Zempire TITAN CANVAS Series Configuration guide
PITCHING INSTRUCTIONS
CARE INSTRUCTIONS
1. Ensure guy ropes are out at all times during use.
2. Never pack your tent away wet. If you must take your tent down when wet, ensure that it is
dried completely as soon as possible to prevent mildew forming.
3. If mildew does form on your tent, wash off with warm water and a soft brush to prevent further
growth, do not use soap or detergents.
4. Do not use an open flame inside your tent. The fabric has been treated with a fire retardant but
is in no way fire-proof.
5. Clean all pegs and poles before storing.
6. This tent is not designed to withstand storm conditions. During strong winds, it is
recommended that the tent be taken down.
7. Do not leave your tent pitched unnecessarily for extended periods of time. UV light damages
the fly and will shorten the life of your tent.
Get out more – you owe it to yourself!
WARRANTY & CARE
5 Year Tent Guarantee
Please take time to read about the protection we offer you.
All our tents come with a guarantee designed to protect you as our valued customer. Flow
Imports Ltd., the makers of ZEMPIRE®Camping Equipment tents, will repair or replace this tent,
at their discretion, should it fail due to faulty materials or manufacture for a period of 5 years from
the date of sale.
The Guarantee is subject to the following conditions:
1. The Guarantee only applies to an original purchaser who purchased this tent from an approved
retail outlet.
2. The Guarantee does not apply if the tent has been used for anything other than reasonable
personal camping use. Commercial use (e.g. rental) or continuous use as a residence are
expressly excluded.
3. Damage due to normal wear and tear, accident, acts of God, negligence (other than by Flow
Imports Ltd.), failure by the purchaser to ensure instructions for setting up and care are
observed, deterioration due to abnormal exposure to ultraviolet light, insect or mildew attack,
or any other cause reasonably beyond the control of Flow Imports Ltd. are not covered.
4. If redress is sought under the terms of this Guarantee, then the tent must be returned by the
purchaser to the outlet from where it was purchased within the Guarantee period, in a clean,
dry state and with proof of purchase.
5. All transport costs and any other indirect costs are excluded from the Guarantee.
6. Flow Imports Ltd. reserves the right to make a reasonable charge for repairs which it
determines are not within the scope of the Guarantee.
7. The Guarantee does not limit, modify or exclude any rights under any law if doing so would
contravene that law or make any part of this Guarantee invalid. However, Flow Imports Ltd.:
a) excludes (to the extent permitted by applicable law) all conditions and warranties that might
otherwise be implied; and
b) limits its liability for breach of any such condition or Guarantee that it cannot exclude
together with its liability under the Guarantee, to repairing or replacing the goods or paying
the cost of having the goods repaired or replaced (at Flow Imports’ option).
This tent has been made with meticulous care and attention to detail. Providing it’s properly
looked after and correctly stored, it will help you enjoy all that nature has to offer for years to
come.
WWW.ZEMPIRECAMPING.COM
For a detailed description of all the features and specifications
of this product please visit our website.
Designed and tested in New Zealand. Made with care in China.
POLE DIAGRAM – TITAN
PACKING AWAY YOUR TENT
1. Open up all windows and close all
doors.
2. Remove the RED awning poles.
3. Remove the YELLOW Support poles.
4. Remove the BLACK ridge poles.
5. Remove the BLUE & GREEN eve poles.
6. Remove all pegs, clean and place in
peg bag.
7. Lay the tent as flat as possible and fold
the awning over the body of the tent.
8. Fold both sides into the centre of the
tent.
9. Fold in half. Ensure the width is the
same as the length of your carry bag.
Adjust if necessary.
10. Expel as much air as possible by
walking down the tent towards the
door.
11. Roll the tent from the rear towards
the door. Ensure that you wipe off any
condensation and dirt as you roll.
POLE CHART
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3, R4
Line 2 - R5, R6,
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
Line 4 - RC, RD
LH Eve Pole (GREEN)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
Support Pole (YELLOW)
Line 1 - S2, S3, S4
Line 2 - S1
Line 3 - S5
Awning Pole (RED)
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs 32
Witch Hats 7
Pole Feet 3
Guy Rope 4m 2
Guy Rope 3m 4
POLE CHART & PACK DOWN
POLE DIAGRAM - SHERATON 25) Guy out the front awning by
attaching the short guy ropes over top of
awning pole spikes. Line up the guy rope
with the pole spkie and the top ridgepole
spike (indicated by the Line). Ensure
the guy rope is at a 45oangle and pegs
are also inserted at a 45oangle.
A3
A4
A3
A4
27) Peg out front valance. the bottom of
the valance should sit level with the
ground. The outside of the valance
should align with the outside of the tent.
The inside of the valance should be
vertical.
26) Insert the longer RED A3/A4
pole into centre of the side of the
awning. Guy out at a 45oangle with the
longer guy rope sections.
45o
45o
90o
28) Place rubber pole feet under support
pole (BLACK RA & RC)
CARING FOR YOUR TENT
- Never store your tent wet.
- If you must pack your tent down while
still wet, hang to dry as soon as possible
to prevent mildew damage.
- Remove dirt, tree sap, and bird
droppings with a soft brush and warm
water before packing down.
- Do not use detergents to clean your
tent. This will damage the waterproong
of the tent fabric.
- When rolling up your tent ensure there
is no condensation on the oor.
- It is not advisable to re-coat your canvas
as a precautionary measure. This will
reduce the breathability and duarbilty of
your tent. Freedom Canvases are pre
coated and will stay waterproof and
breathable for many years.
- When Storing your tent over the winter,
do not store directly on concrete oors.
- If you do get mildew forming on your
tent, remove the pours with warm water
and a soft brush to prevent further
growth.
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
R2
R5
EB
EA
E1
E2
E3
EA
EB
E1
EB
EA
R3
R4
E2
E3
RB
RA
EA
EB
A1
A2
A3
A4
A3
A4
RC
S2
S4
S5
S1
E4
E4
R6
R1
A2
A1
RD
E5
E5
S3
RB
RA
RB
RA
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
PITCHING & CARE INSTRUCTIONS
PACKING AWAY YOUR TENT
1) Open up all windows and close all
doors.
2) Remove the RED awning poles
3) Remove the YELLOW Support
poles.
4) Remove the BLACK Ridge poles.
5) Remove the BLUE & GREEN Eve
poles.
