Zennio Touch-MyDesign Display One User manual

8-Button Capacitive Touch Panel with LCD Display
USER MANUAL
ZVI-TMDD
Application Program Version: [1.0]
User Manual Version: [1.0]_a
www.zennio.com

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
2
CONTENTS
Contents ...................................................................................................................................2
1 Introduction.........................................................................................................................4
1.1 TMD-Display.................................................................................................................4
1.2 TMD-Display One..........................................................................................................6
1.3 Installation ...................................................................................................................7
2 Configuration.......................................................................................................................9
2.1 Default Configuration ...................................................................................................9
2.2 General.......................................................................................................................11
2.2.1 CONFIGURATION.................................................................................................11
2.2.2 Temperature Sensor............................................................................................12
2.2.3 Screensaver.........................................................................................................13
2.2.4 LEDs & Display.....................................................................................................14
2.2.5 Sounds ................................................................................................................17
2.2.6 ADVANCED..........................................................................................................19
2.2.7 Translations.........................................................................................................20
2.2.8 Touch Locking .....................................................................................................22
2.2.9 Cleaning Function................................................................................................23
2.2.10 Welcome Greeting ..............................................................................................25
2.2.11 Welcome Back.....................................................................................................26
2.2.12 Central Area ........................................................................................................28
2.3 Buttons.......................................................................................................................30
2.3.1 CONFIGURATION.................................................................................................30
2.3.2 Disabled ..............................................................................................................33

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
3
2.3.3 Pair .....................................................................................................................33
2.3.4 Individual ............................................................................................................49
2.4 Display........................................................................................................................62
2.4.1 CONFIGURATION.................................................................................................62
2.4.2 Disabled ..............................................................................................................65
2.4.3 Single ..................................................................................................................65
2.4.4 Double ................................................................................................................77
2.4.5 Borders ...............................................................................................................78
2.5 Inputs .........................................................................................................................80
2.6 Thermostat.................................................................................................................81
ANNEX I: LED Illumination Modes ...........................................................................................82
ANNEX II: Communication Objects ..........................................................................................85

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
4
1INTRODUCTION
1.1 TMD-DISPLAY
TMD-Display is an evolution of Touch-MyDesign Plus, the KNX multifunction
capacitive touch switch from Zennio.
TMD-Display provides eight capacitive buttons aligned in 2 columns of 4 buttons
each, LEDs to indicate user presses or states, and a wide display on the top of the
front panel, as in ZAS and Roll-ZAS from Zennio.
TMD-Display is a fully customisable solution for the room control, including hotel
rooms, offices or any other environment where the user needs to control climate
systems, lighting, blinds, scenes, etc.
The versatility of the above functions is enhanced by the built-in analogue/digital
inputs, the internal temperature sensor and the thermostat function, as well as an
elegant and fully customisable design of the front glass – customers can choose
their button icons, texts and colours and even personalise the background with their
pictures, logos, etc.
Moreover, the display offers the possibility to show useful information to the user about
the control states and object values.
Figure 1 TMD-Display.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
5
The most outstanding features of TMD-Display are:
1.8’’ back-lit display with a resolution of 128x64 pixels.
Fully customisable design of the front glass.
8 touch buttons which can operate as individual or pair controls.
Light indicator (LED) for every button, the state of which (on or off) can
depend on different factors according to the user’s needs.
Buzzer for an audible acknowledgement of user actions (with the possibility
of disabling it either by parameter or by object).
Possibility of locking / unlocking the touch panel through binary orders or
scenes, and of setting a timed/automatic locking of the device (cleaning
function).
Welcome greeting on the display and Welcome Back object (binary or
scene).
Central touch area with a customisable object sending when pressed.
Screensaver function.
Up to 5 switchable languages for the displayed texts.
Two analogue/digital inputs (temperature probes, additional switches, etc.).
Thermostat function.
Built-in temperature sensor.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
6
1.2 TMD-DISPLAY ONE
The TMD-Display One application program brings the user the possibility to configure
their TMD-Display as a single-page user interface.
