ZALMAN FS-V7 User manual

VGA Cooler FS-V7
User’s Manual
www.fatal1ty.com

FATAL1TY STORY
Who knew that at age 19, I would be a World
Champion PC gamer. When I was 13, I actually played
competitive billiards in professional tournaments and
won four or five games off guys who played at the
highest level. I actually thought of making a career of it,
but at that young age situations change rapidly.
Because I’ve been blessed with great hand-eye
coordination and a grasp of mathematics (an important
element in video gaming) I gravitated to that activity.
GOING PRO
I started professional gaming in 1999 when I entered the CPL (Cyberathlete
Professional League) tournament in Dallas and won $4,000 for coming in third
place. Emerging as one of the top players in the United States, a company interested
in sponsoring me flew me to Sweden to compete against the top 12 players in the
world. I won 18 straight games, lost none, and took first place, becoming the
number one ranked Quake III player in the world in the process. Two months later
I followed that success by traveling to Dallas and defending my title as the world’s
best Quake III player, winning the $40,000 grand prize. From there I entered
competitions all over the world, including Singapore, Korea, Germany, Australia,
Holland and Brazil in addition to Los Angeles, New York and St. Louis.
WINNING STREAK
I was excited to showcase my true gaming skills when defending my title as CPL
Champion of the year at the CPL Winter 2001 because I would be competing in a
totally different first person shooter (fps) game, Alien vs. Predator II. I won that
competition and walked away with a new car. The next year I won the same title
playing Unreal Tournament 2003, becoming the only three-time CPL champion.
And I did it playing a different game each year, something no one else has ever
done and a feat of which I am extremely proud.
At QuakeCon 2002, I faced off against my rival ZeRo4 in one of the most highly
anticipated matches of the year, winning in a 14 to (-1) killer victory. Competing at
Quakecon 2004, I became the World’s 1st Doom3 Champion by defeating Daler in
a series of very challenging matches and earning $25,000 for the victory.

LIVIN’ LARGE
Since my first big tournament wins, I have been a “Professional Cyberathlete”,
traveling the world and livin’ large with lots of international media coverage on
outlets such as MTV, ESPN and G4TV to name only a few. It's unreal - it's crazy.
I’m living a dream by playing video games for a living. I’ve always been athletic and
took sports like hockey and football very seriously, working out and training hard.
This discipline helps me become a better gamer and my drive to be the best has
opened the doors necessary to become a professional.
A DREAM
Now, another dream is being realized – building the ultimate gaming computer,
made up of the best parts under my own brand. Quality hardware makes a huge
difference in competitions…a couple more frames per second and everything gets
really nice. It's all about getting the computer processing faster and allowing more
fluid movement around the maps.
My vision for Fatal1ty hardware is to allow gamers to focus on the game without
worrying about their equipment, something I’ve preached since I began competing.
I don’t want to worry about my equipment. I want it to be there – over and done
with - so I can focus on the game. I want it to be the fastest and most stable
computer equipment on the face of the planet, so quality is what Fatal1ty brand
products will represent.
Partners
This is just the beginning. We’re already in development for a whole range of new
products, and I’m really grateful to all my partners, such as Zalman, for helping
make my dreams a reality.
I know there is a business side to all of this, but for me the true reward is making
products that are so good I can win with them – and making them available to
fellow gamers. Gaming is my life, and many fellow gamers around the world are
also some of my best friends, so giving back to the gaming community is really
important to me.
Johnathan “Fatal1ty” Wendel

