Zebex ZB- 800 SERIES User manual

ZBX98070101
P/N : MUL-53215-01

USER'S MANUAL
ZB- 800
SERIES
The manual can be used as
keyboard emulation, RS- 232C
serial interface, and CMOS serial
interface.
IMPORTANT NOTICE
ZEBEX INDUSTRIES INC. MAKES NO
WARRANTY WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
ZEBEX INDUSTRIES INC. SHALL NOT BE
LIABLE FOR ERRORS CONTAINED HEREIN OR
FOR INCIDENTAL CONSEQUENTIAL DAMAGES
IN CONNECTION WITH THE FURNISHING,
PERFORMANCE, OR USE OF THIS MATERIALS.
Copyright 1995 by
ZEBEX INDUSTRIES INC.
IBM is a registered trade mark of International Business Machines
Corp.
IBM PC/XT is a product of International Business Machines Corp.
IBM PC/AT is a product of International Business Machines Corp.
IBM PS/2 is a product of International Business Machines Corp.
NEC is a registered trade mark of NEC Corporation.
All other registered trade marks are registered companys'
property.
ZEBEX is a registered trade mark of ZEBEX INDUSTRIES INC.
All rights reserved, reproduction of this document or any
portion of its contents is not allowed without the specific
written consent of ZEBEX INDUSTRIES INC.
Every effort is made to ensure the accuracy of our
product information; however, we accept no responsibility
for errors or omission. Specification or version may be
subject to change without notice. The actual
specification and version are based on the product
delivered.
PRINTED IN DECEMBER 1995

USER'S MANUAL
The manual can be used as
keyboard emulation, RS- 232C
serial interface, and CMOS serial
interface.
IMPORTANT NOTICE
Every effort is made to ensure the
accuracy of our product information;
however, we accept no
responsibility for errors or omission.
Specification or version may be
subject to change without notice.
The actual specification and version
are based on the product delivered.
PRINTED IN DECEMBER 1995

TABLE OF CONTENTS
Introduction....................................................1
Default Parameters.........................................2
Program Procedure ........................................5
System Setting...............................................6
Header And Trailer.........................................7
Inter- Message Delay......................................7
Inter- Character Delay ....................................7
Message/ Block Mode Selection .....................8
Beeper Tone Selection ...................................8
Bar Code ID Selection....................................9
RS- 232C Serial Communication Parameters
Setting .......................................................10
Handshaking Protocol...........................10
ACK/ NAK Response Time Setting........10
Baud Rate............................................11
Data Bit................................................11
Stop Bit................................................12
Parity Setting........................................12
Message Terminator.............................12
Keyboard Emulation Parameters Setting.......13
Keyboard Type Selection......................13
Language Selection..............................14
Message Terminator.............................15
Reading Code Selection...............................15
Code 39 Parametrs Setting...........................17
Interleaved 2 Of 5 Parameters Setting...........18
SLZ 2 Of 5 Parameters Setting .....................18
UPC/ EAN/ JAN Parameters Setting .............19
Codabar/ Monarch Parameters Setting..........22
Code 128 Parameters Setting.......................23
ISBN/ ISSN Conversion................................23
Appendix A
Code 39 Full ASCII Code Table ....................24
Appendix B
Code 39 Full ASCII Bar Code TAble..............26

1. INTRODUCTION
The series Bar Code Wand scanners can be
configured by scanning a series of programming
bar code labels. This allows decoding options and
interface protocols to be tailored to a specific
application. The configuration is stored in non-
volatile memory and will not be lost by removing
power from the scanner.
The scanner must be properly powered before
programming. For RS-232C type scanners, an
external power adaptor must be used to supply DC
power to the scanner. If a keyboard emulation
type scanner is used with a IBM PC/XT/AT, PS/2 or
any fully compatible computers, power will be
drawn from the keyboard port. No external power
adaptor is required. If keyboard emulation type
scanner is used with any other non IBM PC
compatible computers, an external power adaptor
may be needed.
During the programming mode, the scanner will
acknowledge a good and valid reading with a short
beep. It will give long beeps for either an invalid
or bad reading.
2. PROGRAMMING OPTIONS
Programmable options are divided into four groups.
The first group includes the options that show the
general behavior of the scanner. The second
group of options governs the operation of RS-232C
type serial ports. The third group selects the
keyboard type that the keyboard emulation type will
be emulated. The last group sets the decoding
parameters for each bar code symbology.
1