6) Remove all pegs, clean and place in
peg bag.
7) Lay tent as at as possible and fold the
awning over main body of the tent.
8) Fold both sides into the centre of the
tent
9) Fold in half. Ensure the width is the
same as the length of your carry bag.
Adjust if necessary.
10) Expel as much air as possible by
walking down the tent towards the door
11) Roll the tent from the rear towards
the door. Ensure that you wipe o any
condensation and dirt as you roll.
DOOR
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1. Ensure guy ropes are pegged out at all times during use
2. Never pack your tent away wet. If you must take your tent down
when wet, ensure that you dry your tent completely as soon as possible
to prevent mildew forming.
3. If mildew does form on your tent wash off with warm water and a
soft brush to prevent further growth. Do not use detergents.
4. Do not use an open flame inside your tent. The fabric has been
treated with a fire retardant but is in no way fire proof
5. Clean all pegs and poles before storing
6. This tent is not designed to withstand storm conditions. During
strong winds, it is recommended that the tent be taken down
7. Do not leave your tent pitched unnecessarily for extended periods of
time. UV light damages the fly fabric and will shorten the life of your
tent
Flow Imports Ltd General Warranty
Subject to the exclusions and limitations set out below, Flow Imports
Ltd will repair or replace (at its choice) merchandise supplied by Flow
Imports Ltd ( Goods) which fail due to faulty materials and manufacture
during the warranty period.
The following exclusions and limitations apply to the Warranty:
The Warranty does not apply except to an original purchaser who
purchased Goods new from a retail outlet.
The Warranty does not apply if:
(a) a different product specific warranty is provided by Flow Imports ltd;
or
(b) the Goods are not made by Flow Imports Ltd and an express
warranty is provided by the maker of the Goods
The Warranty does not apply if the Goods have been used other than
for reasonable personal camping use. Use in a commercial context
( e.g. for rental or use by a commercial organization in its business
operations ) or continuous use in a domestic context are expressly
excluded.
Damage due to reasonable wear and tear, accident, acts of God,
negligence ( other than by Flow Imports Ltd), failure by the purchaser to
ensure instructions for use and care are observed, deterioration due to
abnormal exposure to the elements, insect or mildew attack, or any
other cause reasonably beyond the control of Flow Imports Ltd are all
excluded.
Goods must be returned by the purchaser to the outlet from where
they were purchased within the Warranty period, in a clean state with
proof of purchase. All transport cost and any other indirect costs are
excluded from the Warranty.
Flow imports Ltd reserves the right to make a reasonable charge for
repairs which it determines are not within the scope of the Warranty.
The Warranty does not limit, modify or exclude any rights under any law
if to do so would contravene that law or make any part of this Warranty
invalid. However, Flow Imports:
(a) Excludes (to the extent permitted by applicable law) all conditions
and warranties that might otherwise be implied; and
(b) Limits its liability for breach of any such condition or warranty that it
cannot exclude together with its liability under Warranty, to repairing or
replacing the Goods or paying the cost of having the Goods repaired or
replace ( at Flow Imports’ option).
This tent design is under copyright protection by Flow imports Ltd. The
Zempire Logo and related Campfire mark are registered trademarks of
Flow imports Ltd, New Zealand. Any reproduction of this manual is
prohibited without prior consent by Flow imports Ltd
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
PITCHING & CARE INSTRUCTIONS
PACKING AWAY YOUR TENT
1) Open up all windows and close all
doors.
2) Remove the RED awning poles
3) Remove the YELLOW Support
poles.
4) Remove the BLACK Ridge poles.
5) Remove the BLUE & GREEN Eve
poles.
6) Remove all pegs, clean and place in
peg bag.
7) Lay tent as at as possible and fold the
awning over main body of the tent.
8) Fold both sides into the centre of the
tent
9) Fold in half. Ensure the width is the
same as the length of your carry bag.
Adjust if necessary.
10) Expel as much air as possible by
walking down the tent towards the door
11) Roll the tent from the rear towards
the door. Ensure that you wipe o any
condensation and dirt as you roll.
DOOR
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1. Ensure guy ropes are pegged out at all times during use
2. Never pack your tent away wet. If you must take your tent down
when wet, ensure that you dry your tent completely as soon as possible
to prevent mildew forming.
3. If mildew does form on your tent wash off with warm water and a
soft brush to prevent further growth. Do not use detergents.
4. Do not use an open flame inside your tent. The fabric has been
treated with a fire retardant but is in no way fire proof
5. Clean all pegs and poles before storing
6. This tent is not designed to withstand storm conditions. During
strong winds, it is recommended that the tent be taken down
7. Do not leave your tent pitched unnecessarily for extended periods of
time. UV light damages the fly fabric and will shorten the life of your
tent
Flow Imports Ltd General Warranty
Subject to the exclusions and limitations set out below, Flow Imports
Ltd will repair or replace (at its choice) merchandise supplied by Flow
Imports Ltd ( Goods) which fail due to faulty materials and manufacture
during the warranty period.
The following exclusions and limitations apply to the Warranty:
The Warranty does not apply except to an original purchaser who
purchased Goods new from a retail outlet.
The Warranty does not apply if:
(a) a different product specific warranty is provided by Flow Imports ltd;
or
(b) the Goods are not made by Flow Imports Ltd and an express
warranty is provided by the maker of the Goods
The Warranty does not apply if the Goods have been used other than
for reasonable personal camping use. Use in a commercial context
( e.g. for rental or use by a commercial organization in its business
operations ) or continuous use in a domestic context are expressly
excluded.
Damage due to reasonable wear and tear, accident, acts of God,
negligence ( other than by Flow Imports Ltd), failure by the purchaser to
ensure instructions for use and care are observed, deterioration due to
abnormal exposure to the elements, insect or mildew attack, or any
other cause reasonably beyond the control of Flow Imports Ltd are all
excluded.
Goods must be returned by the purchaser to the outlet from where
they were purchased within the Warranty period, in a clean state with
proof of purchase. All transport cost and any other indirect costs are
excluded from the Warranty.
Flow imports Ltd reserves the right to make a reasonable charge for
repairs which it determines are not within the scope of the Warranty.
The Warranty does not limit, modify or exclude any rights under any law
if to do so would contravene that law or make any part of this Warranty
invalid. However, Flow Imports:
(a) Excludes (to the extent permitted by applicable law) all conditions
and warranties that might otherwise be implied; and
(b) Limits its liability for breach of any such condition or warranty that it
cannot exclude together with its liability under Warranty, to repairing or
replacing the Goods or paying the cost of having the Goods repaired or
replace ( at Flow Imports’ option).
