ZAVIOMotorizedOutdoorIRBullet

Quick Installation Guide

1



Quick Installation Guide

Please follow the installation steps below to set up your IP camera.

Check the package contents with the list below. See P.1

Physical overview. See P.2

I/O Terminal Block Circuit. See P.3

I/O Terminal Block Pin Definition. See P.3

LED Indicator Definition. See P.3

Installation of hardware and connection of all cables. See P.4

Windows: Go to Zavio website and download Camera Installation Tool. See P.5

Access the IP Camera using Camera Installation Tool. See P.6

MAC OS: using Safari Browser. See P.9

Lighting environment. See P.11

Change language of the web interface. See P.12

Application of IP Camera. See P.13

Package Contents

Camera IP camera

Quick Installation Guide Brief product information and quick installation

Accessory Alignment Sticker

Screw pack for wall and ceiling mounting

Desiccant bag

Terminal block 2pin DC connector

Waterproof connector

Screwdriver

Software

The following software and information are available online:

- Video Management Software

- Camera Installation Tool

- User manuals

- Camera Language Packs

You may download the above at http://www.zavio.com/downloads.php or you

may scan the below QR-Code.

ToactivateVideoManagementSoftware,pleaseenterthelicensekeybelow.

2



Physical overview



Micro-SD Card Slot

The micro-SD card slot is built inside the housing. Remove the three screws of the

back housing as below No.1, and you’ll see the micro-SD card slot.



IRLED

Lens

LightSensor

IRLED

①

3



I/O Terminal Block Circuit



I/O Terminal Block Pin Definition

Definition Description Max. V/A

Alarm Input 1 Connect to GND to activate, or leave

floating/unconnected to deactivate. 30V DC

Alarm Input 2 Connect to GND to activate, or leave

floating/unconnected to deactivate. 30V DC

Alarm Output Relay contact output. Contact capacity with

resistance load.

0.3A at 125V AC

or

1A at 30V DC



LED Indicator

LED Color Indication

Network Green Solid green when network is established.

Orange Blink orange when there is network activity.

4



Install the hardware and connect all cables

A. Wall mounting and Ceiling mounting

1) Attached the alignment sticker to the wall. Drill four holes into the wall. Then

hammer the supplied plastic anchors into the screw holes and secure the

bracket with supplied screws.

2) Adjust the angle of the bracket to aim the desired area.



Note: when the adjustment is finished, please change the desiccant bag in back

cover.

B. Connect all cables

B1. Without Power over Ethernet (PoE) connection

1. Connect the power adaptor to the IP Camera.

2. Use a standard RJ-45 network cable and connect the IP Camera to a

hub/switch/router.



5



B2. Power over Ethernet (PoE)

1. Use a standard RJ-45 network cable and connect the IP Camera to a

PoE-enabled hub/switch/router.

B3. RJ45 waterproof connector

1. Make sure all components are assembled as shown on the below graph.

2. Check that the Ethernet Port and the Waterproof main body are tightly fasten.

Windows: Go to Zavio Website and download Camera Installation Tool

Please go http://www.zavio.com/softwaredownloads.php download “Camera

Installation Tool”. And follow the installation process to complete the

installation.

6



Access the IP Camera using Camera Installation Tool

1. Please check two settings before using Camera Installation Tool.

a. Browser’s Internet Properties →Security→Default Level

b. Browser’s Internet Properties →Privacy →Uncheck Pop-up Blocker

7



2. Click the Camera Installation Tool Icon on your desktop. The main page will

show up listing all active camera and video server devices. Select the

desired IP cameras from the list and click Link to IE.



3. Enter Username and Password to login to the IP Camera.

(Default is admin / admin)



8



4. When accessing the IP Camera for the first time, a yellow information bar

appears below the address bar:This website wants to install the

following add-on: AxvideoView.cab from ‘Zavio Inc’.



5. Click the information bar, and select Install ActiveX control.



6. Click Install



9



7. Live video will display in the center of your web browser.

MAC OS using Safari Browser

1. Select Safari Icon

10



2. Click Bonjour function and select the camera you wish to access.



3. Enter name and password to login to the IP camera

(Default is admin / admin)



11



4. Live video will display in the center of your web browser.



Lighting environment setting

Default setting for lighting environment is Auto. You may change exposure

frequency to 50 or 60 Hz at Setting > Live View > Camera Setting > Image

Setting.



12



Change the Web Interface into your preferred language

Before accessing the Setting page to change the language of the web interface,

you must download the language pack.

1. Go to http://www.zavio.com/downloads.php and download the language pack

corresponding to your IP camera model.

2. Go to the IP camera setting page and upload the preferred language from the

language pack downloaded from step 1.

Setting > System > Maintenance > Language > Upload

3. Once the upload is complete, the browser will automatically change the

language.



13



Application of IP Camera

14



Memo

…………………………………………………………………………………………………………………………………………………..