3. DEFAULT PARAMETERS
This table gives the default settings of all the
programmable parameters. The default settings
will be restored whenever the "Reset" programming
label is scanned and the scanner is in
programming mode.
DEFAULT VALUES OF OPERATING PARAMETERS
Function Default Values
Header and trailer None
Inter-Message delay Normal
Inter-Character delay Normal
Message/Block mode selection Message
Send command in block mode
communication Disable
Good read beeper tone selection 2KHz/120
mSec
Code identifier transmmiting Disable
Code 39 bar code identifier code M
ITF 2 of 5 bar code identifier code I
SLZ 2 of 5 bar code identifier code H
UPC-E bar code identifier code E
UPC-A bar code identifier code E
EAN-13 bar code identifier code F
EAN-8 bar code identifier code FF
Codabar bar code identifier code N
Code 128 bar code identifier code K
Code 93 bar code identifier code L
MSI bar code identifier code P
2
DEFAULT VALUES OF KEYBOARD EMULATION
PARAMETERS SETTING
Function Default Values
Keyboard type selection IBM PC/AT USA
Message terminator Enter/ Carriage
Return
DEFAULT VALUES OF RS-232C SERIAL
COMMUNICATION PARAMETERS
Function Default Values
Handshaking protocol None
ACK/NAK response
time setting 300 msec
Baud rate 9600
Data bit 8
Stop bit 1
Parity Mark (None)
Message terminator
selection CR/LF
3

DEFAULT VALUES OF DECODING
PARAMETERS
Function Default Value
Code 39 Enable
ITF 2 of 5 Enable
SLZ 2 of 5 Disable
UPC/EAN/JAN Enable
Codabar Enable
Reading Codes¡°MSI Disable
Selection Code 128 Enable
Code 93 Enable
¡°ITAT Disable
¡° Italian Pharmac Disable
ISSN/ ISBN Disable
Codes Standard
Code 39 Start/stop characters Not transmitting
Check digit Disable
Interleaved Length 10 digits Fixed
2 of 5 Check Digit Disable
SLZ 2 of 5 Length Variable
Check Digit Disable
Format All
Addendum Disable
UPC-E=UPC-A Disable
UPC-A= EAN-13 Disable
UPC/EAN/JAN UPC-A Leading Digit Transmit
UPC-A Check Digit Transmit
UPC-E Leading Digit Transmit
UPC-E Check Digit Transmit
EAN-13 Check Digit Transmit
EAN-8 Check Digit Transmit
Type Standard
Codabar Start/ Stop
Characters A,B,C,D
Code 128 FNC 2 Append Disable
Check Digit Calculate but not
Transmit
MSI Length Variable
Check digit Transmit
Italian Pharmac Transmit "A"
Character Not transmitting
Note: The configuration of the items with
asterisk (¡°)is optional.
4. PROGRAM PROCEDURE USING BAR CODE
MENUS
START
Read Start of
Configuration Label
Set All
Defaults Set
Operating
Parameters
Set
Serial Port
Parameters
Set
Keyboard
Type
Set
Decoding
Parameters
No No
Finish Discard
Yes Yes
Read End of
configuration
label
Read Abort
Label
END
5

Start of Configuration
•The reading of the "RESET " label turns all the
parameters back to default values.
•When you intend to turn your scanner back to
default parameter, please scan the "Start of
configuration" label first, then scan "RESET"
label and finally scan the "End of configuration"
label.
RESET
•The reading of the "ABORT" label discards all
the parameters read prior to the "End of
configuration".
ABORT
•The lable below must be read to enter into
serial interface for ZB- 800R or ZB- 800C when
the wand is configured the first time.
RS-232C
•The lable below must be read to enter into
serial interface for ZB- 800K when the wand is
configured the first time.
PC/ AT
6
HEADER AND TRAILER
Header
Set
Trailer
INTER-MESSAGE DELAY
None
500 mSec
100 mSec
1 Second
INTER-CHARACTER DELAY
None
20 mSec
10 mSec
50 mSec
End of Configuration
7

Start of Configuration
MESSAGE/BLOCK MODE SELECTION
Message
Block
SEND COMMAND IN BLOCK MODE
COMMUNICATION
Enable
Disable
Store
Set
GOOD READ BEEPER TONE SELECTION
2KHz/ 120 mSec
2 KHz/ 200 mSec
1 KHz/ 120 mSec
1 KHz/ 200 mSec
8
Disable
BAR CODE IDENTIFIER CODE SELECTION
Enable
Disable
BAR CODE IDENTIFIER CODE SETTING
UPC- E
EAN- 13
SLZ 2 OF 5
Codabar
UPC- A
EAN- 8
ITF 2 OF 5
Code 39
End of Configuration
9

