PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
Introduction
Z-3070 Series is ZEBEX’s newest developed handheld type barcode
scanner with optional choices of different scan engine, interface, and as
well as the communications.
Important notices
Thank you for purchasing the Z-3070 Series Handheld Barcode Scanner.
To ensure years of reliable service, please read this Product Reference
Manual carefully and use the scanner safely. Store this Product
Reference Manual in a safe location where you can find it for future use.
© Copyright 2002. ZEBEX Industries Inc. All rights reserved.
The information contained in this document is subject to change without
notice.
No liability is assumed with respect to the use of the information
contained in these written materials or software, or for damages resulting
from the use of the information contained in these written materials or of
the software.
No part of these written materials or software may be reproduced or used
in any form or by any means, electronic or mechanical, including
photocopying and recording and the use of any kind of information
storage and retrieval system or translated to another language, without
prior permission in writing from ZEBEX.
ZEBEX INDUSTRIES INC. All Rights Reserved. i

PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
Precautions
General handling precautions
While using the scanner, please take notes to the following handling
precautions.
 Do not put the scanner to burn in fire.
 Do not put the scanner directly under the sun or by any heat
source.
 Do not use or store the scanner in a very humid place.
 Do not let the scanner drop or collide violently with other objects.
 Do not take apart the scanner without authorization.
ZEBEX INDUSTRIES INC. All Rights Reserved. ii

PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
Contents
Introduction........................................................................................ i
Important notices............................................................................... i
Precautions ....................................................................................... ii
About This Guide
Introduction........................................................................................ vii
Service information............................................................................ vii
Service center ................................................................................... viii
Acquiring information......................................................................... viii
Getting Started With Z-3070
Introduction........................................................................................ 2
Unpacking ......................................................................................... 2
Understanding the scanner parts and functions................................ 3
Installing the cable............................................................................. 4
Power connection.............................................................................. 5
Connecting the scanner to a host...................................................... 6
Getting Ready to Scan with Z-3070
Introduction........................................................................................ 10
Scanning with the Z-3070.................................................................. 10
Aiming ............................................................................................... 10
Scanning mode ................................................................................. 11
Programming and Settings
Introduction........................................................................................ 13
Programming options........................................................................ 13
Default parameters............................................................................ 13
Default values of operating parameters...................................... 14
Predefined barcode identifiers .................................................... 14
Default values of keyboard emulation parameters setting.......... 14
Default values of RS-232C serial communication parameters.... 15
Default values of wand emulation parameters............................ 15
Default values of USB emulation parameters............................. 15
Default values of decoding parameters....................................... 16
Program procedure ........................................................................... 17
System setting................................................................................... 18
General configuration........................................................................ 19
Scanning mode selection (for laser scanner).............................. 19
Scanning mode selection (for CCD scanner).............................. 19
Data redundant check................................................................. 20
Inter-message delay.................................................................... 20
ZEBEX INDUSTRIES INC. All Rights Reserved. iii

PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
Inter-character delay................................................................... 21
Message/block mode selection................................................... 21
Send command in block mode communication........................... 22
Good read beeper tone selection................................................ 22
Sound duration............................................................................ 23
Interface configuration....................................................................... 24
RS-232C serial communication parameters setting.................... 24
Handshaking protocol ........................................................... 24
ACK/NAK response time setting........................................... 24
Baud rate .............................................................................. 25
Data bit.................................................................................. 26
Stop bit.................................................................................. 26
Parity..................................................................................... 26
Message terminator (for RS-232C type only) ....................... 27
Keyboard emulation parameters setting ..................................... 28
Keyboard type selection........................................................ 28
Keyboard language selection................................................ 30
Message terminator (for keyboard wedge use) .................... 31
Keyboard type selection........................................................ 31
Break code on/off setting...................................................... 32
Function key active on/off..................................................... 32
Function key emulation......................................................... 33
00H~1FH ASCII code defined............................................... 33
Wand emulation parameters setting............................................ 34
Emulation speed selection.................................................... 34
Emulation data output selection............................................ 34
Wand emulation narrow/wide ratio........................................ 35
USB interface parameters setting............................................... 36
Keyboard type....................................................................... 36
Message terminator .............................................................. 36
The symbologies............................................................................... 37
Reading code selection............................................................... 37
Code 39 parameters setting........................................................ 40
Interleaved 2 of 5 parameters setting.......................................... 41
Chinese post code parameters setting........................................ 42
UPC/EAN/JAN parameters setting.............................................. 43
Codabar/Monarch parameters setting......................................... 47
Code 128 parameters setting...................................................... 48
UCC/EAN 128 parameters setting .............................................. 49
Matrix 25 parameters setting....................................................... 49
MSI/Plessy parameters setting ................................................... 50
ZEBEX INDUSTRIES INC. All Rights Reserved. iv

PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
Italian pharmacy parameters setting........................................... 52
Barcode length setting ................................................................ 52
ISBN/ISSN conversion................................................................ 53
Data editing....................................................................................... 54
Header and trailer ....................................................................... 54
Barcode identifier code setting.................................................... 55
Truncate header/trailer character................................................ 57
Technical Specifications
Product configuration ........................................................................ 59
Preliminary specifications.................................................................. 60
Special Terms
Terms and definitions ........................................................................ 63
Support and Maintenance
Troubleshooting................................................................................. 69
Customer support.............................................................................. 71
Maintenance...................................................................................... 71
Warranty period and policy................................................................ 72
RMA policy........................................................................................ 73
Product accessories.......................................................................... 75
Cables............................................................................................... 75
User’s documentation ....................................................................... 75
Relative publications ......................................................................... 75
Appendix
Appendix A - Code 39 full ASCII code table...................................... 77
Appendix A - Function key emulation................................................ 79
Appendix B - Code 39 full ASCII barcode table ................................ 80
Appendix C - Barcode samples......................................................... 90
Appendix D - Quick settings.............................................................. 91
ZEBEX INDUSTRIES INC. All Rights Reserved. v

PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
ZEBEX INDUSTRIES INC. All Rights Reserved. vi
ABOUT THIS GUIDE

PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
Introduction
The Z-3070 Series Handheld Barcode Scanner Product Reference
Manual provides general instructions for the setup, programming,
operation, troubleshooting, and maintenance of the Z-3070 Series
Handheld Barcode Scanner.
Service information
If you have any problem with the product, you may contact the ZEBEX
representative in your region, or contact ZEBEX offices for customer care.
Please provide the model number and serial number before contact
ZEBEX for service.
If the problem cannot be solved through e-mails or phone calls, ZEBEX
might request you to send the equipment back for checking. If this is
necessary, you will be given specific directions.
ZEBEX will not be responsible for any damage occurred during shipment
if the approved package is not used. To prevent any possibility that
might void the warranty, please make sure the proper shipment container
is used. If necessary, request an original shipping container from
ZEBEX to send to you.
ZEBEX INDUSTRIES INC. All Rights Reserved. vii

PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
Service Center
For ZEBEX services, warranty repairs, and technical assistance, please
contact your sales representative or the following ZEBEX offices.
HEADQUARTERS
ZEBEX Industries Inc.
2F, 531-1, Chung Cheng Road,
Hsin Tien City, Taipei, Taiwan
TEL / [phone]
FAX / [phone]
E-MAIL / [email protected]
WEBSITE/ www.zebex.com.tw
CHINA
ZEBEX Industries (Shanghai)
No 1998, Qixin Road,
Minhang District, Shanghai,
China Postcode: 201101
TEL / [phone]
FAX / [phone]
E-MAIL / [email protected]
USA
ZEBEX America Inc.
11 Ilene Court, Unit # 2,
Hillsborough, N.J. 08844
TEL / [phone]
FAX / [phone]
E-MAIL / [email protected]
WEBSITE / www.zebex.com
GERMANY
ZEBEX Vertriebs-GmbH
Stimpelwiese 2, D-61250,
Usingen, Germany
TEL / [phone]
FAX / [phone]
E-MAIL / [email protected]
WEBSITE / www.zebex.de
Acquiring Information
You may find the newest software, products information, and technical
supports by connecting to ZEBEX web site at http://www.zebex.com.tw.
If the information needed is not found to solve your problem either from
the Product Reference Manual or ZEBEX web site, please contact
ZEBEX customer services for support.
ZEBEX INDUSTRIES INC. All Rights Reserved. viii

PRODUCT REFERENCE MANUAL
Z-3070 CCD BARCODE SCANNER
GETTING STARTED
WITH Z-3070
ZEBEX INDUSTRIES INC. All Rights Reserved. 1

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Introduction
The Z-3070 Series is the newest developed handheld type barcode
scanner with optional choices of different scan engine, interface, and as
well as the communications.
You can puzzle up your selections with the Z-3070 series to meet your
applications for all kinds of purposes. Selections should be made when
order according to follows:
Z-3070/DC: scans with Dual CCD Engine;
Z-3070/EC: scans with Single CCD Engine;
Z-3070/LR: scans with Long Range Laser Engine;
Z-3070/WA: scans with Wide Angle Laser Engine
Unpacking
Open the package, there should be a scanner and cable. Carefully take
them out of the box. Please make sure both items are the correct ones
as you ordered, and make sure that there is no damage on the cover of
the scanner, and/or the cable.
Contact your supplier or dealer if delivery made is not correct, and/or if
defects found with the scanner or cable.
We highly recommend you to please keep the packing box in case for any
returns or repairs to ZEBEX in the future. ZEBEX will not hold for any
responsibilities for damages occurred during delivery if a non-approved
package material is used.
ZEBEX INDUSTRIES INC. All Rights Reserved. 2