This tent design is under copyright protection by Flow imports Ltd. The
Zempire Logo and related Campfire mark are registered trademarks of
Flow imports Ltd, New Zealand. Any reproduction of this manual is
prohibited without prior consent by Flow imports Ltd
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
PITCHING & CARE INSTRUCTIONS
PACKING AWAY YOUR TENT
1) Open up all windows and close all
doors.
2) Remove the RED awning poles
3) Remove the YELLOW Support
poles.
4) Remove the BLACK Ridge poles.
5) Remove the BLUE & GREEN Eve
poles.
6) Remove all pegs, clean and place in
peg bag.
7) Lay tent as at as possible and fold the
awning over main body of the tent.
8) Fold both sides into the centre of the
tent
9) Fold in half. Ensure the width is the
same as the length of your carry bag.
Adjust if necessary.
10) Expel as much air as possible by
walking down the tent towards the door
11) Roll the tent from the rear towards
the door. Ensure that you wipe o any
condensation and dirt as you roll.
DOOR
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1. Ensure guy ropes are pegged out at all times during use
2. Never pack your tent away wet. If you must take your tent down
when wet, ensure that you dry your tent completely as soon as possible
to prevent mildew forming.
3. If mildew does form on your tent wash off with warm water and a
soft brush to prevent further growth. Do not use detergents.
4. Do not use an open flame inside your tent. The fabric has been
treated with a fire retardant but is in no way fire proof
5. Clean all pegs and poles before storing
6. This tent is not designed to withstand storm conditions. During
strong winds, it is recommended that the tent be taken down
7. Do not leave your tent pitched unnecessarily for extended periods of
time. UV light damages the fly fabric and will shorten the life of your
tent
Flow Imports Ltd General Warranty
Subject to the exclusions and limitations set out below, Flow Imports
Ltd will repair or replace (at its choice) merchandise supplied by Flow
Imports Ltd ( Goods) which fail due to faulty materials and manufacture
during the warranty period.
The following exclusions and limitations apply to the Warranty:
The Warranty does not apply except to an original purchaser who
purchased Goods new from a retail outlet.
The Warranty does not apply if:
(a) a different product specific warranty is provided by Flow Imports ltd;
or
(b) the Goods are not made by Flow Imports Ltd and an express
warranty is provided by the maker of the Goods
The Warranty does not apply if the Goods have been used other than
for reasonable personal camping use. Use in a commercial context
( e.g. for rental or use by a commercial organization in its business
operations ) or continuous use in a domestic context are expressly
excluded.
Damage due to reasonable wear and tear, accident, acts of God,
negligence ( other than by Flow Imports Ltd), failure by the purchaser to
ensure instructions for use and care are observed, deterioration due to
abnormal exposure to the elements, insect or mildew attack, or any
other cause reasonably beyond the control of Flow Imports Ltd are all
excluded.
Goods must be returned by the purchaser to the outlet from where
they were purchased within the Warranty period, in a clean state with
proof of purchase. All transport cost and any other indirect costs are
excluded from the Warranty.
Flow imports Ltd reserves the right to make a reasonable charge for
repairs which it determines are not within the scope of the Warranty.
The Warranty does not limit, modify or exclude any rights under any law
if to do so would contravene that law or make any part of this Warranty
invalid. However, Flow Imports:
(a) Excludes (to the extent permitted by applicable law) all conditions
and warranties that might otherwise be implied; and
(b) Limits its liability for breach of any such condition or warranty that it
cannot exclude together with its liability under Warranty, to repairing or
replacing the Goods or paying the cost of having the Goods repaired or
replace ( at Flow Imports’ option).
This tent design is under copyright protection by Flow imports Ltd. The
Zempire Logo and related Campfire mark are registered trademarks of
Flow imports Ltd, New Zealand. Any reproduction of this manual is
prohibited without prior consent by Flow imports Ltd
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
PITCHING INSTRUCTIONS
1. Clear your site making sure there are
no sharp objects. Try to choose a site
that is flat and clear.
2. Sort the poles into their matching
colour. Once sorted, connect each
colour pole section as per the pole
chart on the previous page.
3. Spread your tent out with floor facing
down. The front is the end with the
large awning roof attached.
4. Peg out the four corners of the tent
pulling the floor as tightly as possible.
(Pegs should be at a 45oangle away
from the tent for greatest hold.) To
ensure the floor sits flat it may be easier
to peg in the following sequence.
5. Peg out the remaining peg points to
ensure the floor sits flat.
6. Open all doors and windows. This
allows air to enter the tent and makes
pitching easier.
7. Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the black webbing loop
before threading through the pole
sleeve. Then, hook the black webbing
loop behind the button pin on the pole.
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
8. At the front of the tent, thread the
BLUE E5 pole up through the pole sock
on the side of the front awning from
the inside to the outside. Thread the
pole through the black webbing loop
before inserting into the pole sleeve
and connecting to the E4 pole. Hook
the webbing over the button pin on
the pole.
9. Cover the pole by wrapping the end of
the pole sleeve over the pole sock and
secure with velcro.
10. Repeat steps 7-9 with the GREEN pole.
11. Insert the remaining BLUE EA and EB
poles into the end of each section and
raise the pole so that the outside wall
sits taught. You will need two people
to do this.
12. Repeat with the GREEN EA and EB
poles.
13. Thread the BLACK R1 to R4 ridgeline
poles into the tent through the pole
sock at the top of the front wall and
opening at the top of centre dividing
wall.
14. Insert the BLACK RB/RA pole into the
hole at the end of the R1 pole and then
through the eyelet at the rear of the
roof and extend until the wall sits tight.
Secure the velcro strips on the rear wall.
15. Repeat with the second BLACK RA/RB
pole at the front of the tent. Thread the
RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof
is too tight, move back one hole before
threading through the eyelet in the
roof. Ensure the end of the BLACK R4
pole extends out the pole sock on the
front wall. Secure the velcro strips on
the front wall around the pole.
16. Place white “Witch Hat” washers on the
outside of the tent onto pole spigot of
all RB poles to prevent water running
down during heavy rain.
17. Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK ridge
pole directly behind the centre dividing
wall and extend until the wall is taught.
