Zaxcom URX50 User manual

1
User Manual
Published December 2020
Firmware Version URX-2.21
URX50

2

3
HOME SCREEN ............................................................................................................................. 8
MAIN MENU ...................................................................................................................................... 9
NAVIGATING THE MAIN MENU .................................................................................................................................... 9
FREQUENCY SELECT ................................................................................................................................................... 9
LOCK SCREEN ............................................................................................................................................................ 9
SUB MENUS ..................................................................................................................................... 10
MENU GROUPS ....................................................................................................................................................... 10
ACCESSING AND NAVIGATING THE MENU GROUPS ......................................................................................................... 10
ENTERING AND NAVIGATING A SUB MENU .................................................................................................................... 10
EXITING THE EXTENDED MENU ................................................................................................................................... 10
CHANNEL PRESET MENU .................................................................................................................. 11
NUMBER OF PRESETS ............................................................................................................................................... 11
PRESET ADJUST ....................................................................................................................................................... 11
SCAN MENU ..................................................................................................................................... 12
FREQUENCY SCAN ................................................................................................................................................... 12
Scanning for a frequency ................................................................................................................................ 12
Selecting the frequency .................................................................................................................................. 12
SETTING THE SCAN RANGE ........................................................................................................................................ 13
AUDIO MENU .................................................................................................................................. 14
HEADPHONE ROUTER ............................................................................................................................................... 14
SPEAKER ENABLE ..................................................................................................................................................... 14
AUDIO DELAY SET .................................................................................................................................................... 14
VOLUME MODE ...................................................................................................................................................... 14
EXTRA VOLUME ...................................................................................................................................................... 14
LANYARD KEYS ........................................................................................................................................................ 15
1KHZ NOTCH ......................................................................................................................................................... 15
VOLUME BEEPS ....................................................................................................................................................... 15
MUTE IF UNIT CODE ................................................................................................................................................ 15
SETUP MENU ................................................................................................................................... 16
MODULATION SELECT .............................................................................................................................................. 16
UNIT CODE ............................................................................................................................................................. 16
IFB VOTING ........................................................................................................................................................... 16
SOFTWARE UPDATE ................................................................................................................................................. 17
DISPLAY FLIP .......................................................................................................................................................... 17
BATTERY TYPE ......................................................................................................................................................... 17
SCAN ON BOOT ....................................................................................................................................................... 17
HIDE FREQUENCY MENU .......................................................................................................................................... 18
TEST TONE ............................................................................................................................................................. 18
INFORMATION PAGE ................................................................................................................................................ 18
ENCRYPTION CODE SET ............................................................................................................................................ 18
Adjusting the encryption code ........................................................................................................................ 18
NAME SET .............................................................................................................................................................. 19

4
OPERATING FREQUENCIES ............................................................................................................... 20
UHF AUDIO ........................................................................................................................................................... 20
FIRMWARE ...................................................................................................................................... 21
SPECIFICATIONS ............................................................................................................................... 22
PRODUCT SUPPORT ......................................................................................................................... 24
ZAXCOM WARRANTY POLICY AND LIMITATIONS ............................................................................. 25

Zaxcom URX50 Front
5
Front
1. Volume Up and Down keys
2. Channel Up and Down keys
• When in the home or lock screen press to cycle through channel presets.
• When in the sub menu press to cycle through the menus.
• When in a menu press the keys to change the menu parameters.
3. Power / Time Code key
• Press and hold for 2 seconds to power up the URX50.
• Press and hold for 4 seconds to power down the URX50 - then pess the MENU key
• Press three times quickly to enter or exit the menu groups.
• From the home or lock screen press to display the time code and user bits.
4. Menu key
• Press to cycle to the next menu item.
1
2
2
3
4
1

Zaxcom URX50 Top
6
Top
1. Antenna
2. OLED Display
3. 3.5mm Headphone Jack
Please note that this jack acts as the second antenna for diversity reception..
3
1
2

Zaxcom URX50 Rear
7
Rear
1. Battery Compartment - The URX50 uses 3 AA batteries and will work with alkaline, NiMH or lithium
AA batteries. The bottom of the URX50 has charging contacts so when using NiMH batteries, the
batteries can be charged by using Zaxcom’s drop in charger.
WARNING: DO NOT USE THE CHARGER WHEN LITHIUM OR ALKALINE BATTERIES ARE INSTALLED.
2. External Speaker
1
2