Start of Configuration
BAR CODE IDENTIFIER CODE SETTING (Cont' d)
Code 128
MSI
Code 93
Set
RS-232C SERIAL COMMUNICATION
PARAMETERS SETTING
HANDSHAKING PROTOCOL
None
RTS/ CTS
ACK/ NAK
Xon/ Xoff
ACK/NAK RESPONSE TIME SETTING
300 mSec
2 Sec
10
500 mSec
1 Sec
3 Sec
5 Sec
BAUD RATE
19200
9600
4800
1200
2400
600
DATA BIT
7
8
End of Configuration
11

Start of Configuration
STOP BIT
1
2
PARITY
Even
Odd
Mark (None)
Space
MESSAGE TERMINATOR (FOR RS-232C TYPE
ONLY)
None
CR/ LF
CR
LF
12
Hor. Tab
EOT
STX/ ETX
KEYBOARD EMULATION PARAMETERS
SETTING
KEYBOARD TYPE SELECTION
IBM AT
IBM 5550
IBM XT
IBM 5530-SC
NEC 9801
PS/ 2 55
IBM 5295 Terminal
IBM 3477/ 3472
Terminal
IBM 5530-ZC
End of Configuration
13

Start of Configuration
KEYBOARD TYPE SELECTION (Cont' d
¡^
IBM 3196 Terminal
PS2/ 30
APPLE MAC II (¡°)
Note: The configuration of the items with asterisk
(¡°) is optional.
KEYBOARD LANGUAGE SELECTION
USA
Germany
Spainish
UK
French
Italian
Swiss
Swedish
14
MESSAGE TERMINATOR (FOR KEYBOARD
WEDGE USE)
None
Return
Hor. TAB
READING CODE SELECTION
Code 39 Enable
Code 39 Disable
Codabar Enable
Codabar Disable
UPC/ EAN/ JAN Enable
UPC/ EAN/ JAN Disable
End of Configuration
15

Start of Configuration
READING CODE SELECTION (Cont' d)
ITF 2 of 5 Enable
ITF 2 of 5 Disable
SLZ 2 of 5 Enable
SLZ 2 of 5 Disable
Code 128 Enable
MSI Enable
Code 128 Disable
MSI Disable
Code 93 Enable
IATA Enable
Code 93 Disable
16
IATA Disable
Italian Pharmac Enable
Italian Pharmac Disable
CODE 39 PARAMETERS SETTING
CHARACTER SET
Standard Code 39
Full ASCII Code 39
START/STOP CHARACTER TRANSMISSION
Yes
No
CHECK DIGIT
Calculate and Transmit
Calculate but not
Transmit
No
End of Configuration
17

Start of Configuration
INTERLEAVED 2 OF 5 PARAMETERS SETTING
LENTGTH
Variable
Fixed
Set CHECK DIGIT
No
Calculate and Transmit
Calculate but not Transmit
SLZ 2 OF 5 PARAMETERS SETTING
LENGTH
Variable
Fixed
Set
18
CHECK DIGIT
No
Calculate and Transmit
Calculate but not Transmit
UPC/ EAN/ JAN PARAMETERS SETTING
FORMAT
All
UPC-A and EAN-13
UPC-A
EAN-8 and EAN-13
UPC-A and UPC-E
UPC-E
EAN-13
EAN-8
End of Configuration
19

Start of Configuration
UPC/ EAN/ JAN PARAMETERS SETTING(Cont' d)
ADDENDUM
No
5 Characters
2 Characters
2 or 5 Characters
FORCE UPC-E TO UPC-A FORMAT
Yes
No
FORCE UPC-A TO EAN-13 FORMAT
Yes
No
20
TRANSMIT UPC-A LEADING CHARACTER
Yes
No
TRANSMIT UPC-A CHECK DIGIT
Yes
No
TRANSMIT UPC-E LEADING CHARACTER
Yes
No
TRANSMIT UPC-E CHECK DIGIT
Yes
No
End of Configuration
21

Start of Configuration
UPC/ EAN/ JAN PARAMETERS SETTING Cont'd)
TRANSMIT EAN-13 CHECK DIGIT
Yes
No
TRANSMIT EAN-8 CHECK DIGIT
Yes
No
CODABAR/ MONARCH PARAMETERS SETTING
START/ STOP CHARACTER TRANSMISSION
No
A, B, C, D
DC1 ~DC4
a/ t, b/ n, c/ *, d/ e
22
CODE 128 PARAMETERS SETTING
FNC 2 CONCATENATION
Enable
Disable
CHECK DIGIT
No
Calculate and Transmit
Calculate but not Transmitt
ISBN/ ISSN CONVERSION
ACTIVE ISBN/ ISSN
INACTIVE ISBN/ ISSN
End of Configuration
23