Secure the velcro strips on the dividing
wall around the pole.
18. Place the YELLOW pole sections S2 to
S4 behind the centre dividing wall.
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
1) Clear your site making sure there are
no sharp objects. Try to choose a site
that is at and clear.
2) Sort the poles into their matching
colour. Once sorted, connect each colour
pole length together as per the pole
chart.
3) Spread your tent out with oor facing
down. The front is the end with the large
awning roof attached.
4) Peg out the four corners of the tent.
Pull the oor as tight as possible. To
ensure the oor sits at it may be easier
to peg in the following Sequence. Pegs
should be at a 45oangle away from the
tent for greatest hold.
7) Thread the BLUE poles (E1 to E4)
through the pole sleeve that runs along
the RHS of the tent. Thread the poles
from the rear of the tent inserting the
pole through the Black webbing loop
before threading through the pole sleeve
and place behind the button pin on the
pole.
EB
EA
EB
EA
E4 E3 E2 E1
E2
E1
E3 E4 E5
9) Cover the pole by wrapping the
end of the pole sleeve over the pole sock
and attach the Velcro.
11) Insert the remaining BLUE EA and
EB poles into the end of each section
and raise the pole so that the outside
wall sits taught. You will need two people
to do this.
5) Peg out the remaining peg points
ensuring the oor sits at.
#1
#2
#3
#4
8) At the front of the tent thread the
BLUE E5 pole up through the pole
sock on the side of the front awning from
the inside to the outside. Thread through
the Black webbing loop before inserting
into the pole sleeve and connecting to
the E4 pole. Pull the webbing over the
button pin on the pole.
6) Open all doors and windows. This
allows air to enter the tent and makes
pitching easier
E5
10) Repeat with the GREEN pole
E4
EA
EA
EB
EB
R1 R2 R3 R4
RA
RB
RC
RD
13) Thread the BLACK R1 to R4 poles
inside the tent by threading through the
pole sock at the top of the Front wall and
opening at the top of centre dividing
wall.
14) Insert the BLACK RB/RA pole
into the hole at the end of the R1 pole
and then through the eyelet at the rear of
the roof and extend until the wall sits
tight. Attach the Velcro strips on the rear
wall.
15) Repeat with the second BLACK
RA/RB pole at the front of the tent. Thread
the RB pole through the outermost of the 3
holes on the BLACK R4 pole. If the roof is
too tight move back one hole before
threading through the eyelet in the roof.
Ensure the end of the BLACK R4 pole
extends out the pocket on the front wall.
Attached the Velcro strips on the front wall
around the pole
17) Connect the C Clip at the top of the
BLACK RC/RD pole to the BLACK
ridge pole directly behind the centre
dividing wall and extend until the wall is
taught. Attach the Velcro strips on the
Dividing wall around the pole.
12) Repeat with the GREEN EA and EB
poles.
RA
RB
16) Place white“Witch Hat” washers onto
pole spikes of bothe RB poles to
prevent water running down during
heavy rain.
R4
R1
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3, R4
Line 2 - R5, R6,
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
Line 4 - RC, RD
LH Eve Pole (GREEN)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
Support Pole (YELLOW)
Line 1 - S2, S3, S4
Line 2 - S1
Line 3 - S5
Awning Pole (RED)
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs 32
Spike Washers 7
Pole Feet 3
Guy Rope 4m 2
Guy Rope 3m 4
WEATHERING YOUR TENT
When you rst get your new tent you will
need to weather it. This is a process of
soaking the fabric to ensure that all the
thread swells up lling stitch holes and
creating a watertight surface.
When you pitch your tent for the rst
time soak the fabric with a garden hose
until the fabric looks visibly damp. Allow
to dry and repeat for two or three times.
Your tent will get more watertight the
more you use it. Do not be concerned if
you have a small amount of water
coming through the seams on the rst
few times you get heavy rain.
NATURAL FIBRE
Freedom Canvas is made of a combina-
tion of Natural Cotton for breathability
and water fastness and Polyester for
strength.
Please note that as Cotton is a natural
bre you will notice variances of both
colour and thickness of the thread. This is
normal and is a characteristic of a natural
and breathable bre.
FIRE RETARDANT
Zempire Canvas Tents are naturally re
retardant. While this signicantly reduces
the risk of the fabric catching in re, it is
by no means reproof. Ensure open
ames are kept well away from your tent
at all times.
S4 S3
S2
18) Place the YELLOW pole sections
S2 to S4 behind the centre dividing
wall.
19) Insert open end of the YELLOW
S1 pole through the pole sock half way
along the RH outside wall. Attach the C
Clip to the BLUE eve pole and lift the
pole sock so it sits under the pole sleeve
Repeat with the YELLOW S5 pole
attaching to the GREEN eve pole.
20) Insert the YELLOW S1 pole into
the end of the S2 pole. Repeat with S5
into S4. Extend both sides by inserting
the button clips into the matching hole.
21) Insert BLACK R6 / R7 pole into
the end of the R4 pole that extends
through the pole sock at the front of the
tent.
R5 R5
23) Extend the BLACK R5/R6 pole
until the awning is tight. You may need to
lower the pole by moving the support
poles to the side.
R6
RB
RA
22) Insert the BLACK RB/RA pole
into the hole at the end of the BLACK
R6 pole and then through the eyelet at
the end of the awning. Extend by
pressing down the button clip.
R5 R6
S5
S1
A1
A2
A1
A2
24) Insert the RED A1/A2 poles into
the eyelets at the front corners of the
awning.
POLE CHART
R4
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
TENT ROOF
WEATHERING INSTRUCTIONS
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3, R4
Line 2 - R5, R6,
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
Line 4 - RC, RD
LH Eve Pole (GREEN)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
Support Pole (YELLOW)
Line 1 - S2, S3, S4
Line 2 - S1
Line 3 - S5
Awning Pole (RED)
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs 32
Spike Washers 7
Pole Feet 3
Guy Rope 4m 2
Guy Rope 3m 4
WEATHERING YOUR TENT
When you rst get your new tent you will
need to weather it. This is a process of
soaking the fabric to ensure that all the
thread swells up lling stitch holes and
creating a watertight surface.
When you pitch your tent for the rst
time soak the fabric with a garden hose
until the fabric looks visibly damp. Allow
to dry and repeat for two or three times.