User’s Manual (English Version)
1. Important Notices
1.1) Please read this manual thoroughly before installation.
1.2) After installing this product on a VGA(Video Graphics Array) card, a PCI slot adjacent to
the AGP (or PCIe) slot will become unusable.
1.3) Before installing on a newly released VGA card, please check for compatibility at
Fatal1ty’s website* or Zalman’s website**.
1.4) This product is not compatible with Matrox VGA cards and NVIDIA PCX 5*** VGA cards.
1.5) If the VGA card and its components interfere with the installation of this product, stop the
installation, refer to the list of compatible VGA cards at Fatal1ty’s website* or Zalman's
website**, and install this product with one of the compatible VGA cards.
1.6) A rear case fan is recommended for enhancing the performance of this product.
* www.fatal1ty.com
** www.zalman.co.kr
Disclaimer
Zalman Tech Co., Ltd., Fatal1ty, Inc., and any of its partners are not responsible for any
damages due to external causes, including but not limited to, improper use, problems with
electrical power, accident, neglect, alteration, repair, improper installation, or improper
testing.
2. Features
2.1) Pure copper heatsink with ultra large surface area for maximum cooling performance.
2.2) 80mm fan (with red LEDs) installed in the heatsink (FHS) cools not only the VGA chipset
and VGA RAM, but all other VGA components as well.
2.3) Quiet Mode(5V) and Performance Mode(12V) selection provided to accommodate the
user's environment and preference.
3. Specifications
3.1) FHS Assembly (Flower Heatsink & Fan)
3.1.1) Dimensions : 91(L) x 126.4(W) x 30(H)mm
3.1.2) Weight : 270g
3.1.3) Base Material : Pure Copper
3.2) Fan Specifications
3.2.1) Dimensions: 80(L) x 80(W) x 15(H)mm
3.2.2) Bearing Type : 2 Ball-Bearing Sets
3.2.3) Fan Speed : 2,050 rpm ±10% (Quiet Mode), 3,500 rpm ±10% (Performance Mode)
3.2.4) Noise Level : 23.7 dB ±10% (Quiet Mode), 36dB ±10% (Performance Mode)

4. Components
①FHS Assembly(Flower Heatsink & Fan)
②Eight (8) RAM Heatsinks
③One (1) Brace Plate
④Two (2) Nipple ‘A’
⑤Two (2) Nipple ‘B’
⑥Four (4) Bolt 'A' (Ø3 x 5mm)
⑦Four (4) Bolt 'B' (Ø4 x 4mm)
⑧Six (6) Rubber Rings
⑨Thermal Grease
⑩One (1) Multi-Connector
⑪User’s Manual
①
②③
④⑤⑥⑦⑧ ⑨ ⑩⑪
User’s
Manual
5. Exploded View
1) VGA RAM
2) Bolt ‘A’
3) FHS Assembly
5) Nipple ‘A’
4) RAM Heatsink
6) Rubber Ring
7) VGA Chipset
8) Rubber Ring
9) Nipple ‘B’
10) RAM Heatsink
11) Brace Plate
12) Bolt 'B'

6. Installation Procedure
※The following installation sequence MUST be followed.
(Nipple ‘A’ and ‘B’ →Brace Plate →VGA RAM Heatsinks
→Thermal Grease Application →VGA Cooler →VGA Card →Supply Power)
1) Nipple ‘A’
2) Rubber Ring
4) Rubber Ring
5) Nipple ‘B’
6.1) Install Nipples ‘A’ and ‘B’
Check the VGA card for compatible installation hole positions. Install Nipple ‘A’ and
Nipple ‘B’ on the heatsink Mounting Holes as shown in the diagram. Remember to use
Rubber Rings in between.
Warning)
The Nipples MUST be tightened by hand. Using tools to tighten the Nipples may break
the tip of the Nipples.
3) Mounting Hole
A B
Nipples
(Nipple Installation Holes for Various VGA Cards)
The Nipples must be installed through the Mounting Holes indicated with black holes(●) as
shown in the diagram.
3) Slot Connector 3) Slot Connector 3) Slot Connector
1) VGA Chipset
2) Mounting Hole
1) VGA Chipset
2) Mounting Hole
1) VGA Chipset
2) Mounting Hole
ATI Radeon 9 Series
ATI Radeon X Series
NVIDIA Geforce4 MX Series
NVIDIA Geforce FX 5200
NVIDIA Geforce FX 5500
NVIDIA Geforce FX 5600(FX 5700)
NVIDIA Geforce4 Ti 4*** Series
NVIDIA Geforce FX 5700(Ultra) Series
NVIDIA Geforce FX 5800 Series
NVIDIA Geforce FX 5900 Series
NVIDIA Geforce FX 5950 Series
NVIDIA Geforce 6600 Series
NVIDIA Geforce 6800 LE Series
NVIDIA Geforce 6800 Series
NVIDIA Geforce 6800 GT Series
NVIDIA Geforce 6800 Ultra Series
NVIDIA Geforce 6800 Ultra Extreme