Zaxcom URX50 Home Screen
8
Received TX Name
Save Indicator
Received RF Signal Strength Meter
Frequency TX Record Status
Audio Level Meter TC Battery Meter
Home Screen
Received Transmitter Name
This is the name of the transmitter being received by the URX50.
Received Transmitter Record Status
This displays the status of the internal recorder of the transmitter being received by the URX50. Stop (STP) Play
(PLY) or Record (REC) will be displayed.
Save Indicator
The save indicator will briefly flash when after a setting change as a parameter is being written to the memory
of the URX50.
Received Frequency
This is the preset position number and the UHF frequency that the URX50 is receiving.
RF Signal Strength
The RF strength meter shows the radio signal strength of the transmitter. The RF signal is depicted as a staircase
pattern with the lowest step (low signal strength) on the left and building up to the right (higher signal strength).
When more stairs are showing the stronger the signal is.
Audio Level
Displays the incoming audio level, the meter extends from the left to the right. The vertical bar is the -20dBFS
mark and the far-right side of the box is 0dBFS.
Time Code
This is the time code of the transmitter that the URX50 is receiving.
Battery Meter
This displays a rough indication of the transmitter’s battery level. For a more accurate battery reading the battery
type being used in the transmitter needs to be set in the setup menu.
TX NAME
(P1) 570.1
REC
09:18:05:03

Zaxcom URX50 Main Menu
9
Main Menu
Navigating the Main Menu
• To enter the main menu - press the MENU key.
• To advance to the next menu press the MENU key again.
Frequency Select
The frequency select menu is where the URX50 receive frequency is set. This frequency needs to match the
frequency that is set on the corresponding transmitter. To adjust the frequency, press the channel up key to
increase the frequency and press the channel down key to decrease the frequency. When enabled, the URX will
also scroll through its preset frequencies from this menu.
The frequency menu will display the modulation format, the name of the transmitter being received, a RF signal
strength meter, audio meter and an arrow showing which antenna the signal is being received on.
Lock Screen
6
When the lock screen is landed on a 5 second countdown clock will start. After 5 seconds elapse the URX50 will
lock and the menus cannot be accessed, this is to prevent the URX settings from accidentally be changed.
When the URX50 is locked the volume adjust keys, the channel preset keys and the time code display key can
still be used.
To exit the lock screen, hold the MENU key and press the CH UP key 4 times.
FREQ: 570.0
STEREO ‘TX NAME’
LOCKING IN 4
FREQ: 570.0
STEREO ‘TX NAME’

Zaxcom URX50 Menu Navigation
10
Sub Menus
Menu groups
The URX50 has four sub menu groups
• Channel Preset - Sets the number of preset channels and sets the frequency of each preset channel.
• Scan - This is where the URX50 can scan the set RF spectrum.
• Audio - This is where the audio functions of the URX50 are set.
• Setup - This is where the setup parameters of the URX50 is set.
Accessing and navigating the menu groups
From in the main menu press the POWER / TC key three times quickly to access the menu groups. Then
pressing the CH UP or CH DOWN key will cycle between the menu items.
Entering and navigating a sub menu
When landing on the desired menu group press the MENU key to enter that menu. Pressing the MENU key
again will cycle through the menu items.
To return to the top of the menu press the MENU key to cycle to the top or press and hold the MENU key for
1.5 seconds.
Exiting the extended menu
To exit the menus, press the POWER / TC key 3 times quickly to return to the main menu.

Zaxcom URX50 Frequency Presets
11
CHANNEL PRESET MENU
Number of Presets
From this menu the number of presets that the URX50 will display can be selected. The URX50 can have up to 31
presets.
Preset Adjust
From this menu each preset frequency can be adjusted by pressing the CH UP and CH DOWN keys. If the
frequency has a corresponding transmitter that is on the name of the transmitter will be displayed.
Each preset can be toggled on and off by pressing the POWER/TC key. When the preset is ON the user will be
able to cycle to that preset and listen to it, if the preset is OFF the user will not be able access that preset.
After the frequency is set press the MENU key to advance to the next preset.
Please note the number of available frequencies will be determined by the number of presets that was set in the
previous menu.
It is important to note that when using the URX remote preset number 1 will need to be set to the frequency of
the TRXCL3 that is supplying the data to the URX50.
NUMBER OF
PRESETS: 31
PRESET 1: 524.3
TX NAME (ON)

