Safety Information
Your safety and the safety of others are very important.
We have provided many important safety messages in this
manual for your appliance. Always read and obey all safety
messages.
This is the Safety Alert Symbol. This symbol alerts you to
potential hazards that can cause severe bodily injury or death.
All safety messages will follow the Safety Alert Symbol and either
the words “DANGER” “WARNING” or “CAUTION”
DANGER
Danger means that failure to heed this safety statement may
result in severe injury or death.
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the manufacturer.
b) Before servicing or cleaning unit, switch power o at service
panel and lock the service disconnecting means to prevent
power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
General Safety
WARNING
Warning means that failure to heed this safety statement
may result in extensive product damage, serious personal
injury, or death.
CAUTION
Caution means that failure to heed this safety statement
may result in minor or moderate personal injury, property or
equipment damage.
WARNING
To reduce the risk of fire or electric shock, do not use this fan
with any solid-state control device.
WARNING
CAUTION
For General Ventilating Use Only. Do Not Use To Exhaust
Hazardous Or Explosive Materials And Vapors. Take care
when using cleaning agents or detergents. Suitable for use in
household cooking area.
WARNING
WARNING - TO REDUCE THE RISK OF A RANGE TOP GREASE
FIRE:
a) Never leave surface units unattended at high settings.
Boilovers cause smoking and greasy spillovers that may ignite.
Heat oils slowly on low or medium settings.
b) Always turn hood ON when cooking at high heat or
when flambeing food. (i.e. Crepes Suzette, Cherries Jubilee,
Peppercorn Beef Flambe’).
c) Clean ventilating fans frequently. Grease should not be
allowed to accumulate on fan or filter.
d) Use proper pan size. Always use cookware appropriate for
the size of the surface element.

5
Cypress Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Safety Information
WARNING
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF INJURY TO PERSONS
IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING:
a) SMOTHER FLAMES with a close-fitting lid, cookie sheet, or
metal tray, then turn o the burner. BE CAREFUL TO PREVENT
BURNS. If the flames do not go out immediately, EVACUATE AND
CALL THE FIRE DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN – You may be burned.
c) DO NOT USE WATER, including wet dishcloths or towels – a
violent steam explosion will result.
d) Use an extinguisher ONLY if:
1) You know you have a Class ABC extinguisher, and you
already know how to operate it.
2) The fire is small and contained in the area where it
started.
3) The fire department is being called.
4) You can fight the fire with your back to an exit
Based on “Kitchen Firesafety Tips” published by NFPA.
WARNING
WARNING
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
CAUTION
To reduce risk of fire and to properly exhaust air outside, do
not vent exhaust air into spaces within walls, ceilings, attics,
crawl spaces, or garages.
WARNING
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable codes and
standards, including fire-rated construction.
b) Sucient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of fuel burning
equipment to prevent back drafting. Follow the heating
equipment manufacturer’s guideline and safety standards such
as those published by the National Fire Protection Association
(NFPA), and the American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE), and the local code
authorities.
c) When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
d) Ducted fans must always be vented to the outdoors.
e) If this unit is to be installed over a tub or shower, it must be
marked as appropriate for the application and be connected
to a GFCI (Ground Fault Circuit Interrupter) - protected branch
circuit.
WARNING
Prop. 65 Warning for California Residents: This product may
contain chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.