This means that the capacitive buttons and the LCD display will perform the same
functions anytime, making it possible to provide the user with an easy-to-use interface,
with no menus or alternating pages.
Because of this, the design of the front glass can contain icons specific enough as to
make the function of the touch buttons evident at a simple glance.
Some of the available functions are:
On the touch buttons:
Pair button functions: numeric counter, light dimmer, shutter controller,
temperature setpoint, etc.
Individual button functions: binary switch, hold & release, scenes, light
dimmer, shutter controller, numeric constants, etc.
On the display:
Single-box indicator: icon, number, text, time of day, climate, etc.
Double-box indicator: icon, number, text, time of day, climate, etc.
In addition to these functions, TMD-Display One incorporates all the features already
mentioned in 1.1.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
7
1.3 INSTALLATION
Figure 2 TMD-Display One. Installation Process.
To install the device, it is first necessary to mount the metallic plate into a square/round
standard appliance box through the suitable screws. Next, TMD-Display is connected
to the KNX bus through the corresponding terminal on the rear side of the device, and
then the input terminal is as well connected to the rear of the device.
Once the input terminal and the KNX terminal are connected, the device can be easily
mounted on the metallic plate by the action of the built-in magnets. After that, it is
necessary to slide it downwards to fix it through the security anchorage system.
Finally, it is advisable to check that the device is properly installed, and that only its
profile becomes visible from above, from below and from both sides (the metallic plate
should be completely hidden).
This device does not need any external supply, as it is powered through the KNX bus.
Figure 3 Element diagram.
2
3
1
4
1. Temperature Sensor.
2. KNX Bus Co nnector.
3. Analogue/Digital Inputs.
4. Test/Prog. Button.
5. Test/Prog. LED.
6. Magnet.
7. Display.
8. Status LED.
9. Main touch area.
10. Central Touch Area.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
8
The programming button (4) can be pressed with the help of a thin screw to set the
device into the Programming Mode. After a short press, the programming LED (5) will
light in red. Note that if this button is held while plugging the device into the KNX bus,
the device will enter the Safe Mode. The LED will then blink in red.
Note:whenever the device recovers the bus power, an immediate self-calibration
process of the touch panel takes place. Please ensure to avoid touching the front glass
while powering the device. If undesired effects arise during normal use, please
disconnect the device from the bus and connect it again, making sure that the front
glass is not touched during this process.
For detailed information about the technical features of the device and for safety
instructions and on the installation process, please refer to the Datasheet bundled with
the original packaging of the device and also available at www.zennio.com.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
9
2CONFIGURATION
2.1 DEFAULT CONFIGURATION
To make the device perform the desired functions, several options need to be
parameterised, either related to its general behaviour (screensaver, sounds, LEDs
and display brightness levels…) or to advanced features (lock procedure of the touch
panel, cleaning function, welcome greeting on the display, welcome back object, etc.).
Some of the above options are common to other Zennio devices such as Touch-
MyDesign, Roll-ZAS or Z41, while others are specific for TMD-Display.
On the other hand, TMD-Display features two opto-coupled inputs, each of which may
be independently configured as a switch/sensor, a push-button or a temperature
probe, so that external accessories can be connected to the device.
In the particular case of an external temperature probe (such as model ZN1AC-NTC68
from Zennio), it will be possible to use it with independence of the built-in temperature
sensor of the device, which implements its own communication objects and can be
enabled and disabled in parameters.
ETS PARAMETERISATION
Figure 4 General.
After importing the corresponding database in ETS and adding the device into the
topology of the project, the configuration process begins by right-clicking into the
device and selecting Edit parameters.
This will bring the window shown in Figure 4, which contains the following tabs:
General: contains the parameters that define the general behaviour of the
device and that enable/disable additional features such as the thermostat or
the external inputs. See section 2.2 for details.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
10
Buttons: contains the parameters involved in the configuration of the touch
buttons of the device. See section 2.3 for details.
Display: contains the parameters related to the configuration of the display of
the device. See section 2.4 for details.
Depending on the configuration, other tabs may show in the tab tree on the left.