Zaxcom URX50 Scan Menu
12
SCAN MENU
Frequency Scan
The frequency scan menu is where the URX50 will scan the user specified frequency range and search for a
clear frequencies. The frequency range that will be scanned will be displayed on the bottom half of the screen.
The frequency range that will be scanned is set and can be changed in the next menu.
After the scan is completed a graphic display of the RF that is present, in the specified range, will be shown.
The URX50 will also suggest a clear frequency. That frequency can be accepted by pressing the CH UP key. Or
press the CH DOWN key to skip the first chosen frequency and have the URX50 suggest another frequency.
Scanning for a frequency
• Turn off the transmitter(s).
• From the scan menu press the CH UP key to initiate a scan.
• While the URX50 is scanning, the frequency being examined is
displayed in the bottom half of the screen. Once the scan has
completed a graphic map of the scan will be displayed. The low end of the frequency range is on
the left side and the high end is on the right. Wherever RF is found, a vertical line will be drawn.
The line extends from the baseline up. The length of the line indicates the level or strength of the
found RF at that frequency.
Selecting the frequency
When the scan is complete the URX50 will draw a vertical blinking line
on the display to indicate where the first suggested frequency is, and
the frequency in MHz will appear below the scan graphic.
• Press the CH UP key to accept the new frequency.
• Press the CH DOWN key to decline and suggest a different frequency.
PRESS TO SCAN
(ALL 200: 512 – 698)
SCANNING 568.9
TO TAKE 618.2

Zaxcom URX50 Scan Menu
13
Setting the Scan Range
The scan range menu sets the frequency range that the URX50 will scan. Pressing the CH UP and CH DOWN keys
will cycle through the scanning options.
Available Scan Ranges
• All 200 - All frequencies from 512.0MHz through 698.0MHz will be scanned.
• LO 100 - Corresponds to the frequency range of 3.5 transmitters, when selected the URX50 will scan all
frequencies from 512.0MHz through 614.0MHz.
• HI 100 - Corresponds to the frequency range of 3.6 transmitters, when selected the URX50 will scan all
frequencies from 596.0 through 698.0MHz.
• BLK (20 -26) - Allows the URX50 to scan a specific block (Blocks 20-26).
• Block 20 - 518-542 MHz
• Block 21 - 536-572 MHz
• Block 22 - 560-590 MHz
• Block 23 - 590-614MHz (block 23 needs to be enabled)
• Block 24 - 614-644 MHz
• Block 25 - 638-668 MHz
• Block 26 - 662-692 MHz
SCAN LIMIT:
ALL 200 512 - 698

Zaxcom URX50 Headphone Routing Menu
14
AUDIO MENU
Headphone Router
When receiving a stereo signal, the headphone routing will which signal (Left, Right or Both) will be routed to
the headphones.
Speaker Enable
• ON - Turns on the speaker.
• OFF - Turns off the speaker.
Audio Delay Set
The audio delay menu is where a variable delay to the output audio is set. A delay is useful if the URX is being
used for personal monitoring and there is a video processing delay to the monitors - so engaging the delay will
delay the audio to match the video. The audio delay can be adjusted from 1MS to 400MS in 1MS increments.
Volume Mode
• Variable - The volume keys will function as normal
• Fixed - The volume keys will be disabled, and the audio output will be fixed at the current gain setting.
Extra Volume
Up to 10dB of digital gain and be added to the headphone output from this menu.
HP ROUTER
BOTH
SPEAKER:
ON
AUDIO DELAY:
OFF
VOLUME MODE:
VARIABLE
EXTRA VOLUME:
0 DB (DEFAULT)

Zaxcom URX50 Headphone Routing Menu
15
Lanyard Keys
When using a headphone with a built -in volume control switches can be disabled from this menu.
1KHZ Notch
When turned on the 1Kilohertz filter will notch out audio at the 1KHz frequency, this way if someone is
monitoring audio and a tone is sent the listener will not hear it.
Volume Beeps
• ON - There will be a beep tone in the headphone out when adjusting the headphone volume.
• OFF - The headphone volume beeps will be muted.
Mute If Unit Code
This menu sets if transmitters with certain ZaxNet unit codes will not be able to be monitored by the URX50.
For example, if this menu is set to 30 any transmitter with a ZaxNet unit code below 30 will not be able to be
monitored by the URX50.
If a muted preset is selected to be monitored “MUTE” will appear on the display and that preset will not be able
to be listened to - even if that preset is enabled.
LANYARD KEYS:
ENABLED
1KHZ NOTCH:
OFF
VOLUME BEEPS:
OFF
MUTE IF UNIT CODE
(NEVER MUTE)
MUTE IF UNIT CODE
IS LESS THAN 2

