Zenith Lapalma FORK P120 User manual

THREADED ROD M8
L. 435 mm
HIT WITH A
RUBBER HAMMER
CORRECT POSITIONING
LEG
L. 488 mm
UNTIL THE END
www.lapalma.it
assembly instructions
FORK P120
02/12/2019 - Rv00
STEP 1
STEP 2
SCREW UNTIL THE END

HIT WITH A
RUBBER HAMMER
www.lapalma.it
assembly instructions
FORK P120
02/12/2019 - Rv00
STEP 3
STEP 4
FIX THE LEG WITH A M8 HEX NUT
REPEAT STEP 1-2-3-4 FOR EACH LEG

THREADED ROD M10
L. 125 mm
HIT WITH A
RUBBER HAMMER
COLUMN
L. 190 mm
MATCH THE
REFERENCES
www.lapalma.it
assembly instructions
FORK P120
02/12/2019 - Rv00
STEP 5
STEP 6
SCREW UNTIL THE END

SCREW M10x65
MATCH THE REFERENCES
4X
SCREW M6x16
www.lapalma.it
assembly instructions
FORK P120
02/12/2019 - Rv00
STEP 7
STEP 8

THREADED ROD M8
L. 550 mm
HIT WITH A
RUBBER HAMMER
CORRECT POSITIONING
LEG
L. 605 mm
UNTIL THE END
www.lapalma.it
assembly instructions
FORK P124
02/12/2019 - Rv00
STEP 1
STEP 2
SCREW UNTIL THE END

HIT WITH A
RUBBER HAMMER
www.lapalma.it
assembly instructions
FORK P124
02/12/2019 - Rv00
STEP 3
STEP 4
FIX THE LEG WITH A M8 HEX NUT
REPEAT STEP 1-2-3-4 FOR EACH LEG

HIT WITH A
RUBBER HAMMER
COLUMN
L. 92 mm
MATCH THE
REFERENCES
www.lapalma.it
assembly instructions
FORK P124
02/12/2019 - Rv00
STEP 5
STEP 6

SCREW M10x90
MATCH THE REFERENCES
4X
SCREW M6x16
www.lapalma.it
assembly instructions
FORK P124
02/12/2019 - Rv00
STEP 7
STEP 8