6Cypress Use, Care, and Installation Guide
CYPRESS
WALL
PRO
Safety Information
Operation
►Always leave safety grilles and filters in place. Without these components, operating blowers could catch onto hair, fingers and
loose clothing.
►The manufacturer declines all responsibility in the event of failure to observe the instructions given here for installation,
maintenance and suitable use of the product. The manufacturer further declines all responsibility for injury due to negligence and
the warranty of the unit automatically expires due to improper maintenance.
NOTE: Please check www.zephyronline.com for revisions before doing any custom work.
Electrical Requirements
Important:
►Observe all governing codes and ordinances.
►It is the customer’s responsibility to be aware of these below:
►To contact a qualified electrical installer.
►To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA 70 latest
edition* or CSA standards C22.1-94, Canadian Electrical Code, Part 1 and C22.2 No.0-M91 - latest edition** and all local codes
and ordinances.
►If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path
is adequate.
►Do not ground to a gas pipe.
►Check with a qualified electrician if you are not sure the range hood is properly grounded.
►Do not have a fuse in the neutral or ground circuit.
►This appliance requires a 120V 60Hz electrical supply and connected to an individual properly grounded branch circuit protected
by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire with ground. Please also refer to Electrical Diagram
on product.
►A cable locking connector (not supplied) might also be required by local codes. Check with local requirements, purchase and
install appropriate connector if necessary.
* National Fire Protection Association Batterymarch Park, Quincy, Massachusetts 02269
** CSA International 8501 East Pleasant Valley Road, Cleveland, Ohio 44131-5575
►Intended for outdoor covered patio or lanai area.
►Suitable for use in damp locations when installed in a GFCI protected branch circuit.
READ AND SAVE THESE INSTRUCTIONS

7
Cypress Use, Care, and Installation Guide
ZEPHYRONLINE.COM
List of Materials
Parts Not Supplied
Ducting, conduit and all installation tools
Cable locking connector (if required by local codes)
12" duct cover accessory (36" models) (AK0736BS)
12" duct cover accessory (42" models) (AK0742BS)
12" duct cover accessory (48" models) (AK0748BS)
12" duct cover accessory (52" models) (AK0754BS)
Duct cover extension (Z1C-0178)
Wood board to hang hood (W x D x H)
Parts Supplied
Quantity Part
1 Hood
2 Pro bae filters (36" & 42" models)
3 Pro bae filters (48" & 54" models)
2 LumiLight LED (36" & 42" models)
4 LumiLight LED (48" & 54" models)
3 10" round starting collar
2 Top cover plate (for horizontal ducting)
1 Hardware package
M6 x 1” (4)
M6 x 1-1/2” (4)
M6 x 2” (4)
M4 x 8 (4) Wire Caps (3)
3/16 x 3/8 (4)

8Cypress Use, Care, and Installation Guide
CYPRESS
WALL
PRO
Installation Instructions
Duct pieces To tal
Equivalent number
length x used =
3- 1/ 4” x 10”
Rect.,
straight
1 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. to
6” round
transition
5 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. to
6” round
transition
900 elbow
20 Ft. x ( ) =Ft.
6”, 7”, 8”, 10”
Round,
900
15 Ft. x ( ) =Ft.
6”, 7”, 8”, 10”
Round,
450
9 Ft. x ( ) =Ft.
Ft.
6”, 7”, 8”, 10”
Round,
straight
1 Ft. x ( ) =Ft.
Subtotal column1 =
Duct pieces To tal
Equivalent number
length x used =
6”, 7”, 8”, 10”
Round, wall
cap with
damper
30 Ft. x ( ) =Ft.
Ft.
Ft.
Ft.
6”, 7”, 8”, 10”
Round
roof cap
30 Ft. x ( ) =Ft.
Subtotal column2 =
Subtotal column1 =
Total ductwork =
Maximum Duct Length: For satisfactory air movement,
the total duct length
should not exceed 150 equivalent feet.
6” round to
3- 1/ 4” x 10”
rect.
transition
1 Ft. x ( ) =Ft.
6” round to
3- 1/ 4” x 10”
rect.
transition
900 elbow
16 Ft. x ( ) =Ft.
7” round to
3 1/ 4” x 10”
rect.
transition
8 Ft. x ( ) =Ft.
7” round to
3- 1/ 4” x 10”
rect.
transition
900 elbow
23 Ft. x ( ) =Ft.
elbow
elbow
7” to 6” or
8” to 7” Round
tapered
reducer
25 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. 900
elbow
15 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. 450
elbow
9 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect. 900
flat elbow
24 Ft. x ( ) =Ft.
3- 1/ 4” x 10”
Rect.
wall cap
with damper
30 Ft. x ( ) =Ft.
Ft. x ( ) =Ft.
15
6”, 7“, 8”
Round
in-line
damper
Ducting Calculation Sheet