1) Brace Plate
2) Screwdriver
3) Bolt 'B'
4) Nipple ‘B’
6.2) Install the Brace Plate
Use each Bolt 'B' to attach the
Brace Plate to each Nipple ‘B’ as
shown in the diagram.
6.3) Attach the VGA RAM Heatsinks
Remove the Film from the Thermal Tapes
on the bottom of the RAM Heatsinks and
attach the heatsinks on the VGA RAM.
3) RAM Heatsink
4) VGA RAM
5) Nipple ‘A’
6) VGA Chipset
1) Thermal
Tape
2) Film
Note 1) If Thermal Grease or other residue remains on the RAM, the Thermal Tapes will not
stick. Clean the surface of the RAM with acetone or alcohol before attaching.
Note 2) The bonding strength of the Thermal Tapes reach 90% after 24 hours of curing.
Do not put excessive force on the RAM Heatsinks during this period.
Note 3) Thermal Tapes lose adhesiveness after they have been used for attachment once
and cannot be reused. New Thermal Tapes should be purchased for later
reattachment.
6.4) Apply Thermal Grease
Clean the contact surface of the VGA
Chipset completely. Apply Thermal
Grease on the VGA Chipset’s core
that makes contact with the base of
the FHS Assembly.
1) Thermal Grease
2) RAM Heatsink
3) Nipple ‘A’
4) VGA Chipset

6.5) Install the FHS Assembly
Align the FHS Assembly’s base on the
center of the VGA Chipset. Screw each
Bolt ‘A’ on each Nipple ‘A’ slightly, and
tighten each Bolt ‘A’ a few turns at a time,
alternating between each bolt, until the
Clip is completely attached to each
Nipple ‘A’.
Note)
Make sure that the heatsink's base and
the VGA Chipset are completely in
contact with each other.
1) Bolt ‘A’
2) FHS Assembly
3) Clip
4) Nipple ‘A’
5) VGA Chipset
6.6) Install the VGA Card
Insert the assembled VGA
card into the motherboard’s
AGP (or PCIe) slot.
Use the Fixing Bolt to fix the
VGA card onto the computer
case.
If the VGA card has a power
connector on it, remember to
plug in the power cable.
1) Fixing Bolt 2) AGP Slot
6.7) Supply Power to the Fan
Connect the Multi-Connector to the
power supply’s 4-pin connector as
shown in the diagram.
1) 12V
2) FS-V7 Fan Connector
3) 5V
4) Multi-Connector 3-Pin
5) Multi-Connector 4-Pin
6) Power Supply
4-Pin Connector
Quiet Mode (5V) Performance Mode (12V)
Speed 2050 rpm ±10% 3,500 rpm ±10%
Noise 23.7 dB ±10% 36 dB ±10%

www.fatal1ty.com
www.zalman.co.kr
www.zalmanusa.com
Fatal1ty and the Fatal1ty logo are trademarks of Fatal1ty, Inc. under the master license of Auravision, Inc.
Zalman and the Zalman logo are trademarks of Zalman Tech Co., Ltd.
©2005 Zalman Tech Co., Ltd. All rights reserved.
