Yota YotaPhone 2 Reference manual

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 1/65
Introduction
Getting started
Get to know your YotaPhone
Your YotaPhone has two displays: the colour display and the always-on display.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 2/65
Install the SIM card
The SIM card tray is located under the volume button and you can open it with the SIM eject
tool included in the package. Your service provider provides you with the SIM card.
To install the SIM card:
1. Headset jack and microphone
2. Ear piece
3. Ambient light sensor and proximity sensor
4. Front camera
5. Volume buttons
6. Power button
7. Colour display
8. Loudspeaker
9. Micro USB connector
10. Main microphone
11. Camera LED flash
12. Main camera
13. Always-on display
14. SIM card tray
15. SIM eject hole
Your YotaPhone is designed to be used with a Nano-SIM card. Using an incompatible
SIM card may damage your phone.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 3/65
Charge your phone
Charge with a USB power adapter
1. Insert the SIM eject tool into the SIM eject hole and push lightly until the SIM card tray
releases.
2. Put the SIM card in the tray with the contact area facing down.
3. Place the SIM card tray carefully back into its slot, and push it until it locks.
The battery of your YotaPhone is non-removable. Do not attempt to open your phone
to remove the battery.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 4/65
1. Connect the USB cable to the USB power adapter.
2. Insert the micro USB end of the cable into the micro USB connector on your YotaPhone.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 5/65
The charger has an LED light that switches on when the phone is charging. When the battery is
full, the LED light switches off.
Charge with a computer
Switch your phone on/off
To switch your phone on, press and hold the power button until the phone vibrates.
3. Insert the power adapter into a wall socket to start charging.
1. Insert the micro USB end of the cable into the micro USB connector on your YotaPhone.
2. Insert the other end of the USB cable into the USB port on your computer.
If the battery is completely empty, it might take a while before the phone shows that
it is charging.
Charge the battery before using your YotaPhone for the first time.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 6/65
To switch your phone off, press and hold the power button, tap Power off, and tap OK.
Basics
Get to know the basic functions of your YotaPhone.
Lock or unlock the screen
When you are holding your YotaPhone, it recognises which display is upwards. You can only lock
or unlock the upwards-facing display.
When you flip the phone, display you are not using locks automatically.
Lock or unlock the colour display
To lock the colour display, press the power button, or touch the screen with three or more
fingers or your palm.
To unlock the colour display, press the power button and slide the lock icon to the side, or swipe
upwards from the bottom of the screen.
Lock or unlock the always-on display
To lock the always-on display, press the power button, or touch the screen with three or more
fingers.
To unlock the always-on display, slide the lock icon upwards.
For more screen lock options, see Protect your YotaPhone.
Use the touch screen
Get to know the basic touch gestures.
Tap
Tap the screen to interact with items on the screen, such
as applications and setting items, to write text using the
on-display keyboard, or to press on-display buttons.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 7/65
Tap and hold
Tap and hold an item on the screen to view a menu.
Double tap
Tap twice quickly on a picture, web page, or map to zoom
in and out.
Drag and drop
To move an application on the home screen, tap and hold

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 8/65
an icon without releasing your finger, move the icon to
another place, and release your finger.
Swipe
To swipe, move your finger across the surface of your
screen.
For example, you can swipe the home screen to the left or
right to view other home screen panels.
Pinch
In some applications, you can zoom in and out by placing
two fingers on the screen. Spread the fingers apart to
zoom in, and pinch them together to zoom out.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 9/65
Nagivate the colour display
The Android™ navigation buttons are located at the bottom of the colour display:
To go back to the previous screen, tap .
To go to the home screen, tap .
To open a list of recently used applications, tap .
To access more options, tap and hold :
To perform a Google search, drag your finger towards Google.
To send the current view to the always-on display using YotaMirror, drag your finger towards
.
To send a screenshot of the current view to the always-on display using YotaSnap, drag your
finger towards .
Switch aeroplane mode on/off
Aeroplane mode switches off Wi-Fi, Bluetooth, and mobile networks, but otherwise allows you to
continue using your phone.