Your tent will get more watertight the
more you use it. Do not be concerned if
you have a small amount of water
coming through the seams on the rst
few times you get heavy rain.
NATURAL FIBRE
Freedom Canvas is made of a combina-
tion of Natural Cotton for breathability
and water fastness and Polyester for
strength.
Please note that as Cotton is a natural
bre you will notice variances of both
colour and thickness of the thread. This is
normal and is a characteristic of a natural
and breathable bre.
FIRE RETARDANT
Zempire Canvas Tents are naturally re
retardant. While this signicantly reduces
the risk of the fabric catching in re, it is
by no means reproof. Ensure open
ames are kept well away from your tent
at all times.
S4 S3
S2
18) Place the YELLOW pole sections
S2 to S4 behind the centre dividing
wall.
19) Insert open end of the YELLOW
S1 pole through the pole sock half way
along the RH outside wall. Attach the C
Clip to the BLUE eve pole and lift the
pole sock so it sits under the pole sleeve
Repeat with the YELLOW S5 pole
attaching to the GREEN eve pole.
20) Insert the YELLOW S1 pole into
the end of the S2 pole. Repeat with S5
into S4. Extend both sides by inserting
the button clips into the matching hole.
21) Insert BLACK R6 / R7 pole into
the end of the R4 pole that extends
through the pole sock at the front of the
tent.
R5 R5
23) Extend the BLACK R5/R6 pole
until the awning is tight. You may need to
lower the pole by moving the support
poles to the side.
R6
RB
RA
22) Insert the BLACK RB/RA pole
into the hole at the end of the BLACK
R6 pole and then through the eyelet at
the end of the awning. Extend by
pressing down the button clip.
R5 R6
S5
S1
A1
A2
A1
A2
24) Insert the RED A1/A2 poles into
the eyelets at the front corners of the
awning.
POLE CHART
R4
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3, R4
Line 2 - R5, R6,
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
Line 4 - RC, RD
LH Eve Pole (GREEN)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
Support Pole (YELLOW)
Line 1 - S2, S3, S4
Line 2 - S1
Line 3 - S5
Awning Pole (RED)
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs 32
Spike Washers 7
Pole Feet 3
Guy Rope 4m 2
Guy Rope 3m 4
WEATHERING YOUR TENT
When you rst get your new tent you will
need to weather it. This is a process of
soaking the fabric to ensure that all the
thread swells up lling stitch holes and
creating a watertight surface.
When you pitch your tent for the rst
time soak the fabric with a garden hose
until the fabric looks visibly damp. Allow
to dry and repeat for two or three times.
Your tent will get more watertight the
more you use it. Do not be concerned if
you have a small amount of water
coming through the seams on the rst
few times you get heavy rain.
NATURAL FIBRE
Freedom Canvas is made of a combina-
tion of Natural Cotton for breathability
and water fastness and Polyester for
strength.
Please note that as Cotton is a natural
bre you will notice variances of both
colour and thickness of the thread. This is
normal and is a characteristic of a natural
and breathable bre.
FIRE RETARDANT
Zempire Canvas Tents are naturally re
retardant. While this signicantly reduces
the risk of the fabric catching in re, it is
by no means reproof. Ensure open
ames are kept well away from your tent
at all times.
S4 S3
S2
18) Place the YELLOW pole sections
S2 to S4 behind the centre dividing
wall.
19) Insert open end of the YELLOW
S1 pole through the pole sock half way
along the RH outside wall. Attach the C
Clip to the BLUE eve pole and lift the
pole sock so it sits under the pole sleeve
Repeat with the YELLOW S5 pole
attaching to the GREEN eve pole.
20) Insert the YELLOW S1 pole into
the end of the S2 pole. Repeat with S5
into S4. Extend both sides by inserting
the button clips into the matching hole.
21) Insert BLACK R6 / R7 pole into
the end of the R4 pole that extends
through the pole sock at the front of the
tent.
R5 R5
23) Extend the BLACK R5/R6 pole
until the awning is tight. You may need to
lower the pole by moving the support
poles to the side.
R6
RB
RA
22) Insert the BLACK RB/RA pole
into the hole at the end of the BLACK
R6 pole and then through the eyelet at
the end of the awning. Extend by
pressing down the button clip.
R5 R6
S5
S1
A1
A2
A1
A2
24) Insert the RED A1/A2 poles into
the eyelets at the front corners of the
awning.
POLE CHART
R4
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3, R4
Line 2 - R5, R6,
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
Line 4 - RC, RD
LH Eve Pole (GREEN)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
Support Pole (YELLOW)
Line 1 - S2, S3, S4
Line 2 - S1
Line 3 - S5
Awning Pole (RED)
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs 32
Spike Washers 7
Pole Feet 3
Guy Rope 4m 2
Guy Rope 3m 4
WEATHERING YOUR TENT
When you rst get your new tent you will
need to weather it. This is a process of
soaking the fabric to ensure that all the
thread swells up lling stitch holes and
creating a watertight surface.
When you pitch your tent for the rst
time soak the fabric with a garden hose
until the fabric looks visibly damp. Allow
to dry and repeat for two or three times.
Your tent will get more watertight the
more you use it. Do not be concerned if
you have a small amount of water
coming through the seams on the rst
few times you get heavy rain.
NATURAL FIBRE
Freedom Canvas is made of a combina-
tion of Natural Cotton for breathability
and water fastness and Polyester for
strength.
Please note that as Cotton is a natural
bre you will notice variances of both
colour and thickness of the thread. This is
normal and is a characteristic of a natural
and breathable bre.
FIRE RETARDANT
Zempire Canvas Tents are naturally re
retardant. While this signicantly reduces
the risk of the fabric catching in re, it is
by no means reproof. Ensure open
ames are kept well away from your tent
at all times.
S4 S3
S2
18) Place the YELLOW pole sections
S2 to S4 behind the centre dividing
wall.
19) Insert open end of the YELLOW
S1 pole through the pole sock half way
along the RH outside wall. Attach the C
Clip to the BLUE eve pole and lift the
pole sock so it sits under the pole sleeve
Repeat with the YELLOW S5 pole
attaching to the GREEN eve pole.
20) Insert the YELLOW S1 pole into
the end of the S2 pole. Repeat with S5
into S4. Extend both sides by inserting
the button clips into the matching hole.
21) Insert BLACK R6 / R7 pole into
the end of the R4 pole that extends
through the pole sock at the front of the
tent.