APPENDIX A
CODE 39 FULL ASCII CODE TABLE
ASCII CODE
39 VALEU
R
HEXA.
ASCII CODE
39 VALEU
R
HEXA.
NUL %U 00 %/E 25
SOH $A 01 &/F 26
STX $B 02 '/G 27
ETX $C 03 (/H 28
EOT $D 04 )/I 29
ENQ $E 05 * /J 2A
ACK $F 06 +/K 2B
BEL $G 07 ,/L 2C
BS $H 08 - - 2D
HT $I 09 . . 2E
LF $J 0A / / 2F
VT $K 0B 0 0 30
FF $L 0C 1 1 31
CR $M 0D 2 2 32
SO $N 0E 3 3 33
SI $O 0F 4 4 34
DLE $P 10 5 5 35
DC1 $Q 11 6 6 36
DC2 $R 12 7 7 37
DC3 $S 13 8 8 38
DC4 $T 14 9 9 39
NAK $U 15 :/Z 3A
SYN $V 16 ;%F 3B
ETB $W 17 <%G 3C
CAN $X 18 =%H 3D
EM $Y 19 >%I 3E
SUB $Z 1A ?%J 3F
ESC %A 1B @%V 40
FS %B 1C A A 41
GS %C 1D B B 42
RS %D 1E C C 43
US %E 1F D D 44
SP SP 20 E E 45
!/A 21 FF46
"/B 22 G G 47
#/C 23 H H 48
$/D 24 I I 49
24
APPENDIX A
CODE 39 FULL ASCII CODE TABLE
ASCII CODE
39 VALEU
R
HEXA.
ASCII CODE
39 VALEUR
HEXA.
J J 4A e+E 65
K K 4B f+F 66
L L 4C g+G 67
M M 4D h+H 68
N N 4E i+I 69
O O 4F j+J 6A
P P 50 k+K 6B
Q Q 51 l+L 6C
R R 52 m+M 6D
S S 53 n +N 6E
T T 54 o+O 6F
U U 55 p +P 70
V V 56 q +Q 71
W W 57 r+R 72
X X 58 s+S 73
Y Y 59 t+T 74
ZZ5A u+U 75
[ %K 5B v+V 76
\%L 5C w+W 77
]%M 5D x+X 78
^%N 5E y+Y 79
_%O 5F z+Z 7A
`%W 60 {%P 7B
a+A 61 |%Q 7C
b+B 62 }%R 7D
c+C 63 ~%S 7E
d+D 64 DEL %T 7F
25

APPENDIX B
CODE 39 FULL ASCII BAR CODE TABLE
Start of Configuration
NUL
ENQ
LF
SOH
ACK
VT
STX
BEL
FF
ETX
BS
CR
EOT
HT
SO
26
APPENDIX B
CODE 39 FULL ASCII BAR CODE TABLE
SI
DC4
EM
DLE
NAK
SUB
DC1
SYN
ESC
DC2
ETB
FS
DC3
CAN
GS
End of Configuration
27

APPENDIX B
CODE 39 FULL ASCII BAR CODE TABLE
Start of Configuration
RS
#
(
US
$
)
SP
%
*
!
&
+
"
'
,
28
APPENDIX B
CODE 39 FULL ASCII BAR CODE TABLE
-
2
7
.
3
8
/
4
9
0
5
:
1
6
;
End of Configuration
29

APPENDIX B
CODE 39 FULL ASCII BAR CODE TABLE
Start of Configuration
<
A
F
=
B
G
>
C
H
?
D
I
@
E
J
30
APPENDIX B
CODE 39 FULL ASCII BAR CODE TABLE
K
P
U
L
Q
V
M
R
W
N
S
X
O
T
Y
End of Configuration
31
Table of contents
Other Zebex Barcode Reader manuals

Zebex
Zebex Z-3192BT User manual

Zebex
Zebex z-3101 Operating instructions

Zebex
Zebex Z-3070/DC User manual

Zebex
Zebex Z-3052 User manual

Zebex
Zebex Z-3272 Plus User manual

Zebex
Zebex Z-325x User manual

Zebex
Zebex z3190BT User manual

Zebex
Zebex Z-3100 User manual

Zebex
Zebex Z-8072 User manual

Zebex
Zebex Z-3130BT User manual

Zebex
Zebex z-3101 Operating instructions

Zebex
Zebex Z-6182 User manual

Zebex
Zebex Z-5130 User manual

Zebex
Zebex Z-3392BT User manual

Zebex
Zebex Z-5652 Plus User manual

Zebex
Zebex ZB-2200AM SERIES User manual

Zebex
Zebex Z-3070 Series User manual

Zebex
Zebex A-50M+ User manual

Zebex
Zebex Z-325x User manual

Zebex
Zebex Z-3191BT User manual