9
Cypress Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Mounting Height, Clearance, & Ducting
36” 30” min.
36” max.
A minimum of 10” round duct is recommended to
maintain maximum air flow eciency.
Always use rigid type metal ducts only. Flexible
ducts could restrict air flow by up to 50%.
Also use the ducting calculation sheet (on page
8) to compute total available duct run when using
elbows, transitions and caps.
ALWAYS, when possible, reduce the number or
transitions and turns. If long duct run is required,
increase duct size.
If turns or transitions are required; install as far
away from hood duct output and as far apart,
between the two as possible.
Minimum mount height between range top to hood
bottom should be no less than 30”.
Maximum mount height should be no higher than
36”.
It is important to install the hood at the proper
mounting height. Hoods mounted too low could
result in heat damage and fire hazard; while hoods
mounted too high will be hard to reach and will lose
its performance and eciency.
If available, also refer range manufacturer’s height clearance requirements and recommended hood
mounting height above range. Always check your local codes for any dierences.
For shipment and installation damages:
►Please fully inspect unit for damage before installation.
►If the unit is damaged in shipment, return the unit to the store in which it was bought for repair or
replacement.
►If the unit is damaged by the customer, repair or replacement is the responsibility of the customer.
►If the unit is damaged by the installer (if other than the customer), repair of replacement must be
made by arrangement between customer and installer.

10 Cypress Use, Care, and Installation Guide
CYPRESS
WALL
PRO
Installation Instructions
Ducting Options
►Use single wall rigid metal ductwork only.
►Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct
Tape.
Fire Hazard: NEVER exhaust air or terminate ductwork into
spaces between walls, crawl spaces, ceilings, attics, or garages.
All exhaust must be ducted to the outside, unless using the
recirculating option.
WARNING
Roof pitch w/
flashing & cap
Sot or crawl space
Side wall cap
w/ gravity damper
Rear ducting

11
Cypress Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Hood Specications
Top View Side View
Back View
Ducting & Electrical Dimensions
15”
32”
4”
18”
11-9/16”
1-3/4”
1-1/16”
11-9/16”
6-1/16”
10-3/8”
14-3/16”
2-5/8”
Ø 9-15/16”
10-3/8”
4-5/16”
11-9/16”
10-3/4”
10-3/8”
14-3/16”
Ø 9-15/16”
1-11/16”
35 7/8” (36”)
41 7/8“ (42”)
47 7/8” (48”)
53 7/8” (54”)
C/L
C/L
Back View
Mounting Dimensions
16-7/8”
16-1/8”
13-5/8”
1-11/16”
3-5/16”
21-1/4”
35-1/4” (42”, 48”, 54”)
5-5/16”
50.5˚
Optional Telescopic
Duct Cover
Z1C-0178
Min. - 48”
Max. - 75”
29”
15”
21-3/4”
29”

12 Cypress Use, Care, and Installation Guide
CYPRESS
WALL
PRO
Installation Instructions
Electrical Supply
Electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards. Turn o
electrical power at service entrance before wiring.
WARNING
For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not
use extension cord or adapter plug with this appliance.
Follow national electrical codes or prevailing local codes and ordinances.
This appliance requires a 120V 60Hz electrical supply, and connected to an individual, properly
grounded branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring
must be 2 wire w/ ground. Please also refer to the Electrical Diagram labeled on product.
Cable Lock
A cable locking connector (not supplied) might be required by local codes. Check with local
requirements and codes, purchase and install appropriate connector if necessary. (FIG. A)
Cable Lock
FIG. A