R5 R5
23) Extend the BLACK R5/R6 pole
until the awning is tight. You may need to
lower the pole by moving the support
poles to the side.
R6
RB
RA
22) Insert the BLACK RB/RA pole
into the hole at the end of the BLACK
R6 pole and then through the eyelet at
the end of the awning. Extend by
pressing down the button clip.
R5 R6
S5
S1
A1
A2
A1
A2
24) Insert the RED A1/A2 poles into
the eyelets at the front corners of the
awning.
POLE CHART
R4
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3, R4
Line 2 - R5, R6,
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
Line 4 - RC, RD
LH Eve Pole (GREEN)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
Support Pole (YELLOW)
Line 1 - S2, S3, S4
Line 2 - S1
Line 3 - S5
Awning Pole (RED)
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs 32
Spike Washers 7
Pole Feet 3
Guy Rope 4m 2
Guy Rope 3m 4
WEATHERING YOUR TENT
When you rst get your new tent you will
need to weather it. This is a process of
soaking the fabric to ensure that all the
thread swells up lling stitch holes and
creating a watertight surface.
When you pitch your tent for the rst
time soak the fabric with a garden hose
until the fabric looks visibly damp. Allow
to dry and repeat for two or three times.
Your tent will get more watertight the
more you use it. Do not be concerned if
you have a small amount of water
coming through the seams on the rst
few times you get heavy rain.
NATURAL FIBRE
Freedom Canvas is made of a combina-
tion of Natural Cotton for breathability
and water fastness and Polyester for
strength.
Please note that as Cotton is a natural
bre you will notice variances of both
colour and thickness of the thread. This is
normal and is a characteristic of a natural
and breathable bre.
FIRE RETARDANT
Zempire Canvas Tents are naturally re
retardant. While this signicantly reduces
the risk of the fabric catching in re, it is
by no means reproof. Ensure open
ames are kept well away from your tent
at all times.
S4 S3
S2
18) Place the YELLOW pole sections
S2 to S4 behind the centre dividing
wall.
19) Insert open end of the YELLOW
S1 pole through the pole sock half way
along the RH outside wall. Attach the C
Clip to the BLUE eve pole and lift the
pole sock so it sits under the pole sleeve
Repeat with the YELLOW S5 pole
attaching to the GREEN eve pole.
20) Insert the YELLOW S1 pole into
the end of the S2 pole. Repeat with S5
into S4. Extend both sides by inserting
the button clips into the matching hole.
21) Insert BLACK R6 / R7 pole into
the end of the R4 pole that extends
through the pole sock at the front of the
tent.
R5 R5
23) Extend the BLACK R5/R6 pole
until the awning is tight. You may need to
lower the pole by moving the support
poles to the side.
R6
RB
RA
22) Insert the BLACK RB/RA pole
into the hole at the end of the BLACK
R6 pole and then through the eyelet at
the end of the awning. Extend by
pressing down the button clip.
R5 R6
S5
S1
A1
A2
A1
A2
24) Insert the RED A1/A2 poles into
the eyelets at the front corners of the
awning.
POLE CHART
R4
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3, R4
Line 2 - R5, R6,
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
Line 4 - RC, RD
LH Eve Pole (GREEN)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
Support Pole (YELLOW)
Line 1 - S2, S3, S4
Line 2 - S1
Line 3 - S5
Awning Pole (RED)
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs 32
Spike Washers 7
Pole Feet 3
Guy Rope 4m 2
Guy Rope 3m 4
WEATHERING YOUR TENT
When you rst get your new tent you will
need to weather it. This is a process of
soaking the fabric to ensure that all the
thread swells up lling stitch holes and
creating a watertight surface.
When you pitch your tent for the rst
time soak the fabric with a garden hose
until the fabric looks visibly damp. Allow
to dry and repeat for two or three times.
Your tent will get more watertight the
more you use it. Do not be concerned if
you have a small amount of water
coming through the seams on the rst
few times you get heavy rain.
NATURAL FIBRE
Freedom Canvas is made of a combina-
tion of Natural Cotton for breathability
and water fastness and Polyester for
strength.
Please note that as Cotton is a natural
bre you will notice variances of both
colour and thickness of the thread. This is
normal and is a characteristic of a natural
and breathable bre.
FIRE RETARDANT
Zempire Canvas Tents are naturally re
retardant. While this signicantly reduces
the risk of the fabric catching in re, it is
by no means reproof. Ensure open
ames are kept well away from your tent
at all times.
S4 S3
S2
18) Place the YELLOW pole sections
S2 to S4 behind the centre dividing
wall.
19) Insert open end of the YELLOW
S1 pole through the pole sock half way
along the RH outside wall. Attach the C
Clip to the BLUE eve pole and lift the
pole sock so it sits under the pole sleeve
Repeat with the YELLOW S5 pole
attaching to the GREEN eve pole.
20) Insert the YELLOW S1 pole into
the end of the S2 pole. Repeat with S5
into S4. Extend both sides by inserting
the button clips into the matching hole.
21) Insert BLACK R6 / R7 pole into
the end of the R4 pole that extends
through the pole sock at the front of the
tent.
R5 R5
23) Extend the BLACK R5/R6 pole
until the awning is tight. You may need to
lower the pole by moving the support
poles to the side.
R6
RB
RA
22) Insert the BLACK RB/RA pole
into the hole at the end of the BLACK
R6 pole and then through the eyelet at
the end of the awning. Extend by
pressing down the button clip.
R5 R6
S5
S1
A1
A2
A1
A2
24) Insert the RED A1/A2 poles into
the eyelets at the front corners of the
awning.
POLE CHART
R4
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
POLE DIAGRAM - SHERATON 25) Guy out the front awning by
attaching the short guy ropes over top of
awning pole spikes. Line up the guy rope
with the pole spkie and the top ridgepole
spike (indicated by the Line). Ensure
the guy rope is at a 45oangle and pegs
are also inserted at a 45oangle.
A3
A4
A3
A4
27) Peg out front valance. the bottom of
the valance should sit level with the
ground. The outside of the valance
should align with the outside of the tent.
The inside of the valance should be
vertical.
26) Insert the longer RED A3/A4
pole into centre of the side of the
awning. Guy out at a 45oangle with the
longer guy rope sections.
45o
45o
90o
28) Place rubber pole feet under support
pole (BLACK RA & RC)
CARING FOR YOUR TENT
- Never store your tent wet.