These tabs will be explained in the next sections.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
11
2.2 GENERAL
As shown in Figure 4, the “General” tab only contains one sub-tab by default:
“Configuration”. However, it may include other tabs depending on the parameterisation.
2.2.1 CONFIGURATION
Figure 5. General - Configuration
This tab shows the following parameters:
Buttons: read-only parameter to make it evident that the “Buttons” tab is
always enabled in the tab tree on the left. See 2.3 for details.
Display: read-only parameter to make it evident that the “Display” tab is
always enabled in the tab tree on the left. See 2.4 for details.
Inputs: enables or disables the “Inputs” tab in the tree on the left, depending
on whether the device will or will not be connected any external accessories.
See section 2.5 for details.
Thermostat: enables or disables the “Thermostat” tab in the tree on the left.
See section 2.6 for details.
Internal temperature sensor: enables or disables the “Temperature Sensor”
tab in the tree on the left. See section 2.2.2 for details.
Screensaver: enables or disables the “Screensaver” tab in the tree on the
left. See section 2.2.3 for details.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
12
LEDs and Display config.: sets whether the LEDs and display should make
use of the pre-defined brightness levels (“Default”) or of a user-defined
configuration (“Custom”).
“Default”: the LEDs will remain off while in the “off” state, and at the
maximum light level while in the “on” state. The display contrast level is set
to 7.
“Custom”: a specific tab will be included in the tab tree on the left so the
integrator can set the desired light levels for the “off” and “on” states and
whether to use the Night Mode or not. The display contrast level will also
be configurable.
See section 2.2.4 for details.
Sounds: sets whether the sound functions (button beeps, alarm and
doorbell) should work according to the pre-defined configuration (“Default”) or
to a user-defined configuration (“Custom”). See section 2.2.5 for details.
Advanced configuration: enables or disables the “Advanced” tab in the tree
on the left. See section 2.2.6 for details.
The project topology shows the following objects by default:
[General] Time of day: object for updating the time shown on the display.
Important: the time of day must be set through the bus by means of an
external reference. In the absence of power, the clock will get outdated.
[General] Scene: Receive and [General] Scene: Send: objects for
respectively receiving and sending scene values from/to the KNX bus
whenever it is necessary (e.g., when the user touches a button that has been
configured to send scene commands; see section 2.3.4).
2.2.2 TEMPERATURE SENSOR
TMD-Display is equipped with one internal temperature probe which can monitor the
ambient temperature of the room, thus making the device capable of reporting it to the
KNX bus and of triggering certain actions when the temperature reaches specific
values.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
13
Please refer to the specific manual “Temperature Sensor in TMD-Display One”
(available at the Zennio homepage, www.zennio.com) for detailed information about
the functionality and the configuration of the related parameters.
2.2.3 SCREENSAVER
The screensaver is a special page that will only be shown after a period of inactivity,
configurable by parameter.
It is possible to configure the screensaver to only show the current Time, the current
Temperature (selecting the desired measurement source: the internal temperature
sensor or an external value) or both (alternating every 3 seconds).
Notes:
The temperature shown will be truncated to the range [-99ºC, 199ºC].
The time of day must be set through the bus by an external reference. In
addition, in the absence of power the clock will get outdated.
The screensaver disappears when any button is touched. It can be set by parameter
whether, while the screensaver is active, this press should simply cause the
screensaver interruption or, moreover –apart from hiding the screensaver–, the
execution of the action corresponding to the pressed button.
ETS PARAMETERISATION
This screen is divided into three parts: Activation, Content and Exit, containing the
following parameters:
Activation timeout: time to automatically show the screensaver after the last
button touch. Range: 1 – 255 seconds, minutes or hours.
Time of Day: sets whether to show the current time or not.
Temperature: sets whether to show the current temperature or not. When
enabled, the following parameter will show up:
Taken from: defines the source of the temperature value: “Internal sensor”
or “External reference”. The latter will bring a new two-byte object to the

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
14
project topology (“[General] Screensaver - External temperature”) so
that it the device can receive the required values from the bus.
Run button action on screensaver exit: sets whether touching a button while
the screensaver is active should cause the execution of the button action, apart
from hiding the screensaver.
