DIMinBOX DX1
1-Channel Universal Dimmer for DIN rail mounting (350W@230VAC/200W@110VAC)
ZDIDBDX1 TECHNICAL DOCUMENTATION
FEATURES
•1 channel for R L C loads and for dimmable CFL and LED lamps.
•Automatic detection of R L C load type.
•Automatic frequency detection.
•Dimming pattern selection for CFL and LED lamps.
•Optional manual dimming control.
•Total data saving on KNX bus failure.
•Integrated KNX BCU.
•Dimensions 67 x 90 x 36mm (2 DIN units).
•DIN rail mounting (EN 50022), through pressure.
•Conformity with the CE directives (CE-mark on the right side).
1. Output channel
2. Power supply input
3. Output status LEDs
4. Manual control push buttons
5. Programming/Test push button
6. Programming/Test LED
7. KNX connector
Figure 1: DIMinBOX DX1
Programming/Test button: short press to set programming mode. If this button is held while plugging the device into the KNX bus, it enters the safe
mode. If this button is held for more than 3 seconds, the device enters the test mode.
Programming/Test LED: programming mode indicator (red). When the device enters the safe mode, it blinks (red) every half second. The manual mode
is indicated by the green color. During the start-up (reset or after KNX bus failure) and if the device is not in safe mode, it emits a red flash.
GENERAL SPECIFICATIONS
CONCEPT
DESCRIPTION
Type of device
Electric operation control device
KNX supply
Voltage (typical)
29VDC SELV
Voltage range
21..31VDC
Maximum
consumption
Voltage
mA
mW
29VDC (typical)
7.05
204.45
24VDC¹
10
240
Connection type
Typical TP1 bus connector for 0.80mm Ø rigid cable
External power supply
110/230VAC 50/60Hz
Operation temperature
0°C .. +55°C
Storage temperature
-20°C .. +55°C
Operation humidity
5 .. 95%
Storage humidity
5 .. 95%
Complementary characteristics
Class B
Protection class
II
Operation type
Continuous operation
Device action type
Type 1
Electrical stress period
Long
Degree of protection
IP20, clean environment
Installation
Independentdevice to be mounted inside electrical panels with DIN rail (EN
50022)
Minimum clearances
Not required
Response on KNX bus failure
Data saving according to parameterization
Response on KNX bus restart
Data recovery according to parameterization
Operation indicator
The programming LED indicates programming mode (red) and test mode
(green). The output LED indicates its status (fixed = active output; flashing
= error in the output)
Weight
105g
PCB CTI index
175V
Housing material
PC FR V0 halogen free
¹ Maximum consumption in the worst-case scenario (KNX Fan-In model)
R,L,C
LN N C
4
7
5
3
6
1
2

© Zennio Avance y Tecnología S.L. Edition 4 Futher information www.zennio.com Page 2/4
SAFETY INSTRUCTIONS ANDADDITIONAL NOTES
•Installation should only be performed by qualified professionals according to the laws and regulations applicable in each country.
•Do not connect the mains voltage nor any other external voltage to any point of the KNX bus; it would represent a risk for the entire
KNX system. The facility must have enough insulation between the mains (or auxiliary) voltage and the KNX bus or the wires of other
accessories, in case of being installed.
•The facility must be equipped with a device that ensures the omnipolar sectioning. Installation of a 10A mini-circuit-breaker is
recommended. To prevent accidents, it must remain open in case of manipulation of the device.
•The device has a short-circuit protection fuse that, in case of activation, should only be rearmed or replaced by the Zennio technical
service.
•Once the device is installed (in the panel or box), it must not be accessible from outside.
•Keep the device away from water (condensation over the device included) and do not cover it with clothes, paper or any other material
while in use.
•The WEEE logo means that this device contains electronic parts and it must be properly disposed of by following the instructions at
http://zennio.com/weee-regulation.
•This device contains software subject to specific licences. For details, please refer to http://zennio.com/licenses.
OUTPUTS SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Number of outputs
1
Output type
Solid state switching device
Short-circuit protection
YES
Overload protection
YES
Connection method
Screw terminal block
Cable cross-section
0.5-4mm² (IEC) / 20-12AWG (UL)
LOADS AND ALLOWED POWER (@ 35°C ambient temperature around the device)
230VAC
110VAC
RLC
Individual channel
Up to 350W
Up to 200W
CFL and LED ¹
Individual channel
Up to 350W
Up to 200W
¹For leading edge, the maximum load could change depending on the load type. Please refer to the link
https://zennio.com/download/technical_note_diminbox-dx_list_process_en.
Also, for load characterization process, please refer to the link https://www.zennio.com/download/technical_note_diminbox-dx2_tests_en.
EXTERNAL POWER SUPPLY SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Power supply protection
fuse
Voltage
250V
Current
10A
Response type
T (time-lag)
Connection method
Screw terminal block
Cable cross-section
0.5-4mm² (IEC) / 20-12AWG (UL)
WIRINGDIAGRAMS
Figure 2: Wiring examples

