Zavio F5110 User manual

P5110 / P5115 User Manual
i

P5110 / P5115 User Manual
i
Contents
CHAPTER 1. SAFETY INSTRUCTION ....................................................................................................................... 1
CHAPTER 2. MINIMUM SYSTEM REQUIREMENT &........................................................................................... 3
PRODUCT FEATURE..................................................................................................................................................... 3
2.1 SYSTEM REQUIREMENT ..........................................................................................................................................3
2.2 PRODUCT FEATURES ............................................................................................................................................... 4
CHAPTER 3. USING IP CAMERA VIA WEB BROWSER ........................................................................................ 5
3.1WINDOWS WEB BROWSER....................................................................................................................................... 5
3.2 MAC WEB BROWSER............................................................................................................................................... 5
3.2 MAC WEB BROWSER............................................................................................................................................... 6
CHAPTER 4. SETTING UP WIRELESS CONFIGURATION (ONLY FOR P5115 ) ............................................... 8
CHAPTER 5. OPERATING IP CAMERA VIA MOBILE PHONE ........................................................................... 9
CHAPTER 5. OPERATING IP CAMERA VIA MOBILE PHONE ......................................................................... 10
5.1 MOBILE PHONE VIEWING .....................................................................................................................................10
5.2 USING IP CAMERA VIA IPHONE............................................................................................................................. 11
CHAPTER 6. MSN MESSENGER............................................................................................................................... 11
CHAPTER 6. MSN MESSENGER............................................................................................................................... 12
CHAPTER 7. CONFIGURATION OF MAIN MENU................................................................................................ 15
7.1 LIVE VIEW .............................................................................................................................................................15
7.1 LIVE VIEW .............................................................................................................................................................16
computer computer.................................................................................................................................................. 16
7.2 SETTING .................................................................................................................................................................18
7.3 CLIENT SETTING ...................................................................................................................................................18
7.3 CLIENT SETTING ...................................................................................................................................................19
7.3.3 Protocol.......................................................................................................................................................... 19
7.4 IMAGE SETUP......................................................................................................................................................... 20
7.5 PT CONTROL ......................................................................................................................................................... 20
7.5 PT CONTROL ......................................................................................................................................................... 21
CHAPTER 8. SETTING-BASIC................................................................................................................................... 22
8.1 SYSTEM ..................................................................................................................................................................22
8.1.1 Information.................................................................................................................................................... 22
8.1.2 Date / Time..................................................................................................................................................... 23
8.1.3 Initialize ......................................................................................................................................................... 24
8.1.4 Language ....................................................................................................................................................... 25
8.2 CAMERA................................................................................................................................................................. 26
8.2.1 General .......................................................................................................................................................... 26
8.2.2 H.264.............................................................................................................................................................. 28
8.2.3 MPEG-4......................................................................................................................................................... 29
8.2.4 MJPEG .......................................................................................................................................................... 31
8.2.5 3GPP.............................................................................................................................................................. 32
8.2.6 Advanced........................................................................................................................................................ 33
8.2.7 PLAYBACK ................................................................................................................................................... 35
8.3 NETWORK ..............................................................................................................................................................36
8.3.1 Information.................................................................................................................................................... 36
8.3.2 PPPoE (Point-to-Point Protocol over Ethernet)........................................................................................... 37
8.3.3 DDNS (Dynamic DNS) ................................................................................................................................. 39
8.3.4 UPnP (Universal Plug and Play) .................................................................................................................. 43
8.3.5 Bonjour.......................................................................................................................................................... 43
8.3.5 Bonjour.......................................................................................................................................................... 44
8.3.6 IP Notification ............................................................................................................................................... 45

