 50 pounds and a technician and
helper are needed for the installation of
the panel.
Description Pounds Kilograms
OptiView 75 34
TABLE 4 - CONTROL PANEL WEIGHTS
1. Lift the OptiView™ Control Center and remove
all packing material.
2. Carefully lower the OptiView™ Control Center
on to the supports on the condenser.
3. Attach the OptiView™ Control Center to the con-
denser with the proper hardware.
4. Connect all unit wiring and harnesses (refer to
YMC2 Unit Wiring and Field Control Modica-
tions (Form 160.78-PW2).
FIGURE 8 - OPTIVIEW CONTROL CENTER
LD16738