© Zennio Avance y Tecnología S.L. Edition 4 Futher information www.zennio.com Page 3/4
SUPPORTEDLOADS
•R = Resistive
•L = Inductive
•C = Capacitive
•CFL = Dimmable Compact Fluorescent Lamps
•LED = Dimmable LED lamps
LOAD COMBINATION
•In case of combiningresistive (R) with inductive (L) loads, the resistive loads must
not exceed the 50% of the total power.
•In case of combining resistive (R) with capacitive (C) loads, the resistive loads
must not exceed the 50% of the total power.
•Combination of capacitive loads with inductive loads is NOT ALLOWED.
•Do not combine CFL or LED lamps with R L C loads.
•It is not advisable to combine different models of CFL lamps, LED lamps or
transformers in the same channel since correct operation can be affected.
OVERHEATING PROTECTION
•When the ambient temperatureis too high the dimmer actuator will regulate itself,
at a maximum of 20%.
•Once the ambient temperature decreases, the dimmer actuator will resume its
normal operation. Please, refer to user manual.
R
L
C
CFL
LED
NO!
Figure 3: Mounting DIMinBOX DX1 on DIN rail
Attaching DIMinBOX DX1 to DIN rail:
Removing DIMinBOX DX1 from DIN rail:
Please, make sure that the loads used are
dimmable.

© Zennio Avance y Tecnología S.L. Edition 4 Futher information www.zennio.com Page 4/4
ERROR NOTIFICATIONS
ERROR
LEDS DESCRIPTION
VISUAL NOTIFICATION
Short circuit
The two status LEDs blink alternately every 0.25
second.
When the output is locked, the programming LED
blinks in blue.
Voltage Surge
The two status LEDs blink simultaneously every
0.25 second.
When the output is locked, the programming LED
lights in blue
Overheating
The LEDs blink every second.
Supply Voltage Failure
One LED blinks every second.
Anomalous Frequency
Alternating blink of each LED during one-second,
followed by a one-second switch off.
Parameterization Error
One LED blinks every second while the other LED
blinks every 0.25 second.
0
0.5
1 0
0.5
1.5 1
1.5
2 2
2.5
2.5 3
3.5
3
0
0.5
1 0
0.5
1.5 1
1.5
2 2
2.5
2.5 3
3.5
3
0
0.5
1
1.5
2
2.5
3
0
0.5
1
1.5
2
2.5
3
0
0.5
1
1.5
2
2.5
3
0
0.5
1
1.5
2
2.5
3
Output
status
LEDS
TIME (s)
Prog. LED
(blue)
Output
status
LEDS
TIME (s)
Prog. LED
(blue)
Output
status
LEDS
TIME (s)
Output
status
LEDS
TIME (s)
Output
status
LEDS
TIME (s)
Output
status
LEDS
TIME (s)
