Zenner multipulse User manual

multipulse, multilog
Installation and
operating manual
Electronic pulse counter module
with 3 inputs for connection
of meters with pulse outputs
EnergyMetering
All that counts.
ZE12B28_MA_Multipulse_EN_V2_D 1 10.10.12 17:24

2
General information
With multipulse resp. multilog you have acquired
one of the most up-to-date and modern electron-
ic pulse counter modules currently available on
the market.
Expressive symbols in the display and easy
menu navigation make readout simple. It can be
operated with one single button. The change of
pulse values and the setting of the data loggers
with multilog is being done via the software GMM.
The pulse counter module is equipped with a long-
life battery made for operation during a period of 5
years including a reserve of at least another year.
With a second battery you will reach 11 years.
Electro-magnetic interference
multipulse resp. multilog fulls the national and
international requirements for interference resis-
tance. To avoid malfunctions due to other inter-
ferences, do not install uorescent lamps, switch
cabinets or electric devices such as motors or
pumps in the immediate vicinity of the meter
(minimum distance 1 m). Cables leaving the
meter should not be laid parallel to live cables
(230V, minimum distance 0.2 m).
Cables leaving the meter should not be laid paral-
lel to live cables (230V, minimum distance 0.2 m).
The device complies with Directive 89/336/EEC
(electromagnetic compatibility).
Care instructions
Clean plastic surfaces with a damp cloth only.
Do not use any scouring or aggressive cleaning
agents! The device is maintenance-free during
the service life. Repairs can only be made by the
manufacturer. The most up-to-date information
about this product and of our installation notice
can be found at www.zenner.com.
ZE12B28_MA_Multipulse_EN_V2_D 2 10.10.12 17:24

3
Technical data
Dispay Multifunctional LCD, 8-digit, oating
Interface meter Models with contact pulsers or active pulsers (no
Namur or Opto) Reed max. 1Hz /active max. 100 Hz
Interfaces optical, optionally ZR-Bus, M-Bus, RS-232,
Ambient temperature °C 0 - 55
Power supply Battery 3.6 V Lithium, optionally mains supply 230 V
Battery lifetime 6 years, optionally 11 years
Protection class IP 54 / IP 65, acc. to DIN 40050
Mechanical/electro-magnetic class M1/E1
ZE12B28_MA_Multipulse_EN_V2_D 3 10.10.12 17:24

4
pulse
52/
54
11
10
GND
pulse
11
10
pulse
11
10
VCC 2,5 … 3,6 V
U = 3 … 30 V
Imax = 20 mA
tp
tp
53/
55
52/
54
53/
55
52/
54
53/
55
GND
Uhigh = 2,5 … 3,6 V
Ulow = 0 … 0,3 V
pulse
52/
54
11
10
GND
pulse
11
10
pulse
11
10
VCC 2,5 … 3,6 V
U = 3 … 30 V
Imax = 20 mA
tp
tp
53/
55
52/
54
53/
55
52/
54
53/
55
GND
Uhigh = 2,5 … 3,6 V
Ulow = 0 … 0,3 V
pulse
52/
54
11
10
GND
pulse
11
10
pulse
11
10
VCC 2,5 … 3,6 V
U = 3 … 30 V
Imax = 20 mA
tp
tp
53/
55
52/
54
53/
55
52/
54
53/
55
GND
Uhigh = 2,5 … 3,6 V
Ulow = 0 … 0,3 V
pulse
52/
54
11
10
GND
pulse
11
10
pulse
11
10
VCC 2,5 … 3,6 V
U = 3 … 30 V
Imax = 20 mA
tp
tp
53/
55
52/
54
53/
55
52/
54
53/
55
GND
Uhigh = 2,5 … 3,6 V
Ulow = 0 … 0,3 V
pulse
52/
54
11
10
GND
pulse
11
10
pulse
11
10
VCC 2,5 … 3,6 V
U = 3 … 30 V
Imax = 20 mA
tp
tp
53/
55
52/
54
53/
55
52/
54
53/
55
GND
Uhigh = 2,5 … 3,6 V
Ulow = 0 … 0,3 V
1 Hz Version: fmax = 1 Hz, Pulse-duty factor 1:1 to 1:9 Input
capacitance: approx. 10 nF, Input resistance approx 850 kOhm
100 Hz Version: not allowed
fmax = 1 Hz,
Pulse-duty factor 1:1 to 1:9
Input capacitance: approx. 15 nF,
Input resistance approx 470 kOhm
1 Hz Version: fmax = 1 Hz, Pulse-duty factor 1:1 to 1:9 Input
capacitance: approx. 10 nF, Input resistance approx 850 kOhm
100 Hz Version: fmax = 30 Hz, Pulse-duty factor 1:1, Input
capacitance: approx. 2,5 nF, Input resistance approx. 850 kOhm
fmax = 1 Hz,
Pulse-duty factor 1:1 to 1:9
Input capacitance: approx. 15 nF,
Input resistance approx 470 kOhm
1 Hz Version: fmax = 1 Hz, Pulse-duty factor 1:1 to 1:9
Uhigh = 2,5 … 3,6V, Ulow = 0 … 0,3 V, Input capacitance:
approx. 10 nF, Input resistance approx 850 kOhm
100 Hz Version: fmax = 100 Hz, Pulse-duty factor 1:1
Uhigh = 2,5 … 3,6V, Ulow = 0 … 0,3 V, Input capacitance:
approx. 2,5 nF, Input resistance approx. 850 kOhm
Passive with
mechanical
contact (Reed)
Passive with
mechanical
contact (Reed)
Passive with
open drain FET
Passive with
open drain FET
Active f.ex. with
C-MOS Gate
Flow sensor input
Electrical connection Schematic diagram Connection data
Electrical connection Schematic diagram Connection data
Technical data additional inputs
Technical data flow sensor input
ZE12B28_MA_Multipulse_EN_V2_D 4 10.10.12 17:24

5
If water meters with a potential free reed contact
are connected to the inputs the connection can
be made in any direction.
The connectors are given twice for the incoming
and outgoing of the M-bus wires.
Depending on the pulse counter module’s model
the version of the connection board can differ.
Note
You can download additional information in our
product area at www.zenner.com.
1 2 3 4 10 11 9 50 51 52 53 54 55 24 25 24 25
Version M-Bus
1 2 3 4 10 11 9 50 51 52 53 54 55
Version without interface
1 2 3 4 10 11 9 50 51 52 53 54 55 71 72 73 74
Version RS 232 / RS 485 (ZR-Bus)
Connector pin assignment
Main input
Volume pulse 10
Volume GND 11
Additional inputs
Input 1 pulse 52
Input 1 GND 53
Input 2 pulse 54
Input 2 GND 55
M-Bus
M-Bus A 24
M-Bus B 25
RS-232
DTR 71
GND 72
Tx 73
Rx 74
RS-485
+UB 71
GND 72
A 73
B 74
ZE12B28_MA_Multipulse_EN_V2_D 5 10.10.12 17:24

6
Dimensions
Height: H = 106 mm
Width: B = 126 mm
Depth: T = 54 mm
Communication
The pulse values can be programmed via
the software GMM. The pulse value can
be called up in the display (see the display
overview, Level 1).
The display resolution should be chosen in
such way that the display can not overow
within one years time.
M-Bus (optional)
The optional M-Bus interface complies
with the norm EN 1434-3 and operates
with 2400 baud xed. It can be set to
300/9600 baud if necessary.
B
H
T