To switch aeroplane mode on, press and hold the power button, and tap .
To switch aeroplane mode off, press and hold the power button, and tap .
Adjust the volume
To adjust the volume, press the volume buttons.
Change the volume settings
Follow the instructions and safety requirements of your airline, and the laws and
regulations of the regions in which you are flying.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 10/65
Switch between silent, vibration, and normal mode
Your YotaPhone is in normal mode by default.
To switch to silent mode, press and hold the power button, and tap .
To switch to vibration mode, press and hold the power button, and tap .
To switch to normal mode, press and hold the power button, and tap .
Personalise the home screen
You can customise the Favourites tray, add and remove application and widget shortcuts on the
home screen, and change your wallpaper.
Customise the Favourites tray
The Favourites tray at the bottom of the home screen keeps your most important shortcuts at
hand.
Remove an application or widget shortcut from the Favourites tray
Tap and hold an application or widget shortcut, and drag it away from the Favourites tray.
Add an application shortcut to the home screen
1. On the home screen, tap > Settings > DEVICE > Sound.
2. Tap Volumes.
3. To adjust the volume of Music, video, games & other media, Ringtone & notifications,
and Alarms, tap and drag the sliders.
You can also switch between silent, vibration, and normal mode by pressing the
volume buttons.
1. On the home screen, tap .
2. Tap and hold an application or widget icon until the Favourites tray on the home screen
appears.
3. Drag the icon into place and release your finger.
You can place four application or widget shortcuts on the Favourites tray.
You can also create a folder on the tray by stacking a shortcut on top of another.
1. On the home screen, tap .

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 11/65
Add a widget shortcut to the home screen
Move an application or widget shortcut
Remove an application or widget shortcut
Create a folder
Choose a wallpaper for the home screen
Change date and time
On the home screen, tap > Settings > SYSTEM > Date & time.
To change the date, tap Set date, and select the correct date.
To change the time, tap Set time, and select the correct time.
To use the 24 hour format, select Use 24 hour format.
Protect your YotaPhone
Learn how to protect your YotaPhone using the screen lock, SIM card lock, and data encryption.
Lock your screen
2. Tap and hold an application icon until the home screen appears.
3. Drag the icon onto the home screen.
1. Tap and hold an empty space on the home screen
2. Tap WIDGETS.
3. Tap and hold a widget icon until the home screen appears.
4. Drag the icon onto the home screen.
1. Tap and hold the application or widget shortcut you want to move.
2. Drag the shortcut to a new location, and release your finger.
1. Tap and hold the application or widget shortcut you want to remove.
2. Drag the shortcut or widget towards Remove, and release your finger.
1. Tap and hold an icon, drag it over another icon, and release your finger. The two icons are
now stacked in a folder.
2. To name a folder, tap the folder to view its name. Tap Unnamed folder, and enter a new
name.
1. On the home screen, tap and hold an empty space.
2. Tap Wallpaper.
3. In the film strip, tap a picture, and tap Set wallpaper.
To automatically get the date, time, and time zone from your service provider’s
network, tick Automatic time zone and Automatic date & time.
1. On the home screen, tap > Settings > PERSONAL > Security > SCREEN SECURITY >
Screen lock.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 12/65
Lock your SIM card
A PIN code helps to protect your SIM card against unauthorised use. You can set your phone to
ask for the PIN code when you switch it on. If the PIN code is not supplied with your SIM card or
you have forgotten the code, contact your service provider.
Encrypt your data
You can protect and encrypt your phone data, such as Google Accounts, application data, music
and other media, and downloaded information. If you encrypt your data, you must enter a
numeric PIN or password each time you switch your phone on. If you have already set up a
screen lock, you must use the same PIN or password. You cannot have two PINs or passwords.
Before enabling encryption:
To enable encryption, on the home screen, tap > Settings > PERSONAL > Security >
ENCRYPTION > Encrypt phone. The encryption may take an hour or more.
2. Tap to choose a screen lock option:
None - No screen lock. This option provides no protection.