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Understanding the scanner parts and functions
Z-3070 Series Scanner Parts
Parts Functions
Handle Ergonomically designed for easy holding the
Scanner.
Trigger For triggering the scanner
Exit Window For light exit and engine protection.
When power is on, the LED is RED.
LED Indicator A barcode is successfully decoded when the
LED indicates GREEN.
Buzzer The buzzer sounds when a barcode is
successfully decoded.
Cable interface port For cable connecting.
ZEBEX INDUSTRIES INC. All Rights Reserved. 3

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Installing the Cable
Plug the interface cable modular connector into the cable interface port
on the bottom of Z-3070 Series handle, and twist the SR lock to the right
to lock as shown:
Different cables are required for different host. To change the scanner
cable:
1. Turn the SR lock counter-clockwise to unlock.
2. Pull the cable out of the cable interface port on the bottom of the
scanner handle.
3. Plug a new cable into the cable interface port, and twist the SR lock
to the right.
ZEBEX INDUSTRIES INC. All Rights Reserved. 4

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Power Connection
If your host does not provide power to the scanner, you will need an
external power connection to the scanner:
1. Connect the interface cable to the bottom of the scanner, as
described in Installing the Cable.
2. Connect the other end of the interface cable to the host (refer to
your host manual to locate for correct port).
3. Connect the right-angle connector of power supply into the power
jack on the interface cable. Plug the other end of the power supply
into an AC outlet.
ZEBEX INDUSTRIES INC. All Rights Reserved. 5

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Connecting the scanner to a host
The Z-3070 Series scanner supports RS-232C, keyboard Emulation,
Wand Emulation, and USB interface to a host system. This section
describes how to set up each of these connections.
RS-232C Connection
This connection is made either through RS-232C interface cable with D
type 9 Pin connector or through a RS-232C interface cable with D type 25
Pin connector to the serial port on the host.
1. Connect the RS-232C interface cable to the bottom of the scanner, as
described in Installing the interface Cable.
2. Connect the other end of the interface cable to the serial port on the
host.
3. Connect the power supply.
RS-232C Connection with D type 9 Pin connector
RS-232C Connection with D type 25 Pin connector
ZEBEX INDUSTRIES INC. All Rights Reserved. 6

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Keyboard Emulation Connection
When configured for Keyboard Emulation input, the host accepts input
from the scanner as keystrokes. The Z-3070 Series Scanner can perform
Keyboard Emulation input using a keyboard interface cable and a male to
female connecting cable.
Keyboard Emulation Connection
1. Connect the Keyboard Emulation interface cable to the bottom of the
scanner, as described in Installing the interface Cable.
2. Connect the male end of the keyboard cable into the female end of
the interface cable.
3. Connect the female end of male-to-female connecting cable into the
male end of the interface cable.
4. Connect the male end of male-to-female connecting cable into the
keyboard port on the host
Wand Emulation Connection
To perform Wand Emulation, the scanner can be connected to a portable
data terminal, or a controller that collects the data as wand data, and
interprets it for the host.
1. Connect the Wand Emulation interface cable to the bottom of the
scanner, as described in Installing the Interface Cable.
2. Connect the other end of the interface cable into the COM port on the
PDT or controller.
3. Plug one end of the power supply cable into the power receptacle on
the interface cable. Plug the other end of the power supply cable into a
wall outlet.
ZEBEX INDUSTRIES INC. All Rights Reserved. 7

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
USB Connection
This connection is made through USB interface cable to the USB port on
the host.
1. Connect the USB interface cable to the bottom of the scanner, as
described in Installing the interface Cable.
2. Connect the other end of the interface cable into the USB port on the
host.
ZEBEX INDUSTRIES INC. All Rights Reserved. 8

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Getting Ready to Scan
With Z-3070
ZEBEX INDUSTRIES INC. All Rights Reserved. 9

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Introduction
This chapter covers some tips about scanning.
Scanning with the Z-3070
1. Ensure all connections are secure and power is on, the LED is
indicating in RED as standby position, and the symbol you want to
scan is within the scanning range.
2. Aim the scanner at the barcode. If your scanner works in trigger mode,
aim and press the trigger.
3. Ensure the scan line crosses every bar and space of the symbol.
4. Upon successful decode, the scanner beeps and the LED indicates
GREEN.
Aiming
Do not hold the scanner directly over the barcode. Scanning light
reflecting directly back into the scanner from the barcode is known as
specular reflection which can make decoding difficult. The area where
specular reflection occurs is known as a “dead zone”.
You can tilt the scanner up to 65° forward or backward and achieve a
successful decode. Simply practice quickly to find what tolerances to
work within.
ZEBEX INDUSTRIES INC. All Rights Reserved. 10

OUTLINE FOR PRODUCT REFERANCE MANUAL
Z-3070 CCD BARCODE SCANNER
Scanning mode
Z-3070/DC and Z-3070/EC supports 4 scanning option, but Z-3070/LR
and Z-3070/WA supports 2 scanning option.
Refer to Programming and Setting for the specific barcode programming
information. When power is on for the first time, Z-3070 Series Scanner
is working in default scanning mode. You may change it to the appropriate
mode.
ZEBEX INDUSTRIES INC. All Rights Reserved. 11