- If you must pack your tent down while
still wet, hang to dry as soon as possible
to prevent mildew damage.
- Remove dirt, tree sap, and bird
droppings with a soft brush and warm
water before packing down.
- Do not use detergents to clean your
tent. This will damage the waterproong
of the tent fabric.
- When rolling up your tent ensure there
is no condensation on the oor.
- It is not advisable to re-coat your canvas
as a precautionary measure. This will
reduce the breathability and duarbilty of
your tent. Freedom Canvases are pre
coated and will stay waterproof and
breathable for many years.
- When Storing your tent over the winter,
do not store directly on concrete oors.
- If you do get mildew forming on your
tent, remove the pours with warm water
and a soft brush to prevent further
growth.
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
R2
R5
EB
EA
E1
E2
E3
EA
EB
E1
EB
EA
R3
R4
E2
E3
RB
RA
EA
EB
A1
A2
A3
A4
A3
A4
RC
S2
S4
S5
S1
E4
E4
R6
R1
A2
A1
RD
E5
E5
S3
RB
RA
RB
RA
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
POLE DIAGRAM - SHERATON 25) Guy out the front awning by
attaching the short guy ropes over top of
awning pole spikes. Line up the guy rope
with the pole spkie and the top ridgepole
spike (indicated by the Line). Ensure
the guy rope is at a 45oangle and pegs
are also inserted at a 45oangle.
A3
A4
A3
A4
27) Peg out front valance. the bottom of
the valance should sit level with the
ground. The outside of the valance
should align with the outside of the tent.
The inside of the valance should be
vertical.
26) Insert the longer RED A3/A4
pole into centre of the side of the
awning. Guy out at a 45oangle with the
longer guy rope sections.
45o
45o
90o
28) Place rubber pole feet under support
pole (BLACK RA & RC)
CARING FOR YOUR TENT
- Never store your tent wet.
- If you must pack your tent down while
still wet, hang to dry as soon as possible
to prevent mildew damage.
- Remove dirt, tree sap, and bird
droppings with a soft brush and warm
water before packing down.
- Do not use detergents to clean your
tent. This will damage the waterproong
of the tent fabric.
- When rolling up your tent ensure there
is no condensation on the oor.
- It is not advisable to re-coat your canvas
as a precautionary measure. This will
reduce the breathability and duarbilty of
your tent. Freedom Canvases are pre
coated and will stay waterproof and
breathable for many years.
- When Storing your tent over the winter,
do not store directly on concrete oors.
- If you do get mildew forming on your
tent, remove the pours with warm water
and a soft brush to prevent further
growth.
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
R2
R5
EB
EA
E1
E2
E3
EA
EB
E1
EB
EA
R3
R4
E2
E3
RB
RA
EA
EB
A1
A2
A3
A4
A3
A4
RC
S2
S4
S5
S1
E4
E4
R6
R1
A2
A1
RD
E5
E5
S3
RB
RA
RB
RA
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
POLE DIAGRAM - SHERATON 25) Guy out the front awning by
attaching the short guy ropes over top of
awning pole spikes. Line up the guy rope
with the pole spkie and the top ridgepole
spike (indicated by the Line). Ensure
the guy rope is at a 45oangle and pegs
are also inserted at a 45oangle.
A3
A4
A3
A4
27) Peg out front valance. the bottom of
the valance should sit level with the
ground. The outside of the valance
should align with the outside of the tent.
The inside of the valance should be
vertical.
26) Insert the longer RED A3/A4
pole into centre of the side of the
awning. Guy out at a 45oangle with the
longer guy rope sections.
45o
45o
90o
28) Place rubber pole feet under support
pole (BLACK RA & RC)
CARING FOR YOUR TENT
- Never store your tent wet.
- If you must pack your tent down while
still wet, hang to dry as soon as possible
to prevent mildew damage.
- Remove dirt, tree sap, and bird
droppings with a soft brush and warm
water before packing down.
- Do not use detergents to clean your
tent. This will damage the waterproong
of the tent fabric.
- When rolling up your tent ensure there
is no condensation on the oor.
- It is not advisable to re-coat your canvas
as a precautionary measure. This will
reduce the breathability and duarbilty of
your tent. Freedom Canvases are pre
coated and will stay waterproof and
breathable for many years.
- When Storing your tent over the winter,
do not store directly on concrete oors.
- If you do get mildew forming on your
tent, remove the pours with warm water
and a soft brush to prevent further
growth.
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
R2
R5
EB
EA
E1
E2
E3
EA
EB
E1
EB
EA
R3
R4
E2
E3
RB
RA
EA
EB
A1
A2
A3
A4
A3
A4
RC
S2
S4
S5
S1
E4
E4
R6
R1
A2
A1
RD
E5
E5
S3
RB
RA
RB
RA
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
POLE DIAGRAM - SHERATON 25) Guy out the front awning by
attaching the short guy ropes over top of
awning pole spikes. Line up the guy rope
with the pole spkie and the top ridgepole
spike (indicated by the Line). Ensure
the guy rope is at a 45oangle and pegs
are also inserted at a 45oangle.
A3
A4
A3
A4
27) Peg out front valance. the bottom of
the valance should sit level with the
ground. The outside of the valance
should align with the outside of the tent.
The inside of the valance should be
vertical.
26) Insert the longer RED A3/A4
pole into centre of the side of the
awning. Guy out at a 45oangle with the
longer guy rope sections.
45o
45o
90o
28) Place rubber pole feet under support
pole (BLACK RA & RC)
CARING FOR YOUR TENT
- Never store your tent wet.
- If you must pack your tent down while
still wet, hang to dry as soon as possible
to prevent mildew damage.
- Remove dirt, tree sap, and bird
droppings with a soft brush and warm
water before packing down.
- Do not use detergents to clean your
tent. This will damage the waterproong
of the tent fabric.
- When rolling up your tent ensure there
is no condensation on the oor.
- It is not advisable to re-coat your canvas
as a precautionary measure. This will
reduce the breathability and duarbilty of
your tent. Freedom Canvases are pre
coated and will stay waterproof and
breathable for many years.
- When Storing your tent over the winter,
do not store directly on concrete oors.
- If you do get mildew forming on your
tent, remove the pours with warm water
and a soft brush to prevent further
growth.