Zaxcom URX50 Set Up Menu
16
SETUP MENU
Modulation Select
The modulation menu is where the receive format is set. Modulation is simply the way a transmitter
“modulates”, or sends, its signal to the URX50. This setting needs to match the modulation mode that the
corresponding transmitter is set to - if the two setting do not match the URX50 will not be able to receive and
decode the signal from the transmitter.
Modulation types
• MONO XR - Select when receiving audio from a transmitter sending mono, stereo or XR modulation.
• ZHD 96 - Select when receiving signal from a ZHD transmitter set to ZHD-96.
Unit Code
This is where the code is set to identify the URX. Each URX needs to have a unique identifier code so it can be
controlled by the remote GUI.
IFB Voting
The IFB voting feature will allow the URX50 to automatically switch to a secondary frequency when it loses its
signal from the primary transmitter. One purpose of this is, on a large set, a second transmitter can be placed at
a distant location, so if the URX50 loses the signal from one transmitter it will automatically switch to the other
transmitter.
To use IFB voting just set the offset in this menu. Then set the second transmitters frequency to the primary
frequency + the offset. So, for example if the primary frequency is 560.000 MHz and the offset is 200 KHz then
the second transmitter should be set to 560.200 MHz
RX FORMAT:
ZHD 96
URX CODE: 1
IFB VOTING: ON
200KHZ OFFSET

Zaxcom URX50 Set Up Menu
17
Software Update
This is where the URX software is updated from.
When in this menu pressing the CH UP key will initiate the update process and the URX50 will wait and search
for software that will be transmitted from a Zaxcom transmitter (please refer to the software update section of
this manual for more information on how to update the URX).
Display Flip
The display flip menu changes the orientation of the display. Please note when the display is flipped the CH UP
and CH DOWN keys are flipped as well.
Battery Type
The battery chemistry that is being used in the URX50 is selected in this menu. Lithium, NIMH or Alkaline can be
selected.
Scan on boot
• ON - When the URX boots up it will look for and if necessary, scan for the data channel being sent from the
Zaxcom GUI Bridge via a Zaxcom TRXCL3 camera link transmitter.
When the URX boots up it will look for data from the TRXCL3’s on preset number 1 if the URX does not find
the data it will initiate a scan to search for the data.
For the URX to automatically find the data from the TRXCL3 the UNIT ID code on the camera link needs to be
set to 99 and transmit frequency needs to be set to a whole MHz frequency (for example any frequency like
550.00 MHz or 551.000 MHz will work - a frequency like 550.100 MHz will not work). Then after the data is
received the URX will automatically go back to the frequency it was originally set at.
• OFF - The URX will boot up as normal. If the data is present on the frequency it booted up to it will take the
data if no data is present the URX will continue to operate as normal.
PRESS TO
UPDATE SOFTWARE
DISPLAY FLIP:
OFF
BATTERY TYPE:
LITHIUM
SCAN ON BOOT:
ON

Zaxcom URX50 Set Up Menu
18
Hide Frequency Menu
• ON – The frequency menu will not be available from the home menu; this is to prevent the user from
accidentally changing the frequency.
• OFF - The frequency adjust menu will appear in the main menu.
Test Tone
The URX50 can be set to output a test tone from this menu. This is useful to set levels and check routing.
Pressing the INC and DEC key will cycle through the different tone settings.
• OFF - No tone is being outputted.
• -20dBFS -Tone is simultaneously sent to both outputs at -20dBFS.
• +0dBFS - Tone is simultaneously sent to both outputs at full scale 0dBFS.
Information Page
This page displays the current firmware version and the serial number of the URX50.
Encryption Code Set
This is where the encryption is turned on and the code is set. This code needs to match the encryption code of
the associated transmitter(s). If an encryption code is set on the transmitter the transmitted audio will be
encrypted and can only be listened to if the URX has the same matching encryption code entered. When the
codes do not match, all that will be heard is white noise.
These two sets of numbers are formed into a single six-digit encryption code which provides a total of
16,777,216 possible combinations. For non-encrypted operations, all six numbers should be set to 0.
Adjusting the encryption code
1. Press the menu key to cycle to the next character.
2. To change the designated character, press the CH UP or CH DOWN key.
3. To exit this page, press and hold the MENU key.
HIDE FREQ MENU:
OFF
ID1: 000 ID0: 000
ENCRYPTION CODE
- - - INFO - - -
FIRMWARE 1-00
SN: 1234
URX-50
nnnnnksksksk
OPT = 03
TONE :
OFF

Zaxcom URX50 Set Up Menu
19
Name Set
The name menu allows the URX50 to be named which aids in identifying the URX.
The maximum name length is 8 characters. Any letter or number can be used and if desired a space can
be used.
To set/change the transmitter name:
1. Press the INC or DEC key to change the character in the current position above the arrow.
2. Press the MENU key to proceed to the next character.
3. When finished, press, and hold the MENU key to set the name
NAME: 1234

Zaxcom URX50 Operating Frequencies
20
Operating Frequencies
UHF Audio
URX50 - L Tuning Range: 500 - 638 MHz
URX50 - H Tuning Range: 542 - 698 MHz