P5110 / P5115 User Manual
ii
8.3.7 Wireless (Only for P5115) ............................................................................................................................. 46
8.3.8 Messenger...................................................................................................................................................... 48
8.4 SECURITY...............................................................................................................................................................50
8.4.1 Account .......................................................................................................................................................... 50
8.4.2 HTTPS........................................................................................................................................................... 51
8.4.3 IP Filter ......................................................................................................................................................... 52
CHAPTER 9. SETTING-ADVANCED ........................................................................................................................ 52
CHAPTER 9. SETTING-ADVANCED ........................................................................................................................ 53
9.1 PT CONTROL ......................................................................................................................................................... 53
9.1.1 Setting ............................................................................................................................................................ 53
9.2 PRESET POSITION ..................................................................................................................................................53
9.2 PRESET POSITION ..................................................................................................................................................54
9.2.1 Setting ............................................................................................................................................................ 54
9.2.2 Alarm Sending............................................................................................................................................... 55
9.3 PATROL .................................................................................................................................................................. 56
9.3 PATROL .................................................................................................................................................................. 57
9.4 FTP CLIENT...........................................................................................................................................................57
9.4 FTP CLIENT...........................................................................................................................................................58
9.4.1 General .......................................................................................................................................................... 58
9.4.2 Alarm sending ............................................................................................................................................... 59
9.4.3 Periodical sending ......................................................................................................................................... 61
9.5 SMTP ....................................................................................................................................................................62
9.5.1 General .......................................................................................................................................................... 62
9.5.2 Alarm sending................................................................................................................................................ 64
9.6 NETWORK STORAGE.............................................................................................................................................. 67
9.6.1 General .......................................................................................................................................................... 67
9.6.2 Alarm sending................................................................................................................................................ 68
9.6.3 Periodical recording ...................................................................................................................................... 70
9.7 HTTP EVENT.........................................................................................................................................................71
9.7.1 General .......................................................................................................................................................... 71
9.7.2 Alarm sending................................................................................................................................................ 72
9.8 ALARM OUTPUT .................................................................................................................................................... 76
9.9 SCHEDULE.............................................................................................................................................................. 78
9.10 ALARM INPUT ......................................................................................................................................................78
9.10 ALARM INPUT ......................................................................................................................................................79
9.11 ALARM BUFFER ...................................................................................................................................................79
9.11 ALARM BUFFER ...................................................................................................................................................80
9.12 MOTION DETECTION........................................................................................................................................... 81
9.13 AUDIO DETECTION ..............................................................................................................................................82
9.14 SYSTEM LOG........................................................................................................................................................ 83
CHAPTER 10. APPENDIX ........................................................................................................................................... 84
A. FRAME-RATE AND BITRATE TABLE –HELP TO SET IPCAMERA WITH YOUR NETWORK ENVIRONMENT TO ACCESS
INTERNET...................................................................................................................................................................... 84
A.1 Mega Mode ...................................................................................................................................................... 84
A.2 VGA Mode........................................................................................................................................................ 87
B. STORAGE REQUIREMENT TABLE -HELP TO SET RECORDING STORAGE SYSTEM....................................................90
B.1 Mega Mode ...................................................................................................................................................... 90
B.2 VGA Mode........................................................................................................................................................ 92
C. SYSTEM REQUIREMENT –HELP TO SETUP SYSTEM ................................................................................................ 94
C.1. 16 Channel IPCamera with CIF Performance.............................................................................................. 94
C.2. 16 Channel IPCamera with D1 Performance................................................................................................ 94
EUROPE – EU DECLARATION OF CONFORMITY .............................................................................................. 95
FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT ............................................ 97

P5110 / P5115 User Manual
1
User Manual
Chapter 1. Safety Instruction
¾Before you use this product
This product has been designed with safety in mind. However, the electrical products can cause
fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to
heed the following.
¾Legal Caution
Video and audio surveillance can be forbidden by laws that vary from country to country. Check the
laws in your local region before using this product for surveillance purposes.
¾Don't open the housing of the product
Don't try to open the housing or remove the covers which may expose yourself to dangerous voltage
or other hazards.
¾Don't use the accessories not recommend by the manufacturer
¾Heed the safety precautions
Be sure to follow the general safety precautions and the “Operation Notice.”
¾Operation Notice - Operating or storage location
Avoid operating or storing the camera in the following locations:
xExtremely hot or cold places
(Operating temperature: 0 °C to + 50 °C [32 °F to 122°F] )
xExposed to direct sunlight for a long time, or close to heating equipment (e.g., near heaters)
xClose to water (e.g.,near a bathtub, kitchen sink, laundry tub)
xClose to sources of strong magnetism
xClose to sources of powerful electromagnetic radiation, such as radios or TV transmitters
xLocations subject to strong vibration or shock
¾In case of a breakdown
In case of system breakdown, discontinue use and contact your authorized dealer.
Safety Instruction