Slide - Swipe to unlock the phone. This option provides minimal protection.
Face Unlock - Use facial recognition to unlock the phone. This option is less secure than a
pattern, PIN, or password, and is not available for the always-on display.
Pattern - Draw a simple pattern with your finger to unlock the phone.
PIN - Use a PIN code to unlock the phone. The PIN code must contain four or more
numbers.
Password - Use a password to unlock the phone. The password must contain four or
more letters or numbers.
When you set a password to lock your screen, keep the password in a safe place
separate from your YotaPhone. If you forget your password and cannot unlock your
YotaPhone because you have entered a wrong password too many times, you may
need to get your YotaPhone serviced and possibly pay additional charges to unlock
your YotaPhone. All the personal data in your YotaPhone may be deleted.
1. On the home screen, tap > Settings > PERSONAL > Security > SIM CARD LOCK > Set
up SIM card lock.
2. Tick Lock SIM card and enter the PIN code.
If you enter the PIN code incorrectly three times in succession, you must unblock the
code with the PUK or PUK2 code. If you do not have them, contact your service
provider.
Encryption is irreversible. The only way to revert to an unencrypted phone is to
perform a factory data reset, which erases all your data.
1. Set a lock screen PIN or password.
2. Charge your phone fully.
Do not interrupt the encryption process or you may lose some or all of your data.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 13/65
Get to know the indicators
The indicators at the top of the screen give you information such as the current time, battery
power level, and signal strength.
No signal GPS activated
Signal strength Call in progress
Roaming (outside of normal service area) Missed call
GPRS network connected Synced with the web
EDGE network connected Connected to computer
UMTS network connected No SIM or USIM card
HSDPA network connected New text or multimedia message
HSPA+ network connected Alarm activated
Downloading Silent mode activated
Calendar reminder Vibration mode activated
LTE network connected Aeroplane mode activated
Wi-Fi connected Error occurred
Bluetooth activated Battery power level
Set up user accounts
Your YotaPhone uses the Android operating system provided by Google. To use Google
applications and services, for example Google Play™ Store, Gmail™, Drive™, or Google Maps™,
you need to set up a Google account.
You can set up an existing Google account, or if you do not have a Google account, you can
create one.
On the home screen, tap , and tap a Google application, such as Play Store, Gmail, or Drive.
Set up an existing Google account
Create a new Google account
1. On the Add a Google Account screen, tap Existing.
2. Enter your email address and password into the corresponding fields.
3. Tap .
1. On the Add a Google Account screen, tap New.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 14/65
Using your phone
Calls
Use your YotaPhone to call your contacts.
Make a call
Call a contact
Make a call from the call log
Make a call by using voice dialler
Answer a call
2. Follow the instructions on the screen.
You can also set up an account in Settings. On the home screen, tap >
Settings > ACCOUNTS > Add account.
1. On the home screen, tap .
2. To open the dialler, tap .
3. Enter an area code and a phone number.
4. Tap .
5. To end a call, tap .
1. On the home screen, tap > .
2. Tap , and select a contact.
3. Tap the contact's phone number.
1. On the home screen, tap > .
2. Tap the phone number you want to call.
1. On the home screen, tap .
2. Tap .
3. Say "call" and then the contact's name.
1. Drag towards .
2. To end the call, tap .

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 15/65
Reject a call
If you cannot answer a call, you can reject the call, and send a message to the caller.
Reject a call
Drag towards .
Reject a call with a message
Make a conference call
A conference call is a call with three or more people.
To make a conference call:
Make an international call
Make an emergency call
You can use your device for emergency calls without inserting a SIM card.
Make an emergency call
When the phone is not locked, you can make an emergency call the same way as other calls.
You can also answer a call on the always-on display.
1. Drag towards .
2. Select a predefined text message, or tap Custom message to write a different message.
1. Call the first participant.
2. After connecting to the first participant, tap to add a second participant.
You can dial a number or choose a number from your contacts or call log. The first
participant is automatically placed on hold while you call the second participant.