13
Cypress Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Mounting the Hood
1. Select preferred ducting application (vertical or
horizontal) and prepare hood. Refer to page 14
for horizontal ducting conversion.
2. Plum and mark center line on wall.
3. Choose desired height above cooking surface
(30” min). Level and mark hood bottom, line A
(FIG. B).
4. Level and mark top of wood board, line B (FIG.
B) 16 7/8” from line A.
5. Mark center line of wood board. Center and
align top of board with line B. Secure wood
board to studs using (4) M6 wood screws.
Wood Board Dimensions: (W x D x H)
AK7836CS - 33” x 1/2” x 4”
AK7842CS - 39” x 1/2” x 4”
AK7848CS - 45” x 1/2” x 4”
AK7854CS - 51” x 1/2” x 4”
6. Prepare duct pipe and duct cut outs in upper
cabinet if needed or wall if horizontally ducting
hood. Prepare electrical wiring and electrical
cut outs in upper cabinet if needed or wall
if horizontal electrical hook up is required.
Refer to hood specifications on page 11 for
dimensions.
7. Mount hood onto wood board and secure using
(4) M6 wood screws.
8. Further secure hood onto wall through lower
FIG. B
C/L
C/L
A
B
16-7/8”
min
30”
4”
wood board
16-7/8”
16-1/8”
13-5/8”
1-11/16”
3-5/16”
21-1/4”
35-1/4” (42”, 48”, 54”)
5-5/16”
body screw holes by (2) M6 wood screws. See dimensions in FIG. C.
9. Install electrical. Install duct work and seal with certified aluminum duct tape.
10. Power up hood and check for leaks around duct tape.
11. Install pro bae filters.
FIG. C
C/L
C/L
A
B
16-7/8”
min
30”
4”
wood board
16-7/8”
16-1/8”
13-5/8”
1-11/16”
3-5/16”
21-1/4”
35-1/4” (42”, 48”, 54”)
5-5/16”

14 Cypress Use, Care, and Installation Guide
CYPRESS
WALL
PRO
Installation Instructions
Horizontal Ducting Conversion
This range hood is equipped with a 10" round vertical duct option by default. To convert from 10"
round vertical to 10" round horizontal ducting, please follow the instructions below.
1. Disconnect blower plug.
2. Remove (4) screws from interior
of hood body attaching blower
plate to top of hood body.
Remove blower and blower plate.
3. Knock out plate A for dual blower
horizontal ducting.
A

15
Cypress Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Horizontal Ducting Conversion
4. From inside hood body, position
top cover plate to top of hood
body. From outside hood body,
attach top cover plate to top of
hood body using (4) 3/16 x 3/8
screws.
5. Position dual blower plate onto
interior back wall mounting
brackets inside hood body.
Attach by (4) screws previously
removed from step 2. Re-connect
blower plug.
6. Attach 10 inch round blower collar
to back of hood using (4) M4 x 8
screws.

16 Cypress Use, Care, and Installation Guide
CYPRESS
WALL
PRO
Features & Controls
Rotary Controls
OFF
OFF
OFF
1
2
3
1
2
1 Blower On/O/Speed Selection
2 Lights Dim/Bright/O
1 Blower On/O/Speed Selection
2 Lights Dim/Bright/O
Rotate dial to change speed levels, (1) for low speed, (2) for medium speed and (3)
for high speed.
Rotate dial to change light settings, (1) for dim light and (2) for bright light.