P5110 / P5115 User Manual
2
¾In case of abnormal operation
xIf the unit emits smoke or an unusual smell,
xIf water or other foreign objects enter the cabinet, or
xIf you drop the unit or damage the cabinet:1 Disconnect the cable and the connecting cables. 2
Contact your authorized dealer or the store where you purchased the product.
¾Transportation
When transporting the camera, repack it as originally packed at the factory or in materials of equal
quality.
¾Ventilation
To prevent heat buildup, do not block air circulation around the device.
¾Cleaning
xUse a soft, dry cloth to clean the external surfaces of the device. Stubborn stains can be
removed using a soft cloth dampened with a small quantity of detergent solution, then wipe dry.
xDo not use volatile solvents such as alcohol, benzene or thinners as they may damage the
surface.
Safety Instruction

P5110 / P5115 User Manual
3
Chapter 2. Minimum System Requirement &
Product Feature
2.1 System Requirement
For normal operation and viewing of the network camera, it’s recommended that your
system meet these minimum requirements for proper operation:
Item Requirements
CPU Pentium 4 1.8GHz (or equivalent AMD)
Graphic Card 64 MB RAM graphic cards(or equivalent on-board graphic cards)
RAM 512 MB
Operating
System
Windows 98, Windows ME (Please see Note)
Windows2000, 2003, XP, Vista, Mac OS X Leopard
Web Browser Internet Explore 6 or later
Note:
1. If using Windows 98 or Windows ME, please install IP Installer before using WEB UI to
ensure the system runs normally.
2. If not able to view the recorded video file, please install Xvid codec while installing
Intelligent IP Installer. (For Windows 98, ME or 2000 server, the codec might not work
properly. Please download Xvid codec 1.0 from the internet.)
3. Please keep updating the latest Windows software and service package. (Ex: Net
Framework, Windows Media Player, Enhance ActiveX Security)
Minimum System Requirement
& Product Feature

P5110 / P5115 User Manual
4
2.2 Product Features
These easy-to-follow instructions make setup and operation quick and simple, so you’ll also soon
be enjoying the benefits of these PRODUCT FEATURES:
SYSTEM
Resolutions
H.264 / MPEG-4 / Motion JPEG:
4 resolutions from 1280x1024 to 320x240 via API and
configuration web page
Screen Resolution Higher than 1024 * 720 pixels
Compressing format H.264 / MPEG-4 / Motion JPEG
Frame Rate Up to 15 fps at 1280x1024
Up to 30 fps at 640x480
Rotation: Mirror, Flip, Mirror Flip
Brightness / Contrast / Saturation
Image settings
Overlay capabilities: time, date, text and privacy image
Image snapshot Yes
Video Recording Yes
Full Screen Viewing Yes
Digital Zoom 10x digital
Two-way (full / half duplex) with built-in microphone
Audio Audio compression: G.711 μ law, a law, and AMR
Instant Messenger Support MSN Live View
Mobile Phone Live
View Through 2.5 WAP
Alarm Sending FTP Client / SMTP / Network Storage / HTTP Event
Security Password Protection / HTTPS encryption / IP Filter
Alarm Buffer Recording image and audio file pre-and-post disconnection up
to 5 sec.
Supported protocols
Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP,
DNS, NTP, UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA
RTSP
Simultanious
Connection Up to 10 users
Operating conditions 0к~ 50к(32л~ 122л)
˛˔˥˗˪˔˥˘ʳ
Lens F1.8, 4.2mm Megapixel board lens
IR LEDs 5ijIR LEDs x 12 (850nm)
IR working distance 15M
I / O 1 in / 1 out
Audio Output 1
Alarm Input 1
Power 12V DC, 1A, Max 5W
NETWORK
Ethernet 10 / 100 Base T (for P5110)
Wireless IEEE 802.11b/g (for P5115)
Minimum System Requirement
& Product Feature