3. After connecting to the second participant, tap to merge the calls.
4. To end the conference call, tap .
1. On the home screen, tap .
2. Tap , and tap and hold 0 until the + sign appears.
3. Enter the country code, area code, and phone number, and tap .
1. On the home screen, tap .
2. Tap , enter the emergency number, and tap .
Make sure to give all the necessary information. End the call only after given permission to do
so.
3. To end the call, tap .

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 16/65
Make an emergency using a locked phone
You can make an emergency call even if the screen is locked.
To make an emergency call when your YotaPhone is locked, tap Emergency call on the lock
screen.
View the call log
On the home screen, tap > .
Save a number from the call log to your contacts list
Send a message to a number in the call log
Clear the call log
Manage your voicemail
You can set up voicemail to receive messages from people who are trying to call you. For more
information, contact your service provider.
Check your voicemail
When you have a new voicemail message, the message icon appears in the notifications
drawer at the top left corner of the screen.
If the phone is switched off, switch it on by pressing and holding the power button
until the phone vibrates.
1. In the call log, tap .
2. Tap Add to contacts.
3. To add the number to a new contact, select CREATE NEW CONTACT, fill in the relevant
information, and tap DONE.
To add the number to an existing contact, select a contact from the list, set the phone
number type, and tap OK.
1. In the call log, tap .
2. Next to the number, tap .
3. Write a message.
4. To send the message, tap .
1. In the call log, tap , and tap Clear call log.
2. Tap OK.
1. To view your notifications, swipe down from the top of the screen.
The message notification shows the number of received messages and the voicemail number
to dial to listen to them.
2. Tap the voicemail number.
Your phone dials the voicemail number. Follow the instructions to listen to your messages.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 17/65
Change the voicemail settings
On the home screen, tap > > Settings > Voicemail.
To set up a new voicemail number, tap Setup, and select the Voicemail number field. Enter a
new voicemail number, and tap OK.
To select a ringtone, tap Voicemail, and tap Sound.
If you want your phone to vibrate when a new voicemail is received, tick Vibrate.
Manage call settings
You can change your ringtone, switch call waiting on/off, and enable Fixed Dialling Numbers.
Change your ringtone
Forward a call
You can set your YotaPhone to forward incoming calls to another number.
Switch call waiting on/off
When call waiting is switched on, you are notified of other incoming calls during a call.
Switch Fixed Dialling Numbers (FDN) on/off
When this feature is switched on, you can make calls only to the phone numbers stored in the
FDN list on the SIM card.
To disable FDN, tap Disable FDN, enter your PIN2 code, and tap OK.
Manage the Fixed Dialling Numbers (FDN) list
1. On the home screen, tap > > Settings.
2. Tap Phone ringtone, select a ringtone, and tap OK.
If you want your phone to vibrate when someone calls you, tick Vibrate when ringing.
1. On the home screen, tap > > Settings > Call forwarding.
2. Select a forwarding mode, and enter the phone number to which you want to forward your
incoming calls.
3. Tap Enable.
1. On the home screen, tap > > Settings > Additional settings.
2. To switch call waiting on, tick Call waiting.
To switch call waiting off, untick Call waiting.
1. On the home screen, tap > > Settings > Fixed Dialling Numbers.
2. Tap Enable FDN, enter your PIN2 code, and tap OK.
1. On the home screen, tap > > Settings > Fixed Dialling Numbers.
2. To view the list of existing FDN numbers, tap FDN list.
3. To add a contact, tap > Add contact.
4. Enter a name and number, and tap Save.
5. Enter your PIN2 code.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 18/65
Change the PIN2 code
Always-on display
The always-on display is an Electronic Paper Display (EPD). Using the always-on display gives you
unique benefits:
The always-on display uses less power, and using it instead of the colour display gives you
longer battery life.
You can use the always-on display even in bright sunshine without straining your eyes.
You can see notifications and other important information without having to pick up the
phone and activate the screen.
The always-on display locks by touching the screen with three or more fingers, or your palm,
pressing the power button, or flipping the phone over and starting to use the colour display.
