YOTRIO Target halsted FBS80020-C1 User manual

halsted
steel wicker chaise lounge
style # FBS80020-C1/C2/C3/C4
dpci # 009005410/5417/5424/8304/8313
>>assembly instructions TM

2
Congratulations on your latest Target purchase.
Now what? Don't start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you'll be on your way to transforming your patio in no time.
Good luck – though we're confident you won't need it.
ATTENTION:
This Chaise Lounge is not intended for use during any kind of inclement weather and the manufacturer is not, and
held responsible for any damages caused as a result of such weather. Weather-related damage, or damage
result of the Chaise Lounge not being stored properly when not in use, is not the responsibility of the manufacturer.
During extended periods of non-usage, off season, or in inclement weather (wind, rain, snow, hail, sleet), freezing
conditions and extreme heat, the Chaise Lounge needs to be stored in a dry, sheltered place to prolong the life and to avoid
damage to the Chaise Lounge.
can not be
as a
IMPORTANT WARNING:
Unpack the box on a clean, soft, level surface and make sure all parts have been included.
To replace missing or damaged parts please call 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.

WARRANTY:
This Chaise Lounge comes with a one year limited warranty against original manufacture defects. If you experience
trouble with your chaise lounge, please call the customer service number below.
before you begin
1. Check for damage or missing parts. Call 855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
3
Target Corporation
Toll Free at: 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.
Code: Yotrio 2018

table of contents
introduction
hardware
parts list
assembly
2-3
5
6
7-12
QUESTIONS?
4Please call 855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have th e style number and DPCI number ready when calling.

hardware
5
(Part I)×1
allen wrench
(Part G)×12
(Part E)×8
M6*25mm screw
(Part F)×2
M6*45mm screw washer
(Part H)×2
M6 nut
(Part J)×1
M6 wrench

ITEM DESCRIPTION QUANTITY
front wall
back wall
1
1
1
A
B
C
D
6
chaise frame
1
adjust lever
A
B
'
&

7
step 01:
1. Take out WKHchaise frame (A), unfold WKHleft side wall and right side wall.
ATTENTION: To avoid damage to your new patio furniture, please
use either the carton or another soft surface such as carpet as a
working surface to prevent product damage during assembly.
A

step 02:
(Part G)×4
washer
(Part E)×4
M6*25mm screw allen wrench
(Part I)×1
8
A
B
(*
1. AttachWKH front wall (B) toWKH side wall of WKHchaise frame (A) by lining up screw holes onWKH side wall
ofWKH chaise frame (A) with corresponding screw holes on front wall (B)
Secure with M6*25mm screws(E) and washers (G) using allen wrench (I).
Do not completely tighten screws until all screws are in place.

9
step 03:
1. Attach the back wall (C) to the side wall of the chaise frame (A) by lining up screw holes on the side wall
of the chaise frame (A) with corresponding screw holes on the back wall (C).
2. Secure with M6*25mm screws(E) and washers(G) using allen wrench (I).
Do not completely tighten screws until all screws are in place.
(Part G)×4
washer allen wrench
(Part I)×1
(Part E)×4
M6*25mm screw
A
C
E
G

10
step 04:
1. Insert the adjust lever (D) to the back of the chaise frame (A).
A
D

step 05:
11
1. Secure with M6*45mm screw (F) and washer (G) using allen wrench (I).
2. On the other side, secure with M6 nut (H) and washer (G) using M6 wrench (J).
3. Repeat above stepsuntil the adjust lever (D) is secured into the back frame of the chaise frame (A).
Do not completely tighten screws until all screws are in place.
(Part G)×4
washer
(Part F)×2
M6*45mm screw M6 nut
(Part H)× 2 (Part I)×1
allen wrench
(Part J)×1
M6 wrench
D
H
G
FG
A

step 06:
12
1 Tighten all screws, including screws preassembled.
2. urn chaise lounge to upright position on a flat level surface.
Put the cushion on the chaise.
You are now ready to enjoy your new chaise lounge.
.