P5110 / P5115 User Manual
5
Chapter 3. Using IP Camera via Web Browser
3.1Windows Web Browser
1. Open your web browser, and enter the IP address or host name of the IP camera in the
Location / Address field of your browser.
Note : If you only want to view the video without accessing Stting screen, enter
“http://<IP>/index2.htm” as your web URL.
2. Use the default account “admin” and default password “admin”.
Note : The default user name “admin” and the password are set at the factory for the
administrator. You can change them in the Account Menu. (Please check “Setting ĺ
Basic ĺSecurity ĺAccount”)
3. The monitor image will be displayed in your browser. In the far left side of main
configuration are Setting, Client Setting, and Image Setup and PT control. For more details,
you can check Chapter 7.2ΕChapter 7.3ΕChapter 7.4 and Chapter 7.5.
Using IP Camera via
Web Browser

P5110 / P5115 User Manual
6
3.2 Mac Web Browser
1. Click the Safari icon, and enter the IP address of the IP camera in the Location / Address
field of your browser.
Note : If you only want to view the video without Setting screen
“http://<IP>/index2.htm” as your web URL.
2. Enter the default account “admin” and default password “admin”.
Note : The default user name “admin” and the password are set at the factory for the
administrator. You can change them in the Account Menu (Please check “Setting ĺ
Basic ĺSecurity ĺAccount”)
Using IP Camera via
Web Browser

P5110 / P5115 User Manual
7
3. The monitor image will be displayed in your browser. In the far left side of main
configuration are Setting, Client Setting, and Image Setup and PT control. For more details,
you can check Chapter 7.2ΕChapter 7.3ΕChapter 7.4 and Chapter 7.5.
Using IP Camera via
Web Browser

P5110 / P5115 User Manual
8
Chapter 4. Setting up Wireless Configuration
(Only for P5115 )
The wireless network has to be set up by using cable network connection. After setting the
camera correctly, the wireless function can work without cable network connection. Please
follow the setting process below step by step:
1. Connect IP Camera with Ethernet connection.
2.Go to “Setting ШBasic ШNetwork ШWireless,” choose option “On”. You will see
the wireless Setting screen.
3. Then click “Refresh”. All access points (AP) around you will show up.
4. Select the AP you wish to connect.
5. Enter password at active transmit key if you need. If you don't know the setting of the
wireless AP, please ask your network administrator.
Setting up Wireless
Configuration

P5110 / P5115 User Manual
9
6. Choose the option of Obtain an IP address automatically (DHCP) and Obtain DNS server
address automatically.
7. Otherwise, Choose Use the following IP address and Use the following DNS sever address.
¾Use the following IP address: Select this when the fixed IP address is set.
zIP address: Enter the IP address of the device.
zSubnet mask: Enter the subnet mask.
zDefault gateway: Enter the default gateway.
¾Use the following DNS server address: Select this when you set the fixed address as the
IP address of DNS server.
zPrimary DNS server: Enter the IP address of the primary DNS server.
zSecondary DNS server: Enter the IP address of the secondary DNS server, if
necessary.
Setting up Wireless
Configuration

P5110 / P5115 User Manual
10
Chapter 5. Operating IP Camera via Mobile Phone
5.1 Mobile Phone Viewing
5.1.1 3G Mobile Phone Streaming Viewing
For 3G mobile phone viewing, type “ rtsp://<IP>:<PORT>/video.3gp ” into your 3G
Streaming Link. <IP> is the Public IP address of your IP camera; <PORT> is the RTSP port
of your IP camera (Default value is 554.) Example: rtsp://100.10.10.1:554/video.3gp
Note: You can also use RTSP clients (RealPlayer, VLC, QuickTime Player…etc.) to
view RTSP streaming, just type in “rtsp://<IP>:<PORT>/video.3gp” as the Player URL
5.1.2 2.5G Mobile Phone WAP Viewing
For 2.5G mobile phone viewing, type “rtsp://<IP>/mobile.wml ” into your 2.5G WAP
Browser. <IP> is the Public IP address of your IP camera.
5.1.3 2.5G Mobile Phone Browser Viewing
For 2.5G mobile phone viewing, type “rtsp://<IP>/mobile.htm ” into your 2.5G Web
Browser. <IP> is the Public IP address of your IP camera.
Using IP Camera
via Mobile Phone

P5110 / P5115 User Manual
11
5.2 Using IP Camera via iPhone
You can use ZAVIO Web User Interface via iPhone. Please follow the setting process below.
Then you can use ZAVIO Web UI via iPhone.
1. Select Safari function 2. Type IP address in your web link.
3. Type name and password.
Default value is admin / admin.
Then click Login In
4. The ZAVIO User Interface and
live image will show up in the
middle of screen.
Note: The image is continuous snapshots, not
video. Thus, live image can’t be recorded
here.
Using IP Camera
via Mobile Phone