Figure 6 General – Screensaver.
2.2.4 LEDs & DISPLAY
As anticipated in section 2.2, the integrator can configure the LEDs of the buttons to
make use of the pre-defined brightness levels or of user-defined levels.
To begin with, each LED can commute between two states: off (which not necessarily
means “no light”) and on (which not necessarily means “light on”). They will switch their
states according to the options explained in ANNEX I: LED Illumination Modes.
Moreover, the LEDs and the display can also commute between two operation modes:
the normal mode and the night mode. The second one is optional. It is provided for
temporary situations and environments where an excess of brightness may disturb the
user. In such cases, it will be possible to switch the mode by means of a one-bit object
and/or a scene object.
Note: a general parameter is provided to make the ETS parameterisation easier in
case the night mode is not required and the integrator feels comfortable with the default
on/off brightness levels.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
15
Regarding the display, it is possible to parameterise a contrast level in parameters. The
integrator can also enable an object to change the display contrast in real time.
ETS PARAMETERISATION
Figure 7 General – LEDs & Display config.
After selecting “Custom” for “LEDs and Display config.” (see section 2.2.1), a new tab
will be incorporated into the tree on the left.
The parameters shown in Figure 7 are equivalent to those for the “Default”
configuration of parameter “LEDs and Display config.”.
The upper section of this new screen is for the LED brightness configuration while the
lower is for the display brightness configuration.
LED Brightness Levels
Normal Mode:
LEDs: OFF level brightness: values between 0 (default) and 255.
LEDs: ON level brightness: values between 0 and 255 (default).
Display: Brightness: values between 0 and 10 (default).
Night Mode: in case of being this mode necessary, this checkbox needs to
be marked, which will incorporate some new parameters:
LEDs: OFF level brightness: values between 0 and 255 (1 by default).
LEDs: ON level brightness: values between 0 and 255 (8 by default).
Display: Brightness: values between 0 and 10 (default).

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
16
Figure 8 General – LEDs & Display – LED Brightness.
In case of enabling the night mode, some more options can be configured:
Control object: 1 bit: when marked, it will be possible to switch the mode by
writing to a binary object (“[General] LEDs & Disp - Brightness Mode”). A
specific drop-down list will show up to select which value should trigger which
mode (“0 = Normal; 1 = Night” or “0 = Night; 1 = Normal”).
Control object: Scene: when marked, it will be possible to switch the mode
by writing a certain scene value to “[General] Scene: Receive”. Two specific
textboxes will show up to enter what scenes (1 through 64) will trigger each
mode.
Idle time to change to Night Mode (0=disabled): when the time set in this
parameter elapses, TMD-Display One will switch to Night Mode (provided
that it was not already in this mode). The range is 0 to 65535 seconds (0 by
default).
Brightness Mode after ETS download: sets which of the two modes
(“Normal” or “Night”) will be active after an ETS Download.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
17
Display
Figure 9 General – LEDs & Display – Display configuration.
Display contrast level: value to set the display contrast level, from 1 to 10 (7
by default).
Object for changing the contrast level: enables a one-byte object
(“[General] Display - Contrast”) to change the display contrast level in real
time.
2.2.5 SOUNDS
Apart from the behaviour of the LEDs, it is possible to make TMD-Display emit a brief
beep as an acoustic feedback in two situations:
When a button is pressed: short beep indicating that the user has pressed a
button. This only applies to step controls, i.e., controls that walk through a
certain range of values and that do not send a value after every touch, but
only the final value after the last press.
When an action has been triggered: sharper beep than the above one,
indicating that a value is being sent to the KNX bus.
Enabling and disabling the button sounds can be done in parameters or through an
object, being also possible to define in parameters whether the button sounds should
be initially enabled or not.
With independence of the aforementioned button sounds, TMD-Display One can also
emit doorbell (a single beep on request) and alarm (a sequence of brief beeps with a
higher pitch) sounds on the reception of certain values through specific objects. The
alarm sequence will only stop when the alarm object gets deactivated or when the user
touches any of the buttons (this will not trigger any action, only the alarm deactivation).