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
R2
R5
EB
EA
E1
E2
E3
EA
EB
E1
EB
EA
R3
R4
E2
E3
RB
RA
EA
EB
A1
A2
A3
A4
A3
A4
RC
S2
S4
S5
S1
E4
E4
R6
R1
A2
A1
RD
E5
E5
S3
RB
RA
RB
RA
TITAN
////// CANVASSERIES
FREEDOM
CAMPING
BY
19. From the outside of the tent, insert
the open end of the YELLOW S1 pole
through the pole sock half way along
the RH outside wall. Attach the C Clip
to the BLUE eve pole and tuck the pole
sock under the pole sleeve.
Repeat with the YELLOW S5 pole
attaching to the GREEN eve pole.
20.Insert the YELLOW S1 pole into the
end of the S2 pole. Repeat with S5 into
S4. Extend both sides by inserting the
button clips into the matching hole.
21. Insert BLACK R6/R7 pole into the end
of the R4 pole that extends through
the pole sock at the front of the tent.
22. Insert the BLACK RB/RA pole into the
hole at the end of the BLACK R6 pole
and then through the eyelet at the
end of the awning. Extend by pressing
down the button clip.
23. Extend the BLACK R5/R6 pole until the
awning is tight. If unable to reach, you
may need to lower the pole by moving
the support pole to the side.
24.Insert the RED A1/A2 poles into the
eyelets at the front corners of the
awning.
25. Guy out the front awning by attaching
the short guy ropes over top of awning
pole spigot. Line up the guy rope with
the pole spigot and the top ridgepole
spike (indicated by the - - Line). Ensure
the guy rope is at a 45º angle and pegs
are also inserted at a 45º angle.
26. Insert the longer RED A3/A4 pole into
centre of the side of the awning. Guy
out at a 45º angle with the longer guy
rope sections.
27. Peg out front valance. The bottom of
the valance should sit level with the
ground. The outside of the valance
should align with the outside of the
tent. The inside of the valance should
be vertical.
28.Place rubber pole feet under support
pole (BLACK RA & RC)
WEATHERING YOUR TENT
When you first get your new tent, you will need to weather it. This is a process of soaking the
fabric to ensure the cotton threads swell up, filling stitch holes and creating a watertight surface.
When you pitch your tent for the first time, soak the fabric with a garden hose until the fabric is
visibly damp. Allow to dry and repeat two or three times.
Your tent will get more watertight the more you use it. Do not be concerned if you have a small
amount of water coming through the seams on the first few times you get heavy rain.
NATURAL FIBRE
ZEMPIRE®Canvas is made of a combination of natural cotton for breathability and water fastness
and polyester for strength. Please note that as cotton is a natural fibre, you will notice variances
of both colour and thickness of the thread. This is normal and is a characteristic of a natural and
breathable fibre.
FIRE RETARDANT
ZEMPIRE®Canvas Tents are naturally fire retardant. While this significantly reduces the risk of the
fabric catching on fire, it is by no means fire-proof. Ensure open flames are kept well away from
your tent at all times.
Ridge Pole (BLACK)
Line 1 - R1 , R2, R3, R4
Line 2 - R5, R6,
Line 3 - RA, RB
Line 3 - RA, RB
Line 3 - RA, RB
Line 4 - RC, RD
LH Eve Pole (GREEN)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
RH Eve Pole (BLUE)
Line 1 - E1 , E2, E3, E4,
Line 2 - E5
Line 3 - EA, EB
Line 4 - EA, EB
Support Pole (YELLOW)
Line 1 - S2, S3, S4
Line 2 - S1
Line 3 - S5
Awning Pole (RED)
Line 1 - A1, A2
Line 2 - A1, A2
Line 3 - A3, A4
Line 4 - A3, A4
Pegs 32
Spike Washers 7
Pole Feet 3
Guy Rope 4m 2
Guy Rope 3m 4
WEATHERING YOUR TENT
When you rst get your new tent you will
need to weather it. This is a process of
soaking the fabric to ensure that all the
thread swells up lling stitch holes and
creating a watertight surface.
When you pitch your tent for the rst
time soak the fabric with a garden hose
until the fabric looks visibly damp. Allow
to dry and repeat for two or three times.
Your tent will get more watertight the
more you use it. Do not be concerned if
you have a small amount of water
coming through the seams on the rst
few times you get heavy rain.
NATURAL FIBRE
Freedom Canvas is made of a combina-
tion of Natural Cotton for breathability
and water fastness and Polyester for
strength.
Please note that as Cotton is a natural
bre you will notice variances of both
colour and thickness of the thread. This is
normal and is a characteristic of a natural
and breathable bre.
FIRE RETARDANT
Zempire Canvas Tents are naturally re
retardant. While this signicantly reduces
the risk of the fabric catching in re, it is
by no means reproof. Ensure open
ames are kept well away from your tent
at all times.
S4 S3
S2
18) Place the YELLOW pole sections
S2 to S4 behind the centre dividing
wall.
19) Insert open end of the YELLOW
S1 pole through the pole sock half way
along the RH outside wall. Attach the C
Clip to the BLUE eve pole and lift the
pole sock so it sits under the pole sleeve
Repeat with the YELLOW S5 pole
attaching to the GREEN eve pole.
20) Insert the YELLOW S1 pole into
the end of the S2 pole. Repeat with S5
into S4. Extend both sides by inserting
the button clips into the matching hole.
21) Insert BLACK R6 / R7 pole into
the end of the R4 pole that extends
through the pole sock at the front of the
tent.
R5 R5
23) Extend the BLACK R5/R6 pole
until the awning is tight. You may need to
lower the pole by moving the support
poles to the side.
R6
RB
RA
22) Insert the BLACK RB/RA pole
into the hole at the end of the BLACK
R6 pole and then through the eyelet at
the end of the awning. Extend by
pressing down the button clip.
R5 R6
S5
S1
A1
A2
A1
A2
24) Insert the RED A1/A2 poles into
the eyelets at the front corners of the
awning.
POLE CHART
R4
TITAN
////// CANVASSERIES
FREEDOM CAMPING
BY
CONDENSATION
It is important that lower vents are opened at all times to reduce the risk of condensation. During
humid or damp conditions, it is recommended that the waterproof door covers are opened to
expose the mesh layer, enabling additional airflow throughout your tent.
Do not use foam swabs or non-bonded mats directly on the tent floor. This will cause
condensation between the mat and floor and if not dried out, can lead to mildew forming.