P5110 / P5115 User Manual
12
Chapter 6. MSN Messenger
Please follow the following steps to set up the Messenger function.
1.Download free MSN software and create a new MSN account (Camera at home) for Microsoft
Live Messenger.
3. If your router has firewall function, you have to set the Port Range on this setting page in
accordance with the one of firewall.
4. Choose the Video Mode, decide the live view image of messenger received from Computer View
(MPEG-4) or Mobile View (3GPP).
5. Choose “On” at the option of IP Notification. If this feature switches On, camera will send IP
notification to the users who are allowed.
6.Choose “On” at the option of Privacy. If you can choose “On” at the privacy option, you can set
an allow list.
7. Use your account to login in the Messenger software. Then, add the new MSN account (Camera
at home )
8.The Camera at home will show up with its Public IP and Private IP if the option of IP
Notification is “On”. ( You can enter “Ping” to show up with Public IP and Private IP. )
2.Go to “SettingШBasicШNetworkШMessenger,” set the Messenger to “ON” . Then, login in new
account and password (Camera at home).
9.Click on the small camera icon .
Then, choose “View a new contact's
webcam”.
MSN Messenger

P5110 / P5115 User Manual
13
10. The IP Camera will accept your
invitation; the live video will show up in the
right screen after few seconds.
11. Click Action button and choose Start
Control Panel to use control panel.
12. The dialog box will show up with “This
application is not part if Window Live
Message…….” Tick the box of “Don’t
show me this again” and click OK.
13. The IP Camera will accept your invitation
to start Control Panel.
MSN Messenger

P5110 / P5115 User Manual
14
14. You can click Camera icon to
snapshot then the picture will send to you
immediatel
y
.
16. You can click joystick icon showing
up with arrows of different directions. You can
click the arrow button of direction to do PT
MSN Messenger
15. You can click paint palette icon
showing up with tool bar to set up image. Then,
you can use the tool bar to optimize video
Brightness , Contrast , Saturation
and Sharpness . After the adjustment of all
setting, you can still click to make
the setting back to the original setting.

P5110 / P5115 User Manual
15
Chapter 7. Configuration of Main Menu
In the left side of main configuration are Setting, Client setting, Image setting and PT control. For
more details, please check Chapter 7.2ΕChapter 7.3ΕChapter 7.4.ΕChapter 7.5.
In the right side, you can control Live View in your main Browser. The functions include
Snapshot, Open digital zoom, Audio, and Video Play.
Sna
p
shot
Full screen
Configuration of
Main Menu
Open digital zoom
Video Play
Audio Play

P5110 / P5115 User Manual
16
7.1 Live View
7.1.1 Snapshot
You can capture a still image shot by clicking the camera icon and save it in the operating
computer.
computer computer.
7.1.2 Digital zoom in / out the image via the monitor
window
zClick to display the digital zoom in window.
zPull the to adjust the digital zoom range, and it will be
showed on the above window.
zUse the left click of your mouse to move to anywhere in the window area.
Symbols Meaning
a snapshot window appears after clicking the icon
Save save the picture captured by snapshot into your computer
Close Return to the view screen
full screen
Configuration of
Main Menu

P5110 / P5115 User Manual
17
7.1.3 Video play buttons
Symbols Meaning
Pause the current video
Play the video
Stop the current video
Record the current video
Note: Concerning the recording storage requirement of your hard disk, please refer to
the CHAPTER 10. APPENDIX / B. Storage Requirement Table.
7.1.4 Audio buttons
Symbols Meaning Note
Speakers turned on mean the speakers of your computer are turned
on to transmit the sounds from the connected IP
camera(s)
Speakers turned off mean the speakers of your computer are turned
off to transmit the sounds from the connected IP
camera(s)
Mute off mean you can broadcast to the connected IP
camera(s) via the Ethernet using your
microphone
Mute on mean you can’t broadcast to the connected IP
camera(s) via the Ethernet using your
microphone
Volume control bar mean you can adjust the sound volume by
the control bar
Configuration of
Main Menu