There is no automatic locking after a time-out.
Use the always-on display
On the always-on display, you can, for example:
See important notifications
Read books, magazines, web articles, PDFs, and office documents
Read social media feeds, and post likes and comments
Read RSS feeds
Read and send emails and text messages
Personalise your phone with your favourite pictures
Show important information, for example an e-ticket, even if the battery is empty
1. On the home screen, tap > > Settings > Fixed Dialling Numbers.
2. Tap Change PIN2.
3. Enter your old PIN2 code, and tap OK.
4. Enter a new PIN2 code, and tap OK.
5. Confirm your PIN2 code.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 19/65
Play games
Answer calls
There are also many other applications and widgets available. You can find more widgets and
applications in the YotaApps catalogue.
Personalise the always-on display
The applications and widgets on the always-on display are placed on YotaPanels. You can
personalise the panels with your favourite widgets.
For privacy purposes or for fun, you can cover your always-on display by a YotaCover, a picture
of your choosing.
Use the YotaHub application on the colour display to customize your always-on display and make
it look like you.
YotaHub
Interaction on the always-on display consists of YotaCover, YotaPanels, and YotaMirror.
YotaHub is an application for customising the always-on display. Use YotaHub to manage your
YotaPanels and YotaCovers. You can customise the panels, the widgets, and the YotaCover
pictures.
To open YotaHub, tap > YotaHub.
To customise your YotaPanels, tap > YotaHub > Panels.
To customise your YotaCovers, tap > YotaHub > YotaCover.
With YotaMirror, you can use the colour display on the always-on display. To use YotaMirror, tap
and hold on the colour display, drag your finger towards , and flip the phone.
Navigation on the always-on display
The navigation panel is located at the bottom of the screen.
To move to the next panel on the left, tap the left arrow. To move to the next panel on the right,
tap the right arrow. You can also swipe the screen with your finger to move to another
YotaPanel.
When you have opened an application on the always-on display, tap to move one step back.
When you have opened an application on the always-on display, tap to return to YotaPanels.
To activate YotaCover, tap .
Answer a call on the always-on display
You can answer a call using the always-on display.
To answer a call, tap and hold the call icon, and drag your finger towards .
You can also tap to answer a call.
To reject a call, tap and hold the call icon, and drag your finger towards .
You can also tap to reject a call.
To reject the call and to send a message to the caller, tap and hold the call icon, and drag
your finger towards .
You can also tap to send a message.

2015/1/23 Introduction
http://yotaphone.com/help/yotaphone2/en/16445.htm 20/65
If you have a missed call, the calls notification appears in full-screen mode for five minutes.
The calls widget on the YotaPanel shows the names or phone numbers of callers, the date and
time of missed calls, and the number of missed calls from each caller.
To view your missed calls on the always-on display, tap the Calls widget.
To make a call, select the contact or the number.
YotaPanel
The widgets on the always-on display are placed on YotaPanels. You can add and remove
widgets using the YotaHub application.
When you first switch on your YotaPhone, the always-on display has one YotaPanel. You can
install four YotaPanels on your phone.
You can add and remove YotaPanels and widgets using the YotaHub application.
Add a preset YotaPanel
Add a YotaPanel grid
Remove a YotaPanel
Add or replace a widget in a grid
1. On the home screen, tap > YotaHub.
2. Tap Panels.
3. Swipe from right to left until you reach an empty panel.
4. Tap .
5. To add a preset panel with widgets added, tap All.
6. Tap the panel you want to add.
7. Tap .
1. On the home screen, tap > YotaHub.
2. Tap Panels.
3. Swipe from right to left until you reach an empty panel.
4. Tap .
5. To add an empty grid and add the widgets yourself, tap Grids.
6. Tap the kind of grid you want to use.
7. Tap .
1. On the home screen, tap > YotaHub.
2. Tap Panels.
3. Swipe left or right to get to the panel you want to remove.
4. Tap > Remove.
1. On the home screen, tap > YotaHub.