17
Cypress Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Maintenance
Hood & Filter Cleaning
Surface Maintenance
►Do not use corrosive detergents, abrasive detergents or oven cleaners.
►Do not use any product containing chlorine bleach or any product containing chloride.
►Do not use steel wool or abrasive scrubbing pads which will scratch and damage surface.
Cleaning Stainless Steel
Clean periodically with warm soapy water and clean cotton cloth or micro fiber cloth. Always rub
in the direction of the stainless steel grain. To remove heavier grease build up use a liquid degreaser
detergent.
After cleaning use a non-abrasive stainless steel polish/cleaners, to polish and bu out the stainless
luster and grain. Always scrub lightly, with clean cotton cloth or micro fiber cloth and bu in the
direction of the stainless steel grain.
Cleaning the Pro Bae Filters
The stainless steel pro baffle filters are intended to trap residue and grease from cooking. Although
the filters should never need replacing, they are required to be cleaned every 30 days or more often
depending on cooking habits.
Filters may be placed in dishwasher at low heat or soaked in hot soapy water Dry filters and re-install
before using hood.
If this hood is installed in a salt water area (e.g. coast), rinse all
surfaces once a week with clear water even if the hood is not
used. Wipe and dry completely after rinsing.
CAUTION

18 Cypress Use, Care, and Installation Guide
CYPRESS
WALL
PRO
Maintenance
Removing Pro Bae Filters, FIG. D
1. Push filter away from front of range hood using handles.
2. Pivot front of filter downward.
3. Remove filter by pulling away from hood.
Replacing Pro Bae Filters
Hood Model Part Number Qty. to Order
AK7836CS 50210031 2
AK7842CS 50210031 2
AK7848CS 50210031 3
AK7854CS 50210031 3
.
1
2
3
FIG. D
LumiLight LED
In the unlikely event that your LumiLight LED fails, please contact Zephyr to order replacement parts.
See the list of parts and accessories page for part numbers and contact information.
LED Removal, FIG. E
1. Remove grease filters.
2. (If applicable) remove both side spacer panels
for each spacer panel.
3. Remove screws on light panel.
4. Disconnect LED light quick connector.
5. Push in the two side clips on the ends of the
LED light.
6. Push LED light through the light panel opening.
Push the clip
FIG. E

19
Cypress Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Wiring Diagram
AK7836CS, AK7842CS,
AK7848CS, AK7854CS
Wiring Diagram
Volts Hz Max Amps
120 60 Dual Motor 9
REMARKS: CONDENSER 22uF / 250VAC 2PCS FIT AC120V 60Hz
Motor
Motor
Green
Body
Green
Body
Red
Yellow
Blue
Brown
Grey
White
Blue
Brown
Grey
White
Red Yellow
Blue
Brown
Grey
Red
Black
White
B/W
B/W
B/W
Body
Green
Black
White
For 48” and 54”
models only

20 Cypress Use, Care, and Installation Guide
CYPRESS
WALL
PRO
Troubleshooting
Possible Problem Possible Cause Solutions
After installation, the
unit doesn’t work.
The power source is not turned
ON.
Make sure the circuit breaker and the
unit’s power is ON.
The power line and the cable
locking connector is not
connecting properly.
Check the power connection with the
unit is connected properly.
The switch board wirings are
disconnected.
Make sure the wirings at the switch
board are connected properly.
The switch board is defective. Change the switch board.
Light works, but
blower is not turning.
The blower wire is not connected. Make sure the blower wire is plugged
into the molex connector.
The thermally protected system
detects if the blower is too hot
to operate and shuts the blower
down.
The blower will function properly after
the thermally protected system cool
down.
Damaged capacitor. Change the capacitor.
The blower is defective, possibly
seized.
Change the blower.
The unit is vibrating. The blower is not secured in place. Tighten the blower in place.
Damaged blower wheel. Replace the blower.
The hood is not secured in place. Check the installation of the hood.
The unit is whistling. A filter is not in the correct
position.
Adjust the filters until the whistling stops.
The duct pipe connections are not
sealed or connected properly.
Check the duct pipe connections to be
sure all connections are sealed properly.
The blower is working,
but the LumiLight
LEDs are not.
The LumiLight LED connector is
disconnected.
Connect the LumiLight LED connector.
Defective LumiLight LED. Change the LumiLight LED.
The switch board is defective. Change the switch board.