Note that doorbell requests are ignored while the alarm is active.
A general parameter is provided to make the ETS parameterisation easier in case the
doorbell and alarm functions are not required and the integrator feels comfortable with

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
18
the default button beeps. On the other hand, customising the button, doorbell and
alarm sounds involves a set of parameters, as explained next.
ETS PARAMETERISATION
In case the default button beep sound matches the requirements of the installation and
the doorbell and alarm functions are not necessary, the “Sounds” parameter in the
general Configuration tab (see section 2.2.1) can be set to “Default”. This will also
imply that the button beeps will be unconditional, as it will not be possible to disable
this function through an object.
On the other hand, if set to “Custom”, a specific tab named “Sounds” will show up in
the tab tree on the left. The initial configuration of this screen is equivalent to the
aforementioned default option. However, the following parameters will be configurable.
Figure 10 General – Sounds.
Disable button sound: enables or disables the button and action beeps. If
enabled (default option) the following parameters will also be available:
Enable / Disable button sounds through a 1-bit object: makes it
possible to disable / resume the button beeping function in runtime by
writing to a specific object (“[General] Sounds – Disabling button
sound”).
The values (0 or 1) that will disable / resume it are parameterisable
through “Value”.
Button sound after ETS Download: sets whether the button beeping
function should start up enabled (default option) or disabled after an ETS
download. This makes sense if the “Enable/Disable Button Sounds
Using 1-Bit Object” checkbox (see below) is enabled too.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
19
Object for doorbell: enables or disables the doorbell function. If enabled, a
specific object (“[General] Sounds: Doorbell”) will be included into the
project topology. The value that will trigger the sound (1 or 0) must be set in
“Value”.
Object for alarm bell: enables or disables the alarm function. If enabled, a
specific object (“[General] Sounds: Alarm”) will be included into the project
topology. The values (1 or 0) that will trigger the alarm sequence and then
stop it must be entered in “Value”.
2.2.6 ADVANCED
As stated in section 2.2.1, an independent tab for the parameterisation of some
advanced functions is shown in ETS if enabled from the “Configuration” tab.
These functions are explained next.
ETS PARAMETERISATION
The “Advanced” tab (Figure 11) contains the following parameters:
Translations: enables or disables the “Translations” tab in the tree on the
left. See section 2.2.7 for details.
Touch locking: enables or disables the “Touch locking” tab in the tree on the
left. See section 2.2.8 for details.
Cleaning function: enables or disables the “Cleaning function” tab in the tree
on the left. See section 2.2.9 for details.
Figure 11 General - Advanced.

TMD-Display One
http://www.zennio.com Technical Support: http://zennioenglish.zendesk.com
20
Welcome greeting on the display: enables or disables the “W elcome
greeting” tab in the tree on the left. See section 2.2.10 for details.
Welcome back object: enables or disables the “Welcome back” tab in the
tree on the left. See section 2.2.11 for details.
Central touch area: enables or disables the “Central area” tab in the tree on
the left. See section 2.2.12 for details.
Hide explanation texts: displays or hides the explanation texts on the top of
the parameter screen of some functions. Experienced users may prefer to
hide these texts to have simpler parameter screens.
Hide INFO parameters: displays or hides the INFO textboxes on the top of
the parameter screen of each parameterisable control. These textboxes have
no functionality – they are offered for the convenience of the integrator, as
they allow assigning a description to each control, which may be useful in
case of later re-parameterisation of the project.
Figure 12 “Info” Textboxes.
2.2.7 TRANSLATIONS
The texts shown on the display (labels of the boxes, enumerated controls, welcome
messages, and any other texts set by parameter) can be translated into up to 5
different languages.
The language selection is performed through 3 types of communication objects:
Up to five one-bit objects, one for each language. When receiving a “1”
through one of them, the corresponding language is activated, if enabled
(otherwise the main language is activated).
A one-byte scene object. The values expected by this object are fixed from
0 to 4, to select the corresponding language. W hen receiving the value of a
non-enabled language, the main language will be activated. When the
received value is out of range, the active language remains unchanged.
